Neff U1ACE2HG0B N 50 Built-in double oven Graphite-Grey

User Manual - Transcript

• Page 1: Double oven en User manual and installation instructions U1ACE2H0B
• Page 2 - English - : en Safety Table of contents USER MANUAL 1 Safety2 2 Preventing material damage 4 3 Environmental protection and saving en ergy 4 4 Familiarising yourself with your appliance 5 5 Accessories8 6 Before using for the first time 10 7 Basic operation 10 8 Timesetting options11 9 Childproof lock12 10 Rapid heating 12 11 Basic settings13 12 Cleaning and servicing14 13 Cleaning function16 14 Shelf supports16 15 Appliance door19 16 Troubleshooting23 17 Disposal25 18 Customer Service25 19 How it works25 20 INSTALLATION INSTRUCTIONS 30 201 General installation instructions 30 1 Safety Observe the following safety instructions 11 General information Read this instruction manual carefully Keep the instruction manual and the product information safe for future refer ence or for the next owner Do not connect the appliance if it has been damaged in transit 12 Intended use This appliance is designed only to be built into kitchen units Read the special installation instructions Only a licensed professional may connect ap pliances without plugs Damage caused by in correct connection is not covered under the warranty Only use this appliance To prepare meals and drinks In private households and in enclosed spaces in a domestic environment Up to an altitude of max 4000m above sea level Do not use the appliance with an external timer or a remote control 13 Restriction on user group This appliance may be used by children aged 8 or over and by people who have reduced physical sensory or mental abilities or inad equate experience andor knowledge provided that they are supervised or have been instructed on how to use the appliance safely and have understood the resulting dangers Do not let children play with the appliance Children must not perform cleaning or user maintenance unless they are at least 15 years old and are being supervised Keep children under the age of 8 years away from the appliance and power cable 14 Safe use Always place accessories in the cooking com partment the right way round quotAccessoriesquot Page8 WARNINGRisk of fire Combustible objects that are left in the cook ing compartment may catch fire Never store combustible objects in the cooking compartment If smoke is emitted the appliance must be switched off or the plug must be pulled out and the door must be held closed in order to stifle any flames Loose food remnants fat and meat juices may catch fire Before using the appliance remove the worst of the food residues and remnants from the cooking compartment heating ele ments and accessories
• Page 3 - English - : Safety en Opening the appliance door creates a draught Greaseproof paper may come into contact with the heating element and catch fire Never place greaseproof paper loosely over accessories when preheating the ap pliance and while cooking Always cut greaseproof paper to size and use a plate or baking tin to hold it down WARNINGRisk of burns The appliance and its parts that can be touched become hot during use Caution should be exercised here in order to avoid touching heating elements Young children under 8 years of age must be kept away from the appliance Accessories and cookware get very hot Always use oven gloves to remove ac cessories or cookware from the cooking compartment When the cooking compartment is hot any al coholic vapours inside may catch fire Only use small quantities of drinks with a high alcohol content in food Open the appliance door carefully WARNINGRisk of scalding The accessible parts of the appliance become hot during operation Never touch these hot parts Keep children at a safe distance Hot steam may escape when you open the appliance door Steam may not be visible de pending on the temperature Open the appliance door carefully Keep children at a safe distance If there is water in the cooking compartment when it is hot this may create hot steam Never pour water into the cooking compart ment when the cooking compartment is hot WARNINGRisk of injury Scratched glass in the appliance door may develop into a crack Do not use any harsh or abrasive cleaners or sharp metal scrapers to clean the glass on the oven door as they may scratch the surface The appliance and its parts that can be touched may have sharp edges Take care when handling and cleaning them If possible wear protective gloves The hinges on the appliance door move when the door is opened and closed which could trap your fingers Keep your hands away from the hinges Components inside the appliance door may have sharp edges Wear protective gloves WARNINGRisk of electric shock Incorrect repairs are dangerous Repairs to the appliance should only be carried out by trained specialist staff Only use genuine spare parts when repair ing the appliance If the power cord of this appliance is dam aged it must be replaced by trained spe cialist staff If the insulation of the power cord is dam aged this is dangerous Never let the power cord come into contact with hot appliance parts or heat sources Never let the power cord come into contact with sharp points or edges Never kink crush or modify the power cord An ingress of moisture can cause an electric shock Do not use steam or highpressure clean ers to clean the appliance If the appliance or the power cord is dam aged this is dangerous Never operate a damaged appliance Never pull on the power cord to unplug the appliance Always unplug the appliance at the mains If the appliance or the power cord is dam aged immediately unplug the power cord or switch off the fuse in the fuse box Call customer services Page25 WARNINGRisk of suffocation Children may put packaging material over their heads or wrap themselves up in it and suffocate Keep packaging material away from chil dren Do not let children play with packaging ma terial
• Page 4 - English - : en Preventing material damage Children may breathe in or swallow small parts causing them to suffocate Keep small parts away from children Do not let children play with small parts 15 Halogen bulb WARNINGRisk of burns The bulbs in the cooking compartment get very hot There is still a risk of burning for some time after they have been switched off Do not touch the glass cover Avoid contact with your skin when cleaning WARNINGRisk of electric shock When changing the bulb the bulb socket con tacts are live Before replacing the bulb ensure that the appliance is switched off in order to pre vent a potential electric shock Also unplug the appliance from the mains or switch off the circuit breaker in the fuse box 2  Preventing material damage 21 General ATTENTION Objects on the cooking compartment floor at over 50C will cause heat to build up The baking and roasting times will no longer be correct and the enamel will be damaged Do not place any accessories greaseproof paper or foil of any kind on the cooking compartment floor Only place cookware on the cooking compartment floor if a temperature above 50C has been set When the cooking compartment is hot any water in side it will create steam The change in temperature may cause damage Never pour water into the cooking compartment when it is still hot Never place cookware containing water on the cooking compartment floor The prolonged presence of moisture in the cooking compartment leads to corrosion Allow the cooking compartment to dry after use Do not keep moist food in the cooking compartment for a long time with the door closed Do not store food in the cooking compartment Leaving the appliance to cool down with the door open will damage the front of neighbouring kitchen units over time Always allow the cooking compartment to cool down with the door closed after cooking at high temperatures Take care not to trap anything in the appliance door Only leave the cooking compartment to dry with the door open if a lot of moisture was produced during operation Fruit juice dripping from the baking tray leaves stains that cannot be removed When baking very juicy fruit flans do not pack too much on the baking tray If possible use the deeper universal pan Using oven cleaner in a hot cooking compartment damages the enamel Never use oven cleaner in the cooking compartment when it is still warm Remove all food remnants from the cooking com partment and the appliance door before you next heat up the appliance If the seal is very dirty the appliance door will no longer close properly during operation This may dam age the front of adjacent kitchen units Keep the seal clean at all times Never operate the appliance if the seal is damaged or missing Sitting or placing objects on the appliance door may damage it Do not place hang or support objects on the appli ance door Do not place cookware or accessories on the appli ance door With certain models accessories may scratch the door pane when closing the appliance door Always push accessories fully into the cooking com partment 3  Environmental protection and saving energy 31 Disposing of packaging The packaging materials are environmentally compat ible and can be recycled Sort the individual components by type and dispose of them separately
• Page 5 - English - : Familiarising yourself with your appliance en 32 Saving energy If you follow these instructions your appliance will use less power Only preheat the appliance if the recipe or the recom mended settings tell you to do so Not preheating the appliance can reduce the en ergy used by up to 20 Use darkcoloured blackcoated or enamelled baking tins These types of baking tin absorb the heat particu larly well Open the appliance door as little as possible during operation This maintains the temperature in the cooking com partment and eliminates the need for the appliance to reheat When baking multiple dishes do so in succession or in parallel The cooking compartment is heated after baking the first dish This reduces the baking time for the second cake If the cooking time is relatively long you can switch the appliance off 10minutes before the cooking time ends There will be enough residual heat to finish cooking the dish Remove any accessories that are not being used from the cooking compartment Accessories that are not being used do not need to be heated Allow frozen food to defrost before cooking This saves the energy that would otherwise be re quired to defrost it Note The appliance requires A maximum of 1W when the appliance is in opera tion with the display switched on A maximum of 05W when the appliance is in oper ation with the display switched off 4  Familiarising yourself with your appliance 41 Controls You can use the control panel to configure all functions of your appliance and to obtain information about the operat ing status On certain models specific details such as colour and shape may differ from those pictured 4 5 6 8 9 10 Buttons quotButtonsquot Page6 Main oven Controls for the main oven Function selector You can turn the function selector clockwise or anticlockwise from the zero setting quotTypes of heatingquot Page6quotFunctionsquot Page7
• Page 6 - English - : en Familiarising yourself with your appliance Heatingup control quotHeatingup controlquot Page8 Temperature selector Use the temperature selector to set the temper ature for the type of heating or select the set ting for other functions You can turn the tem perature selector clockwise from the quotOffquot posi tion until it offers resistance quotTemperature and setting levelsquot Page7 Display quotDisplayquot Page6 Top oven Controls for the top oven Function selector You can turn the function selector clockwise or anticlockwise from the zero setting quotTypes of heatingquot Page6 quotFunctionsquot Page7 Heatingup control quotHeatingup controlquot Page8 Temperature selector Use the temperature selector to set the temper ature for the type of heating or select the set ting for other functions You can turn the tem perature selector clockwise from the quotOffquot posi tion until it offers resistance quotTemperature and setting levelsquot Page7 NoteDepending on the appliance type the control knobs can be pushed in To click it in or out push the control knob in when it is in the off position 42 Buttons The buttons are touchsensitive surfaces Press the corresponding button to select a function Symbol Name Use Timesetting options Sets the time timer cooking time or end time quotTimesetting optionsquot Page11 Left arrow Decreases the adjustment values Right arrow Increases the adjustment values 43 Display The display shows the current settings options or relevant information The red bar above or below a symbol indicates which value is active or can be changed Symbol Name Use Childproof lock activ ated The childproof lock is activated quotChildproof lockquot Page12 Heatingup indicator Appliance is heating quotHeatingup controlquot Page8 44 Types of heating Here you can find an overview of the types of heating You can find recommendations on using the types of heating Use the function selector to set the types of heating Main oven Symbol Type of heating What its used forhow it works CircoTherm hot air Bake and roast on one or more levels The fan distributes the heat from the ringshaped heating element in the back wall evenly around the cooking compartment CircoTherm gentle Cook selected dishes gently on one level without preheating The fan distributes the heat from the ringshaped heating element in the back wall evenly around the cooking compartment The food is cooked in phases us ing residual heat Select a temperature of between 120C and 230C Always keep the appliance door closed when cooking This type of heating is used to determine the energy consumption in air recircu lation mode and the energy efficiency class
• Page 7 - English - : Familiarising yourself with your appliance en Symbol Type of heating What its used forhow it works Fullsurface grill Grill flat items such as steak and sausages or make toast Gratinate food The entire area underneath the grill element becomes hot Circoroasting Roast poultry whole fish and larger pieces of meat The grill element and the fan switch on and off alternately The fan circulates the hot air around the food Topbottom heating Traditionally bake or roast on one level This type of heating is ideal for cakes with moist toppings The heat is emitted evenly from above and below This type of heating is used to measure the energy consumption in the conven tional mode Top oven Symbol Type of heating What its used forhow it works Topbottom heating Bake on one level The heat is emitted evenly from above and below This type of heating is used to measure the energy consumption in the conven tional mode Bottom heating Final baking or cooking food in a bain marie Heat is emitted from below Grill small area Grill small quantities of steak sausages or toast Brown small quantities of food The central area underneath the grill element becomes hot Fullsurface grill Grill flat items such as steak sausages or toast Brown food The entire area underneath the grill element becomes hot 45 Functions Here you can find an overview of the functions Use the function selector to set the functions Main oven Symbol Name Use Rapid heating Rapidly preheat the cooking compartment without accessories quotRapid heatingquot Page12 Oven light Illuminate the cooking compartment without heating quotLightingquot Page8 EasyClean EasyClean removes light dirt from the cooking compartment quotCleaning aid EasyClean quot Page16 Top oven Symbol Name Use Oven light Illuminate the cooking compartment without heating quotLightingquot Page8 46 Temperature and setting levels There are different settings for the types of heating and functions NoteFor temperature settings above 250C the appliance reduces the temperature to approx 240C after ap prox 10minutes If your appliance has the topbottom heating or bottom heating types this temperature reduction does not take place there Symbol Function Use Zero setting The appliance is not heating up 50275 Temperature range Set the temperature in the cooking compartment inC
• Page 8 - English - : en Accessories Symbol Function Use EasyClean Set the cleaning aid Grill intensive The maximum temperature that can be set for Fullsurface grill and Grill small area depending on the appliance type Heatingup control The heatingup indicator for the oven remains lit while the appliance is heating NoteDue to thermal inertia the temperature displayed may differ slightly from the actual temperature inside the cooking compartment Heatingup indicator When the main oven heats up the symbol also lights up in the display This symbol goes out when heating is paused 47 Cooking compartment The functions in the cooking compartment make your appliance easier to use Rails The rails in the cooking compartment enable you to place accessories at different heights quotAccessoriesquot Page8 The shelf positions are numbered from bottom to top You can remove the rails e g for cleaning quotShelf supportsquot Page16 Main cooking compartment The cooking compartment has four shelf positions Top cooking compartment The cooking compartment has three shelf positions Lighting The oven lamp lights up the cooking compartment With most types of heating and functions the lighting lights up during operation When the function selector is turned to bring operation to an end the lighting goes out The Oven light setting on the function selector can be used to switch on the light without heating NoteThe cooling fan also runs at position Oven light Cooling fan The cooling fan switches on automatically during oper ation The hot air escapes above the door ATTENTION Do not cover the ventilation slot above the appliance door The appliance overheats Ensure that the ventilation slots are unobstructed To ensure that the appliance cools down more quickly after operation the cooling fan continues to run for a certain period afterwards Appliance door If you open the appliance door during operation the operation continues 5  Accessories Use original accessories These have been made espe cially for your appliance NoteAccessories may become deformed if they get hot Deformation has no effect on function As the ac cessory cools down it will regain its original shape The accessories supplied may differ depending on the appliance model
• Page 9 - English - : Accessories en Accessories Use Wire rack Cake tins Ovenproof dishes Cookware Meat eg roasting joints or steak Frozen meals Universal pan Moist cakes Baked items Bread Large roasts Frozen meals Catching dripping liquids eg fat when grilling food on the wire rack 51 Locking function The locking function prevents the accessories from tilt ing when they are pulled out You can pull out the accessories approximately halfway without them tipping The accessories must be inserted into the cooking compartment correctly for the tilt pro tection to work properly 52 Sliding accessories into the cooking compartment Always slide accessories into the cooking compartment correctly This is the only way to ensure that accessor ies can be pulled out approximately halfway without tip ping Turn the accessories so that the notch is at the rear and is facing downwards Insert accessories between the two guide rods for the shelf position Wire rack Insert the wire rack with the open side facing the appliance door and the curved lip facing downwards Baking tray Eg univer sal pan or baking tray Slide the tray eg the universal pan in with the sloping edge facing the appliance door Place the accessory at the shelf positions with the pullout rails and pull out the pullout rails Wire rack or baking tray Position the accessory so that its edge is behind the lug on the pull out rail NoteThe pullout rails lock in place when they are fully pulled out Gently push the pullout rails back into the cooking compartment Push the accessory all the way in making sure that it does not touch the appliance door NoteTake any accessories that you will not be using out of the cooking compartment while the appliance is in operation Combining accessories You can combine the wire rack with the universal pan to catch any liquid that drips down Place the wire rack on the universal pan so that both spacers are on the rear edge of the univer sal pan Insert the universal pan between the two guide rods for a shelf position In so doing the wire rack is on top of the upper guide rod Wire rack on univer sal pan 53 Other accessories You can purchase other accessories from our after sales service specialist retailers or online You will find a comprehensive range of products for your appliance in our brochures and online wwwneffinternationalcom
• Page 10 - English - : en Before using for the first time Accessories vary from one appliance to another When purchasing accessories always quote the exact product number E no of your appliance You can find out which accessories are available for your appliance in our online shop or from our after sales service 6  Before using for the first time Configure the settings for initial startup Clean the ap pliance and accessories 61 Initial use You need to make settings for initial use before you can use your appliance Setting the time on the clock Once the appliance has been connected to the mains or following a power failure the time flashes on the dis play The time starts at quot1200quot Set the current time RequirementThe function selector must be set to the quotOffquot position Use the or button to set the time Press the button a The time that is set appears on the display TipYou can go to the basic settings Page13 to specify whether or not the time should be shown on the display 62 Cleaning the appliance before using it for the first time Clean the cooking compartment and accessories be fore using the appliance to prepare food for the first time Remove any accessories and leftover packaging such as polystyrene pellets from the cooking com partment Before heating the appliance wipe the smooth sur faces in the cooking compartment with a soft damp cloth Keep the room ventilated while the appliance is heating Set the type of heating and temperature quotBasic operationquot Page10 Main oven Top oven Type of heating CircoTherm hot air Topbottom heating Temperat ure Maximum 240C Cooking time 1 hour 1 hour Switch off the appliance after the specified cooking time Wait until the cooking compartment has cooled down Clean the smooth surfaces with soapy water and a dish cloth Clean the accessories using soapy water and a dish cloth or soft brush 7  Basic operation 71 Switching on the appliance Turn the function selector to any position other than the quotOffquot position a The appliance is switched on 72 Switching off the appliance Turn the function selector to the quotOffquot position a The appliance is switched off 73 Setting the type of heating and temperature Use the function selector to set the type of heating Use the temperature selector to set the temperature or grill setting a The appliance starts heating after a few seconds When your food is ready switch off the appliance Tips The most suitable type of heating for your food can be found in the description of the type of heating quotTypes of heatingquot Page6 You can also set a cooking time and end time on the appliance quotTimesetting optionsquot Page11 Changing the type of heating You can change the type of heating at any time Use the function selector to set the required type of heating Changing the temperature You can change the temperature at any time Use the temperature selector to set the required temperature
• Page 11 - English - : Timesetting options en 8  Timesetting options Your appliance has different timesetting options with which you can control its operation 81 Overview of the timesetting options With the button select the different timesetting op tions Timesetting option Use Timer The timer can be set independently of the appliance when it is in opera tion It does not affect the appliance Cooking time Main oven If you set a cooking time operation of the appliance stops automatically once this time has elapsed End time Main oven For the cooking time you can set the time at which opera tion ends The appliance starts up automatically so that it finishes cook ing at the required time Time You can set the time 82 Setting the timer The timer runs independently of the appliance when it is in operation The timer can be set when the appli ance is switched on or off up to 23 hours and 59 minutes The timer has its own audible signal so that you can tell whether it is the timer or a cooking time which has elapsed Press the button repeatedly until is highlighted in the display Use the or button to set the timer duration Button Default value 5minutes 10 minutes The timer duration can be set in 30second incre ments up to 10 minutes Above 10 minutes the time increments become longer the higher the value a The timer starts and the timer duration begins to count down after a few seconds a An audible signal sounds and the timer duration is zero in the display when the timer duration has elapsed Once the timer duration has elapsed Press any button to switch off the timer Changing the timer You can change the timer duration at any time Requirement is highlighted on the display Use the or button to change the timer duration a The appliance applies the change after a few seconds Cancelling the timer You can cancel the timer duration at any time Requirement is highlighted on the display Use the button to reset the timer duration to zero a After a few seconds the appliance applies the change and goes out 83 Setting the cooking time You can set a cooking time for operation of up to 23 hours 59 minutes RequirementA type of heating and a temperature or setting are set for the main oven Press the button repeatedly until is highlighted in the display Use the or button to set the cooking time Button Default value 10 minutes 30minutes The cooking time can be set in 1minute increments up to 1 hour and then in 5minute increments a The appliance starts heating and the cooking time counts down after a few seconds a If the cooking time has elapsed an audible signal sounds and the display shows the cooking time as zero When the cooking time has elapsed Press any button to end the audible signal before it sounds To set a cooking time again press the button When your food is ready switch off the appli ance Changing the cooking time You can change the cooking time at any time Requirement is highlighted on the display Change the cooking time using the or button a The appliance applies the change after a few seconds Cancelling the cooking time You can cancel the cooking time at any time Requirement is highlighted on the display Reset the cooking time to zero using the button a After a few seconds the appliance applies the change and continues to heat without a cooking time 84 Setting the end time You can delay the time at which cooking is due to fin ish by up to 23 hours and 59 minutes Notes The end time cannot be set for types of heating with grill function In order to achieve a good cooking result do not delay the end time once the appliance is already in operation Food will spoil if you leave it in the cooking com partment too long
• Page 12 - English - : en Childproof lock Requirements A type of heating and a temperature or setting are set for the main oven A cooking time is set Press the button repeatedly until is highlighted in the display Press the or button a The display shows the calculated end time Use the or button to delay the end time a After a few seconds the appliance applies the set ting and the display shows the set end time a Once the calculated start time has been reached the appliance starts heating up and the cooking time starts counting down a Once the time has elapsed an audible signal sounds and the display shows the cooking time as zero When the cooking time has elapsed Press any button to end the signal prematurely To set another cooking time press the button When your food is ready switch off the appli ance Changing the end time In order to achieve a good cooking result you can only change the set end time before operation starts and the cooking time starts counting down Requirement is highlighted on the display Use the or button to delay the end time a The appliance applies the change after a few seconds Cancelling the end time You can delete the set end at any time Requirement is highlighted on the display Reset the end time to the current time plus the set cooking time using the button a After a few seconds the appliance applies the change and starts heating up The cooking time counts down 85 Setting the time on the clock Once the appliance has been connected to the mains or following a power failure the time flashes on the dis play The time starts at quot1200quot Set the current time RequirementThe function selector must be set to the quotOffquot position Use the or button to set the time Press the button a The time that is set appears on the display TipYou can go to the basic settings Page13 to specify whether or not the time should be shown on the display Changing the time on the clock You can change the time on the clock at any time RequirementThe function selector must be set to the quotOffquot position Press the button repeatedly until is highlighted in the display Use the or button to change the time a The appliance applies the change after a few seconds 9  Childproof lock Secure your appliance to prevent children from acci dentally switching on the main oven or changing the settings Notes You can go to the basic settings Page13 to specify whether you want the option to set the child proof lock After a power cut the childproof lock is deactivated The childproof lock only allows you to lock the controls for the main oven 91 Automatic childproof lock When the appliance is switched off it locks automatic ally You need to pause the automatic childproof lock before you switch on the appliance You can activate and deactivate the automatic child proof lock in the basic settings quotBasic settingsquot Page13 Pausing the automatic childproof lock RequirementThe automatic childproof lock is activ ated in the basic settings quotBasic settingsquot Page13 Press and hold the button until goes out on the display 10  Rapid heating To save time you can use rapid heating to shorten the preheat time Only use rapid heatup when a temperature of over 100C has been set After rapid heating it is best to use the following types of heating CircoTherm hot air 101 Setting rapid heating To ensure an even cooking result do not place the food in the cooking compartment until rapid heating has come to an end Use the function selector to select rapid heating Use the temperature selector to set the required temperature a Rapid heating starts after a few seconds
• Page 13 - English - : Basic settings en a When the rapid heating process ends an audible signal sounds and the heating indicator goes out Use the function selector to set a suitable type of heating Place the food in the cooking compartment 11  Basic settings You can configure the basic settings for your appliance to meet your needs 111 Overview of the basic settings Here you can find an overview of the basic settings and factory settings The basic settings depend on the features of your appliance Display Basic setting Selection Automatic childproof lock quotChildproof lockquot Page12 no yes Time display hide the time display the time Signal duration upon completion of a cook ing time or timer period 10 seconds 30 seconds 2 minutes Button tone when pressing a button off on Cooling fan runon time short medium long extra long Waiting time until a setting is adopted 3 seconds 6 seconds 10 seconds Childproof lock can be adjusted quotChildproof lockquot Page12 no yes Water hardness softened soft up to 15mmoll medium 1525mmoll hard 2538mmoll very hard above 38mmoll Factory setting may vary according to model Only possible if has been set Only for appliance types with steam function 112 Changing basic settings RequirementThe appliance is switched off Press and hold the button for approximately fourseconds a The first basic setting appears in the display eg Use the or button to change the setting Use the button to switch to the next basic setting To save the changes press and hold the button for approx fourseconds NoteFollowing a power failure the factory basic set tings are restored 113 Discarding changes to the basic settings Turn the function selector a All changes are discarded and not saved
• Page 14 - English - : en Cleaning and servicing 12  Cleaning and servicing To keep your appliance working efficiently for a long time it is important to clean and maintain it carefully 121 Cleaning products In order to avoid damaging the various oven surfaces on the appliance do not use unsuitable cleaning products WARNINGRisk of electric shock An ingress of moisture can cause an electric shock Do not use steam or highpressure cleaners to clean the appliance ATTENTION Unsuitable cleaning products may damage the sur faces of the appliance Do not use harsh or abrasive cleaning products Do not use cleaning products with a high alcohol content Do not use hard scouring pads or cleaning sponges Do not use any special cleaners for cleaning the ap pliance while it is hot Using oven cleaner in a hot cooking compartment damages the enamel Never use oven cleaner in the cooking compartment when it is still warm Remove all food remnants from the cooking com partment and the appliance door before you next heat up the appliance New sponge cloths contain residues from production Wash new sponge cloths thoroughly before use Suitable cleaning agents Only use cleaning products that are suitable for the dif ferent surfaces on your appliance Follow the instructions on cleaning the appliance quotCleaning the appliancequot Page15 Appliance front Surface Suitable cleaning agents Information Stainless steel Hot soapy water Special stainless steel cleaning products suitable for hot sur faces To prevent corrosion remove any patches of limescale grease starch or albumin eg egg white on stainless steel surfaces imme diately Apply a thin layer of the stainless steel cleaning product with a soft cloth Plastic or painted surfaces Eg control panel Hot soapy water Do not use glass cleaner or a glass scraper Appliance door Area Suitable cleaning agents Information Door panels Hot soapy water Do not use a glass scraper or a stainless steel wool TipRemove the door panels in order to clean them thoroughly quotAppliance doorquot Page19 Door cover Made of stainless steel Stainless steel cleaner Made of plastic Hot soapy water Do not use glass cleaner or a glass scraper TipRemove the door cover for thorough cleaning quotAppliance doorquot Page19 Door handle Hot soapy water To avoid permanent stains remove descaling agents from the door handle immediately Door seal Hot soapy water Do not remove or scrub
• Page 15 - English - : Cleaning and servicing en Cooking compartment Area Suitable cleaning agents Information Enamel surfaces Hot soapy water Vinegar water Oven cleaner Soak any heavily soiled areas and use a brush or steel wool Leave the appliance door open to dry the cooking compartment after cleaning it Notes Enamel burns at very high temperatures causing minor discol ouration The functionality of your appliance is not affected by this The edges of thin trays cannot be completely enamelled and may be rough This does not impair corrosion protection Food residues will leave a white coating on the enamel surfaces The coating does not pose a health risk The functionality of your appliance is not affected by this You can remove residues with lemon juice Glass cover for the oven light Hot soapy water Use oven cleaner to remove very heavy soiling Rails Hot soapy water Soak any heavily soiled areas and use a brush or steel wool TipRemove the shelf supports for cleaning quotShelf supportsquot Page16 Pullout system Hot soapy water Use a brush to remove very heavy soiling Clean the pullout rails while they are pushed in so that you do not remove the lubricant Do not clean in the dishwasher TipDetach the pullout system for cleaning quotShelf supportsquot Page16 AccessorIes Hot soapy water Oven cleaner Soak any heavily soiled areas and use a brush or steel wool Enamelled accessories are dishwashersafe 122 Cleaning the appliance In order to avoid damaging the appliance you must clean your appliance only as specified and with suit able cleaning products WARNINGRisk of burns The appliance and its parts that can be touched be come hot during use Caution should be exercised here in order to avoid touching heating elements Young children under 8 years of age must be kept away from the appliance WARNINGRisk of fire Loose food remnants fat and meat juices may catch fire Before using the appliance remove the worst of the food residues and remnants from the cooking com partment heating elements and accessories RequirementRead the information on cleaning products quotCleaning productsquot Page14 Clean the appliance using hot soapy water and a dish cloth For some surfaces you can use alternative cleaning agents quotSuitable cleaning agentsquot Page14 Dry with a soft cloth
• Page 16 - English - : en Cleaning function 13  Cleaning function You can use the cleaning function to clean the appli ance 131 Cleaning aid EasyClean Use the cleaning aid EasyClean for intermediate clean ing of the cooking compartment The cleaning aid EasyClean softens dirt by vaporising the soapy water The dirt can then be removed more easily Setting the cleaning aid EasyClean WARNINGRisk of scalding If there is water in the cooking compartment when it is hot this may create hot steam Never pour water into the cooking compartment when the cooking compartment is hot Notes You cannot delay the end time The length of time has been preset and cannot be changed Requirements Start the cleaning aid only when the cooking com partment has completely cooled down To remove particularly stubborn dirt leave the soapy water to work for some time before starting the cleaning aid To remove particularly stubborn dirt rub soapy water onto the dirt on smooth surfaces before starting the cleaning aid Remove the accessories from the cooking compart ment ATTENTION Distilled water in the cooking compartment leads to corrosion Do not use distilled water Mix 04litres water with a drop of washingup liquid and pour into the centre of the cooking compart ment floor Use the function selector and the temperature se lector to set the cleaning aid a The length of time appears in the display a The cleaning aid starts after a few seconds The duration counts down in the display a Once the cleaning aid has run through to the end an audible signal sounds NoteIf flashes in the display when the cleaning aid is switched on this indicates that the cooking compart ment has not completely cooled down Switch off the appliance Wait until appears in the display and switch the cleaning aid back on Recleaning the cooking compartment ATTENTION The prolonged presence of moisture in the cooking compartment leads to corrosion After using the cleaning aid wipe the cooking com partment clean and allow it to dry fully Open the appliance door and remove the remaining water with an absorbent sponge cloth Clean the smooth surfaces in the cooking compart ment with a dish cloth or a soft brush Stubborn residues can be removed using a stainless steel scouring pad Remove limescale with a cloth soaked in vinegar Then wipe with clean water and rub dry with a soft cloth including under the door seal If you are unable to remove stubborn dirt repeat the cleaning aid after the cooking compartment has cooled down To switch off turn the function selector to the zero setting Open the appliance door to the stop position ap prox 30 for approx one hour to allow the sur faces in the cooking compartment to dry thoroughly To dry the cooking compartment quickly heat up the appliance for approx fiveminutes at Circo Therm hot air and 50 C while the door is open 14  Shelf supports To clean the rails and the cooking compartment or to replace the rails you can remove these 141 Detach the rails in the main cooking compartment WARNINGRisk of burns The shelf supports get very hot Never touch the shelf supports when hot Always allow the appliance to cool down Keep children at a safe distance Lift the rail forwards slightly and detach it Pull the whole rail to the front and remove it
• Page 17 - English - : Shelf supports en 142 Attaching the rails in the main cooking compartment Notes The rails only fit on the right or left For both pullout rails ensure that you can pull them forwards and out First push the rail into the middle of the rear socket until the rail rests against the cooking compartment wall and then push this back Push the rail into the front socket until the rail also rests against the cooking compartment wall and then press this downwards 143 Removing the pullout rail WARNINGRisk of burns The shelf supports get very hot Never touch the shelf supports when hot Always allow the appliance to cool down Keep children at a safe distance NoteIf necessary you can use pullout rails on all levels Push on the tab marked PUSH behind the rail and push the rail to the rear Keep the PUSH tab pushed back and swing the rail outwards Pull the rail out towards the front until the retainer at the back unhooks Remove the pullout rail Clean the pullout rail quotCleaning productsquot Page14 144 Attaching the pullout rail NoteThe pullout rails only fit on the right or left Make sure when you fit them that you can pull them out to wards the front
• Page 18 - English - : en Shelf supports Insert the pullout rail between the two bars Push the retainer in between the lower and the upper bar Keep the PUSH tab pushed in and swing the pull out rail inwards until the front retainer is located between the two bars Release the PUSH tab a The retainer clicks into place Pull the pullout rail out as far as it will go and slide it back in 145 Detaching the rails in the top cooking compartment WARNINGRisk of burns The shelf supports get very hot Never touch the shelf supports when hot Always allow the appliance to cool down Keep children at a safe distance Lift the rail forwards slightly and detach it Pull the rail to the front and remove it 146 Attaching the rails in the top cooking compartment Notes The rails only fit on the right or left For both shelf supports ensure that the hooks that are attached at the rear are pointing upwards First push the rail into the middle of the rear socket until the rail rests against the cooking compartment wall and then push this back Push the rail into the front socket until the rail also rests against the cooking compartment wall and then press this downwards
• Page 19 - English - : Appliance door en 15  Appliance door To ensure that your appliance retains its appearance and remains fully functioning for a long time you can detach the appliance door and clean it 151 Detaching the lower appliance door WARNINGRisk of injury Components inside the appliance door may have sharp edges Wear protective gloves The hinges on the appliance door move when the door is opened and closed which could trap your fingers Keep your hands away from the hinges Open the appliance door fully WARNINGRisk of injury When the hinges are not secured they can snap shut with great force Make sure that the locking levers are always either fully closed or when detaching the oven door fully open Open the locking levers on the left and righthand hinges Locking levers opened The hinge is now se cured and cannot snap shut Locking levers closed The appliance door is secured and cannot be detached a The locking levers are open The hinges are now se cured and cannot snap shut Close the appliance door fully Grab hold of the appliance door with both hands on the left and right and pull it upwards and out Carefully place the appliance door on a level sur face 152 Attaching the lower appliance door WARNINGRisk of injury The hinges on the appliance door move when the door is opened and closed which could trap your fingers Keep your hands away from the hinges When the hinges are not secured they can snap shut with great force Make sure that the locking levers are always either fully closed or when detaching the oven door fully open Slide the appliance door straight onto the two hinges Slide the appliance door on as far as it will go Open the appliance door fully Close the locking levers on the left and righthand hinges a The locking levers are closed The appliance door is secured and cannot be detached Close the appliance door 153 Removing the door panes from the lower the appliance door WARNINGRisk of injury The hinges on the appliance door move when the door is opened and closed which could trap your fingers Keep your hands away from the hinges
• Page 20 - English - : en Appliance door Components inside the appliance door may have sharp edges Wear protective gloves Open the appliance door fully Open the locking levers on the left and righthand hinges a The locking levers are open The hinges are now se cured and cannot snap shut Close the appliance door fully Push on the left and righthand side of the door cover from the outside until it is released Remove the door cover Lift out the inner pane and set it down carefully on a flat surface If necessary you can remove the condensate trough for cleaning Open the appliance door Tilt the condensate trough upwards and remove it WARNINGRisk of injury Scratched glass in the appliance door may develop into a crack Do not use any harsh or abrasive cleaners or sharp metal scrapers to clean the glass on the oven door as they may scratch the surface Clean the removed door panes on both sides with glass cleaner and a soft cloth Clean the condensate trough with a cloth and hot soapy water Clean the appliance door quotSuitable cleaning agentsquot Page14 Dry the door panes and refit them quotInstalling the door panes for the lower the appli ance door quot Page20 154 Installing the door panes for the lower the appliance door WARNINGRisk of injury The hinges on the appliance door move when the door is opened and closed which could trap your fingers Keep your hands away from the hinges Components inside the appliance door may have sharp edges Wear protective gloves Open the appliance door fully Place the condensate trough vertically in the retainer and turn it downwards
• Page 21 - English - : Appliance door en Slide the inner pane into the left and righthand retainers Push the inner pane upwards until it is in the left and righthand retainers Put the door cover in position and push down on it until you hear it click into place Open the appliance door fully Close the locking levers on the left and righthand hinges a The locking levers are closed The appliance door is secured and cannot be detached Close the appliance door NoteDo not use the cooking compartment again until the door panes have been correctly fitted 155 Detaching the upper appliance door WARNINGRisk of injury The hinges on the appliance door move when the door is opened and closed which could trap your fingers Keep your hands away from the hinges Open the appliance door fully WARNINGRisk of injury When the hinges are not secured they can snap shut with great force Make sure that the locking levers are always either fully closed or when detaching the oven door fully open Open the locking levers on the left and righthand hinges Locking levers opened The hinge is now se cured and cannot snap shut Locking levers closed The appliance door is secured and cannot be detached a The locking levers are open The hinges are now se cured and cannot snap shut Close the appliance door fully Grab hold of the appliance door with both hands on the left and right and pull it upwards and out Carefully place the appliance door on a level sur face 156 Attaching the upper appliance door WARNINGRisk of injury The hinges on the appliance door move when the door is opened and closed which could trap your fingers Keep your hands away from the hinges When the hinges are not secured they can snap shut with great force Make sure that the locking levers are always either fully closed or when detaching the oven door fully open
• Page 22 - English - : en Appliance door Slide the appliance door straight onto the two hinges Slide the appliance door on as far as it will go Open the appliance door fully Close the locking levers on the left and righthand hinges a The locking levers are closed The appliance door is secured and cannot be detached Close the appliance door 157 Removing the door panes from the upper the appliance door WARNINGRisk of injury The hinges on the appliance door move when the door is opened and closed which could trap your fingers Keep your hands away from the hinges Components inside the appliance door may have sharp edges Wear protective gloves Open the appliance door fully Open the locking levers on the left and righthand hinges a The locking levers are open The hinges are now se cured and cannot snap shut Close the appliance door fully Grab hold of the appliance door with both hands on the left and right and pull it upwards and out Carefully place the appliance door on a level sur face Push on the left and righthand side of the door cover from the outside until it is released Remove the door cover Lift out the inner pane and set it down carefully on a flat surface WARNINGRisk of injury Scratched glass in the appliance door may develop into a crack Do not use any harsh or abrasive cleaners or sharp metal scrapers to clean the glass on the oven door as they may scratch the surface Clean the removed door panes on both sides with glass cleaner and a soft cloth Clean the appliance door quotSuitable cleaning agentsquot Page14 Dry the door panes and refit them quotInstalling the door panes for the upper the appli ance door quot Page23
• Page 23 - English - : Troubleshooting en 158 Installing the door panes for the upper the appliance door WARNINGRisk of injury The hinges on the appliance door move when the door is opened and closed which could trap your fingers Keep your hands away from the hinges Components inside the appliance door may have sharp edges Wear protective gloves Slide the inner pane in In doing so ensure that the inner pane is in the retainer Push the inner pane upwards until it is in the left and righthand retainers Put the door cover in position and push down on it until you hear it click into place Slide the appliance door straight onto the two hinges Slide the appliance door on as far as it will go When doing so ensure that the hinges are in serted into the correct opening Close the locking levers on the left and righthand hinges a The locking levers are closed The appliance door is secured and cannot be detached Close the appliance door NoteDo not use the cooking compartment again until the door panes have been correctly fitted 16  Troubleshooting You can rectify minor faults on your appliance yourself Read the troubleshooting information before contacting aftersales service This will avoid unnecessary costs WARNINGRisk of injury Improper repairs are dangerous Repairs to the appliance should only be carried out by trained specialist staff If the appliance is defective call Customer Service WARNINGRisk of electric shock Incorrect repairs are dangerous Repairs to the appliance should only be carried out by trained specialist staff Only use genuine spare parts when repairing the appliance If the power cord of this appliance is damaged it must be replaced by trained specialist staff
• Page 24 - English - : en Troubleshooting 161 Malfunctions Fault Cause and troubleshooting The appliance is not working The circuit breaker in the fuse box has tripped Check the circuit breaker in the fuse box There has been a power cut Check whether the lighting in your kitchen or other appliances are working The appliance does not switch off fully at the end of a cooking time At the end of a cooking time the appliance stops heating up The oven light and cooling fan do not switch off For types of heating with recirculation the fan continues to run in the back wall of the cooking compartment Turn the function selector to the off position a The appliance is switched off a The oven light and the fan in the back wall are switched off a The cooling fan switches off automatically as soon as the appliance has cooled down The time flashes in the display There has been a power cut Reset the time quotSetting the time on the clockquot Page12 The time does not ap pear in the display when the appliance is switched off The basic setting has been changed Change the basic setting for the time display quotBasic settingsquot Page13 lights up in the display and no set tings can be made on the appliance Childproof lock is activated Use the button to deactivate the childproof lock quotChildproof lockquot Page12 A message with appears in the dis play eg Electronics fault Press the button If required reset the time a If the fault was a oneoff the error message disappears If the error message appears again call the aftersales service Quote the exact error message and the E no of your appliance quotCustomer Servicequot Page25 162 Replacing the oven light bulb If the light in the cooking compartment fails change the oven light bulb NoteHeatresistant 25watt 230 V halogen bulbs are available from the aftersales service or specialist retail ers Only use these bulbs Hold the new halogen bulbs only with a clean dry towel This increases the service life of the bulb WARNINGRisk of burns The appliance and its parts that can be touched be come hot during use Caution should be exercised here in order to avoid touching heating elements Young children under 8 years of age must be kept away from the appliance WARNINGRisk of electric shock When changing the bulb the bulb socket contacts are live Before replacing the bulb ensure that the appliance is switched off in order to prevent a potential electric shock Also unplug the appliance from the mains or switch off the circuit breaker in the fuse box Requirements The appliance is disconnected from the power sup ply The cooking compartment has cooled down You have a new halogen bulb to replace the old one Place a tea towel in the cooking compartment to prevent damage Turn the glass cover anticlockwise to remove it Pull out the halogen bulb without turning it Insert the new halogen lamp and press it firmly into the socket Make sure the pins are positioned correctly Depending on the appliance model the glass cover may have a sealing ring Put the sealing ring in posi tion
• Page 25 - English - : Disposal en Screw the glass cover on Take the tea towel out of the cooking compartment Connect the appliance to the power supply 17  Disposal Find out here how to dispose of old appliances cor rectly 171 Disposing of old appliance Valuable raw materials can be reused by recycling Unplug the appliance from the mains Cut through the power cord Dispose of the appliance in an environmentally friendly manner Information about current disposal methods are available from your specialist dealer or local author ity This appliance is labelled in accord ance with European Directive 201219EU concerning used elec trical and electronic appliances waste electrical and electronic equip ment WEEE The guideline determines the frame work for the return and recycling of used appliances as applicable throughout the EU 18  Customer Service If you have any queries on use are unable to rectify faults on the appliance yourself or if your appliance needs to be repaired contact Customer Service Functionrelevant genuine spare parts according to the corresponding Ecodesign Order can be obtained from Customer Service for a period of at least 10 years from the date on which your appliance was placed on the market within the European Economic Area NoteUnder the terms of the manufacturers warranty the use of Customer Service is free of charge Detailed information on the warranty period and terms of warranty in your country is available from our after sales service your retailer or on our website If you contact Customer Service you will require the product number ENr and the production number FD of your appliance The contact details for Customer Service can be found in the enclosed Customer Service directory or on our website This product contains light sources from energy effi ciency class G 181 Product number ENr and production number FD You can find the product number ENr and the pro duction number FD on the appliances rating plate You will see the rating plate with these numbers if you open the appliance door Make a note of your appliances details and the Cus tomer Service telephone number to find them again quickly 19  How it works Here you can find the ideal settings for various types of food as well as the best accessories and cookware We have perfectly tailored these recommendations to your appliance 191 Cooking tips Observe this information when preparing food The temperature and cooking time depend on the amount of food and the recipe Settings ranges are specified for this reason Try using the lower values to start with The setting values apply to food placed in the cook ing compartment while the cooking compartment is still cold Do not slide the accessory into the cook ing compartment until it has finished preheating Remove any accessories that are not being used from the cooking compartment 192 Notes on baking When baking use the shelf positions indicated Baking on one level Height Deep baked goods or tin on wire rack 2 Flat baked goods or goods in a baking tray Baking on two levels Height Universal pan Baking tray Baking tinsdishes on the wire rack First wire rack Second wire rack Height
• Page 26 - English - : en How it works Baking on three levels Height Baking tray Universal pan Baking tray Notes When baking on several layers always use hot air Baked goods that are placed in the oven at the same time will not necessarily be ready at the same time Position baking tinsdishes either next to one an other or offset on different shelves so that they are not directly one above the other in the cooking com partment For best results we recommend using darkcol oured metal bakeware 193 Notes on roasting and grilling The setting values are based on the assumption that unstuffed chilled readytoroast poultry meat or fish is placed into a cold cooking compartment The larger the poultry meat or fish the lower the cooking temperature and the longer the cooking time Turn the poultry meat or fish after approx 12 to 23 of the time listed Add a little liquid to the poultry in the cookware Cover the bottom of the cookware with approx1 2cm of liquid When you turn poultry ensure that the breast side or skin side is underneath to begin with Cooking time calculation eg 2035 To calculate the cooking time assume 20 minutes per 500g of meat plus an extra 35minutes For 15kg the cooking time is then 95 minutes Cooking time range eg 1015 Your food will be ready within the specified range of time Roasting and grilling on the wire rack Roasting on the wire rack works particularly well for large poultry or for multiple pieces at the same time Depending on the size and type of the food to be roasted add up to 12litre water to the universal pan You can make a sauce from the juices that are caught This also means that less smoke is pro duced and the cooking compartment becomes less dirty Keep the appliance door closed when using the grill Never grill with the appliance door open Place the food to be grilled on the wire rack In ad dition slide the universal pan in at least one shelf position lower with the slanted edge facing the ap pliance door This means that any dripping fat is caught Roasting in cookware When preparing food in cookware with a lid the cook ing compartment remains cleaner Follow the manufacturers instructions for your roasting dishes Glass cookware is best Cookware without lid Use a deep roasting dish Place the cookware onto the wire rack If you do not have any suitable cookware use the universal pan Cookware with lid Place the cookware onto the wire rack Meat poultry and fish can also become crispy in a covered roasting dish Use a roasting dish with a glass lid Set a higher temperature WARNINGRisk of injury If hot glass cookware is placed on a wet or cold sur face the glass may shatter Place hot glass ovenware on a dry mat after cook ing WARNINGRisk of scalding Very hot steam may escape when the lid is opened after cooking Steam may not be visible depending on the temperature Lift the lid in such a way that the hot steam can es cape away from you Keep children away from the appliance
• Page 27 - English - : How it works en 194 Food selection Selection for the main oven Food Accessoriescookware Shelf pos ition Type of heating Temperature in Cgrill setting Cooking time in mins Victoria sponge cake 2 pcs Ø20cm cake tin 2 150170 1525 Rich fruit cake Deep 23 cm diameter tin 2 140150 180210 Fruit pie 20 cm diameter plate or pie tin 2 170190 6075 Quiche Quiche tin darkcoated 3 180200 4055 White bread Loaf tin 1 x900g or 2 x450g 2 190210 2540 Scones Baking sheet on wire rack 3 190200 1015 Biscuits Baking sheet on wire rack 3 140160 1020 Small cakes 12cup tin 3 150 2535 Pavlova Baking sheet on wire rack 3 90100 160180 Yorkshire pudding 12cup tin 3 200220 1825 Pizza homemade Baking tray 3 190210 2030 Pizza homemade thin base Round pizza tray 2 220240 1520 Victoria sponge cake 2 levels 4 pcs Ø20cm cake tin 31 150160 2030 Biscuits 2 or 3levels Baking sheet on wire rack 31 431 140160 1525 Beef top sidetop rump Cookware without lid 2 170 4030 Lamb leg on the bone Cookware without lid 2 160170 2515 Pork belly Cookware without lid 2 1 2 1 170180 2 250 1 3030 2 35 Chicken whole Wire rack 2 170180 2515 Turkey crown Wire rack 2 140150 2025 Turkey whole 48kg Wire rack 1 150160 1212 Fish braised whole 300g eg trout Cookware with lid 2 170190 2535 Diced meat beef pork lamb 500g Cookware with lid 2 140 120140 Complete meal with chicken Wire rack Wire rack Universal pan 41 180 then 200 York shire pud ding Chicken 2525 20 for York shire pud ding Bacon rashers Wire rack 3 1 side 45 2 side 34 Sausages thickness 24cm Wire rack 3 1015 Preheat the appliance Do not use the rapid heating function Preheat the appliance Preheat the appliance for five minutes Do not use the rapid heating function Preheat the appliance to 150C using HotAir Preheat the appliance for 20 minutes Do not turn the food Slide the universal pan underneath the wire rack Add the food after approx one hour Preheat the appliance for 5 minutes Preheat the appliance for three minutes Turn the food occasionally
• Page 28 - English - : en How it works Food Accessoriescookware Shelf pos ition Type of heating Temperature in Cgrill setting Cooking time in mins Pork gammon joint Cookware without lid 2 170180 2520 Chicken whole Cookware without lid 2 170180 2020 Preheat the appliance Do not use the rapid heating function Preheat the appliance Preheat the appliance for five minutes Do not use the rapid heating function Preheat the appliance to 150C using HotAir Preheat the appliance for 20 minutes Do not turn the food Slide the universal pan underneath the wire rack Add the food after approx one hour Preheat the appliance for 5 minutes Preheat the appliance for three minutes Turn the food occasionally 195 Food selection Selection for the top oven Food Accessoriescook ware Shelf pos ition Type of heating Temperature in C Cooking time in mins Scones Baking sheet 1 200210 1012 Small cakes 12cuptin 1 150160 2535 Lamb chops height 23cm Wire rack 3 Grill 1 side 79 2 side 58 Pork sausages thickness 24cm Wire rack 3 Grill 1418 Preheat the appliance 196 Yoghurt You can use your appliance to make your own yoghurt Preparing yoghurt Remove the accessories and shelf supports from the cooking compartment Pour the previously prepared yoghurt mixture into small containers eg into cups or small jars Cover the containers with foil e g with cling film Place the containers on the cooking compartment floor Set the appliance according to the recommended setting After making the yoghurt leave it to cool in the refri gerator Recommended settings for yoghurt Selection for the main oven Food Accessoriescookware Shelf position Type of heating Temperature in C Cooking time in mins Yoghurt Individual moulds Cooking compartment floor 1 2 1 100 2 1 2 89 hrs Preheat the appliance 197 Test dishes These overviews have been produced for test institutes to facilitate appliance testing in accordance with EN 603501 Baking Observe this information when baking test dishes General information The settings apply to food that is placed into a cold cooking compartment Observe the notes about preheating in the tables These setting values apply without rapid heating When baking use the lower of the listed temperat ures to begin with Shelf positions Shelf positions for baking on two levels
• Page 29 - English - : How it works en NoteItems that are placed in the oven on baking trays or in baking tinsdishes at the same time will not ne cessarily be ready at the same time Universal pan Level 3 Baking tray Level 1 Baking tinsdishes on the wire rack First wire rack Level 3 Second wire rack Level 1 Shelf positions for baking on three levels Baking tray Level 4 Universal pan Level 3 Baking tray Level 1 Baking with two springform cake tins Position baking tinsdishes either next to one another or offset on different shelves so that they are not dir ectly one above the other in the cooking compartment Recommended settings for baking Selection for the main oven Food Accessoriescookware Shelf pos ition Type of heating Temperature in C Cook ing time in mins Viennese whirls Baking tray 3 140150 2535 Viennese whirls Baking tray 3 140150 2030 Viennese whirls 2levels Universal pan Baking tray 3 1 140150 2535 Viennese whirls 3levels Universal pan Baking tray 4 3 1 130140 3555 Small cakes Baking tray 3 150160 2030 Small cakes Baking tray 3 140150 2535 Small cakes 2levels Universal pan Baking tray 3 1 140150 2540 Small cakes 3levels Universal pan Baking tray 4 3 1 140 3040 Hot water sponge cake Springform cake tin diameter 26 cm 2 160170 2535 Hot water sponge cake Springform cake tin diameter 26 cm 2 160170 3035 Hot water sponge cake 2levels Springform cake tin diameter 26 cm 3 1 150160 3550 Preheat the appliance for five minutes Do not use the rapid heating function Preheat the appliance Do not use the rapid heating function Recommended settings for grilling Selection for the main oven Food Accessoriescookware Shelf pos ition Type of heating Temperature in Cgrill setting Cook ing time in mins Toasting bread Wire rack 4 0515 Preheat the appliance for five minutes Do not use the rapid heating function
• Page 30 - English - : en Installation instructions Recommended settings for grilling Selection for the top oven Food Accessoriescookware Shelf pos ition Type of heating Temperature in C Cook ing time in mins Browning toast Wire rack 3 Grill 46 20  Installation instructions Observe this information when installing the appliance  201 General installation instructions Follow these instructions before you start with the installation of the appliance The safe operation of this appliance can only be guaranteed if it has been installed to a professional standard in accordance with these installation instructions The in staller shall be liable for damages incurred as a result of incorrect installation Do not use the door handle for the trans port or installation The appliance must be transported by two people using the carry handles on the right and left Check the appliance for damage after un packing it Do not connect the appliance if it has been damaged in transit Before starting up the appliance remove any packaging material and adhesive film from the cooking compartment and the door Proceed in accordance with the installation sheets for installing accessories Fitted units must be heatresistant up to 95C and adjacent unit fronts up to 70C Do not install the appliance behind a decor ative door or the door of a kitchen unit There is a risk of overheating Cutout work on the units should be carried out before installing the appliance Remove any shavings Otherwise the correct opera tion of electrical components may be ad versely affected The mains socket for the appliance must either be located in the hatched area or outside of the area where the appliance is installed Any unsecured units must be secured to the wall using a standard bracket Wear protective gloves so that you do not cut yourself Parts that are accessible dur ing installation may have sharp edges Dimensions of the figures in mm WARNINGRisk of fire It is dangerous to use an extended power cord and nonapproved adapters Do not use multiple socket strips Only use extension cables that are certified have a minimum cross section of 15mm² and comply with the applicable national safety requirements If the power cord is too short contact cus tomer service Only use adapters approved by the manu facturer ATTENTION Carrying the appliance by the door handle could break it The door handle cannot sup port the weight of the appliance Do not carry or hold the appliance by the door handle
• Page 31 - English - : Installation instructions en 202 Appliance dimensions You will find the dimensions of the appliance here 203 Installation in a tall unit Observe the installation dimensions and the installation instructions when installing in a tall unit To ventilate the appliance there must be a gap of 20mm between all intermediate floors and the wall If the tall unit has another back panel in addition to the element back panels this must be removed Only fit the appliance up to a height which allows accessories to be easily removed 204 Corner installation Observe the installation dimensions and the installation instructions when installing in a corner To ensure that the appliance door can be opened you must take the minimum dimensions into consid eration when installing in a corner The dimension is dependent on the thickness of the unit front and the handle 205 Electrical connection In order to safely connect the appliance to the elec trical system follow these instructions The appliance corresponds to protection class I and must only be operated with a protective earth con nection The fuse protection must correspond to the power rating specified on the appliances rating plate and to local regulations The appliance must be disconnected from the power supply whenever installation work is being carried out Contact protection must be guaranteed by the in stallation Electrically connecting an appliance without a protective contact plug NoteOnly a licensed professional may connect the ap pliance Damage caused by incorrect connection is not covered under the warranty An allpole isolating switch must be integrated into the permanent electrical installation according to the install ation regulations Identify the phase and neutral conductors in the socket The appliance may be damaged if it is not connec ted correctly Connect the hob in accordance with the connection diagram The yellowgreen wire for the safety earth terminal must be 10mm longer on the appliance side than the other wires See the rating plate for the voltage Connection 3N 2N 1N Use a H05VVF mains power cable or one with a higher rating
• Page 32 - English - : en Installation instructions 206 Installing the appliance Remove the transport locks on the right and left and then dispose of them The appliance must be transported by two people using the carry handles on the right and left while securing the front of the appliance with one hand Place the appliance in the unit and fold the carry handles down Push the appliance in fully Do not kink or trap the connection cable or route it over sharp edges Centre the appliance There must be an air gap of at least 5mm between the appliance and adjacent unit fronts Use a spirit level to adjust the appliance so that it is perfectly level Screw the appliance into place For handleless kitchens with vertical bar handle strips Attach a suitable filling piece in order to cover any sharp edges and to guarantee a safe install ation Predrill aluminium profiles to establish a screw connection Secure the appliance using a suitable screw 207 Removing the appliance Disconnect the appliance from the power supply Undo the fastening screws Lift the appliance slightly and pull it out completely
• Page 36 - English - : BSH Hausgeräte GmbH CarlWeryStraße 34 81739 München GERMANY 9001580275 en Valid within Great Britain Imported to Great Britain by BSH Home Appliances Ltd Grand Union House Old Wolverton Road Wolverton Milton Keynes MK12 5PT United Kingdom
