Installation Instructions
GSM1800JBB, Black Trim Kit
GSM1800JWW, White Trim Kit
GPF18
Series Kits
Before you begin - Read these instructions completely and carefully.
IMPORTANT: Save these instructions for local inspector's use.
IMPORTANT: OBSERVE ALL GOVERNING CODES AND ORDINANCES.
NOTE TO INSTALLER: Be sure to leave these instructions with the Consumer.
NOTE TO CONSUMER: Keep these instructions with your Owner's Manual for future reference.
To prevent electric shock, disconnect electrical
power supply to dishwasher before changing
panels. Do not operate dishwasher while
changing panel.
CAUTION
The dishwasher will tip over when the door is opened. Hold the
top of the dishwasher securely with one hand and hold the door
with the other hand.
The GPF18 trim kits provide for the installation of a 1/4" thick
custom door panel.
This kit includes:
STEP 1 CUT 1/4" THICK CUSTOM PANEL TO SIZE
Cut door panel to the dimensions shown in Figure 1.
NOTE: The trim provided will conceal the cut edges of the
panel.
1/4" Thick
Door Panel
22-1/8"
17-1/4"
Figure 1
Fully Assembled Door Panel Frame
Tools and Materials Required:
Phillips screwdriver
Gloves to protect against sharp edges
Safety glasses
