23” Speaker Stand for Surround Sound Speakers
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
Instruction Manual
https://vivo-us.com/products/stand-sp02b
SKU: STAND-SP02B
Chat live with an agent!
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
2
PACKAGE CONTENTS
WARNING!
B1 (x2)
Shelf
B2 (x2)
Pole
B3 (x2)
Base
If you do not understand these directions, or if you have any doubts about the safety of the
installation, please call a qualified technician. Check carefully to make sure there are no missing or
defective parts. Improper installation may cause damage or serious injury. Do not use this product
for any purpose that is not explicitly specified in this manual. Do not exceed weight capacity.
We cannot be liable for damage or injury caused by improper mounting, incorrect assembly or
inappropriate use.
NOTE: SOME HARDWARE INCLUDED MAY NOT BE USED
G1 (x2)
Rod
A1 (x2)
Nut
A2 (x2)
Washer
A3 (x2)
Washer
TIPOVER WARNING
SERIOUS OR FATAL CRUSHING INJURIES CAN OCCUR FROM TIPOVER. TO HELP PREVENT TIPOVER:
• NEVER ALLOW CHILDREN TO CLIMB, STAND, HANG, OR PLAY ON ANY PART OF STAND.
• USE TIPOVER RESTRAINT OR ANCHOR STAND TO WALL
USE OF TIPOVER RESTRAINTS MAY ONLY REDUCE, BUT NOT ELIMINATE RISK OF TIPOVER.
WARNING: CHOKING HAZARD
SMALL PARTS - NOT FOR CHILDREN UNDER 3 YEARS. ADULT SUPERVISION IS REQUIRED.
A4 (x8)
Carpet Spike
A5 (x8)
Pad
A6 (x1)
Wrench
A7 (x8)
So Feet
B1
B2
B3
A8 (x8)
Screw
3
ASSEMBLY STEPS
STEP 1
TOOLS NEEDED
Phillips
Screwdriver
STEP 2
Thread rod (G1) into base (B1).
Slide pole (B2) onto rod.
22 lbs
(10 kg)
DO NOT EXCEED WEIGHT CAPACITY.
Failure to do so may result in serious injury.
G1
B1
4
STEP 3
OPTION A: If stands will be used on carpet floor, screw carpet spikes (A4) into base.
OPTION B: If stands will be used on hard floor, attach so feet (A7) to base using screws (A8).
A4x4
5
STEP 4
Place glass base (B3) on rod.
B3
6
STEP 5
Secure base to rod using plastic washer (A3), metal washer (A2), and nut (A1), and tighten with
wrench (A6). Carefully flip the assembled stand right side up.
A1
A2
A3
A6
7
STEP 6
Apply non-slip pads (A5) to top shelf, making sure they’re properly aligned with the base of your
speaker.
A5
LAST UPDATED: 03/06/2020
