User Manual

This is the main product document for model 3020BPL.

The file format is pdf, 2 pages, you can download this manual here .

background
IMPORTANT
Read these instructions for use carefully.
Familiarise yourself with the appliance
before connecting it to its gas container.
Keep these instructions for future
reference.
ONLY USE IN WELL-VENTILATED AREAS.
CARBON MONOXIDE HAZARD!
THIS APPLIANCE CAN PRODUCE CARBON
MONOXIDE WHICH HAS NO ODOUR. USING
IT IN AN ENCLOSED SPACE (FOR EXAMPLE,
CARAVAN, TENT, CAR, MOBILE HOME)
MAY CAUSE DEATH.
• Donotmodifythisappliance.
• Checkthatsealsbetweentheapplianceand
thegascontainerareinplaceandingood
conditionbeforeconnectingthegascontainer.
• Donotusetheapplianceifithasdamagedor
wornseals.
• Donotusethisapplianceifitisleaking,
damagedordoesnotoperateproperly.
• Thisappliancemustonlybeservicedbyan
authorizedperson.
• Theopeningsatthebaseoftheburner
provideairforcombustion,theyshouldnever
beobstructed.Iftheamebecomes
signicantlyorangechecktheseopenings
forablockage.
• Iftheappliancecannotbeadjustedto
performcorrectlyitshouldnotbeuseduntil
servicedorrepaired.
• Tocheckthatthegascylinderislled,when
shakenasloshingsoundwillbeheard.
CAUTION:Accessiblepartsmaybeveryhot.
Keepyoungchildrenaway.
Duringusetheheaterbodywillbeveryhot.
Ensurethegasisturnedoffandtheheateris
coolbeforemoving.
USE OUTDOORS ONLY.
PROPANE PRODUCT
Thisapplianceshallonlybeusedwitha
propanegascylindercertiedtoAS2469.
IT MAY BE HAZARDOUS TO ATTEMPT TO
FIT OTHER TYPES OF GAS CONTAINERS.
Gascylindersshouldbestoredoutdoorsina
wellventilatedareaoutofreachofchildren.Any
indoorstorageshallcomplywithAS/NZS1596.
Afteruse,turnthegascylindervalveoffand
waitfortheametogoout.
Ifthereisaleakonyourappliance(smell
ofgas)immediatelyattempttoturnoffthe
cylindervalve.Removetheappliancetoa
well-ventilatedlocationawayfromanyignition
source.Checkforleaksusingsoapywater.Do
nottrytodetectleaksusingaame.
0274403/11
Important:Retaintheseinstructionsforfutureuse.
Gasmate
®
isaregisteredtrademarkof:SitroGroupAustraliaPtyLtdwww.gasmate.com.au
AberLtd-Hamilton,N.Z. www.gasmate.co.nz
Portable Gas Heater
Model No. 3020B & 3020BPL
Product Features:
• Newburnerdesignradiates
heatmoreefciently
• Polishedalloyreector
andsafetyguard
• Screwsdirectlyonto
a3/8”BSPLH
campingcylinder
• Propanegas
• Foroutdooruseonly
• AGAcertied
For any queries or assistance call
Customer Service
(AustraliaOnly)
1300 174 876
Hoursofoperation:
MondaytoFriday8.30am-5.30pmEST
Do not return to place of purchase.
Contact1300174876
Yourpurchasereceiptwillberequiredforwarrantyclaims.
background
3020B-01
3020B-02
3020B-03
3020B-04
3020B-05
3020B-06
3020B-05
3020B-07
3020B-08
3020B-09
3020BPL
AD901
AD902
GENERAL INFORMATION
GAS CONSUMPTION g/h MJ/h BTU FM Jet
3020B and 3020BPL 96g/h 4.9MJ/h 4650BTU 0.13mm
SAFE APPLIANCE LOCATIONS
Thisapplianceshallonlybeusedinanabove
groundopen-airsituationwithnaturalventilation,
withoutstagnantareas,wheregasleakageand
productsofcombustionarerapidlydispersedby
windandnaturalconvection.
Any enclosure in which the appliance is used
shall comply with the following:
Anenclosurewithwallsonallsides,butatleast
onepermanentopeningatgroundlevelandno
overheadcover(seeExample1).
Withinapartialenclosurethatincludesan
overheadcoverandnomorethantwowalls
(seeExample2&3).
Within a partial enclosure that includes an
overhead cover and more than two walls, the
following will apply:
atleast25%ofthetotalwallareaiscompletely
open,andatleast30%oftheremainingwallarea
isopenandunrestricted(seeExample4&5).
In the case of balconies, at least 20% of the
total wall area shall be and remain open and
unrestricted.
DIAGRAMMATIC REPRESENTATIONS OF OUTDOOR AREAS
Thefollowingguresarediagrammaticrepresentationsofoutdoorareas.Rectangularareashavebeen
usedinthesegures–thesameprinciplesapplytoanyothershapedarea.
INSTRUCTIONS FOR USE
1. Removeappliancefromcartonandremove
anytransitprotectionmaterial.
a. Theapplianceareamustbekeptclearand
freeofcombustiblematerials,gasolineand
otherflammablevapoursandliquids.
b. Gasorificesandburnermustbekept
clearofdirtandcobwebs.Flowof
combustionandventilationairthroughthe
perforatedportionsoftheappliancemust
notbeobstructed.
c.Anycleaningagentusedontheappliance
shouldbeofanon-combustibleand
non-corrosivenature.
2. Properclearancefromcombustiblematerials
mustbemaintainedatalltimes.Theminimum
clearancesareasfollows:
Minimum Clearance from Combustibles:
Side600mm Top600mm
Combustiblematerialsareconsideredtobe
wood,compressedpaper,plantfibres,plastic,
plexiglasorothermaterialscapableofbeing
ignitedandburned.
Suchmaterialsshallbeconsideredcombustible
eventhoughflameproofed,fire-retardant
treatedorplastered.Additionalclearancemay
berequiredforglass,paintedsurfacesandother
materialswhichmaybedamagedbyradiantor
convectionheat.
3. Attachtheappliancetothespecifiedcylinder
andensurethatcontrolvalveisfullyclosed
andthesealinggasketisfirmlysealedagainst
neckofconnector.
4. Theapplianceshouldonlybeoperatedonlyon
alevelandstablesurface.
LIGHTING AND REGULATING
Openthecylindercontrolvalveapproximately
halfaturnandlightgasatburnereitherwith
alightedmatchorpressingthepiezoignitor.
Regulatetheflametotheheatdesiredby
openingorclosingthevalve.Avoidexcessflame
fromthegauze.
REPLACING JETS
Ifthejetshouldbecomeblockedorneed
replacement,unscrewtheadaptorandremove
jet.Toclearblockedjetswashinpetrol.Donot
usewiresorprickers.Ifwashingisunsuccessful,
fitnewjet.
ANNUAL MAINTENANCE
Cleanthebodyofyourapplianceusingacotton
clothsoakedinsoapyhotwater.Neveruse
abrasiveorflammablecleaningproducts.Usea
softbrushtocleantheburner.
STORAGE
Whentheapplianceisnotuseditmustbe
storedinasuitableareatoprotectitfromany
riskofdeterioration.Keepitinawellventilated
areaandoutofreachofchildren.
HANDY HINTS
a.Inspectthe“O”Ringandrubberwasher
regularlyandreplaceifwornordamaged.
b. Neverconnectordisconnecttheappliance
nearanopenflame.
c. CheckforgasleakswithSOAPYWATER.
DO NOT USE A FLAME.
d. Ensuretheapplianceiscompletely
extinguishedbeforedisconnectingfromthe
cylinder.
e. DONOTplacetheappliancecloserthan60cm
fromceilingorflammablematerial.
f. Whenliftingappliancealwaysusethehandle
onthegascylinder,NEVERUSETHEHEATER.
SPARE PARTS
3020B-01 Gaurd
3020B-02 HeatingGauze
3020B-03 Locknut
3020B-04 Reflector
3020B-05 Locknut
3020B-06 BurnerTube
3020B-07 ShieldCup
3020B-08 AirMixingCollar
3020B-09 FMJet(0.13mm)
AD9-01 Connectorforcylinderwith
3/8”BSPLHmalethreading
AD9-02 0-Ringforconnector
3020BPL Piezoignitorassembly
GAS CONTROL
