DOB30P977S | 30-INCH SINGLE WALL OVEN
ACCESSORIES (OPTIONAL)
COOKIE SHEETS (SET OF 3) SKU - ACSM303
GENERAL PROPERTI ES
COOKING MODES
BAKE, BROIL, CONVECTION
BAKE, CONVECTION ROAST,
CONVECTION BROIL, STEAM
BAKE, STEAM ROAST
ADD ITIONAL FEATURES
CLEANING TYPE SELF CLEAN & HYBRID CLEAN
CONTROLS 7” TFT LCD + KNOBS
WI FI YES
RACK POSITIONS 6
CONVECTION TYPE
FOUR PART DUAL PURE
CONVECTION
LIGHTING BRIGHTVUE™ - LED + HALOGEN
OVEN PERFORMANCE
BAKE 3,000W - 8 PASS
BROIL 4,400W - 10 PASS
CONVECTION ELEMENT 1,300W (EACH - 2,600W TOTAL)
STEAM RESERVOIR 650mL
CONTROL FEATURES
DELAY START YES
KITCHEN TIMER YES
SABBATH MODE YES
CHILD LOCK YES
ADDITIONAL MO DES
KEEP WARM YES
HEALTHY COOK YES
STEAM PROOF YES
DEHYDRATE YES
CHEF MODE YES
INSTANTHEAT™ YES
TEMPERATURE PROBE YES
AUTO CONVERSION YES
TECHN ICAL DETAI LS
CIRCUIT BREAKER (A) 30
VOLTS (V) 240 / 208
FREQUENCY (HZ) 60
ENERGY SOURCE ELECTRIC
D IMENS IONS & WE IGHT
APPLIANCE DIMENSIONS (W X H X D) (IN.) 29 3/4” X 28 7/8” X 24 1/2”
REQUIRED CUTOUT SIZE (W X H X D) (IN.) 30 1/4” X 29” X 24 7/8”
OVEN CAPACITY (CUBIC FEET) 5.1
NET WEIGHT (LBS) 176.8 LBS
WARRANTY
LIMITED, PARTS AND LABOR 2 YEARS
ACCESSORIES (INCLUDED)
GLIDERACK™ 2
STANDARD RACK 1
TEMPERATURE PROBE 1
MESH FILTER 2
AUTOMATIC WATER RESERVOIR 1
30-INCH SINGLE WALL OVEN
DOB30P977S | TRANSITIONAL STYLE
Exclusive Four-Part Dual Pure Convection - heat, air,
baffle and filter to precisely distribute heat for superior
cooking results.
Steam and Convection Oven - the power of steam assist
and convection cooking in one.
Oven capacity: 5.1 cu. ft.
Easy to use / refill water reservoir for steam cooking.
7” LCD control panel with Illumina™ knobs.
BrightVue™ - integrated LED lights in the oven door +
Halogen lights.
SoftShut™ oven doors.
SmartThings app with integrated Wi-Fi to control and
monitor remotely.
◊
◊
◊
◊
◊
◊
◊
FEATURES & BE NEFITS
◊
AVAILABLE MODELS
DOB30P 977SM
T
ransitional 30” Single Wall Oven - Silver Stainless Steel
