Semi Flushmount
ITEM #3519194
MODEL #70822 ROB
Mounting Unit
x 1
B
Cap Nut
x 2
EE
Socket Ring (preassembled with fixture)
x 1
FF
E26 Vintage Bulb
x 1
AA
BB
CC
3
2
3. Connect the black to black (power), the
white to white (neutral) and copper wire to
ground wire with the wire nuts (CC) and
secure with electrical tape (not included).
Helpful Hint: If wires out of fixture are the
same color, attach the side with markings
or letters to black (positive) and the other
to white (neutral).
2. Connect the ground wire to the
mounting unit (AA) by securing it with the
ground screw.
1
1. Attach the mounting unit (AA) to the
junction box (not included) with mounting
screws (BB).
AA
4
4. Remove the preinstalled socket ring (EE)
from fixture (A), add the glass shade (B) and
re-secure the socket ring (EE).
6
6. Secure the light fixture (A) to the junction
box by placing the mounting bracket over the
preinstalled support screws on the mounting
unit (AA). Secure with the cap nuts (DD).
5
5. Make sure the screw nuts are fully
inserted into the groove of the glass
shade (B) and is fixed well.
EE
A
DD
B
B
A
7
7. Install 1 x 60 Watt max. vintage bulb (FF),
included.
(continued)
