KIT CONTAINS
If you have questions, call GE Appliances at 800.GE.CARES (800.432.2737) or visit our Website at: GEAppliances.com
In Canada, call 800.561.3344 or visit GEAppliances.ca
Pedestal/Riser Kit
GFP1528/GFR0728
Installation
Instructions
TOOLS YOU WILL NEED
ʄ
Safety Glasses
ʄ
1/4" Socket & Nut Driver
ʄ
9/16" Open end wrench
ʄ
Gloves
ʄ
Level
Rear Front
ʄ
Pedestal or Riser
ʄ
Pedestal or Riser Brackets - 2 each
ʄ
Drawer Divider
(Pedestal Kit Only)
Rear Front
ʄ
Washer/Dryer Brackets - 2 each
ʄ
Installation Screws
(#8-18 x 7/16) - 22
Or
1
INSTALL REAR PEDESTAL/RISER BRACKETS
FOR DRYER AND 32" WASHER
Align rear pedestal/riser bracket as shown on both
sides.
FOR 34" WASHER
Install pedestal/riser bracket rotated 180° from dryer
configuration.
2
INSTALL FRONT PEDESTAL BRACKETS
Install front pedestal/riser brackets on both sides.
PREPARE THE PEDESTAL/RISER
IMPORTANT: Shipping bolts should remain in place during installation.
