GEConsumer & Industrial Appliances
Assembl Instructions
Advantium ®Built-in Accessory Storage
J×2200, J×2201, Z×2201
Drawer
BEFORE YOU BEGIN
Readthese instructions completely and carefully. Read
the Installation Instructions for the Advantium 120V or
2q0v oven completely and carefully for cutout dimen-
sions and step-by-step instructions.
IMPORTANT- savetheseinstructionsfor
local inspector's use.
IMPORTANT- Observeallgoverningcodes
and ordinances.
• NOTE TO INSTALLER: Be sure to leave these
instructions with the Consumer.
• NOTE TO CONSUMER: Keep these instructions with
your Advantium 120V or 240V Oven Owner's Manual
for future reference.
• SKILL LEVEL: Installation of this appliance requires
basic mechanical skills.
• COMPLETION TIME: One hour with the installation
of an Advantium 120V or 240V oven.
• Proper installation is the responsibility of the installer.
• Product failure due to improper installation is not
covered under the Warranty. See the Advantium
120V or 240V Oven Owner's Manual for warranty
information.
MODELS AVAILABLE
Profile Models:
JX2200BB-Black
JX2201SS-Stainless Steel
Monogram Models:
ZX2201SS-Stainless Steel (for installation above 36" only)
NOTE:Advantium 240V model ZSC2202SS and
Advantium 120V model ZSC1202 CANNOT be
installed with an accessory storage drawer. See
Installation Preparation Without an Accessory Storage
Drawer in the Installation Instructions for these models.
PRODUCT DIMENSIONS AND CLEARANCES
Allow 15"Clearance
WhenFullyOpen
NOTE:Appearance will vary by model.
TOOLS REQUIRED
• #2 Phillipsscrewdriver
PARTS SUPPLIED
• Sidesupports(2) • Under-the-Counter
• Brassscrews (8) Mounting Bracket(1)
• Color-matched screws(5)
| REMOVE PACKAGING AND PARTS
• Remove the drawer from the carton.
• Remove oil packing material and tape.
• Open the drawer and remove any parts inside.
• Locate parts.
Assembly
Instructions
SideSupports(2)
AssemblyInstructions
Under-the-C0unter(UTC)
MountingBracket
Screws C010r-Matched
(6required, Screws
2 extra) (4required,
1extra)
SPECIFICATIONSSUBJECTTO CHANGE WITHOUT NOTICE MFL06213304 49-40594 12-08 JR
