About the GE Appliances
®
XWFE Water Filter Cartridge
WATER FILTER CARTRIDGE
The water filter cartridge holder is located in the
back upper-right corner of the fresh food refrigerator
compartment.
WHEN TO REPLACE THE FILTER
If there is a replacement indicator light for the water filter
cartridge on the dispenser, a red light will start blinking to
tell you that you need to replace the filter soon. For models
that don’t have the indicator light, the filter cartridge should
be replaced every six months, or earlier if the flow of water
to the dispenser or icemaker decreases.
REMOVING THE FILTER
If you are replacing the filter, first remove the previous one
by gently grasping the filter and slowly turning it to the left,
about a ¼ turn. The filter should automatically release itself
when you have rotated it far enough to the left. A small
amount of water may drip down.
CAUTION
If air has been trapped in the system, the filter cartridge
may be ejected as it is removed. Use caution when
removing.
FILTER BYPASS PLUG
To reduce the risk of property damage due to water
leakage, you MUST use the filter bypass plug when a
replacement filter cartridge is not available. Some models
do not come equipped with the filter bypass plug. To obtain
a free bypass plug, call 800-GECARES. In Canada, call
800.561.3344. The dispenser and icemaker will not operate
without either the filter or bypass plug installed. The bypass
plug is installed in the same way as a filter cartridge
Application Guidelines/Water Supply
INSTALLING THE FILTER IN A BOTTOM
FREEZER REFRIGERATOR
1. Open the filter cartridge
housing by squeezing the
2 front tabs and gently
pulling down.
2. Line up the ports on the
filter with the ports on the
filter cartridge holder, and
gently insert the filter.
3. Slowly turn the filter to the
right until it stops. DO NOT
OVERTIGHTEN. As you turn
the filter, it will automatically
adjust itself into position. The
filter will move about a ¼ turn
or 90 degrees, until the arrow
on the filter aligns with the
arrow on the filter cartridge
holder.
4. Slowly push the filter up into the clips.
5. Close the filter cartridge
housing by gently pushing the
lid upwards until the tabs lock
into place.
6. Continue following instructions
shown in Purging the Filter
and Reset Filter Change
Indicator Sections.
INSTALLING THE FILTER IN A SIDE BY SIDE
REFRIGERATOR
1. Line up the arrow on the filter with the arrow on the filter
cartridge holder. Gently push the top of the new filter up
inside the holder.
2. Slowly turn the filter to the right until it
stops. DO NOT OVERTIGHTEN. As you
turn the filter, it will automatically raise
itself into position. The filter will move
about a ¼ turn or 90 degrees.
3. Continue following instructions shown
in Purging the Filter and Reset Filter
Change Indicator Sections.
GE is a trademark of the General Electric Company. Manufactured under trademark license.
Service Flow 0.5 gpm (1.89 lpm)
Water Supply Potable Water
Water Pressure 25-120 psi (172-827 kPa)
Water Temperature 33°F-100°F (0.6°C-38°C)
Capacity 170 gallons (643.5 liters)
Sign-up for TEXT REMINDERS
by texting REPLACE to 70543.
