Smeg SAW816 8kg Front Load Washing Machine User Manual

2820523397/ 25-02-13.(12:39)

Document Number

SAW 816

Washing Machine

User’s Manual

2 / EN

Washing Machine / User’s Manual

1 Important instructions for safety and

environment

This section contains safety instructions that will help protect

from risk of personal injury or property damage. Failure to

follow these instructions shall void any warranty.

1.1 General safety

• Thisproductcanbeusedbychildrenatandabove8

yearsoldandbypersonswhosephysical,sensoryor

mentalcapabilitieswerenotfullydevelopedorwho

lack experience and knowledge provided that they are

supervised or trained on the safe usage of the product

andtherisksitbringsout.Childrenmustnotplaywith

theproduct.Cleaningandmaintenanceworksshouldnot

beperformedbychildrenunlesstheyaresupervisedby

someone.

• Neverplacetheproductonacarpet-coveredfloor.

Otherwise,lackofairflowbeneaththemachinewillcause

electricalpartstooverheat.Thiswillcauseproblemswith

your product.

• Iftheproducthasafailure,itshouldnotbeoperated

unlessitisrepairedbytheAuthorizedServiceAgent.

There is the risk of electric shock!

• Thisproductisdesignedtoresumeoperatingintheevent

ofpoweringonafterapowerinterruption.Ifyouwishto

canceltheprogramme,see"Cancellingtheprogramme"

section.

• Connecttheproducttoagroundedoutletprotected

bya16Afuse.Donotneglecttohavethegrounding

installationmadebyaqualifiedelectrician.Ourcompany

shallnotbeliableforanydamagesthatwillarisewhen

the product is used without grounding in accordance with

the local regulations.

• Thewatersupplyanddraininghosesmustbesecurely

fastenedandremainundamaged.Otherwise,thereisthe

risk of water leakage.

• Neveropentheloadingdoororremovethefilterwhile

thereisstillwaterinthedrum.Otherwise,riskofflooding

and injury from hot water will occur.

• Donotforceopenthelockedloadingdoor.Theloading

doorwillbereadytoopenjustafewminutesafterthe

washingcyclecomestoanend.Incaseofforcingthe

loadingdoortoopen,thedoorandthelockmechanism

may get damaged.

• Unplugtheproductwhennotinuse.

• Neverwashtheproductbyspreadingorpouringwater

onto it! There is the risk of electric shock!

• Nevertouchtheplugwithwethands!Neverunplugby

pullingonthecable,alwayspulloutbygrabbingtheplug.

• Usedetergents,softenersandsupplementssuitablefor

automatic washing machines only.

• Followtheinstructionsonthetextiletagsandonthe

detergent package.

• Theproductmustbeunpluggedduringinstallation,

maintenance,cleaningandrepairingprocedures.

• Alwayshavetheinstallationandrepairingprocedures

carriedoutbytheAuthorized Service Agent.

Manufacturershallnotbeheldliablefordamagesthat

mayarisefromprocedurescarriedoutbyunauthorized

persons.

• Ifthepowercableisdamaged,itmustbereplacedbythe

manufacturer,aftersalesserviceorasimilarlyqualified

person(preferablyanelectrician)orsomeonedesignated

bytheimporterinordertoavoidpossiblerisks.

1.2 Intended use

• Thisproducthasbeendesignedfordomesticuse.Itisnot

suitableforcommercialuseanditmustnotbeusedout

of its intended use.

• Theproductmustonlybeusedforwashingandrinsingof

laundry that are marked accordingly.

• Themanufacturerwaivesanyresponsibilityarisenfrom

incorrect usage or transportation.

1.3 Children's safety

• Packagingmaterialsaredangeroustochildren.Keep

packaging materials in a safe place away from reach of

the children.

• Electricalproductsaredangerousforthechildren.Keep

childrenawayfromtheproductwhenitisinuse.Donot

letthemtotamperwiththeproduct.Usechildlockto

prevent children from intervening with the product.

• Donotforgettoclosetheloadingdoorwhenleavingthe

room where the product is located.

• Storealldetergentsandadditivesinasafeplaceaway

fromthereachofthechildrenbyclosingthecoverofthe

detergent container or sealing the detergent package.

1.4 Package information

• Packagingmaterialsoftheproductaremanufactured

fromrecyclablematerialsinaccordancewithour

NationalEnvironmentRegulations.Donotdisposeofthe

packaging materials together with the domestic or other

wastes. Take them to the packaging material collection

pointsdesignatedbythelocalauthorities.

1.5 Disposing of the waste product

• Thisproducthasbeenmanufacturedwithhighquality

partsandmaterialswhichcanbereusedandaresuitable

forrecycling.Therefore,donotdisposetheproductwith

normal domestic waste at the end of its service life. Take

it to a collection point for the recycling of electrical and

electronicequipment.Pleaseconsultyourlocalauthorities

to learn the nearest collection point. Help protect the

environmentandnaturalresourcesbyrecyclingused

products.Forchildren'ssafety,cutthepowercableand

breakthelockingmechanismoftheloadingdoorsothat

itwillbenon-functionalbeforedisposingoftheproduct.

1.6 Compliance with WEEE Directive

ThisproductcomplieswithEUWEEEDirective

(2012/19/EU).Thisproductbearsa

classificationsymbolforwasteelectricaland

electronicequipment(WEEE).

Thisproducthasbeenmanufacturedwith

highqualitypartsandmaterialswhichcan

bereusedandaresuitableforrecycling.Do

not dispose of the waste product with normal domestic

and other wastes at the end of its service life. Take it to the

collection center for the recycling of electrical and electronic

equipment.Pleaseconsultyourlocalauthoritiestolearn

aboutthesecollectioncenters.

3 / EN

Washing Machine / User’s Manual

2 Installation

RefertothenearestAuthorisedServiceAgentforinstallation

oftheproduct.Tomaketheproductreadyforuse,review

the information in the user manual and make sure that the

electricity,tapwatersupplyandwaterdrainagesystemsare

appropriatebeforecallingtheAuthorizedServiceAgent.If

theyarenot,callaqualifiedtechnicianandplumbertohave

any necessary arrangements carried out.

Preparationofthelocationandelectrical,tapwaterand

waste water installations at the place of installation is

undercustomer'sresponsibility.

warning: Installationandelectricalconnectionsof

theproductmustbecarriedoutbytheAuthorized

ServiceAgent.Manufacturershallnotbeheldliablefor

damagesthatmayarisefromprocedurescarriedoutby

unauthorizedpersons.

warning: Priortoinstallation,visuallycheckiftheproduct

hasanydefectsonit.Ifso,donothaveitinstalled.

Damagedproductscauserisksforyoursafety.

Make sure that the water inlet and discharge hoses

aswellasthepowercablearenotfolded,pinchedor

crushed while pushing the product into its place after

installation or cleaning procedures.

2.1 Appropriate installation location

• Placethemachineonarigidfloor.Donotplaceitona

long pile rug or similar surfaces.

• Totalweightofthewashingmachineandthedryer-with

full load- when they are placed on top of each other

reachestoapprox.180kilograms.Placetheproduct

on a solid and flat floor that has sufficient load carrying

capacity!

• Donotplacetheproductonthepowercable.

• Donotinstalltheproductatplaceswheretemperature

mayfallbelow0ºC.

• Placetheproductatleast1cmawayfromtheedgesof

other furniture.

2.2 Removing packaging reinforcement

Tiltthemachinebackwardstoremovethepackaging

reinforcement.Removethepackagingreinforcementby

pullingtheribbon.

2.3 Removing the transportation locks

warning: Donotremovethetransportationlocksbefore

taking out the packaging reinforcement.

warning: Removethetransportationsafetyboltsbefore

operatingthewashingmachine!Otherwise,theproduct

willbedamaged.

1.Loosenalltheboltswithasuitablespanneruntilthey

rotate freely (C).

2.Removetransportationsafetyboltsbyturningthem

gently.

3.AttachtheplasticcoverssuppliedintheUserManualbag

into the holes on the rear panel. (P)

Keepthetransportationsafetyboltsinasafeplaceto

reusewhenthewashingmachineneedstobemoved

again in the future.

Never move the product without the transportation safety

boltsproperlyfixedinplace!

2.4 Connecting water supply

Thewatersupplypressurerequiredtoruntheproductis

between1to10bars(0.1–1MPa).Itisnecessaryto

have10–80litersofwaterflowingfromthefullyopen

tap in one minute to have your machine run smoothly.

Attachapressurereducingvalveifwaterpressureis

higher.

Ifyouaregoingtousethedoublewater-inletproduct

as a single (cold)water-inletunit,youmustinstallthe

suppliedstoppertothehotwatervalvebeforeoperating

theproduct.(Appliesfortheproductssuppliedwitha

blindstoppergroup.)

warning: Modelswithasinglewaterinletshouldnotbe

connectedtothehotwatertap.Insuchacasethelaundry

will get damaged or the product will switch to protection

mode and will not operate.

warning: Donotuseoldorusedwaterinlethosesonthe

newproduct.Itmaycausestainsonyourlaundry.

1.Connectthespecialhosessuppliedwiththeproductto

the water inlets on the product. Red hose (left) (max. 90

ºC)isforhotwaterinlet,bluehose(right)(max.25ºC)is

for cold water inlet.

warning: Ensure that the cold and hot water connections

are made correctly when installing the product.

Otherwise,yourlaundrywillcomeouthotattheendof

the washing process and wear out.

2.Tightenallhosenutsbyhand.Neveruseatoolwhen

tightening the nuts.

3. Open the taps completely after making the hose

connection to check for water leaks at the connection

4 / EN

Washing Machine / User’s Manual

points.Ifanyleaksoccur,turnoffthetapandremovethe

nut. Retighten the nut carefully after checking the seal. To

preventwaterleakagesanddamagescausedbythem,

keep the taps closed when the machine is not in use.

2.5 Connecting to the drain

• Theendofthedrainhosemustbedirectlyconnectedto

thewastewaterdrainortothewashbasin.

warning: Yourhousewillbefloodedifthehosecomes

outofitshousingduringwaterdischarge.Moreover,there

is risk of scalding due to high washing temperatures!

To prevent such situations and to ensure smooth water

intakeanddischargeofthemachine,fixtheendofthe

discharge hose tightly so that it cannot come out.

• Thehoseshouldbeattachedtoaheightofatleast40

cm,and100cmatmost.

• Incasethehoseiselevatedafterlayingitonthefloor

levelorclosetotheground(lessthan40cmabovethe

ground),waterdischargebecomesmoredifficultandthe

laundrymaycomeoutexcessivelywet.Therefore,follow

theheightsdescribedinthefigure.

• Topreventflowingofdirtywaterbackintothemachine

andtoallowforeasydischarge,donotimmersethehose

end into the dirty water or do not drive it in the drain more

than15cm.Ifitistoolong,cutitshort.

• Theendofthehoseshouldnotbebent,itshouldnotbe

steppedonandthehosemustnotbepinchedbetween

the drain and the machine.

• Ifthelengthofthehoseistooshort,useitbyadding

an original extension hose. Length of the hose may

notbelongerthan3.2m.Toavoidwaterleakfailures,

theconnectionbetweentheextensionhoseandthe

drainhoseoftheproductmustbefittedwellwithan

appropriate clamp as not to come off and leak.

2.6 Adjusting the feet

warning: Inordertoensurethattheproductoperates

moresilentlyandvibration-free,itmuststandleveland

balancedonitsfeet.Balancethemachinebyadjusting

thefeet.Otherwise,theproductmaymovefromitsplace

andcausecrushingandvibrationproblems.

1.Loosenthelocknutsonthefeetbyhand.

2.Adjustthefeetuntiltheproductstandsleveland

balanced.

3.Tightenalllocknutsagainbyhand.

warning: Donotuseanytoolstoloosenthelocknuts.

Otherwise,theywillgetdamaged.

2.7 Electrical connection

Connecttheproducttoagroundedoutletprotectedbya16

Afuse.Ourcompanyshallnotbeliableforanydamages

that will arise when the product is used without grounding in

accordance with the local regulations.

• Connectionmustcomplywithnationalregulations.

• Powercableplugmustbewithineasyreachafter

installation.

• Ifthecurrentvalueofthefuseorbreakerinthehouseis

lessthan16Amps,haveaqualifiedelectricianinstalla

16Ampfuse.

• Thevoltagespecifiedinthe"Technicalspecifications"

sectionmustbeequaltoyourmainsvoltage.

• Donotmakeconnectionsviaextensioncablesormulti-

plugs.

warning: Damagedpowercablesmustbereplacedby

theAuthorizedServiceAgents.

Transportation of the product

1.Unplugtheproductbeforetransportingit.

2. Remove water drain and water supply connections.

3.Drainallwaterthathasremainedintheproduct.

4.Installtransportationsafetyboltsinthereverseorderof

removal procedure;

Never move the product without the transportation safety

boltsproperlyfixedinplace!

warning: Packagingmaterialsaredangeroustochildren.

Keeppackagingmaterialsinasafeplaceawayfrom

reach of the children.

5 / EN

Washing Machine / User’s Manual

3 Preparation

3.1 Sorting the laundry

• Sortlaundryaccordingtotypeoffabric,colour,and

degreeofsoilingandallowablewatertemperature.

• Alwaysobeytheinstructionsgivenonthegarmenttags.

3.2 Preparing laundry for washing

• Laundryitemswithmetalattachmentssuchas,

underwiredbras,beltbucklesormetalbuttonswill

damage the machine. Remove the metal pieces or wash

theclothesbyputtingtheminalaundrybagorpillow

case.

•Takeoutallsubstancesinthepocketssuchascoins,

pensandpaperclips,andturnpocketsinsideoutand

brush.Suchobjectsmaydamagetheproductorcause

noiseproblem.

• Putsmallsizeclothessuchasinfant'ssocksandnylon

stockingsinalaundrybagorpillowcase.

• Placecurtainsinwithoutcompressingthem.Remove

curtain attachment items.

• Fastenzippers,sewloosebuttonsandmendripsand

tears.

• Wash“machinewashable”or“handwashable”labeled

products only with an appropriate programme.

• Donotwashcoloursandwhitestogether.New,dark

colouredcottonsreleasealotofdye.Washthem

separately.

• Toughstainsmustbetreatedproperlybeforewashing.If

unsure,checkwithadrycleaner.

• Useonlydyes/colourchangersandlimescaleremovers

suitableformachinewash.Alwaysfollowtheinstructions

on the package.

• Washtrousersanddelicatelaundryturnedinsideout.

• KeeplaundryitemsmadeofAngorawoolinthefreezer

forafewhoursbeforewashing.Thiswillreducepilling.

• Laundrythataresubjectedtomaterialssuchasflour,

limedust,milkpowder,etc.intenselymustbeshakenoff

beforeplacingintothemachine.Suchdustsandpowders

onthelaundrymaybuildupontheinnerpartsofthe

machine in time and can cause damage.

3.3 Things to be done for energy saving

Following information will help you use the product in an

ecological and energy-efficient manner.

• Operatetheproductinthehighestcapacityallowedby

theprogrammeyouhaveselected,butdonotoverload;

see,"Programmeandconsumptiontable".

• Alwaysfollowtheinstructionsonthedetergent

packaging.

• Washslightlysoiledlaundryatlowtemperatures.

• Usefasterprogrammesforsmallquantitiesoflightly

soiled laundry.

• Donotuseprewashandhightemperaturesforlaundry

that is not heavily soiled or stained.

• Ifyouplantodryyourlaundryinadryer,selectthe

highest spin speed recommended during washing

process.

• Donotusedetergentinexcessoftheamount

recommended on the detergent package.

3.4 Initial use

Beforestartingtousetheproduct,makesurethatall

preparations are made in accordance with the instructions in

sections“Importantsafetyinstructions”and“Installation”.

Topreparetheproductforwashinglaundry,performfirst

operationinDrumCleaningprogramme.Ifyourproduct

isnotequippedwithDrumCleaningprogramme,perform

theInitialUseprocedureinaccordancewiththemethods

describedunder“5.2Cleaningtheloadingdoorandthe

drum”sectionoftheusermanual.

Useananti-limescalesuitableforthewashingmachines.

Somewatermighthaveremainedintheproductdueto

thequalitycontrolprocessesintheproduction.Itisnot

harmful for the product.

3.5 Correct load capacity

Themaximumloadcapacitydependsonthetypeoflaundry,

the degree of soiling and the washing programme desired.

The machine automatically adjusts the amount of water

according to the weight of the loaded laundry.

warning: Followtheinformationinthe“Programme

andconsumptiontable”.Whenoverloaded,machine's

washingperformancewilldrop.Moreover,noiseand

vibrationproblemsmayoccur.

Laundry type Weight (g)

Bathrobe

1200

Napkin

100

Duvetcover

700

BedSheet

500

Pillowcase

200

Tablecloth

250

Towel

200

Hand towel

100

Evening gown

200

Underclothing

100

Men’s overalls

600

Men’s shirt

200

Men’s pajamas

500

Blouses

100

3.6 Loading the laundry

1. Open the loading door.

2.Placelaundryitemslooselyintothemachine.

3.Pushtheloadingdoortocloseuntilyouhearalocking

sound. Ensure that no items are caught in the door.

6 / EN

Washing Machine / User’s Manual

The loading door is locked while a programme is running.

Thedoorcanonlybeopenedawhileaftertheprogramme

comes to an end.

warning: Incaseofmisplacingthelaundry,noiseand

vibrationproblemsmayoccurinthemachine.

3.7 Using detergent and softener

Whenusingdetergent,softener,starch,fabricdye,bleach

or limescale remover read the manufacturer's instructions

on the package carefully and follow the suggested dosage

values.Usemeasuringcupifavailable.

Detergent Drawer

The detergent drawer is composed of three compartments:

–(1)forprewash

–(2)formainwash

–(3)forsoftener

–(*)inaddition,thereissiphonpieceinthesoftener

compartment.

Detergent, softener and other cleaning agents

• Adddetergentandsoftenerbeforestartingthewashing

programme.

• Neverleavethedetergentdraweropenwhilethewashing

programme is running!

• Whenusingaprogrammewithoutprewash,donot

put any detergent into the prewash compartment

(compartmentnr."1").

• Inaprogrammewithprewash,donotputliquiddetergent

intotheprewashcompartment(compartmentnr."1").

• Donotselectaprogrammewithprewashifyouareusing

adetergentbagordispensingball.Placethedetergent

bagorthedispensingballdirectlyamongthelaundryin

the machine.

• Ifyouareusingliquiddetergent,donotforgettoplace

theliquiddetergentcupintothemainwashcompartment

(compartmentnr."2").

Choosing the detergent type

Thetypeofdetergenttobeuseddependsonthetypeand

colourofthefabric.

• Usedifferentdetergentsforcolouredandwhitelaundry.

• Washyourdelicateclothesonlywithspecialdetergents

(liquiddetergent,woolshampoo,etc.)usedsolelyfor

delicate clothes.

• Whenwashingdarkcolouredclothesandquilts,itis

recommendedtouseliquiddetergent.

• Washwoolenswithspecialdetergentmadespecifically

for woolens.

warning: Useonlydetergentsmanufacturedspecifically

for washing machines.

warning: Donotusesoappowder.

Adjusting detergent amount

Theamountofwashingdetergenttobeuseddepends

ontheamountoflaundry,thedegreeofsoilingandwater

hardness.

• Donotuseamountsexceedingthedosagequantities

recommended on the detergent package to avoid

problemsofexcessivefoam,poorrinsing,financial

savingsandfinally,environmentalprotection.

• Uselesserdetergentforsmallamountsorlightlysoiled

clothes.

Using softeners

Pourthesoftenerintothesoftenercompartmentofthe

detergent drawer.

•Donotexceedthe(>max<)levelmarkinginthesoftener

compartment.

•Ifthesoftenerhaslostitsfluidity,diluteitwithwater

beforeputtingitinthedetergentdrawer.

Using liquid detergents

If the product contains a liquid detergent cup:

• Makesurethatyouhaveplacedtheliquiddetergentcup

incompartmentnr."2".

•Iftheliquiddetergenthaslostitsfluidity,diluteitwith

waterbeforeputtinginthedetergentcup.

If the product does not contain a liquid detergent cup:

• Donotuseliquiddetergentfortheprewashina

programme with prewash.

• Liquiddetergentstainsyourclotheswhenusedwith

DelayedStartfunction.IfyouaregoingtousetheDelayed

Startfunction,donotuseliquiddetergent.

Using gel and tablet detergent

Applythefollowinginstructionswhenusingtablet,geland

similar detergents.

• Ifthegeldetergentthicknessisfluidalandyourmachine

doesnotcontainaspecialliquiddetergentcup,putthe

gel detergent into the main wash detergent compartment

duringfirstwaterintake.Ifyourmachinecontainsaliquid

detergentcup,fillthedetergentintothiscupbefore

starting the programme.

• Ifthegeldetergentthicknessisnotfluidalorintheshape

ofcapsuleliquidtablet,putitdirectlyintothedrumbefore

washing.

• Puttabletdetergentsintothemainwashcompartment

(compartmentnr."2")ordirectlyintothedrumbefore

washing.

Tabletdetergentsmayleaveresiduesinthedetergent

compartment.Ifyouencountersuchacase,placethe

tabletdetergentbetweenthelaundry,closetothelower

part of the drum in future washings.

Usethetabletorgeldetergentwithoutselectingthe

prewash function.

7 / EN

Washing Machine / User’s Manual

Using starch

• Addliquidstarch,powderstarchorthefabricdyeintothe

softener compartment.

• Donotusesoftenerandstarchtogetherinawashing

cycle.

• Wipetheinsideofthemachinewithadampandclean

cloth after using starch.

Using bleaches

• Selectaprogrammewithprewashandaddthebleaching

agentatthebeginningoftheprewash.Donotput

detergentintheprewashcompartment.Asanalternative

application,selectaprogrammewithextrarinseandadd

thebleachingagentwhilethemachineistakingwater

from the detergent compartment during first rinsing step.

• Donotusebleachingagentanddetergentbymixing

them.

• Usejustalittleamount(approx.50ml)ofbleachingagent

and rinse the clothes very well as it causes skin irritation.

Donotpourthebleachingagentontotheclothesanddo

not use it for coloured clothes.

• Whenusingoxygenbasedbleaches,selectaprogramme

that washes at a lower temperature.

• Oxygenbasedbleachescanbeusedtogetherwith

detergents;however,ifitsthicknessisnotthesame

withthedetergent,putthedetergentfirstintothe

compartmentnr."2"inthedetergentdrawerandwait

until the detergent flows while the machine is taking

inwater.Addthebleachingagentfromthesame

compartment while the machine is still taking in water.

Using limescale remover

•Whenrequired,uselimescaleremoversmanufactured

specifically for washing machines only.

3.8 Tips for efficient washing

Clothes

Light colours and whites Colours Dark colours

Delicates/

Woolens/Silks

(Recommended temperature

rangebasedonsoilinglevel:

40-90ºC)

(Recommended temperature

rangebasedonsoilinglevel:

cold-40ºC)

(Recommended

temperature range

basedonsoilinglevel:

cold-40ºC)

(Recommended

temperature range

basedonsoilinglevel:

cold-30ºC)

Soiling Level

Heavily Soiled

(difficult stains such

asgrass,coffee,

fruitsandblood.)

Itmaybenecessarytopre-

treat the stains or perform

prewash.Powderandliquid

detergents recommended

forwhitescanbeusedat

dosages recommended for

heavilysoiledclothes.Itis

recommended to use powder

detergents to clean clay and

soil stains and the stains that

aresensitivetobleaches.

Powderandliquid

detergents recommended

forcolourscanbeusedat

dosages recommended for

heavilysoiledclothes.Itis

recommended to use powder

detergents to clean clay and

soil stains and the stains that

aresensitivetobleaches.Use

detergentswithoutbleach.

Liquiddetergents

suitableforcolours

and dark colours can

beusedatdosages

recommended for

heavily soiled clothes.

Preferliquid

detergents produced

for delicate clothes.

Woolenandsilk

clothesmustbe

washed with special

woolen detergents.

Normally Soiled

(Forexample,stains

causedbybodyon

collars and cuffs)

Powderandliquiddetergents

recommended for whites

canbeusedatdosages

recommended for normally

soiled clothes.

Powderandliquiddetergents

recommended for colours

canbeusedatdosages

recommended for normally

soiledclothes.Usedetergents

withoutbleach.

Liquiddetergents

suitableforcolours

and dark colours can

beusedatdosages

recommended for

normally soiled clothes.

Preferliquid

detergents produced

for delicate clothes.

Woolenandsilk

clothesmustbe

washed with special

woolen detergents.

Lightly Soiled

(Novisiblestains

exist.)

Powderandliquiddetergents

recommended for whites

canbeusedatdosages

recommended for lightly soiled

clothes.

Powderandliquiddetergents

recommended for colours

canbeusedatdosages

recommended for lightly

soiledclothes.Usedetergents

withoutbleach.

Liquiddetergents

suitableforcolours

and dark colours can

beusedatdosages

recommended for lightly

soiled clothes.

Preferliquid

detergents produced

for delicate clothes.

Woolenandsilk

clothesmustbe

washed with special

woolen detergents.

8 / EN

Washing Machine / User’s Manual

4 Operating the product

4.1 Control panel

6 7 8

2 3 4 5

1 -SpinSpeedAdjustmentbutton

2 -Display

3 -TemperatureAdjustmentbutton

4 -ProgrammeSelectionknob

5 -On/Offbutton

6 -DelayedStartbuttons(+/-)

7 -AuxiliaryFunctionbuttons

8 -Start/Pause/Cancelbutton

4.2 Display symbols

a -SpinSpeedindicator

b -Temperatureindicator

c -Spinsymbol

d -Temperaturesymbol

e -RemainingTimeandDelayedStartindicator

f -ProgrammeIndicatorsymbols(Prewash/MainWash/

Rinse/Softener/Spin)

g -Economysymbol

h -DelayedStartsymbol

i -DoorLockedsymbol

j -Startsymbol

k -Pausesymbol

l -AuxiliaryFunctionsymbols

m-NoWatersymbol

4.3 Preparing the machine

Make sure that the hoses are connected tightly. Pluginyour

machine. Turn the tap on completely. Placethelaundryinthe

machine. Adddetergentandfabricsoftener.

4.4 Programme selection

Selecttheprogrammesuitableforthetype,quantity

and soiling degree of the laundry in accordance with the

"Programmeandconsumptiontable"andthetemperature

tablebelow.

90˚C

Heavilysoiledwhitecottonsandlinens.(coffeetable

covers,tableclothes,towels,bedsheets,etc.)

60˚C

Normallysoiled,coloured,fadeprooflinens,cottonsor

syntheticclothes(shirt,nightgown,pajamas,etc.)and

lightlysoiledwhitelinens(underwear,etc.)

40˚C-

30˚C-Cold

Blendedlaundryincludingdelicatetextile(veilcurtains,

etc.),syntheticsandwoolens.

SelectthedesiredprogrammewiththeProgramme

Selectionbutton.

Programmesarelimitedwiththehighestspinspeed

appropriateforthatparticulartypeoffabric.

Whenselectingaprogramme,alwaysconsiderthetype

offabric,colour,degreeofsoilingandpermissiblewater

temperature.

Alwaysselectthelowestrequiredtemperature.Higher

temperature means higher power consumption.

Forfurtherprogrammedetails,see"Programmeand

consumptiontable"

9 / EN

Washing Machine / User’s Manual

4.5 Main programmes

Dependingonthetypeoffabric,usethefollowingmain

programmes.

• Cottons

Usethisprogrammeforyourcottonlaundry(suchasbed

sheets,duvetandpillowcasesets,towels,bathrobes,

underwear,etc.).Yourlaundrywillbewashedwithvigorous

washing action for a longer washing cycle.

• Synthetics

Usethisprogrammetowashyoursyntheticclothes(shirts,

blouses,synthetic/cottonblends,etc.).Itwasheswitha

gentle action and has a shorter washing cycle compared to

theCottonsprogramme.

Forcurtainsandtulle,usetheSynthetic40˚Cprogramme

withprewashandanti-creasingfunctionsselected.Astheir

meshedtexturecausesexcessivefoaming,washtheveils/

tullebyputtinglittleamountofdetergentintothemain

washcompartment.Donotputdetergentintheprewash

compartment.

• Wool

Usethisprogrammetowashyourwoolenclothes.Select

the appropriate temperature complying with the tags of your

clothes.Useappropriatedetergentsforwoolens.

“TheWoolwashcycleofthismachinehasbeen

testedandapprovedbyTheWoolmarkCompany

forthewashingofWoolmarkgarmentslabelledas

“machinewash”providedthatthegarmentsare

washed according to the instructions on the garment

labelandthoseissuedbythemanufacturerofthis

washingmachine.”

“InUK,Eire,HongKongandIndiatheWoolmarktrade

markisaCertificationtrademark.”

4.6 Additional programmes

Forspecialcases,additionalprogrammesareavailablein

the machine.

Additionalprogrammesmaydifferaccordingtothe

model of the machine.

• Cottons Eco

Youmaywashyournormallysoileddurablecottonand

linen laundry in this programme with the highest energy

and water saving compared to all other wash programmes

suitableforcottons.Actualwatertemperaturemaydiffer

fromthedeclaredcycletemperature.Programmeduration

mayautomaticallybeshortenedduringlaterstagesofthe

programme if you wash less amount (e.g. ½ capacity or

less)oflaundry.Inthiscaseenergyandwaterconsumption

willbefurtherdecreasedgivingyoutheopportunityfora

moreeconomicalwash.Thisfeatureisavailableforcertain

models having remaining time display.

• Hygienic heavy duty

Usethisprogrammeforyourlaundryforwhichyourequire

an anti-allergic and hygienic washing at high temperature

with intensive and long washing cycles.

• Gentle

Usethisprogrammetowashyourdelicateclothes.Itwashes

with a gentle action without any interim spin compared to

theSyntheticsprogramme.

• Full load quick

Usethisprogrammetowashyourlightlysoiledcotton

clothes in a short time.

• Small load 14

Usethisprogrammetowashyourlittleamountoflightly

soiled cotton clothes in a short time.

• Shirts

Usethisprogrammetowashtheshirtsmadeofcotton,

syntheticandsyntheticblendedfabricstogether.

• Denim

Usethisprogrammetowashclothessuchastrousers,

jackets,vests,etc.,madeofdenim.Lowermechanical

movement in washing cycles and lower rpm in spinning

cycles are used to prevent washing damages on stoned

jeans as well as to ensure a longer life.

Soilinglevelandtemperaturecanbeselected

separately in this programme.

• Blankets

Usethisprogrammetowashyourfiberduvetsthatbear

"machinewashable"tag.Makesurethatyouhaveloaded

the duvet correctly in order not to damage the machine and

theduvet.Removetheduvetcoverbeforeloadingtheduvet

into the machine. Fold the duvet into two and load it into the

machine. Load the duvet into the machine paying attention

toplaceitinawaythatitwillnotcontactthebellow.

Donotloadmorethan1doublefibreduvet(200x200

cm).

Donotwashyourduvets,pillowsandetc.thatcontain

cotton in the machine.

warning: Donotwashtheitemsapartfromduvetssuch

ascarpets,rugsandetc.inthemachine.Permanent

damage occurs in the machine.

• Delicates

Usethisprogrammetowashdelicatessuchasunderwears.

Ifthereislittleamountoflaundry,usealaundrynet.

• Freshen up

Usethisprogrammetoremovetheodouronthelaundrythat

are worn only for once and do not contain any stains or dirt.

• Drum Clean

Usethisprogrammeregularly(onceinevery1-2months)to

cleanthedrumandprovidetherequiredhygiene.Runthe

programmewithoutanylaundryinthemachine.Toobtain

betterresults,putpowderlimescaleremoverforwashing

machinesintothedetergentcompartmentII.Whenthe

programmeisover,leavetheloadingdoorajarsothatthe

inside of the machine gets dry.

Thisisnotawashingprogramme.Itisamaintenance

programme.

10 / EN

Washing Machine / User’s Manual

Donotruntheprogrammewhenthereissomethingin

themachine.Ifyoutrytodoso,themachinedetects

thatthereisaloadinsideandabortstheprogramme.

4.7 Special programmes

Forspecificapplications,selectanyofthefollowing

programmes.

• Rinse

Usethisprogrammewhenyouwanttorinseorstarch

separately.

• Spin

Usethisprogrammetoapplyanadditionalspincyclefor

your laundry or to drain the water in the machine.

Beforeselectingthisprogramme,selectthedesiredspin

speedandpressStart/Pause/Cancelbutton.Themachine

will spin the laundry with the set spin speed and drain the

water coming out of them.

Ifyouwishtodrainonlythewaterwithoutspinningyour

laundry,selectthePump+Spinprogrammeandthenselect

theNoSpinfunctionwiththehelpofSpinSpeedAdjustment

button.PressStart/Pause/Cancelbutton.

Usealowerspinspeedfordelicatelaundries.

4.8 Temperature selection

Wheneveranewprogrammeisselected,themaximum

temperature for the selected programme appears on the

temperature indicator.

Todecreasethetemperature,presstheTemperature

Adjustmentbutton.Temperaturedecreaseswithincrements

of10°andfinally,“-”symbolindicatingthecoldwashoption

appears on the display.

IfyouscrolltocoldwashoptionandpressTemperature

Adjustmentbuttonagain,therecommended

temperature for the selected programme appears on

thedisplay.PresstheTemperatureAdjustmentbutton

again to decrease the temperature.

Economy symbol

Indicatestheprogrammesandtemperaturesthatprovide

energy savings.

EconomysymbolcannotbeselectedinIntensiveand

Hygiene programmes since washing is performed in

long times and at high temperatures in order to provide

hygiene.Similarly,Economysymbolcannotbeselected

inBaby,Refresh,DrumCleaning,SpinandRinse

programmes as well.

4.9 Spin speed selection

Wheneveranewprogrammeisselected,therecommended

spin speed of the selected programme is displayed on the

spin speed indicator.

Todecreasethespinspeed,presstheSpinSpeed

Adjustmentbutton.Spinspeeddecreasesgradually.Then,

dependingonthemodeloftheproduct,"RinseHold"and

"NoSpin"optionsappearonthedisplay.See"Auxiliary

functionselection"sectionforexplanationsoftheseoptions.

RinseHoldoptionisindicatedwith“ ”symboland

NoSpinoptionisindicatedwith“ ”symbol.

11 / EN

Washing Machine / User’s Manual

4.10 Programme and consumption table

•:Selectable

*:Automaticallyselected,nocancelling.

**:EnergyLabelprogramme(EN60456Ed.3)

***Ifmaximumspinspeedofthemachineislowerthenthisvalue,youcanonlyselectuptothemaximumspinspeed.

-:Seetheprogrammedescriptionformaximumload.

**“CottonEconomic40°CandCottonEconomic60°Carestandardcycles.”Thesecyclesareknownas‘40°Ccottonstandard

cycle’and‘60°Ccottonstandardcycle’andindicatedwiththe symbolsonthepanel.

Theauxiliaryfunctionsinthetablemayvaryaccordingtothemodelofyourmachine.

Waterandpowerconsumptionmayvarysubjecttothechangesinwaterpressure,waterhardnessandtemperature,ambient

temperature,typeandamountoflaundry,selectionofauxiliaryfunctionsandspinspeed,andchangesinelectricvoltage.

Youcanseethewashingtimeoftheprogrammeyouhaveselectedonthedisplayofthemachine.Itisnormalthatsmall

differencesmayoccurbetweenthetimeshownonthedisplayandtherealwashingtime.

Auxiliary functions

Programme

Max. Load (kg)

Water Consumption (l)

Energy Consumption

(kWh)

Max. Speed***

Prewash

Quick Wash

Anti-Crease

#REF!

Selectable

temperature

range °C

Cottons 90 8 70 2.60 1600 • • • • 90-Cold

Cottons 60 8 70 1.75 1600 • • • • 90-Cold

Cottons 40 8 70 0.90 1600 • • • • 90-Cold

Hygienic heavy duty 90 8 100 2.25 1600 • 90-30

Cottons Eco 40** 8 69 0.90 1600 • 40-Cold

Cottons Eco Cold 8 69 0.45 1600 • 40-Cold

Synthetics 60 4 56 0.90 1200 • • • • 60-Cold

Synthetics 40 4 56 0.50 1200 • • • • 60-Cold

Gentle 40 3 54 0.44 1200 • • 40-Cold

Delicates 30 1 50 0.25 1200 30-Cold

Blankets 40 - 55 0.75 1200 60-40

Small load 14 30 2 42 0.10 1400 • 30-Cold

Full load quick 90 8 65 2.22 1400 • 90-Cold

Full load quick 60 8 65 1.05 1400 • 90-Cold

Full load quick 30 8 65 0.28 1400 • 90-Cold

Wool 40 2 45 0.31 1200 • 40-Cold

Jeans 40 4 95 0.60 1200 • 40-Cold

Shirts 60 4 55 1.15 800 • • * • 60-Cold

Drum Clean 70 - 110 2.00 1200 70

Freshen up - 2 35 0.03 1200 • -

12 / EN

Washing Machine / User’s Manual

4.11 Auxiliary function selection

Selectthedesiredauxiliaryfunctionsbeforestarting

theprogramme.Furthermore,youmayalsoselector

cancelauxiliaryfunctionsthataresuitabletotherunning

programmebypressingtheStart/Pause/Cancelbutton

whenthemachineisoperating.Forthis,themachinemust

beinastepbeforetheauxiliaryfunctionyouaregoingto

select or cancel.

Dependingontheprogramme,pressa,b,cordbuttonsto

selectthedesiredauxiliaryfunction.Symboloftheselected

auxiliary function appears on the display.

Somefunctionscannotbeselectedtogether.Ifasecond

auxiliary function conflicting with the first one is selected

beforestartingthemachine,thefunctionselected

firstwillbecanceledandthesecondauxiliaryfunction

selectionwillremainactive.Forexample,ifyouwantto

selectQuickWashafteryouhaveselectedthePrewash,

PrewashwillbecanceledandQuickWashwillremain

active.

Anauxiliaryfunctionthatisnotcompatiblewiththe

programmecannotbeselected.(See“Programmeand

consumptiontable”)

AuxiliaryFunctionbuttonsmayvaryaccordingtothe

model of the machine.

• Prewash

APrewashisonlyworthwhileforheavilysoiledlaundry.Not

usingthePrewashwillsaveenergy,water,detergentand

time.

F1 appears on the display when you select this function (a).

• Quick Wash

ThisfunctioncanbeusedinCottonsandSynthetics

programmes.Itdecreasesthewashingtimesandalsothe

numberofrinsingstepsforlightlysoiledlaundry.

F2appearsonthedisplaywhenyouselectthisfunction(b).

Whenyouselectthisfunction,loadyourmachine

with half of the maximum laundry specified in the

programmetable.

• Rinse Plus

Thisfunctionenablesthemachinetomakeanotherrinsing

in addition to the one already made after the main wash.

Thus,theriskforsensitiveskins(babies,allergicskins,etc.)

tobeeffectedbytheminimaldetergentremnantsonthe

laundrycanbereduced.

F3 appears on the display when you select this function (c).

• Anti-Creasing

Thisfunctioncreasestheclotheslesserwhentheyarebeing

washed.Drummovementisreducedandspinningspeedis

limitedtopreventcreasing.Inaddition,washingisdonewith

a higher water level.

F4 appears on the display when you select this function (d).

• Rinse Hold

Ifyouarenotgoingtounloadyourclothesimmediatelyafter

theprogrammecompletes,youmayuserinseholdfunction

to keep your laundry in the final rinsing water in order to

prevent them from getting wrinkled when there is no water

inthemachine.PressStart/Pause/Cancelbuttonafterthis

process if you want to drain the water without spinning your

laundry.Programmewillresumeandcompleteafterdraining

the water.

Ifyouwanttospinthelaundryheldinwater,adjusttheSpin

SpeedandpressStart/Pause/Cancelbutton.

Theprogrammeresumes.Waterisdrained,laundryisspun

and the programme is completed.

This function helps to remove pet hair that remain on your

garments more effectively.

Whenyouselectthisfunction,PrewashandExtraRinse

stepsareaddedtothenormalprogramme.Thus,washing

is performed with more water (30%) and the pet hair is

removed more effectively.

Never wash your pets in the washing machine.

4.12 Time display

Remaining time to complete the programme appears on the

display while the programme is running. Tim is displayed as

“01:30”inhoursandminutesformat.

Programmetimemaydifferfromthevaluesinthe

“Programmeandconsumptiontable”dependingon

thewaterpressure,waterhardnessandtemperature,

ambienttemperature,amountandthetypeoflaundry,

auxiliary functions selected and the changes at the

mains voltage.

Delayed start

WiththeDelayedStartfunctionthestartupofthe

programmemaybedelayedupto24hours.Delayedstart

timecanbeincreasedbyincrementsof30minutes.

DonotuseliquiddetergentswhenyousetDelayed

Start!Thereistheriskofstainingoftheclothes.

Opentheloadingdoor,placethelaundryandputdetergent,

etc.Selectthewashingprogramme,temperature,spin

speedand,ifrequired,theauxiliaryfunctions.Setthe

desireddelayedstarttimebypressingtheDelayedStart+or

-buttons.DelayedStartsymbolflashes.PressStart/Pause

/Cancelbutton.Delayedstartcountdownstarts.Delayed

Startsymbolilluminatessteadily.Startsymbolappears.“:”

starts flashing.

Additionallaundrymaybeloadedduringthedelayed

startperiod.Attheendofthecountdown,DelayedStart

symboldisappears,washingcyclestartsandthetime

of the selected programme appears on the display.

Changing the delayed start period

Ifyouwanttochangethetimeduringcountdown:

PressStart/Pause/Cancelbutton.“:”signinthemiddleof

thedelayedstarttimeonthedisplaystopsflashing.Pause

symbolappears.DelayedStartsymbolflashes.Startsymbol

disappears.Setthedesireddelayedstarttimebypressing

theDelayedStart+or-buttons.PressStart/Pause/

Cancelbutton.DelayedStartsymbolilluminatessteadily.

Pausesymboldisappears.Startsymbolappears.“:”sign

in the middle of the delayed start time on the display starts

flashing.

13 / EN

Washing Machine / User’s Manual

Cancelling the Delayed Start function

Ifyouwanttocancelthedelayedstartcountdownandstart

the programme immediately:

PressStart/Pause/Cancelbutton.“:”signinthemiddle

ofthedelayedstarttimeonthedisplaystopsflashing.Start

symboldisappears.PausesymbolandDelayedStartsymbol

flashes.Decreasethedelayedstarttimebypressingthe

DelayedStart-button.Programmedurationappearsafter

30minutes.PressStart/Pause/Cancelbuttontostartthe

programme.

4.13 Starting the programme

PressStart/Pause/Cancelbuttontostarttheprogramme.

Startsymbolshowingthestartupoftheprogrammewillturn

on.LoadingdoorislockedandDoorLockedsymbolappears

onthedisplay.Thesymbolofthestepfromwhichthe

programmehasstartedappearsonthedisplay(Prewash,

MainWash,Rinse,SoftenerandSpin).

4.14 Progress of programme

Progressofarunningprogrammeisindicatedonthedisplay

withasetofsymbols.

Relevantsymbolappearsonthedisplayatthebeginningof

eachprogrammestepandallsymbolsremainlitattheend

oftheprogramme.Thefarthermostrightsymbolindicates

the current programme step.

Prewash

IfthePrewashauxiliaryfunctionisselected,Prewashsymbol

appears on the display indicating that the prewash step has

started.

Main Wash

MainWashsymbolindicatingthatthemainwashstephas

started appears on the display.

Rinse

Rinsesymbolindicatingthattherinsingstephasstarted

appears on the display.

Softener

Softenersymbolindicatingthatthesoftenerstephasstarted

appears on the display.

Spin

Appearsatthebeginningofthefinalspinstepandremains

litduringSpinandPumpspecialprogrammes.

Ifthemachinedoesnotpasstothespinningstep,

RinseHoldfunctionmightbeactiveortheautomatic

unbalancedloaddetectionsystemmightbeactivated

duetotheunbalanceddistributionofthelaundryinthe

machine.

4.15 Loading door lock

There is a locking system on the loading door of the

machine that prevents opening of the door in cases when

thewaterlevelisunsuitable.

DoorLockedsymbolappearswhentheloadingdooris

locked.Thissymbolwillflashuntiltheloadingdoorbecomes

ready to open when programme completes or the machine

ispaused.Donotforcetoopentheloadingdoorinthisstep.

Symboldisappearswhenthedoorisreadytoopen.Youcan

openthedoorwhenthesymboldisappears.

4.16 Changing the selections after

programme has started

Switching the machine to pause mode

PresstheStart/Pause/Cancelbuttontoswitchthe

machinetopausemode.Pausesymbolappearsonthe

displayindicatingthatthemachineispaused.Startsymbol

disappears.

Changing the speed and temperature settings for

auxiliary functions

Dependingonthesteptheprogrammehasreached,you

maycanceloractivatetheauxiliaryfunctions;see,"Auxiliary

functionselection".

You may also change the speed and temperature settings;

see,"Spinspeedselection"and"Temperatureselection".

Adding or taking out laundry

PresstheStart/Pause/Cancelbuttontoswitchthe

machine to pause mode. The programme follow-up light of

the relevant step during which the machine was switched

intothepausemodewillflash.WaituntiltheLoadingDoor

canbeopened.OpentheLoadingDoorandaddortake

outthelaundry.ClosetheLoadingDoor.Makechanges

inauxiliaryfunctions,temperatureandspeedsettingsif

necessary.PressStart/Pause/Cancelbuttontostartthe

machine.

The loading door will not open if the water temperature

inthemachineishighorthewaterlevelisabovethe

door opening.

4.17 Child Lock

UseChildLockfunctiontopreventchildrenfromtampering

with the machine. Thus you can avoid any changes in a

running programme.

You can switch on and off the machine with On / Off

buttonwhentheChildLockisactive.Whenyouswitch

onthemachineagain,programmewillresumefrom

where it has stopped.

To activate the Child Lock:

Pressandhold2

and 4

AuxiliaryFunctionbuttonsfor3

seconds.“Con”appearsonthedisplay.

Samephrasewillappearonthedisplayifyoupress

anybuttonwhenChildLockisenabled.

To deactivate the Child Lock:

Pressandhold2

and 4

AuxiliaryFunctionbuttonsfor3

seconds.“COFF”appearsonthedisplay.

Donotforgettodisablethechildlockattheendof

theprogrammeifitwasenabledbefore.Otherwise,

machine will not allow to select a new programme.

4.18 Cancelling the programme

PressandholdStart/Pause/Cancelbuttonfor3seconds.

Startsymbolflashes.Symbolofthestepatwhichthe

programmewascancelledremainslit."End"appearsonthe

display and the programme is cancelled.

Ifyouwanttoopentheloadingdoorafteryouhave

cancelledtheprogrammebutitisnotpossibletoopen

the loading door since the water level in the machine

isabovetheloadingdooropening,thenturnthe

ProgrammeSelectionknobtoPump+Spinprogramme

and discharge the water in the machine.

14 / EN

Washing Machine / User’s Manual

5 Maintenance and cleaning

Servicelifeoftheproductextendsandfrequentlyfaced

problemsdecreaseifcleanedatregularintervals.

5.1 Cleaning the detergent drawer

Cleanthedetergentdraweratregularintervals(every

4-5washingcycles)asshownbelowinordertoprevent

accumulation of powder detergent in time.

1.Pressthedottedpointonthesiphoninthesoftener

compartment and pull towards you until the compartment

is removed from the machine.

Ifmorethannormalamountofwaterandsoftener

mixturestartstogatherinthesoftenercompartment,the

siphonmustbecleaned.

2.Washthedetergentdrawerandthesiphonwithplentyof

lukewarmwaterinawashbasin.Wearprotectivegloves

oruseanappropriatebrushtoavoidtouchingofthe

residues in the drawer with your skin when cleaning.

3.Insertthedrawerbackintoitsplaceaftercleaningand

make sure that it is seated well.

Ifyourdetergentdraweristheoneindicatedinthefollowing

figure:

Lift the rear part of the siphon to remove it as illustrated.

Afterperformingtheabovementionedcleaning

procedures,replacethesiphonbacktoitsseatingand

push its front section downwards to make sure that the

lockingtabengages.

5.2 Cleaning the loading door and the drum

Residuesofsoftener,detergentanddirtmayaccumulatein

your machine in time and may cause unpleasant odours and

washingcomplaints.Toavoidthis,usetheDrum Cleaning

programme.IfyourmachineisnotfeaturedwithDrum

Cleaningprogramme,useCottons-90programmeand

select Additional Water or Extra Rinse auxiliary functions

as well. Run the programme without any laundry in the

machine.Beforestartingtheprogramme,putmax.100

g of powder anti-limescale into the main wash detergent

compartment(compartmentnr.2).Iftheanti-limescaleisin

tabletform,putonlyonetabletintocompartmentnr.2.Dry

theinsideofthebellowwithacleanpieceofclothafterthe

programme has come to an end.

4.19 Machine is in Rinse Hold mode

SpinsymbolflashesandPausesymbolilluminateswhenthe

machine is in Rinse Hold mode.

Ifyouwanttospinyourlaundrywhenthemachineisinthis

mode:

AdjustthespinspeedandpressStart/Pause/Cancel

button.PausesymboldisappearsandStartsymbolappears.

Programmeresumes,dischargesthewaterandspinsthe

laundry.

Ifyouonlywanttodrainthewaterwithoutspinning:

JustpressStart/Pause/Cancelbutton.Pausesymbol

disappears.Startsymbolappears.Programmeresumesand

discharges the water only.

4.20 End of programme

“End”appearsonthedisplayattheendoftheprogramme.

Symbolsoftheprogrammestepsremainlit.Auxiliary

function,spinspeedandtemperaturethatwereselectedat

thebeginningoftheprogrammeremainselected.

4.21 Your machine is equipped

with a “Standby Mode”

Incaseofnotstartinganyprogrammeorwaitingwithout

making any other operation when the machine is turned

onbyOn/Offbuttonandwhileitisinselectionsteporif

no other operation is performed approximately 2 minutes

aftertheprogrammeyouselectedhascometoanend,

your machine will automatically switch to energy saving

mode.Brightnessofindicatorlightswilldecrease.Also,

ifyourproductisequippedwithadisplayshowingthe

programmeduration,thisdisplaywillcompletelyturnoff.In

caseofrotatingtheProgrammeSelectionknoborpressing

anybutton,lightsanddisplaywillrestoretotheirprevious

condition. Your selections made while exiting the energy

savingmodemaychange.Checktheappropriatenessof

yourselectionsbeforestartingtheprogramme.Readjustif

necessary. This is not a fault.

15 / EN

Washing Machine / User’s Manual

RepeatDrumCleaningprocessinevery2months.

Useananti-limescalesuitableforthewashingmachines.

Aftereverywashingmakesurethatnoforeignsubstanceis

left in the drum.

Iftheholesonthebellowshowninthefigureisblocked,

open the holes using a toothpick.

Foreignmetalsubstanceswillcauseruststainsinthe

drum.Cleanthestainsonthedrumsurfacebyusing

cleaning agents for stainless steel. Never use steel wool

or wire wool.

warning: Neverusespongeorscrubmaterials.Thesewill

damage the painted and plastic surfaces.

5.3 Cleaning the body and control panel

Wipethebodyofthemachinewithsoapywaterornon-

corrosivemildgeldetergentsasnecessary,anddrywitha

soft cloth.

Useonlyasoftanddampclothtocleanthecontrolpanel.

5.4 Cleaning the water intake filters

There is a filter at the end of each water intake valve at the

rear of the machine and also at the end of each water intake

hose where they are connected to the tap. These filters

preventforeignsubstancesanddirtinthewatertoenterthe

washingmachine.Filtersshouldbecleanedastheydoget

dirty.

1.Closethetaps.

2. Remove the nuts of the water intake hoses to access

thefiltersonthewaterintakevalves.Cleanthemwithan

appropriatebrush.Ifthefiltersaretoodirty,takethemout

bymeansofpliersandcleanthem.

3. Take out the filters on the flat ends of the water intake

hoses together with the gaskets and clean thoroughly

under running water.

4. Replace the gaskets and filters carefully in their places

andtightenthehosenutsbyhand.

5.5 Draining remaining water and

cleaning the pump filter

The filter system in your machine prevents solid items

suchasbuttons,coinsandfabricfiberscloggingthepump

impellerduringdischargeofwashingwater.Thus,thewater

willbedischargedwithoutanyproblemandtheservicelife

of the pump will extend.

Ifthemachinefailstodrainwater,thepumpfilterisclogged.

Filtermustbecleanedwheneveritiscloggedorinevery3

months.Watermustbedrainedofffirsttocleanthepump

filter.

Inaddition,priortotransportingthemachine(e.g.,when

movingtoanotherhouse)andincaseoffreezingofthe

water,watermayhavetobedrainedcompletely.

warning: Foreignsubstancesleftinthepumpfiltermay

damageyourmachineormaycausenoiseproblem.

Inordertocleanthedirtyfilteranddischargethewater:

1.Unplugthemachinetocutoffthesupplypower.

warning: Temperature of the water inside the machine

mayriseupto90ºC.Toavoidburningrisk,filtermustbe

cleaned after the water in the machine cools down.

2. Open the filter cap.

 Ifthefiltercapiscomposedoftwopieces,pressthe

tabonthefiltercapdownwardsandpullthepieceout

towards yourself.

Ifthefiltercapisonepiece,pullthecapfrombothsidesat

the top to open.

Youcanremovethefiltercoverbyslightlypushing

downwardswithathinplastictippedtool,throughthe

gapabovethefiltercover.Donotusemetaltippedtools

to remove the cover.

3.Someofourproductshaveemergencydraininghoseand

somedoesnothave.Followthestepsbelowtodischarge

the water.

16 / EN

Washing Machine / User’s Manual

Dischargingthewaterwhentheproducthasanemergency

draining hose:

a. Pulltheemergencydraininghoseoutfromitsseat

b. Placealargecontainerattheendofthehose.Drainthe

waterintothecontainerbypullingouttheplugattheend

ofthehose.Whenthecontainerisfull,blocktheinlet

ofthehosebyreplacingtheplug.Afterthecontaineris

emptied,repeattheaboveproceduretodrainthewaterin

the machine completely.

c. Whendrainingofwaterisfinished,closetheendbythe

plug again and fix the hose in its place.

d. Turn the pump filter to take it out.

Dischargingthewaterwhentheproductdoesnothavean

emergency draining hose:

a. Placealargecontainerinfrontofthefiltertocatchwater

from the filter.

b. Loosenpumpfilter(anticlockwise)untilwaterstartsto

flow. Fill the flowing water into the container you have

placedinfrontofthefilter.Alwayskeepapieceofcloth

handytoabsorbanyspilledwater.

c. Whenthewaterinsidethemachineisfinished,takeout

thefiltercompletelybyturningit.

4.Cleananyresiduesinsidethefilteraswellasfibers,if

any,aroundthepumpimpellerregion.

5.Installthefilter.

6.Ifthefiltercapiscomposedoftwopieces,closethefilter

capbypressingonthetab.Ifitisonepiece,seatthetabs

inthelowerpartintotheirplacesfirst,andthenpressthe

upper part to close.

17 / EN

Washing Machine / User’s Manual

Models (EN) SAW816

Maximum dry laundry capacity (kg) 8

Height (cm)

Width(cm) 60

Depth(cm)

Net weight (±4 kg.) 76

Electricalinput(V/Hz)

220-240V/50Hz

Totalcurrent(A) 10

Totalpower(W)

2000-2300

Spinspeed(rpm/min.,max.) 1600

Main model code

918

SingleWaterinlet/DoubleWaterinlet •/-

  WoolmarkNo:

6 Technical specifications

Technicalspecificationsmaybechangedwithoutpriornoticetoimprovethequalityoftheproduct.

Figures in this manual are schematic and may not match the product exactly.

Valuesstatedontheproductlabelsorinthedocumentationaccompanyingitareobtainedinlaboratoryconditionsinaccordance

withtherelevantstandards.Dependingonoperationalandenvironmentalconditionsoftheproduct,thesevaluesmayvary.

“TheWoolwashcycleofthismachinehasbeentestedandapprovedbyTheWoolmarkCompanyfor

thewashingofWoolmarkgarmentslabelledas“machinewash”providedthatthegarmentsarewashed

accordingtotheinstructionsonthegarmentlabelandthoseissuedbythemanufacturerofthiswashing

machine.”

“InUK,Eire,HongKongandIndiatheWoolmarktrademarkisaCertificationtrademark.”

18 / EN

Washing Machine / User’s Manual

7 Troubleshooting

Programme cannot be started or selected.

•Washingmachinehasswitchedtoselfprotectionmodeduetoasupplyproblem(linevoltage,waterpressure,etc.).>>>Press and hold

Start / Pause button for 3 seconds to reset the machine to factory settings. (See "Cancelling the programme")

Water in the machine.

•Somewatermighthaveremainedintheproductduetothequalitycontrolprocessesintheproduction.>>>This is not a failure; water is

not harmful to the machine.

Machine vibrates or makes noise.

•Machinemightbestandingunbalanced.>>>Adjust the feet to level the machine.

•Ahardsubstancemighthaveenteredintothepumpfilter.>>>Clean the pump filter.

•Transportationsafetyboltsarenotremoved.>>>Remove the transportation safety bolts.

•Laundryquantityinthemachinemightbetoolittle.>>>Add more laundry to the machine.

•Machinemightbeoverloadedwithlaundry.>>>Take out some of the laundry from the machine or distribute the load by hand to

balance it homogenously in the machine.

•Machinemightbeleaningonarigiditem.>>>Make sure that the machine is not leaning on anything.

Machine stopped shortly after the programme started.

•Machinemighthavestoppedtemporarilyduetolowvoltage.>>>It will resume running when the voltage restores to the normal level.

Programme time does not countdown. (On models with display)

•Timermaystopduringwaterintake.>>>Timer indicator will not countdown until the machine takes in adequate amount of water. The

machine will wait until there is sufficient amount of water to avoid poor washing results due to lack of water. Timer indicator will resume

countdown after this.

•Timermaystopduringheatingstep.>>>Timer indicator will not countdown until the machine reaches the selected temperature.

•Timermaystopduringspinningstep.>>>Automatic unbalanced load detection system might be activated due to the unbalanced

distribution of the laundry in the drum.

•Machinedoesnotswitchtospinningstepwhenthelaundryisnotevenlydistributedinthedrumtopreventanydamagetothemachineand

toitssurroundingenvironment.Laundryshouldberearrangedandre-spun.

Foam is overflowing from the detergent drawer.

•Toomuchdetergentisused.>>>Mix 1 tablespoonful softener and ½ l water and pour into the main wash compartment of the

detergent drawer.

•Putdetergentintothemachinesuitablefortheprogrammesandmaximumloadsindicatedinthe“Programmeandconsumptiontable”.

Whenyouuseadditionalchemicals(stainremovers,bleachsandetc),reducetheamountofdetergent.

Laundry remains wet at the end of the programme

•Excessivefoammighthaveoccurredandautomaticfoamabsorptionsystemmighthavebeenactivatedduetotoomuchdetergentusage.

>>>Use recommended amount of detergent.

•Machinedoesnotswitchtospinningstepwhenthelaundryisnotevenlydistributedinthedrumtopreventanydamagetothemachineand

toitssurroundingenvironment.Laundryshouldberearrangedandre-spun.

warning: Ifyoucannoteliminatetheproblemalthoughyoufollowtheinstructionsinthissection,consultyourdealerorthe

AuthorizedServiceAgent.Nevertrytorepairanonfunctionalproductyourself.

19 / EN

Washing Machine / User’s Manual

20 / EN

Washing Machine / User’s Manual

Smeg SAW816 8kg Front Load Washing Machine

Product's Documents

User Manual

Specifications

Smeg SAW816 Questions and Answers
