SLR Digital Camera
Operating Manual
This Operating Manual provides information on how to use the
shooting and playback functions of this camera and related
precautions.
Thoroughly read this Operating Manual to make the best use of
the functions available with this camera. Be sure to keep this
Operating Manual for future reference.
It is recommended to update the camera firmware to the latest
version before using the camera.
For details on the latest firmware version, refer to the firmware
download site.
http://www.ricoh-imaging.com/
RICOH IMAGING COMPANY, LTD.
Introduction
1
2
Getting Started
3
Shooting
4
Playback
5
Sharing
6
Settings
7
Appendix
Model No. R03010
• Specifications and external dimensions are subject to
change without notice.
51553 Copyright © RICOH IMAGING COMPANY, LTD. 2020
R01DTL20 Printed in Philippines
e_kb582_cover_6mm.fm Page 1 Thursday, December 10, 2020 1:19 PM
We have paid close attention to the safety of this camera. When using this
camera, we request your special attention regarding items marked with the
following symbols.
Warning
• Do not disassemble or modify the camera. High voltage areas are
present inside the camera, with the risk of electric shock.
• If the camera interior is exposed due to dropping or otherwise damaging
the camera, never touch the exposed portion. There is a risk of electric
shock.
• Do not aim the camera at the sun or other strong light sources when
taking images or leave the camera sitting in direct sunlight with a lens
cap off. Doing so may cause the camera to malfunction or cause a fire.
• Do not look at the sun or other strong light sources through a lens. Doing
so may lead to a loss of eyesight or cause vision to be impaired.
• If any irregularities occur during use, such as smoke or a strange odor,
stop use immediately, remove the battery or the AC adapter, and contact
your nearest service center. Continued use can cause a fire or electric
shock.
Caution
• Some portions of the camera heat up during use. There is a risk of low
temperature burns when holding such portions for long periods.
• Should the monitor be damaged, be careful of glass fragments. Also, be
careful not to allow the liquid crystal to get on your skin or in your eyes
or mouth.
• Depending on your individual factors or physical condition, the use of the
camera may cause itching, rashes or blisters. In case of any
abnormality, stop using the camera and get medical attention
immediately.
Warning
• Wipe off the power plug if it should become covered with dust.
Accumulated dust may cause a fire.
• Do not handle the power plug with wet hands. This can cause an electric
shock.
• Always grip the plug section when disconnecting the power plug. Do not
pull the power cord. This can damage the power cord and result in a fire
or electric shock.
• If the generation of smoke or strange odor from the adapter or other
abnormality occurs, immediately remove the power plug from the outlet
and contact your nearest dealer or service center for repair. Do not use
the adapter until it is repaired.
• If you see a lightning flash or hear thunder during use of the adapter, do
not touch the power plug. This can cause an electric shock.
Caution
• Securely insert the power plug into the outlet. Failure to observe this
precaution may cause a fire.
For Using Your Camera Safely
Warning
This symbol indicates that ignoring this item
could cause serious personal injuries.
Caution
This symbol indicates that ignoring this item
could cause minor or medium personal injuries,
or loss of property.
About the Camera
About the USB Power Adapter
e_kb582_cover_6mm.fm Page 2 Thursday, December 10, 2020 1:19 PM
1
Warning
• Always use the optional battery charger and AC adapter exclusively
developed for this camera, with the specified power and voltage. Using
a battery charger or AC adapter not exclusive to this camera, or using
the exclusive battery charger or AC adapter with an unspecified power
or voltage can cause a fire, electric shock, or camera breakdown. The
specified voltage is 100 to 240 VAC.
• Do not disassemble or modify the product. This can cause a fire or
electric shock.
• If the generation of smoke or strange odor from the product or other
abnormality occurs, immediately discontinue using and consult your
nearest service center. Continued use can cause a fire or electric shock.
• If water should happen to get inside the product, consult your nearest
service center. Continued use can cause a fire or electric shock.
• If you see a lightning flash or hear thunder during use of the battery
charger or AC adapter, unplug the power plug and discontinue using.
Continued use can cause damage to the product, fire, or electric shock.
• Wipe off the power plug if it should become covered with dust.
Accumulated dust may cause a fire.
Caution
• Do not place or drop heavy objects on or forcefully bend the AC plug
cord. Doing so may damage the cord. Should the AC plug cord be
damaged, consult your nearest service center.
• Do not touch or short-circuit the terminal area of the AC plug cord while
the cord is plugged in.
• Do not handle the power plug with wet hands. This can cause an electric
shock.
• Do not drop the product, or subject it to violent impact. This can cause
the product to breakdown.
Warning
• If any leakage from the battery should come in contact with your eyes,
do not rub them. Flush your eyes with clean water and get medical
attention immediately.
Caution
• Only use the specified battery with this camera. Use of other batteries
may cause an explosion or fire.
• Do not disassemble the battery. Disassembling the battery may cause
an explosion or leakage.
• Remove the battery from the camera immediately if it becomes hot or
begins to smoke. Be careful not to burn yourself during removal.
• Keep wires, hairpins, and other metal objects away from the + and -
contacts of the battery.
• Do not short the battery or dispose of the battery in fire. This can cause
an explosion or fire.
• If any leakage from the battery should come in contact with skin or
clothing, it may cause irritation to the skin. Wash the affected areas
thoroughly with water.
• Precautions for D-LI90 Battery Usage:
- USE ONLY THE CAMERA OR SPECIFIED CHARGER TO CHARGE
THE BATTERY. RISK OF FIRE AND BURNS.
- DO NOT INCINERATE.
- DO NOT DISASSEMBLE.
- DO NOT SHORT CIRCUIT.
- DO NOT EXPOSE TO HIGH TEMP. (140°F / 60°C)
- SEE MANUAL.
• Lithium-Ion batteries are recyclable.
You can help preserve our environment by returning your used
rechargeable batteries to the collection and recycling location nearest
you.
For more information regarding recycling of rechargeable batteries, call
toll free 1-800-822-8837, or visit http://www.call2recycle.org/.
Warning
• Do not place the camera and its accessories within the reach of small
children.
1. If the product falls or is operated accidentally, it may cause serious
personal injuries.
2. Wrapping the strap around a neck may cause suffocation.
3. To avoid the risk of a small accessory such as the battery or memory
cards from being swallowed by mistake, keep them out of the reach
of small children. Seek medical attention immediately if an accessory
is accidentally swallowed.
About the Optional Battery Charger and AC
Adapter
About the Rechargeable Lithium-ion Battery
Keep the Camera and its Accessories out of the
Reach of Small Children
How to Use This Manual
2
Checking the Contents of the Package ..... p.8
Names and Functions of the Working
Parts .............................................................p.9
Display Indicators .......................................p.12
How to Change Function Settings ............. p.18
Menu List ......................................................p.22
Attaching the Strap .....................................p.37
Attaching a Lens .........................................p.37
Using the Battery and Charger ..................p.38
Inserting a Memory Card ............................p.41
Initial Settings ..............................................p.42
Basic Shooting Operation ..........................p.44
Reviewing Images .......................................p.47
Configuring the Capture Settings ..............p.48
Taking Still Images ......................................p.49
Recording Movies .......................................p.54
Setting the Exposure ..................................p.57
Setting the Focus Method ..........................p.59
Selecting the Drive Mode ............................p.66
Setting the White Balance ..........................p.74
Using a Flash ...............................................p.77
Controlling the Image Finishing Tone .......p.78
Correcting Images .......................................p.80
How to Use This Manual
1
Introducing the K-3 Mark III..............p.8
Gives you an overview of the K-3 Mark III.
Read this and get to know your K-3 Mark III!
2
Getting Started........................................p.37
Explains how to get your K-3 Mark III ready for
shooting as well as basic operations.
3
Taking Images.........................................p.48
Once you’ve confirmed that the camera works
properly, try out the camera and take lots of images!
How to Use This Manual
3
Using the Playback Functions ...................p.85
Changing the Playback Method .................p.85
Organizing Files ..........................................p.88
Editing and Processing Images .................p.91
Using the Camera with a Computer ...........p.97
Using the Camera with a Communication
Device ........................................................... p.99
Camera Settings ..........................................p.100
File Management Settings ..........................p.111
Restrictions on the Combinations of Special
Functions .....................................................p.115
Functions Available with Various
Lenses ..........................................................p.116
Functions when Using an External
Flash .............................................................p.119
Using the GPS Unit .....................................p.121
Troubleshooting ..........................................p.123
Main Specifications .....................................p.126
Index .............................................................p.131
Care to be Taken During Handling ............p.135
WARRANTY POLICY ...................................p.138
There is a possibility that the illustrations and the display screen
of the monitor in this manual are different from the actual ones.
4
Playback Functions..............................p.85
Explains various operations for playing back and
editing images.
5
Sharing Images.......................................p.97
Explains how to connect your K-3 Mark III to a
computer or communication device to operate the
camera and use images in the camera.
6
Changing the Settings ........................p.100
Explains how to change other settings.
7
Appendix....................................................p.115
Provides other resources to get the most from your
K-3 Mark III.
Contents
4
How to Use This Manual .........................2
Introducing the K-3 Mark III .....................8
Checking the Contents of the Package ..............8
Names and Functions of the Working Parts ......9
Operating Controls ....................................................... 10
Display Indicators ...............................................12
Monitor ......................................................................... 12
LCD Panel and Viewfinder ........................................... 16
Electronic Level ........................................................... 18
How to Change Function Settings .................... 18
Using the Direct Keys .................................................. 18
Using the Smart Function ............................................ 19
Using the Control Panel ............................................... 20
Using the Menus .......................................................... 20
Menu List .............................................................22
A Still Image Setting Menus ...................................... 22
B Movie Setting Menus ............................................. 25
C Playback Setting Menus ........................................27
E Customization Menus ............................................. 28
D Setup Menus .......................................................... 34
Getting Started .......................................37
Attaching the Strap ............................................37
Attaching a Lens .................................................37
Using the Battery and Charger ..........................38
Inserting/Removing the Battery ................................... 38
Charging the Battery .................................................... 39
Using the AC Adapter .................................................. 41
Inserting a Memory Card ...................................41
Initial Settings ..................................................... 42
Turning the Camera On ............................................... 42
Setting the Display Language, Date and Time, and
Color ............................................................................ 43
Formatting a Memory Card .......................................... 43
Basic Shooting Operation .................................44
Shooting with the Viewfinder ........................................ 44
Shooting while Viewing the Live View Image ............... 46
Reviewing Images ..............................................47
Taking Images ........................................48
Configuring the Capture Settings ..................... 48
Memory Card Recording Settings ................................ 48
Still Image Capture Settings ........................................ 48
Movie Capture Settings ................................................ 49
Taking Still Images .............................................49
Exposure Modes .......................................................... 50
EV Compensation ........................................................ 54
Recording Movies ...............................................54
Playing Back Movies .................................................... 56
Setting the Exposure ..........................................57
ISO Sensitivity .............................................................. 57
AE Metering ................................................................. 59
Setting the Focus Method .................................. 59
Setting the Autofocus when Shooting with the
Viewfinder .................................................................... 60
Setting the Autofocus when Shooting with
Live View ...................................................................... 62
Fine-tuning the Autofocus ............................................ 64
Checking the Depth of Field (Preview) ........................ 65
Selecting the Drive Mode ................................... 66
Continuous Shooting .................................................... 67
Bracketing .................................................................... 67
Depth of Field Bracketing ............................................. 68
Motion Bracketing ........................................................ 69
Mirror Lock-up Shooting ............................................... 69
Multi-exposure ............................................................. 70
Interval Shooting .......................................................... 71
Interval Composite ....................................................... 72
Contents
Contents
5
Self-timer ..................................................................... 73
Remote Control ............................................................ 73
Setting the White Balance ................................. 74
Adjusting the White Balance Manually ........................ 76
Adjusting the White Balance with Color
Temperature ................................................................ 76
Using a Flash ......................................................77
Connecting a Flash ...................................................... 77
Setting the Flash Mode ................................................ 77
Controlling the Image Finishing Tone ..............78
Custom Image ............................................................. 78
Digital Filter .................................................................. 79
Correcting Images ..............................................80
Adjusting the Brightness .............................................. 80
Adjusting the Lens Properties ...................................... 81
Adjusting the Image Quality Level and Texture ........... 82
Reducing Blurring of Images ....................................... 83
Correcting the Skew of Images .................................... 84
Fine-tuning the Composition ........................................ 84
Playback Functions ...............................85
Using the Playback Functions ..........................85
Setting the Operation in the Playback Mode ............... 85
Changing the Playback Method ........................ 85
Displaying Multiple Images .......................................... 85
Displaying Images by Folder or Shooting Date ........... 87
Connecting the Camera to an AV Device .................... 87
Organizing Files .................................................. 88
Deleting Images ........................................................... 88
Protecting Images ........................................................ 89
Rotating Images ........................................................... 89
Copying Images ........................................................... 90
Transferring Images ..................................................... 90
Saving the RAW Data .................................................. 91
Editing and Processing Images ........................91
Processing Images with Digital Filters .........................91
Developing RAW Images ............................................. 92
Changing the Image Size ............................................ 93
Correcting JPEG Images ............................................. 94
Editing Movies .............................................................. 96
Sharing Images ......................................97
Using the Camera with a Computer ..................97
Setting the Connection Mode ....................................... 97
Copying an Image on the Memory Card ...................... 97
Installing the Provided Software .................................. 98
Operating the Camera with a Computer ...................... 98
Using the Camera with a Communication
Device ..................................................................99
Changing the Settings .........................100
Camera Settings ...............................................100
Saving Frequently Used Settings ............................... 100
Customizing the Operating Controls .......................... 102
Setting the Monitor Display, Indicator Lamp
Illumination, and Sound Effects ................................. 107
Selecting Settings to Save in the Camera ................. 111
File Management Settings ...............................111
Specifying the Folder/File Settings ............................ 111
Setting the Copyright Information .............................. 114
Appendix...............................................115
Restrictions on the Combinations of Special
Functions .......................................................... 115
Functions Available with Various Lenses ......116
Using the Aperture Ring ............................................. 118
Setting the Focal Length ............................................ 119
Functions when Using an External Flash ......119
Using the GPS Unit ...........................................121
Shooting Celestial Bodies (ASTROTRACER) ........... 121
Troubleshooting ...............................................123
Sensor Cleaning ........................................................ 124
Error Messages .......................................................... 125
Main Specifications .......................................... 126
Camera ...................................................................... 126
USB Power Adapter AC-U1/AC-U2 ........................... 129
Contents
6
Operating Environment for USB Connection and
Provided Software ..................................................... 130
Index .................................................................. 131
Care to be Taken During Handling ..................135
WARRANTY POLICY ........................................138
Regarding copyrights
Images taken with this camera that are for anything other
than personal enjoyment cannot be used without permission
according to the rights as specified in the Copyright Act.
Please take care, as there are cases where limitations are
placed on taking images even for personal enjoyment during
demonstrations, performances or of items on display.
Images taken with the purpose of obtaining copyrights also
cannot be used outside the scope of use of the copyright as
laid out in the Copyright Act, and care should be taken here
also.
To users of this camera
• Do not use or store this camera in the vicinity of equipment
that generates strong electromagnetic radiation or
magnetic fields. Strong static charges or the magnetic
fields produced by equipment such as radio transmitters
could interfere with the monitor, damage the stored data,
or affect the camera’s internal circuitry and cause camera
misoperation.
• The liquid crystal panel used for the monitor is
manufactured using extremely high precision technology.
Although the level of functioning pixels is 99.99% or better,
you should be aware that 0.01% or fewer of the pixels may
not light up or may light up when they should not.
However, this has no effect on the recorded image.
• The Shake Reduction (SR) mechanism of this camera
uses the PENTAX original technology and moves the
image sensor to an appropriate position at high speed with
a magnetic force, which reduces image blurring caused by
camera motion. A rattling sound is made when the camera
is shaken, for example, by changing its orientation, but this
is not a malfunction.
• In this manual, the generic term “computer(s)” refers to
either a Windows
®
PC or a Mac.
• In this manual, the term “battery(ies)” refers to any type of
batteries used for this camera and its accessories.
Regarding User Registration
In order to better serve you, we request that you complete
the user registration which can be found on our website.
Thank you for your cooperation.
http://www.ricoh-imaging.com/registration/
1
Introduction
8
Checking the Contents of the Package
Hot shoe cover FK
(Installed on the camera)
Eyecup FU
(Installed on the camera)
ME viewfinder cap Sync socket 2P cap
(Installed on the camera)
Body mount cap K II
(Installed on the camera)
Triangular ring and protective cover
(Installed on the camera)
Battery grip terminal cover
(Installed on the camera)
Rechargeable lithium-ion
battery D-LI90
USB power adapter
AC-U1 or AC-U2*
*
Differs depending on the region.
Power plug USB cable
I-USB166
Strap
O-ST162
Operating Manual (this manual) Wireless Communication Guide
Lenses You Can Use
Lenses that can be used with this camera are D FA, DA, DA L, FA, and FA J lenses and lenses that have an 9 (Auto) position
on the aperture ring. To use any other lens or accessory, see p.116.
1
Introduction
9
Names and Functions of the Working Parts
Card access lamp
LCD panel
Terminal cover
Cable switch terminal
Self-timer lamp/Remote control receiver
Diopter adjustment dial
Microphone terminal
Image plane indicator
Viewfinder
Monitor
Dual card slot for SD Memory Cards
Dial indicator
Eye sensor
Self-timer lamp/Remote control receiver
AF coupler
Mirror
Lens unlock button
Lens information contacts
Strap lug
Hot shoe
Lens mount index
Microphone
X-sync socket
AF assist light
Speaker
Headphone terminal
Tripod socket
Battery cover
Battery cover unlock knob
Battery grip contacts
USB terminal (USB Type-C)
HDMI
®
terminal (Type D)
Microphone
1
Introduction
10
1
Still image/Live View/Movie selector dial (
A
/
K
/
B
dial)
Switches between shooting with the viewfinder in the A
(still image) mode, shooting with Live View in the A mode,
and shooting in the B (movie) mode. (p.44)
2 Smart Function button (U)
Press to select the function set with the Smart Function and
change settings for the selected function. (p.19)
3 ISO button (N)
Press to change the ISO sensitivity. (p.57)
4 Shutter release button (0)
Press to capture images. (p.45)
In the playback mode, press halfway to switch to the capture
mode.
5 Main switch
Turns the power on or off, or activates the preview function.
(p.42, p.65)
6 Front e-dial (Q)
Changes the values for camera settings such as exposure.
(p.51)
You can change the menu type when a menu screen is
displayed. (p.20)
In the playback mode, use this dial to select a different
image.
7 EV Compensation button (J)
Press to change the exposure compensation value. (p.54)
8 Mode dial lock button
Press to allow the mode dial to be turned. (p.44)
9 Mode dial
Changes the capture mode. (p.49)
0 Mode dial lock release lever
Use this lever to release the mode dial lock to operate the
mode dial without pressing the mode dial lock button. (p.45)
a Shake Reduction button (5)
Changes the Shake Reduction function. (p.83)
b RAW button (O)
Temporarily changes the file format. (p.103)
c AF Mode button (b)
Press to change the AF mode or the AF active area. (p.60)
d Focus method switch
Changes the focus method. (p.59)
e AE Metering/Delete button (2/L)
Press to change the metering mode. (p.59)
In the playback mode, press to delete images. (p.47)
Operating Controls
2
g
d
i
j
m
o
0
9
h
n
8
4
3
b
a
5
1
f
e
k
c
l
6
p
q
7
1
Introduction
11
f Operation lock button (7)
Temporarily disables button operations to prevent
misoperation. (p.46)
g Green button (M)
Resets the value being adjusted.
Switches to ISO Auto when adjusting the ISO sensitivity.
In the playback mode, press this button to switch between
the memory cards inserted in the two slots, SD1 and SD2.
(p.47)
h Playback button (3)
Switches to the playback mode. (p.47) Press the button
again to switch to the capture mode.
i Smart Function dial (V)
Change settings for the function selected with the Smart
Function. (p.19)
j AE Lock button (H)
Locks the exposure value before shooting.
In the playback mode, press this button to display the
playback function selection screen. (p.85)
k AF button (I)
Available for adjusting focus, instead of pressing 0
halfway. (p.59)
l Rear e-dial (R)
Changes the values for camera settings such as exposure.
(p.51)
Changes the menu items when a menu screen is displayed.
(p.20)
You can change camera settings when the control panel is
displayed. (p.20)
In the playback mode, use this dial to magnify the image or
display multiple images at the same time. (p.47, p.85)
m AF point selector lever (6)
Changes the AF point. (p.60) The AF point can be moved
up, down, left, right, and diagonally.
When an image is magnified during shooting with Live View
or in the playback mode, use this lever to move the display
area. Push the lever in to return the display area to the
center of the image. (p.46, p.47)
n Four-way controller (ABCD)
Displays the setting screen for [Drive Mode], [Outdoor View
Setting], [White Balance], or [Custom Image]. (p.18)
When a menu or the control panel is displayed, use this
controller to move the cursor or change the item to set.
o OK button (E)
When a menu or the control panel is displayed, press this
button to confirm the selected item.
p MENU button (F)
Displays a menu. Press this button while the menu is
displayed to return to the previous screen. (p.20)
q INFO button (G)
Changes the style of the display on the monitor. (p.13, p.14)
About the Four-way Controller
In this manual, each button of the four-
way controller is indicated as shown in
the illustration on the right.
Customization of Operating Controls
For some buttons, you can change the button function to
another one. (p.102)
This manual describes the camera operation based on the
default function assignment.
1
Introduction
12
With this camera, you can take images while looking through
the viewfinder or while viewing the image on the monitor.
When using the viewfinder, you can take images while checking
the status screen displayed on the monitor and looking through
the viewfinder. (p.44) When not using the viewfinder, you can
take images while viewing the Live View image displayed on the
monitor. (p.46)
The camera is in the “standby mode” when it is ready to shoot,
such as when the status screen or Live View image is displayed.
The settings for shooting are displayed.
Status Screen
Live View
t Memo
•
In [Monitor Display] of the
E
4 menu, you can change the
display settings of the status screen and Live View. (p.108)
• You can change the display color set in “Initial Settings” (p.42)
in [Color Settings] of [Monitor Display] in the E4 menu.
(p.108)
Display Indicators
Monitor
Capture Mode
Standby Mode
1 0 : 1 010:10
1 /1/
250250
16001600
FF
5.65.6
SR
35
111054321
12 13
1512
12 17
26
29
2827
22
25
2120
23
31
32 33
30
1612
1412
18 19
34
24
9876
0 1 / 0 1 / 2 0 2 101/01/2021
9 9 9 99999
9 9 9 99999
1/ 4001/400 F 5 . 6F5.6 1600
35
11105
32
427 28 3261
2
21
36
3940
37
38
13
16
14 15
17
33
32
34
9876
9 9 9 99999
9 9 9 99999
1 Capture mode (p.49) 17 EV bar scale
2 AE Lock 18 Focus method (p.59)
3 Clarity (p.83)/Skin Tone
(p.83)/Digital Filter
(p.79)/HDR Capture
(p.81)/Pixel Shift
Resolution (p.82)
19 Hold AF Status (p.61)
20 Operation guide for 5
21 Operation guide for 7
22 Operation guide for 3
23 Operation guide for O
4 GPS positioning status
(p.121)
24 Operation guide for 2
25 Operation guide for H
5 Bluetooth
®
communication
26 Drive Mode (p.66)
27 White Balance (p.74)
6 Wireless LAN
communication
28 Custom Image (p.78)
29 Outdoor View Setting
7 Flash Mode (p.77) 30 Focusing area (AF point)
(p.60)
8 Anti-Aliasing Filter
Simulator (p.82) 31 Date and time/Operation
guide
9 AE Metering (p.59)
10 Shake Reduction (p.83)/
Auto Horizon Correction
(p.84)
32 Electronic level (p.18)
33 File Format (p.48)
34 Image storage capacity
11 Battery level 35 Card slot number
12 E-dial guide 36 Warning Display (p.110)
13 Shutter speed 37 Temperature warning
14 Aperture value 38 Histogram
15 ISO Sensitivity (p.57) 39 JPEG Recorded Pixels
(p.48)
16 Operation guide for
Smart Function (p.19) 40 Crop (p.48)
1
Introduction
13
Press G in the standby mode to display the “control panel”
and change settings.
The following functions are displayed with the default setting.
Adjusting the Monitor Brightness
If the monitor display is difficult to
see when you take images
outdoors or in other situations,
adjust the brightness of the
monitor in [Outdoor View Setting]
of the D2 menu. By default,
[Outdoor View Setting] is
assigned to B. (p.102)
Also, when shooing in a dark place for a long period of time,
you can prevent eyes dazzling in dark places by using [Night
Vision Display] of the D2 menu.
In addition, you can set [Brightness], [Saturation], [Adjust:
Blue-Amber], and [Adjust: Green-Magenta] in [Monitor
Adjustment] of the D2 menu. [Brightness] can also be
adjusted automatically. (By default, [Brightness] is adjusted
automatically.) (p.109)
When the Camera is Held Vertically
When the camera is rotated to the vertical
position, the status screen is displayed
vertically.
To not display the status screen vertically,
change the display rotation setting in
[Status Screen] of [Monitor Display] in the
E4 menu. (p.108)
Outdoor View Setting
Outdoor View Setting
Cancel
Cancel
OK
OK
1 0 : 1 0
10:10
1 /
1/
250
250
F
F
5.6
5.6
1600
SR
0 1 / 0 1 / 2 0 2 1
01/01/2021
9 9 9 9
9999
9 9 9 9
9999
Control Panel
1 Function name 14 HDR Capture (p.81)
2 Setting 15 Pixel Shift Resolution
(p.82)
3 File Format (p.48)
4 Number of recordable
still images/Movie
recordable time
16 Distortion Correction
(p.81)
17 Peripheral Illumination
Correction (p.81)5 Card slot number
6 ISO Auto Upper Limit
(p.57)
18 ASTROTRACER (p.121)
19 Anti-Aliasing Filter
Simulator (p.82)7 Highlight Correction
(p.80)
20 AF Assist Light (p.60)
8 Shadow Correction
(p.80)
21 Memory Card Options
(p.48)
9 Slow Shutter Speed
Noise Reduction (p.52)
22 File Format (p.48)
23 JPEG Recorded Pixels
(p.48)/Movie Recorded
Pixels (p.49)
10 High-ISO Noise
Reduction (p.58)
11 Clarity (p.83) 24 Program Line (p.52)
12 Skin Tone (p.83) 25 Wireless LAN Setting
13 Digital Filter (p.79) 26 List of setting options
302928
27
21 22 23 24 25
16 17 18 19 20
11 12 13 14 15
678910
43
1
2
5
26
±1.0EV
ISO AUTO MAX
6400
HDR Capture
O
9999
9999
9999
9999
302928
27
39 40
21 23 37 38 25
13 33 34 35 36
31 32 20 7 8
4
1
2
5
26
AF Active Area
Auto Area
9:59′59″
9:59′59″
9:59′59″
9:59′59″
B Mode
A Mode
1
Introduction
14
t Memo
• Refer to “Using the Control Panel” (p.20) for how to use the
control panel.
• The functions displayed on the control panel can be changed
in [Control Panel] of the E5 menu. (p.106)
The shooting information display changes each time G is
pressed in the standby mode.
t Memo
• The information displayed on Live View can be customized in
[Live View] of [Monitor Display] in the E4 menu. (p.108)
The captured image and shooting
information are displayed in the single
image display of the playback mode.
Press G to change the type of information displayed in the
single image display.
t Memo
• The playback information display can be set in [Playback Info
Display] of [Monitor Display] in the E4 menu. (p.108)
• When the camera is turned off and on again and enters the
playback mode, an image is displayed in the single image
display with the information displayed last. If [Playback Info
Display] is set to Y (Off) in [Memory] of the E5 menu, the
Standard Information Display always appears first when the
camera is turned on. Also, if [Image for Playback] is set to Z
(On) in [Memory], the last image played back is displayed first
next time. (p.111)
27 Camera battery level 35 Wind Noise Reduction
(p.49)
28 Battery grip battery level
(when D-BG8 is
attached)
36 Headphone Volume
(p.49)
29 Operation guide for the
control panel
customization (p.106)
37 Framerate (p.49)
38 Grid Style
39 Live View Shooting
Touch AF (p.51)
30 Parameter
31 AF Active Area (p.63) 40 Movie Recording Touch
AF (p.55)
32 Focus Peaking (p.64)
33 Shake Reduction (p.83)
34 Recording Sound Level
(p.49)
Changing the Shooting Information Display
When shooting
with the viewfinder
Status Screen Control Panel
Display Off Status Screen
When shooting
with Live View
Standard Information Display Control
Panel Simplified Information Display
No Information Display Standard
Information Display
Playback Mode
Standard
Information
Display
Captured image, file format, JPEG recorded
pixels, exposure parameters, and operation
guide indicators are displayed.
Detailed
Information
Display
Detailed information on how and when the
image was taken is displayed. (p.15)
No Information
Display
Only the captured image is displayed.
10:00
10:00
1/1
1/1
EV 0.0
EV 0.0
1/100
1/100
F5.6
F5.6
200
200
100-0001
100-0001
01/01/2021
01/01/2021
Manage Image
Manage Image
1
Introduction
15
Detailed Information Display
1 Shooting date and time 9 Image transfer status
(p.90)
2
Bluetooth
®
communication
3 Wireless LAN
communication
10
Store Location Information
11 Captured image
4 File Format, JPEG
Recorded Pixels (p.48)/
Movie Recorded Pixels
(p.49)
12 Image edit
13 Capture mode (p.49)
14 AE Metering (p.59)
15 Flash Mode (p.77)
5 Folder number-File
number (p.111)
16 Crop (p.48)
17 JPEG Quality (p.48)/
Framerate (p.49)6 Card slot number in use
7 Battery level 18 JPEG Recorded Pixels
(p.48)
8 Protect (p.89)
19 Color Space (p.48)
100-000110:3010:30
10:3010:30
10:3010:30
EV+0.7EV+0.7
1
8
9
10
11
12
13 14
20
28
31
23 24
3029
25
35 36 3733 34
38 39
40 41
4232
27
45 46 47 48 49
26
21 22 43
44
15 16 17 18 19
23 4 5 6 7
1
8
9
11
13 14
28
20
23
29
25
38 39
42
45 46 47 48 49
51 43
44
50 17
23 4 5 6 7
1
8
9
10
11
12
55 56
57 58
45 46 47 48 49
52
54
53
54
23 4 5 6 7
BA
EE
NN
01/01/202101/01/2021
01/01/202101/01/2021
01/01/202101/01/2021
+0.3+0.3
+1.0EV+1.0EV
RR+200%+200%
GG +20%+20%
BB 0%0%
1000.0mm1000.0mm
9999999999 00:0 0′23″00:00′23″
6192x41286192x4128
00
00
00
00
00
00
00
100-0001100-0001
100-0001100-0001
RR+200%+200%
GG +20%+20%
BB
0%0%
1000.0mm1000.0mm
99′59″99′59″
1/4001/400 F5.6F5.6 16001600 EV+0.7EV+0.7
00
00
00
00
00
00
00
9999/99999999/9999
1/4001/400 F5.6F5.6 16001600 EV+0.7EV+0.7 9999 /99999999/9999
1234567890ABCDEF1234567890ABCDEF
1234567890ABCDEF1234567890ABCDEF
1234567890ABCDEF1234567890ABCDEF
1234567890ABCDEF1234567890ABCDEF
10:30:0010:30:00
359
°
359
°
9999m9999m
1/4001/400 F5.6F5.6 16001600 9999/99999999/9999
59.999′59.999′
59.999′59.999′
179
°
179
°
89
°
89
°
01/01/202101/01/2021
Still Images
Movies
Page 2
20 Drive Mode (p.66) 36
Diffraction Correction (p.81)
21 Number of shots for
Interval Shooting/Interval
Composite (p.71)
37 Color Fringe Correction
(p.92)
38
Highlight Correction (p.80)
22
Total shooting time for
Interval Composite (p.72)
39
Shadow Correction (p.80)
40 Slow Shutter Speed
Noise Reduction (p.52)23 White Balance (p.74)
24 Anti-Aliasing Filter
Simulator (p.82)
41 High-ISO Noise
Reduction (p.58)
25 Digital Filter (p.79) 42
RGB value for Filter Effect
26 Brightness histogram 43 Custom Image (p.78)
27 RGB histogram 44
Custom Image parameters
28 Shake Reduction (p.83)/
Auto Horizon Correction
(p.84)
45 Shutter speed
46 Aperture value
47 ISO Sensitivity (p.57)
29 Lens focal length 48 EV Compensation (p.54)
30 HDR Capture (p.81)/
Pixel Shift Resolution
(p.82)/Clarity (p.83)/Skin
Tone (p.83)
49 Number of images
50 Recording Sound Level
(p.49)
51 Length of time of the
recorded movie
31 Focus method (p.59)
32 Focusing area (AF point)
(p.60)
52 Photographer (p.114)
53 Copyright Holder (p.114)
33 Distortion Correction
(p.81)
54
Tampered image warning
55 Altitude
34 Peripheral Illumination
Correction (p.81)
56 Lens direction
57 Latitude/Longitude
35 Lateral Chromatic
Aberration Adjustment
(p.81)
58 Universal Coordinated
Time
Using the Touch Panel
You can use the touch panel to select functions, set the AF
point for shooting, and perform other operations. (p.51)
When not using the touch panel
function, set [Monitor Touch
Operation] to [Off] in the E3
menu.
Monitor Touch Operation
On
O
CancelCancel OKOK
1
Introduction
16
The shooting information such as the exposure value is
displayed on the LCD panel and in the viewfinder.
LCD Panel
Viewfinder Display
LCD Panel and Viewfinder
Sv
P
AU
T
O
U1
U2
U3
U
5
X
M
TAv
B
Av
Tv
1
1
2
2
3
3
5
5
4
4
7
7
8
8
16
16
17
17
10
10
11
11
13
13
12
12
15
15
6
6
9
9
14
14
1 Shutter speed/
Remaining processing
time for Slow Shutter
Speed Noise Reduction
(p.52)/AF Mode (p.60)/
Number of shots for
Bracketing (p.67)
4 EV Compensation
(p.54)/Bracketing (p.67)
5 EV bar scale
6 Card slot number
7 Flash Exposure
Compensation (p.77)
8 Multi-exposure (p.70)
2 Aperture value 9 Continuous Shooting
(p.67)
3 ISO Sensitivity (p.57)/
Exposure compensation
value/Image storage
capacity/AF Active Area
(p.60)
10 Remote Control (p.73)
11 AE Metering (p.59)
12 Mirror Up
13 Interval Shooting (p.71)
30
28
33
12 14 89 19 20 21
22
49 5047 48 51 52 53 54
23 24 2625
7 17
31
29
27
32
34 35 36 37 38 39 40 41 43 44 45 4642
1 2 3 41118 5
27
1
Introduction
17
t Memo
• The LCD panel illumination and the viewfinder display can be
changed in [LCD Panel] of the E4 menu and [Viewfinder
Display] of the E4 menu, respectively. (p.108, p.107)
• No. 1 to 26 for the viewfinder display are the outside-field-of-
view information. The outside-field-of-view information is
displayed in the viewfinder when 0 is pressed halfway,
or during the meter operating time (default setting: 10
seconds). To not display the outside-field-of-view information,
change the [Info Display Outside FOV] setting in [Viewfinder
Display] of the E4 menu. You can change the meter
operating time in [Meter Operating Time] of the E5 menu.
(p.33)
• The functions currently enabled for the Smart Function and
their settings are displayed for No. 17 and No. 33 to 53. When
U is operated, the icons of registered functions appear,
and the icon of the currently selected function blinks. (p.19)
• You can adjust the viewfinder
image sharpness using the diopter
adjustment dial.
14 Warning Display (p.110) 35 Pixel Shift Resolution
(p.82)
15 Self-timer (p.73)
16 Battery level 36 AF Mode (p.60)
17 Smart Function (p.19) 37 AF Active Area (p.60)
18 Focus indicator 38 AE Metering (p.59)
19 HDR Capture (p.81) 39 EV Compensation (p.54)
20 Focus method (p.59) 40 Program Line (p.52)
21 File Format (p.48) 41 E-Dial
22 AE Lock 42 Flash Exposure
Compensation
23 Shake Reduction (p.83)
24 Pixel Shift Resolution
(p.82)
43 Custom Image (p.78)
44 Crop (p.48)
25 Anti-Aliasing Filter
Simulator (p.82)
45 Zoom Review
46 Outdoor View Setting
(p.13)26 Flash indicator (p.77)
27 Electronic level 47 HDR Capture (p.81)
28 Grid display (p.107) 48 Shake Reduction (p.83)
29 Cropping frame (p.48) 49 Focus Peaking (p.64)
30 AF Frame (p.45) 50 Hold AF Status (p.61)
31 Spot Metering Frame
(p.59)
51 ISO Sensitivity (p.57)
52 White Balance (p.74)
32 AF point (p.60) 53 Grid Guide
33 Drive (p.66) 54 Operation Control Lock
(p.46)
34 Anti-Aliasing Filter
Simulator (p.82)
Eye Sensor
The eye sensor detects whether
the user is looking through the
viewfinder in the standby mode
while shooting with the viewfinder.
When the sensor detects the
user’s eye, the monitor backlight
turns off and the metering starts.
The setting can be changed in
[Eye Sensor] of the E4 menu. (p.107)
The eye sensor may operate when an object is brought close
to it or it is exposed to direct sunlight. It is also used for the
automatic brightness adjustment of the monitor. (p.109)
Eye sensor
1
Introduction
18
The electronic level is displayed on the status screen and Live
View and in the viewfinder to check whether the camera is tilted.
The horizontal scale shows the horizontal camera angle, and
the vertical scale shows the vertical camera angle, in units of
0.5°.
Example of Viewfinder Display
t Memo
• For the electronic level displayed in the viewfinder, you can
hide the vertical camera angle by changing the [Electronic
Level Type] setting in [Viewfinder Display] of the E4 menu.
(p.107)
Most functions are set from the menus. Frequently used
functions can also be set by operating buttons, using the Smart
Function, or selecting on the control panel. The functions set
with the button operation, Smart Function, and control panel can
be customized.
Press ABCD in the standby mode.
By default, the following functions can be set.
t Memo
• The functions of ABCD and other buttons such as O
can be changed in [Fx Button] of the E2 menu. (p.102)
Electronic Level
When the camera is level (tilt: 0°)
When the camera is tilted downward to the left by more than 5°
When the camera is held vertically and tilted downward to the right by 3°
How to Change Function Settings
Using the Direct Keys
A Drive Mode p.66
B
Outdoor View
Setting
p.13
C White Balance p.74
D Custom Image p.78
1
Introduction
19
You can quickly change the settings for the five registered
functions while looking through the viewfinder or displaying the
Live View.
By default, the following functions can be set.
1 Press U, and then turn
R.
The function selection changes.
The icons of the settable
functions appear in the viewfinder
and on the LCD panel.
The icon of the selected function
blinks.
The operation guide is displayed
on the status screen and Live
View.
Available operations
2 Turn V.
The setting for the selected
function changes.
t Memo
• The functions set with the Smart Function can be changed in
[Smart Function] of the E2 menu. (p.106)
• The setting of the last selected function can be changed with
V in the standby mode.
Using the Smart Function
Function Setting Description Page
User AF
Switches between the settings of [AF
Mode], [AF Active Area], and [Hold AF
Status] specified in advance.
p.60
E-Dial Changes the exposure value. p.50
Drive
Switches between the drive modes of
[Drive] in [Drive Mode] specified in advance.
p.66
Crop
Switches between the settings of [Crop] in
the A5 menu.
p.48
Grid
Guide
Switches between the display patterns
specified in advance in [Viewfinder Screen]
of [Viewfinder Display] when shooting with
the viewfinder.
Changes the type of grid displayed on the
Live View screen when shooting with Live
View.
p.107
p.108
U
Starts/ends changing the settings.
M
Resets the function setting to the default
setting.
OK
OK
User AF
User AF
Current Settings
Current Settings
1
Introduction
20
The shooting functions can be set.
1 Press G in the standby mode.
The control panel appears.
2 Use ABCD to select a
function.
3 Turn R to change the
setting.
Available operations
4 Press F.
The screen in the standby mode reappears.
t Memo
• The functions that can be selected vary depending on the
current camera settings.
• The functions displayed on the control panel can be changed
by pressing J on the screen of Step 2 or changing the
[Control Panel] setting in the E5 menu. (p.106)
Most functions can be set from the menus.
1 Press F.
The menu appears.
2 Turn Q to switch the
menu type.
The menu type can also be switched by pressing C twice,
selecting the type with AB, and pressing D twice.
3 Use AB to select a function.
Each menu type includes one to eight menus.
Turn R to switch between menus.
4 Find a function to set and
press D.
The settings for the selected
function are displayed.
Using the Control Panel
Q Changes the parameter for the selected
function (when detailed settings can be
made).
E Displays the menu screen for the selected
function.
J
Customizes the control panel.
409600
6400
12800
25600
51200
102400
204800
3200
ISO AUTO MAX
6400
ISO Auto Upper Limit
9999
9999
9999
9999
±2.0EV
ISO AUTO MAX
6400
HDR Capture
O
9999
9999
9999
9999
Using the Menus
A Still image setting menus (p.22)
B In B mode: Movie setting menus (p.25)
C Playback setting menus (p.27)
E Customization menus (p.28)
D Setup menus (p.34)
AF with Live View
AF Assist Light
AE Metering
Face Priority AE
Link AE and AF Point
ISO Sensitivity Setting
AF with Viewfinder
Focus Settings
On
O
Monitor Touch Operation
Monitor Touch Operation
LV Shooting Touch AF
Movie Touch AF
Eye Sensor
Viewfinder Display
LCD Panel
Monitor Display
On
1
Introduction
21
5 Use AB to select a setting
and press E.
The screen of Step 4 reappears.
Press F to return to the
previous screen without changing
the setting.
6 Press F several times to return to previous
screens.
t Memo
• The menu displayed in Step 2 varies depending on the A/
K/B dial setting.
• When F is pressed, the last used menu screen appears
first. To display the most appropriate menu for the camera
settings at that time, set [Store Cursor Position] to [Off] in the
D2 menu.
• The changed settings remain even after the camera is turned
off. For some functions, you can set whether to keep the
changed settings in [Memory] of the E5 menu. (p.111)
• Each menu type can be restored to
the default settings in [Reset] of the
D8 menu.
Monitor Touch Operation
On
O
CancelCancel OKOK
Reset
Reset Item
Execute Reset
Select items to reset.
1
Introduction
22
Menu List
A Still Image Setting Menus
Item Function Default Setting Page
A1 Focus Settings
AF with Viewfinder
AF Mode
Selects the autofocus method for shooting with the
viewfinder.
Single AF p.60
AF Active Area Sets the AF point for shooting with the viewfinder. Auto Area p.60
AF Area Restriction Limits the range of selectable AF points. Off p.61
AF.S Setting
Sets the camera operation priority for when the autofocus
mode is set to [Single AF] and 0 is fully pressed.
Focus-priority p.61
1st Frame Action in
AF.C
Sets the camera operation priority for the first frame when
the autofocus mode is set to [Continuous AF] and 0
is fully pressed.
Auto p.61
Action in AF.C Cont.
Sets the camera operation priority during the continuous
shooting when the autofocus mode is set to [Continuous AF].
Auto p.61
Hold AF Status
Maintains the focus for a certain amount of time when the
subject happens to move out of the selected focusing area
after being focused during shooting with [Continuous AF].
Low p.61
Action When AF Fails
Sets the camera operation for when autofocus fails. Drive Lens p.61
AF Point Tracking in
AF.C
Sets the method for tracking AF points when the autofocus
mode is set to [Continuous AF].
Type 1 p.62
Subject Recognition Prioritizes the recognized subject while autofocusing. On p.62
Catch-in Focus
Enables Catch-in Focus shooting when a manual focus lens
is attached. The shutter is released automatically when the
subject comes into focus.
Off p.62
AF with Live View
AF Active Area
Sets the AF active area (AF point) for shooting with Live
View.
Auto Area p.63
Focus Peaking
Emphasizes the outline of the subject in focus and makes it
easier to check the focus.
Off p.64
Contrast AF Options
Sets the camera operation priority for when 0 is fully
pressed.
Focus-priority p.64
Face Detection
Detects faces and performs autofocus for the detected faces.
On p.64
1
Introduction
23
AF Assist Light
Illuminates the assist light when autofocusing in dark
locations.
On p.60
A2 Exposure Setting
AE Metering
Selects the part of the sensor to use for measuring
brightness and determining the exposure.
Multi-segment p.59
Face Priority AE
Adjusts the exposure value by giving priority to the detected
faces when [AE Metering] is set to [Multi-segment].
On p.59
Link AE and AF Point
Adjusts the exposure value according to the brightness of
the AF point.
Off p.59
ISO Sensitivity
Setting
ISO Auto Upper Limit
Sets the ISO sensitivity upper limit for ISO Auto. 6400
p.57
ISO Auto Lower Limit
Sets the ISO sensitivity lower limit for ISO Auto. 100
Min. Shutter Speed
Op.
Sets whether to set the minimum shutter speed
automatically or manually.
Auto
ISO Auto with Min.
Speed
Sets how to increase the sensitivity. Standard
Minimum Shutter
Speed
Sets the shutter speed at which the ISO sensitivity is increased
when [Min. Shutter Speed Op.] is set to [Shutter Speed Control].
1/125
Flash Mode Sets the flash mode.
Flash On or
Auto Flash
Discharge
p.77
Program Line Selects the Program Line setting. Standard p.52
Auto EV Compensation
Automatically compensates the exposure when the correct
exposure cannot be achieved with the current settings.
Off p.51
A3 White Balance Settings
White Balance Sets the white balance according to the light source.
Auto White
Balance
p.74
Auto Adjust. for Source
Automatically fine-tunes the white balance when the light
source is specified for the white balance setting.
Off
p.75
AWB in Tungsten Light
Sets the correction level for tungsten light when the white
balance is set to [Auto White Balance].
High
A4 Shooting Settings
Drive Mode
Drive Selects the drive mode.
Single Frame
Shooting
p.66
Timer/Remote
Control
Sets whether to use the self-timer and remote control
functions.
Off p.73
Item Function Default Setting Page
1
Introduction
24
AA Filter Simulator
Applies a low-pass filter effect using the Shake Reduction
mechanism.
Off p.82
HDR Capture
HDR Capture
Makes settings for high dynamic range shooting.
Off
p.81Bracket Value ±2.0EV
Auto Align On
Pixel Shift Resolution
Merges multiple images and outputs a high-definition
image.
Off p.82
ASTROTRACER
ASTROTRACER Makes settings to track and capture celestial bodies. Off
p.121
Precise Calibration Performs a calibration. —
A5 Image Capture Settings
Memory Card
Options
Memory Card
Options
Sets the recording method for when two memory cards are
inserted.
Sequential Use
p.48
Card Slot Sequence
Selects one of the memory cards inserted in the SD1 and
the SD2 slots to use when [Memory Card Options] is set to
[Sequential Use].
SD1
File Format Sets the file format of images.
JPEG
p.48
Crop Sets the angle of view for shooting. Off
JPEG Recorded Pixels Sets the recording size of JPEG images.
q
JPEG Quality Sets the quality of JPEG images. Super Fine
RAW File Format Sets the RAW file format.
PEF
Color Space Sets the color space to use.
sRGB
A6 Image Process Settings
Custom Image Sets the image finishing tone including color and contrast.
Bright
p.78
Digital Filter Applies a digital filter effect when taking images. Off p.79
Clarity
Changes the clarity of images using an image processing
function.
±0 p.83
Skin Tone
Enhances the skin tone of images using an image
processing function.
Off p.83
Item Function Default Setting Page
1
Introduction
25
Lens Correction
Distortion Correction
Reduces distortions occurring due to lens properties. Off
p.81
Peripheral Illumin.
Corr.
Reduces peripheral light fall-off occurring due to lens
properties.
Off
Lat-Chromatic-Ab
Adj
Reduces lateral chromatic aberrations occurring due to lens
properties.
On
Diffraction
Correction
Corrects blur caused by diffraction when using a small
aperture.
On
D-Range
Correction
Highlight Correction
Expands the dynamic range and prevents overexposed
areas from occurring.
Auto
p.80
Shadow Correction
Expands the dynamic range and prevents underexposed
areas from occurring.
Auto
Noise Reduction
Slow Shutter Speed
NR
Sets the noise reduction setting when shooting with a slow
shutter speed.
Auto p.52
High-ISO Noise
Reduction
Sets the noise reduction setting when shooting with a high
ISO sensitivity.
Auto
p.58
Custom Options
Sets the noise reduction level for each ISO sensitivity
setting for [High-ISO Noise Reduction].
Medium
A7 Shooting Assist
Shake Reduction
Activates the Shake Reduction function. Auto p.83
Auto Shake Reduction Off
Automatically sets the Shake Reduction function to [Off]
when [Self-timer] or [Remote Control] is used.
Enable Auto
SR Off
p.83
Auto Horizon Correction Corrects horizontal tilt during still image shooting. Off p.84
Composition Adjustment
Allows you to adjust the composition of your image using
the Shake Reduction mechanism.
Off p.84
B Movie Setting Menus
Item Function Default Setting Page
B1 Focus Settings
AF with Live View
AF Active Area Sets the AF active area (AF point). Auto Area p.63
Movie Mode AF Sets the autofocus operation in B mode. Continuous AF p.55
Focus Peaking
Emphasizes the outline of the subject in focus and makes it
easier to check the focus.
Off p.64
Item Function Default Setting Page
1
Introduction
26
AF Assist Light
Illuminates the assist light when autofocusing in dark
locations.
On p.60
B2 Exposure Setting
AE Metering
Selects the part of the sensor to use for measuring
brightness and determining the exposure.
Multi-segment p.59
Link AE and AF Point
Sets whether to link the exposure value and the AF point in
the focusing area.
Off p.59
B3 White Balance Settings
White Balance Sets the white balance according to the light source.
Auto White
Balance
p.74
Auto Adjust. for Source
Automatically fine-tunes the white balance when the light
source is specified.
Off
p.75
AWB in Tungsten Light
Sets the tungsten light color tone when the white balance is
set to [Auto White Balance].
High
B4 Shooting Settings
Remote Control Sets whether to use the remote control function. Off p.73
B5 Movie Capture Settings
Memory Card Options
Selects one of the memory cards inserted in the SD1 and
the SD2 slots for recording movies.
SD1
p.48
Recorded Pixels Sets the number of recorded pixels of the movie. z
p.49
Framerate Sets the number of framerate of the movie. 30p
Recording Sound Level Sets the sound volume level for recording. Auto
Wind Noise Reduction Reduces wind noise. On
Headphone Volume Sets the sound volume when a headphone is connected. 20
B6 Image Process Settings
Custom Image Sets the image finishing tone including color and contrast. Bright p.78
Digital Filter Applies a digital filter effect when recording movies. Off p.79
D-Range
Correction
Highlight Correction
Expands the dynamic range and prevents overexposed
areas from occurring.
Auto
p.80
Shadow Correction
Expands the dynamic range and prevents underexposed
areas from occurring.
Auto
B7 Shooting Assist
Shake Reduction
Activates the Shake Reduction function. On p.83
Item Function Default Setting Page
1
Introduction
27
Auto Shake Reduction Off
Automatically sets the Shake Reduction function to [Off]
when [Remote Control] is used.
Enable Auto
SR Off
p.83
C Playback Setting Menus
Item Function Default Setting Page
C1 Playback Settings
Select Playback Card
Selects one of the memory cards inserted in the SD1 and
the SD2 slots for playing back images.
SD1
p.85
Auto Image Rotation
Rotates images which were captured with the camera held
vertically or of which the rotation information has been
changed.
On
Playback Order Options Sets the image display order during playback. File No.
Playback Sound Volume Sets the sound volume during movie playback. 20
Touch Img. Browse Effect
Sets whether to use the screen effect when the previous or
next image is displayed by touch operation.
On
C2 File Management
Delete Deletes images. — p.88
Protect Protects images from being accidentally erased. — p.89
Image Rotation Changes the rotation information of an image. — p.89
Image Copy
Copies images between cards in the SD1 and the SD2
slots.
—p.90
File Transfer
Sets the transfer reservation for images to transfer to a
communication device.
—p.90
Save RAW Data Saves the RAW data of a captured JPEG image. — p.91
C3 RAW/JPEG Image Edit
Digital Filter Processes images with digital filters. — p.91
Cropping Crops out only the desired area of an image. — p.94
C4 RAW Image Edit
RAW Development
Develops RAW images into JPEG images and saves them
as new files.
—p.92
C5 JPEG Image Edit
Resize Changes the number of recorded pixels of an image. — p.93
Item Function Default Setting Page
1
Introduction
28
Levels Adjustment
Adjusts the brightness and contrast of the highlight, mid-
tone, and shadow areas in images.
—p.94
WB Adjustment Adjusts the white balance. — p.95
Color Moiré Correction Reduces color moiré in images. — p.95
C6 Movie Edit
Extract Movie
Saves the range specified with the start and end points as
a new file.
—
p.96
Divide Movie
Divides a movie into two files at the specified devision point
and saves as new files.
—
C7 Save Settings from Image
Save as Manual WB
Saves the white balance settings of a captured image as
Manual White Balance.
—p.76
Save Cross Processing
Saves the settings used for an image captured with [Cross
Processing] of [Custom Image] as your favorite settings.
—p.79
E Customization Menus
Item Function Default Setting Page
E1 User Mode
Save User Mode Settings
Saves frequently used capture settings in up to ten setting
boxes.
—
p.100
Rename User Mode Changes the name of a setting box. —
Recall User Mode Setting Assigns the saved settings to O to 5 of the mode dial. —
Reset User Mode Settings Resets the settings saved in a setting box. —
Exposure in User Mode
Temporarily changes the exposure mode when the mode
dial is set to one of the modes from O to 5.
G p.101
User Settings Restoration
Set the timing to restore the settings saved in the user
mode.
Type 1 p.101
Item Function Default Setting Page
1
Introduction
29
E2 Customize Controls
Fx Button
Shake Reduction
Button
Customizes the button functions.
Shake
Reduction
p.102
RAW Button
One Push File
Format
Operation Lock
Button
Operation
Control Lock
AE Metering Button AE Metering
Playback Button
Playback
Mode
AE Lock Button AE Lock
Up Button Drive Mode
Down Button
Outdoor View
Setting
Left Button White Balance
Right Button Custom Image
One Push File
Format
Sets the file format to change to with the One Push File
Format function.
RAW+JPEG,
On
p.103
Shake Reduction
Sets the Shake Reduction operation switching pattern when
the button is pressed.
OFF→AUTO
→PAN
p.103
Operation Control
Lock
Sets the type of buttons to lock the operation when the
button is pressed.
Exposure
Change Lock
AF/AE Lock
Settings
Still Image
Sets the autofocus operation when 0 is pressed
halfway or I is pressed in A mode.
Enable AF,
Enable AF
Off
p.104
Movie
Sets the autofocus operation when 0 is pressed
halfway in B mode.
Enable AF p.55
Preview Dial
Preview Method
Sets the camera operation for when the main switch is
turned to the U position.
Optical
Preview
p.65
Digital Preview
Settings
Sets the functions to use during Digital Preview. All On
Item Function Default Setting Page
1
Introduction
30
E-Dial
Programming
Still Image
G
Sets the Q/R/M/V operation for each exposure
mode.
I
HYPER,
J
HYPER,
XG
, ISO
p.104
H
Off, ISO, —,
J
I
I, Off, —,
ISO
J
Off, J, —,
ISO
K
I, J, —,
J
L
I, J,
G LINE, ISO
M
Off, J,
Timed
exposure, ISO
N
Off, J, —,
ISO
Movie
G
Sets the Q/R/M/V operation for each exposure
mode.
Off, Off, —, J
I
I, Off, —,
J
J
Off, J, —,
J
K
I, J, —,
J
L
I, J,
G LINE, ISO
Rotation Direction Reverses the effect obtained when Q or R is turned. Rotate Right p.105
HYPER P/Sv
Options
Sets the camera operation when the camera enters the
Hyper mode in G or H mode.
Standard p.105
Smart Function
Function 1
Registers the functions to use with the Smart Function.
User AF
p.106
Function 2 E-Dial
Function 3 Drive
Function 4 Crop
Function 5 Grid Guide
Item Function Default Setting Page
1
Introduction
31
One Push ISO Auto
Resets to ISO Auto with N without displaying the setting
screen when the ISO sensitivity can be changed with Q,
R, and V.
Off p.57
One Push Exposure Reset
Resets the compensation value with J when the exposure
can be compensated with Q, R, and V.
Off p.54
E3 Monitor Touch Operation
Monitor Touch Operation
Sets whether to use the touch panel function to operate the
camera.
On p.15
LV Shooting Touch AF
Sets the camera operation when Touch AF is performed
during shooting with Live View.
AF Point p.51
Movie Touch AF
Sets the camera operation when Touch AF is performed
during movie recording.
AF Point p.55
E4 Display Customization
Eye Sensor
Link Monitor Display
Turns off the monitor backlight when the eye sensor detects
the user’s eye.
On
p.107
AE with Eye Sensor Starts metering when the eye sensor detects the user’s eye. Off
Detection Sensitivity Sets the eye sensor detection sensitivity. Medium
Viewfinder Display
Viewfinder Screen Sets the display in the viewfinder. F1
p.107
Electronic Level
Type
Displays the electronic level in the viewfinder. Level+Tilt
Viewfinder Light
Sets whether to light up the viewfinder when focusing the
subject or changing the focusing area.
Auto
Info Display Outside
FOV
Displays information at the bottom outside the field of view
in the viewfinder.
On
LCD Panel
Illumination
Brightness
Sets the brightness of the LCD panel. High
p.108
LCD Panel
Illumination
Sets the illumination method of the LCD panel. Auto
Item Function Default Setting Page
1
Introduction
32
Monitor Display
Color Settings
Sets the display color and style of the status screen, control
panel, and menu cursor.
Color: 01,
Style: 1
p.108
Status Screen Sets the status screen display.
On, On,
Level+Tilt,
Type 1
Live View
Sets the information to display when the style of the display
is switched with G during shooting with Live View.
L1, Level+Tilt,
Type 1, 50Hz
Playback Info
Display
Sets the information to display when the screen is switched
with G in the playback mode.
All Off
Grid Guide Sets the type and color of grid lines.
4x4 Grid,
Black
Instant Review
Display Time Sets the Instant Review display time. 1sec.
p.109
Zoom Review
Displays the magnified image with R during Instant
Review.
On
Save RAW (RAW
Button)
Saves the RAW data with O during Instant Review. On
Delete Img. (Delete
Btn.)
Deletes the displayed image with L during Instant Review. On
Manage Img. (AE-L
Btn.)
Displays the file management screen with H during Instant
Review.
On
Histogram Displays the histogram during Instant Review. Off
Highlight Alert Sets overexposed areas to blink red during Instant Review. Off
Zoom Review
Quick Zoom
Sets the display magnification and trigger operation for the
quick zoom function during Instant Review.
100%
p.109
Focus Magnification Zooms the display centering on the focused point. On
Warning Display
Release Lock
Warning
Displays the warning icon when the shutter cannot be
released.
On
p.110
Release Timer
Warning
Displays the warning icon when the shutter cannot be
released immediately because [Self-timer] or [Remote
control] is used.
On
Image Processing
Warning
Displays the warning icon when the image processing takes
a long time after shooting.
On
E5 Function Customization
Control Panel Customizes the functions displayed on the control panel. — p.106
Item Function Default Setting Page
1
Introduction
33
Memory
ISO Sensitivity
Determines which settings to save when the power is
turned off.
On
p.111
EV Compensation On
Flash Mode On
Flash Exposure Comp.
On
White Balance On
Drive On
Timer/Remote Control
On
HDR Capture Off
Pixel Shift Resolution
Off
Crop On
Custom Image On
Digital Filter Off
Clarity Off
Skin Tone Off
Composition Adjustment
On
Shooting Info Display
On
Playback Info Display
On
Image for Playback Off
Operation Control
Lock
On
Outdoor View Setting
Off
Night Vision Display Off
EV Steps Sets the adjustment steps for the exposure. 1/3 EV Steps p.51
ISO Sensitivity Steps Sets the adjustment steps for the ISO sensitivity. 1 EV Step p.57
Meter Operating Time Sets the time to continue metering after it is started. 10sec. p.17
Bulb (B) Mode Options
Sets the camera operation when 0 is pressed in M
mode.
Bulb
p.53
X Mode Sync Speed Sets the flash sync speed. 1/200 p.120
E6 Function Customization
AF with Remote Control
Sets whether to use autofocus when shooting with the
remote control unit.
Off p.74
Color Temperature Steps
Sets the adjustment steps for [Color Temperature] of the
white balance.
Kelvin p.76
Item Function Default Setting Page
1
Introduction
34
MF Lens Focal Length
Sets the focal length when using a lens of which focal length
information cannot be obtained.
35mm
p.119
Length Input on Startup
Sets whether to input the focal length when the camera is
turned on with a lens of which focal length information
cannot be obtained.
On p.119
Save Rotation Info
Sets the angle recorded as rotation information in captured
images.
Auto p.89
Using Aperture Ring
Releases the shutter even when the lens aperture ring is set
to a position other than 9 (Auto).
Off p.118
Aperture Info Record
Records the manually input aperture value in captured
images when the lens aperture value cannot be obtained.
Off p.118
E7 Function Customization
AF Fine Adjustment
Precisely fine-tunes lenses with the camera’s autofocus
system.
Off p.64
D Setup Menus
Item Function Default Setting Page
D1 File Setting
Format Formats a memory card. — p.43
Create New Folder Creates a new folder on the memory card. — p.111
Folder Name Sets the folder name in which images are stored. Date p.112
File Name Sets the file name assigned to an image. IMGP p.113
Sequential Numbering
Continues the sequential numbering for the file name when
a new folder is created.
Folder & File p.113
Reset Numbering
Resets the file number setting and returns to 0001 each
time a new folder is created.
—p.113
Copyright Information
Sets the photographer and copyright information embedded
in the Exif data.
Off p.114
D2 Monitor Settings
Store Cursor Position
Saves the last menu displayed on the monitor and displays
it again the next time F is pressed.
On p.21
Guide Display
Displays the setting change status when the Fx button is
operated.
On p.103
Item Function Default Setting Page
1
Introduction
35
Monitor Adjustment
Adjusts the brightness, saturation, and color tone of the
monitor.
Brightness:
Auto Brt. Adj.,
Others: 0
p.109
Outdoor View Setting Adjusts the brightness of the monitor for outdoor shooting. Off p.13
Night Vision Display
Changes the monitor display color to red for shooing at
night or in a dark place.
Off p.122
Exp. Simulation LV
Adjusts the screen brightness according to the exposure
setting when shooting with Live View.
On p.51
D3 Lamp/Sound Settings
Indicator Lamps
Self-timer
Sets whether to light up the self-timer lamp when shooting
with the self-timer.
On
p.110Remote Control
Sets whether to light up the self-timer lamp when shooting
with the remote control unit.
On
GPS Unit
Sets whether to light up the lamps when the GPS unit is
attached to the camera.
On
Sound Effects Volume Sets the sound volume of beep sounds.
3
p.110
Sound Effects
Setting
Electronic Shutter
Sound
Makes a shutter sound while shooting with the electronic
shutter.
On
In-focus Makes a beep sound when the subject is focused.
On
AE Lock Makes a beep sound when the exposure value is locked.
On
Count Down
Makes a beep sound during the countdown for shooting
with the self-timer or remote control unit (shutter release
after 3 seconds).
On
Mirror Up Makes a beep sound during the mirror lock-up shooting.
On
Fx Button Operation Makes a beep sound when the Fx button is operated. On
D4 Communication Settings
USB Setting
Sets the USB connection mode when connecting to a computer.
MTP p.97
Bluetooth Setting
Action Mode
Sets whether to use the Bluetooth
®
communication function.
Off
Separate
guide
*1
Pairing
Performs pairing between the camera and a communication
device.
—
Communication Info.
Displays [Device Name] of the camera. —
Wireless LAN
Setting
Action Mode
Sets whether to use the wireless LAN communication
function.
Off
Communication Info.
Displays [SSID], [Password], and [MAC Address] of the camera.
—
Item Function Default Setting Page
1
Introduction
36
*1 See RICOH IMAGING website for details.
Smartphone Link
Store Location Info.
Records the location information of the communication
device in captured images.
Off
Separate
guide
*1
Auto Image Transfer
Automatically transfers captured images to the
communication device after shooting.
Off
Auto Resize
Reduces the number of recorded pixels of images before
transferring them.
Off
Image Transfer
while Off
Continues the image transfer even when the camera is
turned off midway through the transfer.
Off
GPS Settings
Performs a calibration of electronic compass information
when the optional GPS unit is attached to the camera.
—p.121
D5 Power Supply Settings
Auto Power Off
Sets the time until the camera turns off automatically if no
operations are made for a certain period of time.
1min. p.42
Power Saving Mode
Controls the display time of the status screen to reduce
battery consumption.
High p.40
Battery Grip Settings
Sets the camera operation for when the optional battery grip
is attached to the camera.
Auto p.39
USB Power Supply to Ext. Supplies power to an external device via the USB cable. — p.40
D6 Maintenance
Firmware Info/Options
Displays the camera’s firmware version. You can check the
current firmware version before running an update.
——
Certification Marks
Displays the certification marks of conformance to wireless
technical standards.
—
Separate
guide
Pixel Mapping Maps out and corrects defective pixels on the sensor. — p.123
Dust Removal
Cleans the sensor by applying high-frequency (ultrasonic)
vibrations.
On, On p.123
Sensor Cleaning
Locks the mirror in the up position for cleaning the sensor
with a blower.
—p.124
D7 Language/Date Setting
Language/W Changes the display language.
English
p.43
Date Adjustment Sets the date and time and the display format.
01/01/2021
p.43
D8 Reset
Reset
Resets the settings of the direct keys, Smart Function,
menu items, and control panel items.
—p.21
Item Function Default Setting Page
2
Getting Started
37
1 Pass the end of the strap
through the triangular ring.
2 Secure the end of the strap
on the inside of the clasp.
1 Make sure that the camera is turned off.
2
Remove the body mount
cap (
1
) and lens mount
cover (
2
).
Turn the body mount cap
counterclockwise while pressing
the lens unlock button (3).
After removing the cover, be sure
to put the lens down with the lens
mount side facing upward.
3 Align the lens mount
indexes (red dots: 4) on
the camera and the lens,
and secure by turning the
lens clockwise until it
clicks.
To remove the lens
Attach the lens cap, and then turn
the lens counterclockwise while
pressing the lens unlock button.
Attaching the Strap
When the Battery Grip is Used
When the optional Battery Grip
D-BG8 is used, you can attach
one end of the strap to the battery
grip.
Attaching a Lens
2
1
3
4
2
Getting Started
38
u Caution
• When attaching or removing the lens, choose an environment
that is relatively free of dirt and dust.
• Keep the body mount cap attached on the camera when a
lens is not attached.
• Be sure to attach the lens mount cover and lens cap to the
lens after removing it from the camera.
• Do not insert your fingers inside the lens mount of the camera
or touch the mirror.
• The camera body and lens mount incorporate lens
information contacts. Dirt, dust, or corrosion may damage the
electrical system. Please contact your nearest service center
for professional cleaning.
• When a retractable lens is attached and is not extended, you
cannot take images or use some functions. If the lens is
retracted during shooting, the camera stops working. Refer to
“How to Use a Retractable Lens” (p.46) for details.
• We assume no responsibility nor liability for accidents,
damages, and malfunctions resulting from the use of lenses
made by other manufacturers.
t Memo
• Refer to “Functions Available with Various Lenses” (p.116) for
details on the functions of each lens.
Use the battery D-LI90 exclusively developed for this camera.
u Caution
• Insert the battery correctly. If the battery is inserted
incorrectly, it may not be removed.
• Wipe the electrodes of the battery with a soft dry cloth before
inserting.
• Do not remove the battery while the power is on.
• Be careful as the camera or battery may become hot after the
camera has been used continuously for a long period of time.
• Remove the battery when you do not use the camera for a
long period of time. The battery may leak and damage the
camera if left installed during prolonged periods of non-use. If
the removed battery is not used for six months or longer,
charge the battery for about 30 minutes before storing it. Be
sure to recharge the battery every six to twelve months.
• Store the battery in a location where the temperature will
remain at or below room temperature. Avoid locations with
high temperatures.
• The date and time may be reset if you leave the battery out of
the camera for long periods of time. If this happens, set the
current date and time again.
1 Open the battery cover.
Lift the battery cover unlock
knob, turn it towards OPEN to
unlock, and then pull the cover
open.
Using the Battery and Charger
Inserting/Removing the Battery
2
1
2
Getting Started
39
2 Face the A mark on the
battery towards the
outside of the camera, and
insert the battery until it
locks into place.
To remove the battery, push the
battery lock lever in the direction
of 3.
3 Close the battery cover.
Turn the battery cover unlock
knob towards CLOSE to lock,
and then put it down.
t Memo
• The battery level may not be displayed properly if the camera
is used at low temperatures or when performing continuous
shooting for a long time.
• Battery performance temporarily decreases as the
temperature decreases. When using the camera in cold
climates, have extra batteries at hand and keep them warm in
your pocket. Battery performance will return to normal at
room temperature.
• Have extra batteries ready when traveling overseas or taking
a lot of images.
• When the optional Battery Grip D-BG8 is used, you can set
the priority order of battery use in [Battery Grip Settings] of the
D5 menu.
1 Insert the power plug to
the USB power adapter
until it clicks.
2 Connect the USB cable to
the USB power adapter.
3 Plug the USB power
adapter into the power
outlet.
4 Make sure that the main switch of the camera is
set to [OFF], and open the terminal cover.
5 Connect the USB cable to
the USB terminal.
The self-timer lamp on the back
of the camera turns on while
charging (blinks once at intervals
of 5 seconds), and turns off when
the battery is fully charged.
3
4
5
Charging the Battery
2
3
2
Getting Started
40
u Caution
• If the camera is turned on while charging, the charging stops.
• If the self-timer lamp continues to blink rapidly, make sure that
the main switch is set to [OFF], remove the USB cable and
battery from the camera, and start over from the beginning. If
this does not improve the situation, contact your nearest
service center.
• If the battery starts to run down more quickly even after being
charged, the battery may have reached the end of its service
life. Replace the battery with a new one.
t Memo
• The maximum charging time is approximately 4.5 hours (it
depends on temperature and remaining battery power).
Charge the battery in a location where the temperature is
between 10°C and 40°C (50°F and 104°F).
• You can also charge the battery by connecting the camera to
a computer using the USB cable and turning the camera off.
(p.97)
• You can also charge the battery using the optional Battery
Charger D-BC177.
• When the optional Battery Grip D-BG8 is used, you can
charge the battery in the battery grip. The battery set in
[Battery Grip Settings] of the D5 menu of the camera is
charged first. The self-timer lamp blinks twice continuously
while charging the battery in the camera, and three times
continuously while charging the battery in the battery grip.
• You can also charge the battery by connecting a commercial
portable charger to the camera with a USB cable.
Supplying Power to Another Device
You can supply power to another device using the battery of
the camera via a USB cable. Select [Execute] in [USB Power
Supply to Ext.] of the D5 menu, and turn the camera off.
This function cannot be used if the battery level is
insufficient.
Power Saving Mode
The battery consumption can be reduced by controlling the
display time of the status screen. Make settings in [Power
Saving Mode] of the D5 menu.
Low
Turns the monitor off when the time set in [Meter
Operating Time] of the E5 menu elapses.
High
Performs metering for 2 seconds after Instant
Review during shooting, and turns the monitor off.
(Default setting)
Off
Keeps the monitor on even after the metering time
elapses.
2
Getting Started
41
We recommend the use of the optional AC Adapter Kit K-AC166
when using the camera for a long time.
1 Connect the AC adapt er to the AC plug cord, and
plug the cord into the power outlet.
2 Make sure that the camera
is turned off, and open the
terminal cover.
3 Connect the USB Type-C
cable of the AC adapter to
the USB terminal of the
camera.
u Caution
• Make sure that the camera is turned off before connecting or
disconnecting the AC adapter.
• Make sure that the connections are secure between the
terminals. The memory card or data may be corrupted if the
connection to the power supply is lost while the card is being
accessed.
• Be sure to read the manual of the AC adapter kit before using
the AC adapter.
The following memory cards can be used with this camera.
• SD Memory Card
• SDHC Memory Card
• SDXC Memory Card
In this manual, these cards are referred to as memory cards.
1 Make sure that the camera is turned off.
2 Slide the memory card
cover in the direction of 1,
and then rotate it to open
as shown by 2.
3 Insert a card all the way
into each memory card slot
with the memory card label
facing toward the side with
the monitor.
Push the memory card in once
and release to remove.
Using the AC Adapter
Inserting a Memory Card
2
1
2
Getting Started
42
4 Rotate the memory card
cover as shown by 3, and
slide it in the direction of
4.
u Caution
• When inserting a memory card into the memory card slot,
insert it straight. Inserting the memory card at an angle or
applying excessive force may damage the card or memory
card slot.
• Do not remove the memory card while the card access lamp
is lit.
• If the memory card cover is opened while the power is on, the
camera turns off. Do not open the cover while the camera is
in use.
• Use this camera to format (initialize) a memory card that is
unused or has been previously used on other devices. (p.43)
• Use a high-speed memory card when recording movies. If the
writing speed cannot keep up with the recording speed,
writing may stop during recording.
t Memo
• For details on how the data is recorded when two memory
cards are inserted, refer to “Memory Card Recording
Settings” (p.48).
• Memory cards compatible with the UHS-I/UHS-II standard
can be used. However, if an UHS-II memory card is inserted
in the SD2 slot, it operates at a speed equivalent to UHS-I.
Turn the camera on and make the initial settings.
1 Turn the main switch to
[ON].
The first time the camera is
turned on after purchase, the
[Language/W] screen
appears.
t Memo
• The power automatically turns off when you do not perform
any operations within a set period of time. (Default setting:
1min.) You can change the setting in [Auto Power Off] of the
D5 menu. The camera recovers from Auto Power Off when
0 or 3 is pressed.
4
3
Initial Settings
Turning the Camera On
2
Getting Started
43
1 Use AB to select the desired language in the
[Language/W] screen, and press E.
The selected language is set and the [Date Adjustment]
screen appears.
2 Set the display format and
the date and time.
Use CD to select an item and
AB to change the value.
Press F to cancel the setting.
3 Press E.
The date and time are set and the [Color Settings] screen
appears.
4 Make settings for [Color]
and [Style].
Use CD to select an item and
AB to change the value.
5 Press E.
The camera switches to the capture mode and is ready to
take an image.
t Memo
• You can change the settings of the display language and date
and time in the D7 menu, and the display color in [Color
Settings] of [Monitor Display] in the E4 menu. (p.36, p.108)
1 Press F.
The menu appears.
2 Turn Q to select D.
3 Select [Format] and press
D.
The [Format] screen appears.
4 Use AB to select the
memory card slot in which
the memory card to format
is inserted and press D.
5 Use A to select [Execute]
and press E.
Formatting starts. When
formatting is completed, the
screen of Step 4 reappears.
6 Press F twice.
The screen in the capture mode reappears.
u Caution
• Do not remove the memory card while formatting, or the card
may be damaged.
• Formatting deletes all data, both protected and unprotected.
t Memo
• When a memory card is formatted, the volume label “K-3 III”
is assigned to the card.
Setting the Display Language, Date and
Time, and Color
Color
Sets the display color of the status screen,
control panel, and menu cursor.
Style
Sets the style of the status screen and control
panel.
00 0001 ：//M/D/Y 01 2021
Cancel OK
Date Adjustment
Set the Date Format,
Date and Time.
101
F
F
5.6
5.6
1 /
1/
125
125
Color Style
Cancel OK
Color Settings
Formatting a Memory Card
D1
IMGP
File Setting
Format
Create New Folder
Folder Name Date
O
File Name
Sequential Numbering
Reset Numbering
Copyright Information
SD1
SD2
Format
Deletes all data on the SD1 slot
memory card.
Execute
Cancel
OK
2
Getting Started
44
Take images in R (Scene Analyze Auto) mode in which the
camera analyzes shooting conditions and automatically sets the
optimal shooting settings.
1 Remove the front lens cap
by pushing the top and
bottom portions as
indicated in the
illustration.
When a retractable lens is
attached, extend the lens before
turning the camera on.
y How to Use a Retractable Lens (p.46)
2 Turn the camera on.
3 Set the A/K/B dial to
A.
4 Set the focus method
switch to v.
5 Set the mode dial to R
while pressing the mode
dial lock button.
Basic Shooting Operation
Shooting with the Viewfinder
Sv
P
AUT
O
U1
U2
U3
U
5
X
M
TAv
B
Av
Tv
Sv
P
AUTO
U1
U2
U3
U5
X
M
TAv
B
Av
Tv
Mode dial
lock button
Dial indicator
2
Getting Started
45
You can release the mode dial
lock using the mode dial lock
release lever to easily operate
the mode dial without having to
press the mode dial lock button.
The selected capture mode is
displayed on the monitor.
6 Look through the viewfinder to view the subject.
When using a zoom lens, turn the zoom ring to the right or
left to change the angle of view.
7 Position the subject inside
the AF frame and press
0 halfway.
Autofocus is performed.
The focus indicator (P) appears
and you will hear a beep when the
subject comes into focus.
y Sound Effects settings (p.110)
8 Press 0 fully.
The captured image is displayed on the monitor (Instant
Review).
Available operations during Instant Review
t Memo
• You can use I to focus on the subject. (p.59)
• You can preview the image on the monitor and check the
depth of field before shooting. (p.65)
• You can set the operation and display settings for Instant
Review in [Instant Review] of the E4 menu. (p.109)
• When you want to lock the exposure value (AE Lock) by
pressing 0 halfway, make settings in [Still Image] of
[AF/AE Lock Settings] in the E2 menu.
u Caution
• Some functions are not available in R mode.
1 0 : 1 010:10
1 /1/
250250
1600
FF
5.65.6
SR
0 1 / 0 1 / 2 0 2 101/01/2021
9 9 9 99999
9 9 9 99999
L
Deletes the image.
R to the
right / E
Magnifies the image.
Use 6 to change the area to display.
O
Saves the RAW data (only when a JPEG
image was taken and the data remains in
the buffer).
H
Displays the file management screen for
deleting images, protecting images,
transferring files, and saving the RAW data.
Shutter/AF Button
Enable AF, Enable AF
No Function, Enable AF
Enable AF, Cancel AF
Shooting AE Lock
Shutter Halfway Press
When in Focus
Off
2
Getting Started
46
1 Set the A/K/B dial to
K in Step 3 of “Shooting
with the Viewfinder” (p.44).
The Live View image is displayed
on the monitor.
2 View the Live View image.
Available operations
3 Position the subject inside
the AF frame on the
monitor and press 0
halfway.
The AF frame turns green and
you will hear a beep when the
subject comes into focus.
Subsequent steps are the same as shooting with the
viewfinder.
Shooting while Viewing the Live View Image
E
Magnifies the image and returns to 1× image
display.
R Changes the magnification (up to 16×).
6 Change the area to display.
Push the lever in to return the display area to
the center of the image.
1/250
F 5 . 6
F5.6
AF frame
Disabling Operation Controls
Operation of buttons and dials can
be temporarily disabled to prevent
misoperation during shooting.
Turning R while pressing 7
disables the operation of buttons
and dials. Turning R again
enables the operation of them.
e is displayed on the status
screen as well as in the viewfinder
and Live View while the operation
of buttons and dials is disabled.
The group of buttons and dials to
be disabled can be selected in
[Operation Control Lock] of [Fx
Button] in the E2 menu. (p.103)
How to Use a Retractable Lens
If the camera is turned on when a
retractable lens, such as HD
PENTAX-DA 18-50mm F4-5.6 DC
WR RE, is attached and is not
extended, an error message is
displayed on the monitor. Turn the
zoom ring in the direction of 2
while pressing the button on the ring (1) to extend the lens.
When retracting the lens, turn the zoom ring in the opposite
direction to 2 while pressing the button on the ring and align
the white dot to the position 3.
1 /1/
250250
1600
FF
5.65.6
SR
9 9 9 99999
9 9 9 99999
1
2
3
2
Getting Started
47
You can review the captured image on the monitor.
1 Press 3.
The camera enters the playback
mode and the most recently
captured image is displayed
(single image display).
2 Review the captured image.
Available operations
t Memo
• When R is turned to the right to magnify the image, the
magnification is displayed at the bottom right of the screen.
“100%” appears when the image is displayed at the actual
pixel size (1× image display). You can set the display
magnification and trigger operation when magnifying images
in [Quick Zoom] of [Zoom Review] in the E4 menu. (p.109)
• When O is displayed on the monitor, the JPEG image that
was just taken can also be saved in RAW format (Save RAW
Data).
• You can change the information to display in the single image
display in [Playback Info Display] of [Monitor Display] in the
E4 menu. (p.108)
• While the power is on, the last played image is stored. If you
want to store the last played image even when the camera is
turned off, set [Image for Playback] to Z (On) in [Memory] of
the E5 menu. (p.111)
Reviewing Images
CD / Q / Flick Displays the previous or next
image.
L Deletes the image.
R to the right /
Pinch out /
Double-tap
Magnifies the image (up to 16×).
Use 6 to change the area to
display.
Push the lever in to return the
display area to the center of the
image.
E
Magnifies the image with the
magnification set in [Quick Zoom]
of [Zoom Review] in the
E
4
menu. (p.109)
In magnified view: Returns to the
entire image display.
10:00
10:00
1/1
1/1
EV 0.0
EV 0.0
1/100
1/100
F5.6
F5.6
200
200
100-0001
100-0001
01/01/2021
01/01/2021
Manage Image
Manage Image
R to the left /
Pinch in
Switches to the thumbnail display
(p.85).
M
Switches between the SD1 card
and the SD2 card.
O Saves the RAW data (only when
a JPEG image was taken and the
data remains in the buffer).
G
Changes the type of information
displayed (p.14).
H /
Tap and hold
Displays the playback function
selection screen (p.85).
3
Shooting
48
You can set the recording method for
when two memory cards are inserted
in [Memory Card Options] of the A5
menu.
In B mode, select [SD1] or [SD2] as the slot to use for saving
movies.
You can set the file format for still
images in the A5 menu.
u Caution
• When [Memory Card Options] is set to [Separate RAW/
JPEG] in the A5 menu, [File Format] is fixed to
[RAW+JPEG].
• When [Crop] is set to [1.3x], q cannot be selected for [JPEG
Recorded Pixels].
t Memo
• When [File Format] is set to [RAW+JPEG], a JPEG image
and a RAW image with the same file number are saved at the
same time.
• You can change the setting so that you can take images in
another file format when O is pressed (One Push File
Format). (p.103)
• [PEF] of [RAW File Format] is a PENTAX original RAW file
format.
• When [Crop] is set to [1.3x], the cropping frame is displayed
in the viewfinder. (p.16) Perform shooting so that the subject
is positioned in the frame.
Configuring the Capture Settings
Memory Card Recording
Settings
A5 / B5
Sequential Use When the memory card in one slot
becomes full, saves data to the card in the
other slot.
The slot to use can be switched with [Card
Slot Sequence].
Save to Both Saves the same data to the memory cards
in both the SD1 and the SD2 slots.
Separate RAW/
JPEG
Saves the RAW data to the memory card
in the SD1 slot, and the JPEG data to the
card in the SD2 slot.
Memory Card Options
Memory Card Options
Card Slot Sequence
Still Image Capture Settings
A5
File Format JPEG, RAW, RAW+JPEG
Crop 1.3x, Off
JPEG Recorded Pixels q, p, o, r
JPEG Quality Super Fine, Fine, Economy
RAW File Format PEF, DNG
Color Space sRGB, AdobeRGB
PEF
File Format
Crop O
JPEG Recorded Pixels
JPEG Quality
RAW File Format
Color Space
Memory Card Options
Image Capture Settings
3
Shooting
49
You can set the file format for movies
in [Movie Capture Settings] of the
B5 menu.
u Caution
• When [Recorded Pixels] is set to z, [60p] cannot be
selected for [Framerate].
t Memo
• Setting [Wind Noise Reduction] to [On] cuts off the low-pitch
sound. It is recommended to set [Wind Noise Reduction] to
[Off] when it is not necessary.
Select the capture mode that suits the subject and shooting
conditions.
The following capture modes are available on this camera.
Movie Capture Settings
B5
Recorded Pixels z, x
Framerate 60p, 30p, 24p
Recording Sound
Level
Auto, Manual (0 to 40)
Wind Noise Reduction On, Off
Headphone Volume 0 to 40
Recorded Pixels
Framerate
Recording Sound Level
Wind Noise Reduction
Headphone Volume
Custom Image
Memory Card Options
Movie Capture Settings
Taking Still Images
Capture Mode Function Page
R
(Scene Analyze Auto
mode)
Automatically sets the
optimal shooting settings.
p.44
G, H, I, J, K,
L, M, N
(Exposure modes)
Allows you to change the
shutter speed, aperture
value, and ISO
sensitivity.
p.50
O to 5
(User modes)
Allows you to save
frequently used exposure
modes and capture
settings together.
p.100
3
Shooting
50
x: Available #: Restricted
×
: Not available
*1 You can set the value to be changed in [E-Dial Programming] of the
E2 menu. (p.104)
*2 ISO Auto is not available.
*3 You can change the shutter speed in the range of 1 second to 20
minutes for the timed exposure. (p.53)
*4 You can change the flash sync speed in [X Mode Sync Speed] of the
E5 menu.
1 Set the mode dial to the desired exposure mode.
Q, R, or V appears next to
the value on the status screen
and Live View in the following
situations.
• When a fixed value is set and it
can be changed with Q, R,
or V
• When the camera is in the mode to change values after
operations such as pressing a function button
D appears next to the value that
can be changed on the outside-
field-of-view information in the
viewfinder and on the LCD panel.
Exposure Modes
Mode
Changing
Shutter
Speed
Changing
Aperture
Value
Changing
ISO
Sensitivity
EV Com-
pensation
G
Program AE
#
*1
#
*1
xx
H
Sensitivity
Priority AE
#
*1
#
*1
x
*2
x
I
Shutter
Priority AE
x #
*1
xx
J
Aperture
Priority AE
#
*1
xxx
K
Shutter &
Aperture
Priority AE
xx#
*1
x
L
Manual
Exposure
xxx
*2
x
M
Bulb
Exposure
×
*3
xx
*2
×
N
Flash X-sync
Speed
×
*4
xx
*2
x
1 0 : 1 0
10:10
1 /
1/
250
250
1600
1600
F
F
5.6
5.6
SR
0 1 / 0 1 / 2 0 2 1
01/01/2021
9 9 9 9
9999
9 9 9 9
9999
1/250
F 5 . 6
F5.6
16 00
1600
9 9 9 9
9999
9 9 9 9
9999
3
Shooting
51
2 Turn R or Q.
When [E-Dial], [ISO Sensitivity],
or [EV Compensation] is set for
the Smart Function, turn V.
t Memo
• The exposure value can be specified in increments of 1/3 EV
steps. In [EV Steps] of the E5 menu, you can change the
adjustment steps to 1/2 EV steps.
•In L or N mode, the difference from the correct exposure is
displayed on the EV bar scale while the exposure is adjusted.
• For each exposure mode, you can set the camera operation
for when Q or R is turned or M is pressed. Make settings
in [E-Dial Programming] of the E2 menu. (p.104)
• To compensate the exposure automatically by pressing
0 halfway when the correct exposure cannot be
achieved, set [Auto EV Compensation] to [On] in the A2
menu. When you release 0, the exposure returns to the
original value.
• While shooting with Live View in L, N, or M (with the timed
exposure set) mode, the brightness of Live View changes
according to the exposure setting. To not adjust the
brightness according to the exposure setting, set [Exp.
Simulation LV] to [Off] in the D2 menu.
u Caution
• The correct exposure may not be obtained with the selected
shutter speed and aperture value when the ISO sensitivity is
fixed at a certain sensitivity. (If the ISO sensitivity is set to ISO
Auto, the correct exposure may be obtained.)
•In M mode, [Drive Mode] cannot be set to [Continuous
Shooting], [Bracketing], [Interval Shooting], or [Interval
Composite] in the A4 menu. (When the timed exposure is
set, you can select [Interval Shooting] and [Interval
Composite].)
Autofocusing Using the Touch Panel
While shooting with Live View, you can change the AF point
using the touch panel. To perform autofocus and shooting
using the touch panel, make settings in [LV Shooting Touch
AF] of the E3 menu.
AF Point
Sets the AF point to the touched point.
(Default setting)
AF
Point+Focus
Sets the AF point to the touched point
and performs autofocus.
AF
Point+Focus+
Shoot
Sets the AF point to the touched point,
and performs autofocus and shooting.
Off
Does not use the touch panel for
shooting.
3
Shooting
52
When shooting with a slow shutter
speed, you can reduce image noise
in [Slow Shutter Speed NR] of [Noise
Reduction] in the A6 menu.
In [Program Line] of the A2 menu,
you can specify how exposure is
controlled in G, H, K, and L
modes.
Reducing Noise when Shooting with a
Slow Shutter Speed
A6
Auto
Applies noise reduction according to the ISO
sensitivity, shutter speed, and internal temperature of
the camera.
On
Applies noise reduction when the shutter speed is
slower than 1 second.
Off Does not apply noise reduction at any shutter speed.
Setting the Exposure Control Method A2
Auto Determines the appropriate settings.
Standard
Sets to the basic program automatic
exposure (all-around mode).
Hi-speed Priority Prioritizes high shutter speeds.
DOF Priority
(Deep)
Closes the aperture for a deep depth of
field.
DOF Priority
(Shallow)
Opens the aperture for a shallow depth of
field.
MTF Priority
Sets the sharpest aperture of the
attached lens when a D FA, DA, DA L,
FA, or FA J lens is used.
Slow Shutter Speed NR
Auto
On
O
CancelCancel OKOK
Program Line
Auto
Standard
Hi-speed Priority
DOF Priority (Deep)
DOF Priority (Shallow)
MTF Priority
Cancel
Cancel
OK
OK
Hyper Program
You can shift the shutter speed and aperture value while
keeping the correct exposure by changing the shutter speed
or aperture value in G mode. This feature is called “hyper
program”. When the camera enters the hyper program
mode, the exposure mode is temporarily displayed as I or
J mode. Either the shutter speed or the aperture value can
be changed in the hyper program mode.
Press M to return to the normal G mode.
Hyper Manual
In L mode where the ISO sensitivity, shutter speed, and
aperture value can be set freely, the automatic exposure
control is temporarily performed only while M is pressed.
The exposure mode to change when M is pressed can be
set in [E-Dial Programming] of the E2 menu. (p.104)
3
Shooting
53
1 Set the mode dial to M.
2 Use R to set the aperture
value.
3 To enable the timed exposure, press M, and
then turn Q to set the exposure time.
You can set the exposure time within the range from 1" to
20'00".
4 Press 0.
While 0 is pressed, the exposure continues.
If the timed exposure is enabled in Step 3, the exposure
ends when the set exposure time elapses after 0 is
fully pressed.
t Memo
• You can start and end the exposure also by pressing 0.
Make settings in [Bulb (B) Mode Options] of the E5 menu.
•
During the bulb exposure, [Shake Reduction] is fixed to [Off] in
the
A
7 menu.
• When performing the bulb exposure, use a tripod and mount
the camera on it securely. The use of the optional cable
release is recommended.
u Caution
•In M mode, [Drive Mode] cannot be set to [Continuous
Shooting] or [Bracketing] in the A4 menu.
• When the timed exposure is not set, [Drive Mode] cannot be
set to [Interval Shooting] or [Interval Composite] in the A4
menu.
Advanced Mode
When [HYPER P/Sv Options] of [E-Dial Programming] is set
to [Advanced] in the E2 menu, you can use the “advanced
mode” in G or H mode. (p.105) To use the hyper mode in
other exposure modes, assign the hyper mode function to
dials in [E-Dial Programming] of the E2 menu (p.104).
If you change the ISO sensitivity, shutter speed, and
aperture value, the camera enters the hyper mode for each
item in the order in which the value is changed. When all the
ISO sensitivity, shutter speed, and aperture value are
changed, the camera enters the hyper L mode. Press M
to return to the exposure mode set with the mode dial.
Example) In G mode with ISO Auto
• G (Change the aperture value) Hyper J mode
(Change the shutter speed) Hyper K mode
(Change the ISO sensitivity) Hyper L mode
Exposure
Mode
ISO
Sensitivity
Operation
1
Hyper
Mode
Operation
2
Hyper
Mode
Operation
3
Hyper
Mode
G
AUTO
Aperture
value
J
Shutter
speed
K
ISO
sensitivity
L
Shutter
speed
I
Aperture
value
K
ISO
sensitivity
L
Fixed
value
Aperture
value
J
Shutter
speed
L
Shutter
speed
I
Aperture
value
L
H
Fixed
value
Aperture
value
J
Shutter
speed
L
Shutter
speed
I
Aperture
value
L
I
AUTO
Aperture
value
K
ISO
sensitivity
L
Fixed
value
Aperture
value
L
J
AUTO
Shutter
speed
K
ISO
sensitivity
L
Fixed
value
Shutter
speed
L
K AUTO
ISO
sensitivity
L
Bulb Exposure
Bulb
While 0 is pressed, the exposure
continues. (Default setting)
Time
The exposure starts when 0 is pressed
and ends when 0 is pressed again.
Bulb
Bulb
1600
1600
F
F
5.6
5.6
SR
9 9 9 9
9999
9 9 9 9
9999
3
Shooting
54
The compensation value can be set between -5 and +5 EV (-2
and +2 EV in B mode).
1 Press J, and then turn
R.
Available operations
t Memo
• You can make settings so that pressing J resets the
compensation value when the exposure compensation
function is assigned to Q, R, or V. Make settings in [One
Push Exposure Reset] of the E2 menu.
1 Set the A/K/B dial to
B.
Live View appears.
2 Use the mode dial to select an exposure mode.
G, I, J, K, or L mode can be selected.
3 Use Q or R to set the exposure.
4 Focus on the subject.
When the focus method is set to v, press 0
halfway.
5 Press 0 fully.
Movie recording starts.
6 Press 0 fully again.
Movie recording stops.
EV Compensation
J
Starts/ends adjusting the compensation
value.
M
Resets the compensation value to the
default setting.
Recording Movies
0′00″
4 . 0 G B4.0GB
Sound
Recording time
3
Shooting
55
u Caution
• When recording a movie with sound, camera operation
sounds are also recorded.
• When recording a movie with an image processing function
such as [Digital Filter] of the B6 menu applied, the movie file
may be saved with some frames omitted.
• If the internal temperature of the camera becomes high
during recording, recording may be terminated.
•
When a retractable lens is attached, recording stops if the lens
is retracted during recording and an error message is displayed.
t Memo
• When the mode dial is set to other than the modes described
in Step 2, the camera operates in G mode.
• You can set the autofocus operation during movie shooting in
[Movie Mode AF] of [AF with Live View] in the B1 menu.
• When a compatible lens is attached to the camera, [AF Mode]
can be set to [Continuous AF] in [AF with Live View] of the
B1 menu. When [Continuous AF] is set, autofocus is always
performed even while recording a movie.
• To disable the autofocus operation with 0 pressed
halfway in B mode, set [Movie] to [Off] in [AF/AE Lock
Settings] of the E2 menu.
• You can record a movie continuously up to 4 GB or 25
minutes. When the memory card is full, recording stops.
Movie Recording Using the Touch Panel
When recording a movie, you can start and stop recording
and change the following settings using the touch panel.
• ISO sensitivity, shutter speed, aperture value, and
exposure compensation value
•AF point
• Screen display on/off
To perform autofocus while recording a movie, make
settings in [Movie Touch AF] of the E3 menu.
AF Point
Sets the AF point to the touched point.
(Default setting)
AF Point+
Continuous AF
Sets the AF point to the touched point
and continues autofocus when a
compatible lens is attached to the
camera.
AF Point+Sgl.
AF at Start
Sets the AF point to the touched point
and performs autofocus once.
Off
Does not use the touch panel for
recording movies.
3
Shooting
56
u Caution
• Do not connect a microphone or other device outside the
recommended specifications to the microphone terminal or
headphone terminal. Also, do not use an external microphone
with a 3-m or longer cable. Doing so may cause the camera
to malfunction.
• If an external microphone is used when recording a movie
with the wireless LAN function enabled, radio noise may be
recorded depending on the compatibility with the microphone.
1 Display the movie to play
back in the single image
display of the playback
mode.
Available operations
t Memo
• The sound volume at the start of movie playback can be set
in [Playback Sound Volume] of the C1 menu. (p.85)
• You can divide a movie file into multiple segments or delete
selected frames in the C6 menu. (p.96)
Using a Microphone or
Headphones
You can reduce the possibility of
recording camera operation
sounds by connecting a
commercially available stereo
microphone to the microphone
terminal on the camera.
The following specifications are
recommended for external
microphones. (A monaural
microphone cannot be used with
this camera.)
You can record and play back movies while listening to the
sound by connecting commercially available headphones to
the headphone terminal.
Microphone terminal
Headphone terminal
Plug Stereo mini plug (3.5 mm dia.)
Format Stereo electret condenser
Power
Plug-in Power Method (operating
voltage of 2.0 V or lower)
Impedance 2.2 kΩ
Playing Back Movies
A / Tap Plays back/Pauses a movie.
C D Fast-reverses/Fast-forwards
playback.
Reverses/Forwards a frame
(when paused).
B / Double-tap Stops playback.
R
Adjusts the sound volume (41
levels).
H Saves the displayed frame as a
JPEG file (when paused).
G Switches between [Standard
Info. Display] and [No
Information Display].
10:00
10:00
1/1
1/1
00´00˝ / 01’00
00´00˝ / 01’00
01/01/2021
01/01/2021
Manage Image
Manage Image
100-0001
100-0001
3
Shooting
57
1 Press N, and then turn
R.
Available operations
t Memo
•In B mode, the ISO sensitivity can be set from ISO 100 to
ISO 25600.
• The adjustment steps for the ISO sensitivity is 1 EV step. To
adjust the ISO sensitivity in accordance with the EV step
setting for the exposure, make settings in [ISO Sensitivity
Steps] of the E5 menu.
• You can make settings so that pressing N resets the ISO
sensitivity to ISO Auto without displaying the setting screen
when the ISO sensitivity setting function is assigned to Q,
R, or V. Make settings in [One Push ISO Auto] of the E2
menu.
You can set the range in which the
ISO sensitivity is automatically
adjusted when the ISO sensitivity is
set to ISO Auto. Make settings in [ISO
Sensitivity Setting] of the A2 menu.
Setting the Exposure
ISO Sensitivity
N
Starts/ends changing the ISO sensitivity.
M
Resets the ISO sensitivity to ISO Auto.
Setting the Range of ISO Auto A2
ISO Auto Upper
Limit
Sets the ISO sensitivity upper limit for ISO
Auto.
ISO Auto Lower
Limit
Sets the ISO sensitivity lower limit for ISO
Auto.
Min. Shutter
Speed Op.
Sets whether to automatically determine
the lower limit according to the focal length
information of the lens or to manually set
the limit.
ISO Auto with
Min. Speed
Sets the manner in which the ISO
sensitivity is increased when [Min. Shutter
Speed Op.] is set to [Auto].
Minimum
Shutter Speed
Sets the shutter speed in units of 1 EV
when [Min. Shutter Speed Op.] is set to
[Shutter Speed Control].
1/125
100
3200
ISO Sensitivity Setting
ISO Auto Upper Limit
ISO Auto Lower Limit
ISO Auto with Min. Speed
Minimum Shutter Speed
Min. Shutter Speed Op.
3
Shooting
58
You can use the noise reduction feature when shooting with a
high ISO sensitivity.
1 Select [Noise Reduction] in the A6 menu and
press D.
The [Noise Reduction] screen appears.
2 Select [High-ISO Noise Reduction] and press D.
3 Select the noise reduction
level and press E.
Proceed to Step 7 when other than [Custom] is selected.
4 Select [Custom Options] and press D.
5 Select the noise reduction
level for each ISO
sensitivity setting.
Available operations
6 Press E.
The screen of Step 3 reappears.
7 Press F twice.
Reducing Noise when Shooting with a
High ISO Sensitivity
A6
Auto
Applies noise reduction at optimally calculated
levels throughout ISO sensitivity range.
Low,
Medium,
High
Applies noise reduction at constant chosen
level throughout ISO sensitivity range.
Custom
Applies noise reduction at user-defined levels
for each ISO sensitivity setting.
Off
Does not apply noise reduction at any ISO
sensitivity setting.
High-ISO Noise Reduction
Auto
Low
Medium
High
ustom
Off
ncelncel OKOK
AB Selects the ISO sensitivity.
CD Selects the noise reduction level.
M Resets the noise reduction level to the
default setting.
SO 100
SO 200
SO 400
SO 800
SO 1600
SO 3200
-
-
-
-
-
-
High-ISO Noise Reduction
Cancel
Cancel
Reset
Reset
OK
OK
3
Shooting
59
You can choose the part of the sensor to use for measuring
brightness and determining the exposure.
1 Press 2, and then turn
R.
Alternatively, select [AE
Metering] in the A2 or B2
menu.
t Memo
•
To adjust the exposure for detected faces when [Multi-segment]
is selected, set [Face Priority AE] to [On] in the
A
2 menu.
• To adjust the exposure according to the brightness at the AF
point when [Multi-segment] or [Spot] is selected, set [Link AE
and AF Point] to [On] in the A2 menu.
Set the focus method switch to v
or w.
The autofocus method for shooting with the viewfinder differs
from that for shooting with Live View.
AE Metering
A2 / B2
Multi-
segment
Meters the brightness in multiple
different zones of the sensor.
In backlit conditions, this mode
automatically adjusts the exposure.
Center-
weighted
Meters the brightness with an emphasis
on the center of the sensor.
The sensitivity increases at the center
and no automatic adjustment is
performed even in backlit conditions.
Spot
Meters the brightness only within a
limited area at the center of the sensor.
Highlight-
weighted
Meters the exposure in multiple areas of the
frame with emphasis on the bright areas.
1 /1/
250250
1600
FF
5.6
SR
9 9 9 99999
9 9 9 99999
Setting the Focus Method
Shooting with the
viewfinder
Phase-matching detection autofocus:
[Single AF] or [Continuous AF] can be
selected.
Faster autofocus performance than the
contrast detection autofocus is possible.
Shooting with Live
View
Contrast detection autofocus
Focusing on the Subject Using I
You can use I to perform
autofocus.
The 0/I operation can be
set in [AF/AE Lock Settings] of the
E2 menu. (p.104)
3
Shooting
60
You can set the autofocus operation
when shooting with the viewfinder in
[AF with Viewfinder] of the A1 menu.
t Memo
• The [AF Mode] and [AF Active Area] setting can be changed
by pressing b and then turning Q or R. (p.60)
1 Press b, and then turn
Q.
You can select the AF points.
The AF points can be selected from 41 points out of 101 points.
1 Press b, and then turn
R.
Setting the Autofocus when Shooting
with the Viewfinder
A1
AF Mode
Single AF
When 0 is pressed halfway and
the subject comes into focus, the
focus is locked at that position.
The AF assist light turns on as necessary.
Continuous
AF
The subject is kept in focus by
continuous adjustment while 0
is pressed halfway.
The shutter can be released even if
the subject is not in focus.
AF with Viewfinder
AF Mode
AF Active Area
AF Area Restriction
O
AF.S Setting
1st Frame Action in AF.C
Action in AF.C Cont.
1 /
1/
250
250
1600
F
F
5.6
5.6
SR
9 9 9 9
9999
9 9 9 9
9999
AF Active Area (AF Point)
Auto Area
Automatically selects the optimum
focusing points out of all AF points.
Zone Select
Automatically selects the optimum
focusing points out of the selected
21 AF points.
Select
Sets the AF points to the user
selected five points.
Expanded
Area AF (S)
Sets the AF points to the user
selected five points.
When the subject happens to move
out of the selected AF points after
being focused, 16 peripheral points
are used as back-up points for
autofocus.
This setting is available only with
[Continuous AF].
Expanded
Area AF (M)
Sets the AF points to the user
selected five points.
When the subject happens to move
out of the selected AF points after
being focused, 60 peripheral points
are used as back-up points for
autofocus.
This setting is available only with
[Continuous AF].
1 /
1/
250
250
1600
F
F
5.6
5.6
SR
9 9 9 9
9999
9 9 9 9
9999
3
Shooting
61
Proceed to Step 2 when other than [Auto Area] or [Spot] is
selected.
2 Use 6 to select the
desired AF points.
Push the lever in to reset the AF
points.
The selected AF points are
displayed on the status screen.
t Memo
• The selected AF points can be checked also in the viewfinder.
(p.16)
u Caution
• The selectable AF points differ depending on the lens
attached. (p.117)
You can limit the range of AF points.
When [AF Area Restriction] is set to [On], only the inner AF
frame is used.
You can select the camera operation priority for when the
0 is pressed fully while the autofocus mode is set to
[Single AF] from [Focus-priority] and [Release-priority].
You can select the camera operation priority for the first frame
when the 0 is pressed fully while the autofocus mode is
set to [Continuous AF] from [Auto], [Focus-priority], and
[Release-priority].
You can select the camera operation priority for continuous
shooting when the autofocus mode is set to [Continuous AF]
from [Auto], [Focus-priority], and [FPS-priority].
You can set whether to immediately reactivate autofocus or to
maintain the focus for a certain amount of time before
reactivating autofocus when the subject happens to move out of
the selected focusing points while tracking the subject with
[Continuous AF]. The setting can be selected from [Off], [Low],
[Medium], and [High].
You can select whether to adjust focus manually with the lens
or to wait until the camera can perform autofocus when
autofocus fails.
Expanded
Area AF (L)
Sets the AF points to the user
selected five points.
When the subject happens to move
out of the selected AF points after
being focused, 96 peripheral points
are used as back-up points for
autofocus.
This setting is available only with
[Continuous AF].
Select (S)
Performs autofocus with fewer AF
points than those for [Select].
Spot Sets the AF point to the center point.
1 /
1/
250
250
1600
F
F
5.6
5.6
SR
9 9 9 9
9999
9 9 9 9
9999
AF Area Restriction
AF.S Setting
1st Frame Action in AF.C
Action in AF.C Cont.
Hold AF Status
Action When AF Fails
3
Shooting
62
You can set the method for tracking AF points when the
autofocus mode is set to [Continuous AF].
You can make settings so that the recognized subject is
prioritized while autofocusing when [AF Active Area] is set to
[Auto Area] or [Zone Select].
You can perform Catch-in Focus shooting. The shutter is
released automatically when the subject comes into focus.
Use a manual focus lens or a lens with the v/w switch set
to w.
1 Attach a manual focus lens to the camera.
2 Set the focus method to v.
3 Set [Catch-in Focus] to [On] in [AF with
Viewfinder] of the A1 menu.
4 Place the camera on a fixed support such as
tripods.
5 Adjust the focus to the position where the
subject may pass and press 0 fully.
When the subject comes into focus at the specified position,
the shutter is released automatically.
You can set the autofocus operation when shooting with Live
View in [AF with Live View] of the A1 or B1 menu.
t Memo
• The [AF Active Area] setting can be changed by pressing b
and then turning R. (p.63)
AF Point Tracking in AF.C
Type 1
Tracks AF points using AF sensor and AE sensor
information.
Type 2 Tracks AF points using AF sensor information only.
Subject Recognition
Catch-in Focus
Setting the Autofocus when
Shooting with Live View
A1 / B1
AF with Live View
AF Active Area
Focus Peaking
Movie Mode AF
AF with Live View
AF Active Area
Focus Peaking
Contrast AF Options
Face Detection
A1 Menu B1 Menu
3
Shooting
63
You can select the AF active areas.
1 Press b, and then turn
R.
*1 Not available in B mode.
Proceed to Step 2 when other than [Auto Area] or [Spot] is
selected.
2 Use 6 to select the AF
active areas.
Push the lever in to reset the AF
active areas.
AF Active Area
Auto Area
Automatically selects the optimum
focusing area out of all AF active
areas.
Zone Select
Performs autofocus in the selected
3×3 areas.
Tracking
*1
Tracks the subject in focus.
Select (L)
Performs autofocus with more areas
than those for [Select (M)].
Select (M)
Performs autofocus with the
selected areas.
Select (S)
Performs autofocus with fewer areas
than those for [Select (M)].
Spot
Sets the AF active area to the center
area.
1/250 F 5 . 6F5.6 1600
9 9 9 99999
9 9 9 99999
3
Shooting
64
You can set the autofocus operation in B mode. Select
whether to lock focus or continue autofocus.
When [Continuous AF] is selected, autofocus is performed
automatically without pressing 0 halfway. The continuous
autofocus function is available only when a compatible lens is
attached.
When [Highlight Edge] or [Extract Edge] is selected, the outline
and contrast of the subject in focus are emphasized, and this
makes it easier to check the focus. This function works in both
v and w focus methods.
u Caution
• While autofocusing and recording a movie, focus peaking is
not displayed.
• While focus peaking is displayed, the histogram and highlight
alert are not displayed.
You can select the camera operation priority for when the
0 is pressed fully from [Focus-priority] and [Release-
priority].
You can make settings so that the camera detects the faces of
up to ten people and performs autofocus for the detected faces.
You can precisely fine-tune your lenses with the camera’s
autofocus system.
1 Select [AF Fine Adjustment] in the E7 menu and
press D.
The [AF Fine Adjustment] screen appears.
2 Press D.
The adjustment method selection screen appears.
3 Select the adjustment method and press E.
4 Press B and adjust the
value.
Available operations
5 Press F twice.
The camera returns to the standby mode.
Movie Mode AF
Focus Peaking
Contrast AF Options
Face Detection
On
Detects faces when [AF Active Area] is set
to other than [Tracking].
Only in Auto Area
Detects faces only when [AF Active Area]
is set to [Auto Area].
Off
Follows the [Face Detection] setting
without detecting faces.
Fine-tuning the Autofocus
E7
Common
Applies the same adjustment value to all
lenses.
Individual
Saves an adjustment value for the lens being
used. (Up to 20 values can be saved.)
Off Does not fine-tune the autofocus.
D Adjusts the focus to a closer position (toward
the front).
C Adjusts the focus to a farther position
(toward the rear).
M
When [Individual] is selected: Resets the
adjustment value to the default setting.
+5
AF Fine Adjustment
AF Fine Adjustment
Reset
Reset
3
Shooting
65
Turn the main switch to U to use the
preview function.
There are two preview methods.
t Memo
• Press F during Digital Preview to end the preview.
1 Select [Preview Dial] in the E2 menu and press
D.
The [Preview Dial] screen appears.
2 Select [Preview Method]
and press D.
3 Select [Optical Preview] or [Digital Preview], and
press E.
When [Digital Preview] is
selected, the operations and
information displayed during the
preview can be set in [Digital
Preview Settings].
4 Press F two or three times.
The camera returns to the standby mode.
u Caution
• The effects of some functions cannot be checked during
Digital Preview or are not applied to the saved preview image.
Checking the Depth of Field (Preview)
Optical Preview
Activates the Optical Preview function to
check the depth of field with the viewfinder.
Digital Preview
Activates the Digital Preview function to
check the composition, exposure, and
focus on the monitor.
You can magnify or save the preview
image.
Setting the Preview Method E2
Preview Dial
Preview Method
Digital Preview Settings
Digital Preview Settings
Zoom Review
Save Preview Image
Histogram
Highlight Alert
3
Shooting
66
You can use the [Drive] and [Timer/Remote Control] functions
in combination.
1 Press A in the standby mode.
Alternatively, select [Drive Mode] in the A4 menu.
The [Drive Mode] screen
appears.
2 Press D.
The [Drive] screen appears.
Refer to p.73 for [Timer/Remote Control].
3 Use AB to select a drive
mode.
u Caution
• There are restrictions on some drive modes when used in
combination with some other functions. (p.115)
t Memo
• The [Drive] setting is saved even after the power is turned off.
If [Drive] is set to Y (Off) in [Memory] of the E5 menu, the
setting returns to [Single Frame Shooting] when the power is
turned off. (p.111)
Selecting the Drive Mode
A4
Single Frame
Shooting
Performs normal shooting.
Continuous
Shooting (H)
Continuous
Shooting (M)
Continuous
Shooting (L)
Continuously takes images while
0 is kept pressed. (p.67)
Bracketing
Takes consecutive images at
different exposure levels. (p.67)
Depth of Field
Bracketing
Continuously takes images with
different depth-of-field settings
(aperture values). (p.68)
Drive Mode
Drive Mode
Single Frame Shooting
Single Frame Shooting
Cancel
Cancel
OK
OK
Drive
Drive
Single Frame Shooting
Single Frame Shooting
Motion
Bracketing
Continuously takes images with
different shutter speeds. (p.69)
Mirror Lock-up
Shooting
Takes images with the mirror
raised. The mirror is raised when
0 is pressed fully, and an
image is taken when 0 is
pressed fully again. (p.69)
Multi-exposure
Creates a composite image by
taking multiple images and
merging them into a single
image. (p.70)
Interval
Shooting
Takes images at the set interval
and saves them. (p.71)
Interval
Composite
Takes images at the set interval
and merges them into a single
image. (p.72)
3
Shooting
67
1 Select [Continuous
Shooting (H)], [Continuous
Shooting (M)], or
[Continuous Shooting (L)]
on the [Drive] screen.
2 Press E.
The camera returns to the standby mode.
t Memo
• When [AF Mode] is set to [Single AF] in [AF with Viewfinder]
of the A1 menu, the autofocus position is locked at the focus
position of the first image.
• When using the [Self-timer] function together, press G on
the screen of Step 1 and set the number of shots in [No. of
Cont. Timer Shots] (2 to 20).
1 Select [Bracketing] on the [Drive] screen.
2 Set the number of shots
and bracket value.
Available operations
3 Press G.
4 Set the shooting
conditions.
5 Press E.
The camera returns to the standby mode.
6 Shoot.
After images are taken, the camera returns to the standby
mode.
Continuous Shooting
Performs continuous shooting at high speed.
Performs continuous shooting at medium speed.
Performs continuous shooting at low speed.
Cancel
Cancel
OK
OK
Drive
Drive
Continuous Shooting (H)
Continuous Shooting (H)
Bracketing
Q
Sets the number of shots.
R
Changes the bracket value.
J R
Adjusts the exposure compensation value.
M
Resets the compensation value to the
default setting.
Bracketing Order
Changes the shooting order of
images.
One-Push
Bracketing
Takes all images with one release of
the shutter.
x3
x3
±1.0EV
±1.0EV
Drive
Drive
Bracketing
Bracketing
OK
OK
Cancel
Cancel
0−+
Bracketing
Bracketing Order
One-Push Bracketing
On
3
Shooting
68
t Memo
• The bracket value can be set in increments of [1/3 EV Steps]
or [1/2 EV Steps] according to the setting of [EV Steps] in the
E5 menu.
• The number of shots and bracket value can also be changed
on the [Drive Mode] screen.
You can take three images continuously by changing the
aperture value step by step without changing the exposure.
This drive mode can be selected only in J or K mode.
1 Select [Depth of Field Bracketing] on the [Drive]
screen.
2 Set the bracket value.
Available operations
3 Press E.
The camera returns to the standby mode.
4 Shoot.
Three images are taken with one release of the shutter.
The camera returns to the standby mode.
t Memo
• The bracket value can be set in increments of [1/3 EV Steps]
or [1/2 EV Steps] according to the setting of [EV Steps] in the
E5 menu.
u Caution
• [Depth of Field Bracketing] cannot be selected when a lens
with an 9 position is used with the aperture ring set to a
position other than 9.
Depth of Field Bracketing
R Changes the bracket value.
M Resets the bracket value to the default
setting.
Larger bracket
value
Takes an image with a deep depth of
field based on the current aperture value.
Smaller bracket
value
Takes an image with a shallow depth of
field based on the current aperture value.
-1.0STOP
-1.0STOP
Cancel
Cancel
OK
OK
Drive
Drive
Depth of Field Bracketing
Depth of Field Bracketing
3
Shooting
69
You can take three images continuously by changing the shutter
speed step by step without changing the exposure.
This drive mode can be selected only in I or K mode.
1 Select [Motion Bracketing] on the [Drive]
screen.
2 Set the bracket value.
Available operations
3 Press E.
The camera returns to the standby mode.
4 Shoot.
Three images are taken with one release of the shutter.
The camera returns to the standby mode.
t Memo
• The bracket value can be set in increments of [1/3 EV Steps]
or [1/2 EV Steps] according to the setting of [EV Steps] in the
E5 menu.
1 Select [Mirror Lock-up
Shooting] on the [Drive]
screen.
2 Press E.
The camera returns to the standby mode.
3 Press 0 halfway, and then fully.
The mirror pops up and the AE Lock function is activated.
4 Press 0 fully again.
The mirror returns to its original position after the image is
taken.
t Memo
• A beep sound is made during mirror lock-up shooting. You
can also make settings so that a beep sound is not made.
(p.110)
•
During mirror lock-up shooting, [Shake Reduction] is fixed to
[Off] in the
A
7 menu.
• The outside-field-of-view information is not displayed in the
viewfinder during mirror lock-up shooting.
• The mirror automatically returns to its original position if 1
minute elapses after the mirror pops up.
Motion Bracketing
R Changes the bracket value.
M Resets the bracket value to the default
setting.
Larger bracket
value
Takes an image in which the subject
appears to be stationary based on the
current shutter speed.
Smaller bracket
value
Takes an image in which the subject
appears to be moving based on the
current shutter speed.
-1.0STEP
-1.0STEP
Drive
Drive
Motion Bracketing
Motion Bracketing
OK
OK
Cancel
Cancel
Mirror Lock-up Shooting
Drive
Drive
Mirror Lock-up Shooting
Mirror Lock-up Shooting
OK
OK
Cancel
Cancel
3
Shooting
70
1 Select [Multi-exposure] on
the [Drive] screen and
press G.
2 Set the shooting
conditions.
3 Press F.
The screen of Step 1 reappears.
4 Press E.
The camera returns to the standby mode.
5 Press 0.
The Instant Review image is displayed.
6 To take the next image, select [Next shot], and
then press E.
Select [Retake shot] to retake the image.
Select [Complete] to end shooting.
u Caution
• [Continuous Shooting] is not available in M mode.
Multi-exposure
Composite
Mode
[Average]: Creates a composite image
with the average exposure.
[Additive]: Creates a composite image with
the cumulatively added exposure.
[Bright]: Compares the captured image with
the previous image pixel by pixel, and creates
a composite image by replacing only the
brightest pixel between the images.
Save Interim
Images
Sets whether to save images in the middle
of processing.
Continuous
Shooting
Sets whether to perform continuous
shooting.
No. of Cont.
Timer Shots
Sets the number of images taken
continuously after the countdown for
shooting with [Self-timer].
The number of images can be selected
from 2 to 20.
Save Interim Images
Save Interim Images
Composite Mode
Composite Mode
Average
Average
Multi-exposure
Multi-exposure
Drive
Drive
Cancel
Cancel
OK
OK
20
Multi-exposure
Composite Mode
Save Interim Images
Continuous Shooting
No. of Cont. Timer Shots
Average
3
Shooting
71
1 Select [Interval Shooting]
on the [Drive] screen and
press G.
2 Set the shooting
conditions.
3 Press F.
The screen of Step 1 reappears.
4 Press E.
The camera returns to the standby mode.
5 Press 0.
When [Start Interval] is set to [Now], the first image is taken.
When [Start Interval] is set to [Set Time], shooting starts at
the set time.
Press E to cancel shooting.
After the specified number of images are taken, the camera
returns to the standby mode.
t Memo
• For each interval shooting, a new folder is created and the
images are saved there.
• The second and later exposures start at the interval set in
[Interval]. When the shutter speed is longer than the interval
set in [Interval], the shooting result varies depending on the
[Fixed Time Release] setting.
• When [Fixed Time Release] is set to [On], [Minimum] is not
available for [Interval]. If [Interval] is set to [Minimum], the
setting changes to [1sec.].
• The time set by [Minimum] in [Interval] varies depending on
the combination with the A menu functions.
Interval Shooting
Interval
Sets the shooting interval. The interval
can be selected from [Minimum] and 1
second to 24 hours.
Number of
Shots
Sets the number of images to take. The
number can be selected from [∞] and 2 to
9999.
Start Interval Sets the timing to take the first image.
Start Time
Sets the shooting start time for when
[Start Interval] is set to [Set Time].
Fixed Time
Release
Sets whether to take images at the
interval set in [Interval] regardless of the
shutter speed.
AF Operation
per Shot
Sets whether to lock the focus position
used when the first image is taken or
perform autofocus each time an image is
taken.
2
2
00:00
00:00
Interval Shooting
Interval Shooting
Interval
Interval
Number of Shots
Number of Shots
Start Interval
Start Interval
Start Time
Start Time
Now
Now
Minimum
Minimum
Drive
Drive
Cancel
Cancel
OK
OK
00:00´01˝
2
00:00
Interval Shooting
Interval
Number of Shots
Start Interval
Now
Start Time
Fixed Time Release
O
AF Operation per Shot
On
Fixed Time
Release
When the Shutter Speed Is Longer than the
Interval Set in [Interval]
On
Some shutter releases are skipped.
Example) When [Interval] is set to 2 seconds,
and the shutter speed is set to 3 seconds:
The first exposure has not yet finished at the
time the second exposure is supposed to be
started (2 seconds after shooting has
started), and so the second image is not
taken. (Shooting ends before the images
specified in [Number of Shots] are taken.)
Off
No shutter releases are skipped.
Example) When [Interval] is set to 2 seconds,
and the shutter speed is set to 3 seconds:
The second exposure does not start even 2
seconds after shooting has started, and
starts after the first exposure finishes.
(Shooting ends after the images specified in
[Number of Shots] are taken.)
3
Shooting
72
1 Select [Interval Composite]
on the [Drive] screen and
press G.
2 Set the shooting
conditions.
3 Press F.
The screen of Step 1 reappears.
4 Press E.
The camera returns to the standby mode.
5 Press 0.
When [Start Interval] is set to [Now], the first image is taken.
When [Start Interval] is set to [Set Time], shooting starts at
the set time.
Press E to cancel shooting.
After the specified number of images are taken, the camera
returns to the standby mode.
t Memo
• When [Save Interim Images] is set to [Unblended] or
[Blended], a new folder is created and the images are saved
there for each interval shooting.
• The second and later exposures start at the interval set in
[Interval]. When the shutter speed is longer than the interval
set in [Interval], the shooting result varies depending on the
[Fixed Time Release] setting.
• When [Fixed Time Release] is set to [On], [Minimum] is not
available for [Interval]. If [Interval] is set to [Minimum], the
setting changes to [1sec.].
• The time set by [Minimum] in [Interval] varies depending on
the combination with the A menu functions.
•
Set the camera on a fixed support such as tripods during
shooting.
Interval Composite
Interval
Sets the shooting interval. The interval
can be selected from [Minimum] and 1
second to 24 hours.
Number of
Shots
Sets the number of images to take. The number
can be selected from [∞] and 2 to 9999.
Start Interval Sets the timing to take the first image.
Start Time
Sets the shooting start time for when [Start
Interval] is set to [Set Time].
Composite
Mode
Sets the composite mode. The mode can
be selected from [Average], [Additive],
and [Bright].
Save Interim
Images
Sets whether to save images in the middle
of processing.
Fixed Time
Release
Sets whether to take images at the interval set
in [Interval] regardless of the shutter speed.
AF Operation
per Shot
Sets whether to lock the focus position used
when the first image is taken or perform
autofocus each time an image is taken.
2
2
00:00
00:00
Now
Now
Minimum
Minimum
Interval Composite
Interval Composite
Interval
Interval
Number of Shots
Number of Shots
Start Interval
Start Interval
Start Time
Start Time
Drive
Drive
Cancel
Cancel
OK
OK
2
00:00
00:00´01˝
Interval Composite
Interval
Number of Shots
Start Interval
Now
Start Time
Composite Mode
Average
Save Interim Images
Fixed Time
Release
When the Shutter Speed Is Longer than the
Interval Set in [Interval]
On
Some shutter releases are skipped.
Example) When [Interval] is set to 2 seconds,
and the shutter speed is set to 3 seconds:
The first exposure has not yet finished at the
time the second exposure is supposed to be
started (2 seconds after shooting has
started), and so the second image is not
taken. (Shooting ends before the images
specified in [Number of Shots] are taken.)
Off
No shutter releases are skipped.
Example) When [Interval] is set to 2 seconds,
and the shutter speed is set to 3 seconds:
The second exposure does not start even 2
seconds after shooting has started, and
starts after the first exposure finishes.
(Shooting ends after the images specified in
[Number of Shots] are taken.)
3
Shooting
73
1 Select [Timer/Remote Control] on the [Drive
Mode] screen and press D.
2 Use AB to select a
setting.
3 Press E.
The camera returns to the standby mode.
4 Press 0 halfway, and then fully.
The shutter is released after about 12 seconds or 2
seconds.
t Memo
• The self-timer lamp blinks during the countdown for self-timer
shooting. You can also make settings so that the lamp does
not blink. (p.110)
• A beep sound is made during the countdown for self-timer
shooting. You can also make settings so that a beep sound is
not made. (p.110)
• During self-timer shooting, [Shake Reduction] of the A7
menu is automatically turned off. If you do not want to turn off
the [Shake Reduction] function, make settings in [Auto Shake
Reduction Off] of the A7 menu.
1 Select [Timer/Remote Control] on the [Drive
Mode] screen and press D.
2 Use AB to select a
setting.
3 Press 0 halfway.
4 Point the remote control unit towards the remote
control receiver of the camera, and press the
shutter release button on the remote control
unit.
Self-timer
Performs self-timer shooting. (The shutter is
released after about 12 seconds.)
Performs self-timer shooting. (The shutter is
released after about 2 seconds.)
Timer/Remote Control
Timer/Remote Control
Cancel
Cancel
OK
OK
Self-timer (12 sec.)
Self-timer (12 sec.)
If Light Enters through the Viewfinder
When [Self-timer] or [Remote
Control] is used, exposure may be
affected by the light entering
through the viewfinder. In such a
case, use the AE Lock function or
attach the optional ME viewfinder
cap. Remove the eyecup before
attaching the ME viewfinder cap.
Remote Control
Performs shooting with the remote control unit.
(The shutter is released immediately.)
Performs shooting with the remote control unit.
(The shutter is released after about 3 seconds.)
Remote Control (0 sec.)
Remote Control (0 sec.)
Timer/Remote Control
Timer/Remote Control
Cancel
Cancel
OK
OK
3
Shooting
74
t Memo
•For B mode, make settings in [Remote Control] of the B4
menu.
• When shooting with the remote control unit is enabled, the
lamp of the camera remote control receiver blinks. You can
also make settings so that the lamp does not blink. (p.110)
• The eye sensor is disabled while [Remote Control] is
selected.
• During shooting with the remote control unit, [Shake
Reduction] of the A7 and B7 menus is automatically turned
off. If you do not want to turn off the [Shake Reduction]
function, make settings in [Auto Shake Reduction Off] of the
A7 and B7 menus.
• The maximum operating distance of the remote control unit is
about 4 m from the front of the camera, and about 2 m from
the back of the camera.
• To adjust focus while shooting with the remote control unit,
set [AF with Remote Control] to [On] in the E6 menu.
• When using the Remote Control Waterproof O-RC1, the
autofocus system can be operated with the q button on the
remote control unit. The r button cannot be used.
• The [Timer/Remote Control] setting is saved even after the
power is turned off. If [Timer/Remote Control] is set to Y (Off)
in [Memory] of the E5 menu, the setting returns to [Off] when
the power is turned off. (p.111)
1 Press C in the standby mode.
Alternatively, select [White Balance] in the A3 or B3
menu.
The [White Balance] screen appears.
2 Use AB to select a white
balance setting.
Setting the White
Balance
A3 / B3
Auto White Balance
Multi Auto White Balance
*1
Daylight
Shade
Cloudy
Fl. - Daylight Color
Fl. - Daylight White
Fl. - Cool White
Fl. - Warm White
Tungsten
Color Temperature Enhancement
Cancel
Cancel
Auto White Balance
Auto White Balance
White Balance
White Balance
OK
OK
3
Shooting
75
*1 Not available in B mode.
Available operations when shooting with the
viewfinder
Proceed to Step 5 if you do not need to fine-tune the white
balance.
3 Press G.
The fine-tuning screen appears.
Available operations
4 Press E.
The screen of Step 2 reappears.
5 Press E.
The camera returns to the standby mode.
u Caution
•In R mode, the white balance setting is fixed to [Auto
White Balance].
t Memo
• When [Multi Auto White Balance] is set, even if various light
sources are present at the shooting location, the camera
automatically adjusts the white balance according to the light
source of each area.
• The settings for the white balance can be made in the A3
menu.
• You can also correct the white balance after shooting. (p.95)
Manual White Balance 1 to 3
Color Temperature 1 to 3
Main switch to U Uses Digital Preview to preview
the background image with the
selected setting applied.
H
Saves the preview image (only
when the image can be saved).
AB
Adjusts the Green-Magenta balance.
CD
Adjusts the Blue-Amber balance.
M
Resets the adjustment value to the default
setting.
G1:A1
G1:A1
Daylight
Daylight
OK
OK
Cancel
Cancel
Auto Adjust. for Source
On, Off
AWB in Tungsten Light High, Low
3
Shooting
76
You can measure the white balance at a selected location.
1 Select o1 to o3 in Step
2 of “Setting the White
Balance” (p.74).
When the image for measuring is
displayed, proceed to Step 3.
2 Under the light you wish to measure the white
balance of, select a white area as the subject,
and set the main switch to U.
The captured image is displayed.
3 Press O.
The measuring area selection screen appears.
4 Use ABCD to specify the
measuring area.
5 Press E.
The white balance setting screen reappears.
The message [Data process failed.] appears when
measuring is unsuccessful. Press E to remeasure the
white balance.
t Memo
• You can copy the white balance settings of a captured image
and save them as o1 to o3 in [Save as Manual WB] of the
C7 menu.
You can specify the white balance with the color temperature.
1 Select p1 to p3 in Step 2 of “Setting the White
Balance” (p.74).
2 Press G.
3 Adjust the color
temperature.
Set the color temperature value
within the range from 2,500 to
10,000 K (Kelvin).
Available operations
4 Press E.
The white balance setting screen reappears.
t Memo
• Set [Color Temperature Steps] to [Mired] in the E6 menu to
set the color temperature in mired units. The color
temperature can be changed in 20 mired units with Q, and
100 mired units with R. However, figures are converted to
and displayed in Kelvin.
Adjusting the White Balance Manually
Manual White Balance
Manual White Balance
OK
OK
Cancel
Cancel
White Balance
White Balance
Cancel
Cancel
Manual White Balance
Manual White Balance
OK
OK
Adjusting the White Balance with Color
Temperature
Q
Changes the color temperature in
increments of 10 K.
V
Changes the color temperature in
increments of 100 K.
R
Changes the color temperature in
increments of 500 K.
ABCD Fine-tunes the color temperature.
0:0
0:0
10000K
10000K
500K
500K
100K
100K
10K
10K
Color Temperature
Color Temperature
Cancel
Cancel
OK
OK
3
Shooting
77
When an external flash (optional) is connected to the camera,
you can discharge a flash for shooting.
Remove the hot shoe cover from the
camera, and attach an external flash.
t Memo
• Refer to “Functions when Using an External Flash” (p.119) for
details on the functions of external flashes.
1 Select [Flash Mode] in the A2 menu and press
D.
The [Flash Mode] screen appears.
2 Select a flash mode.
Available operations
3 Press E.
4 Press F.
The camera returns to the standby mode.
t Memo
• The flash modes that can be selected vary depending on the
capture mode.
• When the flash is used in J mode, the shutter speed
automatically changes over a range from 1/200 seconds to a
slow shutter speed depending on the lens being used. The
shutter speed is locked at 1/200 seconds when a lens other
than a D FA, DA, DA L, FA, FA J, or F lens is used.
• When the flash is used in I, K, or L mode, any desired
shutter speed of 1/200 seconds or slower can be set.
Using a Flash
Connecting a Flash
Setting the Flash Mode
A2
Auto Flash
Discharge
Automatically measures the
ambient light and determines
whether to use the flash.
Auto Flash+
Red-eye
Discharges a pre-flash for red-eye
reduction before an automatic
flash.
0.0EV
0.0EV
Cancel
Cancel
Flash On
Flash On
Flash Mode
Flash Mode
OK
OK
Flash On
Discharges a flash for each
image.
Flash On+
Red-eye
Discharges a pre-flash for red-eye
reduction before the main flash for
each image.
Slow-speed
Sync
Sets to a slow shutter speed and
discharges a flash for each
image.
Use this, for example, when
shooting a portrait with the sunset
in the background.
Slow Sync+
Red-eye
Discharges a pre-flash for red-eye
reduction before the main flash is
discharged with a slow shutter
speed.
R Compensates the flash exposure (-2.0 to
+1.0).
M Resets the compensation value to the
default setting.
3
Shooting
78
1 Press D in the standby mode.
Alternatively, select [Custom Image] in the A6 or B6
menu.
The [Custom Image] screen appears.
2 Use AB to select an
image finishing tone.
Available operations when shooting with the
viewfinder
Proceed to Step 6 when [Auto Select] is selected or if you
do not need to change the parameters.
3 Press G.
The parameter setting screen appears.
4 Set the parameters.
Available operations
5 Press E.
The screen of Step 2 reappears.
The adjustment values for parameters are displayed.
6 Press E.
The camera returns to the standby mode.
u Caution
•In R mode, the image finishing tone is fixed to [Auto
Select].
Controlling the Image Finishing
Tone
Custom Image
A6 / B6
Auto Select
Bright
Natural
Portrait
Landscape
Vibrant
Radiant
Muted
Flat
Bleach Bypass
Reversal Film
Monotone
Cross Processing
Main switch to U Uses Digital Preview to preview
the background image with the
selected setting applied.
H
Saves the preview image (only
when the image can be saved).
0
0
0
0
0
0
+1
+1
0
0
0
+1
Custom Image
Custom Image
Bright
Bright
Cancel
Cancel
OK
OK
AB
Selects a parameter.
CD
Adjusts the value.
R
Switches between [Sharpness] and [Fine
Sharpness].
M
Resets the adjustment value to the default
setting.
0
0
0
0
0
0
+1
0
0
0
0
+1
Bright
Bright
Saturation
Saturation
Cancel
Cancel
OK
OK
3
Shooting
79
The outcome of the random processing function of Cross
Processing varies each time an image is taken. If a cross
processed image that you like is taken, you can save the Cross
Processing settings used in the image so that you can
repeatedly use the same settings.
1 Select [Save Cross Processing] in the C7 menu
and press E.
The camera searches for cross processed images starting
from the most recent image taken.
The message [No image can be processed.] appears if
there are no cross processed images.
2 Use Q to select a cross
processed image.
3 Use AB to select the save destination from [F1]
to [F3], and press E.
The settings of the selected image are saved.
t Memo
• The saved Cross Processing settings can be loaded by
selecting [Cross Processing] in Step 2 of “Custom Image”
(p.78), and selecting one of the saved settings [F1] to [F3] for
the parameter.
1 Select [Digital Filter] in the A6 or B6 menu and
press D.
The [Digital Filter] screen appears.
2 Use AB to select a filter.
Select [Off] to not shoot with a
digital filter.
*1 Not available in B mode.
Available operations when shooting with the
viewfinder
Proceed to Step 6 if you do not need to change the
parameters.
3 Press G.
The parameter setting screen appears.
Saving the Cross Processing Settings of a
Captured Image
C7
Save Cross Processing
Save Cross Processing
Cancel
Cancel
OK
OK
Digital Filter
A6 / B6
Extract Color
Replace Color
Toy Camera
*1
Retro
High Contrast
Shading
*1
Invert Color
Unicolor Bold
Tone Expansion
*1
Bold Monochrome
Grainy Monochrome
*1
Main switch to U Uses Digital Preview to preview
the background image with the
selected effect applied.
H
Saves the preview image (only
when the image can be saved).
Digital Filter
Digital Filter
Extract Color
Extract Color
Cancel
Cancel
OK
OK
3
Shooting
80
4 Set the parameters.
Available operations
5 Press E.
The screen of Step 2 reappears.
6 Press E.
7 Press F.
The camera returns to the standby mode.
u Caution
• This function cannot be used in combination with some other
functions. (p.115)
• Depending on the filter used, it may take longer to save
images.
t Memo
• You can also process images with digital filters after shooting.
(p.91)
You can reduce the occurrence of
overexposed/underexposed areas by
expanding the dynamic range and
enabling a wider range of tones to be
recorded by the CMOS sensor.
Make settings in [D-Range
Correction] of the A6 or B6 menu.
u Caution
• When the ISO sensitivity is set to less than ISO 200,
[Highlight Correction] cannot be set to [On].
t Memo
•In B mode, [Highlight Correction] can be set to [Auto] or
[Off].
AB
Selects a parameter.
CD
Adjusts the value.
R
3
--
3
0
Extract Color
Extract Color
Extracted Color 1
Extracted Color 1
Cancel
Cancel
OK
OK
Correcting Images
Adjusting the Brightness
Highlight Correction and Shadow
Correction
A6 / B6
D-Range Correction
Highlight Correction
Shadow Correction
3
Shooting
81
You can take an image having wide dynamic range even in a
scene where the dynamic range becomes narrow by taking
three consecutive images at three different exposure levels and
compositing them.
1 Select [HDR Capture] in the A4 menu and press
D.
The [HDR Capture] screen appears.
2 Select a capture type in
[HDR Capture], and press
E.
3 Set the range in which to change the exposure in
[Bracket Value].
Select a range from [±1.0EV], [±2.0EV], and [±3.0EV].
4 Set whether to use [Auto Align] or not.
5 Press F twice.
The camera returns to the standby mode.
u Caution
• [HDR Capture] cannot be used in the following situations.
•In M or N mode
•In B mode
• This function cannot be used in combination with some other
functions. (p.115)
• When [Drive Mode] is set to [Interval Shooting] in the A4
menu, [Auto Align] is fixed to [Off].
• When [Auto Align] is set to [Off], [Shake Reduction] of the
A7 menu is fixed to [Off].
• For HDR Capture, multiple images are combined together to
create a single image, so it may take time to save the image.
The following corrections can be
made in [Lens Correction] of the A6
menu.
t Memo
• Corrections can only be made when a compatible lens is
attached. (p.116) The corrections are disabled when using an
accessory such as rear converters that is attached between
the camera and the lens.
• When [File Format] is set to [RAW] or [RAW+JPEG] in the
A5 menu, correction information is saved as a RAW file
parameter and you can select [On] or [Off] for applying the
correction to the images when developing them with [RAW
Development] of the C4 menu. When developing RAW
images with [RAW Development], [Color Fringe Correction] is
also available. (p.92)
HDR Capture A4
±2.0EV
HDR Capture
HDR Capture
Auto Align On
Bracket Value
Adjusting the Lens Properties
A6
Distortion
Correction
Reduces distortions occurring due to lens
properties.
Peripheral
Illumin. Corr.
Reduces peripheral light fall-off occurring
due to lens properties.
Lat-Chromatic-
Ab Adj
Reduces lateral chromatic aberrations
occurring due to lens properties.
Diffraction
Correction
Corrects blur caused by diffraction when
using a small aperture.
Lens Correction
Distortion Correction
Peripheral Illumin. Corr.
Lat-Chromatic-Ab Adj
Diraction Correction
3
Shooting
82
Pixel Shift Resolution is the function that enables outputting a high-
definition image of a stationary object by merging four images.
Make settings in [Pixel Shift
Resolution] of the A4 menu.
When shooting is performed, captured four images are
displayed in turn, and then they are merged into a single image.
t Memo
• The use of Pixel Shift Resolution function in combination with
[Mirror Lock-up Shooting], [Self-timer], or [Remote Control] of
[Drive Mode] in the A4 menu is recommended.
•
While the Pixel Shift Resolution function is used, [Shake
Reduction] is fixed to [Off] in the
A
7 menu.
u Caution
• The Pixel Shift Resolution function cannot be used in the
following situations.
•In M or N mode
•In B mode
• This function cannot be used in combination with some other
functions. (p.115)
• While the Pixel Shift Resolution function is used, [AA Filter
Simulator] is fixed to [Off] in the A4 menu.
• When shooting with [Pixel Shift Resolution], use a tripod and
mount the camera on it securely.
By shaking the Shake Reduction unit, a moiré reduction effect
simulating that of a low-pass filter can be achieved.
1 Select [AA Filter Simulator] in the A4 menu and
press D.
2 Select a capture type and
press E.
u Caution
• This function cannot be used in combination with some other
functions. (p.115)
• [Bracketing (Off, High)] and [Bracketing (Off, Lo, Hi)] cannot
be selected in the following situations.
•In M mode
• When [Drive Mode] is set to other than [Single Frame
Shooting] in the A4 menu
• While [HDR Capture] or [Pixel Shift Resolution] of the A4
menu is used
• When the shutter speed is faster than 1/1000 seconds, the full
effect of this function cannot be achieved.
Adjusting the Image Quality Level and
Texture
Shooting High-Definition Images A4
Tripod (Motion
Corr. On)
Reduces mosaic-pattern noise when a
moving object is detected.
Tripod (Motion
Corr. Off)
Does not detect moving objects.
Off Does not use Pixel Shift Resolution.
9999999999 9999999999
Pixel Shift Resolution
Securely mount the camera on a tripod
and then shoot a still subject. Correction
is applied when the subject moves.
Tripod (Motion Corr. On)
Tripod (Motion orr. Off)
Off
CancelCancel OKOK
Reducing Moiré A4
Low
Takes images while balancing the
resolution and moiré reduction.
High Prioritizes the moiré reduction.
Bracketing
(Off, High)
Takes consecutive two images in order of
[Off] and [High].
Bracketing
(Off, Lo, Hi)
Takes consecutive three images in order
of [Off], [Low], and [High].
High
Low
Bracketing (O, High)
Bracketing (O, Lo, Hi)
O
AA Filter Simulator
CancelCancel OKOK
3
Shooting
83
The texture and surface details of an
image can be adjusted in the range of
-4 to +4.
Make settings in [Clarity] of the A6
menu.
The skin tone of portraits can be
enhanced.
Make settings in [Skin Tone] of the
A6 menu.
By using the built-in Shake Reduction unit of the camera,
blurring of images can be reduced.
Press 5 or use [Shake Reduction]
of the A7 menu to turn on and off
this function.
In B mode, select [On] or [Off].
t Memo
•
[Shake Reduction] is fixed to [Off] in the following situations.
•In M mode
• When [Drive Mode] is set to [Mirror Lock-up Shooting],
[Self-timer], or [Remote Control] in the A4 menu
• While [Pixel Shift Resolution] of the A4 menu is used
• To not turn [Shake Reduction] off while [Self-timer] or
[Remote Control] of [Drive Mode] in the A4 menu is used,
set [Auto Shake Reduction Off] to [Disable Auto SR Off] in the
A7 or B7 menu.
• You can set the camera operation when 5 is pressed in
[Shake Reduction] of [Fx Button] in the E2 menu. (p.103)
u Caution
• The operating noise of the Shake Reduction unit may be
recorded during movie recording.
Adjusting the Texture A6
Enhancing the Skin Tone A6
Type 1
Determines the skin tone of the subject by the Face
Detection function, and creates a natural-looking skin
tone. (The skin tone is enhanced only when a face is
detected.)
Type 2
Softens the entire image, and makes skin
irregularities less noticeable.
Clarity
CancelCancel OKOK
Skin Tone
Adjusts the hue and lightness of
the skin based on the detected face.
Type 1
Type 2
Off
CancelCancel OKOK
Reducing Blurring of Images
A7 / B7
Auto
Automatically switches between the normal Shake
Reduction function and the Shake Reduction
function specialized for panning.
Panning
Turns on the Shake Reduction function specialized
for panning a slowly moving subject.
Off Turns off the Shake Reduction function.
Shake Reduction
Applies Shake Reduction to match
camera conditions.
Auto
Pnning
Off
CancelCancel OKOK
3
Shooting
84
The horizontal camera angle
detected by the electronic level can
be corrected. Make settings in [Auto
Horizon Correction] of the A7 menu.
By using the Shake Reduction mechanism, the composition of
the image can be fine-tuned. Use this function when you want
to adjust the composition, such as when using a tripod while
shooting with Live View.
1 Set [Composition Adjustment] to [On] in the A7
menu.
2 Press F.
The camera returns to the standby mode.
3 Set the A/K/B dial to K.
The [Composition Adjustment] screen appears.
4 Adjust the composition.
The adjustment values are
displayed at the top right of the
screen.
Available operations
5 Press E.
The camera returns to the standby mode with Live View.
u Caution
• [Composition Adjustment] cannot be used while
[ASTROTRACER] of the A4 menu is used.
t Memo
• The adjusted composition is saved even if Live View is ended
or the camera is turned off. To reset the saved adjustment
value when the camera is turned off, set [Composition
Adjustment] to Y (Off) in [Memory] of the E5 menu. (p.111)
• If [Composition Adjustment] is registered in [Fx Button] in the
E2 menu, you can start the composition adjustment by
pressing the button. (p.102)
Correcting the Skew of Images
A7
Fine-tuning the Composition
A7
ABCD
Moves the composition of the image (up
to 24 steps).
R
Corrects the tilt of the composition (up to 8
steps). (The tilt is not corrected when the
amount of adjustment steps is 17 or more.)
M
Resets the adjustment value to the
default setting.
Auto Horizon Correction
Ensures the camera shoots at a level
position by rotating the sensor according
to tilt detected by the electronic level.
On
Off
CancelCancel OKOK
0
0
0
0
0
0
Composition Adjustment
Composition Adjustment
Reset
Reset
Cancel
Cancel
OK
OK
4
Playback
85
You can select the playback functions from the C menus (p.27)
or on the “playback function selection screen”.
Press H in the playback mode to
display the playback function
selection screen. The functions of the
C2 to C7 menus can be selected
on the playback function selection
screen.
u Caution
• The playback functions that are not supported by the
displayed image cannot be used.
t Memo
• Even if a playback function is executed for an image, the
shooting date of the image is not changed.
You can set the basic operation in the playback mode in the
C1 menu.
The following settings can be made.
t Memo
• The playback function is executed for the memory card in the
slot selected in [Select Playback Card].
You can display 20, 48, or 70 thumbnail images at the same
time.
1 Turn R to the left in the playback mode.
The multi-image display screen
appears.
Available operations
2 Press E.
The selected image appears in the single image display.
Using the Playback Functions
Setting the Operation in the Playback
Mode
C1
Select Playback Card SD1, SD2
Auto Image Rotation On, Off
Playback Order Options File No., Shooting Date/Time
Playback Sound Volume 0 to 40
Touch Img. Browse Effect On, Off
OK
OK
File Management
File Management
Delete
Delete
Cancel
Cancel
Changing the Playback Method
Displaying Multiple Images
ABCD
Moves the selection frame.
Q
Shows the next/previous page.
G
Changes the number of thumbnail
images displayed on a page.
M
Switches between the SD1 card and the
SD2 card.
H
Displays the playback function selection
screen.
L
Deletes multiple images.
19/999919/99991/4001/400 F5.6F5.6 EV+0.7EV+0.764006400
10:00
10:00
100-0019100-0019
01/01/202101/01/2021
4
Playback
86
When multiple images are displayed, you can select images
and execute the playback functions for them.
1 Press F or H in Step 1 of “Displaying
Multiple Images” (p.85).
The C menu or playback function selection screen is
displayed.
2 Use AB to select a
function, and press E.
3 Select images to execute
the function for.
Available operations
4 Press G.
The confirmation screen appears.
5 Select [Execute] and press E.
t Memo
• You can execute the function for the images selected
individually along with the images selected by specifying the
range.
• Refer to the following pages for details on each function.
• Delete (p.88)
• Protect (p.89)
• Image Copy (p.90)
• File Transfer (p.90)
• RAW Development (p.92)
• When a function that cannot be executed for multiple images
is selected in Step 2, the selected function is applied to the
image with the selection frame.
• When [File Transfer] is selected in
Step 2, you can select [Transfer
Reservation] or [Cancel
Reservation]. Select [Transfer
Reservation] to select the format of
transferred files and make a
transfer reservation. Select [Cancel
Reservation] to cancel the transfer reservation for all images.
Selecting Multiple Images
ABCD
Moves the selection frame.
E
Confirms/cancels the selection of the
image.
J
Specifies the start and end points for
image selection range.
R
Shows the selected image in the single
image display.
Use Q to show a different image.
CancelCancel OKOK
File ManagementFile Management
DeleteDelete
10:00
10:00 100-0019100-0019
ExecuteExecute
01/01/202101/01/2021
File Transfer
CancelCancel OKOK
Cancel ReservationCancel Reservation
Transfer ReservationTransfer Reservation
4
Playback
87
You can display images by folder where the images are saved
or by shooting date, and execute a playback function for them.
Whether the images are displayed by folder or by shooting date
depends on the [Playback Order Options] setting in the
C
1 menu.
1 Turn R to the left in Step 1 of “Displaying
Multiple Images” (p.85).
The folder display screen or
shooting date display screen
appears.
Available operations
2 Press E.
The images in the selected folder or on the selected
shooting date are displayed.
t Memo
•
When the playback function selection screen is displayed in Step 1,
a function can be executed for all images in the selected folder or on
the selected shooting date. If a function that cannot be executed for
multiple images is selected, an error message is displayed.
You can connect the camera to an AV device, such as a TV,
equipped with an HDMI
®
terminal to display Live View images
while shooting or to display images in the single image display
in the playback mode.
Make sure to have a commercially available HDMI
®
cable
equipped with an HDMI
®
terminal (Type D).
1 Turn the AV device and camera off.
2 Open the terminal cover of the camera, and
connect the cable to the HDMI
®
terminal.
3 Connect the other end of the cable to the input
terminal on the AV device.
4 Turn the AV device and camera on.
The camera turns on in the video output mode, and the
camera information is displayed on the screen of the
connected AV device.
u Caution
• While the camera is connected to an AV device, nothing is
displayed on the camera monitor. Also, you cannot adjust the
sound volume on the camera. Operate the camera while
viewing the monitor of the AV device.
Displaying Images by Folder or Shooting
Date
ABCD
Moves the selection frame.
R to the
right
Displays the multi-image display screen.
M
Switches between the SD1 card and the SD2 card.
H
Displays the playback function selection screen.
L
Deletes the images by the selected
folder or by the selected shooting date.
100 103102101
108
111110109
104
107106105
9999
100-0012100-0012
9999
01/01 01/02 01/03 01/04
01/08
01/12
01/05 01/06 01/07
01/09 01/10 01/11
02/02/202102/02/2021
Connecting the Camera to an AV Device
4
Playback
88
t Memo
• Check the operating manual of the AV device and select a
suitable input terminal for connecting the camera.
• If you intend to use the camera continuously for a long period,
the use of the optional AC adapter kit is recommended. (p.41)
1 Select [Delete] in the C2 menu or on the
playback function selection screen.
2 Select [Delete 1 Image] or [Delete All Images].
For images captured with [File
Format] set to [RAW+JPEG],
select the file format to delete.
When [Delete All Images] is
selected, proceed to Step 4.
3 Use Q to select an image.
4 Press E.
When [Delete All Images] is selected, the confirmation
screen appears. Proceed to Step 5.
5 Select [Execute] and press E.
Organizing Files
Deleting Images
C2
100-0001
10:00
10:00
01/01/2021
01/01/2021
OK
OK
Delete All Images
Delete All Images
Delete RAW
Delete RAW
Delete JPEG
Delete JPEG
Delete RAW+JPEG
Delete RAW+JPEG
CancelCancel
4
Playback
89
You can protect images from being accidentally deleted.
1 Select [Protect] in the C2 menu or on the
playback function selection screen.
2 Select [Protect 1 Image] or
[Protect All Images].
When [Protect All Images] is
selected, proceed to Step 4.
3 Use Q to select an image.
4 Press E.
When [Protect All Images] is selected, the confirmation
screen appears. Proceed to Step 5.
5 Select [Protect] and press E.
u Caution
• Even protected images are deleted if the inserted memory
card is formatted.
t Memo
• To cancel the protection for an image, set the protection for
the image again.
When [Auto Image Rotation] is set to [On] (default setting) in the
C1 menu, the image is automatically rotated based on the
rotation information during playback.
The rotation information of an image can be changed by
following the procedure below.
1 Display the image to rotate in the single image
display.
2 Select [Image Rotation] in the C2 menu or on
the playback function selection screen.
3 Use AB to select the
desired rotation direction
and press E.
The image rotation information is
saved, and the camera returns to
the single image display mode.
u Caution
• You cannot change image rotation information in the
following cases.
• Protected images
•Movies
• Images without a rotation information tag
t Memo
• You can save the rotation information at a specific angle in
[Save Rotation Info] of the E6 menu.
Protecting Images
C2
10:00
10:00
100-0001
100-0001
01/01/2021
01/01/2021
OK
OK
Protect All Images
Protect All Images
Protect 1 Image
Protect 1 Image
CancelCancel
Rotating Images
C2
Image Rotation
Image Rotation
Cancel
Cancel
OK
OK
4
Playback
90
You can copy images between memory cards in the SD1 slot
and the SD2 slot.
1 Select [Image Copy] in the C2 menu or on the
playback function selection screen.
2 Select [Copy 1 Image] or [Copy All Images].
For images captured with [File
Format] set to [RAW+JPEG],
select the file format to copy.
When [Copy All Images] is
selected, proceed to Step 4.
3 Use Q to select an image.
4 Press E.
When [Copy All Images] is selected, select [Execute] and
press E.
The selected image is copied to the other memory card.
You can select images to transfer to a communication device
and make a transfer reservation. When the camera is
connected to a communication device via a wireless LAN, the
file transfer automatically starts.
1 Select [File Transfer] in the C2 menu or on the
playback function selection screen.
2 Select [Transfer 1 Image].
For images captured with [File
Format] set to [RAW+JPEG],
select the file format to transfer.
3 Use Q to select an image.
4 Press E.
The transfer reservation is made
for the image.
t Memo
• To cancel the transfer reservation, select [Transfer 1 Image]
again.
Copying Images
C2
100-0001
10:00
10:00
01/01/2021
01/01/2021
OK
OK
Copy All Images
Copy All Images
Copy RAW
Copy RAW
Copy JPEG
Copy JPEG
Copy RAW+JPEG
Copy RAW+JPEG
CancelCancel
Transferring Images
C2
100-0001
10:00
10:00
01/01/2021
01/01/2021
OK
OK
Transfer RAW
Transfer RAW
Transfer JPG
Transfer JPG
CancelCancel
10:00
10:00
1/1
1/1
EV 0.0
EV 0.0
1/100
1/100
F5.6
F5.6
200
200
100-0001
100-0001
01/01/2021
01/01/2021
4
Playback
91
You can save the RAW data when it remains in the buffer of the
captured JPEG image.
1 Select [Save RAW Data] in the C2 menu in the
single image display.
The confirmation screen appears.
When no JPEG images have RAW data, the message [No
image can be processed.] is displayed.
2 Select [Save RAW Data]
and press E.
The RAW data is saved.
u Caution
• The RAW data cannot be saved from the playback function
selection screen.
t Memo
• When a JPEG image that has RAW data is displayed in the
single image display, you can also save the data by pressing
O.
• The images for which [Save RAW Data] is executed are
treated the same as the images captured with [File Format]
set to [RAW+JPEG] in the A5 menu.
You can edit and process the images captured with the camera.
1 Display the image to edit in the single image
display.
2 Select [Digital Filter] in the C3 menu or on the
playback function selection screen.
The [Digital Filter] screen appears.
3 Use AB to select a filter.
Available operations
Proceed to Step 7 if you do not need to change the
parameters.
4 Press G.
The parameter setting screen appears.
Saving the RAW Data
C2
Save RAW Data
Save RAW Data
The RAW data of this images will be
The RAW data of this images will be
saved in addition.
saved in addition.
OK
OK
Save RAW Data
Save RAW Data
CancelCancel
Editing and Processing Images
Processing Images with Digital Filters
C3
Base Parameter Adj
Extract Color
Replace Color
Toy Camera
Retro
High Contrast
Shading
Invert Color
Unicolor Bold
Tone Expansion
Bold Monochrome
Grainy Monochrome
Miniature
Soft
Fish-eye
Slim
Monotone
Frame Composite
N
Displays the preview.
Digital FilterDigital Filter
Base Parameter AdjBase Parameter Adj
CancelCancel
PreviewPreview
OKOK
4
Playback
92
5 Set the parameters.
Available operations
6 Press E.
The screen of Step 3 reappears.
7 Press E.
The filter addition confirmation screen appears.
8 Select [Add Filter] or [Save], and press E.
Select [Add Filter] when you want to apply additional filters
to the same image.
The screen of Step 3 reappears.
When [Save] is selected, the save confirmation screen
appears.
9 Select [SD1] or [SD2], and press E.
u Caution
• Only JPEG and RAW images captured with this camera can
be edited with [Digital Filter].
• RAW images captured using [HDR Capture] or [Pixel Shift
Resolution] of the A4 menu cannot be processed with
[Digital Filter].
t Memo
• Up to seven filters, including the filter used during shooting
that is set in [Digital Filter] of the A6 menu (p.79), can be
applied to the same image.
You can convert RAW images into the JPEG or TIFF format and
then save them as new files.
1 Display the image to edit in the single image
display.
2 Select [RAW Development] in the C4 menu or
on the playback function selection screen.
The RAW development setting screen appears.
3 Select the setting item to
change.
Available operations
4 Press G.
The save confirmation screen appears.
AB
Selects a parameter.
CD
Adjusts the value.
0
0
0
0
0
0
0
0
0
0
Base Parameter Adj
Base Parameter Adj
Brightness
Brightness
Cancel
Cancel
OK
OK
Developing RAW Images
C4
White Balance
Custom Image
Sensitivity
Digital Filter
Clarity
Skin Tone
HDR Capture
Pixel Shift Resolution
Distortion Correction
Peripheral Illumin. Corr.
Lat-Chromatic-Ab Adj
Diffraction Correction
Color Fringe Correction
High-ISO Noise Reduction
Shadow Correction
File Format
JPEG Recorded Pixels
JPEG Quality
Aspect Ratio
Color Space
Q
Selects a different image.
AB
Selects a setting item.
D
Makes detailed settings.
N
Displays the preview.
0.0
0.0
100-0108
White Balance
White Balance
Auto White Balance
Auto White Balance
Save
Save
Preview
Preview
Cancel
Cancel
4
Playback
93
5 Select [SD1] or [SD2], and press E.
6 Select [Continue] or [Finish], and press E.
When [Continue] is selected, the screen of Step 3
reappears.
u Caution
• [RAW Development] can be executed only for RAW images
captured with this camera.
• The RAW images captured when [Drive Mode] is set to [Multi-
exposure] or [Interval Composite] in the A4 menu are
developed according to the [Lens Correction] setting used
during shooting. The [Lens Correction] setting cannot be
changed when developing the RAW images.
t Memo
• When [RAW Development] is executed from the multi-image
display screen, folder display screen, or shooting date display
screen, a new folder is created, and the images are stored in
it.
• For [Digital Filter], [Clarity], [Skin Tone], [HDR Capture], and
[Pixel Shift Resolution], the setting item of which parameters
can be changed varies depending on the item used during
shooting. For the RAW images captured using [HDR Capture]
or [Pixel Shift Resolution], you cannot change the parameters
of [Digital Filter], [Clarity], and [Skin Tone] when developing
the RAW images.
• With the provided software “Digital Camera Utility 5”, you can
develop RAW images on a computer. (p.98)
u Caution
• Images already resized or cropped to the minimum file size
cannot be processed.
You can change the number of recorded pixels of the selected
image, and save it as a new file.
1 Display the image to edit in the single image
display.
2 Select [Resize] in the C5 menu or on the
playback function selection screen.
The [Resize] screen appears.
3 Use AB to select the
number of recorded pixels
and press E.
You can select an image size
smaller than that of the original
image.
The save confirmation screen appears.
4 Select [SD1] or [SD2], and press E.
u Caution
• [Resize] can be executed only for JPEG images captured
with this camera.
Changing the Image Size
Changing the Number of Recorded Pixels
(Resize)
C5
4752x3168
4752x3168
Resize
Resize
Cancel
Cancel
Save
Save
4
Playback
94
You can crop out only the desired area of the selected image,
and save it as a new file.
1 Display the image to edit in the single image
display.
2 Select [Cropping] in the C3 menu or on the
playback function selection screen.
The [Cropping] screen appears.
3 Specify the size and
position of the area to crop
by using the cropping
frame.
Available operations
4 Press E.
The save confirmation screen appears.
5 Select [SD1] or [SD2], and press E.
You can adjust the brightness and contrast of the highlight, mid-
tone, and shadow areas in images.
1 Display the image to edit in the single image
display.
2 Select [Levels Adjustment] in the C5 menu or
on the playback function selection screen, and
press D.
The [Levels Adjustment] screen appears.
3 Adjust the value.
Available operations
4 Press E.
The save confirmation screen appears.
5 Select [SD1] or [SD2], and press E.
Cropping Out Part of the Image (Cropping) C3
R
Changes the size of the cropping frame.
ABCD
Moves the cropping frame.
G
Changes the aspect ratio.
Q
Rotates the image by 0.1°.
H
Rotates the cropping frame by 90° (only
when possible).
M
Resets the rotation settings.
3840x2560
3840x2560
1.0
1.0
Cropping
Cropping
Preview
Preview
Cancel
Cancel
Save
Save
Correcting JPEG Images
C5
Correcting Highlight/Shadow Areas (Levels
Adjustment)
G
Switches the adjustment points.
CD
Adjusts the value.
M
Automatically adjusts the value.
N
Displays the preview.
Levels Adjustment
Levels Adjustment
Switch Points
Switch Points
Auto Adjust
Auto Adjust
Cancel
Cancel
Save
Save
Preview
Preview
4
Playback
95
You can adjust the white balance.
1 Display the image to edit in the single image
display.
2 Select [WB Adjustment] in the C5 menu or on
the playback function selection screen, and
press D.
The [WB Adjustment] screen appears.
3 Adjust the value.
Available operations
4 Press E.
The save confirmation screen appears.
5 Select [SD1] or [SD2], and press E.
You can reduce color moiré in images.
1 Display the image to edit in the single image
display.
2 Select [Color Moiré Correction] in the C5 menu
or on the playback function selection screen.
The [Color Moiré Correction] screen appears.
3 Adjust the value.
Available operations
4 Press E.
The save confirmation screen appears.
5 Select [SD1] or [SD2], and press E.
u Caution
• Some images may not be corrected properly.
• If [Color Moiré Correction] is executed, color loss or color
bleeding may occur.
Correcting the White Balance
AB
Adjusts the Green-Magenta balance.
CD
Adjusts the Blue-Amber balance.
M
Resets the adjustment value to the default
setting.
N
Displays the preview.
0:0
0:0
WB Adjustment
WB Adjustment
Reset
Reset
Cancel
Cancel
Save
Save
Preview
Preview
Correcting Color Moiré
AB
Selects the correction level.
N
Displays the preview.
Color Moiré Correction
Color Moiré Correction
Cancel
Cancel
Low
Medium
Medium
High
High
Save
Save
Preview
Preview
4
Playback
96
1 Display the movie to edit in the single image
display.
2 Select [Extract Movie] or [Divide Movie] in the
C6 menu or on the playback function selection
screen.
3 Press E.
The [Extract Movie] screen or [Divide Movie] screen
appears.
4 Select the point where you
want to divide the movie.
You can play or pause the movie
in the same manner as when
playing back a movie. (p.56)
Available operations
5 Press E.
The save confirmation screen appears.
6 Select [SD1] or [SD2], and press E.
Editing Movies
C6
Extract Movie
Saves the range specified with the start
and end points as a new file.
Divide Movie
Divides a movie into two files at the
specified devision point and saves as
new files.
00’20” / 00’45”
00’20” / 00’45”
Extract Movie
Extract Movie
Synchronize Points
Synchronize Points
Switch Points
Switch Points
OK
OK
Cancel
Cancel
Preview
Preview
00’20” / 00’45”
00’20” / 00’45”
Divide Movie
Divide Movie
Synchronize Points
Synchronize Points
OK
OK
Cancel
Cancel
Preview
Preview
Q
When [Extract Movie] is selected: Moves the
start or end point.
When [Divide Movie] is selected: Moves the
division point.
G
When [Extract Movie] is selected: Switches
between the start and end points.
M
Synchronizes the points.
N
Displays the preview.
5
Sharing
97
Connect the camera to a computer using the provided USB
cable.
Set the connection mode in [USB Setting] of the D4 menu
according to the operation to be performed with a computer.
t Memo
• Refer to “Operating Environment for USB Connection and
Provided Software” (p.130) for system requirements to
connect the camera to a computer and use the provided
software.
• The following functions are disabled while the camera is
connected to a computer with a USB cable.
• [Wireless LAN Setting] of the D4 menu
• [Auto Power Off] of the D5 menu
1 Turn the camera off.
2 Open the terminal cover of
the camera, and connect
the USB cable to the USB
terminal.
3 Connect the USB cable to the USB port of the
computer.
4 Turn the camera on.
The camera is recognized by the computer.
For Mac, the app “Photos” starts. (When the app does not
start, start it manually.)
5 Save the captured images to the computer.
6 Disconnect the camera from the computer.
t Memo
• Charging of the battery starts when the camera is turned off
after it is connected to the computer.
• On the computer, the memory cards are displayed as [SD1]
and [SD2].
Using the Camera with a
Computer
Setting the Connection Mode
D4
MTP
(default
setting)
Allows you to copy the data in the memory card to
a computer or perform tethered shooting by
operating the camera with a computer.
The memory card is displayed on the computer.
CD-ROM
Allows you to install the provided software stored in
the internal memory. (p.98)
The software is displayed as the software
installation CD-ROM [S-SW177] on the computer.
Copying an Image on the Memory Card
5
Sharing
98
The provided software “Digital Camera Utility 5” is stored in the
internal memory of the camera. With “Digital Camera Utility 5”,
you can develop RAW images, make color adjustments, or
check shooting information on the computer.
The software can be installed by following the procedure below.
1 Set [USB Setting] to [CD-ROM] in the D4 menu.
2 Turn the camera off.
3 Connect the camera to a computer using a USB
cable.
4 Turn the camera on.
The camera is recognized as CD-ROM [S-SW177].
5 Open [S-SW177] on the computer.
The [Win] or [Mac] folder appears.
6 Open the [Win] or [Mac] folder.
7 Double-click [setup32.exe] or [setup64.exe] for
Windows, or [INSTPUT5.pkg] for Mac.
For subsequent steps, follow the on-screen instructions.
8 Return [USB Setting] to [MTP] in the D4 menu.
9 Turn the camera off and back on.
The [USB Setting] setting switches to [MTP].
You can perform tethered shooting with the camera connected
to a computer using the optional “IMAGE Transmitter 2”.
1 Set [USB Setting] to [MTP] in the D4 menu.
2 Turn the camera off.
3 Connect the camera to a computer using a USB
cable.
4 Turn the camera on.
5 Start “IMAGE Transmitter 2” on the computer.
“IMAGE Transmitter 2” is started and the computer
recognizes the camera.
u Caution
• When the A/K/B dial is set to B, tethered shooting is not
available until a memory card is inserted to the camera.
t Memo
• For details on “IMAGE Transmitter 2”, download and refer to
the latest version of the “User Guide [Operation]” available at
the following website.
http://www.ricoh-imaging.co.jp/english/support/
download_manual.html
• During tethered shooting, the camera always operates with
[Release-priority] regardless of the autofocus settings ([AF.S
Setting] of [AF with Viewfinder] and [Contrast AF Options] of
[AF with Live View] in the A1 menu). (p.60, p.62)
Installing the Provided Software Operating the Camera with a Computer
5
Sharing
99
You can connect the camera to a communication device
wirelessly via Bluetooth
®
or wireless LAN. By using the
dedicated app “Image Sync”, the camera can be operated from
the communication device and the images saved in the memory
cards can be displayed on the communication device to import
them.
Refer to the separate “Wireless Communication Guide” for how
to use the camera connected with a communication device.
Using the Camera with a
Communication Device
6
Settings
100
You can save up to ten frequently used settings and assign the
settings to O to 5 of the mode dial so that you can easily use
the settings for shooting.
The following settings can be saved.
You can save up to ten settings.
1 Set the exposure mode and all the necessary
settings to save.
2 Select [Save User Mode Settings] in the E1
menu and press D.
The [Save User Mode Settings] screen appears.
3 Select a box from [BOX1]
to [BOX10], and press E.
4 Select whether to enter the box name and press
E.
When [Cancel] is selected, proceed to Step 7.
When [Enter Name] is selected, the text-entry screen
appears.
5 Enter the box name.
Up to 32 single-byte
alphanumeric characters and
symbols can be entered.
Available operations
6 After entering the text, press G.
7 Select a user mode to
register the saved settings
to from USER1 (O) to
USER5 (5) of the mode
dial, and press E.
The screen of Step 3 reappears.
u Caution
• [Save User Mode Settings] cannot be selected when the
mode dial is set to R.
t Memo
• If the box name is not entered, the date and time when the
settings are saved are used as the box name.
• To change the box name, select [Rename User Mode] in the
E1 menu.
• To reset the saved settings, select [Reset User Mode
Settings] in the E1 menu.
Camera Settings
Saving Frequently Used Settings
E1
Exposure mode (except
for R)
Shutter speed and
aperture value
ISO sensitivity
Exposure value
compensation
A menu and E menu
settings (with exceptions)
Saving the Settings
BOX1
:
BOX2
:
BOX3
:
BOX4
:
BOX5
:
BOX6
:
Save User Mode Settings
CancelCancel OKOK
ABCD
Moves the cursor.
J
Switches between upper and lower case
letters.
N
Switches between alphabetical and
numeric characters.
E
Enters a character at the position of the
cursor.
L
Deletes a character from the entered
text.
㹵e r t y u i o pq
s d f g h j k la
z
123
x c v b n m
CancelCancel OKOK
USER1: XXXXXXXXX
USER2:
USER3:
Assign settings saved
in User Mode Box
to Mode Dial.
Save User Mode Settings
ExitExit
6
Settings
101
You can change the settings assigned to the mode dial.
1 Select [Recall User Mode Setting] in the E1
menu and press D.
The [Recall User Mode Setting] screen appears.
2 Select a user mode to
register the saved settings
to from USER1 (O) to
USER5 (5) of the mode
dial, and press D.
3 Select the saved settings from [BOX1] to
[BOX10], and press E.
The selected settings are assigned to the mode dial.
The screen of Step 2 reappears.
t Memo
• If [Recall User Mode Setting] is registered as a function
displayed in the control panel, you can use R to change the
box when the mode dial is set to O to 5. (p.106)
1 Set the mode dial to O to 5.
2 Change the settings as necessary.
The exposure mode can be
temporarily changed in
[Exposure in User Mode] of the
E1 menu.
t Memo
• The settings changed in Step 2 are not saved as the user
mode settings. When the camera is turned off or the mode
dial is turned, the user mode settings are reset to the
originally saved ones. The timing to reset the user mode
settings can be set in [User Settings Restoration] in the E1
menu.
• If the settings saved in the box assigned to the mode dial are
changed, the settings applied to the mode dial are also
changed.
Changing the Settings
USER1:
USER2:
USER3:
Recall User Mode Setting
Assign settings saved
in User Mode Box
to Mode Dil.
Using the User Mode
Setting
When the camera is
turned off
When the mode dial is
turned
Type 1 Reset Not reset
Type 2 Not reset Reset
Type 3 Reset Reset
Program AE
Shutter Priority AE
Sensitivity Priority AE
Shutter & Aperture Prior.
Manual Exposure
Aperture Priority AE
Exposure in User Mode
CancelCancel OKOK
6
Settings
102
You can set the functions for when ABCD, 5, O, 7,
2, 3, or H is pressed. These customizable buttons are
called “Fx button”.
The function set for each button can be checked on the status
screen.
1 Select [Fx Button] in the E2 menu and press D.
The [Fx Button] screen appears.
2 Use AB to select a button
and press D.
The screen to set the function for
the selected button is displayed.
3 Use AB to select the
function to assign to each
button.
The following functions can be assigned.
*1 Changes the number of shots and bracket value.
*2 Changes the file format according to the [File Format] setting
when the button is pressed. (p.103)
*3 Displays the [Composition Adjustment] screen when the A/K/
B dial is set to K.
*4 Switches to shooting with Live View while keeping the A/K/
B dial set to A.
4 Press E.
The screen of Step 2 reappears.
Repeat Steps 2 to 4.
5 Press F twice.
Customizing the Operating Controls
Setting the Button Operation E2
Fx Button
Shake Reduction Button
RAW Button
Operation Lock Button
Shake Reduction Button
Unset
Face Detection
AE Lock
AE Metering
Flash Mode
Focus Peaking
CancelCancel OKOK
Focus Peaking
Face Detection
AE Lock
AE Metering
Flash Mode
White Balance
Drive Mode
Drive
Bracketing
*1
Timer/Remote Control
HDR Capture
Pixel Shift Resolution
AA Filter Simulator
One Push File Format
*2
Crop
Custom Image
Shake Reduction
Auto Horizon Correction
Composition Adjustment
*3
Operation Control Lock
One Push LV
*4
Monitor Touch Operation
Viewfinder Light
LCD Panel Illumination
Electronic Level Display
Playback Mode
Outdoor View Setting
Night Vision Display
Wireless LAN Setting
6
Settings
103
t Memo
• You can check the functions
assigned to each button on the
status screen.
• You can set the same function to
multiple buttons.
• The setting switches or the setting
screen appears when the Fx button
is pressed.
• Depending on the assigned function, a beep sounds when
the Fx button is pressed. To not make a beep sound, change
the [Fx Button Operation] setting of [Sound Effects Setting] in
the D3 menu. (p.110)
• When [Shake Reduction] or [Operation Control Lock] is
assigned to the Fx button, press G on the screen of Step
2 to set the camera operation when the button is pressed.
You can temporarily change the file format by pressing the
button during shooting. Select the file format to change to when
the button is pressed for each [File Format] setting.
1 Select [One Push File Format] in Step 3 of
“Setting the Button Operation” (p.102).
2 Press G on the [Fx Button] screen.
The [One Push File Format] screen appears.
3 Make the [JPEG Options],
[RAW Options], and
[RAW+JPEG Options]
settings.
Select the file format to change to
when each button is pressed.
4 Make the [Cancel after 1 Shot] setting.
5 Press F twice.
The camera returns to the standby mode.
u Caution
• The button to which the One Push File Format function is
assigned cannot be used when [Memory Card Options] is set
to [Separate RAW/JPEG] in the A5 menu. (p.48)
Shake Reduction
OFF→AUTO→PAN (panning)
AUTO→PAN (panning)
OFF→AUTO
OFF→PAN (panning)
Operation
Control Lock
Exposure Change Lock (shutter speed,
aperture value, ISO sensitivity, EV
Compensation, M, AE Lock)
Misoperation Prevention (ABCD,
6, F)
1 0 : 1 0
10:10
1 /
1/
250
250
1600
F
F
5.6
5.6
SR
0 1 / 0 1 / 2 0 2 1
01/01/2021
9 9 9 9
9999
9 9 9 9
9999
Setting the One Push File Format
On
The file format returns to the [File Format] setting
in the A5 menu after an image is taken.
Off
The file format is retained until any of the following
operations is performed.
• Turning the camera off
• Switching the user modes
• Setting the camera to the payback mode
• Setting the camera to the B mode
One Push File Format
JPEG Options
RAW Options
On
RAW+JPEG Options
Cancel after 1 Shot
6
Settings
104
You can set the button operations and timing for autofocus and
AE Lock in [AF/AE Lock Settings] of the E2 menu.
The following settings can be made
for [Still Image].
In B mode, the I function is fixed to the autofocus operation.
Set whether to perform autofocus with 0.
t Memo
• When a lens that is capable of AF tracking is attached to the
camera, you can turn on and off the tracking operation by
pressing E during movie recording.
For each exposure mode, you can set the functions for when
Q or R is turned, when M is pressed, and when [E-Dial] is
set for the Smart Function and V is turned.
1 Select [E-Dial Programming] in the E2 menu
and press D.
The [E-Dial Programming] screen appears.
2 Select [Still Image] or
[Movie], and press D.
The exposure mode selection
screen appears.
3 Use CD to select an
exposure mode and press
E.
The current settings are
displayed.
4 Select [Basic Operation]
and press D.
5 Use AB to select the
combination of functions
for when Q, R, or V is
turned and when M is
pressed.
Setting the Autofocus and AE Lock Operations
E2
Shutter/AF Button Sets the operations when 0 is
pressed halfway or I is pressed.
Shooting AE Lock Sets the timing to lock the exposure
value.
Setting the E-dial Operation E2
Still mge
Shutter/AF Button
Shooting AE Lock
Enable AF
Enable AF
E-Dial Programming
Still Image
Movie
Rotation Direction
HYPER P/Sv Options
Changes the shutter speed.
Shifts the shutter speed.
Changes the aperture value.
Shifts the aperture value.
Changes the ISO sensitivity.
Automatically adjusts the ISO
sensitivity.
Shifts the ISO sensitivity.
Compensates the exposure value.
Resets the compensated exposure
value.
Still Image
Sets the e-dial operation
for each exposure mode.
Basic Operation
reen Button
S.Fn Dil (E-Dil)
E-Dial Programming
Basic Operation
Cancel
Cancel
OK
OK
6
Settings
105
6 Press E.
The screen of Step 4 reappears.
When [E-Dial] is set for the Smart Function, make the [S.Fn
Dial (E-Dial)] setting.
7 Press F.
The screen of Step 3 reappears.
Repeat Steps 3 to 7.
8 Press F three times.
t Memo
• You can check the functions assigned to each dial on the
status screen.
• When assigning a function to V, assign [E-Dial] to [Smart
Function] in the E2 menu. (p.106)
• If you select [Rotation Direction] on the screen of Step 2, you
can reverse the effect obtained by turning Q or R.
• If you select [HYPER P/Sv Options] on the screen of Step 2,
you can set the camera operation when the camera enters
the hyper mode in G or H mode.
Executes the Program Shift.
Executes the Program Line.
Sets the camera to the hyper mode.
Sets the camera to the advanced
hyper mode.
Cancels the hyper mode.
Enables/Disables the timed
exposure.
Not available
Standard
Determines the exposure by prioritizing the last
changed shutter speed and aperture value.
Advanced
Fixes the changed exposure parameters: ISO
sensitivity, shutter speed, and aperture value.
When all parameters are changed, the camera
enters the hyper L mode.
6
Settings
106
You can register five functions for the Smart Function.
1 Select [Smart Function] in the E2 menu and
press D.
The [Smart Function] screen appears.
2 Select a function number
from [Function 1] to
[Function 5], and press D.
3 Use AB to select the function to assign to each
function number.
The following functions can be assigned.
Up to six settings can be registered for a function. The order
of the settings can also be registered.
*1
The camera operates with the [AF Mode], [AF Active Area], and
[Hold AF Status] settings made in advance in [AF with Viewfinder].
*2 Press G to make detailed settings.
*3 You can change the ISO sensitivity and exposure compensation
values between the values registered in advance for each
exposure mode by turning V.
4 Press E.
The screen of Step 2 reappears.
Repeat Steps 2 to 4.
5 Press F twice.
You can customize the functions displayed on the control panel.
Some functions in the A, B, and D menus can be saved as
control panel items.
1 Select [Control Panel] in the E5 menu and press
D.
2 Select [Still Image] or [Movie], and press D.
The control panel customization screen appears.
3 Use ABCD to select the
function to change.
4 Press E.
Selectable functions are displayed in the pop-up menu.
5 Use AB to select the
function to save.
Select [--] if you do not want to
save any function.
6 Press E.
The screen of Step 3 reappears.
Press M to reset to the default functions.
7 Press F three times.
t Memo
• When the control panel is displayed from the standby mode,
you can display the screen of Step 3 by pressing J to
customize the control panel.
Setting the Smart Function E2
Unset
User AF
*1 *2
AF Mode
AF Active Area
*2
Hold AF Status
*2
Focus Peaking
*2
AE Metering
*2
E-Dial
*3
ISO Sensitivity
EV Compensation
Flash Exposure Compensation
Program Line
*2
White Balance
*2
Drive
*2
AA Filter Simulator
*2
HDR Capture
*2
Pixel Shift Resolution
*2
Crop
Custom Image
*2
Shake Reduction
*2
Zoom Review
Grid Guide
Outdoor View Setting
Specifies the functions that can be used
with Smart Function and the settings
that can be selected.
Smrt Function
Function 1
Function 2
Function 3
Customizing the Control Panel E5
ISO AUTO MAX
6400
Select the location of the
item you want to change.
Reset
Reset
OK
OK
--
--
ISO AUTO MAX
6400
HDR Capture
AF Mode
OK
OK
Cancel
Cancel
6
Settings
107
You can set the camera operation when the eye sensor detects
the user’s eye in [Eye Sensor] of the E4 menu.
You can set the display in the viewfinder in [Viewfinder Display]
of the E4 menu.
You can switch the viewfinder display between the registered
four patterns. You can also change the items to display for each
pattern.
1 Select [Viewfinder Screen] in [Viewfinder
Display] of the E4 menu, and press D.
The [Viewfinder Screen] screen appears.
2 Select [Current Display
Pattern] and press D, and
select a pattern from F1 to
F4.
3 When customizing the display items, select [F1
Customization] to [F4 Customization], and press
D.
The grid style can be selected,
and the display of each item can
be turned on and off.
4 Press F four times.
t Memo
• You can easily switch the
viewfinder screen patterns using
the Smart Function or control
panel. If there are patterns that you
do not want to use, select
[Available Display Pattern] on the
screen of Step 2 and set them to Y
(Off).
Setting the Monitor Display, Indicator Lamp
Illumination, and Sound Effects
Eye Sensor E4
Link Monitor
Display
Turns off the monitor backlight when the
eye sensor detects the user’s eye.
AE with Eye
Sensor
Starts metering when the eye sensor
detects the user’s eye.
Detection
Sensitivity
Sets the eye sensor detection sensitivity.
Viewfinder Display E4
Viewfinder
Screen
Sets the combination of display items from
among the grid guide, electronic level, AF
frame, spot metering frame, AF points,
and Smart Function icons (p.107).
Electronic Level
Type
Sets the electronic level type to
[Level+Tilt] or [Level].
Viewfinder Light
Sets whether to illuminate the viewfinder.
When [Auto] is set, the viewfinder is
illuminated only in dark places.
Info Display
Outside FOV
Sets whether to display information such
as the exposure value outside the field of
view in the viewfinder.
Setting the Viewfinder Screen Display
F1
1/2/3/4
Viewfinder Screen
Current Display Pattern
Available Display Pattern
F1 Customization
F2 Customization
F3 Customization
F4 Customization
F1 Customization
Grid Guide
Electronic Level Display
AF Frame
Spot Metering Frame
AF Points
S.Fn Display
F1
F2
F3
Select a display pattern that can be
switched via the control panel and
Smart Function during shooting.
Available Display Pattern
6
Settings
108
You can set the illumination of the LCD panel in [LCD Panel] of
the E4 menu.
You can set the information displayed on the monitor in [Monitor
Display] of the E4 menu.
You can switch the Live View display between the registered
three patterns. You can also change the items to display for
each pattern.
1 Select [Live View] in [Monitor Display] of the E4
menu, and press D.
The [Live View] screen appears.
2 Select [Shooting Info Display] and press D.
3 Select [Current Display
Pattern] and press D, and
select a pattern from L1 to
L3.
4 When customizing the display items, select [L1
Customization] to [L3 Customization], and press
D.
The display of each item can be
turned on and off.
5 Press F four times.
t Memo
• You can switch the Live View
shooting information display by
pressing G during shooting. If
there are patterns that you do not
want to use, select [Available
Display Pattern] on the screen of
Step 3 and set them to Y (Off).
LCD Panel E4
Illumination
Brightness
Sets the brightness to [Low] or [High].
LCD Panel
Illumination
[Auto]: Illuminates the LCD panel when the
metering is started while shooting with the
viewfinder.
[Manual]: Illuminates the LCD panel when
the button to which [LCD Panel Illumination]
is assigned in [Fx Button] of the E2 menu is
pressed.
[Off]: Does not illuminate the LCD panel.
Monitor Display E4
Color Settings
Sets [Color] and [Style] of the status screen
and control panel.
Status Screen
Sets [Auto Display Rotation], [Electronic
Level Display], [Electronic Level Type], and
[Electronic Level Design].
Live View
Sets [Shooting Info Display], [Electronic
Level Type], [Electronic Level Design], and
[Flicker Reduction].
Playback Info
Display
Sets the information to display when the
screen is switched with G in the playback
mode.
Grid Guide
Sets [Grid Style] and [Grid Color] of the grid
lines displayed while shooting with Live View
and in the playback mode.
Setting the Live View Display
L1
1/2/3
Shooting Info Display
Current Display Pattern
Available Display Pattern
L1 Customization
L2 Customization
L3 Customization
L1 Customization
Histogram
Grid Guide
Highlight Alert
Electronic Level Display
L1
L2
L3
Select a display pattern that can be
switched with the INFO button during
shooting.
Avilble Disply Pttern
6
Settings
109
You can set the brightness, saturation, and color balance of the
monitor.
1 Select [Monitor Adjustment] in the D2 menu
and press D.
The monitor adjustment screen appears.
2 Set each item.
Available operations
3 Press E.
u Caution
• [Brightness] cannot be set when the monitor brightness is
adjusted with [Outdoor View Setting] of the D2 menu.
t Memo
• The eye sensor is used when the automatic adjustment
(default setting) is selected for [Brightness]. If the eye sensor
is in the shade or exposed to strong light, the brightness may
not be adjusted correctly. To not change the brightness
automatically, use the manual adjustment.
You can set the display and operation of “Instant Review” that
is displayed immediately after shooting in [Instant Review] of the
E4 menu.
You can set the camera operation when the display is zoomed
in [Zoom Review] of the E4 menu.
Monitor Adjustment D2
AB Selects the item.
CD Adjusts the value.
G [Brightness]: Switches between the
automatic adjustment and the manual
adjustment.
M Resets the adjustment value to the default
setting.
Cancel
Cancel
Auto Brt. Adj.
Auto Brt. Adj.
OK
OK
Brightness
Brightness
Instant Review E4
Display Time
Sets the Instant Review display time.
When [Display Time] is set to [Hold],
Instant Review is displayed until the next
operation.
Zoom Review
Displays the magnified image with R
during Instant Review.
Save RAW (RAW
Button)
Saves the RAW data with O during
Instant Review.
Delete Img.
(Delete Btn.)
Deletes the displayed image with L
during Instant Review.
Manage Img.
(AE-L Btn.)
Displays the file management screen (for
[Delete], [Save RAW Data], [Protect], and
[Transfer Reservation]) with H during
Instant Review.
Histogram
Displays the histogram during Instant
Review.
Highlight Alert
Displays the highlight alert during Instant
Review.
Zoom Review E4
Quick Zoom
[Display Magnification]: Sets the display
magnification for the quick zoom function.
[Zoom Trigger]: Sets the trigger operation for
the quick zoom function.
Focus
Magnification
Zooms the display centering on the focused
point.
6
Settings
110
You can set whether to display the warning icon in the
viewfinder and on the LCD panel and monitor in [Warning
Display] of the E4 menu.
You can set whether to light up the indicator lamps in [Indicator
Lamps] of the D3 menu.
You can set the sound volume of beep sounds in [Sound Effects
Volume] (0 to 5), and set whether to make beep sounds in
[Sound Effects Setting] of the D3 menu.
Warning Display E4
Release Lock
Warning
Displays the warning icon when the shutter
cannot be released because there is no
available space on the memory card or due
to other problems.
Release Timer
Warning
Displays the warning icon when the shutter
cannot be released immediately because
[Timer/Remote Control] is turned on in [Drive
Mode] of the A4 menu or due to other
problems.
Processing
Warning
Displays the warning icon when a function for
which the image processing takes a long
time after shooting, such as [HDR Capture]
and [Pixel Shift Resolution] in the A4 menu,
is enabled.
Indicator Lamps D3
Self-timer
Makes the indicator lamps blink during the
countdown for shooting with [Self-timer (12
sec.)], [Self-timer (2 sec.)], or [Remote
Control (3 sec.)] in [Drive Mode] of the A4
menu.
Remote
Control
Makes the indicator lamps blink during the
standby for shooting with [Remote Control] in
[Drive Mode] of the A4 menu.
GPS Unit
Lights up the indicator lamps when the GPS
unit is attached to the camera.
Sound Effects D3
Electronic
Shutter Sound
Makes an electronic shutter sound while
shooting with [Pixel Shift Resolution] of the
A4 menu.
In-focus
Makes a beep sound when the subject is
focused.
AE Lock
Makes a beep sound when the exposure
value is locked.
Count Down
Makes a beep sound during the countdown
for shooting with [Self-timer] or [Remote
Control (3 sec.)] in [Drive Mode] of the A4
menu.
Mirror Up
Makes a beep sound during the mirror lock-
up shooting with [Mirror Lock-up Shooting] in
[Drive Mode] of the A4 menu.
Fx Button
Operation
Makes a beep sound when the Fx button is
pressed, to which [One Push File Format],
[Crop], [Shake Reduction], [Auto Horizon
Correction], [Monitor Touch Operation],
[Viewfinder Light], [LCD Panel Illumination],
[Electronic Level Display], [Night Vision
Display], or [Wireless LAN Setting] is
assigned.
6
Settings
111
The setting values for most functions
of this camera are saved even if the
camera is turned off. For the following
function settings, you can select
whether to save the settings (Z: On)
or to return the settings to their default
values (Y: Off) when the camera is
turned off. Make settings in [Memory] of the E5 menu.
t Memo
• When [Reset] of the D8 menu is performed, all [Memory]
settings return to the default values.
When [Create New Folder] is selected in the D1 menu, a folder
is created with a new number when the next image is saved.
u Caution
• You cannot successively create multiple folders.
t Memo
• A new folder is automatically created in the following cases.
• When [Drive Mode] is set to [Interval Shooting] in the A4
menu (p.71)
• When [Save Interim Images] is set to [Unblended] or
[Blended] in [Interval Composite] of [Drive Mode] in the
A4 menu (p.72)
• When [RAW Development] of the C4 menu is executed
from the multi-image display screen, folder display screen,
or shooting date display screen (p.92)
Selecting Settings to Save in the
Camera
E5
ISO Sensitivity
EV Compensation
Flash Mode
Flash Exposure Compensation
White Balance
Drive
Timer/Remote Control
HDR Capture
Pixel Shift Resolution
Crop
Custom Image
Digital Filter
Clarity
Skin Tone
Composition Adjustment
Shooting Info Display
Playback Info Display
Image for Playback
Operation Control Lock
Outdoor View Setting
Night Vision Display
Memory
ISO Sensitivity
EV Compensation
Flash Mode
Flash Exposure Comp.
White Balance
Drive
File Management Settings
Specifying the Folder/File Settings
D1
Create New Folder
6
Settings
112
When images are captured with this camera, a folder is
automatically created and the captured images are stored in it.
Each folder name consists of a sequential number from 100 to
999 and a string of five characters.
The character string in the folder name can be changed.
1 Select [Folder Name] in the
D1 menu and press D.
The [Folder Name] screen
appears.
2 Select [Date] or [Optional] for [Folder Name] and
press E.
The screen of Step 1 reappears.
When you select [Date] or do not need to change the
character string, proceed to Step 6.
3 Press B to select [Enter Text], and press D.
The text-entry screen appears.
4 Change the text.
Enter five single-byte
alphanumeric characters.
Available operations
5 After entering the text, press G.
The screen of Step 1 reappears.
6 Press F twice.
t Memo
• A folder with a new number is created when the folder name
is changed.
u Caution
• The maximum folder number is 999. After the folder number
reaches 999, you cannot capture new images if you attempt
to change the folder name or create a new folder, or when the
file name number reaches 9999. In this case, perform [Reset
Numbering] in the D1 menu.
Folder Name
Date
The four digits of the month and day of the
shooting date are assigned after the folder
number.
The month and day appear according to the
date format set in [Date Adjustment] of the D7
menu.
Example) 101_0125: The folder for images
captured on January 25th
Optional
A freely defined string of five characters is
assigned after the folder number.
(Default setting: PENTX)
Example) 101PENTX
PENTX
100_MMDD
Folder Name
Folder Name Date
Enter Text
ABCD
Moves the cursor.
N
Switches between alphabetical and
numeric characters.
E
Enters a character at the position of the
cursor.
㹕E R T Y U I O PQ
S D F G H J K LA
Z
123
X C V B N M
PENTX
_
Cancel OK
6
Settings
113
One of the following string of characters is used as the file name
prefix depending on the [Color Space] setting in the A5 menu.
The first four characters can be changed to a character string of
your choice.
1 Select [File Name] in the D1 menu and press D.
The [File Name] screen appears.
2 Select [Still Image] or
[Movie], and press D.
The text-entry screen appears.
3 Change the text.
Up to four single-byte alphanumeric characters can be
entered as an alternative for the first part of the file name,
while the asterisks stand for figures that increase
automatically shot by shot.
y Text entry (p.112)
4 Press F twice.
t Memo
• When [Color Space] is set to [AdobeRGB], the file name
prefix is “_” and first three characters of the entered character
string becomes the file name.
• For movies, regardless of the [Color Space] setting, the file
name is “IMGP.MOV” or the one with the entered
string of characters.
In [Sequential Numbering] of the D1
menu, you can set whether to
continue the sequential numbering for
folder and file names even when a
new folder is created or when
memory cards are replaced.
The serial number is continued or
reset at the following timings depending on the [Sequential
Numbering] setting.
When a new image is taken after [Reset Numbering] of the D1
menu is performed, a folder with a new folder number is created
and the file number starts from 0001.
t Memo
• When the file number reaches 9999, a new folder is created
and the file number is reset.
File Name
Color Space File Name
sRGB IMGP
.JPG
AdobeRGB _IMG
.JPG
IMGP0001.JPG IMGP0001.MOV
IMGP
IMGP
File Name
Still Image
Movie
Sequential Numbering
Sequential
Numbering
When a new
folder is
created
When memory cards are
replaced
File No. Folder Name File No.
Folder &
File
Continue Continue Continue
File Continue Reset Continue
Off Reset Reset Reset
Reset Numbering
Sequential Numbering
Folder & File
CancelCancel OKOK
File
O
6
Settings
114
You can set the photographer and copyright information
embedded in the Exif data.
1 Select [Copyright Information] in the D1 menu
and press D.
The [Copyright Information] screen appears.
2 Select [Embed Copyright
Data] and press D, select
[On] or [Off], and press E.
3 Select [Photographer] or [Copyright Holder],
and press D.
The text-entry screen appears.
4 Change the text.
Up to 32 single-byte alphanumeric characters and symbols
can be entered.
y Text entry (p.100)
5 Press F twice.
t Memo
• The Exif information can be checked in the “detailed
information display” in the playback mode (p.15) or using the
provided software “Digital Camera Utility 5”.
Setting the Copyright Information
D1
XXXXXXXXXXXXXXX
XXXXXXXXXXXXXXX
Copyright Information
Embed Copyright Data On
Photographer
Copyright Holder
7
115
Appendix
#: Restricted
×
: Not available
*1 [Bracketing] is not available.
*2 Only the final frame can be saved.
Restrictions on the Combinations of Special Functions
AA Filter
Simulator
HDR
Capture
Pixel Shift
Resolution
ASTRO-
TRACER
Digital Filter/
Clarity/
Skin Tone
Distortion
Correction/
Diffraction
Correction
Save RAW
Data
Drive Mode
Continuous
Shooting
#
*1
××× ×
Bracketing #
*1
×××
#
*2
Mirror Lock-up
Shooting
#
*1
×
Multi-exposure #
*1
×××××
Interval Shooting #
*1
××
#
*2
Interval Composite #
*1
×××××
#
*2
AA Filter Simulator
××
#
*1
#
*2
HDR Capture
×
×××
Pixel Shift Resolution
××
××
7
Appendix
116
All capture modes are available when a D FA, DA, DA L, FA, or
FA J lens is used, or when a lens with an 9 position is used with
the aperture ring set to the 9 position.
When other lenses than above are used, or a lens with an 9
position is used in a position other than 9, the following
restrictions apply.
x: Available #: Restricted
×
: Not available
*1 Lenses with a maximum aperture of F2.8 or faster. Only available at
the 9 position.
*2 Lenses with a maximum aperture of F5.6 or faster.
*3 Available when using AF540FGZ, AF540FGZ II, AF360FGZ,
AF360FGZ II, AF201FG, AF200FG, or AF160FC.
*4 Only available with compatible lenses.
*5 [Distortion Correction] and [Peripheral Illumin. Corr.] are disabled
when a DA FISH-EYE 10-17mm lens is used.
*6 To use an FA SOFT 28mm F2.8 lens, FA SOFT 85mm F2.8 lens, or
F SOFT 85mm F2.8 lens, set [Using Aperture Ring] to [On] in the E6
menu. Images can be taken with the aperture you set, but only within
a manually adjustable aperture range.
*7 The auto zoom and preset zoom are disabled.
*8 The Lens Correction is available with the following FA lenses (only
[Distortion Correction] and [Lat-Chromatic-Ab Adj] can be used when
the aperture ring is set to a position other than 9.):
FA
k
24mm F2 AL [IF], FA 28mm F2.8 AL, FA 31mm F1.8 Limited, FA
35mm F2 AL, FA 43mm F1.9 Limited, FA 50mm F1.4, FA 77mm F1.8
Limited, FA
k
85mm F1.4 [IF], FA
k
200mm F2.8 ED [IF],
FA
k
MACRO 200mm F4 ED, FA
k
300mm F2.8 ED [IF], FA
k
300mm
F4.5 ED [IF], FA
k
400mm F5.6 ED [IF], FA
k
600mm F4 ED [IF],
FA
k
28-70mm F2.8 ED [IF], FA
k
80-200mm F2.8 ED [IF], and
FA
k
250-600mm F5.6 ED [IF].
*9 Fixed to [Spot].
*10 J with the aperture set to wide open. (The aperture ring has no
effect on the actual aperture value.)
u Caution
• When the aperture ring is set to a position other than 9 or a
lens without an 9 position or accessories such as an
extension tube are used, the camera does not operate unless
[Using Aperture Ring] is set to [On] in the E6 menu. Refer to
“Using the Aperture Ring” (p.118). for details.
• When a retractable lens is attached and is not extended, you
cannot take images or use some functions. If the lens is
retracted during shooting, the camera stops working.
Functions Available with Various
Lenses
Lens
[Mount type]
Function
D FA
DA
DA L
FA
*6
FA J
F
*6
A
M
P
[KAF]
[KAF2]
[KAF3]
[KAF4]
[KAF]
[KAF2]
[KAF] [KA] [K]
Autofocus
(Lens only)
(With AF adapter 1.7×)
*1
x
—
x
—
x
—
—
#
—
#
Manual focus
(With focus indicator)
*2
(With matte field)
xxxxx
Quick-shift focus #
*4
××××
AF Active Area [Auto Area] xxx
×
*9
×
*9
AE Metering [Multi-segment] xxxx
×
G/H/I/J/K mode xxxx #
*10
L mode xxxx #
P-TTL auto flash
*3
xxxx
×
Power zoom — #
*7
———
Automatic obtaining of the
lens focal length information
xxx
××
Lens Correction #
*5
#
*8
×××
7
Appendix
117
When the following lenses are used,
the AF points on both sides cannot be
used while shooting with the
viewfinder.
See RICOH IMAGING website for the
latest information.
(As of October 2020)
Lens Names and Mount Names
• DA lenses with a motor and FA zoom lenses with a power
zoom use the KAF2 mount. (Of these lenses, the lenses
without an AF coupler use the KAF3 mount.)
• The KAF3 mount equipped with an electromagnetic
diaphragm mechanism instead of an aperture control
lever is referred to as the KAF4 mount.
• FA single focal length lenses, DA and DA L lenses without
a motor, and D FA, FA J, and F lenses use the KAF mount.
Refer to respective lens manuals for details.
Mount
Lens
Name
Lens Type
MF
SS
For 35mm full-frame sizeK P, M
KA A
AF
KAF
D FA For 35mm full-frame size
DA
For APS-C size
Without the aperture ring
FA
For 35mm full-frame size
Power zoom not compatible
FA J
For 35mm full-frame size
Without the aperture ring
F For 35mm full-frame size
KAF2
DA
For APS-C size
Compatible with the built-in
motor
Without the aperture ring
FA
For 35mm full-frame size
Power zoom compatible
KAF3
KAF4
D FA
For 35mm full-frame size
Dedicated for the built-in motor
Without the aperture ring
DA
For APS-C size
Dedicated for the built-in motor
Without the aperture ring
Restrictions on the Selection of AF Points
Type Lens
A
smc PENTAX-F 35-70mmF3.5-4.5
smc PENTAX-F 35-80mmF4-5.6
smc PENTAX-FA 28mmF2.8AL
smc PENTAX-FA 28mmF2.8 soft
smc PENTAX-FA 35-80mmF4-5.6
smc PENTAX-FAJ 18-35mmF4-5.6
smc PENTAX-FAJ 28-80mmF3.5-5.6
smc PENTAX-DA FISH-EYE10-17mmF3.5-4.5ED[IF]
HD PENTAX-DA FISH-EYE10-17mmF3.5-4.5ED
smc PENTAX-DA 50-200mmF4-5.6 ED
smc PENTAX-DA 50-200mmF4-5.6 ED WR
smc PENTAX-DAL 50-200mmF4-5.6 ED
smc PENTAX-DAL 50-200mmF4-5.6 ED WR
smc PENTAX-DA 18-250mmF3.5-6.3ED AL[IF]
B
smc PENTAX-DA 15mmF4ED AL Limited
HD PENTAX-DA 15mmF4ED AL Limited
smc PENTAX-DA 21mmF3.2AL Limited
HD PENTAX-DA 21mmF3.2AL Limited
HD PENTAX-DA 560mmF5.6ED AW
AF points for type A lenses
AF points for type B lenses
7
Appendix
118
The shutter can be released even if the aperture ring of the D
FA, FA, F, or A lens is not set to the 9 position or a lens without
an 9 position is attached.
Set [Using Aperture Ring] to [On] in
the E6 menu.
With the automatic exposure control, the camera operates as
follows.
t Memo
• [F--] appears for the aperture indicator on the status screen,
etc. When [Aperture Info Record] is set to [On] in the E6
menu, the aperture value set with Q, R, and V is
displayed, and only “F” blinks.
• Set [Aperture Info Record] to [On] in the E6 menu to record
the aperture value set for recording with Q, R, and V in
captured images.
u Caution
• When shooting using the automatic exposure control, note
the following points.
• Images can be taken with the set aperture value but an
exposure deviation may occur.
• When shooting with the optical viewfinder, you cannot
check the shutter speed and ISO sensitivity before
shooting because the metering is performed immediately
before the shutter is released. When shooting with Live
View, you can check the shutter speed and ISO sensitivity
before shooting because the aperture is always narrowed
down.
• When a lens with automatic diaphragm is attached, the
aperture is narrowed down immediately before the shutter
is released, causing a time lag in the shutter release.
Using the Aperture Ring
E6
Mode Dial Camera Operation
G, H, JJ mode
I
When the ISO sensitivity is set to ISO Auto: K
mode
When the ISO sensitivity is set to a fixed value:
L mode
KK mode
LL mode
M
M mode
N
N mode
Shutter will release when
Using Aperture Ring
aperture ring is not set to the
On
O
CancelCancel OKOK
"A" position.
How to Achieve the Correct Exposure with the Aperture
Ring Not Set to 9
The correct exposure can be achieved by the following
procedures when the aperture ring is not set to 9.
1 Set the mode dial to L.
2 Set the aperture ring to the desired aperture.
3 Press M.
The correct shutter speed will be set.
4 If the correct exposure cannot be achieved, adjust the
ISO sensitivity.
7
Appendix
119
The Shake Reduction function operates by obtaining the lens
information such as focal length. Set the focal length when
using a lens that the focal length information cannot be
automatically obtained.
1 Set [Using Aperture Ring] to [On] in the E6
menu.
2 Turn the camera off.
3 Attach a lens to the camera and turn the camera
on.
The [MF Lens Focal Length] screen appears.
4 Use ABCD to set the
focal length.
The focal length can also be
selected from the input history by
pressing G.
5 Press E.
t Memo
• The focal length setting can be changed in [MF Lens Focal
Length] of the E6 menu.
• When a zoom lens is used, set the actual focal length which
the zoom is set to.
• To not input the focal length at the camera startup when a
lens that cannot automatically obtain the focal length
information is attached to the camera, set [Length Input on
Startup] to [Off] in the E6 menu.
• To record the focal length information you input in the image
when a lens that cannot automatically obtain the focal length
information is attached, set [Using Aperture Ring] to [On] in
the E6 menu.
Use of the following external flashes (optional) enables a variety
of flash modes, such as P-TTL auto flash mode.
x: Available #: Restricted
×
: Not available
Setting the Focal Length
E6
mm
0 035
Select History
MF Lens Focal Length
When using a lens that cannot acquire
the focal length, enter a focal length
applied to camera control.
CancelCancel OKOK
Functions when Using an
External Flash
Compatible Flash
Camera Function
AF540FGZ
AF540FGZ II
AF360FGZ
AF360FGZ II
AF201FG
AF200FG
AF160FC
Red-eye reduction flash xx
Auto Flash Discharge
*1
#
*2
#
*2
Automatic switch to the flash sync speed xx
Automatic setting of the aperture value in
G or I mode
#
*2
#
*2
P-TTL auto flash #
*2
#
*2
Slow-speed Sync flash xx
Flash Exposure Compensation xx
AF assist light of the external flash #
*3
×
Trailing Curtain Sync flash
*4
x #
*5
Contrast Control Sync flash #
*6
#
*7
Slave flash #
*6
×
High-speed Sync flash x
×
Wireless flash #
*6
×
7
Appendix
120
*1 Only the R mode is available for the capture mode.
*2 Available only when using a D FA, DA, DA L, FA, FA J, F, or A lens.
(When using a lens with an aperture ring, set the aperture ring to the
9 position.)
*3 AF assist light is not available with the AF540FGZ or AF360FGZ.
*4 Shutter speed of 1/100 seconds or slower.
*5 Not available with the AF200FG or AF160FC.
*6 Multiple AF540FGZ, AF540FGZ II, AF360FGZ, or AF360FGZ II units
are required.
*7 Available only when combined with the AF540FGZ, AF540FGZ II,
AF360FGZ, or AF360FGZ II.
u Caution
• Flashes with the reversed polarity (the center contact on the
hot shoe is minus) cannot be used due to the risk of damaging
the camera and flash.
• Do not combine with accessories that have a different
number of contacts, such as Hot Shoe Grip, as a malfunction
may occur.
• Combining with flashes from other manufacturers may cause
equipment breakdown.
t Memo
• With the AF540FGZ, AF540FGZ II, AF360FGZ, or
AF360FGZ II, you can use the high-speed sync flash to
discharge a flash and take an image at a shutter speed faster
than 1/200 seconds. Set the exposure mode to I, K, or
L.
• By using two or more external flashes (AF540FGZ,
AF540FGZ II, AF360FGZ, or AF360FGZ II), you can use the
wireless mode to shoot in the P-TTL flash mode without
connecting the flash units with a cord. In this case, set the
camera channel on the external flashes.
• You can set the flash sync speed in [X Mode Sync Speed] of
the E5 menu.
• You can connect an external flash
to the camera with a sync cord by
using the X-sync socket. Remove
the sync socket 2P cap to connect
a sync cord to the X-sync socket.
7
Appendix
121
When the optional GPS Unit O-GPS1 is attached to the camera,
GPS information is saved in the shooting information of an
image, and furthermore, the “ASTROTRACER” function can be
used.
You can check the GPS positioning
status on the status screen and Live
View screen.
When an image is taken while the GPS is on, the GPS
information is saved internally in the image file. The GPS
information is not saved in the movie file. You can check the
GPS information in “Detailed Information Display” in the
playback mode. (p.15)
u Caution
• “Electronic Compass”, “Simple Navigation”, and “GPS Time
Sync” cannot be used with this camera.
t Memo
• Refer to the manual of the GPS unit for details on how to
attach the unit and information on the unit’s functions.
• Perform a calibration with the GPS unit before shooting using
[Calibration] in [GPS Settings] of the D4 menu to obtain the
GPS information correctly.
By matching the movement of the Shake Reduction unit built in
the camera with the movement of celestial bodies, celestial
bodies can be captured as individual points even when shooting
with a long exposure setting.
1 Attach the GPS unit to the camera and turn the
camera on.
2 Select [ASTROTRACER] in the A4 menu and
press D.
The [ASTROTRACER] screen appears.
3 Select [ASTROTRACER] and press D.
4 Select a type and press E.
5 Select [Precise Calibration] and press D.
The [Precise Calibration] screen appears.
6 Rotate the camera according to the instruction
displayed on the monitor.
The result of calibration appears.
Using the GPS Unit
3D positioning
2D positioning
No positioning
1 0 : 1 0
10:10
1 /
1/
250
250
1600
F
F
5.6
5.6
SR
0 1 / 0 1 / 2 0 2 1
01/01/2021
9 9 9 9
9999
9 9 9 9
9999
Shooting Celestial Bodies
(ASTROTRACER)
Setting the ASTROTRACER A4
Type 1
Tracks and captures celestial bodies in M
mode using the Shake Reduction function.
Type 2
Tracks and captures celestial bodies with
settings suitable for starscape photography in
M mode using the Shake Reduction function.
Uses SR to track and capture celestial
ASTROTRACER
bodies in B mode.
Enable the GPS unit.
Type 1
Type 2
O
CancelCancel OKOK
7
Appendix
122
7 Press E.
The screen of Step 4 reappears.
If [Calibration failed. Perform calibration again.] appears,
change the camera direction and perform a calibration
again.
8 Press F twice.
The camera returns to the standby mode.
u Caution
• When performing a calibration, be careful not to drop the
camera. Wrap the strap around your wrist or take other
preventive measures.
• If the battery is removed, perform a calibration again after the
battery is put back in.
• As the magnetic field environment varies depending on the
shooting location, [Precise Calibration] must be performed at
each location.
• Changing the lens after performing a calibration may have
some effect on the magnetic field environment. In this case,
perform a calibration again.
1 Set the exposure mode to M.
The ASTROTRACER is ready for use.
2 Set the shooting
conditions.
Available operations
3 Adjust the focus and press 0.
When the timed exposure is enabled, shooting stops
automatically after the set time has elapsed.
When the timed exposure is not set, the exposure continues
while 0 is pressed.
u Caution
• This function cannot be used in combination with some other
functions. (p.115)
• Shooting cannot be performed when the GPS information has
not been obtained by the GPS unit.
When the Monitor Is Too Bright
When shooing in a dark place for a long period of time,
change the [Outdoor View Setting] setting in the D2 menu
to reduce glare.
Also, you can prevent eyes dazzling in dark places by setting
[Night Vision Display] to [On] in the D2 menu.
Shooting with the ASTROTRACER
M Enables/Disables the timed exposure.
Q Changes the exposure time within the range
from 0'01" to 5'00" when the timed exposure
is enabled.
R Changes the aperture value.
J Performs a precise calibration.
Bulb
Bulb
1600
1600
2′30″
F
F
5.6
5.6
SR
9 9 9 9
9999
9 9 9 9
9999
7
Appendix
123
t Memo
• In rare cases, the camera may not operate correctly due to
causes such as static electricity, etc. This can be remedied by
taking the battery out and putting it back in again. If the
camera operates correctly, it does not require any repairs.
Troubleshooting
Problem Cause Remedy
The camera does
not turn on.
The battery is not
installed properly.
Check the orientation of the
battery.
The battery power
is low.
Charge the battery.
The shutter cannot
be released.
There is no
available space on
the memory card.
Insert a memory card with
available space or delete
unwanted images.
Data is being
processed.
Wait until processing is
finished.
The lens aperture
ring is set to a
position other than
9.
Set the lens aperture ring to the
9 position or set [Using
Aperture Ring] to [On] in the E6
menu. (p.118)
[AF Mode] is set to
[Single AF] and
the subject is not
in focus.
Set the focus method to w
and adjust focus manually.
Autofocus does
not work.
The subject is
difficult to focus
on.
v cannot work well for low-
contrast objects (the sky, white
walls, etc.), dark colors,
intricate designs, rapidly-
moving objects, or scenery shot
through a window or a net-like
pattern.
Lock focus on another object
located at the same distance as
your subject, then aim at the
subject and take an image.
Alternatively, use w.
The subject is too
close.
Move away from the subject
and take an image.
The flash does not
discharge.
[Fl as h M o de ] is set
to [Auto Flash
Discharge].
When [Flash Mode] is set to
[Auto Flash Discharge] in the
A2 menu, the flash does not
discharge if the subject is
bright.
Change the [Flash Mode]
setting. (p.77)
The memory card
is not recognized
when the camera
is connected to a
computer.
The [USB Setting]
is set to [CD-
ROM].
Set [USB Setting] to [MTP] in
the D4 menu. (p.97)
Dust or dirt
particles appear in
images.
The CMOS sensor
is dirty or dusty.
Activate [Dust Removal] from
the D6 menu. The Dust
Removal function can be
activated every time the camera
is turned on and off.
Refer to “Sensor Cleaning”
(p.124) if the problem persists.
Pixel defects such
as bright spots
and dark spots
appear in the
image.
There are
defective pixels in
the CMOS sensor.
Activate [Pixel Mapping] from
the D6 menu.
It takes about 30 seconds to
correct the defective pixels, so
be sure to install a fully charged
battery.
Problem Cause Remedy
7
Appendix
124
Raise the mirror up and open the shutter when cleaning the
CMOS sensor with a blower.
1 Turn the camera off and remove the lens.
2 Turn the camera on.
3 Select [Sensor Cleaning] in the D6 menu and
press D.
The confirmation screen appears.
4 Select [Execute] and press E.
The mirror rises up.
5 Clean the CMOS sensor with a blower.
6 Turn the camera off.
The mirror automatically returns to its original position.
u Caution
• Never use a spray blower or a blower with a brush. The
CMOS sensor may be damaged. Do not wipe the CMOS
sensor with a cloth.
• Do not put the tip of the blower inside the lens mount area. If
the power is turned off during cleaning, it may cause damage
to the shutter, the CMOS sensor, and the mirror. Hold the
camera with the lens mount down while cleaning the sensor
so dust will fall away from the sensor when the blower is used.
• When the battery level is low, the message [Not enough
battery power remaining to clean sensor.] is displayed on the
monitor. Install a fully charged battery. If the battery capacity
becomes low during cleaning, a warning beep will sound. In
this case, stop cleaning immediately.
t Memo
• Please contact your nearest service center for professional
cleaning as the CMOS sensor is a precision part.
• You can use the optional Image Sensor Cleaning Kit O-ICK1
when cleaning the CMOS sensor.
Sensor Cleaning
D6
7
Appendix
125
Error Messages
Error Message Description
Memory card full.
The memory card is full and no more
images can be saved. Insert a new
memory card or delete unwanted files.
No image.
There are no images that can be played
back on the memory card.
This image cannot be
displayed.
You are trying to play back an image in a
format not supported by this camera. You
may be able to play it back on a computer.
No card in the camera.
There is no memory card inserted in the
camera.
Memory card error.
The memory card has a problem, and
image capture and playback are
impossible. You may be able to play back
or recover the images on a computer.
Card is not formatted.
The memory card you have inserted is
unformatted or has been previously used
on another device and is not compatible
with this camera. Use the card after
formatting it with this camera.
Card is locked.
The write-protect switch on the memory
card you have inserted is locked. (p.135)
This card cannot be used.
A memory card not compatible with this
camera is inserted.
This image cannot be
magnified.
You are trying to magnify an image that
cannot be magnified.
Not enough battery power
remaining to activate Pixel
Mapping.
The battery level is too low to perform
[Pixel Mapping] or [Sensor Cleaning] of
the D6 menu, or to update the firmware.
Install a fully charged battery.
Not enough battery power
remaining to clean sensor.
Not enough battery power
remaining to update the
firmware.
Not enough battery power
remaining to provide USB
power supply.
The battery level is too low to perform
[USB Power Supply to Ext.] of the D5
menu. Install a fully charged battery.
Unable to update firmware.
There is a problem with the
firmware update file.
The firmware cannot be updated. The
update file is damaged. Try downloading
the update file again.
Image folder cannot be
created.
The maximum folder number (999) is
being used, and no more images can be
saved. Insert a new memory card or
format the card.
Unable to store image.
The image could not be saved because of
a memory card error.
Data process failed.
The operation failed. Try the operation
again.
No image can be
processed.
There are no images with which RAW
images can be developed or Cross
Processing settings can be saved.
This image cannot be
processed.
You are trying to perform C menu
functions for the images captured using
other cameras or perform [Resize] or
[Cropping] for the minimum file-size
images, or the maximum number of digital
filters that can be applied to an image is
reached.
This function cannot
process multiple images
as a batch.
You are trying to perform a playback
function that cannot be performed for
multiple images on the folder display
screen or shooting date display screen.
This function is not
available in the current
mode.
You are trying to set a function that is not
available with the currently selected
capture mode.
The camera will turn off to
prevent damage from
overheating.
The camera will turn off because its
internal temperature is too high. Leave
the camera turned off until it has had time
to cool down before turning on the
camera again.
Turn the lens zoom ring to
the position where
shooting is possible.
Images cannot be taken when a
retractable lens is attached and is not
extended. (p.46)
Error Message Description
7
Appendix
126
Model Description
Image Capture Unit
File Formats
Viewfinder
Live View
LCD Monitor
Main Specifications
Camera
Type TTL autofocus, auto-exposure SLR digital camera
Lens Mount
PENTAX KAF2 bayonet mount (AF coupler, lens
information contacts, K-mount with power contacts)
Compatible
Lenses
KAF4, KAF3, KAF2 (power zoom compatible), KAF,
KA mount lenses
Image Sensor Primary color filter, CMOS, Size: 23.3 × 15.5 (mm)
Effective Pixels Approx. 25.73 megapixels
Total Pixels Approx. 26.78 megapixels
Dust Removal
Image sensor cleaning using ultrasonic vibrations
“DR II”
Sensitivity
(Standard Output)
ISO Auto, Manual ISO range: 100 to 1600000
• EV steps can be set to 1 EV, 1/2 EV, or 1/3 EV.
Image Stabilizer
Sensor-shift Shake Reduction “SR II” (5-axis image
stabilization system), Setting: Auto, Panning, Off
AA Filter
Simulator
Moiré reduction using the SR unit: Off, Low, High,
Bracketing (2 images), Bracketing (3 images)
Recording
Formats
RAW (PEF/DNG), JPEG (Exif 2.3 compliant), DCF
2.0 compliant
Recorded Pixels
JPEG: q (26M: 6192 × 4128)
p (15M: 4752 × 3168)
o (9M: 3648 × 2432)
r (2M: 1920 × 1280)
RAW: (26M: 6192 × 4128)
Quality Level
RAW (14bit): PEF, DNG
JPEG: m (Super Fine), l (Fine), k
(Economy)
• RAW + JPEG simultaneously recordable
Color Space sRGB, AdobeRGB
Storage Media
SD/SDHC*/SDXC* memory cards
* UHS-I/UHS-II compatible (UHS-II is only available
for the memory card inserted in the SD1 slot.)
Dual Card Slots
Sequential Use, Save to Both, Separate RAW/
JPEG, Copying images between slots possible
Storage Folder
Folder Name: Date (100_1018, 101_1019...) or a
user-assigned name (default: PENTX)
Storage File
File Name: User-assigned name (default:
IMGP
)
File No.: Sequential Numbering, Reset
Type Pentaprism finder
Coverage (FOV) Approx. 100%
Magnification Approx. 1.05× (FA 50mm F1.4 at infinity)
Eye-Relief Length
Approx. 20.5 mm (from the view window)
Approx. 22.0 mm (from the center of lens)
Diopter
Adjustment
Approx. -4 to +1 m
-1
Focusing Screen Natural-Bright-Matte III focusing screen
Overlay Items
AF points, Grid display, Electronic level, AF frame,
Spot metering frame, Frame for cropping, Smart
Function icons, Operation Control Lock icon
Type TTL method using the CMOS image sensor
Focusing System
Contrast detection (Auto Area, Zone Select,
Tracking, Select (L, M, S), Spot)
Function Focus Peaking, Face Detection, Touch AF
Display
Field of view: approx. 100%, Magnified view (up to
16×), Grid Display (4×4 Grid, Golden Section, Scale,
Square (L), Square (S), Grid Color: Black, Gray,
White), Histogram, Highlight Alert, Composition
Adjustment
Type
Wide viewing angle TFT color LCD with air-gapless
tempered glass
Size 3.2 inches (aspect ratio 3:2)
Dots Approx. 1620K dots
Touch Panel Capacitance type
Adjustment
Brightness (Auto, Manual), saturation, and colors
adjustable
Outdoor View
Setting
Adjustable ±2 steps
7
Appendix
127
White Balance
Focus System
Exposure Control
Shutter
Drive Modes
External Flash
Capture Functions
Night Vision Display
On, Off
Type
Method using a combination of the CMOS image
sensor and the RGB-Ir sensor
Preset Modes
Auto White Balance, Multi Auto White Balance,
Daylight, Shade, Cloudy, Fluorescent (
D
: Daylight
Color,
N
: Daylight White,
W
: Cool White,
L
: Warm
White), Tungsten,
n
, Manual White Balance (up to
3 settings), Color Temperature (up to 3 settings),
Copying the white balance settings of a captured image
Fine Adjustment Adjustable ±14 steps on A-B axis and G-M axis
Type TTL phase-matching detection autofocus
Focus Sensor
SAFOX13, 101 points (25 cross type focus points in
the center)
Brightness Range
EV -4 to 18 (ISO 100, at normal temperature)
• -4 EV is only available for AF points that support
F2.8 light flux when an F2.8-light-flux compatible
lens is attached.
AF Modes Single AF (AF.S), Continuous AF (AF.C)
Focusing Area
Selection Modes
Auto Area, Zone Select, Select, Expanded Area AF
(S, M, L), Select (S), Spot
AF Assist Light Dedicated LED AF assist light
AE Metering
TTL open-aperture metering using 307K pixel RGB-
Ir sensor
Metering modes: Multi-segment, Center-weighted,
Spot, Highlight-weighted
Metering Range EV -3 to 20 (ISO 100 at 50mm F1.4)
Exposure Modes
Scene Analyze Auto, Program, Sensitivity Priority,
Shutter Priority, Aperture Priority, Shutter & Aperture
Priority, Manual, Bulb, Flash X-sync Speed, USER1,
USER2, USER3, USER4, USER5
EV Compensation ±5 EV (1/3 EV steps or 1/2 EV steps can be selected)
AE Lock
Button type (timer-control: two times the meter
operating time set in customization setting);
continues as long as 0 is halfway pressed.
Type
Electronically controlled vertical-run focal plane shutter
• Electronic shutter is used for Pixel Shift
Resolution.
Shutter Speed
Auto: 1/8000 to 30 seconds, Manual: 1/8000 to 30
seconds (1/3 EV steps or 1/2 EV steps), Bulb (timed
exposure settable: 1 second to 20 minutes)
Mode Selection
Single Frame Shooting, Continuous Shooting (H, M,
L), Bracketing (2, 3, or 5 frames), Depth of Field
Bracketing, Motion Bracketing, Mirror Lock-up
Shooting, Multi-exposure (Average, Additive,
Bright), Interval Shooting, Interval Composite
Timer/Remote
Control
Self-timer (12 or 2 seconds), Remote Control (Now,
3 seconds)
Continuous
Shooting
Max. approx. 12 fps, JPEG (q: m at Continuous
Shooting (H)): Up to approx. 37 frames, RAW: Up to
approx. 32 frames, RAW+: Up to approx. 30 frames
Max. approx. 7.0 fps, JPEG (q: m at
Continuous Shooting (M)): Up to approx. 60 frames,
RAW: Up to approx. 37 frames, RAW+: Up to
approx. 33 frames
Max. approx. 2.5 fps, JPEG (q: m at
Continuous Shooting (L)): Up to approx. 90 frames,
RAW: Up to approx. 39 frames, RAW+: Up to
approx. 37 frames
• When the ISO sensitivity is set to ISO 100
• The continuous shooting speed is slower when
shooting with a high ISO sensitivity.
Flash Modes
Auto Flash Discharge, Auto Flash + Red-eye
Reduction, Flash On, Flash On + Red-eye
Reduction, Slow-speed Sync, Slow-speed Sync +
Red-eye Reduction, P-TTL, Contrast Control Sync*,
High-speed Sync, Wireless Sync*
* Available with two or more dedicated external flash
units
Sync Speed 1/200 seconds
Flash Exposure
Compensation
-2.0 to +1.0 EV
Custom Image
Auto Select, Bright, Natural, Portrait, Landscape,
Vibrant, Radiant, Muted, Flat, Bleach Bypass,
Reversal Film, Monotone, Cross Processing
7
Appendix
128
Movie
Playback Functions
Cross Processing Random, Preset 1 to 3, Favorite 1 to 3
Digital Filter
Extract Color, Replace Color, Toy Camera, Retro,
High Contrast, Shading, Invert Color, Unicolor Bold,
Bold Monochrome, Grainy Monochrome
Clarity -4.0 to +4.0
Skin Tone Type1, Type2
HDR Capture
Auto, Type1, Type2, Type3, Advanced HDR
Bracket Value adjustable
Auto Align: On, Off
Pixel Shift
Resolution
Tripod (Motion Correction On), Tripod (Motion
Correction Off)
Lens Correction
Distortion Correction, Peripheral Illumination
Correction, Lateral Chromatic Aberration
Adjustment, Diffraction Correction
Dynamic Range
Correction
Highlight Correction, Shadow Correction
Noise Reduction
Slow Shutter Speed Noise Reduction, High-ISO
Noise Reduction
Horizon
Correction
SR On: Corrects up to 1 degree
SR Off: Corrects up to 2 degrees
Composition
Adjustment
Adjustment range of ±1.5 mm up, down, left or right
(±1 mm when rotated), Rotating range of ±1 degree
Electronic Level
Viewfinder Display (horizontal direction and vertical
direction), Monitor Display (horizontal direction and
vertical direction)
Program Line
Auto, Standard, Hi-speed Priority, DOF Priority
(Deep), DOF Priority (Shallow), MTF Priority
Recording Format MPEG-4 AVC/H.264 (MOV)
Recorded Pixels/
Frame Rate
z (3840 × 2160, 30p/24p)
x (1920 × 1080, 60p/30p/24p)
Sound
Built-in stereo microphone, external microphone
(stereo recording compatible)
Recording Sound Level adjustable, Wind Noise
Reduction
Recording Time
Up to 4 GB or 25 minutes
Automatically stops recording if the internal
temperature of the camera becomes high
White Balance
Auto White Balance, Daylight, Shade, Cloudy,
Fluorescent (D: Daylight Color, N: Daylight White,
W: Cool White, L: Warm White), Tungsten, n,
Manual White Balance (up to 3 settings), Color
Temperature (up to 3 settings), Copying the white
balance settings of a captured image
Custom Image
Auto Select, Bright, Natural, Portrait, Landscape,
Vibrant, Radiant, Muted, Flat, Bleach Bypass,
Reversal Film, Monotone, Cross Processing
Cross Processing Random, Preset 1 to 3, Favorite 1 to 3
Digital Filter
Extract Color, Replace Color, Retro, High Contrast,
Invert Color, Unicolor Bold, Bold Monochrome
Playback View
Single image, Multi-image display (20, 48, and 70
thumbnails), Image magnification (Up to 16×, 100%
display, Quick Zoom, and Focus Magnification), Grid
(4×4 Grid, Golden Section, Scale, Square (L),
Square (S), Grid Color: Black, Gray, White), Rotated
image display, Histogram display (Y histogram, RGB
histogram), Highlight Alert display, Auto image
rotation, Detailed information display, Copyright
Information display (Photographer, Copyright
Holder), GPS information (Latitude, Longitude,
Altitude, Coordinated Universal Time (UTC)),
Direction, Folder display, Shooting date display
Delete
Single image, All images, Selected images, Folder,
Images on the selected shooting date, Instant
Review image
Digital Filter
Base Parameter Adj, Extract Color, Replace Color,
Toy Camera, Retro, High Contrast, Shading, Invert
Color, Unicolor Bold, Tone Expansion, Bold
Monochrome, Grainy Monochrome, Miniature, Soft,
Fish-eye, Slim, Monotone, Frame Composite
RAW
Development
Development options: Single image, Multiple images,
Folder, Images on the selected shooting date
Development parameters: White Balance, Custom
Image, Sensitivity, Digital Filter, Clarity, Skin Tone, HDR
Capture, Pixel Shift Resolution, Distortion Correction,
Peripheral Illumination Correction, Lateral Chromatic
Aberration Adjustment, Diffraction Correction, Color
Fringe Correction, High-ISO Noise Reduction, Shadow
Correction, File Format (JPEG, TIFF), JPEG Recorded
Pixels, JPEG Quality, Aspect Ratio, Color Space
7
Appendix
129
Customization
Power Supply
Interfaces
Wireless LAN
Bluetooth
®
Dimensions and Weight
Operating Environment
Included Accessories
Editing Features
Protect, Image Rotation, Image Copy, File Transfer,
Save RAW Data, Resize, Cropping (aspect ratio can
be changed and tilt correction is available), Levels
Adjustment, White Balance Adjustment, Color Moiré
Correction, Extract Movie, Divide Movie, Save Movie
Frame as Image
Customizable
Items
User Mode, Fx Button, AF/AE Lock Settings,
Preview Dial, E-Dial Programming, Smart Function,
Touch Panel, Eye Sensor, Viewfinder Display, LCD
Panel, Monitor Display, Instant Review, Zoom
Review, Warning Display, Control Panel, Memory,
EV Steps, ISO Sensitivity Steps, Color Temperature
Steps, Focal Length Input, Save Rotation
Information, Aperture Information Record, AF Fine
Adjustment, Copyright Information
Language
21 languages: Japanese, English, French, German,
Spanish, Portuguese, Italian, Dutch, Danish,
Swedish, Finnish, Polish, Czech, Hungarian,
Turkish, Greek, Russian, Thai, Korean, Traditional
Chinese, Simplified Chinese
Battery Type Rechargeable Lithium-ion Battery D-LI90
AC Adapter AC Adapter Kit K-AC166 (optional)
Battery Life
Number of recordable images: Approx. 800 images
Playback time: Approx. 250 minutes
• Tested in compliance with CIPA standard using a
fully charged lithium-ion battery at a temperature
of 23°C (73°F). Actual results may vary depending
on the shooting conditions/circumstances.
Connection Port
USB terminal (USB Type-C), Cable release terminal
(2.5 mm dia.), X-sync socket, HDMI
®
terminal (Type
D), Microphone terminal, Headphone terminal
USB Connection
USB 3.2 Gen 1
Data transfer: MTP, CD-ROM
Battery recharge, Power supply to the camera (when
the dedicated AC adapter is used)
Standards IEEE 802.11b/g/n (standard wireless LAN protocol)
Frequency
(Center
Frequency)
2412 to 2462 MHz (channels: Ch 1 to Ch 11)
Security
Authentication: WPA2
Encryption: AES
Standards Bluetooth
®
v4.2 (Bluetooth Low Energy)
Frequency
(Center
Frequency)
2402 to 2480 MHz (channels: Ch 0 to Ch 39)
Dimensions
Approx. 134.5 mm (W) × 103.5 mm (H) × 73.5 mm
(D) (5.3 in. (W) × 4.1 in. (H) × 2.9 in. (D)) (excluding
protrusions)
Weight
Approx. 820 g (28.9 oz) (including the dedicated
battery and an SD Memory Card)
Approx. 735 g (25.9 oz) (body only)
Temperature -10 to 40°C (14 to 104°F)
Humidity 85% or less (no condensation)
Package
Contents
Strap O-ST162, ME Viewfinder Cap, Rechargeable
Lithium-ion Battery D-LI90, USB Power Adapter,
Power Plug, USB Cable I-USB166
<Mounted to the camera> Eyecup FU, Hot shoe
cover FK, Sync socket 2P cap, Body mount cap KII,
Battery grip terminal cover
Software Digital Camera Utility 5
USB Power Adapter AC-U1/AC-U2
Power Supply 100 to 240 VAC (50/60 Hz), 0.2 A
Output 5.0 VDC, 1000 mA, 5.0 W
Average Active
Efficiency
76.8%
No-Load Power
Consumption
50 mW
Temperature 10 to 40°C (50 to 104°F)
Dimensions
42.5 mm (W) × 22 mm (H) × 66.5 mm (D) (1.7 in. (W)
× 0.9 in. (H) × 2.6 in. (D)) (excluding the power plug)
Weight Approx. 40 g (1.4 oz) (excluding the power plug)
7
Appendix
130
(When using the fully charged battery)
• The image storage capacity (normal recording) is based on measuring
conditions in accordance with CIPA standards, while other data is based
on our measuring conditions. Some deviation from the above figures
may occur in actual use depending on the selected capture mode and
shooting conditions.
(When using an 8 GB memory card)
• The number of storable images may vary depending on the subject,
shooting conditions, selected capture mode, memory card, etc.
We recommend the following system requirements to connect
the camera to a computer and to use the software.
t Memo
• Application software that supports the MOV format is required
to play back movie files transferred to a computer.
Approximate Image Storage Capacity and
Playback Time
Battery Temperature Normal Shooting Playback Time
D-LI90 23°C (73°F) 800 250 minutes
Approximate Image Storage Capacity by Size
Recorded Pixels
JPEG Quality
RAW
m l k
q 26M
495 1120 2190 141
p 15M
837 1872 3607 —
o 9M
1401 3105 5840 —
r 2M
4717 9812 16353 —
Operating Environment for USB Connection
and Provided Software
Windows
®
OS
Windows
®
10 (FCU, CU) (32-bit, 64-bit) or
Windows
®
8.1 (32-bit, 64-bit)
CPU Intel
®
Core™ i5 or higher
RAM 8 GB or more
HDD
For installing and starting up the program:
Approx. 100 MB or more of available space
For saving image files: Approx. 15 MB/file (JPEG),
Approx. 50 MB/file (RAW)
Monitor 1280 × 1024 dots, 24-bit full color or higher
Mac
OS
macOS 11.0 Big Sur, macOS 10.15 Catalina,
macOS 10.14 Mojave, macOS 10.13 High Sierra,
or macOS 10.12 Sierra
CPU Intel
®
Core™ i5 or higher
RAM 8 GB or more
HDD
For installing and starting up the program:
Approx. 100 MB or more of available space
For saving image files: Approx. 15 MB/file (JPEG),
Approx. 50 MB/file (RAW)
Monitor 1280 × 1024 dots, 24-bit full color or higher
7
Appendix
131
Symbols
A menus ........................ 22
B menus ........................ 25
C menus ........................ 27
E menus ......................... 28
D menus......................... 34
B mode.......................... 54
A/K/B dial ................. 44
Numerics
1× image display ............. 47
1st Frame Action in AF.C
........................................ 61
A
AC Adapter ...................... 41
Action in AF.C Continuous
Shooting .......................... 61
Action When AF Fails ...... 61
AdobeRGB ...................... 48
Advanced mode .............. 53
AE Metering..................... 59
AF Active Area (contrast
detection autofocus) ........ 63
AF Active Area (phase-
matching detection
autofocus)........................ 60
AF Area Restriction ......... 61
AF Assist Light ............ 9, 60
AF coupler ......................... 9
AF Fine Adjustment ......... 64
AF Frame .................. 45, 46
AF Mode .......................... 60
AF point ........................... 61
AF point selector lever..... 61
AF Point Tracking in AF.C
........................................ 62
AF with Live View ............ 62
AF with Remote Control .. 74
AF with Viewfinder........... 60
AF.S Setting .................... 61
AF/AE Lock Settings
.......................... 45, 59, 104
Anti-Aliasing Filter Simulator
........................................ 82
Aperture Priority AE......... 50
Aperture value ................. 50
Aspect Ratio .............. 92, 94
ASTROTRACER ........... 121
Auto Adjustment for Set Light
Source ............................. 75
Auto Area (contrast detection
autofocus)........................ 63
Auto Area (phase-matching
detection autofocus) ........ 60
Auto Display Rotation .... 108
Auto EV Compensation
.................................. 23, 51
Auto Flash Discharge ...... 77
Auto Horizon Correction .. 84
Auto Image Rotation........ 85
R mode.................... 44
Auto Power Off ................ 42
Auto Select (Custom Image)
........................................ 78
Auto Shake Reduction Off
........................................ 83
Auto White Balance (White
Balance) .......................... 74
Auto White Balance under
Tungsten Light................. 75
Autofocus ........................ 59
J bracketing ................. 68
AV device ........................ 87
J mode......................... 50
B
M mode ........................... 53
Base Parameter Adjustment
(Digital Filter) ................... 91
Battery ............................. 38
Battery grip ...................... 39
Battery grip contacts.......... 9
Battery Grip Settings
.................................. 39, 40
Bleach Bypass (Custom
Image) ............................. 78
Bluetooth
®
....................... 99
Bold Monochrome (Digital
Filter) ......................... 79, 91
Bracketing ....................... 67
Bracketing Order ............. 67
Bright (Custom Image) .... 78
Brightness adjustment
.................................. 13, 80
Bulb ................................. 53
Bulb (B) Mode Options .... 53
Bulb exposure ........... 50, 53
Button .............................. 10
C
Cable switch terminal ........ 9
Calibration ..................... 121
Capture mode.................. 49
Card................................. 41
Card access lamp.............. 9
Card Slot Sequence ........ 48
Catch-in Focus ................ 62
CD-ROM.......................... 97
Center-weighted metering
........................................ 59
Changing display ............. 14
Changing the image size
........................................ 93
Charging the battery ........ 39
Charging time .................. 40
Clarity .............................. 83
Cleaning ........................ 124
Cloudy (White Balance)... 74
Color Fringe Correction ... 92
Color Moiré Correction .... 95
Color Settings .......... 43, 108
Color Space..................... 48
Color Temperature (White
Balance) .......................... 76
Color Temperature Steps
........................................ 76
Composition Adjustment.. 84
Computer......................... 97
Continuous AF................. 60
Continuous Shooting ....... 67
Contrast Detection AF
Release Options .............. 64
Contrast detection autofocus
.................................. 59, 62
Control Panel..... 13, 20, 106
Copyright Holder............ 114
Copyright Information .... 114
Correcting images ........... 80
Create New Folder ........ 111
Crop................................. 48
Cropping .......................... 94
Cross Processing (Custom
Image) ............................. 78
CTE ................................. 74
Custom Image ................. 78
Customization................ 102
Customization menus ...... 28
Index
7
Appendix
132
D
Date Adjustment.............. 43
Daylight (White Balance)
........................................ 74
Delete ........................ 47, 88
Delete All Images ............ 88
Deleting selected images
........................................ 86
Depth of field ................... 65
Depth of Field Bracketing
........................................ 68
Detailed information display
........................................ 15
Developing RAW images
........................................ 92
Dial .................................. 10
Dial indicator.................... 44
Diffraction Correction....... 81
Digital Camera Utility 5
.................................. 93, 98
Digital Filter ............... 79, 91
Digital Preview................. 65
Diopter adjustment dial.... 17
Direct keys....................... 18
Distortion Correction........ 81
Divide Movie.................... 96
DNG ................................ 48
Drive mode ...................... 66
Dust Removal ................ 123
Dynamic range ................ 80
Dynamic Range Correction
........................................ 80
E
E-Dial Programming ...... 104
Editing images ................. 91
Electronic level ................ 18
Electronic Level Type
.............................. 107, 108
Error messages ............. 125
EV Compensation ........... 54
EV Steps ......................... 51
Exif data ........................ 114
Expanded Area AF (phase-
matching detection
autofocus)........................ 60
Exposure in User Mode
...................................... 101
Exposure mode ............... 50
Exposure Simulation Live
View................................. 51
External flash................. 119
Extract Color (Digital Filter)
.................................. 79, 91
Extract Movie................... 96
Eye Sensor .............. 17, 107
F
Face Detection ................ 64
Face Priority AE .............. 59
File Format ...................... 48
File Name ...................... 113
File Transfer .................... 90
Filter .......................... 79, 91
Firmware Info/Options ..... 36
Fish-eye (Digital Filter) .... 91
Flash........................ 77, 119
Flash compensation ........ 77
Flash Mode...................... 77
Flash On .......................... 77
Flash X-sync Speed ........ 50
Flat (Custom Image)........ 78
Flicker Reduction........... 108
Fluorescent - Cool White
(White Balance) ............... 74
Fluorescent - Daylight Color
(White Balance) ............... 74
Fluorescent - Daylight White
(White Balance) ............... 74
Fluorescent - Warm White
(White Balance) ............... 74
Focal length input .......... 119
Focus Magnification ...... 109
Focus method.................. 59
Focus method switch
.................................. 44, 59
Focus Peaking................. 64
Folder display .................. 87
Folder Name.................. 112
Format ............................. 43
Four-way controller.... 11, 18
Frame Composite (Digital
Filter) ............................... 91
Framerate ........................ 49
Fx Button ....................... 102
G
GPS ............................... 121
GPS Settings ................. 121
Grainy Monochrome (Digital
Filter) ......................... 79, 91
Grid Guide ..................... 108
H
HDMI
®
terminal ............... 87
HDR Capture ................... 81
Headphone ...................... 56
Headphone Volume......... 49
High Contrast (Digital Filter)
.................................. 79, 91
High-ISO Noise Reduction
........................................ 58
Highlight Correction ......... 80
Highlight-weighted metering
........................................ 59
Hold AF Status ................ 61
Hot shoe .......................... 77
Hyper manual .................. 52
HYPER P/Sv Options .... 105
Hyper program ................ 52
I
Image Capture Settings... 48
Image Copy ..................... 90
Image finishing tone ........ 78
Image plane indicator ........ 9
Image storage capacity
...................................... 130
Image Sync...................... 99
IMAGE Transmitter 2....... 98
Indicator Lamps ............. 110
Information Display Outside
Field of View ............ 17, 107
Initial settings................... 42
Instant Review ......... 45, 109
Interval Composite........... 72
Interval Shooting.............. 71
Invert Color (Digital Filter)
.................................. 79, 91
ISO Auto Lower Limit....... 57
ISO Auto Upper Limit....... 57
ISO Auto with Minimum
Shutter Speed.................. 57
ISO sensitivity.................. 57
ISO Sensitivity Setting ..... 57
ISO Sensitivity Steps ....... 57
J
JPEG ............................... 48
JPEG Quality ................... 48
JPEG Recorded Pixels .... 48
K
Kelvin............................... 76
L
Landscape (Custom Image)
........................................ 78
Language setting ............. 43
Language/W ................ 42
Lateral Chromatic Aberration
Adjustment....................... 81
LCD Panel ............... 16, 108
7
Appendix
133
Length Input on Startup
...................................... 119
Lens......................... 37, 116
Lens Correction ............... 81
Lens focal length ........... 119
Lens information contacts
.......................................... 9
Lens mount index ........ 9, 37
Lens unlock button .......... 37
Lens with aperture ring.. 118
Levels Adjustment ........... 94
Lever ............................... 10
Link Exposure and Focus
Point ................................ 59
Live View ................. 12, 108
Low-pass filter ................. 82
LV Shooting Touch AF .... 51
M
L mode .......................... 50
Mac................................ 130
Magnifying the image
............................ 45, 46, 47
Manual Exposure ............ 50
Manual focus ................... 59
Manual White Balance .... 76
ME viewfinder cap ........... 73
Memory ......................... 111
Memory card ................... 41
Memory Card Options ..... 48
Menu ............................... 20
Meter Operating Time ..... 17
MF Lens Focal Length... 119
Microphone.................. 9, 56
Miniature (Digital Filter) ... 91
Minimum Shutter Speed.. 57
Minimum Shutter Speed
Options ............................ 57
Mired ............................... 76
Mirror ................................. 9
Mirror Lock-up Shooting .. 69
Mirror Up ......................... 69
Mode dial ......................... 44
Mode dial lock button ...... 44
Mode dial lock release lever
........................................ 45
Moiré reduction................ 82
Monitor ............................ 12
Monitor Adjustment
................................ 13, 109
Monitor Display.............. 108
Monitor Touch Operation
........................................ 15
Monotone (Custom Image)
........................................ 78
Monotone (Digital Filter) .. 91
Motion Bracketing............ 69
Mount names................. 117
Movie Capture Settings ... 49
Movie Edit........................ 96
Movie mode ..................... 54
Movie Mode AF ............... 64
Movie setting menus ....... 25
Movie Touch AF .............. 55
MTP ................................. 97
Multi Auto White Balance
(White Balance) ............... 74
Multi-exposure ................. 70
Multi-image display.......... 85
Multi-segment metering ... 59
Muted (Custom Image).... 78
N
Natural (Custom Image) .. 78
Night Vision Display ........ 13
Noise Reduction ........ 52, 58
O
One Push Exposure Reset
........................................ 54
One Push File Format ... 103
One Push ISO Auto ......... 57
One-Push Bracketing ...... 67
Operating environment .. 130
Operation Control Lock ... 46
Optical Preview ............... 65
Outdoor View Setting
................................ 13, 122
P
G mode .......................... 50
PEF ................................. 48
Peripheral Illumination
Correction ........................ 81
Phase-matching detection
autofocus ......................... 59
Photographer................. 114
Pixel Mapping ................ 123
Pixel Shift Resolution ...... 82
Playback card ............ 47, 85
Playback function selection
screen.............................. 85
Playback Info Display
................................ 14, 108
Playback mode ................ 47
Playback Order Options .. 85
Playback setting menus .. 27
Playback Sound Volume
.................................. 56, 85
Portrait (Custom Image) .. 78
Power .............................. 42
Power Saving Mode ........ 40
Preview............................ 65
Preview Method............... 65
Processing images .......... 91
Program AE ..................... 50
Program Line ................... 52
Protect ............................. 89
Provided software.......... 130
Q
Quality ............................. 48
Quality level adjustment .. 82
Quick Zoom ............. 47, 109
R
Radiant (Custom Image)
........................................ 78
RAW ................................ 48
RAW Development .......... 92
RAW File Format ............. 48
Recall User Mode Setting
...................................... 101
Recorded Pixels ........ 48, 49
Recording Sound Level ... 49
Red-eye reduction ........... 77
Reducing blurring of images
........................................ 83
Remote Control ............... 73
Remote control receiver .... 9
Rename User Mode ...... 100
Replace Color (Digital Filter)
.................................. 79, 91
Reset ............................... 21
Reset (memory card)....... 43
Reset Numbering........... 113
Reset User Mode Settings
...................................... 100
Reseting the menu .......... 21
Resize.............................. 93
Retractable lens............... 46
Retro (Digital Filter) ... 79, 91
Reversal Film (Custom
Image) ............................. 78
Rotating images............... 89
Rotation Direction .......... 105
S
Save as Manual White
Balance............................ 76
Save Cross Processing ... 79
Save RAW Data .. 45, 47, 91
Save Rotation Info ........... 89
7
Appendix
134
Save User Mode Settings
...................................... 100
Scene Analyze Auto mode
........................................ 44
SD Memory Card............. 41
Select (contrast detection
autofocus)........................ 63
Select (phase-matching
detection autofocus) ........ 60
Self-timer ......................... 73
Self-timer lamp .................. 9
Sensitivity .................. 57, 92
Sensitivity Priority AE ...... 50
Sensor Cleaning............ 124
Sequential Numbering ... 113
Setup menus ................... 34
Shade (White Balance) ... 74
Shading (Digital Filter)
.................................. 79, 91
Shadow Correction .......... 80
Shake Reduction ............. 83
Sharpness (Custom Image)
........................................ 78
Shooting .......................... 44
Shooting celestial bodies
...................................... 121
Shooting date display ...... 87
Shooting Info Display .... 108
Shooting with Live View .. 46
Shooting with viewfinder.. 44
Shutter & Aperture Priority
AE.................................... 50
Shutter Priority AE........... 50
Shutter speed .................. 50
Single AF ......................... 60
Single Frame Shooting.... 66
Single image display
.................................. 14, 47
Skin Tone ........................ 83
Slim (Digital Filter) ........... 91
Slow Shutter Speed Noise
Reduction ........................ 52
Slow-speed Sync............. 77
Smart Function ........ 19, 106
Soft (Digital Filter)............ 91
Sound .............................. 54
Sound Effects ................ 110
Speaker ............................. 9
Specifications ................ 126
Spot (contrast detection
autofocus)........................ 63
Spot (phase-matching
detection autofocus) ........ 61
Spot metering .................. 59
sRGB............................... 48
Status screen .......... 12, 108
Still image setting menus
........................................ 22
Still image/Live View/Movie
selector dial ..................... 44
Store Cursor Position ...... 21
Strap ................................ 37
Subject Recognition ........ 62
Supplying power .............. 40
H mode ........................ 50
Sync socket 2P cap ....... 120
T
K mode ........................ 50
Tethered shooting ........... 98
Text entry ...................... 100
Texture adjustment.......... 82
Thumbnail display ..... 47, 85
TIFF ................................. 92
Time ................................ 53
Timed exposure............... 53
Tone Expansion (Digital
Filter) ......................... 79, 91
Touch Image Browse Effect
........................................ 85
Toy Camera (Digital Filter)
.................................. 79, 91
Tracking (contrast detection
autofocus)........................ 63
Tripod socket ..................... 9
Tungsten (White Balance)
........................................ 74
I bracketing ................. 69
I mode......................... 50
U
Unicolor Bold (Digital Filter)
.................................. 79, 91
USB connection....... 97, 130
USB Power Supply to
External Device ............... 40
USB Setting ..................... 97
USB terminal ............. 39, 97
User registration ................ 7
User Settings Restoration
...................................... 101
Using Aperture Ring ...... 118
V
Vertical position ............... 13
Vibrant (Custom Image) .. 78
Viewfinder........................ 16
Viewfinder Display ... 17, 107
Viewfinder Light ............. 107
Viewfinder Screen ......... 107
Volume ............................ 35
Volume label.................... 43
W
Warning Display ............ 110
WARRANTY POLICY.... 138
White Balance ................. 74
White Balance Adjustment
........................................ 95
Wind Noise Reduction ..... 49
Windows
®
...................... 130
Wireless LAN................... 99
X
N mode .......................... 50
X Mode Sync Speed
................................ 50, 120
X-sync socket ................ 120
Z
Zone Select (contrast
detection autofocus) ........ 63
Zone Select (phase-matching
detection autofocus) ........ 60
Zoom Review................. 109
7
Appendix
135
• When the camera has not been used for a long time, confirm that it is still
working properly, particularly prior to taking important images (such as
at a wedding or when traveling). Contents of the recording cannot be
guaranteed if recording, playback, or transferring your data to a
computer, etc. is not possible due to a malfunction of your camera or
recording media (memory cards), etc.
• To keep the battery in optimum condition, avoid storing it in a fully
charged state or in high temperatures.
• If the battery is left inserted and the camera is not used for a long time,
the battery will over-discharge and shorten the battery’s life.
• Charging the battery a day before use or on the day of use is
recommended.
• Do not subject the camera to high temperatures or high humidity. Do not
leave the camera in a vehicle, as the temperature can get very high.
• Do not subject the camera to strong vibrations, shocks, or pressure. Use
a cushion to protect the camera from vibrations of motorcycles,
automobiles, or ships.
• The temperature range for camera use is -10°C to 40°C (14°F to 104°F).
• The monitor may appear black at high temperatures, but will return to
normal at normal temperatures.
• The monitor may respond more slowly at low temperatures. This is due
to liquid crystal properties, and is not a malfunction.
• Sudden temperature changes will cause condensation on the inside and
outside of the camera. Place the camera in your bag or a plastic bag,
and remove it after temperatures of the camera and surroundings are
equalized.
• Avoid contact with garbage, mud, sand, dust, water, toxic gases, or salt.
These could cause the camera to breakdown. Wipe the camera to dry
off any rain or water drops.
• Do not press on the monitor with excessive force. This could cause it to
break or malfunction.
• Be careful not to overtighten the screw in the tripod socket when using
a tripod.
• Do not clean the camera with organic solvents such as thinner, alcohol,
and benzine.
• Use a lens brush to remove dust accumulated on a lens. Never use a
spray blower for cleaning as it may damage the lens.
• Please contact your nearest service center for professional cleaning of
the CMOS sensor. (This will involve a fee.)
• Periodic inspections are recommended every one to two years to
maintain high performance.
• Do not store the camera with preservatives or chemicals. Storage in high
temperatures and high humidity can cause mold to grow on the camera.
Remove the camera from its case and store it in a dry and well-ventilated
place.
• Avoid using or storing the camera where it may be exposed to static
electricity or electrical interference.
• Avoid using or storing the camera in direct sunlight or in locations where
it may be exposed to rapid changes in temperature or to condensation.
• The SD Memory Card is
equipped with a write-protect
switch. Setting the switch to
LOCK prevents new data from
being recorded on the card, the
stored data from being deleted,
and the card from being
formatted by the camera or
computer.
• The SD Memory Card may be
hot when removing the card immediately after using the camera.
•
Do not remove the SD Memory Card or turn off the power while the card
is being accessed. This may cause the data to be lost or the card to be
damaged.
• Do not bend the SD Memory Card or subject it to violent impact. Keep it
away from water and store away from high temperatures.
• Do not remove the SD Memory Card while formatting. The card may be
damaged and become unusable.
• Data on the SD Memory Card may be deleted in the following
circumstances. We do not accept any liability for data that is deleted if
1. the SD Memory Card is mishandled by the user;
2. the SD Memory Card is exposed to static electricity or electrical
interference;
3. the SD Memory Card has not been used for a long time;
Care to be Taken During Handling
Before Using Your Camera
About the Battery and Charger
Precautions on Carrying and Using Your Camera
Cleaning Your Camera
Storing Your Camera
About SD Memory Cards
Write-protect
switch
7
Appendix
136
4. the SD Memory Card or the battery is removed while the card is being
accessed.
• If the SD Memory Card is not used for a long time, the data on the card
may become unreadable. Be sure to regularly make a backup of
important data on a computer.
• Format new SD Memory Cards. Also format SD Memory Cards
previously used with other cameras.
• Please note that deleting data stored on an SD Memory Card, or
formatting an SD Memory Card does not completely erase the original
data. Deleted data can sometimes be recovered using commercially
available software. If you are going to discard, give away, or sell your SD
Memory Card, you should ensure that the data on the card is completely
deleted or the card itself is destroyed if it contains any personal or
sensitive information.
• The data on your SD Memory Card should be managed at your own risk.
• Microsoft and Windows are registered trademarks of Microsoft
Corporation in the United States of America and other countries.
• Mac and macO S are trademarks of Apple Inc., registered in t he U.S. and
other countries.
• IOS is a trademark or registered trademark of Cisco in the U.S. and
other countries and is used under license.
• Intel and Intel Core are trademarks of Intel Corporation in the U.S. and/
or other countries.
• SDXC Logo is a trademark of SD-3C, LLC.
• The Bluetooth word mark and logos are registered trademarks owned by
Bluetooth SIG, Inc., and any use of such marks by Ricoh Company, Ltd.
is under license.
• USB Type-C is a trademark of USB Implementers Forum.
• This product includes DNG technology under license by Adobe Systems
Incorporated.
• The DNG logo is either a registered trademark or trademark of Adobe
Systems Incorporated in the United States and/or other countries.
• HDMI, the HDMI logo and High-Definition Multimedia Interface are
trademarks or registered trademarks of HDMI Licensing, LLC in the
United States and/or other countries.
All other trademarks are the property of their respective owners.
• This product uses the RICOH RT font designed by Ricoh Company Ltd.
• This product supports PRINT Image Matching III. PRINT Image
Matching-enabled digital still cameras, printers, and software help
photographers to produce images more faithful to their intentions. Some
functions are not available on printers that are not PRINT Image
Matching III compliant.
Copyright 2001 Seiko Epson Corporation. All Rights Reserved. PRINT
Image Matching is a trademark of Seiko Epson Corporation. The PRINT
Image Matching logo is a trademark of Seiko Epson Corporation.
Trademarks
7
Appendix
137
This product is licensed under the AVC Patent Portfolio License for the
personal use of a consumer or other uses in which it does not receive
remuneration to (i) encode video in compliance with the AVC standard
(“AVC video”) and/or (ii) decode AVC video that was encoded by a
consumer engaged in a personal activity and/or was obtained from a video
provider licensed to provide AVC video. No license is granted or shall be
implied for any other use.
Additional information may be obtained from MPEG LA, L.L.C.
See http://www.mpegla.com.
This camera includes the open source software (OSS) licensed under the
GNU General Public License (GPL), GNU Lesser General Public License
(LGPL), and/or other licenses. The information about licenses of each
OSS used in the camera is saved in the camera internal memory as a text
file. Connect the camera to a computer, access the “oss_license” folder,
and open each text file to read the license terms.
The source codes of OSS used in the camera are disclosed under the
license terms of GPL, LGPL, etc. If you need the source codes, access the
following URL.
http://www.ricoh-imaging.co.jp/english/products/oss/
This product includes software licensed under the BSD License. BSD
license is a form of license which permits the redistribution of the software
provided that it is clearly stated that use is unwarranted, and a copyright
notice and a list of licensing conditions are provided. The following
contents are displayed based on the abovementioned licensing conditions
and are not for the purpose of restricting your use of the product, etc.
Tera Term
Copyright (C) 1994-1998 T. Teranishi
(C) 2004-2018 TeraTerm Project
All rights reserved.
Redistribution and use in source and binary forms, with or without
modification, are permitted provided that the following conditions are met:
1. Redistributions of source code must retain the above copyright notice,
this list of conditions and the following disclaimer.
2. Redistributions in binary form must reproduce the above copyright
notice, this list of conditions and the following disclaimer in the
documentation and/or other materials provided with the distribution.
3. The name of the author may not be used to endorse or promote
products derived from this software without specific prior written
permission.
THIS SOFTWARE IS PROVIDED BY THE AUTHOR “AS IS” AND ANY
EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT
LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN
NO EVENT SHALL THE AUTHOR BE LIABLE FOR ANY DIRECT,
INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR
CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO,
PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF
USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION)
HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER
IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING
NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE
USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY
OF SUCH DAMAGE.
AVC Patent Portfolio License
Announcement about the Open Source Software
Announcement on the Use of BSD-Licensed Software
7
Appendix
138
All our cameras purchased through authorized bona fide
photographic distribution channels are guaranteed against
defects of material or workmanship for a period of twelve
months from the date of your purchase. Service will be
rendered, and defective parts will be replaced without cost to
you within that period, provided the camera does not show
evidence of impact, sand or liquid damage, mishandling,
tampering, battery or chemical corrosion, operation contrary to
operating instructions, or modification by an unauthorized repair
shop. The manufacturer or its authorized representatives shall
not be liable for any repair or alterations except those made with
its written consent and shall not be liable for damages from
delay or loss of use or from other indirect or consequential
damages of any kind, whether caused by defective material or
workmanship or otherwise; and it is expressly agreed that the
liability of the manufacturer or its representatives under all
guarantees or warranties, whether expressed or implied, is
strictly limited to the replacement of parts as hereinbefore
provided. No refunds will be made on repairs by non-authorized
service facilities.
Procedure During 12-month Warranty Period
Any camera which proves defective during the 12-month
warranty period should be returned to the dealer from whom you
purchased the camera or to the manufacturer. If there are no
representatives of the manufacturer in your country, send the
camera to the manufacturer, with postage prepaid. In this case,
it will take a considerable length of time before the camera can
be returned to you owing to the complicated customs
procedures required. If the camera is covered by warranty,
repairs will be made and parts replaced free of charge, and the
camera will be returned to you upon completion of servicing. If
the camera is not covered by warranty, regular charges of the
manufacturer or of its representatives will apply. Shipping
charges are to be borne by the owner. If your camera was
purchased outside of the country where you wish to have it
serviced during the warranty period, regular handling and
servicing fees may be charged by the manufacturer’s
representatives in that country. Notwithstanding this, your
camera returned to the manufacturer will be serviced free of
charge according to this procedure and warranty policy. In any
case, however, shipping charges and customs clearance fees
to be borne by the sender. To prove the date of your purchase
when required, please keep the receipt or bills covering the
purchase of your camera for at least a year. Before sending
your camera for servicing, please make sure that you are
sending it to the manufacturer’s authorized representatives or
their approved repair shops, unless you are sending it directly
to the manufacturer. Always obtain a quotation for the service
charge, and only after you accept the quoted service charge,
instruct the service station to proceed with the servicing.
• This warranty policy does not affect the customer’s
statutory rights.
• The local warranty policies available from our
distributors in some countries can supersede this
warranty policy. Therefore, we recommend that you
review the warranty card supplied with your product at
the time of purchase, or contact our distributor in your
country for more information and to receive a copy of
the warranty policy.
WARRANTY POLICY
7
Appendix
139
For Customers in USA
STATEMENT OF FCC COMPLIANCE
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept
any interference received, including interference that may
cause undesired operation.
FCC CAUTION:
Changes or modifications not approved by the party responsible
for compliance could void the user’s authority to operate the
equipment.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
The available scientific evidence does not show that any health
problems are associated with using low power wireless devices.
There is no proof, however, that these low power wireless
devices are absolutely safe. Low power Wireless devices emit
low levels of radio frequency energy (RF) in the microwave
range while being used. Whereas high levels of RF can produce
health effects (by heating tissue), exposure of low-level RF that
does not produce heating effects causes no known adverse
health effects. Many studies of low-level RF exposures have not
found any biological effects. Some studies have suggested that
some biological effects might occur, but such findings have not
been confirmed by additional research. R03010 has been
tested and found to comply with FCC radiation exposure limits
set forth for an uncontrolled environment and meets the FCC
radio frequency (RF) Exposure Guidelines.
Declaration of Conformity
According to 47CFR, Parts 2 and 15 for
Class B Personal Computers and Peripherals
We: RICOH IMAGING AMERICAS
CORPORATION
Located at: 2 Gatehall Drive Suite 204,
Parsippany, New Jersey 07054,
U.S.A.
Phone: 800-877-0155
Declare under sole responsibility that the product identified
herein complies with 47CFR Parts 2 and 15 of the FCC rules as
a Class B digital device. Each product marketed is identical to
the representative unit tested and found to be compliant with the
standards. Records maintained continue to reflect the
equipment being produced can be expected to be within the
variation accepted, due to quantity production and testing on the
statistical basis as required by 47CFR §2.909. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) This device must accept
any interference received, including interference that may
cause undesired operation. The above named party is
responsible for ensuring that the equipment complies with the
standards of 47CFR §15.101 to §15.109.
Product Name:
Digital Camera
Model Number: R03010
Contact Person: Customer Service Manager
Date and Place: September, 2020 Parsippany
7
Appendix
140
For Customers in Canada
Innovation, Science and Economic Development Canada
(ISED) Regulatory Compliance Notice
This Class B digital apparatus complies with Canadian ICES-
003 (B).
This device contains licence-exempt transmitter(s)/receiver(s)
that comply with Innovation, Science and Economic
Development Canada’s licence-exempt RSS(s). Operation is
subject to the following two conditions:
1. This device may not cause interference.
2. This device must accept any interference, including
interference that may cause undesired operation of the
device.
The available scientific evidence does not show that any health
problems are associated with using low power wireless devices.
There is no proof, however, that these low power wireless
devices are absolutely safe. Low power wireless devices emit
low levels of radio frequency energy (RF) in the microwave
range while being used. Whereas high levels of RF can produce
health effects (by heating tissue), exposure of low-level RF that
does not produce heating effects causes no known adverse
health effects. Many studies of low-level RF exposures have not
found any biological effects. Some studies have suggested that
some biological effects might occur, but such findings have not
been confirmed by additional research. The R03010 has been
tested and found to comply with ISED radiation exposure limits
set forth for an uncontrolled environment and meets RSS-102
of the ISED radio frequency (RF) Exposure rules.
Pour les utilisateurs au Canada
Avis de conformité à la réglementation d’Innovation,
Sciences et Développement économique Canada (ISDE)
Cet appareil numérique de la classe B est conforme à la norme
NMB-003 (B) du Canada.
L’émetteur/récepteur exempt de licence contenu dans le
présent appareil est conforme aux CNR d’Innovation, Sciences
et Développement économique Canada applicables aux
appareils radio exempts de licence. L’exploitation est autorisée
aux deux conditions suivantes :
1. L’appareil ne doit pas produire de brouillage ;
2. L’appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d’en compromettre le
fonctionnement.
Les connaissances scientifiques dont nous disposons n’ont mis
en évidence aucun problème de santé associé à l’usage des
appareils sans fil à faible puissance. Nous ne sommes
cependant pas en mesure de prouver que ces appareils sans fil
à faible puissance sont entièrement sans danger. Les appareils
sans fil à faible puissance émettent une énergie fréquence
radioélectrique (RF) très faible dans le spectre des micro-ondes
lorsqu’ils sont utilisés. Alors qu’une dose élevée de RF peut
avoir des effets sur la santé (en chauffant les tissus),
l’exposition à de faibles RF qui ne produisent pas de chaleur n’a
pas de mauvais effets connus sur la santé. De nombreuses
études ont été menées sur les expositions aux RF faibles et
n’ont découvert aucun effet biologique. Certaines études ont
suggéré qu’il pouvait y avoir certains effets biologiques, mais
ces résultats n’ont pas été confirmés par des recherches
supplémentaires. Le R03010 a été testé et jugé conforme aux
limites d’exposition aux rayonnements ISDE énoncées pour un
environnement non contrôlé et respecte les règles d’exposition
aux fréquences radioélectriques (RF) CNR-102 de l’ISDE.
7
Appendix
141
For Customers in Europe
Information for Users on Collection and Disposal of Old
Equipment and Used Batteries
1. In the European Union
These symbols on the products, packaging and/
or accompanying documents mean that used
electrical and electronic equipment and batteries
should not be mixed with general household
waste.
Used electrical/electronic equipment and
batteries must be treated separately and in
accordance with legislation that requires proper
treatment, recovery and recycling of these
products.
By disposing of these products correctly you will
help ensure that the waste undergoes the
necessary treatment, recovery and recycling
and thus prevent potential negative effects on
the environment and human health which could
otherwise arise due to inappropriate waste
handling.
If a chemical symbol is added beneath the symbol shown
above, in accordance with the Battery Directive, this indicates
that a heavy metal (Hg = Mercury, Cd = Cadmium, Pb = Lead)
is present in the battery at a concentration above an applicable
threshold specified in the Battery Directive.
For more information about collection and recycling of used
products, please contact your local authorities, your waste
disposal service or the point of sale where you purchased the
products.
2. In other countries outside the EU
These symbols are only valid in the European Union. If you wish
to discard used products, please contact your local authorities
or dealer and ask for the correct method of disposal.
For Switzerland: Used electrical/electronic equipment can be
returned free of charge to the dealer, even when you don’t
purchase a new product. Further collection facilities are listed
on the home page of www.swico.ch
or www.sens.ch.
CAUTION:
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN
INCORRECT TYPE. DISPOSE OF USED BATTERIES
ACCORDING TO THE INSTRUCTIONS.
Notice to Users in EEA Countries
This product complies with the essential requirements and
provisions of RE Directive 2014/53/EU.
The CE Declaration of Conformity is available by accessing the
URL:
http://www.ricoh-imaging.co.jp/english/support/
declaration_of_conformity.html
and selecting the product applicable.
Operating frequency band: 2400 MHz - 2483.5 MHz
Maximum radio-frequency power: 14 dBm EIRP
European importer: RICOH IMAGING EUROPE S.A.S.
Parc Tertiaire SILIC 7-9, avenue Robert Schuman - B.P. 70102,
94513 Rungis Cedex, FRANCE
Manufacturer: RICOH IMAGING COMPANY, LTD.
1-3-6, Nakamagome, Ohta-ku, Tokyo 143-8555, JAPAN
7
Appendix
142
Notice to Users in CE marking
Importer (CE marking): RICOH IMAGING EUROPE S.A.S.
Parc Tertiaire SILIC 7-9, avenue Robert Schuman - B.P. 70102,
94513 Rungis Cedex, FRANCE
Manufacturer: RICOH IMAGING COMPANY, LTD.
3-6, Nakamagome 1-chome, Ohta-ku, Tokyo, 143-8555 Japan
Notice to Users in UKCA marking
Manufacturer: RICOH IMAGING COMPANY, LTD.
3-6, Nakamagome 1-chome, Ohta-ku, Tokyo, 143-8555 Japan
For Customers in Thai
This telecommunication equipment conforms to the
requirements of the Office of the National Broadcasting and
Telecommunications Commission.
The CE Mark is a Directive conformity mark of the
European Union.
The UKCA Mark is a Regulation conformity mark
of the United Kingdom.
Memo
Memo
We have paid close attention to the safety of this camera. When using this
camera, we request your special attention regarding items marked with the
following symbols.
Warning
• Do not disassemble or modify the camera. High voltage areas are
present inside the camera, with the risk of electric shock.
• If the camera interior is exposed due to dropping or otherwise damaging
the camera, never touch the exposed portion. There is a risk of electric
shock.
• Do not aim the camera at the sun or other strong light sources when
taking images or leave the camera sitting in direct sunlight with a lens
cap off. Doing so may cause the camera to malfunction or cause a fire.
• Do not look at the sun or other strong light sources through a lens. Doing
so may lead to a loss of eyesight or cause vision to be impaired.
• If any irregularities occur during use, such as smoke or a strange odor,
stop use immediately, remove the battery or the AC adapter, and contact
your nearest service center. Continued use can cause a fire or electric
shock.
Caution
• Some portions of the camera heat up during use. There is a risk of low
temperature burns when holding such portions for long periods.
• Should the monitor be damaged, be careful of glass fragments. Also, be
careful not to allow the liquid crystal to get on your skin or in your eyes
or mouth.
• Depending on your individual factors or physical condition, the use of the
camera may cause itching, rashes or blisters. In case of any
abnormality, stop using the camera and get medical attention
immediately.
Warning
• Wipe off the power plug if it should become covered with dust.
Accumulated dust may cause a fire.
• Do not handle the power plug with wet hands. This can cause an electric
shock.
• Always grip the plug section when disconnecting the power plug. Do not
pull the power cord. This can damage the power cord and result in a fire
or electric shock.
• If the generation of smoke or strange odor from the adapter or other
abnormality occurs, immediately remove the power plug from the outlet
and contact your nearest dealer or service center for repair. Do not use
the adapter until it is repaired.
• If you see a lightning flash or hear thunder during use of the adapter, do
not touch the power plug. This can cause an electric shock.
Caution
• Securely insert the power plug into the outlet. Failure to observe this
precaution may cause a fire.
For Using Your Camera Safely
Warning
This symbol indicates that ignoring this item
could cause serious personal injuries.
Caution
This symbol indicates that ignoring this item
could cause minor or medium personal injuries,
or loss of property.
About the Camera
About the USB Power Adapter
e_kb582_cover_6mm.fm Page 2 Thursday, December 10, 2020 1:19 PM
RICOH IMAGING COMPANY, LTD.
1-3-6, Nakamagome, Ohta-ku, Tokyo 143-8555, JAPAN
(http://www.ricoh-imaging.co.jp)
RICOH IMAGING EUROPE
S.A.S.
Parc Tertiaire SILIC 7-9, avenue Robert Schuman - B.P. 70102,
94513 Rungis Cedex, FRANCE
(http://www.ricoh-imaging.eu)
RICOH IMAGING AMERICAS
CORPORATION
2 Gatehall Drive Suite 204, Parsippany, New Jersey 07054, U.S.A.
(http://www.us.ricoh-imaging.com)
RICOH IMAGING CANADA
INC.
5560 Explorer Drive Suite 100, Mississauga, Ontario, L4W 5M3, CANADA
(http://www.ricoh-imaging.ca)
RICOH IMAGING CHINA CO.,
LTD.
Room A 23F Lansheng Building, 2-8 Huaihaizhong Road, Huangpu District,
Shanghai, 200021, CHINA
(http://www.ricoh-imaging.com.cn)
http://www.ricoh-imaging.co.jp/english
This contact information may change without notice.
Please check the latest information on our websites.
SLR Digital Camera
Operating Manual
This Operating Manual provides information on how to use the
shooting and playback functions of this camera and related
precautions.
Thoroughly read this Operating Manual to make the best use of
the functions available with this camera. Be sure to keep this
Operating Manual for future reference.
It is recommended to update the camera firmware to the latest
version before using the camera.
For details on the latest firmware version, refer to the firmware
download site.
http://www.ricoh-imaging.com/
RICOH IMAGING COMPANY, LTD.
Introduction
1
2
Getting Started
3
Shooting
4
Playback
5
Sharing
6
Settings
7
Appendix
Model No. R03010
• Specifications and external dimensions are subject to
change without notice.
51553 Copyright © RICOH IMAGING COMPANY, LTD. 2021
R02DTC21 Printed in Philippines
*4RE2Z020*
e_kb582_cover_6mm.fm Page 1 Friday, March 5, 2021 1:46 PM
