Owner™s Manual for Honda 2023 GROM

Table of Contents

  • Vehicle Safety
  • Operation Guide
  • Maintenance
  • Troubleshooting
  • Information
  • Specifications

Operation Guide

Setting Mode A

If the button is not pressed for about 30 seconds, the control is automatically switched from the setting mode to the ordinary display.

If the button is not pressed for about 30 seconds, items in the process of being set will be discarded and only items where settings have been finalized will be applied. Only if the ignition switch is turned to the OFF position will items in the process of being set and those that are finalized be applied.

1 Clock setting:

aTurn the ignition switch to the ON position.

bPress and hold the SEL and the SET buttons until the hour digits start flashing.

cPress the SEL button until the desired hour is displayed.

  • Press and hold the SEL button to advance the hour fast.

dPress the SET button. The minute digits start flashing.

ePress the SEL button until the desired minute is displayed.

  • Press and hold the SEL button to advance the minute fast.

fPress the SET button. The clock is set, and then the display moves to the backlight brightness adjustment.

2 Backlight brightness adjustment:

You can adjust the brightness to one of five levels.

aPress the SEL button. The brightness is switched.

bPress the SET button. The backlight is set, and then the display moves to the changing the speed and mileage unit.

3 Changing the speed and mileage unit:

aPress the SEL button to select either “mph” and “mile” or “km/h” and “km”.

bPress the SET button. speed and mileage unit is set, and then the display moves to the unit setting.

4 Unit setting:

You can change the fuel mileage units.

  • aSelect the “km/L” or “L/100km” using the SEL button.

GROM ABS type for Canada When selecting the “mph” and “mile” for speed and mileage unit, the fuel mileage shown by “mile/gal” or “mile/L”.

  • bPress the SET button. The fuel mileage unit setting is set, and then the display returns to the ordinary display

Setting Mode B

If the button is not pressed for about 30 seconds, the control is automatically switched from the setting mode to the ordinary display. If the button is not pressed for about 30 seconds, items in the process of being set will be discarded and only items where settings have been finalized will be applied. Only if the ignition switch is turned to the OFF position will items in the process of being set and those that are finalized be applied.

Starting the Engine

Start your engine using the following procedure, regardless of whether the engine is cold or warm.

NOTICE

• If the engine does not start within 5 seconds, turn the ignition switch to the OFF position and wait 10 seconds before trying to start the engine again to recover battery voltage.

• Extended fast idling and revving the engine can damage the engine and the exhaust system.

Consult your dealer for advice if you plan to ride your vehicle at an altitude above 8,000 feet (2,500 m).

NOTICE If the vehicle is transported to a place 6,500 feet (2,000 m) higher or lower than the start point, you may not be able to achieve sufficient engine performance at the new altitude. Consult your dealer before transporting your vehicle.

aMake sure the engine stop switch is in the (Run) position.

bTurn the ignition switch to the ON position.

cShift the transmission to Neutral ( N indicator comes on). Alternatively, pull in the clutch lever to start your motorcycle while the transmission is in gear as long as the side stand is raised.

dPress the start button with the throttle completely closed.

  • If you cannot start the engine, open the throttle slightly (about 0.1 in [3 mm], without freeplay) and press the start button

If the engine does not start:

  • aOpen the throttle fully and press the start button for 5 seconds.
  • bRepeat the normal starting procedure.
  • cIf the engine starts, open the throttle slightly if idling is unstable.
  • dIf the engine does not start, wait 10 seconds before trying step a & b again
