EN
DETAILED
INSTRUCTIONS FOR USE
OF REFRIGERATOR
2
829705
We thank you for the confidence you have shown by purchasing
our appliance which is designed to simplify your life. To make the use of the
product easier, we have supplied detailed instructions for use, and installation
instructions supplied on a separate sheet. The instructions should allow you to
learn about your new appliance as quickly as possible.
We wish you find a lot of pleasure in its use.
The appliance is intended solely for household use.
The refrigerator is intended for storing fresh food at temperatures above 0°C.
Please visit our website where you can enter your appliance model number,
indicated on the rating plate or the warranty sheet, to find detailed description
of your appliance, tips on use, troubleshooting, service information, instructions
for use etc.
Important safety warning
General information and tips
i
Protecting the environment
!
Do not wash in the dishwasher
3
CONTENTS
829705
INTRODUCTION
APPLIANCE
DESCRIPTION
DEFROSTING
AND CLEANING
THE APPLIANCE
4 IMPORTANT NOTES AND PRECAUTIONS
4 BEFORE USING THE APPLIANCE FOR THE FIRST TIME
5 IMPORTANT SAFETY INSTRUCTIONS
8 IMPORTANT INFORMATION ON THE USE OF APPLIANCE
9 ENVIRONMENT PROTECTION
10 ADVICE FOR SAVING POWER WITH REFRIGERATION
APPLIANCES
11 INSTALLATION AND CONNECTION
13 APPLIANCE DESCRIPTION
14 OPERATING THE APPLIANCE
19 APPLIANCE INTERIOR EQUIPMENT
23 RECOMMENDED DISTRIBUTION OF FOOD IN THE
APPLIANCE
24 STORING FOOD IN THE REFRIGERATOR
29 STORING FOOD IN THE FreshZone DRAWER
30 DEFROSTING THE APPLIANCE
31 CLEANING THE APPLIANCE
32 TROUBLESHOOTING
34 INFORMATION ABOUT APPLIANCE NOISE
MISCELLANEOUS
STORING AND
FREEZING FOOD
4
829705
IMPORTANT NOTES AND
PRECAUTIONS
Before connecting the appliance to the power mains, please
read carefully the instructions for use which describe the
appliance and its correct and safe use. The instructions
apply to several appliance types/models; thus, settings or
equipment may be described herein which is not available
in your appliance. We recommend saving this instruction
manual for future reference and attach it to the appliance if
it is sold in the future.
Check for any damage or irregularities on your appliance. If
you find your appliance is damaged, notify the retailer from
which you have purchased the appliance.
Before connecting the appliance to the power mains, let
the appliance rest in a vertical position for a minimum of 2
hours. This will reduce the possibility of operation faults due
to the effect of transport on the cooling system.
BEFORE USING THE APPLIANCE FOR
THE FIRST TIME
i
5
829705
The appliance must be connected to the power mains and
grounded in compliance with the effective standards and
regulations.
WARNING! Do not locate multiple portable socket-outlets
or portable power supplies at the rear of the appliance.
Before cleaning the appliance, unplug it from the power
mains (unplug the power cord from the wall outlet).
WARNING! If the supply cord is damaged, it must be
replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
WARNING! When positioning the appliance, ensure the
supply cord is not trapped or damaged.
If LED lighting does not work, call a service technician. Do
not attempt a repair of the LED lighting yourself, as there is
danger of contact with high voltage!
IMPORTANT SAFETY INSTRUCTIONS
!
WARNING! Do not use any electric devices inside the
appliance, except for those allowed by the manufacturer
of this refrigeration appliance.
WARNING! Do not use mechanical devices or other
means to accelerate the defrosting process, other than
those recommended by the manufacturer.
WARNING! To avoid any hazard resulting from poor
stability of the appliance, make sure it is installed as
instructed.
!
!
!
WARNING! Risk of fire/flammable materials.
6
829705
Danger of frostbite
Never put frozen food in your mouth and avoid touching
frozen food as this may cause frostnip or frostbite.
Safety of children and vulnerable persons
The appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not
play with the appliance.
Cleaning and user maintenance shall not be made by
children without supervision.
Cleaning and user maintenance shall not be made by
children without supervision.
Remove the packaging intended to protect the appliance
or particular parts during transport and keep it outside the
reach of children.
It presents danger of injury or suffocation.
For European markets only
This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by
children without supervision.
7
829705
Children aged from 3 to 8 years are allowed to load and
unload refrigerating appliances.
Warning regarding the refrigerant
The appliance contains a small amount of an
environmentally friendly yet flammable gas R600a. Make
sure that no parts of the cooling system are damaged. A
gas leak is not hazardous to the environment, but it could
cause eye injury or fire.
In case of a gas leak, ventilate the room thoroughly,
disconnect the appliance from the power mains, and call a
service technician.
8
829705
The appliance may not be used outdoors and it may not be
exposed to rain.
Do not store explosive substances such as aerosol cans
with a flammable propellant in this appliance.
If the appliance will be out of use for an extended period of
time, switch it off using the relevant button, and unplug it
from the power mains. Empty the appliance, defrost it, clean
it, and leave the door ajar.
In case of an error or power supply failure, do not open the
freezer compartment unless the freezer has not operated
for over 16 hours. After this period, use the frozen food or
provide sufficient cooling (e.g. a replacement appliance).
IMPORTANT INFORMATION ON THE USE
OF APPLIANCE
WARNING! Keep ventilation openings, in the
appliance enclosure or in the built-in structure, clear of
obstruction.
WARNING! This appliance is intended to be used in
household and similar applications such as:
– staff kitchen areas in shops, offices and other working
environments;
- farm houses and by clients in hotels, motels and other
residential type environments;
- bed and breakfast type environments;
- catering and similar non-retail applications.
i
9
829705
The symbol on the product or its packaging indicates that the product
should not be treated as normal household waste. The product should be
taken to an authorized collection centre for waste electric and electronic
equipment processing. Correct disposal of the product will help prevent
any negative effects on the environment and health of people which could
occur in case of incorrect product removal. For detailed information on
removal and processing of the product, please contact the relevant municipal
body in charge of waste management, your waste disposal service, or the
store where you bought the product.
Packaging is made of environmentally friendly materials
that can be recycled, disposed of, or destroyed without any
hazard to the environment.
!
Removing an obsolete appliance
To protect the environment, take the obsolete appliance to
an authorized home appliance collection centre.
Before doing so, do the following:
• disconnect the appliance from the power mains;
• do not allow children to play with the appliance.
ENVIRONMENT PROTECTION
WARNING! Do not damage the refrigerant circuit.
This will also prevent pollution.
Technical information on the appliance
Rating plate can be found in the appliance interior. It
indicates data on voltage, gross and net volume, type
and amount of refrigerant, and information on the climate
classes.
If the language on the rating plate is not the language of
your choice or the language of your country, replace it with
the one supplied.
i
10
ADVICE FOR SAVING POWER
WITH REFRIGERATION
APPLIANCES
829705
• Install the appliance as specified in the instruction manual.
• Do not open the door more often than necessary.
• Occasionally make sure air circulation underneath the appliance is
unobstructed.
• Condenser unit on the rear wall should be kept clean (see chapter Cleaning the
appliance).
• If the gasket is damaged or does not provide a perfect seal for any reason,
have it replaced as soon as possible.
• Store the food in tightly sealed containers or appropriate packaging.
• Before placing the food in the refrigerator, allow it to cool down to room
temperature.
• Defrost frozen food in the refrigerator compartment.
• To make use of the entire freezer compartment interior volume, remove
some of the drawers as described in the instruction manual.
• Defrost your conventional freezer when an approximately 3–5 millimetre
layer of frost or ice has built up on the refrigerated surfaces.
• Make sure the layout of shelves in the compartment is uniform and that
the food is placed so that the air can freely circulate in the appliance
interior (observe the recommended placement of food as described in the
instructions).
• In appliances with a fan, do not block the fan slots or vents.
• If you do not need the fan or the ionizer, switch them off to reduce power
consumption.
11
829705
INSTALLATION AND CONNECTION
SELECTING THE ROOM
• Install the appliance in a dry and well ventilated room. The appliance will operate
correctly if the environment temperature is in the interval specifi ed in the table. The
appliance class is indicated on the rating plate / label with the basic information on
the appliance.
Class Temperature Relative Humidity
SN (subnormal) from +10 °C to +32 °C
75%
N (normal) from +16 °C to +32 °C
ST (subtropical) from +16 °C to +38 °C
T (tropical) from +16 °C to +43 °C
• Do not place an appliance in a room where temperature can drop to
below 5 °C as this may cause abnormal appliance operation or failure!
i
• After the installation, the appliance mains plug should be accessible!
• Do not place the appliance near appliances or devices radiating heat, such as
a cooker, a stove, a radiator, water heater etc., and do not expose it to direct
sunlight. The appliance should stand at least 3 cm away from an electric or gas
cooker or at least 30 cm away from an oil or solid fuel stove. If the distance
between such source of heat and the appliance is smaller, use an insulating
panel.
Note: Place the appliance in a su ciently large room. There should be at least 1
m
3
of space per 8 grams of refrigerant. Amount of refrigerant is indicated on the
rating plate in the appliance interior.
• At the base of the kitchen unit intended for building in the integrated
appliance, there should be at least 200 cm
2
free space, for adequate air
circulation.
On the upper part of the appliance the air is coming out, so try not to cover
the opening for the outfl ow air.
Ignoring this caution may result in damage to the appliance.
Note:
When installing the appliance side-by-side into kitchen cabinets, each appliance
should be integrated into a separate cabinet.
An anti-condensation service kit should be purchased, complete with a power
cord for connecting the kit to the power mains. An additional power socket is
required for connecting the anti-condensation service kit.
For safety reasons, the service kit may only be installed by an authorized
service technician!
12
829705
The process of changing the appliance door opening and integrating the
appliance into a cabinet is described on the separate installation instructions
supplied in the bag with the instruction manual.
CONNECTING THE APPLIANCE
• Connect the appliance to the power
mains using the power cord. The wall
outlet should be fi tted with a ground
contact (safety socket). Nominal
voltage and frequency are indicated
on the rating plate/label with basic
information on the appliance.
• The appliance must be connected
to the power mains and grounded
in compliance with the e ective
standards and regulations. The
appliance will withstand short-term
deviations from the nominal voltage,
but not more than +/- 6%.
CHANGING THE DOOR OPENING DIRECTION AND
INTEGRATING THE APPLIANCE INTO A CABINET
13
APPLIANCE DESCRIPTION
829705
1 Control unit
2 LED lighting
3 Fan with air ionizer
(+ on/off switch)
4 Bottle rack
5 Glass shelves
6 FreshZone drawer
7 CrispZone fruit and
vegetables drawer
with humidity control
8 Fruit and vegetables
drawer
9 Low door shelves
10 Bottle shelve
Appliance interior equipment may change according to the appliance model.
14
B
CD
A
OPERATING THE APPLIANCE
829705
To set the appliance temperature or activate extra functions, press the A key
successively. When the key is first pressed, the currently set value or function
will start to flash. With each successive press of the key, the indicator moves
to the next setting. The indicator cycles through the settings in a circular
manner, from right to left. While the settings are being adjusted, the display
will flash. Three seconds after the key is released, the setting will be stored
automatically and the relevant symbol will be lit.
A Appliance on/o , temperature settings, and extra function key
B Refrigerator temperature display
The indicator for the selected temperature will be lit.
C Intensive cooling (cooling boost) function indicator
The C symbol will be lit when the intensive cooling function is activated.
D High temperature or open door alarm indicator
15
829705
ADJUSTING THE TEMPERATURE IN THE APPLIANCE
SWITCHING THE APPLIANCE ON/OFF
Switching the appliance on: Press the
A key and hold it for 3 seconds.
Switching off the appliance: Again
press the A key and hold it for 3
seconds. The appliance will be off, but
there is still voltage in it as it is still
connected to the power mains.
• Adjust the temperature as desired
using the A key.
• Press the A key (several times) until
the desired temperature indicator
lights up.
• When the A key is pressed for the
fi rst time, the currently set value
or function will start to fl ash. Every
successive time you press the A key,
the settings indicator will move to
the next setting (from right to left, in
a circular manner).
• After three seconds, the setting
will stop fl ashing. Your setting will
be stored and the corresponding
indicator will be continuously lit.
• The factory default setting is the recommended temperature of 4 °C.
• After the appliance is switched on, it may take several hours for the set
temperature to be reached. Do not place any food into the refrigerator
before the temperature drops to the selected setting.
i
16
829705
INTENSIVE COOLING (COOLING BOOST) FUNCTION
To activate the intensive cooling
(cooling boost) function, press the A
key several times until the symbol C
lights up.
• Use this setting after switching on the appliance for the fi rst time, before
cleaning, or 24 hours before adding a large amount of food.
• If any other function is selected while the intensive cooling function is active,
the intensive cooling function will be deactivated immediately.
• To switch o the intensive cooling function, press the A key to select the
desired temperature (B). If the intensive cooling function is not deactivated
manually, it will be automatically switched o (after approximately six hours),
and the temperature will return to the most recently set value.
• If there is a power outage while the intensive cooling function is active, the
function will be restarted when power supply resumes.
• When the intensive cooling function is activated, the appliance will
operate with maximum power. During this time, operation may be
somewhat louder.
i
The numbers 2, 4, 6 and 8 indicate the
degrees Celsius (°C) in the appliance
refrigerator compartment.
• The recommended temperature
setting is +4 °C. At this temperature,
food quality and freshness are
preserved longer.
• If the temperature of the room where
the appliance is installed is below
16 °C, we recommend setting a
temperature lower than 4 °C.
17
829705
HIGH TEMPERATURE ALARM
If the temperature inside the appliance is
too high, acoustic alarm will be activated
(intermittent tone) and the D symbol will
flash.
• Every time the appliance is switched
on with the A key, there is a 24-
hour delay in high temperature
alarm operation. If the appliance
does not reach the su ciently low
temperature in this period, the alarm
will be activated.
Switching o the alarm:
• To acknowledge and switch o the acoustic alarm, press the A key. If the alarm
is not switched o , it will be sounded every 30 minutes for approximately 3
minutes.
• When you press the A key for the fi rst time, the alarm will be acknowledged
and turned o . When you press the A key again, it will already work as a
settings adjustment key.
• The D symbol fl ashes until the appliance reaches a suitable temperature.
18
829705
OPEN DOOR ALARM
If the refrigerator compartment door
is open for more than 2 minutes, an
acoustic alarm (repetitive beep) will
be activated. If the acoustic alarm
is not switched off, it will switch off
automatically after 10 minutes. The
appliance will continue to operate as if
the door was closed.
Switching off the alarm: To switch off the alarm, close the door.
If you switch off the alarm by pressing the A key, the alarm will be
reactivated in 4 minutes if the door is still open.
i
19
APPLIANCE INTERIOR
EQUIPMENT
(* EQUIPMENT DEPENDS ON THE MODEL)
829705
SHELF
WIRE BOTTLE RACK*
• Some models also feature a wire
bottle holder. It is protected against
being inadvertently pulled out. It can
only be pulled out when it is empty.
To pull it out, lift it slightly at the
back and pull it towards you. Place
the bottle holder so that the length
of the bottles does not prevent
proper closing of the door.
The holder can take a maximum load of nine 0.75-litre bottles or 13 kilograms
of total weight – see label on the right side in the appliance interior.
• Cans may also be placed on the bottle rack (lengthwise or crosswise).
• Empty shelves can be distributed
as you see fi t across the guides in
the refrigerator interior without
having to remove the shelf from the
refrigerator.
To only move the shelf to a di erent
height/guide, lift it at the front, hold
it at the back, and move it higher
or lower. To take the shelf from the
refrigerator, fi rst lift it at the front
part, hold it at the back part, and pull
it out from the appliance.
Store quickly perishable food at
the back of the shelf where the
temperature is the lowest.
20
829705
INTERIOR SIDE OF THE REFRIGERATOR DOOR
The shelves mounted on the interior side of the refrigerator door are intended
for storing cheese, butter, eggs, yoghurt and other smaller packages, tubes,
cans, etc. There is a bottle shelf at the lower end of the door.
FRUIT AND VEGETABLE BIN WITH
HUMIDITY CONTROL
• The bin at the bottom of the refrigerator is intended for storing fruit and
vegetables. It provides humidity and prevents the food from drying out. The
bin has integrated humidity regulator which allows setting the humidity level.
Slider position to the right: closed
vents, higher humidity in the bin
Slider position to the left: open vents,
lower humidity in the bin
If you observe droplets accumulating
below the glass shelf, open the vents
and wipe the shelf (see chapter
TROUBLESHOOTING).
• Pulling out the bin:
- Pull out the bin as far as it will go.
Then, lift the front part and pull it
out completely.
21
• MultiBox bin o ers a convenient way for storing food with a strong or pungent
smell, e.g. ripened or blue-vein cheese, sausages, onions, butter etc.
• The silicone lid provides an air-tight seal that prevents the food from drying
out and the odour to spread throughout the refrigerator compartment.
• The silicone lid can also be used as an egg or ice tray.
• If the fl exible lid is used as an egg tray, place it directly on the bottom of the
door bin and use the open lower part of the MultiBox bin to store food in
smaller packages – pâté, jams, smaller tubes etc.
Interior side of the refrigerator door is
fitted with shelves intended for storing
cheese, butter, eggs, yoghurt, and
other smaller packages, tubes, cans
etc.
Maximum load on each door shelf is 5
kg.
829705
ADJUSTABLE DOOR SHELVES
MultiBox STORAGE BIN*
22
• The fan placed under the refrigerator compartment ceiling will make sure the
temperature is distributed more evenly, and reduce condensation (dew) on the
storage surfaces.
It is activated automatically when there is need for more intensive cooking.
Innovative sensor technology allows adjusting appliance operation to the
user's habits or behaviour. Adaptive intelligent system monitors, analyzes, and
records on a daily and weekly basis the use of appliance and adapts appliance
operation to the perceived patterns. If the appliance is able to anticipate
increased frequency of door opening, the appliance will automatically lower
the temperature before such time to prevent the increase of food temperature
as the door is opened more often. The appliance will also anticipate adding
larger amounts of food into the refrigerator or freezer and adapt by cooling or
freezing more intensively.
PersonalSystem
Switching the ionizer on/o
On = I O = O
829705
FAN*
• Advanced fan system with dynamic cooling evenly distributes the ionized air
and equalizes the temperature throughout the entire refrigerator. Air enriched
with extra negative ions mimics the natural microclimate that keeps the food
fresh for longer. Moreover, the any type of food can be placed on any shelf in
the fridge as there are not temperature di erences.
• To switch the air ionizer on and o , use the switch located on the fan housing.
AIR IONIZER (IonAir)*
When the ionizer is switched on, a red dot will be visible on the switch.
23
RECOMMENDED DISTRIBUTION
OF FOOD IN THE APPLIANCE
829705
Sections in the refrigerator compartment:
- upper part: canned food, bread, wine, pastry etc.
- middle part: dairy products, ready-made meals, desserts, soft drinks, beer,
cooked food, etc.
- FreshZone bin: - meat, meat produce, delicatessen;
- Fruit and vegetable bin: fresh fruit, vegetables, salads, root vegetables,
potatoes, onions, garlic, tomatoes, sauerkraut, turnips etc.
Sections in the refrigerator
compartment door:
- upper/middle door bins: eggs,
butter, cheese etc.
- lower door bins: beverages, cans,
bottles
Do not store fruit (bananas,
pineapples, papaya, citruses) and
vegetables (zucchini, eggplant,
cucumbers, bell peppers,
tomatoes, and potatoes) sensitive
to low temperatures in the
refrigerator.
i
24
STORING FOOD IN THE
REFRIGERATOR
829705
IMPORTANT WARNINGS REGARDING FOOD STORAGE
i
Correct use of the appliance, appropriate packaging,
maintaining the right temperature, and observing the food
hygiene standards have a decisive impact on the quality
of food storage.
Observe the expiry dates for the food, indicated on the
packaging.
Food stored in the refrigerator should be kept in closed
containers or in appropriate packaging to prevent it from
emitting or receiving odours and humidity.
Do not store inflammable, volatile, and explosive
substances in the refrigerator.
Bottles with high alcohol content should be tightly sealed
and stored in an upright position.
Some organic solutions, essential oils in lemon and orange
peel, butter acid, etc. may damage the plastic surfaces
in case of a prolonged contact, causing damage and
premature ageing of these materials.
Unpleasant odour warns of lacking cleanliness of the
appliance or perished contents (see chapter Cleaning the
Appliance).
If you are leaving home for a longer period of time,
remove perishables from the refrigerator.
25
829705
AVOID CONTAMINATION OF FOOD
To avoid contamination of food, please respect the following instructions:
• Opening the door for long periods can cause a signifi cant increase of the
temperature in the compartments of the appliance.
• Regularly clean surfaces that can come in contact with food and accessible
drainage systems.
• Store raw meat and fi sh in suitable containers in the refrigerator, so that it is
not in contact with or drip onto other food.
• If the refrigerating appliance is left empty for long periods, switch o , defrost,
clean, dry, and leave the door open to prevent mould developing within the
appliance.
26
829705
STORING FOOD
TYPE OF FOOD Optimum
storage
temperature (°C)
Optimum
storage humidity
level (%)
Approximate
storage time
Pork -1 to 4 95 3 days
Beef 0 to 4 95 up to 3 weeks
Lamb 0 to 4 95 14 days
Chicken 0 to 4 95 3 days
Fish 0 to 4 95 3 to 10 days
Mollusc 0 to 4 95 2 days
Wet-aged beef 1,5 95 16 weeks
Dairy products
(yoghurt, sour
cream, butter,
soft cheese,
cheese spreads
etc.)
2 to 4 95 7 to 10 days
Beetroot 0 95 3 to 5 months
Broccoli 0 95-100 10 to 14 days
Cabbage, young 0 98-100 3 to 6 weeks
Carrots, ripe 0 98-100 4 to 5 months
Lettuce, winter 0 95-100 2 to 3 weeks
Garlic 0 65-70 6 to 7 months
Kohlrabi 0 98-100 2 to 3 months
Brussels sprouts 0 90-95 3 to 5 weeks
Cabbage,
Chinese
0 95-100 2 to 3 months
Cabbage, late
varieties
0 98-100 3 to 4 months
Carrots 0 95-100 2 weeks
Cauliflower 0 95-98 2 to 4 weeks
Celery, regular 0 98-100 2 to 3 months
Swiss chard 0 95-100 10 to 14 days
Radicchio 0 95-100 2 to 4 weeks
Corn, sweet 0 95-98 5 to 8 days
27
829705
TYPE OF FOOD Optimum
storage
temperature (°C)
Optimum
storage humidity
level (%)
Approximate
storage time
Leeks 0 95-100 2 to 3 months
Mushrooms 0 95 3 to 4 days
Parsley 0 95-100 2 to 3 days
Parsnip 0 98-100 4 to 6 months
Radish, winter 0 95-100 2 to 4 months
Horseradish 0 98-100 10 to 12 months
Cauliflower 0 to 2 90-95 2 to 4 weeks
Onions 0 to 2 65-70 6 to 7 months
Asparagus 0 to 2 95-100 2 to 3 weeks
Peas, green 0 to 2 95-98 1 to 2 weeks
Vegetables,
chopped
0 to 2 90-95 up to 5 days
Brussels sprout 0 to 2 90-95 1 to 2 weeks
Gooseberries 0 to 2 90-95 3 to 4 weeks
Cucumbers 4 to 10 95 10 to 14 days
Potatoes 7 to 10 90-95 up to 9 months
Avocado, unripe 7 to 10 85-95 up to 6 weeks
Bell peppers 7 to 10 90-95 2 to 3 weeks
Tomatoes 10 to 12 85-90 4 to 7 days
Beans, seeds < 15 40-50 6 to 10 months
Pears -3 90-95 2 to 7 months
Apricots -1 90-95 1 to 3 weeks
Strawberries 0 90-95 3 to 7 days
Raspberries 0 to 2 90-95 2 to 3 days
Currants 0 to 2 90-95 1 to 4 weeks
Blueberries 0 to 2 90-95 14 days
Cherries 0 to 2 90-95 2 to 3 weeks
Grapes 0 to 2 85 2 to 8 weeks
Kiwi, ripe 0 to 2 90-95 1 to 3 months
Peaches 0 to 2 90-95 2 to 4 weeks
28
829705
TYPE OF FOOD Optimum
storage
temperature (°C)
Optimum
storage humidity
level (%)
Approximate
storage time
Cherries 0 to 2 90-95 2 to 3 weeks
Kiwi, unripe 0 to 2 90-95 2 to 6 months
Nectarines 0 to 2 90-95 1 to 3 weeks
Oranges 0 to 2 90-95 2 to 4 weeks
Persimmon 0 to 2 90-95 2 to 3 months
Plums 0 to 2 90-95 2 to 5 weeks
Fruit, chopped 0 to 2 90-95 up to 10 days
Apples 0 to 4 90-95 1 to 12 months
Melons 4 90-95 15 days
Oranges 4 to 7 90-95 2 to 4 weeks
Tangerines 5 to 8 90-95 2 to 4 weeks
Mango 10 to 13 85-95 2 to 3 weeks
Melons 10 to 13 85-95 1 to 2 weeks
Pineapples 10 to 13 85-95 2 to 4 weeks
Lemons 11 to 13 90-95 2 to 3 weeks
Watermelon 12 to 15 85-95 1 to 3 weeks
Bananas, ripe 13 to 16 85-95 3 days
Grapefruit 13 to 16 90-95 1 to 3 weeks
29
STORING FOOD IN THE
FreshZone DRAWER
829705
In the FreshZone compartment, food stays fresh longer than in a conventional
refrigerator, retaining more flavour and nutrients.
Decay and loss of mass are slowed down; therefore, fruit and vegetables remain
fresh and natural longer. For optimum performance, the drawer should be fully
closed.
• When buying food, make sure it is fresh as this will determine the quality of
the food, as well as how long it will keep in the fridge.
• Store the food in closed containers or appropriate packaging to prevent it
from emitting or receiving odours.
• Take the food from the drawer 30 to 60 minutes before use to allow the aroma
and fl avour develop at room temperature.
• Food sensitive to low temperature and not appropriate for storage in the
FreshZone drawer includes the following: pineapples, avocado, bananas,
olives, potatoes, eggplant, cucumbers, beans, peppers (capsicum), melons,
watermelons, pumpkins, squash, zucchini etc.
• To remove the drawer:
- Pull out the drawer until it is
blocked.
- Then, lift it at the front and pull it
all the way out.
(Only in some models)
30
DEFROSTING THE APPLIANCE
829705
Refrigerator does not need defrosting because the ice on the back interior wall
is thawed automatically.
Any accumulated ice will melt when the compressor unit is inactive. Drops will
flow through an opening in the refrigerator rear wall into a tray fitted above the
compressor, from where they will evaporate.
Make sure the opening in the back wall in the refrigerator interior is never
blocked by food or any other object.
If an excessive layer of ice is formed on the rear wall of refrigerator interior (3–5
mm), switch off the appliance and defrost the appliance manually.
AUTOMATIC REFRIGERATOR DEFROSTING
31
CLEANING THE APPLIANCE
829705
• Use a soft cloth to clean all surfaces. Cleaners that contain abrasive
substances, acids, or solvents are not suitable for cleaning as they may
damage the surface.
Clean the appliance exterior with water or a mild solution of suds.
Lacquer-coated and aluminium surfaces may be cleaned with lukewarm water
to which you have added a mild detergent. Use of cleaners with low alcohol
content is allowed (e.g. window cleaners). Do not use cleaners containing
alcohol for cleaning plastic materials.
• A gutter and an opening for discharging
the water from thawed frost deposits are
located underneath the cooling panel
that cools the refrigerator interior. The
gutter and the opening may not be
clogged. Inspect them often and clean if
necessary (e.g. with a plastic straw).
• Frost or ice build-up, 3–5 mm thick,
will increase power consumption.
Therefore, it should be regularly
removed. Do not use any sharp
objects, solvents, or sprays.
• The condenser unit mounted on the
(exterior) back wall should always be
kept clean, free of dust or deposits
resulting from kitchen smoke or
fumes. Occasionally clean the dust
using a soft non-metal brush or a
vacuum cleaner.
• After cleaning, switch the appliance
back on and insert the food.
Appliance interior can be cleaned with lukewarm water to which you
can add some vinegar.
Before cleaning, unplug the appliance from the power mains – switch off the
appliance (see chapter Switching the Appliance On/Off) and unplug the power
cord from the wall outlet.
!
• Do not wash the parts of appliance interior equipment in a dishwasher as
they may be damaged.
32
TROUBLESHOOTING
Problem: Cause or remedy:
Appliance is connected
to the power mains but
it does not work.
• Make sure there is voltage in the power outlet and
that the appliance is switched on.
Cooling system
operates continuously
for a long period of
time:
A
• Too high environment temperature.
• Door opened too frequently or too long.
• Door not closed correctly (possible impurities on
the seal, misaligned door, damaged seal etc.).
• Too much fresh food inserted at once.
• Sensor in the refrigerator (A) blocked by fresh
food. Make sure the air can circulate around the
sensor (only with some models).
• Insufficient compressor and condenser unit
cooling. Check for sufficient air circulation behind
the appliance and clean the condenser unit.
Excessive build-up of
ice on the back wall
of refrigerator interior
can be a result of the
following:
• Door opened too frequently or too long.
• Warm food placed in the refrigerator.
• Food or containers in contact with the back
interior wall of the refrigerator.
• Poor door sealing.
• If the seal is dirty or damaged, clean or replace it.
Condensate (dew) on
the shelf above the
drawers:
• This is transient phenomenon which cannot be
entirely avoided in periods of high environment
temperature and humidity. It subsides when
temperature and humidity are normalized. We
recommend cleaning the drawers more frequently
and wiping the droplets occasionally.
• Open the humidity control slider.
• Put food in bags or other packaging with a good
seal.
Water is dripping/
leaking from the
refrigerator:
• Clogged water discharge opening or water
dripping past the water gutter.
• Clean the blocked opening, e.g. using a plastic
straw.
• If a thick layer of ice builds up, defrost the
appliance manually (see Defrosting the Appliance).
829705
33
Problem: Cause or remedy:
Indicator D flashes: • Door opened too frequently or too long.
• Door not closed correctly (possible impurities on
the seal, misaligned door, damaged seal etc.).
• An extended power failure.
• Too much fresh food inserted at once.
Door is difficult to open: • If you are trying to open the refrigerator door after
just having closed it, this could be difficult to do.
As you open the door, some cool air escapes from
the appliance and it is replaced by warm air from
the environment. When this air is cooled, negative
pressure is generated which results in problems as
you try to open the door. After a few minutes, the
condition is normalized and the door can be easily
opened again.
LED lighting does not
work:
• If LED lighting does not work, call a service
technician.
• Do not attempt a repair of the LED lighting
yourself, as there is danger of contact with high
voltage!
If the above tips do not resolve your problem, call the nearest authorized service
centre and state the type, model, and serial number indicated on the appliance
rating plate or label located in the appliance interior.
829705
34
INFORMATION ABOUT
APPLIANCE NOISE
829705
Cooling in refrigerator freezers is made possible by a cooling system that also
includes a compressor (and a fan with some appliances), which generates some
noise. The level of noise depends on installation, proper use, and age of the
appliance.
• After connecting the appliance to the power mains, compressor operation,
or the sound of fl owing liquid, may be somewhat louder. This is not a sign
of malfunction and it will not a ect the useful life of the appliance. In time,
appliance operation and this noise will become quieter.
• Sometimes, unusual or loud noises may appear during appliance operation;
these are mostly the result of improper installation:
- The appliance must stand level and stable on a solid base.
- The appliance may not be in contact with a wall or adjacent furniture.
- Make sure the interior equipment sits firmly in its place and that the noise is
not caused by rattling cans, bottles or other containers placed next to each
other.
• Due to the higher workload on the cooling system when the door is opened
more frequently or for a longer time, when a large amount of fresh food is
introduced or when intensive freezing or cooling functions are activated, the
appliance can temporarily generate more noise.
WE RESERVE THE RIGHT TO CHANGES THAT DO NOT AFFECT THE
APPLIANCE FUNCTIONALITY.
COOLER BI540 ADV SME en (05-20)
