EN
Quick Guide
THANK YOU FOR PURCHASING A HOTPOINT PRODUCT.
To receive more comprehensive assistance, register the
appliance on
www.hotpoint.eu/register
Before using the appliance carefully read the Health and Safety guide.
Before using the machine, it is imperative that the transport bolts are removed. For more
detailed instructions on how to remove them, see the Installation Guide.
CONTROL PANEL
WASH CYCLE TABLE
Note: spin speed values shown on the display can slightly differs from the values stated in the table.
For all testing institutes:
2) Long cotton cycle: set programme 5 at temperature 40°C.
3) Long synthetics cycle: set cycle 6 at a temperature of 40°C.
* By selecting the cycle and excluding the spin cycle, the washer-dryer will drain only.
** The duration of the programme is shown on the display.
*** After programme end and spinning with maximum selectable spin speed, in default
programme setting.
**** The display will show the suggested spin speed as default value.
For wash programmes with temperatures above 50°C, we recommend using powder detergent
rather than liquid, and following the directions given on the detergent package.
This data may dier in your home due to changing conditions in inlet water temperature,
water pressure etc. Approximate programme duration values refer to the default setting of
the programmes, without options.
The values given for programmes other than the Eco 40-60
programme are indicative only.
For all Test Institutes
1)
Eco 40-60 (Wash)- Test wash cycle in compliance with EU Ecodesign regulation 2019/2014. The most
efficient programme in terms of energy and water consumption for washing normally soiled cotton
laundry.
4) Eco 40-60 (Wash&Drying)-
Test
wash&
drying cycle in compliance with EU Ecodesign
regulation
2019/2014
. To access “wash and dry” cycle select “Eco 40-60” wash programme
and set “Drying” option level to
“ ”.
The most ecient programme in terms of energy and
water consumption for washing and drying normally soiled cotton laundry. At the end of cycle
the garments can be immediately stored to the cupboard.
Maximum load 9 kg
Power input in o mode 0.5 W / in left-on mode 8 W
Detergents and
Additives
Recommended
detergent
Residual
dampness %
(***)
Energy
consumption
kWh
Total water lt
Laundry
temperature °C
Wash cycle
Temperature
Maximum
spin
(r.p.m.)
Max. load
for wash
cycle (kg)
Max. load
for drying
cycle (kg)
Duration
(h : m)
Drying
Wash
Fabric
softener
Powder Liquid
Setting Range 2 3
1 Mixed Wash&Dry 40 °C 40 °C 800 3,5 3,5 **
–
– – – –
2 Shirts and T-shirts 40 °C 40 °C 1000 2,0 2,0 **
–
– – – –
3 Pre Iron – – – 2,0 – ** – – – – – – – – –
4 Steam Refresh – – – 2,0 – ** – – – – – – – – –
5 Cotton (2) 40 °C
- 60 °C
1400 9,0 6,0 3:55
49 1,4 105 45
6 Synthetics (3) 40 °C
- 60 °C
1200 4,0 4,0 2:55
35 0,8 55 43
7 Anti Stain Quick 40 °C
- 40 °C
1200 4,5 4,5 **
–
– – – –
8 Anti Stain 40° 40 °C
- 40 °C
1400 9,0 6,0 **
–
– – – –
9 White 60 °C
- 90 °C
1400 9,0 6,0 2:45
49 0,9 90 55
10
Eco 40-60 (1)
(Wash)
40 °C 40°C
1351 9,0 6,0 3:40
53,5 0,86 54 38
1351 4,5 3,0 2:50
53,5 0,68 54 37
1351 2,25 – 2:10
53,5 0,46 40 34
11 20°C 20 °C
- 20 °C
1400 9,0 6,0 1:50
–
49 0,2 90 22
12 Delicates 30 °C
- 30 °C
600
(****)
1,0 1,0 **
–
– – – –
13 Wool 40 °C
- 40 °C
800 2,0 2,0 **
–
– – – –
14 Rapid 30‘ 30 °C
- 30 °C
1200
(****)
4,5 - 0:30 –
–
71 0,2 45 27
Rinse & Spin – – 1400 9,0 6,0 –
–
– – – – – –
Spin & Drain * – – 1400 9,0 6,0 –
– – – – – – – –
Required dosage Optional dosage
10
Eco 40-60 (4)
(Wash&Drying)
40 °C 40 °C
1351 6,0 6,0 9:20
0 3,80 75 33
1351 3,0 3,0 5:10
0 1,98 47 32
1. ON/OFF button
2. START/PAUSE button
3. TEMPERATURE button
4. ENERGY SAVER button
5. DRY ONLY button / Lock
button
6. DRYING SETTINGS button
7. START DELAY button
8. SPIN SPEED button
9. WASH CYCLE SELECTOR KNOB
1 2
5
6
7
8
4
3
9
DISPLAY INDICATORS
Washing phase
Indicates washing phase of the cycle
Drying phase
Energy Saver activated
Key lock activated
Drying only
Time drying mode
Drying automatic levels
Start delay activated
Door locked
PRODUCT DESCRIPTION
1. Worktop
2. Detergent dispenser
3. Control panel
4. Door handle
5. Door
6. Water lter
7. Adjustable feet (4)
DETERGENT DISPENSER
Compartment 1:
Do not insert detergent in this compartment.
Compartment 2: Washing detergent
(powder or liquid)
Compartment 3: Additives (fabric softeners,
etc.)
The fabric softener must not exceed the “MAX”
level.
! Use powder detergent for white cotton
garments, for pre-washing, and for washing at
temperatures over 60°C.
! Follow the instructions given on the detergent packaging.
1
2
3
1.
3.
2.
5.
4.
6.
7.
! This symbol reminds you to read this instruction manual.
