ELECTRONIC OVEN CONTROL
Control Pad Functions
Read the instructions carefully before using the oven. For satisfactory use of your oven, become familiar with the
various functions of the oven as described below. Note: The graphics on your timer may not look exactly like those
shown. This doesn't change the way it operates.
Note: The time of day must first be set in order to operate the oven. J
BAKEPAD--Used to
selectthe bakefunction.__
BROIL PAD-- Used
to select the variable --
broil function.
TIMER ON/OFF PAD-- Used to set
or cancelthe minute timer. The
minute timer doesnot start or stop
cooking.
UP and DOWN ARROW
along with the
function pads to select oven
temperature, time of day,
clean time and minute timer,
CLOCK SET PAD--- Used to
set the time of day.
\
OFF/CANCEL-- Usedto clear any function
previouslyentered except the time of dayand
minute timer. PushOFF/CANCELto stop
cooking.
Setting the Clock and Minute Timer
To Set the Clock
When the range is first plugged in, or when the power supply to the range has been interrupted, the display will flash
"12:00".
1. PressCLOCK SET pad.
2. Within5sec_nds_pressandh__dtheUP_rD_WNARR_wpadunti_thec_rrecttime_fdayappearsinthedisplay.
To Set the Minute Timer:
1. PressTIMER ON/OFF pad.
2. Pressthe UP ARR_W pad t_ increase the time in _ne minute increments. Pressand h__dthe UP ARR_W pad t_ increase
the time in 10 minute increments. The timer can be set for any amount of time from 1 minute to 11 hours and 59
minutes.
Note: If you press the DOWN ARROW pad first, the timer will advance to 11 hours and 59 minutes.
3. The display shows the timer count down in minutes until one minute remains. Then the display will count down in
seconds.
4. When the set time has run out, the timer will sound a 3 second beep. 0:00 will appear in the display until TIMER ON/
OFF pad is pressed.
Note: While the minute timer is counting down, the ":" will flash. The minute timer
does not start or stop cooking. It serves as an extra timer in the kitchen that will beep
when the set time has run out. The minute timer can be used alone or during any of
the other oven functions. When the minute timer is in use with any other function,
the minute timer will be shown in the display. To view other functions, press the pad
for that function.
To Change the Minute Timer while it is in use:
While the timer is active and shows in the display, press and hold the UP or DOWN
ARROW pad to increase or decrease the time.
To Cancel the Minute Timer before the set time has run out: PressTIMER ON/OFF.
1
Versibn en espafiol
Sideseaobtener unacopiaen
espafiol de este Manual del
Usuario, sirvaseescribir a la
direccibn que se incluye a
continuacibn, Solicite la P/N
318204015.
Spanish Owner's Guides
Frigidaire Company
P.O. Box9061
Dublin, Ohio 43017-0961
318200140(0104)Rev. A
