User Guide
Quality, Design and Innovation
home.liebherr.com/fridge-manuals
Contents
1 Appliance at a glance............................................ 3
1.1 Scope of delivery...................................................... 3
1.2 Overview of the appliance and features.................... 3
1.3 Appliance range of use............................................. 3
1.4 Conformity................................................................ 3
2 General safety instructions................................... 4
3 Putting into operation............................................ 5
3.1 Switching on appliance............................................. 5
3.2 Inserting the components......................................... 5
4 Foods management............................................... 5
4.1 Storing food.............................................................. 5
4.2 Storage times........................................................... 6
5 Saving energy........................................................ 7
6 Controls.................................................................. 7
6.1 Controls and displays............................................... 7
6.1.1 Status display.......................................................... 7
6.1.2 Navigation............................................................... 7
6.1.3 Display symbols...................................................... 8
6.2 Control concept........................................................ 8
6.2.1 Activating/deactivating the function......................... 8
6.2.2 Selecting function value.......................................... 8
6.2.3 Activating/deactivating settings............................... 8
6.2.4 Selecting the setting value.......................................9
6.2.5 Go to the Customer menu....................................... 9
6.3 Functions.................................................................. 9
Temperature............................................................ 9
SuperCool............................................................. 10
SuperFrost............................................................ 10
PowerCool.............................................................10
PartyMode.............................................................10
HolidayMode.........................................................10
EnergySaver..........................................................10
HydroCool............................................................. 10
HydroBreeze......................................................... 11
IceMaker / MaxIce.................................................11
6.4 Settings.................................................................... 11
Language.............................................................. 11
Connecting to the WLAN.......................................11
Entry lock.............................................................. 12
Display brightness.................................................12
Door alarm............................................................ 12
Info........................................................................ 12
SabbathMode........................................................12
CleaningMode.......................................................13
TubeClean.............................................................13
Ice cubes...............................................................13
BioFresh B-Value...................................................13
Reminder...............................................................13
Reset.....................................................................13
Turn off appliance.................................................. 13
6.5 Warnings.................................................................. 14
6.5.1 Message............................................................... 14
6.5.2 DemoMode........................................................... 14
7 Features.................................................................. 14
7.1 Door rack.................................................................. 14
7.2 Shelves.................................................................... 15
7.3 Dividing shelf............................................................ 16
7.4 Space for baking tray................................................ 16
7.5 Adjustable bottle shelf.............................................. 16
7.6 Drawers.................................................................... 17
7.7 Fruit & Vegetable safe cover..................................... 18
7.8 Adjusting the moisture levels.................................... 18
7.9 HydroBreeze............................................................ 19
7.10 IceMaker.................................................................. 19
7.11 VarioSpace............................................................... 20
7.12 Accessories.............................................................. 20
8 Maintenance........................................................... 21
8.1 FreshAir carbon filter................................................ 21
8.2 Defrosting the appliance........................................... 22
8.3 Cleaning the appliance............................................. 22
9 Customer help........................................................ 23
9.1 Technical specifications............................................ 23
9.2 Operating noises...................................................... 23
9.3 Technical fault........................................................... 24
9.4 Customer Services................................................... 25
9.5 Model plate............................................................... 25
10 Shutting down........................................................ 25
11 Disposing of the appliance................................... 25
The manufacturer works constantly on the further development
of all the types and models. Therefore please understand that
we have to reserve the right to make design, equipment and
technical modifications.
To get to know all the benefits of your new appliance, please
read the information contained in these instructions carefully.
The instructions apply to several models. Differences may
occur. Text relating only to specific appliances is marked with
an asterisk (*).
Instructions are marked with a , and results are marked
with a .
These operating instructions apply to:
ICBN(h) 51..
2 * Depending on model and options
1 Appliance at a glance
1.1 Scope of delivery
Check all parts for damage during transport. If you have any
complaints, please contact your retailer or Customer Services
(see 9.4 Customer Services) .
Your new appliance comes with the following parts:
-
Built-in appliance
-
Features (depending on the model)
-
Installation materials (depending on the model)
-
User Guide
-
Installation Guide
1.2 Overview of the appliance and
features
Fig. 1 Example illustration
Temperature range
(A) Fridge compartment (C) Freezer compartment
(B) BioFresh
(D) Coldest zone
Features
(1) Controls (11) Outlet
(2) Fan with FreshAiracti-
vated charcoal filter
(12) Meat & Dairy safe
(3) Stainless steel rear wall (13) Freezer compartment
(4) Separable storage shelf (14) IceMaker
(5) Storage shelve (15) VarioSpace
(6) Space for baking tray (16) Freezer tray
(7) Adjustable bottle shelf (17) Serial tag
(8) HydroBreeze (18) Door shelf
(9) Fruit & Vegetable safe
cover
(19) Bottle holder
(10) Fruit & Vegetable safe (20) VarioBoxes
Note
u
Shelves, drawers and baskets are arranged for optimum
energy efficiency when the appliance is delivered. Changing
how the shelves, for example, are inserted in the fridge
compartment does not have any impact on energy
consumption.
1.3 Appliance range of use
Intended use
The appliance is only suitable for cooling food
products in a domestic or household-like envi-
ronment. This includes, for example, use:
-
in staff kitchens, bed and breakfast establish-
ments,
-
by guests in country houses, hotels, motels
and other accommodation,
-
for catering and similar services in the whole-
sale trade.
All other types of use are not permitted.
Foreseeable misuse
The following applications are expressly
forbidden:
-
Storing and refrigerating medicines, blood
plasma, laboratory preparations or similar
substances and products based on the
Medical Device Directive 2007/47/EC
-
Use in outdoor areas with very high humidity
-
Use in areas at risk of explosions
Misusing the appliance may lead to damage to
the goods stored or they may spoil.
Climate classifications
Depending on the climate classification the
appliance is designed to operate in restricted
ambient temperatures. The climate classifica-
tion applying to your appliance is printed on the
rating plate.
Note
u
Keep to the specified ambient temperatures
in order to guarantee that the appliance works
properly.
Climate classi-
fication
for ambient temperatures of
SN 10 °C to 32 °C
N 16 °C to 32 °C
ST 16 °C to 38 °C
T 16 °C to 43 °C
1.4 Conformity
The refrigerant circuit has been tested for leaks. When
installed, the appliance complies with the applicable safety
regulations and with the directives 2014/35/EU, 2014/30/EU,
2009/125/EC, 2011/65/EU, 2010/30/EU and 2014/53/EU.
Appliance at a glance
* Depending on model and options 3
The full text of the EU Declaration of Conformity is available on
the following website: www.Liebherr.com
The BioFresh compartment meets the requirements of a cold
storage compartment as set out in DIN EN 62552:2020.
2 General safety instructions
Danger for the user:
-
This device can be used by children and
people with impaired physical, sensory or
mental abilities or with a lack of experi-
ence and knowledge provided that they are
supervised or have received instruction in
the safe use of this device, and about the
resulting hazards. Children must not play
with this appliance. Cleaning and user main-
tenance work must not be carried out by chil-
dren without adult supervision. Children aged
between 3 and 8 are allowed to load and
unload the appliance. Children below the age
of 3 must be kept away from the appliance
unless they are under continuous adult super-
vision.
-
When disconnecting the appliance from the
supply, always take hold of the plug. Do not
pull the cable.
-
In the event of a fault pull out the mains plug
or deactivate the fuse.
-
Do not damage the mains power cable. Do
not operate the appliance with a defective
mains power cable.
-
Only customer service or other specially
trained staff may repair or perform other oper-
ations on the appliance.
-
Only install, connect and dispose of the appli-
ance according to the instructions.
-
Only use the appliance when it is installed.
-
Please keep these instructions in a safe place
and pass them on to any subsequent owners.
-
The manufacturer is not liable for damage
caused by a faulty fixed water connection.
Fire hazard:
-
The coolant used (information on the model
plate) is eco-friendly but also flammable. Any
leaking coolant may ignite.
•
Do not damage the refrigerant circuit pipes.
•
Do not handle ignition sources inside the
appliance.
•
Do not use electrical appliances inside the
appliance (e.g. steam cleaners, heaters, ice
cream makers, etc.).
•
If the refrigerant leaks: remove any naked
flames or ignition sources from the vicinity
of the leakage point. Properly air the room.
Inform customer services.
-
Do not store explosives or sprays using
combustible propellants such as butane,
propane, pentane, etc. in the appliance. To
identify these spray cans, look for the list
of contents printed on the can, or a flame
symbol. Gases possibly escaping may ignite
due to electrical components.
-
Please be sure to store alcoholic drinks or
other packaging containing alcohol in tightly
closed containers. Any alcohol that leaks out
may be ignited by electrical components.
Danger of tipping and falling:
-
Do not misuse the plinth, drawers, doors etc.
as a step or for support. This applies particu-
larly to children.
Danger of food poisoning:
-
Do not consume food which has been stored
too long.
Danger of frostbite, numbness and pain:
-
Avoid prolonged skin contact with cold
surfaces or refrigerated/frozen goods or take
protective measures, e.g wear use gloves.
Danger of injury and damage:
-
Hot steam can lead to injury. Do not use elec-
trical heating or steam cleaning equipment,
open flames or defrosting sprays to defrost.
-
Do not use sharp implements to remove the
ice.
Danger of crushing:
-
Do not hold the hinge when opening and
closing the door. Fingers may get caught.
Symbols on the appliance:
The symbol can be located on the
compressor. It refers to the oil in the
compressor and indicates the following
danger: Swallowing or inhaling can be fatal.
This is only relevant for recycling. There is no
danger in normal operation.
This symbol is found on the compressor and
indicates the danger of flammable materials.
Do not remove the sticker.
A sticker to this effect may be applied to
the rear of the appliance. It refers to the
foam-padded panels in the door and/or the
housing. This is only relevant for recycling. Do
not remove the sticker.
Please observe the specific information in
the other sections:
DANGER identifies a situation involving direct
danger which, if not obviated, may
result in death or severe bodily
injury.
General safety instructions
4 * Depending on model and options
WARNING identifies a dangerous situation
which, if not obviated, may result in
death or severe bodily injury.
CAUTION identifies a dangerous situation
which, if not obviated, may result in
minor or medium bodily injury.
NOTICE identifies a dangerous situation
which, if not obviated, may result in
damage to property.
Note It contains useful instructions and
tips.
3 Putting into operation
3.1 Switching on appliance
Ensure that the following conditions are met:
q
Appliance is installed and connected according to installa-
tion instructions.
q
All adhesive strips, adhesive and protective films as well
as transport safety devices in and on the appliance are
removed.
q
All marketing leaflets are removed from the drawers.
u
Switch on the appliance from the display.
Fig. 2
*
u
After switching on the appliance, select the language.
Fig. 3
u
The status screen appears.
u
If the DemoMode is displayed together with the blue screen
after switching on the appliance, the DemoMode can be
deactivated within the next 5 minutes.
Fig. 4
u
Press DemoMode for 3 seconds.
w
DemoMode is off.
Note
The manufacturer recommends:
u
Storing food: wait approx. 6 hours for the set temperature to
be reached.
u
Store frozen produce at -18 °C or colder.
3.2 Inserting the components
u
Insert the supplied components to make the most of your
appliance.
u
Purchase and install the SmartDevice Box (see https://
smartdevice.liebherr.com/install).
u
Install the SmartDevice app (see https://
apps.home.liebherr.com/).
Note
You can purchase accessories from the Liebherr household
appliance store (home.liebherr.com).
4 Foods management
4.1 Storing food
WARNING
Risk of fire
u
Do not use any electrical appliances in the food area of the
appliance unless recommended by the manufacturer.
Note
The energy consumption increases and the cooling power
goes down if ventilation is not sufficient.
u
Always keep air slots clear.
When storing food, always observe the following:
q
Air vents on the inside rear wall are unobstructed.
q
Air vents on the fan are unobstructed.
q
Food is in sealed packaging.
q
Foods that easily absorb or give off smell or taste are stored
in sealed containers or covered.
q
Raw meat and fish are in clean, sealed containers to prevent
them coming into contact with or dripping onto other foods.
q
Liquids are in sealed containers.
q
Foods are not stored too closely together, as the air needs
to circulate.
Note
Failure to follow these guidelines can lead to food perishing.
4.1.1 Fridge section
The natural air circulation creates a range of temperatures.
Arrange your food as follows:
Putting into operation
* Depending on model and options 5
u
In the top section and in the door: butter and cheese,
preserves and tubes.
u
In the coldest zone
Fig. 1 (D)
: easily perishable food such as
prepared meals.
4.1.2 BioFresh
BioFresh helps certain fresh foods stay fresh for longer
compared to conventional cooling methods.
In the case of foods with a minimum shelf life, the date indi-
cated on the packaging still applies.
If the temperature drops below 0 °C, foods can freeze.
Note
Store cold-sensitive fruit and vegetables such as cucumbers,
aubergines, courgettes and tropical fruit in the cooling section.
Fruit & Vegetable-Safe
This provides a fresh storage climate with the lid closed. A
moist climate is suitable for storing loose foods with a high
moisture content (e.g. salad, vegetables, fruit).
The air moisture in the compartment depends on the moisture
content of the items being stored and the number of times the
door is opened. You can adjust the air moisture.
Arrange your food as follows:
u
Store your loose fruit and vegetables.
u
Excessive air moisture: Regulate the air humidity
(see 7.8 Adjusting the moisture levels) .
Meat & Dairy-Safe
Here a relatively dry storage climate is set. A dry climate is
great for dry or packaged foods (e.g. dairy products, meat, fish,
sausage).
Arrange your food as follows:
u
Place the dry or packaged foods inside.
4.1.3 Freezer compartment
This provides a dry, frosty storage climate at -18 °C. A frosty
climate is great for storing frozen food and frozen goods for
several months, making ice cubes and freezing fresh food.
Freezing food
You can freeze as many kilograms of fresh food within 24 hours
as indicated on the nameplate (see 9.5 Model plate) under
"freezing capacity ... kg/24h".
So that the food is rapidly frozen through to the core, keep to
the following quantities per pack:
-
Fruit, vegetables up to 1 kg
-
Meat up to 2.5 kg
Before freezing goods, please make sure of the following:
q
SuperFrost is activated (see 6.3 Functions) when the
amount of food to freeze exceeds approx. 2 kg.
q
With a small amount to freeze: SuperFrost is on for about 6
hours beforehand.
q
With a maximum amount to freeze: SuperFrost is on for
about 24 hours beforehand.
Arrange your food as follows:
CAUTION
Risk of injury from glass fragments!
Drink bottles and cans may explode if frozen. This applies
particularly to carbonated drinks.
u
Only freeze drink bottles and cans when using the
bottle
timer
function.
With a small amount to freeze:
u
Put packaged food in the top drawers.
With a maximum amount to freeze:
u
Remove the top drawers and place the packaged food onto
the top shelves.
With the maximum frozen quantities:
u
Once SuperFrost turns off automatically, place the food in
the drawer compartment.
Defrost the food
- In the fridge
- In the microwave
- In the stove/oven
- At room temperature
WARNING
Risk of food poisoning!
u
Do not re-freeze thawed food.
u
Only take out the food you need at the time.
u
Cook defrosted food as soon as possible.
Freezer tray
Use the freezer tray for berries, herbs, vegetables and other
small goods without them freezing together in the process. The
food keeps its shape and is easier to separate into portions
later on.
You can also store the freezer packs in the freezer tray to save
space.
u
Spread food, unsealed, at a good distance apart, over the
whole surface of the freezer tray.
4.2 Storage times
Refer to the specified storage times as a guide.
In the case of foods with a minimum shelf life, the date indi-
cated on the packaging still applies.
4.2.1 Fridge section
Always follow the best-before date stated on the packaging.
4.2.2 BioFresh
Note
You can also use the guides in the BioFresh
app https://home.liebherr.com/de/deu/service/apps/landing-
page-apps-emea.html .
Recommended storage periods in the Meat & Dairy-Safe
Butter at 1 °C up to 90 days
Hard cheese at 1 °C up to 110 days
Milk at 1 °C up to 12 days
Sausage, cold meats at 1 °C up to 8 days
Poultry at 1 °C up to 6 days
Pork at 1 °C up to 6 days
Beef at 1 °C up to 6 days
Game at 1 °C up to 6 days
Note
u
Remember that high-protein foods perish quicker; shellfish
and crustaceans do not last as long as fish, and fish does
not last as long as meat.
Recommended storage periods in the Fruit & Vegetable-
Safe
Vegetables, salads
Foods management
6 * Depending on model and options
Recommended storage periods in the Fruit & Vegetable-
Safe
Artichokes at 1 °C up to 14 days
Celery at 1 °C up to 28 days
Cauliflower at 1 °C up to 21 days
Broccoli at 1 °C up to 13 days
Chicory at 1 °C up to 27 days
Lettuce at 1 °C up to 19 days
Peas at 1 °C up to 14 days
Kale at 1 °C up to 14 days
Carrots at 1 °C up to 80 days
Garlic at 1 °C up to 160 days
Turnip at 1 °C up to 14 days
Lettuce at 1 °C up to 13 days
Herbs at 1 °C up to 13 days
Leeks at 1 °C up to 29 days
Mushrooms at 1 °C up to 7 days
Radishes at 1 °C up to 10 days
Brussels sprouts at 1 °C up to 20 days
Asparagus at 1 °C up to 18 days
Spinach at 1 °C up to 13 days
Savoy at 1 °C up to 20 days
Fruit
Apricots at 1 °C up to 13 days
Apples at 1 °C up to 80 days
Pears at 1 °C up to 55 days
Blackberries at 1 °C up to 3 days
Dates at 1 °C up to 180 days
Strawberries at 1 °C up to 7 days
Figs at 1 °C up to 7 days
Blueberries at 1 °C up to 9 days
Raspberries at 1 °C up to 3 days
Currants at 1 °C up to 7 days
Sweet cherries at 1 °C up to 14 days
Kiwis at 1 °C up to 80 days
Peaches at 1 °C up to 13 days
Plums at 1 °C up to 20 days
Cranberries at 1 °C up to 60 days
Rhubarb at 1 °C up to 13 days
Gooseberries at 1 °C up to 13 days
Grapes at 1 °C up to 29 days
4.2.3 Freezer compartment
Recommended storage period for various types of food
Ice cream at -18 °C 2 to 6 months
Sausages, ham at -18 °C 2 to 3 months
Recommended storage period for various types of food
Bread, baked goods at -18 °C 2 to 6 months
Game, pork at -18 °C 6 to 9 months
Fatty fish at -18 °C 2 to 6 months
Lean fish at -18 °C 6 to 8 months
Cheese at -18 °C 2 to 6 months
Poultry, beef at -18 °C 6 to 12 months
Vegetables, fruit at -18 °C 6 to 12 months
5 Saving energy
-
Pay attention to good ventilation. Do not cover ventilation
holes or grids.
-
Always keep the fan air slits clear.
-
Do not install the appliance in direct sunlight, next to an
oven, radiator or similar.
-
Energy consumption depends on the installation conditions,
e.g. the ambient temperature (see 1.3 Appliance range of
use) . A warmer ambient temperature can increase the
energy consumption.
-
Open the appliance for as short a time as possible.
-
The lower the temperature is set the higher the energy
consumption.
-
Sort your food: home.liebherr.com/food.
-
Keep all food properly packed and covered. This prevents
frost from forming.
-
Only take food out for as long as necessary so that it doesn’t
warm up too much.
-
Inserting warm food: allow to cool down to room temperature
first.*
-
Thaw frozen food in the refrigerator.
-
For longer periods of absence, use HolidayMode (see Holi-
dayMode) .
6 Controls
6.1 Controls and displays
The display provides a quick overview of the temperature
setting and the status of functions and settings. You can control
the functions and settings either by deactivating/activating them
or by selecting a value.
6.1.1 Status display
Fig. 5
(1) Temperature display of
the fridge section
(3) Freezer compartment
temperature display
(2) Temperature display
BioFresh
The Status display shows the set temperatures and is the
home display. From there, you can navigate to the options and
settings.
6.1.2 Navigation
Navigate in the menu to see the individual functions. An audible
signal sounds after confirming a function or setting. If no selec-
Saving energy
* Depending on model and options 7
tion is made after 10 s the display switches to the Status
screen.
The appliance is operated by swiping and confirming in the
display:
Fig. 6
Back:
-
Confirm your selection in the submenu. The display returns
to the menu.
-
. The display returns to the function/setting.
Back to Status display:
-
Close and open the door.
-
Wait 10 s. The display switches to the Status display.
6.1.3 Display symbols
Display symbols provide information on the current appliance
status:
Symbol Appliance status
Standby
The appliance or temperature zone is
switched off.
Flashing number
Appliance is working. Temperature
flashes until the set temperature is
reached.
Flashing symbol
Appliance is working. Setting is made.
6.2 Control concept
6.2.1 Activating/deactivating the function
You can activate/deactivate the following functions:
Symbol Function
SuperCool
x
PowerCool
x
SuperFrost
x
Symbol Function
IceMaker and MaxIce
x
PartyMode
x
HolidayMode
EnergySaver
HydroBreeze
HydroCool
x
When a function is on, the appliance works harder. This
means the appliance could make louder noises and consume
more energy.
u
Swipe left in the display until the function appears.
u
Confirm selected function with a short tap.
w
You hear the confirmation tone.
w
Status appears in the menu.
w
Function is on/off.
6.2.2 Selecting function value
With the following functions you can set a value in the
submenu:
Symbol Function
Cool:
Setting the temperature
Turn on/off the temperature zone
Freeze:
Setting the temperature
Turn on/off the temperature zone
u
Swipe left in the display until the function appears.
u
Confirm selected function with a short tap.
u
Select the setting value by swiping the display.
Setting the temperature
u
Confirm with a short tap.
w
You hear the confirmation tone.
w
The display changes to blue when active.
w
Display switches back to the menu.
Switching the temperature zone on/off
u
To Confirm, press for 3 seconds.
w
You hear the confirmation tone.
w
Display returns to the Status screen.
6.2.3 Activating/deactivating settings
You can activate/deactivate the following settings:
Symbol Setting
WiFi
1
Entry lock
2
Controls
8 * Depending on model and options
Symbol Setting
SabbathMode
2
Cleaning Mode
2
Reminders
1
Reset
2
Off
2
u
Swipe left in the display until Settings appears.
u
Tap to confirm settings.
u
Swipe until you see the setting you want.
1
Activate setting (shortpress)
u
Tap briefly to confirm.
w
You hear the confirmation tone.
w
Status appears in the menu.
w
Setting is on / off.
2
Activate setting (longpress)
u
Press the selection for 3 seconds to confirm.
w
You hear the confirmation tone.
w
Status appears in the menu.
w
Display changes.
6.2.4 Selecting the setting value
With the following settings you can set a value in the submenu:
Symbol Settings
Brightness
Door alarm
Language
u
Swipe left in the display until Settings appears.
u
Tap to confirm settings.
u
Swipe until you see the setting you want.
u
Tap briefly to confirm.
u
Select the desired setting value by swiping the display.
u
Tap briefly to confirm.
w
You hear the confirmation tone.
w
Status appears briefly in the submenu.
w
Display switches back to the menu.
6.2.5 Go to the Customer menu
You can see the following settings in the Customer menu:
Symbol Function
BioFresh B-Value
1
TubeClean
2
Symbol Function
Ice cubes
1
u
Swipe left in the display until Settings appears.
u
Confirm settings by tapping.
u
Swipe until About appliance appears in the display.
u
Confirm with a short tap.
u
Go to the Customer menu: Enter the code 151.
u
Swipe in the customer menu until you see the setting you
want.
1
Select the value
u
Confirm with a short tap.
w
You hear the confirmation tone.
w
Status appears briefly in the display.
w
Display switches back to the menu.
2
Activate the setting
u
To confirm, press the display for 3 seconds.
w
You hear the confirmation tone.
w
Status appears on the display.
w
The symbol flashes as long as the appliance is working.
6.3 Functions
Temperature
The temperature depends on the following factors:
-
The amount of times the door is opened
-
How long the door is open for
-
The room temperature of the installation site
-
The type, temperature and amount of food
Temperature zone Recommended setting
Fridge section
5 °C
Freezer compart-
ment
-18 °C
Setting the temperature
Fig. 7
*
u
Set the value. (see 6.2 Control concept) .
w
Set temperature is shown at the bottom right of the display.
Switching off a temperature zone
You can switch the fridge compartment off separately.
Switching off the freezer section turns off all the temperature
zones.
u
Deactivate IceMaker.
u
Set the value. (see 6.2 Control concept) .
Controls
* Depending on model and options 9
w
appears.
SuperCool
This function selects the lowest cooling temperature. This gives
you colder storage temperatures.
This function is relevant to the fridge section
Fig. 1 (A)
Use:
-
Cool large amounts of food quickly.
Activating/deactivating the function
u
Using the fridge section: activate the function when you add
the goods.
u
Activating/deactivating (see 6.2 Control concept) .
The function automatically turns off. The appliance goes back
to normal mode. The temperature adjusts itself to the set level.
SuperFrost
This function selects the lowest freezing temperature. This
gives you colder storage temperatures.
This function refers to the freezer section
Fig. 1 (C)
.
Use:
-
For storing more than 2 kg fresh food every day.
-
Freezing fresh food quickly to the core.
-
Increasing the cold reserves in the stored goods before
defrosting the appliance.
Activating/deactivating the function
With a small amount to freeze:
u
Activate 6 hours before use.
With a maximum amount to freeze:
u
Activate 24 hours before use.
u
Activating/deactivating (see 6.2 Control concept) .
The function automatically turns off. The appliance goes back
to normal mode. The temperature adjusts itself to the set level.
PowerCool
This function provides the perfect blanket temperature to cool
your food.
This function refers to the fridge section
Fig. 1 (A)
.
Use:
-
At higher room temperatures (from approx. 35 °C )
-
When humidity is high e.g. on summer days
-
When storing moist goods, to avoid condensation building
up inside
Activating/deactivating the function
u
Activating/deactivating (see 6.2 Control concept) .
Note
The fan can run even when function is deactivated. This
ensures optimal temperature distribution in the appliance.
w
Function activated: Energy consumption of the appliance is
slightly increased.
PartyMode
This option offers an assortment of special functions and
settings that are useful if you are having a party.
The following functions are on:
-
SuperCool
-
IceMaker
and
MaxIce
All the functions can be adjusted flexibly and separately.
Changes are discarded when the function turns off.
Activating/deactivating the function
u
Activating/deactivating (see 6.2 Control concept) .
w
On: All functions are activated at the same time.
w
Off: Preset temperatures are restored.
After 24 hours the function turns off automatically.
HolidayMode
This function minimises the energy consumption during
an extended absence. The temperature of the refrigerator
compartment is set to 15 °C and this is displayed on the status
screen when the temperature has been reached.
The set freezer temperature remains unchanged.
This function refers to the fridge section
Fig. 1 (A)
.
Use:
-
Save energy if you plan to be away for a while.
-
Avoid coming home to bad smells and mould.
Activating/deactivating the function
u
Empty everything from the fridge section.
u
Activating/deactivating (see 6.2 Control concept) .
w
On: Fridge temperature is raised.
w
Off: the previously set temperature is restored.
EnergySaver
This function reduces energy consumption. If you activate this
function, the cooling temperature increases.
Temperature zone Recom-
mended
setting
Temperature when
EnergySaver acti-
vated
Fridge compart-
ment
5 °C 7 °C
Freezer compart-
ment
-18 °C -16 °C
Use:
-
Save energy.
Activating/deactivating the function
u
Activating/deactivating (see 6.2 Control concept) .
w
Activated: Higher temperatures are set in all temperature
zones.
w
Deactivated: Previously set temperatures are restored.
HydroCool
The air humidity in the appliance can be set depending on
which foodstuffs are to be stored. The HydroCool produces a
moist climate. When the drawer is full a very fresh climate is set
with a humidity of up to a max. of 90 %.
Use:
-
For storing loose salad, vegetables and fruit with a high
moisture content.
Controls
10 * Depending on model and options
Activating/deactivating the function
u
Activating/deactivating (see 6.2 Control concept) .
HydroBreeze
HydroBreeze creates a fine mist in the drawer every 90 minutes
for 4 seconds when the door is closed. This function is also
activated when you open the door. The function is not activated
when the appliance is delivered.
Use:
-
For storing loose salad, vegetables and fruit with a high
moisture content.
Choose from these options:
•
1: Duration of function while opening door 4 s
•
2: Duration of function while opening door 6 s
•
3: Duration of function while opening door 8 s
•
Off: HydroBreeze is off.
Activating/deactivating the function
u
Activating/deactivating (see 6.2 Control concept) .
IceMaker / MaxIce
This function creates ice cubes.
This function refers to the freezer compartment
Fig. 1 (C)
.
Use:
-
If this function is activated, you can decide between the
normal IceMaker function and MaxIce.
-
The MaxIce function enables your appliance to make
approx. 1.5 kg of ice cubes per 24 h within a short time.
The ice cube size can be set with the ice cube size function.
(see Ice cubes)
The lines can be cleaned with the TubeClean function.
(see TubeClean)
Activating the function
Ensure that the following conditions are met:
q
The water supply is established at the fixed water connec-
tion. See installation instructions.
q
IceMaker is put into operation. (see 7.10 IceMaker)
u
Activate the function. (see 6.2 Control concept)
-or-
u
Activate the function via the Liebherr SmartDevice-App.
w
It can take up to 24 hours for the first ice cubes to be made.
Deactivating the function
u
Deactivate the function. (see 6.2 Control concept)
w
If ice cubes are currently being made, the system completes
the process. After that, the IceMaker switches off.
Note
IceMaker
is deactivated: Groceries up to a max. height of
10 cm can be stored in the drawer for freezing.
6.4 Settings
Language
This setting lets you choose the language of the display.
Choose from the following languages:
-
German
-
English
-
French
-
Spanish
-
Italian
-
Dutch
-
Czech
-
Polish
-
Portuguese
-
Russian
-
Chinese
Activating/deactivating settings
u
Activating/deactivating (see 6.2 Control concept) .
Connecting to the WLAN
This setting connects the appliance to the internet. The
connection is managed in the SmartDevice-Box. You can use
the SmartDevice-App to add your appliance to a SmartHome-
System. Use the SmartDevice-App or other compatible partner
networks to enjoy advanced options and settings.
Note
The SmartDevice Box is available from the Liebherr home
appliance store (home.liebherr.com).
More information about availability, requirements and
the individual options, can be found online at smartde-
vice.liebherr.com.
Use:
-
Manage the appliance with the SmartDevice-App or a
compatible partner network.
-
Enjoy advanced functions and settings.
-
Check the current status of the appliance in the SmartDe-
vice-App.
q
The SmartDevice Box is purchased and installed (see
https://smartdevice.liebherr.com/install).
q
The SmartDevice app is installed (see https://
apps.home.liebherr.com/).
Setting up the connection
Fig. 8
*
u
Activating the setting (see 6.2 Control concept) .
w
The connection is set up: Connecting appears. The symbol
flashes.
w
The connection is set up: WiFi appears, the display turns
blue.
w
The connection failed: WiFi Error appears.
Disconnecting the appliance
u
Deactivate the setting (see 6.2 Control concept) .
Controls
* Depending on model and options 11
Fig. 9
*
w
There is no connection: The symbol is displayed
constantly.
Restoring the connection
u
Restore settings (see 6.2 Control concept) .
Fig. 10
*
w
Connection and other settings are restored to factory
settings.
Entry lock
This setting prevents unintentional use of the appliance, e.g. by
children.
Use:
-
Avoid settings being changed unintentionally.
-
Avoid the appliance being switched off unintentionally.
-
Avoid the temperature being changed unintentionally.
Activating/deactivating settings
u
Activating/deactivating. (see 6.2 Control
concept)
Display brightness
Set the brightness level of the display.
You can set the following brightness levels:
-
40%
-
60%
-
80%
-
100%
Choose the setting
u
Set the level (see 6.2 Control concept) .
Door alarm
Set the time before the door alarm (see Close door) sounds.
The options are as follows:
-
1 min
-
2 min
-
3 min
-
Off
Choose the setting
u
Set the time (see 6.5 Warnings) .
Info
This setting allows the appliance information to be read out as
well as access to the customer menu.
It provides the following information:
-
Model name
-
Index
-
Serial number
-
Service number
Show appliance data
u
Swipe in the display until Settings appears.
u
Confirm the display.
u
Swipe in the display until About appears.
u
Read the appliance info.
SabbathMode
This setting meets the religious requirements on the Sabbath
and Jewish festivals. Turn on SabbathMode to switch off
certain controls. This means you can use the appliance without
anyone changing the settings.
You can find a list of Star-K-certified appliances at www.star-
k.org/appliances.
WARNING
Danger of food poisoning.
If there is a power cut while the appliance is in SabbathMode,
this message is not saved. Once power is restored, the appli-
ance continues in SabbathMode. When this mode is over no
message about the power cut is displayed on the temperature
display.
If there was a power cut during SabbathMode:
u
Check the food for quality. Do not eat the food if it has
thawed.
What happens on the appliance when in SabbathMode:
-
The Status display permanently shows SabbathMode.
-
The display is locked for all functions apart from turning off
SabbathMode.
-
Any functions/settings that are already on, remain active.
-
The display stays bright when the door is closed.
-
Reminders are disabled. The set time intervals are also
paused. This function is disabled in SabbathMode.
-
Reminders and warnings are not displayed. There are no
acoustic signals, and the display does not show warnings or
settings such as temperature alarm or door alarm.
-
The IceMaker is out of use.
-
The internal light is off.
-
The defrost cycle only works for the specified time without
taking account of fridge use.
-
After a power cut the appliance automatically returns to
SabbathMode.
Controls
12 * Depending on model and options
Activating/deactivating SabbathMode
u
To activate this function, swipe the display until you see
Settings
in the menu and press for 1 second. The menu
changes to show the available settings.
u
Swipe the display until you see the SabbathMode (Menora)
symbol. Press the symbol for 3 seconds.
w
The display changes colour.
w
SabbathMode is activated.
To deactivate the function, press the display for 3 seconds.
SabbathMode is deactivated.
CleaningMode
Use this setting to easily clean the appliance.
This setting refers to the fridge section
Fig. 1 (A)
.
Use:
-
Clean the fridge section by hand.
What happens on the appliance when this setting is on:
-
The display permanently shows: CleaningMode.
-
The fridge section is switched off.
-
The internal light is on.
-
Reminders and warnings are not shown. There is no
acoustic signal.
Activating/deactivating settings
u
Activating/deactivating the setting (see 6.2 Control
concept) .
w
On: fridge section is off. Light stays on.
w
Off: preset temperature is restored.
After 60 min the setting turns off automatically. The appliance
then continues running in normal mode.
TubeClean
This setting cleans the IceMaker pipes.
Ensure that the following conditions are met:
q
IceMaker cleaning is ready (see 8.3.5 Cleaning the
IceMaker) .
Activating the setting
u
Activate the setting in the Customer menu (see 6.2 Control
concept) .
w
The rinse process is ready (max. 60 min.): Symbol flashes.
w
Water pipes are rinsed: Symbol flashes.
w
Rinsing process is complete: Function turns off automati-
cally.
Ice cubes
Set the ice cube size.
Choose the setting
u
Set the size in the Customer menu (see 6.2 Control
concept) .
BioFresh B-Value
When delivered, the temperature in the BioFresh compart-
ment is set to B5. The status indicator on the display shows
the appropriate target temperature in the full-space BioFresh
compartment.
You can change this value slightly if a higher or lower ambient
temperature makes it necessary. When setting the value, note:
Value Description
B1 Lowest temperature
B1-B4 The temperature can drop to under 0 °C, so food can
freeze easily.
B5 Default temperature
B9 Highest temperature
BioFresh B-Value
Choose the setting
u
Set the size in the Customer menu (see 6.2 Control
concept) .
Reminder
Reminders are given out acoustically by a beep and visually by
a symbol in the display. The signal gets louder until the alert
stops.
Replace FreshAir active carbon filter
This message appears when the air filter needs replacing.
u
Change the air filter every six months.
u
Confirm the message with OK.
w
The service interval resets.
w
The air filter guarantees the air quality in the fridge.
Insert IceMaker drawer
This message appears if the IceMaker drawer is open.
u
Push the IceMaker drawer in.
w
The message disappears.
w
The IceMaker produces ice cubes.
Activating the setting
u
Activating/deactivating (see 6.2 Control concept) .
Reset
This function resets all settings to the factory settings. All
settings that you have made thus far will be reset to their orig-
inal values.
Activating the setting
u
Activate (see 6.2 Control concept) .
Turn off appliance
This setting turns off the whole appliance.
Controls
* Depending on model and options 13
Switching off the entire appliance
Fig. 11
*
u
Turning off the IceMaker .
u
Activating/deactivating (see 6.2 Control concept) .
w
Off: Display goes black.
6.5 Warnings
Warnings are issued with an acoustic signal and visually with
a symbol on the display. The signal gets louder until the alert
stops.
6.5.1 Message
Close door
This message appears if the door is open for too long.
You can set how long it takes for this message to appear .
u
Stop alarm: Confirm the message.
-or-
u
Close the door.
Power cut
This message appears if the freezer temperature increased
due to a power cut. After the power is restored, the appliance
continues to work at the set temperature.
u
Stop alarm: Confirm the message.
w
Temperature alert appears (see Temperature alarm) .
Temperature alarm
This message appears if the freezer temperature does not
match the set temperature.
Variations in temperature could be because:
-
Hot, fresh food was inserted.
-
Too much warm room air flowed in when rearranging and
removing food.
-
The power was cut off for a while.
-
The appliance is faulty.
When the fault is eliminated the appliance continues to work at
the set temperature.
u
Confirm the display.
w
The highest temperature is shown.
u
Confirm display again.
w
The status display is displayed.
w
The current temperature is shown.
Error
This message appears if there is a fault with the appliance. An
appliance component indicates a fault.
u
Open the door.
u
Note down the fault code.
u
Confirm the message.
w
The audible signal stops.
w
The display switches to the Status screen.
u
Close the door.
u
Contact Customer Services (see 9.4 Customer Services) .
6.5.2 DemoMode
If “D” appears on the display, demo mode is on. This option is
designed for retailers, as it turns off all the cooling functions.
Stopping DemoMode
If you see the following running in the display:
u
Confirm the display within the countdown.
w
DemoMode is off.
If the timer is not running:
u
Unplug the appliance.
u
Plug the appliance in again.
w
DemoMode is off.
7 Features
7.1 Door rack
7.1.1 Move/remove the door rack
Fig. 12
u
Slide the rack upwards.
u
Pull forwards.
u
Re-insert it in reverse order.
Fig. 13
You can use just one or both VarioBoxes. To store oversized
bottles, just suspend one box over the bottle rack.
Move the VarioBox shelf:
Fig. 14
u
Pull it up and out.
u
Put it back in at any position.
Moving the VarioBoxes:
Features
14 * Depending on model and options
Fig. 15
If the door rack is removed:
u
Remove containers.
Fig. 16
u
Place the shelf on the table.
Fig. 17
u
Pull off the middle holder
Fig. 17 (1)
.
u
Insert the middle holder in the second position
Fig. 17 (2)
.
Fig. 18
u
Replace containers.
7.1.2 Disassembling the door rack
The door rack can be taken apart for cleaning.
Fig. 19
Fig. 20
u
Disassemble the door rack.
7.2 Shelves
7.2.1 Adjusting/removing the shelves
The shelves are prevented from being pulled out accidentally
by pull out stops.
Fig. 21
u
Lift the shelf and pull forward.
w
Line up the side runner.
u
Adjust the height of the shelf: Lift or lower it to the desired
height and slide it in.
-or-
Fig. 22
u
Remove the shelf completely: Pull it out to the front.
u
Easier removal: Set the shelf at an angle.
u
Insert the shelf again: Slide it in all the way.
w
The pull-out stoppers point downwards.
w
The pull-out stoppers are behind the front support.
Features
* Depending on model and options 15
7.3 Dividing shelf
7.3.1 Using the dividing shelf
The shelves are prevented from being pulled out accidentally
by pull out stops.
Fig. 23
u
Push the dividing shelf underneath as shown.
Fig. 24
Adjusting the height:
u
Pull the glass panels out
Fig. 24 (1)
from the front, one at a
time.
u
Release the support rails and click in at the height you want.
u
Slide in the glass panels one at a time.
w
Flat pull-out stoppers at the front, right behind the support
rails.
w
High pull-out stoppers at the back.
Using both shelves:
u
Hold the glass panel with one hand and pull it to the front.
w
The glass panel
Fig. 24 (1)
and trim strip are at the front.
w
The stops
Fig. 24 (3)
point down.
7.4 Space for baking tray
There is space for a baking tray
Fig. 1 (6)
above the drawers.
Fig. 25
Ensure that the following conditions are met:
q
Max. baking tray dimensions are adhered to (see 9.1 Tech-
nical specifications) .
q
Baking tray is cooled to room temperature.
q
The lowest door rack is set at least one position higher.
With the door open to 90°:
u
Slide the baking tray onto the lower side runners.
-or-
If baking tray is uneven:
u
Use the supplied support rails.
Fig. 26
u
Snap support rails into the lowest runners.
With the door open to 90°:
u
Slide the baking tray in on the support rails.
7.5 Adjustable bottle shelf
7.5.1 Using the bottle shelf
In the bottom of the fridge section you can either use the vari-
able bottle shelf or the glass panel.
Fig. 27
u
Remove the glass panel and store in a safe place.
u
Lay bottles with their base towards the rear wall.
Note
If the bottles are protruding over the front of the bottle shelf:
u
Move the lower door rack up a place.
7.5.2 Removing the bottle shelf
You can remove the bottle shelf for cleaning.
u
Remove the glass panel above the bottle shelf.
Fig. 28
u
Lift the bottle shelf at the front and pull out.
Note
Liebherr recommends the following:
Do not place any goods on the drawer cover below.
Features
16 * Depending on model and options
7.5.3 Inserting the bottle shelf
Fig. 29
u
Slide in the bottle shelf until it engages and push down.
w
The lugs at the back of the bottle shelf are connected auto-
matically.
w
LED comes on.
7.6 Drawers
Drawers can be removed for cleaning.
The shelves below can be used for storage until the drawers
are replaced.
The way to remove/insert the drawers varies depending on the
pull-out system. Your appliance can include various pull-out
systems.
Note
The energy consumption increases and the cooling power
goes down if ventilation is not sufficient.
u
Leave the bottom drawer in the appliance!
u
Always leave the fan air vents clear on the back wall!
7.6.1 Removing the drawer
Drawer without a pull-out system
Fig. 30
u
Remove the drawer as shown in the illustration.
Drawer on telescopic rails
Fig. 31
Ensure that the following conditions are met:
q
Drawer is completely pulled out (see Fig. 90) .
Fully extendible:*
Fig. 32
*
u
Lift the left clamp and simultaneously pull the drawer on the
left forwards
Fig. 32 (1)
.*
u
Lift the right clamp and simultaneously pull the drawer on the
right forwards
Fig. 32 (2)
.*
u
Take out the drawer to the front
Fig. 32 (3)
.*
u
Slide the rails in.*
Partial pull-out fridge compartment:*
Fig. 33
*
u
Pull out the drawer half-way
Fig. 33 (1)
.*
u
Lift at the front
Fig. 33 (2)
.*
u
Insert left rail
Fig. 33 (3)
.*
u
Insert right rail
Fig. 33 (4)
.*
u
Take out the drawer to the front
Fig. 33 (5)
.*
Fig. 34
*
If the rails are not yet fully inserted after removing the
drawer:*
u
Push the rails in completely.*
Partial pull-out freezer compartment
Note
If the magnet on the top drawer in the freezer compartment is
damaged or removed, the door sensors will malfunction.
u
Do not damage or remove the magnet.
Fig. 35
*
If the drawer is in the top freezer:
u
Lift up the drawer at the front
Fig. 35 (1)
.
u
Take out to the front
Fig. 35 (2)
.
u
Slide the rails in.
Features
* Depending on model and options 17
Fig. 36
*
If the drawer is in the middle part of the freezer compart-
ment:
u
Pull out the drawer half-way.
u
Lift it up at the back from below
Fig. 36 (1)
.
u
Take out to the front
Fig. 36 (2)
.
u
Slide the rails in.
7.6.2 Inserting the drawer
Drawer without a pull-out system
Fig. 37
u
Insert the drawer as shown.
Drawer on telescopic rails
Fully extendible:*
Fig. 38
*
u
Slide the rails in.*
u
Place the drawer on the rails.*
u
Push all the way back.*
w
Fully extendible: Latches in audibly at the back.*
Partial pull-out fridge compartment:*
Fig. 39
*
u
Slide the rails in.*
u
Place the drawer on the rails.*
u
Push all the way back.*
Partial pull-out freezer compartment
Fig. 40
*
u
Slide the rails in.
u
Guide the drawer around the stoppers
Fig. 40 (1)
.
u
Place the drawer on the rails.
u
Push all the way back.
7.7 Fruit & Vegetable safe cover
You can remove the compartment cover for cleaning.
7.7.1 Removing the compartment cover
Ensure that the following conditions are met:
q
Bottle shelf is removed (see 7.5 Adjustable bottle shelf) .
Fig. 41
When the drawers are removed:
u
Pull the lid up at the front to the opening in the retaining
parts
Fig. 41 (1)
.
u
Lift from the back and pull it up and out
Fig. 41 (2)
.
7.7.2 Inserting the compartment cover
Fig. 42
If the text THIS SIDE UP points upwards:
u
Insert the lip of the cover over the opening of the rear
bracket
Fig. 42 (1)
and click into place
Fig. 42 (2)
.
u
Position the cover where you want it (see 7.8 Adjusting the
moisture levels) .
7.8 Adjusting the moisture levels
You can adjust the moisture in the drawer yourself by adjusting
the compartment cover.
The compartment lid is attached to the drawer and can be
hidden by a shelf or additional drawers.
Fig. 43
Features
18 * Depending on model and options
Low air humidity
u
Open the drawer.
u
Slide the compartment cover forwards.
w
With the drawer closed: Gap between the cover and the
compartment.
u
Switch off HydroBreeze.
w
The air moisture in the Safe decreases.
High air moisture
u
Open the drawer.
u
Slide the cover back.
w
With the drawer closed: The cover seals the compartment.
u
Activate the HydroBreeze.
w
The air moisture in the Safe increases.
If there is too much moisture in the compartment:
u
Choose the setting “low air moisture”.
-or-
u
Remove any excess moisture with a cloth.
Note
You can apply the “low air moisture” setting to the Fruit & Vege-
table-Safe and the Meat & Dairy-Safe.
u
Set the “low air moisture” option.
7.9 HydroBreeze
HydroBreeze emits a mist over the refrigerated goods to
provide moisture every time the door is opened.
The HydroBreeze and its water tank are located in the adjust-
able bottle shelf.
Ensure that the following conditions are met:
-
The water tank is clean (see 8.3.3 Clean the components) .
-
The water tank is properly engaged.
-
Moisture is set to “high moisture” (see 7.8 Adjusting the
moisture levels) .
-
HydroBreeze is on (see HydroBreeze) .
7.9.1 Fill the water tank
WARNING
Unclean water!
Contaminants.
u
Only fill with drinking water.
u
The HydroBreeze is off: empty water tank.
u
The HydroBreeze is no longer in use: empty water tank.
NOTICE
Sugar-content liquids!
Damage to HydroBreeze.
u
Only fill with drinking water.
Note
Only use filtered, decarbonised water for the best quality
drinking water and to make the HydroBreeze, work smoothly.
This water quality can be achieved using a table water filter of
the kind available in trade retail outlets.
u
Only ever fill the water tank with filtered, decarbonised
drinking water.
The water tank is built into the adjustable bottle shelf
(see 1.2 Overview of the appliance and features) .
Fig. 44
u
Press on the back-left corner of the front glass plate.
w
The glass panel folds up at the front.
u
Lift the glass panel and fold towards the rear until it clicks
into place
Fig. 44 (1)
.
w
Glass panel stands upright.
u
Slide the slider
Fig. 44 (2)
to the left.
w
The water tank jumps out of its recess.
u
Remove the water tank
Fig. 44 (3)
.
u
Cleaning the water tank (see 8.3.3 Clean the components) .
Square opening:
u
Fill with drinking water up to the marker.
u
Insert the water tank into the recess, bottom first.
u
Slowly lower the front part and push the tank in.
w
The water tank is clicked into place.
7.9.2 Dismantling the water tank
You can take the water tank apart for cleaning.
Fig. 45
u
Dismantling the water tank.
7.10 IceMaker
The IceMaker will produce ice cubes for household use only.
Ensure that the following conditions are met:
-
IceMaker is cleaned (see 8 Maintenance) .
-
IceMaker drawer is fully inserted.
7.10.1 Producing ice cubes
The volume depends on the freezing temperature. The colder
the temperature, the more ice cubes the system can produce in
a certain time period.
After the IceMaker is turned on for the first time, it can take up
to 24 hours for the first ice cubes to be made.
u
Activate the IceMaker function (see 6.2 Control concept) .
u
To make a high number of ice cubes: Activate the MaxIce
function (see 6.2 Control concept) .
u
To make a high number of ice cubes: Move the divider in the
IceMaker drawer or remove it completely.
u
Distribute the ice cubes evenly in the drawer to increase the
capacity.
u
Closing the drawer: IceMaker starts making ice cubes again
automatically.
Features
* Depending on model and options 19
Note
When a certain level is reached in the IceMaker drawer, it stops
producing ice cubes. The IceMaker does not fill the drawer all
the way to the top.
7.11 VarioSpace
Fig. 46
You can remove drawers and glass panels from your appliance.
This provides more room for large food items such as poultry,
joints of meat, large game, and tall baked products. You can
then freeze these items whole for later preparation.
u
Note the weight limits on the drawers and glass panels
(see 9.1 Technical specifications) .
7.12 Accessories
7.12.1 Butter dish
Opening/closing the butter dish
Fig. 47
Dismantling the butter dish
You can take the butter dish apart for cleaning.
Fig. 48
u
Disassembling the butter dish.
7.12.2 Egg rack
You can pull out and turn the egg rack. You can use both sides
of the egg rack so you can label specifics like the purchase
date.
Using the egg rack
Fig. 49
u
Top layer: for storing hen eggs.
u
Bottom layer: for storing quail eggs.
7.12.3 Bottle holder
Using the bottle holder
Fig. 50
u
Push the bottle holder onto the bottles.
w
The bottles are prevented from falling over.
Removing the bottle holder
Fig. 51
u
Move the bottle holder all the way to the right.
u
Push the bottle holder to the back to remove.
Features
20 * Depending on model and options
7.12.4 FlexSystem
Using the FlexSystem
The FlexSystem helps you store and organise your food in a
clear and flexible way. It lets you clearly divide your food into
fruit, vegetables or by use-by dates, for example.
Fig. 52
u
Move the inner shell.
Removing the FlexSystem
Fig. 53
u
Lift the FlexSystem from the back.
u
Pull up and out.
Inserting the FlexSystem
Fig. 54
u
Insert the FlexSystem front-first.
u
Lower the rear part.
Disassembling the FlexSystem
You can take the FlexSystem apart for cleaning.
Fig. 55
u
Disassembling the FlexSystem
7.12.5 Freezer pack
Freezer packs prevent the temperature rising too quickly should
there be a power cut.
The freezer packs are in the drawer.
Using the freezer pack
Fig. 56
When the freezer packs are fully frozen:
u
Place on the frozen goods in the top, front part of the freezer.
8 Maintenance
8.1 FreshAir carbon filter
The FreshAir carbon filter is in the compartment above the fan.
It guarantees the best air quality.
q
Replace the carbon filter every 6 months.
With the
Reminder
setting on, a message on the display
prompts you to replace it.
q
The carbon filter can be disposed of with the regular house-
hold waste.
Note
You can purchase the FreshAir carbon filter from the Liebherr
household appliance store (home.liebherr.com).
8.1.1 Removing the FreshAir carbon filter
Fig. 57
u
Pull out the compartment
Fig. 57 (1)
.
Maintenance
* Depending on model and options 21
u
Remove the carbon filter
Fig. 57 (2)
.
8.1.2 Inserting the FreshAir carbon filter
Fig. 58
u
Insert the carbon filter as shown in the diagram
Fig. 58 (1)
.
w
The carbon filter clicks into place.
If the carbon filter is pointing downwards:
u
Push the compartment in
Fig. 58 (2)
.
w
The carbon filter is now ready for use.
8.2 Defrosting the appliance
8.2.1 Defrosting the fridge section
Defrosting is automatic. The thawing water drains through the
outlet and evaporates.
u
Clean the outflow opening regularly (see 8.3 Cleaning the
appliance) .
8.2.2 Defrost freezer section using the NoFrost
option
Defrosting happens automatically via the NoFrost system.
The moisture is deposited on the evaporator, is periodically
defrosted and evaporates.
The appliance does not need to be defrosted.
8.3 Cleaning the appliance
8.3.1 Ready
WARNING
Danger of electric shock!
u
Remove the refrigerator connector or interrupt the power
supply.
WARNING
Risk of fire
u
Do not damage the refrigeration circuit.
u
Empty the appliance.
8.3.2 Cleaning the interior
NOTICE
Improper cleaning!
Damage to the appliance.
u
Only use soft cleaning cloths and ph-neutral all-purpose
cleaners.
u
Plastic surfaces: clean by hand with a soft clean cloth, luke-
warm water and a little detergent.
u
Metal surfaces: clean by hand with a soft clean cloth, luke-
warm water and a little detergent.
u
Drain outlet
Fig. 1 (11)
: remove any deposits with a thin item
such as a cotton bud.
8.3.3 Clean the components
NOTICE
Improper cleaning!
Damage to the appliance.
u
Only use soft cleaning cloths and ph-neutral all-purpose
cleaners.
Clean with a soft, clean cloth, lukewarm water and some
detergent:
- Fruit & Vegetable safe cover
- Drawer
Please note: Do not remove the magnet on the drawer. The
magnet ensures the functionality of the IceMaker.
- Divider in the IceMaker drawer
- Adjustable bottle shelf
- FlexSystem
- Freezer tray
Clean with a damp cloth:
- Retractable rails
Please note: The grease in the tracks is used for lubrication
and must not be removed!
Wash in the dishwasher up to 60 °C:
- Door rack
- VarioBox
- Bottle rack
- Shelf
- Dividing shelf
- Holder of the dividing shelf
- HydroBreeze water tank and water tank lid
- Egg rack
- Butter dish
u
To disassemble components: see the relevant section.
u
Clean the components.
8.3.4 Cleaning the HydroBreeze
Cleaning is required in the following cases:
q
Initial operation
q
HydroBreeze is off for more than 48 hours.
q
Refill the water tank.
Ensure that the following conditions are met:
q
HydroBreeze is off (see HydroBreeze) .
q
Water tank has been removed and cleaned in the dish-
washer.
u
Wipe out the recess with a damp cloth.
u
Insert the water tank.
u
Activate the HydroBreeze.
8.3.5 Cleaning the IceMaker
There are various options for cleaning the IceMaker.
Cleaning is required in the following cases:
q
Initial operation
q
If out of use for more than 5 days.
Ensure that the following conditions are met:
q
IceMaker drawer is emptied.
q
IceMaker drawer is in place.
q
IceMaker is on (see 6.2 Control concept) .
First use or after a long period of non-use
Clean the IceMaker with the TubeClean function.
u
Place a 1.5 l empty container (max. height 10 cm) into the
drawer under the IceMaker.
u
Activate the TubeClean function (see 6.2 Control concept) .
Maintenance
22 * Depending on model and options
u
Remove the IceMaker drawer and remove the container.
u
Clean the IceMaker drawer with warm water and a little
detergent.
u
Push the IceMaker drawer in.
w
The system starts making ice cubes automatically.
u
Dispose of any ice cubes that were made 24 hours after the
first ice cubes.
If cleaning is required
Clean the IceMaker by hand.
u
Remove the IceMaker drawer and clean with warm water
and a little detergent.
u
Push the IceMaker drawer in.
w
The system starts making ice cubes automatically.
8.3.6 After cleaning
u
Wipe the appliance and the components dry.
u
Connect and switch on the appliance.
u
Activate SuperFrost (see 6.3 Functions) .
The temperature is cold enough:
u
Place the food inside.
u
Repeat cleaning regularly.
9 Customer help
9.1 Technical specifications
Temperature range
Cooling 3 °C to 9 °C
BioFresh 0 °C to 3 °C
Freeze -26 °C to -15 °C
Maximum freezer quantity / 24 hrs
Freezer compart-
ment
See the type plate under “Freezer
goods … /24 hours”
Maximum component capacity
Features Appliance
width 55 cm
(see Instal-
lation
Guide,
Appliance
Dimen-
sions)
Appliance
width 60 cm
(see Instal-
lation
Instruc-
tions, Appli-
ance
Dimen-
sions)
Appliance
width 70 cm
(see Instal-
lation
Guide,
Appliance
Dimen-
sions)
Drawer
Freezer compart-
ment
12 kg 12 kg
Glass shelf in the
freezer section
35 kg 35 kg 55 kg
Maximum size baking tray
Width 466 mm
Depth 386 mm
Height 50 mm
Ice cube production
Ice cube produc-
tion / 24 h
At a temperature of -18 °C: 1.2 kg of ice
cubes
Ice cube production
Maximum ice
cube production /
24 hours
With the MaxIce function on: 1.5 kg of
ice cubes
Lighting
Class
1
Light source
This product contains a light source that meets
energy efficiency rating F*
LED*
This product contains a light source that meets
energy efficiency rating G*
LED*
1 The appliance may contain light sources with different energy
efficiency classes. The lowest class is given here.
9.2 Operating noises
The appliance makes different noises when it is on.
-
At higher temperatures the appliance uses less energy but
works for longer. It is quieter.
-
At lower temperatures the food is cooled faster. It is
louder.
Examples:
•
Functions on (see 6.3 Functions)
•
Fan running
•
Food recently added
•
High ambient temperature
•
Door open for a while
Noise Possible cause Type of noise
Bubbling and
splashing
Coolant flowing into
the cooling circuit.
Normal operating
noise
Hissing Coolant sprays into
the cooling circuit.
Normal operating
noise
Humming The appliance
is cooling. The
volume depends on
the cooling output.
Normal operating
noise
Suction noises Soft-closing door is
being opened and
closed.
Normal operating
noise
Humming and
rustling
The fan is running. Normal operating
noise
Clicking Components
turning on and off
Normal switching
noise
Rattling or
humming
Valves or flaps are
working.
Normal switching
noise
Noise Possible
cause
Type of noise Lifting
Vibration Improper
installation.
Defective
noise
Check the
installation.
Level the
appliance.
Rattling Components,
items inside
the appliance
Defective
noise
Secure
components.
Leave enough
space
between the
items.
Customer help
* Depending on model and options 23
9.3 Technical fault
Your appliance is designed and built to ensure it works reliably
and has a long service life. In the unlikely event that a fault
occurs during operation, please check whether it is due to an
operating error. If so, you will be charged for the callout and
repair costs even if it falls within the warranty period.
You can fix the following faults yourself.
9.3.1 Appliance function
Defect Cause Remedy
The appliance is
not working.
→ The appliance is not switched on.
u
Switch the appliance on.
→ The power plug is not properly
plugged into the socket.
u
Check the power plug.
→ There is something wrong with the
power outlet fuse.
u
Check the fuse.
→ Power cut
u
Keep the appliance closed.
u
Protecting food: Lay freezer packs on top of the food or use
another freezer if the power is off for a prolonged period.
u
Do not re-freeze defrosted food,
→ The appliance plug does not fit the
appliance properly.
u
Check the appliance plug.
Temperature is not
cold enough.
→ The appliance door is not closed
properly.
u
Close the appliance door.
→ Not enough ventilation.
u
Keep ventilation grille clear, and clean it.
→ The ambient temperature is too high.
u
Solution: (see 1.3 Appliance range of use) .
→ The appliance was opened too many
times or for too long.
u
Wait to see if the required temperature corrects itself. If not,
contact Customer Service (see 9.4 Customer Services) .
→ Too much fresh food was placed
inside without SuperFrost.
u
Solution: (see SuperFrost)
→ The temperature is set incorrectly.
u
Turn down the temperature and check after 24 hours.
→ The appliance is too close to a heat
source (oven, radiator, etc).
u
Move the appliance or the heat source.
→ The appliance was not correctly
installed in the recess.
u
Check if the appliance was installed correctly and that the
door closes properly.
The door seal is
defective or needs
to be replaced for
another reason.
→ The door seal can be replaced. It
can be replaced without the need for
special tools.
u
Contact Customer Services (see 9.4 Customer Services) .
The appliance
builds up too
much ice or
condensation.
→ The door seal may have slipped out
of its groove.
u
Check that the door seal is well fitted in the groove.
9.3.2 Features
Defect Cause Remedy
You cannot acti-
vate the IceMaker.
→ The appliance and therefore the
IceMaker are not connected.
u
Connect the appliance (see the Installation Guide).
The IceMaker is
not producing ice
cubes.
→ The IceMaker is not on.
u
Activate the IceMaker.
→ The drawer of the IceMakers is not
connected properly.
u
Push the drawer in correctly.
→ The water connection is not open.
u
Open the water connection.
HydroBreeze is
not keeping refri-
→ The HydroBreeze is not on.
u
Activate the HydroBreeze.
Customer help
24 * Depending on model and options
Defect Cause Remedy
gerated goods
moist.
→ There is not enough water in the
water tank.
u
Fill the water tank.
→ There is dirt in front of the concen-
trator.
u
Clean the HydroBreeze.
→ The water tank is not clicked into
place properly.
u
Click the water tank into place.
→ The cover of the Fruit & Vegetable-
Safe is in “low air moisture” mode.
u
Set the Fruit & Vegetable-Safe to the “high air moisture”
mode.
The internal light
does not come on.
→ The appliance is not switched on.
u
Switch the appliance on.
→ The door was open for longer than
15 minutes.
u
Interior lighting turns off automatically after approx. 15 min.
with the door open.
→ The LED light is faulty or the cover is
damaged:
WARNING
Risk of injury due to electric shock!
There are live electrical parts under the cover.
u
Only ever have the inside LED light replaced or repaired by
customer service or trained personnel.
9.4 Customer Services
First check if you can fix the error yourself (see 9 Customer
help) . If you can't, contact Customer Services.
Please refer to the enclosed “Liebherr-Service” brochure for the
address.
WARNING
Unprofessional repair!
Injuries.
u
Have any repairs and action - not expressly specified -
on the appliance and mains cable carried out by service
personnel only. (see 8 Maintenance)
u
A damaged mains cable may only be replaced by the manu-
facturer, the manufacturer’s Customer Service or a similarly
qualified person.
u
In the case of appliances with an IEC connector, the change
may be made by the customer.
9.4.1 Contact Customer Services
Make sure you have the following appliance data at the ready:
q
Appliance name (model and index)
q
Service no. (Service)
q
Serial no. (S no.)
u
Look up the appliance information on the display (see Info) .
-or-
u
Referring to appliance info on the nameplate (see 9.5 Model
plate) .
u
Note down the appliance information.
u
Notify Customer Services of the following: Give us the appli-
ance data.
w
This will help us to provide you with a faster, more accurate
service.
u
Follow any further instructions given by Customer Services.
9.5 Model plate
The model plate is behind the drawers on the inside of the
appliance.
Fig. 59
(1) Appliance description (3) Serial no.
(2) Service no.
u
Note the data on the model plate.
10 Shutting down
u
Empty the appliance.
u
Turn off the IceMaker .
u
Turn off the appliance (see 6.4 Settings) .
u
Remove mains connector.
u
Remove appliance connector if required: Remove and move
from left to right at the same time.
u
Clean the appliance (see 8.3 Cleaning the appliance) .
u
Leave the door open to avoid bad smells building up.
11 Disposing of the appliance
The appliance contains some reusable materials
and should be disposed of properly - not simply
with unsorted household refuse. Appliances which
are no longer needed must be disposed of in a
professional and appropriate way, in accordance
with the current local regulations and laws.
Do not damage the refrigeration circuit of the old appliance
during removal to prevent the refrigerant contained (information
on the type plate (see 9.5 Model plate) ) and the oil from
escaping in an uncontrolled manner.
Decommission the appliance:
u
Pull out the plug.
u
Remove the connection cable from the appliance.
Shutting down
* Depending on model and options 25
home.liebherr.com/fridge-manuals
integrated fridge/freezer with BioFresh
Issue date: 20211118
Part number index: 7088282-00
Liebherr-Hausgeräte Ochsenhausen GmbH
Memminger Straße 77-79
88416 Ochsenhausen
Deutschland
