PRODIGIO&MILK
MY MACHINE
Job: NES-432001-2004D Prodigio-Milk Breville C
Datum: 15-10-21
von: timea.trojko
Uhrzeit: 12:50:46
Seite: p1
Version: --
pUMObjekt:
22
EN
Instruction manual
3
Job: NES-432001-2004D Prodigio-Milk Breville C
Datum: 15-10-21
von: timea.trojko
Uhrzeit: 12:50:46
Seite: p2
Version: --
pUMObjekt:
Congratulations on getting Nespresso Prodigio&Milk, the first connected coffee machine by Nespresso. This machine allows
you to brew a perfect coffee time after time while living a unique connected experience with your Smartphone or Tablet. To start your
connected journey, you will need to get the Nespresso App and pair your Smartphone to your Nespresso Prodigio&Milk machine.
To check your device’s compatibility, go on www.nespresso.com/Prodigio
3
Nespresso Prodigio&Milk
EN
Job: NES-432001-2004D Prodigio-Milk Breville C
Datum: 15-10-21
von: timea.trojko
Uhrzeit: 12:50:46
Seite: p3
Version: --
pUMObjekt:
+
=
ON
Launch the App. Click on the Machine Icon. Download the Nespresso App.
If you have it already, please update the App.
?
WHAT ARE THEY?
- Capsules stock management
- Schedule a coffee brewing
- Brew Now
- Maintenance notifications
- Descaling alert
- And more to see via the App
When the pairing is
complete, the Nespresso Light
will blink 3 times.
Please remember that the Bluetooth
®
mode must be activated beforehand on your
smartphone or tablet.
EN
4
Pairing Connectivity Functions
Get the App
Job: NES-432001-2004D Prodigio-Milk Breville C
Datum: 15-10-21
von: timea.trojko
Uhrzeit: 12:50:46
Seite: p4
Version: --
pUMObjekt:
X16
PRODIGIO
MY MACHINE
Welcome
220-240 V~, 50-60 Hz, 1700 W
max
19 bar / 1.9 MPa
~ 4 kg / 8 lbs
0.8 L / 27 oz
21.84 cm 25.53 cm 37.4 cm
8.6 in 10.53 in 14.7 in
INSTRUCTION MANUAL
Nespresso is an exclusive system creating the perfect Espresso, time after
time. All Nespresso machines are equipped with a unique extraction system
that guarantees up to 19 bar pressure. Each parameter has been calculated
with great precision to ensure that all the aromas from each Grand Cru can be
extracted, to give the coffee body and create an exceptionally thick and smooth
crema.
CAUTION: when you see this sign, please refer to the
safety precautions to avoid possible harm and damage.
INFORMATION: when you see this sign, please take note of the advice for
the correct and safe usage of your coffee machine.
INFORMATION: when you see this sign, please note that you can
also use the App for this function. Consult App for more information.
Packaging Content
Tasting Box of Nespresso
Grands Crus Capsules
Nespresso Welcome Brochure
User Manual
2 x Water Hardness Test Stick, in the User
Manual and on Quickstart guide
Prodigio&Milk Coffee Machine
EN
5
Prodigio&Milk
C75 Specifications
BEC500
Job: NES-432001-2004D Prodigio-Milk Breville C
Datum: 15-10-21
von: timea.trojko
Uhrzeit: 12:50:46
Seite: p5
Version: --
pUMObjekt:
Content
EN
6
Nespresso Prodigio&Milk 3
Get the App 4
Pairing 4
Connectivity Functions 4
Packaging Content 5
Prodigio&Milk 5
Specifications 5
Safety Precautions 7-9
Machine Overview 10
First Use 11-12
Regular Coffee Preparation 13-14
Milk Froth Preparation 15
Energy Saving Concept 16
Programming the Water Volume 16
Reset to Factory Setting 17
Emptying the System 17
Cleaning 18
Descaling 19-21
Troubleshooting 22
Troubleshooting Milk Froth Preparation 23
Contact Nespresso Club 24
The Positive Cup: Our approach to sustainability 24
Disposal and Environmental Protection 25
Limited Guarantee 26
Job: NES-432001-2004D Prodigio-Milk Breville C
Datum: 15-10-21
von: timea.trojko
Uhrzeit: 12:50:46
Seite: p6
Version: --
pUMObjekt:
Safety Precautions
77
CAUTION: the safety
precautions are part of
the appliance. Read them
carefully before using your
new appliance for the first
time. Keep them in a place
where you can find and
refer to them later on.
CAUTION: when you see
this sign, please refer to the
safety precautions to avoid
possible harm and damage.
INFORMATION: when
you see this sign, please
take note of the advice for
the correct and safe usage
of your appliance.
t
The appliance is intended to
prepare beverages according
to these instructions.
t
Do not use the appliance
for anything other than its
intended use.
t
This appliance has been
designed for indoor and
non-extreme temperature
conditions use only.
t
Protect the appliance
from direct sunlight effect,
prolonged water splash and
humidity.
t
This is a household
appliance only. It is not
intended to be used in: staff
kitchen areas in shops,
offices and other working
environments; farm houses;
by clients in hotels, motels
and other residential type
environments; bed and
breakfast type environments.
t
This appliance may be used
by children of at least 8 years
of age, as long as they are
supervised and have been
given instructions about
using the appliance safely
and are fully aware of the
dangers involved. Cleaning
and user maintenance shall
not be made by children
unless they are older than 8
and they are supervised by
an adult.
t
Keep the appliance and its
cord out of reach of children
under 8 years of age.
t
This appliance may be used
by persons with reduced
physical, sensory or mental
capabilities, or whose
experience or knowledge
is not sufficient, provided
they are supervised or have
received instruction to use
the appliance safely and
understand the dangers.
t
Children shall not use the
device as a toy.
t
The manufacturer accepts
no responsibility and the
warranty will not apply
for any commercial use,
inappropriate handling or use
of the appliance, any damage
resulting from use for other
purposes, faulty operation,
non-professionals repair or
failure to comply with the
instructions.
Avoid risk of fatal electric
shock and fire.
t
In case of an emergency:
immediately remove the plug
from the power socket.
t
Only plug the appliance into
suitable, easily accessible,
earthed mains connections.
Make sure that the voltage
of the power source is the
same as that specified on
the rating plate. The use of
an incorrect connection voids
the warranty.
t
Do not put in the dishwasher
EN
Job: NES-432001-2004D Prodigio-Milk Breville C
Datum: 15-10-21
von: timea.trojko
Uhrzeit: 12:50:46
Seite: p7
Version: --
pUMObjekt:
Safety Precautions
8
and do not immerse into
water for cleaning purposes,
do not water the bottom
part of the Aeroccino which
contains the electrical plug,
but clean the interior of the
Aeroccino with the detergent
and rinse with warm/hot
water.
t
Dry all Aeroccino with a
fresh and clean towel, cloth
or paper and reassemble all
parts.
t
If the bottom part of the
Aeroccino is wet, dry it before
putting it back in contact with
the plug.
The appliance must
only be connected after
installation.
t
Do not pull the cord over
sharp edges, clamp it or
allow it to hang down.
t
Keep the cord away from
heat and damp.
t
If the supply cord is
damaged, it must be
replaced by the manufacturer,
its service agent or similarly
qualified persons, in order to
avoid all risks.
t
If the cord is damaged, do
not operate the appliance;
return the appliance to
the Nespresso Club or to
a Nespresso authorised
representative.
t
If an extension cord is
required, use only an earthed
cord with a conductor cross-
section of at least 1.5 mm
2
or
matching input power.
t
To avoid hazardous damage,
never place the appliance on
or beside hot surfaces such
as radiators, stoves, ovens,
gas burners, open flame, or
similar.
t
Always place it on a
horizontal, stable and even
surface. The surface must be
resistant to heat and fluids,
like water, coffee, descaler or
similar liquids.
t
Disconnect the appliance
from the mains when not
in use for a long period.
Disconnect by pulling out the
plug and not by pulling the
cord itself or the cord may
become damaged.
t
Before cleaning and
servicing, remove the plug
from the mains socket and
let the appliance cool down.
t
Never touch the cord with
wet hands.
t
Never immerse the appliance
or part of it in water or other
liquid.
t
Never put the appliance or
part of it in a dishwasher.
t
Electricity and water together
is dangerous and can lead to
fatal electrical shocks.
t
Do not open the appliance.
Hazardous voltage inside!
t
Do not put anything into any
openings. Doing so may
cause fire or electrical shock!
t
Use cold milk for better
quality foam.
t
Use UHT Milk (or minimum
fresh pasteurized).
t
Clean after each preparation.
Use detergent and rinse
with warm/hot water. For
Aeroccinos, remove seal from
lid and remove whisk.
t
Use dishwasher for
dishwashable components. If
not, use a non-abrasive cloth.
Avoid possible harm
when operating the
appliance.
t
Never leave the appliance
unattended during operation.
t
Do not use the appliance if it
EN
Job: NES-432001-2004D Prodigio-Milk Breville C
Datum: 15-10-21
von: timea.trojko
Uhrzeit: 12:50:46
Seite: p8
Version: --
pUMObjekt:
9
is damaged or not operating
perfectly. Immediately
remove the plug from the
power socket. Contact the
Nespresso Club or Nespresso
authorised representative
for examination, repair or
adjustment.
t
A damaged appliance can
cause electrical shocks, burns
and fire.
t
Always completely close
the slider and never open it
during operation. Scalding
may occur.
t
Do not put fingers under
coffee outlet, risk of scalding.
t
Do not put fingers into capsule
compartment or the capsule
shaft. Danger of injury!
t
Water could flow around a
capsule when not perforated
by the blades and damage
the appliance.
t
Never use a damaged or
deformed capsule. If a
capsule is blocked in the
capsule compartment, turn
the machine off and unplug it
before any operation. Call the
Nespresso Club or Nespresso
authorised representative.
t
Fill the water tank only with
fresh and potable water.
t
Empty water tank if the
appliance will not be used for
an extended time (holidays,
etc.).
t
Replace water in water tank
when the appliance is not
operated for a weekend or a
similar period of time.
t
Do not use the appliance
without the drip tray and drip
grid to avoid spilling any liquid
on surrounding surfaces.
t
Do not use any strong
cleaning agent or solvent
cleaner. Use a damp cloth
and mild cleaning agent
to clean the surface of the
appliance.
t
To clean machine, use only
clean cleaning tools.
t
When unpacking the
machine, remove the plastic
film and dispose.
t
This appliance is designed for
Nespresso coffee capsules
available exclusively through
the Nespresso Club or
your Nespresso authorised
representative.
t
All Nespresso appliances
pass stringent controls.
Reliability tests under practical
conditions are performed
randomly on selected units.
This can show traces of any
previous use.
t
Nespresso reserves the right
to change instructions without
prior notice.
t
This machine contains
magnets.
Descaling
t
Nespresso descaling agent,
when used correctly, helps
ensure the proper functioning
of your machine over its
lifetime and that your coffee
experience is as perfect as
the first day.
t
For coffee and coffee&milk
machines, descale
according to user manual
recommendations or specific
alerts.
SAVE THESE
INSTRUCTIONS
Pass them on to any
subsequent user.
This instruction manual is
also available as a PDF at
nespresso.com
EN
Job: NES-432001-2004D Prodigio-Milk Breville C
Datum: 15-10-21
von: timea.trojko
Uhrzeit: 12:50:46
Seite: p9
Version: --
pUMObjekt:
EN
Machine Overview
Coffee Buttons (Ristretto, Espresso & Lungo)
Slider for Capsule Insertion
Coffee Outlet
Adjustable Water Tank &
Milk Frother Arm
Water Tank & Lid
Lid
Frothing Spring (for Milk
Froth)
Mixer (for hot milk)
Seal
Aeroccino Milk Frother
Start/Stop Button
Used Capsule Container & Drip Tray
Adjustable
Cup Support
&DripGrid
EN
*Nespresso Light: capsules stock management
Maintenance Light: water tank empty, capsule container out or full,
*descaling needed
10
*Available only with a connected machine
EN
10
Job: NES-432001-2004D Prodigio-Milk Breville C
Datum: 15-10-21
von: timea.trojko
Uhrzeit: 12:50:46
Seite: p10
Version: --
pUMObjekt:
First Use
Rinse the water tank before
filling it with potable water.
Plug the machine into the
mains.
Remove the Aeroccino, water tank
and capsule container to clean them.
Choose position for water tank.
Place the water tank, insert
the drip tray, Aeroccino and the
capsule container in position.
For your safety, operate the
machine only with drip tray and
capsule container in position.
Insert the remaining cable in the
guide under water tank left or right
socket, depending on the position
chosen for the water tank. Ensure
machine is in the upright position.
EN
11
Read the safety precautions first to avoid risks of fatal electrical shock and fire.
Job: NES-432001-2004D Prodigio-Milk Breville C
Datum: 15-10-21
von: timea.trojko
Uhrzeit: 12:50:46
Seite: p11
Version: --
pUMObjekt:
3x
> 3 sec
Finding nearby
machines
It may take up to 50 seconds to detect.
CANCEL
First Use
Turn the machine ON by
pressing any coffee button or
by opening the slider. Lights
will blink. Heating up takes
approximately 25 seconds.
Steady lights: machine is ready.
To turn OFF your machine, ensure all the 3 coffee buttons
are ON. Press and hold Lungo and
Espresso buttons simultaneously for 3 seconds.
Before making any coffee, make sure to
rinse your machine by:
1. Placing a container under coffee outlet.
2. Closing the slider and pressing the Lungo
button to rinse the machine.
3. Repeat three times.
EN
12
To connect your machine, please follow the instructions in sections «Get the App»
and «Pairing» on page 4.
Multiple devices can be connected to your Prodigio&Milk machine only if using a
unique club members number. To pair these additional devices, please follow the
instructions in sections «Get the App» and «Pairing» on page 4.
Job: NES-432001-2004D Prodigio-Milk Breville C
Datum: 15-10-21
von: timea.trojko
Uhrzeit: 12:50:46
Seite: p12
Version: --
pUMObjekt:
Lungo
Espresso
Ristretto
Regular Coffee Preparation
Fill the water tank
with potable water.
Place a cup under
the coffee outlet.
Turn machine ON by pressing any
coffee button or by opening the slider.
Lights will blink. Heating up
approximately takes 25 seconds.
Steady lights: ready.
Open the slider, insert a capsule and close the slider. Select your
coffee size based on the chosen Grand Cru:
Ristretto (25 ml / 0.84 oz)
Espresso (40 ml / 1.35 oz)
Lungo (110 ml / 3.7 oz)
You can select the desired coffee button, by pressing it, even while
the machine is still heating up.
The selected coffee button will blink and becomes steady on when
machine is ready to brew. The coffee will then flow.
To ensure hygienic conditions, it is highly recommended to
not reuse a used capsule.
EN
13
Job: NES-432001-2004D Prodigio-Milk Breville C
Datum: 15-10-21
von: timea.trojko
Uhrzeit: 12:50:46
Seite: p13
Version: --
pUMObjekt:
Lungo
Espresso
Ristretto
Max 10 sec
Regular Coffee Preparation
To stop the coffee flow, press
the selected coffee button or
slightly move the slider towards
the back of the machine until
the coffee flow stops. Please
note, a manual top-up is not
possible in this case.
To manually top up your
coffee, touch any of the
coffee buttons within 10
seconds from the end of
preparation.
To change the selected cup size during brewing select the new desired coffee
button. The machine will immediately stop if the coffee volume extracted is larger
than new desired coffee size.
To accommodate a milk
recipe glass, lift the cup
support.
Preparation will stop
automatically.
The capsule will eject
automatically.
EN
14
Job: NES-432001-2004D Prodigio-Milk Breville C
Datum: 15-10-21
von: timea.trojko
Uhrzeit: 12:50:46
Seite: p14
Version: --
pUMObjekt:
+
+
2X 1X
1X
max
max
a
b
Attach the relevant whisk.
Close the Aeroccino with its
lid and place it on the base.
For a hot preparation, briefly press
button to start.
- Button lights up red.
Takes approx. 70-80 sec.
For cold milk froth, keep button
pressed for approx. 2 seconds.
- Button lights up blue.
Takes approx. 60 sec.
Clean after each
preparation.
Only use non abrasive cloth,
never use a brush.
Jug is waterproof.
Do not put in dishwasher.
Fill milk frother up to one of the two «max» level
indicators:
a) Highest «max milk» level indicator
(230 ml/ 7.78 oz) is for hot milk preparations.
b) Lowest «max foam» level indicator
(110 ml/ 3.72 oz) is for milk froth preparations.
WARNING: Do not put the Aeroccino in the dishwasher. Risk of electrical shock and fire! Make sure the under side
of the milk frother is dry.
EN
15
Milk Froth Preparation
Only use the Aeroccino with the base provided. TIP: For optimal milk froth, use whole or semi skimmed milk at refrigerated temperature (about 4-6 °C).
Job: NES-432001-2004D Prodigio-Milk Breville C
Datum: 15-10-21
von: timea.trojko
Uhrzeit: 12:50:46
Seite: p15
Version: --
pUMObjekt:
< 9 min
> 3 sec
Energy Saving Concept
Programming the Water Volume
Automatic OFF mode: the machine will
turn into OFF mode automatically after 9
minutes of non-use.
To change automatic OFF mode from 9 to 30 minutes:
- Ensure the machine is turned OFF
- Press and hold both the Lungo and Ristretto buttons for more than 3 sec.
- Espresso button flashes 3 times for confirmation.
To revert back to 9 minutes, repeat the same procedure.
Espresso button flashes once for confirmation.
Any coffee button can be programmed.
1. Ristretto button: from 15 to 30 ml / 0.5-1 oz.
2. Espresso button: from 30 to 70 ml /1 to 2.33 oz.
3. Lungo button: from 70 to 130 ml / 2.33 to 3 oz.
- Ensure the machine is ON
- Open the slider and insert the capsule.
- Close the slider.
- Press and hold the selected coffee button.
- Release the button when desired volume is reached.
- The 3 coffee buttons flash for confirmation.
- Water volume is now stored for the button used during programming.
EN
16
Job: NES-432001-2004D Prodigio-Milk Breville C
Datum: 15-10-21
von: timea.trojko
Uhrzeit: 12:50:46
Seite: p16
Version: --
pUMObjekt:
Min 5 sec
> 6 sec
Reset to Factory Settings
Emptying the System
before a period of non-use or for frost protection
Factory settings are:
- Lungo, Espresso, Ristretto coffee buttons 110ml /
3.7oz, 40ml / 1.35 oz., 25ml / 0.84 oz.
- Automatic OFF mode after 9 minutes.
- The water hardness set by default is hard, which
corresponds to around 1000 Espresso cups.
To do it via your machine:
1. Ensure the machine is turned OFF.
2. Press and hold Espresso & Lungo buttons for at
least 5 seconds.
All the coffee buttons and LEDs will blink once as
confirmation. To unpair your machine, please refer
to the «Troubleshooting section».
If you reset to factory settings,
this will cancel the pairing, reset
the capsules stock management
and the descaling alert.
Remove the water
tank. Place a
container under the
coffee outlet.
Ensure the machine
is ON, press and hold
the Ristretto & Lungo
buttons together for at
least 6 seconds.
The Ristretto and Lungo coffee buttons will
flash for confirmation. Then close the slider to
start procedure. If the slider was already closed,
the emptying process starts automatically. When
the procedure is finished, clean the drip tray and
the cup support. Machine turns to OFF mode
automatically when empty.
EN
17
To note, the machine remains blocked for 10 minutes after emptying!
Job: NES-432001-2004D Prodigio-Milk Breville C
Datum: 15-10-21
von: timea.trojko
Uhrzeit: 12:50:47
Seite: p17
Version: --
pUMObjekt:
Cleaning
Empty the drip tray and
the capsule container
every day. Also remove lid
and water tank and clean
them all with odorless
detergent and rinse with
warm / hot water.
Do not use any strong or
abrasive solvent, sponge or
cream cleaner. Do not put in
the dishwasher.
Never immerse the
appliance or part of it in
water or any other liquid.
Dry all water tank container
parts with a fresh and clean
towel, cloth or paper and
reassemble all parts.
Clean the coffee outlet and
inside the machine regularly
with a damp cloth.
EN
18
To ensure hygienic conditions, it is highly recommended to empty and clean the used capsule container every day.
Job: NES-432001-2004D Prodigio-Milk Breville C
Datum: 15-10-21
von: timea.trojko
Uhrzeit: 12:50:47
Seite: p18
Version: --
pUMObjekt:
Descaling
Read the safety precautions on the descaling
package and refer to the table for the frequency of use.
The descaling solution can be harmful. Avoid contact
with eyes, skin and surfaces. Never use any product
other than the Nespresso descaling kit available at the
Nespresso Club to avoid damage to your machine. The
following table will indicate the descaling frequency
required for the optimum performance of your machine,
based on water hardness. For any additional questions
you may have regarding descaling, please contact the
Nespresso Club.
EN
19
Duration approximately 15 minutes.
Job: NES-432001-2004D Prodigio-Milk Breville C
Datum: 15-10-21
von: timea.trojko
Uhrzeit: 12:50:47
Seite: p19
Version: --
pUMObjekt:
Descaling
Empty the drip tray and
the used capsule container.
To enter the descaling mode, ensure the machine is ON, press and hold
the 3 coffee buttons for 6 seconds until the confirmation with a beep. The 3
buttons will start blinking (buttons will flash until the exit of this mode).
Fill the water tank with 1
unit of Nespresso descaling
liquid and add 0.5 L / 17 oz
of water.
Place a container (minimum
volume: 0.8 L / 27 oz) under
the coffee outlet.
Ensure the slider is closed
and press any coffee button
to start the descaling cycle,
pump will run. Machine will
stop automatically when
water tank is empty.
Info: maintenance light is ON during the descaling process.
EN
20
Job: NES-432001-2004D Prodigio-Milk Breville C
Datum: 15-10-21
von: timea.trojko
Uhrzeit: 12:50:47
Seite: p20
Version: --
pUMObjekt:
EN
21
App. fH dH CaCO3
(40 ml)
/ Niveau < 5 < 3 < 50 mg/l 4000 fH
/ Niveau > 7 > 4 > 70 mg/l 3000 dH
/ Niveau > 13 > 7 > 130 mg/l 2000 CaCO3
/ Niveau > 25 > 14 > 250 mg/l 1500
/ Niveau > 38 > 21 > 380 mg/l 1000
Water hardness:* Descaling after:*
Level 0
French degree
Level 1
German Grade
Level 2
Calcium Carbonate
Level 3
Level 4
*On the App, the water hardness can be adjusted any time under "Water status".
Press any button to start descaling a second time. Machine will stop
automatically when the water tank is empty.
Empty and rinse the water tank, drip tray and cup support thoroughly
to avoid any residue.
Refill the water tank with fresh potable water.
Press any button to start rinsing the machine, pump will run.
Machine will stop automatically when the water tank is empty.
Repeat this twice.
To exit the descaling mode, press and
hold the 3 buttons for 6 seconds until the
confirmation with a beep.
The machine is now ready for use.
Refill the water tank with the used
descaling agent (already passed
in the machine) collected into the
container.
Empty the drip
tray.
Job: NES-432001-2004D Prodigio-Milk Breville C
Datum: 15-10-21
von: timea.trojko
Uhrzeit: 12:50:47
Seite: p21
Version: --
pUMObjekt:
Troubleshooting
Videos are available on the App and on www.nespresso.com - Go to section «services».
2222
Pairing has not been successful. - Check that the Bluetooth
®
on the smartphone or tablet is activated.
- Check the compatibility of your smartphone or tablet with the machine (see
page 3).
- Ensure the smartphone or tablet is placed next to the machine during the pairing
- Make sure to not turn ON any microwave close to the machine during pairing.
If you want to unpair your machine,
via the app:
- Go on the App «Name», click on «Machine status»,then click on «Unpair this
machine».
- Click on «unpair this device» to confirm the unpairing.
- Note: In case of a unpairing, all the setups and specifications will be lost and the
machine will be reset to factory settings.
If you want to unpair your machine,
via the machine:
- Press simultaneously Ristretto and Espresso buttons and remove the plug
from the mains.
- Note: this action will deactivate the Bluetooth
®
function from the machine.
If you want to reactivate the Bluetooth
®
on
your machine, via the machine:
- Please reset to factory settings. See paragraph on «Reset to Factory Settings».
No light on the coffee buttons. - Machine turns OFF automatically. See paragraph on «Energy Saving
Concept».
- Check the mains: plug, voltage, fuse.
No coffee, no water, unusual coffee flow. - Check if the water tank is correctly positioned, if empty, fill with potable water.
- Descale it if necessary.
Coffee is not hot enough. - Preheat cup. - Descale the machine if necessary.
The slider does not close completely or the
machine doesn't start brewing.
- Empty the capsule container. - Check that no capsule is blocked inside the machine.
(Note: do not put the finger inside the machine)
Leakage (water under the machine). - Empty drip tray if full. - If problem persists, call the Nespresso Club.
Maintenance light is ON. - Empty the used capsule container and check no capsules are blocked.
- Check the water tank. If empty, fill with potable water and brew a coffee.
- If problem persists, call the Nespresso Club.
Nespresso light is ON. - It means your capsules stock is empty. You can order capsules via the App or
Nespresso website.
3 coffee buttons flash quickly. - To exit the descaling mode, press and hold the 3 buttons for 6 seconds until
the confirmation with a beep.
- If problem persists, call the Nespresso Club, or check the App for more
information.
Water or coffee flow does not stop even
when pushing a coffee button.
- Gently move the slider towards the back of the machine to stop the flow.
No coffee flow, water goes directly into the
drip tray (despite inserted capsule).
- Pull the slider to ensure it is closed. - If problem persists, call the Nespresso Club.
Machine turns to OFF mode. - To save energy the machine will turn to OFF mode after 9 minutes of non-use.
- See paragraph on «Energy Saving Concept».
- Press one of the coffee buttons to turn to "ON-mode" or open the slider.
EN
Job: NES-432001-2004D Prodigio-Milk Breville C
Datum: 15-10-21
von: timea.trojko
Uhrzeit: 12:50:47
Seite: p22
Version: --
pUMObjekt:
EN
23
Troubleshooting Milk Froth Preparation
Aeroccino does not start. - Be sure to position the jug correctly on a clean base. Be sure to attach
the whisk to the jug correctly.
Quality of milk froth not up to standard. - Be sure to use whole or semi-skimmed milk at refrigerated temperature
(about 4-6 °C).
- Be sure to use the appropriate whisk and the jug is clean.
Red Button blinking. - a) The appliance is too hot.
Rinse it under cool water.
b) Whisk is missing.
c) Not enough milk. Fill milk frother up to one of the two «max» level.
Milk Overflows. - Be sure to use the appropriate whisk.
- Check the corresponding indicator level.
Aeroccino does not start. - Be sure to position the jug correctly on a clean base. Be sure to attach
the whisk to the jug correctly.
Quality of milk froth not up to standard. - Be sure to use whole or semi-skimmed milk at refrigerated temperature
(about 4-6 °C). For a best result, the milk must be newly opened.
- Be sure to use the appropriate whisk and the jug is clean.
Red Button blinking. a) The appliance is too hot.
Rinse it under cool water.
b) Whisk is missing.
c) Not enough milk. Fill milk frother up to one of the two «max» level.
Milk Overflows. - Be sure to use the appropriate whisk.
- Check the corresponding indicator level.
Job: NES-432001-2004D Prodigio-Milk Breville C
Datum: 15-10-21
von: timea.trojko
Uhrzeit: 12:50:47
Seite: p23
Version: --
pUMObjekt:
Contact the Nespresso Club
As we may not have foreseen all uses of your appliance, should you need
any additional information, in case of problems or simply to seek advice, call the
Nespresso Club or your Nespresso authorised representative.
Contact details for your Nespresso Club or your Nespresso authorised
representative can be found in the «Welcome to Nespresso» folder in your
machine box or at nespresso.com
The Positive Cup: our approach to sustainability
At Nespresso, we believe that each cup of coffee can not only deliver
a moment of pleasure, but also restore, replenish and revive environmental
resources and communities. As a company, sustainability is our way of doing
business and is at the heart of everything we do.
Through our sustainability strategy The Positive Cup, we are aiming to reach
our 2020 goal of making every cup of Nespresso a positive cup. To realise this
vision, Nespresso has set itself ambitious commitments:
Coffee: 100% sustainably sourced coffee
Capsules: 100% sustainably managed aluminum
Climate: 100% carbon insetting
For more information, go to www.nespresso.com/positive
EN
24
Job: NES-432001-2004D Prodigio-Milk Breville C
Datum: 15-10-21
von: timea.trojko
Uhrzeit: 12:50:47
Seite: p24
Version: --
pUMObjekt:
Disposal and environmental protection
This appliance complies with the EU Directive 2012/19/EC. Packaging
materials and appliance contain recyclable materials.
Your appliance contains valuable materials that can be recovered or can be
recycled. Separation of the remaining waste materials into different types
facilitates the recycling of valuable raw materials. Leave the appliance at
a collection point. You can obtain information on disposal from your local
authorities.
EN
25
Job: NES-432001-2004D Prodigio-Milk Breville C
Datum: 15-10-21
von: timea.trojko
Uhrzeit: 12:50:47
Seite: p25
Version: --
pUMObjekt:
Limited Guarantee
Breville guarantees this product against defects in materials and workmanship for two years domestic use (or 3 months commercial use) from the date of purchase.
During this period, Breville will either repair or replace, at its discretion, any defective product at no charge to the consumer. In the event of a product or accessory
being repaired or replaced during the guarantee period, the guarantee on the repaired product will expire two years from the purchase date of the original product,
not two years from the date of repair. This guarantee excludes liability for consequential loss or any other loss or damage caused to property or person arising from
any cause whatsoever. It also excludes defects caused by the product not being used in accordance with instructions, accidental damage, misuse, being tampered
with by unauthorised persons, improper maintenance, consumable items or normal wear and tear and does not cover the cost of claiming under the warranty.
Except to the extent applicable by law, the terms of this warranty do not exclude, restrict or modify, and are in addition to, the mandatory statutory rights applicable
to the sale of the product to you. Only the use of Nespresso capsules will guarantee the proper functioning and lifetime of your Nespresso machine.
Any defect resulting from the usage of non-genuine Nespresso capsules will not be covered by this warranty.
How to Claim Under the Breville Warranty
Nespresso is handling product enquiries and product servicing on Breville’s behalf. If you believe your product is defective, contact the Nespresso customer service
team directly for instructions on where to send or bring it for repair by a Breville authorised service agent. Contact Nespresso Australia: 1800 623 033 or New
Zealand: 0800 234 579 [email protected].
This product is imported and distributed by Breville and this warranty is provided by Breville. To the extent permitted by law, Nespresso has no liability for the product
and all guarantees, warranties and conditions by Nespresso are excluded.
EN
26
Job: NES-432001-2004D Prodigio-Milk Breville C
Datum: 15-10-21
von: timea.trojko
Uhrzeit: 12:50:47
Seite: p26
Version: --
pUMObjekt:
27
Job: NES-432001-2004D Prodigio-Milk Breville C
Datum: 15-10-21
von: timea.trojko
Uhrzeit: 12:50:47
Seite: p27
Version: --
pUMObjekt:
PRODIGIO&MILK
by Nespresso
NES-432001-2004D-1
Job: NES-432001-2004D Prodigio-Milk Breville C
Datum: 15-10-21
von: timea.trojko
Uhrzeit: 12:50:47
Seite: p28
Version: --
pUMObjekt:
