Bagless Vacuum Cleaner
User's manual
EN
EN-1
Before first use, please read all instructions contained in this user's manual carefully, even if you are already
familiar with using similar products. Only use this product in accordance with the instructions described in the
user's manual. Keep the manual for future use.
Save the original packaging, including the internal packing material, warranty card and proof of purchase receipt,
at least for the duration of the warranty. If you need to ship this product, pack it in the original cardboard box
to ensure maximum protection during shipping or transport (e.g. when moving or when you need to send this
product for repair).
2019 05/2019
SVC 510GR / SVC 511TQ
SVC 512VT („Allegro“)
EN-2
EN
Bagless Vacuum Cleaner
SVC 510GR / SVC 511TQ / SVC 512VT (Allegro)
2019 05/2019
CONTENTS
IMPORTANT SAFETY NOTICE .............................................................. 3
DESCRIPTION OF THE VACUUM CLEANER .................................................... 6
VACUUM CLEANER ASSEMBLY ............................................................ 7
VACUUM CLEANER OPERATION ........................................................... 7
VACUUM CLEANER ACCESSORIES ......................................................... 8
VACUUM CLEANER STORAGE ............................................................ 9
CLEANING AND MAINTENANCE ........................................................... 9
TROUBLESHOOTING ................................................................... 13
TECHNICAL SPECIFICATIONS ............................................................. 13
INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF USED PACKAGING MATERIALS ....... 14
DISPOSAL OF USED ELECTRICAL AND ELECTRONIC EQUIPMENT .................................. 14
Bagless Vacuum Cleaner
SVC 510GR / SVC 511TQ / SVC 512VT (Allegro)
EN
EN-3
2019 05/2019
IMPORTANT SAFETY NOTICE
READ CAREFULLY AND STORE FOR FUTURE USE.
• Thisvacuumcleanermaybeusedbychildren8years
of age and older and by persons with physical or
mental impairments or by inexperienced persons, if
they are properly supervised or have been informed
abouthowtousethisvacuumcleanerinasafemanner
and understand the potential dangers. Children
must not play with the vacuum cleaner. Cleaning
and maintenance performed by the user must not be
performed by unsupervised children. Keep the vacuum
cleaner and its accessories out of reach of children that
areyoungerthan8yearsofage.
• This vacuum cleaner is designed for use in households,
ofcesandsimilartypesofareas.Donotuseinindustrial
surroundings.
• Do not expose the vacuum cleaner to direct sunlight
anddonotplaceitnearanopenreorappliancesthat
areasourceofheat.
• Beforeconnectingthepowercordtoapowersocket,
check that the technical details on the vacuum
cleaner’s rating label match the electrical voltage in
thesocket.
• Makesurethepowercordisnottouchingahotsurface
or sharp objects.
• Do not submerge the vacuum cleaner under water
or any other liquid and do not rinse it under running
water.
EN-4
EN
Bagless Vacuum Cleaner
SVC 510GR / SVC 511TQ / SVC 512VT (Allegro)
2019 05/2019
• Beforeturningonthevacuumcleaner,makesurethat
the dust bag is inserted inside and that the inow
micro-lterandtheoutowlterareinstalledintheir
place.
• When the vacuum cleaner is running, ensure that the
airoutletsandthesuctionopeningarenotblocked.
• Donotusethevacuumcleanertovacuumthefollowing
items:
–
smouldering cigarettes, burning items, matches or embers;
– water and other liquids;
– ammableorvolatilematerials;
– sharpitems,e.g.brokenglass,needles,pins,etc.;
– our, wall plaster, cement and other building
materials;
– larger pieces of paper or plastic bags, which can
easilyblockthesuctionopening.
• Vacuuming of some types of oors or oor surfaces
cancreateaelectrostaticdischarge,whichpresentsno
danger to the user.
• Do not place the suction nozzle or tube against any
parts of the face.
• Always turn off the vacuum cleaner and disconnect
it from the power socket when leaving it without
supervision,afternishingusingitandbeforecleaning
it.
• Disconnect the power cord from the power socket
by pulling on the plug, never pulling on the cord.
Otherwise, this could damage the power cord or
the socket. Hold the power cord in your hand when
winding it up.
Bagless Vacuum Cleaner
SVC 510GR / SVC 511TQ / SVC 512VT (Allegro)
EN
EN-5
2019 05/2019
• In the event that the power cord is damaged, it
must be replaced by an authorised service centre or
by a similarly qualied person, this will prevent the
creationofadangeroussituation.Itisforbiddentouse
thevacuumcleanerifithasadamagedpowercord.
• Do not use the vacuum cleaner if it is not working
correctly, if it has been damaged or has been submerged
inwater.Donotrepairthevacuumcleaneryourselfor
makeanyadjustmentstoit.Haveallrepairsperformed
at an authorised service centre. By tampering with the
appliance, you risk voiding your legal rights arising
from unsatisfactory performance or quality warranty.
EN-6
EN
Bagless Vacuum Cleaner
SVC 510GR / SVC 511TQ / SVC 512VT (Allegro)
2019 05/2019
DESCRIPTION
A
1 START/STOP button
2 Dust container safety latch
3 Dust container handle
4 Vacuum hose connection hole
5 Vacuum cleaner handle
6 Cord winding button
7 Rubber wheel
8 Dust container
9 Handle
q; Sliding knob for air suction
qa Two-part plastic tube
qs Floor inlet nozzle
qd Flap position for vacuuming
hard (smooth) floors
qf Flap position for vacuuming
carpets
qg Hose
qh Stopper for the horizontal
parking position
qj Locking lugs
qk Hose end
1
2
3
4
5
6
7
8
9
q;
qa
qs
qf
qd
qj
qh
qg
qk
B
1 Motor power output control
2 Horizontal parking position
3 Outflow micro-filter cover
4 Power cord
1
2
3
4
Bagless Vacuum Cleaner
SVC 510GR / SVC 511TQ / SVC 512VT (Allegro)
EN
EN-7
2019 05/2019
C
1 Handle
2 Front wheel mechanism
3 Vertical parking position
4 Motor air inlet
1
2
3
4
ASSEMBLY
Inserting the hose into the air suction hole on the vacuum cleaner:
Insert the hose end into the hole in the vacuum cleaner and turn it so that both lugs on the hose end lock in.
Thehose is now secured in correct position.
Attach the holder to the tube:
Make sure to place the holder with the hose on the wider part of the tube.
Attach the floor inlet nozzle to the tube:
Place the oor nozzle on to the narrower part of the tube and place the second part of the tube on to it.
USING YOUR VACUUM CLEANER
Connecting your vacuum cleaner to the electrical power grid
Pull the plug attached to the power cord out from the vacuum cleaner until the desired length of the cord is out
of the product. Insert the plug into the power socket.
Caution:
Yellow marking on the power cord warns that the power cord is close to its end. Do not pull
the cord further than the red marking.
Adjusting the floor inlet nozzle according to the floor surface.
You may set the inlet nozzle according to the oor surface by adjusting the inlet ap:
• If you want to vacuum carpets, close the bristles of the inlet inside the inlet nozzle, by turning the ap
accordingly.
• If you want to vacuum hard and smooth surfaces, move the bristles out of the nozzle, by turning the ap
accordingly.
EN-8
EN
Bagless Vacuum Cleaner
SVC 510GR / SVC 511TQ / SVC 512VT (Allegro)
2019 05/2019
Turning your vacuum cleaner on and off
To switch your machine on or off, press the START / STOP button on the vacuum cleaner body.
Adjusting the suction strength
The suction strength may be adjusted by moving the rider on the vacuum cleaner body ( small range) or by the
moveable rider on the hose handler.
Tips
• Use the maximum suction strength when vacuuming carpets or floors with ahard surface. Use
the reduced strength when vacuuming upholstery, window curtains, etc.
• If the hose holder becomes blocked when vacuuming, disconnect it from the tube and also
disconnect the hose from the vacuum cleaner body. Then place the holder inside the suction hole
on the vacuum cleaner body and vacuum the stuck dirt out.
Temporary interruption of the vacuuming process
If you want to temporarily stop vacuuming, you can use one of the so-called parking positions, into which you
slide the stopper on the oor nozzle together with the tube and hose (pic. A16).
Attention:
Do not move the vacuum cleaner from place to place if the hose is in the parked position! It may
break off or the lug for the floor nozzle may break off.
USING YOUR ACCESSORIES
D
1
2
3
4
1
2
3
4
1 Slot nozzle for vacuuming in hard to reach places (e.g. windows, corners, book shelves, areas between
mattresses, upholstery, etc.)
2 Upholstery nozzle
3 Brush nozzle
Bagless Vacuum Cleaner
SVC 510GR / SVC 511TQ / SVC 512VT (Allegro)
EN
EN-9
2019 05/2019
Ending the vacuuming process
When you nish vacuuming, switch the vacuum cleaner off by pressing the START / STOP button and then
disconnect the power plug from the socket.
To wind the power cord back to the vacuum cleaner, press and hold the winding button with one hand. Hold the
cord with your other hand to protect the vacuum cleaner input area from damage
Tip:
If the winding process stops and part of the power cord is still outside, release the winding button and
pull the cable out again by about 50 cm and press the winding button again and repeat the winding
process.
Carrying your vacuum cleaner
It is possible to hold and carry the vacuum cleaner using the handle (pic. A5) or the handle at the front of the
vacuum cleaner (pic. C1).
Caution:
Never try to carry your vacuum cleaner by holding the dust container handle!
STORAGE OF VACUUM CLEANER
Before storage you can disassemble your product to each individual part or you can store it assembled with the
tube stored in one of the parking positions.
CLEANING AND MAINTENANCE
Caution:
Before cleaning disconnect this product from the power source.
Emptying the dust container
Empty the dust container as soon as the air ow and the suction power of the vacuum cleaner decline.
1) Press the safety lock (pic. E1) and pull the dust container handle (pic. E2) up at the same time to remove the
dust container from the vacuum cleaner.
2) Place the dust container over awaste bin.
3) Press the clip on the ip-out lid (pic. E3) on the dust container and carefully remove the lid.
4) In the same way tip out the dust and dirt from the dust container into ordinary household waste. If the
container is heavily soiled you may wash the entire container under lukewarm running water. However,
before doing so, it is necessary to remove the H.E.P.Alter and its foam pre-lter from the container!
5) If the plastic conical lter becomes heavily soiled (pic. F1), we recommended that you wash the lter under
astrong water current in the shower.
6) Place the ends of the lid against the dust container and tilt the lid back so that it clicks into place.
7) Place the dust container back into the vacuum cleaner.
Caution:
Before replacing the dust container and the plastic conical filter back into the vacuum cleaner,
make sure that all parts are completely dry.
EN-10
EN
Bagless Vacuum Cleaner
SVC 510GR / SVC 511TQ / SVC 512VT (Allegro)
2019 05/2019
E
1 Dust container safety
latch
2 Dust container handle
3 Dust container lid clip
1
2
3
F
1 Head of the plastic conical
filter
2 Dust container handle
3 Dust container clip
4 Dust container lid clip
1
2
3
4
Replacing and cleaning the H.E.P.A. lter and the foam pre-lter
1) Press the safety clip and pull the dust container handle up at the same time to remove the dust container
from the vacuum cleaner.
2) Pull the clip (pic. G2) to take out the H.E.P.A. lter, pulling it towards yourself from the dust container and
also take out the foam pre-lter located behind it.
3) Wash both lters under running lukewarm water and if necessary replace with new ones.
4) Then rst insert the foam pre-lter and afterwards the H.E.P.A. lter.
5) Place the dust container back into the vacuum cleaner.
Bagless Vacuum Cleaner
SVC 510GR / SVC 511TQ / SVC 512VT (Allegro)
EN
EN-11
2019 05/2019
G
1 H.E.P.A. filter
2 Safety clip for the H.E.P.A. filter
2
1
H
1 Dust container
2 Foam pre-filter
3 H.E.P.A. filter
1
2
3
Attention:
Never insert the filters back into the vacuum cleaner if they are wet or damp! Always wait until
they are thoroughly dry. The dust container is equipped with asafety, which in the absence of
the H.E.P.A. filter will not make it possible to insert the dust container into the vacuum cleaner.
EN-12
EN
Bagless Vacuum Cleaner
SVC 510GR / SVC 511TQ / SVC 512VT (Allegro)
2019 05/2019
Changing the outow lter
I
1 Outflow micro-filter cover
2 Cover clip
3 Outflow micro-filter
4 Compartment for outflow
micro-filter and grill
1
2
3
4
1) First take off the grill of the outow lter by pressing the clip while pulling the entire grill towards yourself.
2) Wash outow micro-lters under running lukewarm water and if necessary replace with new ones.
3) After reinserting the outow micro-lters, attach the cover and click in the clip.
Caution:
Never insert the filters back into the vacuum cleaner if they are wet or damp! Always wait until
they are thoroughly dry.
Cleaning your vacuum cleaner.
To clean the outside parts of the product use a ne cloth dipped in lukewarm water. Do not use aggressive
cleaning agents, paint thinners or solvents. Using these solutions could damage the surface of the product.
Bagless Vacuum Cleaner
SVC 510GR / SVC 511TQ / SVC 512VT (Allegro)
EN
EN-13
2019 05/2019
TROUBLESHOOTING
Before you decide to contact an authorized service centre, please read these following tips in the
troubleshooting chart:
Problem Possible cause Recommended action
The engine will not start - The power cord is not firmly
inserted in the socket
- The wall power outlet is
damaged
- The vacuum cleaner is not
switched on
- Insert the plug firmly into the power
outlet
- Inspect the power outlet
- Turn the product on.
The suction output is insufficient - The product is clogged
- The dust filter needs cleaning.
- The dust container is inserted in
the wrong position
- The filter is clogged
- Remove the blockage or foreign
object
- Clean the dust filter
- Close the dust container
- Clean the filter
The power cord is not wound in
completely
The power cord may have slipped
down from the winding pulley
during winding.
Hold the power cord during the
winding. Apply slight tension (by
pulling the power cord back) to the
power cord during the winding process
The power cord cannot be pulled
out
The power cord is wound up
incorrectly
Press the winding button and try to
rewind the power cord again
The speed control is not
working.
The product is out of order Have the product repaired by
technician.
(only by aqualified technician).
The power cord starts to wind in
when you do not required.
The winding mechanism is out
of order
Have the product repaired by
atechnician.
(only by aqualified technician).
The dust container cannot be
closed
The dust filter is inserted incorrectly
or in an incorrect position
Reinstall and secure the filter in
position and try again
TECHNICAL SPECIFICATIONS
Nominal voltage ........................................................................................................................220 – 240 VAC
Nominal frequency ....................................................................................................................................50Hz
Rated power input ................................................................................................................................... 890W
Safety class (with regard to electric shock protection) ........................................................................................ II
Noise level ........................................................................................................................................... 76dB(A)
Length of the power cord ............................................................................................................................5m
Operating range .......................................................................................................................................7.5m
Dust container capacity .............................................................................................................................. 1.5l
Dimensions (length
×
width
×
height) .............................................................................. 330
×
277
×
225mm
Weight .................................................................................................................................................... 3.5kg
The declared noise emission level of the appliance is 76 dB(A), which represents alevel Aof acoustic power with
respect to areference acoustic power of 1 pW.
Amendments to text and technical parameters are reserved.
EN-14
EN
Bagless Vacuum Cleaner
SVC 510GR / SVC 511TQ / SVC 512VT (Allegro)
2019 05/2019
INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF USED
PACKAGING MATERIALS
Dispose of packaging material at apublic waste disposal site.
DISPOSAL OF USED ELECTRICAL AND ELECTRONIC APPLIANCES
The meaning of the symbol on the product, its accessory or packaging indicates that this product
shall not be treated as household waste. Please, dispose of this product at your applicable
collection point for the recycling of electrical & electronic equipment waste. Alternatively in
some states of the European Union or other European states you may return your products to
your local retailer when buying an equivalent new product. The correct disposal of this product
will help save valuable natural resources and help in preventing the potential negative impact on
the environment and human health, which could be caused as aresult of improper liquidation
of waste. Please ask your local authorities or the nearest waste collection centre for further
details. The improper disposal of this type of waste may fall subject to national regulations for
nes.
For business entities in the European Union
If you wish to dispose of an electrical or electronic device, request the necessary information
from your seller or supplier.
Disposal in other countries outside the European Union
If you wish to dispose of this product, request the necessary information about the correct
disposal method from local government departments or from your seller.
This product meets all the basic EU regulation requirements that relate to it.
Changes to the text, design and technical specications may occur without prior notice and we reserve the
right to make these changes.
