User Manual Dyson 349352-01 V7 Cord-free Vacuum Cleaner

Dyson 349352-01 V7 Cord-free Vacuum Cleaner - Use Manual - Use Guide PDF.
Documents: Go to donwload!
  • Owner's manual - (English)

User manual of Dyson 349352-01 (16 pages)
file thumbnail

Operating manual

Assembly

SV11

Wash filter

Wash filter with cold water at least once every month.

Ensure the filter is completely dry before refitting.

Register today

3 easy ways to register your Dyson 2 year guarantee.

Powerful suction

Max mode

REGISTER ONLINE Visit our website to register your Dyson full parts and labour guarantee online.

AU: www.dyson.com.au/register NZ: www.dyson.co.nz/register

REGISTER BY PHONE Call our dedicated Helpline.

AU 1800 239 766 NZ 0800 397 667

REGISTER BY MAIL Complete and return the form to Dyson in the envelope supplied.

Dyson customer care THANK YOU FOR CHOOSING TO BUY A DYSON APPLIANCE.

Your Dyson appliance will be covered for parts and labour (excluding replacement filters where there is no defect) for 2 years from the date of purchase. as detailed in the terms of the Dyson guarantee in this Dyson Operating Manual.

If you have a query about your Dyson appliance. contact us via the website. Alternatively. call the Dyson Customer Care Helpline quoting your serial number and details of where and when you bought the appliance.

Visit our website to register your Dyson full parts and labour guarantee online. and for online help. support videos. general tips and useful information about Dyson.

AU: www.dyson.com.au/support

NZ: www.dyson.co.nz/support

This illustration is for example purposes only.

Your serial number can be found on your rating plate which is on the base of the appliance.

3 EASY WAYS TO REGISTER YOUR DYSON 2 YEAR GUARANTEE

DYSON CUSTOMER CARE Australia Website: www.dyson.com.au Email: [email protected] Dyson Customer Care: 1800 239 766 (Mon-Fri 8:00am to 6:00pm EST. Sat-Sun 8:30am to 4:00pm EST).

Address: Dyson Appliances (Aust.) Pty Limited. PO Box 2835. Taren Point.

NSW 2229 Australia.

New Zealand Website: www.dyson.co.nz Email: [email protected] Dyson Customer Care: 0800 397 667 (Mon-Fri 8:30am to 5:00pm).

Address: Avery Robinson Ltd. Unit 6. 99 Carbine Road. Mount Wellington.

Auckland. 1060. New Zealand.

IMPORTANT SAFETY INSTRUCTIONS BEFORE USING THIS APPLIANCE READ ALL INSTRUCTIONS AND CAUTIONARY MARKINGS IN THIS MANUAL AND ON THE APPLIANCE

When using an electrical appliance. basic precautions should always be followed. including the following:

WARNING These warnings apply to the appliance. and also where applicable. to all tools. accessories. chargers or mains adaptors.

TO REDUCE THE RISK OF FIRE.

ELECTRIC SHOCK OR INJURY:

This Dyson appliance can be used by children aged from 8 years and above and persons with reduced physical. sensory or reasoning capabilities. or lack of experience and knowledge. only if they have been given supervision or instruction by a responsible person concerning use of the appliance in a safe way and understand the hazards involved. Cleaning and user maintenance should not be performed by children without supervision.

Do not allow to be used as a toy.

Close attention is necessary when used by or near children. Children should be supervised to ensure that they do not play with the appliance.

Use only as described in this Dyson Operating Manual. Do not carry out any maintenance other than that shown in this manual. or advised by the Dyson Helpline.

Suitable for dry locations ONLY. Do not use outdoors or on wet surfaces.

Do not handle any part of the plug or appliance with wet hands.

Do not use with a damaged cable or plug.

If the supply cable is damaged it must be replaced by Dyson. its service agent or similarly qualified person in order to avoid a hazard.

If the appliance is not working as it should. has received a sharp blow. has been dropped. damaged. left outdoors. or dropped into water. do not use and contact the Dyson Helpline.

Contact the Dyson Helpline when service or repair is required. Do not disassemble the appliance as incorrect reassembly may result in an electric shock or fire.

Do not stretch the cable or place the cable under strain. Keep the cable away from heated surfaces. Do not close a door on the cable. or pull the cable around sharp edges or corners. Arrange the cable away from traffic areas and where it will not be stepped on or tripped over. Do not run over the cable.

10. Do not unplug by pulling on the cable.

To unplug. grasp the plug. not the cable. The use of an extension cable is not recommended.

11. Do not use to pick up water.

12. Do not use to pick up flammable or

13. Do not pick up anything that is burning or

14. Keep hair. loose clothing. fingers. and all

15. Do not put any object into openings.

Do not use with any opening blocked; keep free of dust. lint. hair and anything that may reduce airflow.

16. Use only Dyson recommended accessories

Do not use without the clear bin and filter in place.

18. Unplug when not in use for extended

19. Use extra care when cleaning on stairs.

20. Do not install. charge or use this appliance

21. Use only Dyson chargers for charging this

Dyson appliance. Use only Dyson batteries: other types of batteries may burst. causing injury to persons and damage.

22. FIRE WARNING – Do not place this

23. Always turn OFF’ the appliance before

24. FIRE WARNING – Do not apply any

READ AND SAVE THESE INSTRUCTIONS This Dyson appliance is intended for household use only.

Do not use near naked flames.

Do not store near heat sources.

Do not pick up water or liquids.

Do not pick up burning objects.

Do not put hands near the brush bar when the appliance is in use.

Do not place on or near the cooker

3.5 hrs

Using the dock

Lights during use

Light during charging

Solid blue: 'ON'.

Flashing amber: No power. temporary fault (e.g. too hot/cold).

Flashing red: Fault (contact Dyson helpline).

Flashing blue: No power. charge battery.

Solid amber: Fault (contact Dyson helpline).

Solid blue: Charging.

Lights off: Charging complete.

Solid amber: Fault – if this persists contact the Dyson Helpline.

Flashing red: Fault (contact Dyson helpline).

Flashing blue – Not charging – Re-fit charger or try another socket. If warning light persists. contact the Dyson Helpline.

Direct drive cleanerhead: Clearing obstructions

Important!

Wash filter

Wash filter with cold water at least once every month.

Ensure the filter is completely dry before refitting.

Using your Dyson appliance

Please read the Important Safety Instructions’ in this Dyson operating manual before proceeding.

Operation

• Do not use outdoors or on wet surfaces or to vacuum water or other liquids – electric

• Ensure the appliance remains upright in use and in storage. Dirt and debris may be

• Do not operate while checking for blockages.

• For domestic indoor and car use only. Do not use it whilst the car is in motion or

• To operate the Max mode. locate the switch on the top of the appliance. Slide the

• To switch off Max mode. slide the switch back to the Powerful Suction mode position.

• This appliance has carbon fibre brushes. Take care if coming into contact with

Docking station installation

• Use appropriate mounting hardware for your wall type and ensure that the

Carpets or hard floors

• Before vacuuming your flooring. rugs and carpets. check the manufacturer’s

• The brush bar on the appliance can damage certain carpet types and floors.

Some carpets will fuzz if a rotating brush bar is used when vacuuming. If this happens. we recommend vacuuming without the motorised floor tool and consulting with your flooring manufacturer.

• Before vacuuming highly polished floors. such as wood or lino. first check that the

Looking after your Dyson appliance

• Do not carry out any maintenance or repair work other than that shown in this

Dyson Operating Manual. or advised by the Dyson Helpline.

• Only use parts recommended by Dyson. If you do not this could invalidate

• Store the appliance indoors. Do not use or store it below 3°C (37.4°F). Ensure the

• Clean the appliance only with a dry cloth. Do not use any lubricants. cleaning

• Check the brush bar regularly and clear away any debris (such as hair). Debris left

Vacuuming

• Do not use without the clear bin and filters in place.

• Fine dirt such as flour should only be vacuumed in very small amounts.

• Do not use the appliance to pick up sharp hard objects. small toys. pins. paper clips.

• When vacuuming. certain carpets may generate small static charges in the clear

• Use extra care when cleaning on stairs.

• Do not rest the appliance on chairs. tables. etc.

• Do not press down on the nozzle with excessive force when using the appliance as

• Do not leave the cleaner head in one place on delicate floors.

• On waxed floors the movement of the cleaner head may create an uneven lustre.

If this happens. wipe with a damp cloth. polish the area with wax. and wait for it to dry.

Emptying the clear bin

• Empty as soon as the dirt reaches the level of the MAX mark – do not overfill.

• Ensure the appliance is disconnected from the charger before emptying the clear

• To make emptying the clear bin easier. it is advisable to remove the wand and

• To minimise dust/allergen contact when emptying. encase the clear bin tightly in a

• To release the dirt. hold the appliance by the handle. pull the red lever back and lift

• Remove the clear bin carefully from the bag.

• Seal the bag tightly. dispose as normal.

• To close. push the cyclone downwards until it is in the normal position and manually

Cleaning the clear bin

• Ensure the appliance is disconnected from the charger before removing the clear

• Remove the wand and floor tool.

• To remove the cyclone. hold the appliance by the handle. pull the red lever towards

• To detach the clear bin from the appliance. pull back on the red catch located at the

• Clean the clear bin with a damp cloth only.

• Do not use detergents. polishes or air fresheners to clean the clear bin.

• Do not put the clear bin in a dishwasher.

• Ensure the clear bin is completely dry before replacing.

• To replace the clear bin. align the tabs on the clear bin with the grooves on the main

• Slide the cyclone into the grooves of the main body and push downwards until it is in

Washable parts

Your appliance has washable parts. which require regular cleaning. Follow the instructions below.

Washing your filter

• Ensure the appliance is disconnected from the charger before removing the filter.

Be careful not to pull the ON’ trigger.

• Your appliance has one washable filter. located as shown.

• To remove the filter. lift it out of the top of the appliance.

• Check and wash the filter regularly according to instructions to

• The filter may require more frequent washing if vacuuming fine dust or if used

• Wash the filter with cold water only. No hot water and no detergents.

• Run water over the outside of the filter until the water runs clear.

• Squeeze and twist with both hands to make sure the excess water is removed.

• Leave the filter to dry completely for a minimum of 24 hours.

• Do not put the filter in a dishwasher. washing machine. tumble dryer. oven.

• To refit. place the dry filter back into the top of the appliance. Make sure it is seated

Blockages – automatic cut-out

• This appliance is fitted with an automatic cut-out.

• If any part becomes blocked the appliance may automatically cut out.

• This will happen after the motor pulses a number of times (i.e switches on and off in

• Leave to cool down before looking for blockages.

• Ensure the appliance is disconnected from the charger before looking for blockages.

Failure to do so could result in personal injury.

• Clear any blockage before restarting.

• Refit all parts securely before using.

• Clearing blockages is not covered by your guarantee.

Looking for blockages

The motor will pulse when there is a blockage. Please follow the instructions below to locate the blockage:

• Ensure the appliance is disconnected from the charger before looking for blockages.

Be careful not to pull the ON’ trigger.

• Do not operate while checking for blockages. Doing so could result in

• Beware of sharp objects when checking for blockages.

• To check for blockages in the main body of the appliance. remove the clear bin and

• If you cannot clear an obstruction you may need to remove the brush bar. Use a

• This appliance has carbon fibre brushes. Take care if coming into contact with

• Refit all parts securely before using.

• Clearing blockages is not covered by your guarantee.

Charging and storing

• This appliance will switch OFF’ if the battery temperature is below 3°C (37.4°F).

This is designed to protect the motor and battery. Do not charge the appliance and then move it to an area with a temperature below 3°C (37.4°F) for storage purposes.

• To help prolong battery life. avoid recharging immediately after a full discharge.

Allow to cool for a few minutes.

• Avoid using the appliance with the battery flush to a surface. This will help it run

Clearing mini motorised tool brush bar obstructions

Battery safety instructions

• If the battery needs replacing please contact the Dyson Helpline.

• Use only Dyson chargers for charging this Dyson appliance.

• The battery is a sealed unit and under normal circumstances poses no safety

Inhalation – can cause respiratory irritation. Expose to fresh air and seek medical advice.

Eye contact – can cause irritation. Immediately flush eyes thoroughly with water for at least 15 minutes. Seek medical attention.

Disposal – wear gloves to handle the battery and dispose of immediately. following local ordinances or regulations.

Caution

The battery used in this device may present a risk of fire or chemical burn if mistreated. Do not disassemble. short contacts. heat above 60°C (140°F). or incinerate. Keep away from children. Do not disassemble and do not dispose of in fire.

Disposal information

Dyson products are made from high grade recyclable materials. Please dispose of this product responsibly and recycle where possible.

When your Dyson appliance reaches the end of its life. we are responsible for its safe disposal. You can send your old Dyson appliance back to us (at our cost) and we will organise for it to be recycled.*

+Please note that not all parts are recyclable. Recycling of parts is subject to the capabilities of 3rd party suppliers. Available in Australia only.

Simply: 1. Box up your old Dyson appliance.

2. Take the package to your local post office and send to the address below:

Dyson We Recycle Reply Paid 83215 Dyson Service Centre 8–10 Mangrove Lane Taren Point. NSW 2229

• Keep the used batteries away from children as these can still harm children

• Your filter unit is non-washable and non-recyclable.

• To dispose of your old filter unit: remove it from the appliance and place it in your

• The battery should be removed from the product before disposal.

ONLINE SUPPORT

• For online help. general tips. videos and useful information about Dyson.

AU: www.dyson.com.au/support NZ: www.dyson.co.nz/support

Dyson customer care

Thank you for choosing to buy a Dyson appliance.

After registering your 2 year Dyson guarantee. your Dyson appliance will be covered for parts and labour for 2 years from the date of purchase. subject to the terms of the guarantee. If you have any questions about your Dyson appliance. call the Dyson Helpline with your serial number and details of where/when you bought the appliance. Most questions can be solved over the phone by one of our trained Dyson Helpline staff.

Australian consumer law

The details of the Dyson guarantee are set out below. In addition to your rights under the Dyson guarantee. we also provide the following statement as required by the Australian Consumer Law: In Australia. your Dyson appliance comes with statutory guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage. You are also entitled to have your Dyson appliance repaired or replaced if it fails to be of acceptable quality and the failure does not amount to a major failure.

• If your Dyson appliance needs a service. call the Dyson Customer Care Helpline so

Limited 2 year guarantee

Terms and conditions of the Dyson 2 year limited guarantee

What is covered

• The repair or replacement of your Dyson appliance (at Dyson’s discretion) if it

• This Dyson guarantee will only be valid if the appliance is used in the country in

What is not covered

Under your Dyson guarantee. Dyson shall not be liable for costs of repair or replacement of a product incurred as a result of:

• Accidental damage. faults caused by negligent use or care. misuse. neglect. careless

• Use of the Dyson appliance for anything other than normal domestic purposes in

• Use of parts not assembled or installed in accordance with the instructions of Dyson.

• Use of parts and accessories other than those produced or recommended by Dyson.

• Repairs or alterations carried out by parties other than Dyson or its

• Damage from external sources such as transit. weather. electrical outages or

• Failures caused by circumstances outside Dyson’s control.

• Blockages – please refer to the illustrations and the section ’Looking for Blockages

• Normal wear and tear (e.g. fuse. brush bar etc.).

• Use of this appliance on rubble. ash. plaster.

• Reduction in battery discharge time due to battery age or use (cordless machines

• If your Dyson guarantee does not apply. you may have statutory rights and remedies

• If your Dyson guarantee does not apply. you may have statutory rights and remedies

Dyson 2 year guarantee

Terms and conditions of your Dyson 2 year guarantee.

• The Dyson guarantee becomes effective from the date of purchase.

• All work will be carried out by Dyson Appliances (Aust.) Pty Limited. Avery Robinson

Ltd. (NZ) or their authorised agents.

• Any parts replaced by Dyson or its service agents will become the property of Dyson

Appliances (Aust.) Pty Limited or Avery Robinson Ltd. (NZ).

• The repair or replacement of your Dyson appliance under the Dyson guarantee will

• The Dyson guarantee provides benefits which are additional to and do not affect

• You must provide proof of (both the original and any subsequent) delivery/purchase

About your privacy

When registering your Dyson Product

• You will need to provide us with basic contact information to register your product

• When you register. you will have the opportunity to choose whether you would

JN.85061 PN.232540-12-02 16.03.17

Important!

Wash filter

Wash filter with cold water at least once every month.

Ensure the filter is completely dry before refitting.

Dyson customer care

Your Dyson appliance will be covered for parts and labour for 2 years from the date of purchase. as detailed in the terms of the Dyson guarantee in this Dyson Operating Manual.

If you have a query about your Dyson appliance. contact us via the website. Alternatively. call the Dyson Customer Care Helpline quoting your serial number and details of where and when you bought the appliance.

Most queries can be solved over the phone by one of our Dyson Customer Care Helpline staff.

DYSON CUSTOMER CARE Australia Website: www.dyson.com.au Email: [email protected] Dyson Customer Care: 1800 239 766 (Mon-Fri 8:00am to 6:00pm EST. Sat-Sun 8:30am to 4:00pm EST).

Address: Dyson Appliances (Aust.) Pty Limited. PO Box 2835.

Taren Point. NSW 2229 Australia.

New Zealand Website: www.dyson.co.nz Email: [email protected]n.co.nz Dyson Customer Care: 0800 397 667 (Mon-Fri 8:30am to 5:00pm).

Address: Avery Robinson Ltd. Unit 6.

99 Carbine Road. Mount Wellington. Auckland. 1060. New Zealand.

REGISTER ONLINE Visit our website to register your Dyson full parts and labour guarantee online.

AU: www.dyson.com.au/register NZ: www.dyson.co.nz/register

REGISTER BY PHONE Call our dedicated Helpline.

AU 1800 239 766 NZ 0800 397 667

REGISTER BY MAIL Complete and return the form to Dyson in the envelope supplied.

Date of purchase Country of purchase Australia New Zealand

Serial number

Privacy Act Dyson may use this information for future marketing and research purposes (including sending commercial electronic messages) and may disclose it to third parties for the purposes of providing the services you have requested or to our business partners or professional advisers.

If you wish to access your personal information or see our full privacy policy. please contact us at [email protected]

If you wish to receive marketing information by these methods from Dyson please tick this box. ■

Title Surname

First name

Telephone

Postcode

Address

Mobile

Store of purchase

GUARANTEE FORM



Newest Added: 300111-01 226419-01 DC43HMATTRESS DC54MULTIFLOOR 271642-01

Tags: Dyson DC 40, Dyson V8 Wall Fixing, Dyson Wall, Dyson Animal 2 Wand And Hose Removal, Dyson Dock, Dyson Animal 3

Dyson 349352-01 | Pages: 16 | Created on: 2017-03-20 | File type: PDF | Filename: 14924940_349352-01.pdf | Size: 1.86 MB | Language: English

Download User Manual

Product Infomation and Reviews - 349352-01 photo

349352 01 Photo

Dyson in United States

1-866-693-9766 US based Helpline open: 8:00am - 8:00pm CST Monday to Friday 9:00am - 6:00pm CST Saturday

Dyson 349352-01 Questions and Answers
