Versión en español
Si desea obtener una copia en español de estas
Instrucciones de Funcionamiento, sírvase escribir a
la dirección que se incluye a continuación.
Solicite la P/N 131921000.
Spanish Owner's Guides
Frigidaire Company
P. O. Box 212378
Augusta, GA 30917
Before Operating Your Dryer
Read your dryer Owner's Guide.
It has important
safety and warranty information. It also has many
suggestions for best drying results.
To reduce the risk of fire, electric
shock, or injury to persons, read the IMPORTANT
SAFETY INSTRUCTIONS in your dryer owner's guide
before operating this appliance.
Operating Steps
Read Drying Procedures in your Owner's Guide.
It
explains these operating steps in detail.
1. Prepare items for drying.
2. Check that lint screen is clean and in place.
3. Load the dryer.
If desired, add a dryer fabric
softener sheet.
4. Close the dryer door.
5. Set Temperature control.
6. Turn cycle selector clockwise to desired
setting.
7. Push START button for 2 seconds or turn the
START knob clockwise to ON, hold for 1-2
seconds and release.
8. A signal will sound when the cycle ends. The
Cycle Signal is adjustable on some models.
9. Remove items immediately and hang or fold.
10. Clean lint screen after every load.
T emperature Selection
Always follow directions on fabric care labels.
To avoid fire hazard, do not use heat to
dry items containing feathers or down, foam rubber,
plastics, or similarly textured, rubber-like materials. Use
Air Fluff-No Heat setting (some models) or Cool Down
only.
The
REGULAR-HIGH HEAT, PERM PRESS-MEDIUM
HEAT
, and
KNITS/DELICATES-LOW HEAT
temp-
erature settings may be used with any cycle setting. The
AIR FLUFF-NO HEAT
setting (some models) can be used
only in the Timed Dry cycle.
AIR FLUFF-NO HEAT
setting (some models) tumbles the
load without heat. Use Air Fluff (some models) or Cool
Down to freshen clothing, pillows or blankets, or to dust
draperies.
Printed in U.S.A.
OPERATING INSTRUCTIONS
P/N 134145400A (0503)
ON
OFF
COOL DOWN
PRESS SAVER
START
20
30
40
50
60
70
LESS DRY
AUTOMATIC
PERM PRESS/COLORS
START
REGULAR/WHITES
HIGH HEAT
PERM PRESS/COLORS
MEDIUM HEAT
KNITS/DELICATES
LOW HEAT
AIR FLUFF
NO HEAT
TEMPERATURE
MORE DRY
* SOME MODELS
*
TIMED DRY
REGULAR
*
Cycle Selection
Turn cycle selector clockwise to desired cycle and
setting.
Each cycle ends with a cool down period. The heat
automatically turns off and the load continues to
tumble for 5-10 minutes. This reduces wrinkling and
makes items easier to handle during unloading.
Drying time varies depending on size and dampness of
load, weight and fabric type. Room temperature and
humidity, type of installation and electrical voltage or
gas pressure can also affect drying time.
Automatic Perm Press/Colors Cycle
This cycle is best for permanent press, knit and delicate
items. Drying time is determined automatically at the
temperature selection of your choice.
• Medium heat is suggested for permanent press
items.
• Low heat is suggested for knit and delicate items.
If the dried load cannot be removed promptly, the cycle
selector will advance to the
Press Saver/Fabric Sentry
Energy Saving Tips
• Keep the lint screen clean and exhaust the dryer
correctly.
• Sort laundry properly and select proper temperature
and cycle settings. Choose an automatic dry cycle
whenever possible for accurate drying time.
• Dry only full loads. Single items and small loads
usually take longer to dry.
• Avoid overloading, adding wet items to a partially dry
load, and overdrying.
• Dry one load after another to take advantage of a
warm dryer.
• Opening the door needlessly causes warm air to
escape, which prolongs drying time.
• If possible, use the dryer on low humidity days.
• Install the dryer in an area where the room temperature
is at least 45°F (7°C).
setting where unheated tumbling continues for 40
minutes to help reduce wrinkling.
Unless the Cycle Signal has been turned off (some
models), it will sound briefly every 5 minutes as a
reminder to remove the load.
Automatic Regular/Whites Cycle
This cycle is best for cotton items that can be tumble
dried.
Drying time is determined automatically at the
temperature selection of your choice. This cycle is best
for items of similar fabric, weight and construction.
• For items requiring more drying time, set cycle
selector on
MORE/MAX
• For items requiring less drying time, set cycle selector
on
LESS /MIN
Timed Dry Regular Cycle
This cycle provides up to 70 minutes of drying time at
the temperature selection of your choice.
P/N 134145400A (0503)
ON
OFF
COOL DOWN
PRESS SAVER
START
20
30
40
50
60
70
LESS DRY
AUTOMATIC
PERM PRESS/COLORS
START
REGULAR/WHITES
HIGH HEAT
PERM PRESS/COLORS
MEDIUM HEAT
KNITS/DELICATES
LOW HEAT
AIR FLUFF
NO HEAT
TEMPERATURE
MORE DRY
* SOME MODELS
*
TIMED DRY
REGULAR
*
