Operating and installation
instructions
Fridge-freezer
To avoid the risk of accidents or damage to the appliance it is essen-
tial to read these instructions before it is installed and used for the
first time.
en - GB, IE, ZA M.-Nr. 10 360 950
Contents
2
Warning and Safety instructions...................................................................... 5
Caring for the environment .............................................................................. 14
Saving energy .................................................................................................... 15
Guide to the appliance...................................................................................... 17
Writing on the appliance doors (Blackboard edition) .......................................... 18
Accessories ....................................................................................................... 21
Accessories supplied .......................................................................................... 21
Optional accessories........................................................................................... 22
Before using for the first time .......................................................................... 23
Before using for the first time.............................................................................. 23
Cleaning the appliance................................................................................... 23
Connecting the appliance ................................................................................... 23
Switching on and off ......................................................................................... 24
Touch display ...................................................................................................... 24
Switching on........................................................................................................ 24
Start screen ......................................................................................................... 24
Switching off the refrigeration appliance............................................................. 25
Switching off for longer periods of time .............................................................. 27
The correct temperature................................................................................... 28
...in the refrigerator section ................................................................................ 28
...in the freezer section ....................................................................................... 28
Temperature display ............................................................................................ 29
Setting the temperature....................................................................................... 29
Temperature range ......................................................................................... 30
Using Super cool, Super freeze and DynaCool .............................................. 31
Super freeze function ..................................................................................... 31
Super cool function......................................................................................... 31
DynaCool function.......................................................................................... 32
Switching a function on or off ............................................................................. 32
Displaying a selected function ....................................................................... 33
Temperature and door alarm............................................................................ 34
Temperature alarm............................................................................................... 34
Door alarm........................................................................................................... 35
Selecting further settings ................................................................................. 37
Settings overview ................................................................................................ 37
Contents
3
Explanation of the different Settings ................................................................... 40
Switching Party mode on or off .................................................................. 40
Switching Holiday mode on / off .............................................................. 41
Using the minute minder (QuickCool timer) .............................................. 42
Activating or deactivating the safety lock ............................................ 43
Switching the refrigeration appliance off ................................................... 43
Switching Sabbath mode on/off ................................................................. 44
Setting the time before the door alarm is triggered ................................... 45
Switching the sensor tone on / off....................................................... 45
Setting the volume/Switching alarms and audible tones on/off ............... 45
Setting the display brightness ................................................................... 46
Setting the temperature unit°C/°F ................................................................. 46
Switching Demo mode off........................................................................... 46
Resetting to the factory default settings .................................................. 46
Accessing information................................................................................. 46
Replace charcoal filter reminder................................................................ 47
Clean ventilation grille reminder ................................................................ 47
Storing food in the refrigerator section........................................................... 48
Different storage zones ....................................................................................... 48
Food which is not suitable for storage in the refrigerator section ....................... 49
Notes on buying food.......................................................................................... 49
Storing food correctly.......................................................................................... 50
Protein-rich food............................................................................................. 50
Storing food in the DailyFresh drawer............................................................. 51
Adjusting the interior fittings (refrigerator section) ....................................... 53
Adjusting the door/bottle shelf ............................................................................ 53
Moving the shelves.............................................................................................. 53
Adjusting the bottle rack ..................................................................................... 53
Removing the DailyFresh drawer and rollers....................................................... 54
Moving the storage drawer (CompactCase)........................................................ 54
Adjusting or removing the bottle holder.............................................................. 55
Moving the charcoal filters .................................................................................. 55
Freezing and storing food................................................................................. 56
Maximum freezing capacity ................................................................................ 56
Freezing fresh food.............................................................................................. 56
Storing frozen food.............................................................................................. 56
Home freezing ..................................................................................................... 57
Storage time for frozen food........................................................................... 58
Defrosting frozen goods ................................................................................. 58
Adjusting the interior fittings................................................................................ 59
Contents
4
Using accessories ............................................................................................... 60
Defrosting........................................................................................................... 61
Cleaning and care ............................................................................................. 62
Cleaning agents................................................................................................... 62
Preparing the refrigeration appliance for cleaning .............................................. 63
Cleaning the interior and accessories ................................................................. 64
Cleaning the front of the appliance and the side panels..................................... 65
Cleaning the ventilation grille .............................................................................. 66
Cleaning the door seal ........................................................................................ 66
After cleaning ...................................................................................................... 67
Replacing the charcoal filters .............................................................................. 67
Problem solving guide ...................................................................................... 69
Noises................................................................................................................. 79
Service................................................................................................................ 80
Contact in the event of a fault ............................................................................. 80
–Displaying licence agreements.................................................................... 80
EPREL database ................................................................................................. 80
Warranty .............................................................................................................. 80
Installation.......................................................................................................... 81
Installation ........................................................................................................... 81
Side-by-side installation................................................................................. 81
Location.......................................................................................................... 82
Ventilation....................................................................................................... 83
Fitting supplied wall spacers.......................................................................... 83
Installing the refrigeration appliance .............................................................. 84
Levelling the appliance door .......................................................................... 85
Installing the refrigeration appliance in a run of kitchen units ........................ 85
Appliance dimensions .................................................................................... 87
Changing the door hinging.................................................................................. 88
Aligning the appliance doors............................................................................... 98
Electrical connection ........................................................................................... 99
Warning and Safety instructions
5
This refrigeration appliance complies with current safety require-
ments. Inappropriate use can, however, lead to personal injury and
material damage.
Please read the operating and installation instructions carefully be-
fore using the refrigeration appliance for the first time. They con-
tain important information on safety, installation, use and mainten-
ance. This is to protect yourself from injury, and from damaging
your refrigeration appliance.
In accordance with standard IEC60335-1, Miele expressly and
strongly advises that you read and follow all information provided
on installing the refrigeration appliance, as well as the safety notes
and warnings.
Miele cannot be held liable for injury or damage caused by non-
compliance with these instructions.
Keep these operating and installation instructions in a safe place
and pass them on to any future owner.
Correct application
This refrigeration appliance is intended for use in the home and in
similar environments, for example
– in shops, offices and similar work settings
– by the guests in hotels, motels, bed & breakfasts and other typical
home settings.
This refrigeration appliance is not intended for outdoor use.
This appliance is intended for domestic use only for cooling and
storing food and drink as well as for storing deep frozen food, freez-
ing fresh food and for making ice.
Any other usage is not supported by the manufacturer and could be
dangerous.
Warning and Safety instructions
6
This refrigeration appliance is not suitable for storing and keeping
cool medicines, blood plasma, laboratory preparations or similar
substances or products that are subject to the Medical Device Dir-
ective. Incorrect use of the refrigeration appliance for such purposes
may cause deterioration of the items stored. The refrigeration appli-
ance is also not suitable for use in areas where there is a risk of ex-
plosion.
Miele cannot be held liable for damage caused by improper or incor-
rect use or operation of the appliance.
The appliance can only be used by people with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge,
if they are supervised whilst using it, or have been shown how to use
it in a safe way and recognise and understand the consequences of
incorrect operation.
Safety with children
Children under 8 years of age must be kept away from the refri-
geration appliance unless they are constantly supervised.
Children 8 years and older may only use the appliance unsuper-
vised if they have been shown how to use it in a safe way and recog-
nise and understand the consequences of incorrect operation.
Children must not be allowed to clean or maintain the appliance
unsupervised.
Please supervise children in the vicinity of the appliance and do
not let them play with it.
Danger of suffocation! Whilst playing, children could become en-
tangled in packaging (such as plastic wrapping) or pull it over their
head and suffocate. Keep packaging material away from children.
Warning and Safety instructions
7
Technical safety
The coolant circuit has been checked for leaks. The refrigeration
appliance complies with statutory safety requirements and the ap-
propriate EU directives.
This refrigeration appliance contains the refrigerant isobutane
(R600a), a natural gas which is environmentally friendly but flam-
mable. The refrigerant does not damage the ozone layer and does
not contribute to the greenhouse effect.
The use of this refrigerant has, however, led to a slight increase in
the noise level of the appliance. In addition to the noise of the com-
pressor, you might be able to hear the refrigerant flowing around the
cooling circuit. Unfortunately, this cannot be avoided, but it does not
affect the performance of the refrigeration appliance.
When transporting and installing the refrigeration appliance, ensure
that no parts of the cooling circuit are damaged. Splashes of refri-
gerant can damage the eyes.
In the event of damage:
- Avoid naked flames or anything which creates a spark.
- Disconnect the refrigeration appliance from the mains electricity
supply.
- Ventilate the room where the refrigeration appliance is located for
several minutes.
- Contact the Miele Customer Service Department.
The more coolant there is in a refrigeration appliance, the larger
the room it should be installed in. In the event of a leakage, if the ap-
pliance is in a small room, there is the danger of a combustible gas/
air mixture building up. For every 11g of coolant at least 1m
3
of
room space is required. The amount of coolant in the refrigeration
appliance is stated on the data plate inside the appliance.
Warning and Safety instructions
8
To avoid the risk of damage to the appliance, make sure that the
connection data (fuse rating, frequency and voltage) on the data
plate corresponds to the household supply.
Check that this is the case before connecting the appliance. Consult
a qualified electrician if in any doubt.
The electrical safety of this appliance can only be guaranteed
when correctly earthed. It is essential that this standard safety re-
quirement is met. If in any doubt please have the electrical installa-
tion tested by a qualified electrician.
Reliable and safe operation of this appliance can only be assured
if it has been connected to the mains electricity supply.
If the electrical connection cable is faulty it must only be replaced
by a Miele authorised service technician to protect the user from
danger.
Do not connect the appliance to the mains electrical supply by a
multi-socket adapter or extension lead. These are a fire hazard and
do not guarantee the required safety of the appliance.
If moisture gets into electrical components or into the mains con-
nection cable, it could cause a short circuit. Therefore, do not oper-
ate this refrigeration appliance in areas which are exposed to mois-
ture (e.g in a garage or utility room).
This appliance must not be used in a non-stationary location (e.g.
on a ship).
Do not use a damaged appliance. It could be dangerous. Check
the appliance for visible signs of damage.
This refrigeration appliance is not intended for use as a built-in ap-
pliance.
The appliance must be isolated from the electricity supply during
installation, maintenance and repair work.
Warning and Safety instructions
9
Unauthorised installation, maintenance and repairs can cause
considerable danger for the user.
Installation, maintenance and repairs must only be carried out by a
Miele authorised technician.
While the appliance is under warranty, repairs should only be un-
dertaken by a Miele authorised service technician. Otherwise the
warranty is invalidated.
Faulty components must only be replaced with genuine Miele ori-
ginal spare parts. Miele can only guarantee the safety standards of
the appliance when Miele replacement parts are used.
This refrigeration appliance is supplied with a special lamp to
cope with particular conditions (e.g. temperature, moisture, chemical
resistance, abrasion resistance and vibration). This lamp must only
be used for the purpose for which it is intended. The lamp is not suit-
able for room lighting. Replacement lamps may only be fitted by a
Miele authorised technician or by the Miele Customer Service De-
partment. This refrigeration appliance contains several light sources
with at least energy efficiency classG.
Correct use
This refrigeration appliance is designed for use within specific am-
bient temperatures (climate range). Do not use in ambient temperat-
ures for which it is not designed. The climate range is stated on the
data plate in the interior cabinet of the refrigeration appliance. A
lower ambient temperature will cause the compressor to switch off
for longer periods, meaning that the refrigeration appliance is unable
to maintain the required temperature.
Do not cover or block the air vents as this could impair the effi-
ciency of the appliance, increase the electricity consumption and
could cause damage to the components.
If storing food which contains a lot of fat or oil in the appliance or
the door, make sure that it does not come into contact with plastic
components as this could cause stress cracks or break the plastic.
Warning and Safety instructions
10
Risk of fire and explosion. Do not store explosive materials in the
refrigeration appliance or any products containing propellants (e.g.
spray cans). Electrical components can cause flammable mixes of
gases to ignite.
Danger of explosion. Do not operate any electrical equipment (e.g.
an electric ice-cream maker) inside the refrigeration appliance.
Danger of sparking and explosion.
Danger of injury and damage to the appliance. Do not store cans
or bottles containing carbonated drinks or liquids which could freeze
in the freezer zone. Otherwise they could burst.
Danger of injury and damage to the appliance. When cooling
drinks quickly in the freezer zone, make sure bottles are not left in for
more than one hour. Otherwise they could burst.
Danger of injury. Never handle frozen food or the metal parts of
the appliance with wet hands. Your hands may freeze to the frozen
food or to the metal.
Danger of injury. Do not take ice cubes out with your bare hands
and never place ice cubes or ice lollies in your mouth straight from
the freezer zone. The very low temperature of the frozen food can
cause frost burn to the lips and tongue.
Do not refreeze partially or fully defrosted food. Consume defros-
ted food as soon as possible, as it will lose its nutritional value and
spoil if left for too long. Defrosted food may only be re-frozen after it
has been cooked.
Observe the manufacturer's “use-by” dates and storage instruc-
tions given on food to avoid the risk of food poisoning. Storage times
will depend on several factors, including the freshness and quality of
the food, as well as the temperature at which it is stored.
Warning and Safety instructions
11
Accessories and spare parts
Only use genuine original Miele accessories and spare parts with
this appliance. Using accessories or spare parts from other manu-
facturers will invalidate the warranty, and Miele cannot accept liabil-
ity.
Miele will guarantee to supply functional spare parts for a min-
imum of 10years and up to 15years following the discontinuation of
your refrigeration appliance.
Warning and Safety instructions
12
Cleaning and care
Scratches on the door glass can result in the glass breaking. Do
not use abrasive cleaners, hard sponges, brushes or sharp metal
tools to clean the door glass.
Do not use any oils or grease on the door seals, as these will
cause the seals to deteriorate and become porous with time.
Do not use a steam cleaning appliance to clean or defrost this ap-
pliance.
Steam could reach electrical components and cause a short circuit.
Sharp edged or pointed objects will damage the evaporator, caus-
ing irreversible damage to the appliance. Do not use sharp edged or
pointed objects to
- remove frost and ice,
- separate frozen food or remove ice trays.
Do not place electric heaters or candles in the appliance to de-
frost it. These can damage the plastic parts.
Do not use defrosting sprays or de-icers, as they could contain
substances which could damage the plastic parts or which might
cause the build-up of gases and pose a danger to health.
Transport
Always transport the appliance in an upright position and in its ori-
ginal transport packaging to avoid damage in transit.
Danger of injury and damage to the appliance. The refrigeration
appliance is very heavy and must be transported by two people.
Warning and Safety instructions
13
Disposal of your old appliance
If your old refrigeration appliance has a door lock, destroy it. This
will prevent the risk of children playing accidentally locking them-
selves in and endangering their lives.
Splashes of coolant can damage the eyes. Be careful not to dam-
age any part of the pipework whilst awaiting disposal, e.g. by
- puncturing the coolant channels in the condenser,
- bending any pipework, or
- scratching the surface coating.
Caring for the environment
14
Disposal of the packing mater-
ial
The packaging is designed to protect
the appliance from damage during
transportation. The packaging materials
used are selected from materials which
are environmentally friendly for disposal
and should be recycled.
Recycling the packaging reduces the
use of raw materials in the manufactur-
ing process and also reduces the
amount of waste in landfill sites.
Disposing of your old appli-
ance
Electronic and electrical appliances
contain many valuable materials. They
also contain certain materials, com-
pounds and components which were
essential for their correct functioning
and safety. These could be hazardous
to your health and to the environment if
disposed of with general waste or if
handled incorrectly. Please do not,
therefore, dispose of your old appliance
with general waste.
Instead, please make use of officially
designated collection and disposal
points to dispose of and recycle elec-
trical and electronic appliances in your
local community, with your dealer or
with Miele. By law, you are solely re-
sponsible for deleting any personal data
from the appliance prior to disposal.
Take care not to damage your refrigera-
tion appliance’s pipework before or dur-
ing transportation to an authorised col-
lection depot.
This is to ensure that coolant in the
cooling circuit and oil in the compressor
is contained, and will not leak into the
environment.
Please ensure that your old appliance
poses no risk to children while being
stored prior to disposal. For further in-
formation, see “Warning and Safety in-
structions” in these operating and in-
stallation instructions.
Saving energy
15
Normal energy consump-
tion
Increased energy con-
sumption
Installation /
Maintenance
In a ventilated room. In an enclosed, unventilated
room.
Protected from direct sun-
light.
In direct sunlight.
Not near to a heat source
(radiator, oven).
Near to a heat source (radi-
ator, oven).
Where the ideal ambient
room temperature is approx.
20°C.
Where the ambient room
temperature is above 25°C.
Ventilation gaps uncovered
and dusted regularly.
Ventilation gaps covered or
dusty.
Temperature
setting
Refrigerator section 4 to
5°C
The lower the temperature,
the higher the energy con-
sumption.
Freezer section -18°C
Saving energy
16
Normal energy consump-
tion
Increased energy con-
sumption
Use Drawers and shelves ar-
ranged as they were when
the appliance was delivered.
Only open the door when
necessary and for as short a
time as possible. Store food
in an organised way.
Frequent opening of doors
for long periods will cause a
loss of coldness. The appli-
ance will try to cool down
and the compressor will run
for longer periods.
Take an insulated cool bag
when shopping, and load
food in the appliance as
soon as possible.
Replace any food removed
as quickly as possible, be-
fore it warms up too much.
Allow hot food and drinks to
cool down before placing
them in the appliance.
Hot food or food at room
temperature raises the tem-
perature inside the appli-
ance. The appliance will try
to cool down and the com-
pressor will run for longer
periods.
Store food well packaged or
covered.
The evaporation or condens-
ation of liquids in the refri-
gerator section will cause a
loss of coldness.
Place frozen food in the refri-
gerator to defrost.
Do not over-fill the appliance
to allow air to circulate.
Poor air circulation will
cause a loss of coldness.
Guide to the appliance
17
This drawing is for illustration purposes only.
a
Control panel with display
b
Interior lighting
c
Fan
d
Door shelf / Egg tray
e
Adjustable shelf
f
Storage drawer (CompactCase)
g
Bottle rack
h
Bottle shelf with bottle holder
i
Regulator for setting the humidity
level in the DailyFresh drawer
j
Condensate channel and drain hole
k
DailyFresh drawer (on rollers)
l
Recessed handle with door opening
aid (Click2open)
m
Freezer drawers
n
Ventilation grille
For easier installation there are trans-
port handles on the back at the top and
transport wheels underneath the appli-
ance.
Guide to the appliance
18
Writing on the appliance doors
(Blackboard edition)
The appliance doors are made from
safety glass with a satin finish which is
printed on the back. This surface allows
you to write on the appliance doors, for
example, to leave a note for other mem-
bers of the family.
Before writing on the glass front for the
first time, it is advisable to clean the en-
tire surface with a microfibre cloth suit-
able for glass and lukewarm water.
Then dry the surface with a soft cloth.
Risk of damage due to writing
with the wrong products.
Never write on the glass front with a
ballpoint pen, crayon or pencil, cor-
rection pencil, wax crayon, oil chalk,
felt-tip pen (e.g. permanent marker,
highlighter, foil pen, etc.). They are
difficult or impossible to remove from
the glass front.
Only use the products recommended
to write on the glass front as these
can be removed easily.
We recommend the following products
for writing on the doors:
- Liquid chalk pens,
such as an edding4095 chalk marker
(supplied as an accessory)
- Traditional blackboard chalk
Risk of damage as a result of in-
correct cleaning.
The glass front can alter and discol-
our if you spot-clean it, remove soil-
ing when it is dry or use the wrong
cleaning agent.
In order to keep the glass surface in
optimum condition, please observe
the instructions given in “Cleaning
and care – Cleaning agents – Clean-
ing the front of the appliance and the
side panels”.
Guide to the appliance
19
Symbols on the display
Controls
Symbol Meaning
Standby For switching on the whole refrigeration ap-
pliance,
for switching on the refrigerator section sep-
arately
Settings mode For selecting settings (see “Selecting further
settings”)
/ Minus/plus For altering a setting (e.g. temperature)
OK For confirming a setting
/ Left/right navigation ar-
row
For scrolling in Settings mode to select a
setting
Back For exiting a menu
Guide to the appliance
20
Information
Symbol Meaning
Standby The appliance is connected to the electrical
supply but is not switched on.
The refrigerator section is switched off sep-
arately.
Freezer section Identifies the freezer section temperature
display.
Super cool (refrigerator
section) / Super freeze
(freezer section)
Function can be selected depending on sec-
tion (see “Using Super cool, Super freeze
and DynaCool”).
DynaCool (refrigerator
section)
Function can be selected depending on sec-
tion (see “Using Super cool, Super freeze
and DynaCool”).
Temperature alarm Warning (see “Problem solving guide - Dis-
play warnings”).
Door alarm Warning (see “Problem solving guide - Dis-
play warnings”).
Power failure Warning (see “Problem solving guide - Dis-
play warnings”).
Accessories
21
Accessories supplied
Edding4095 chalk marker
Egg tray
Bottle holder
The flexible ribs grip the bottles se-
curely when the door is opened and
closed.
Bottle rack
Bottles can be stored horizontally using
the bottle rack to save space.
The bottle rack can be placed at differ-
ent positions in the appliance.
Ice cube tray
Cool pack
The cool pack prevents the temperature
in the freezer section from rising too
quickly in the event of a power cut. This
can help prolong the storage life.
The cool pack will be at its most effect-
ive after it has been in the freezer for
approx. 24hours.
Accessories
22
Optional accessories
A range of useful Miele accessories and
care products are available for your ap-
pliance.
Accessories are available to order via
the Miele Webshop, from Miele dir-
ectly (see back cover for contact de-
tails) or from your Miele dealer.
Multi-purpose microfibre cloth
The microfibre cloth is suitable for re-
moving fingerprints and light soiling
from surfaces such as stainless steel,
glass, plastic and chrome without the
use of chemicals.
Bottle rack
The appliance is supplied with a bottle
rack for the refrigerator section. Addi-
tional bottle racks can be fitted if re-
quired.
KKF-FF charcoal filter with holder
(Active AirClean)
Charcoal filters neutralise unpleasant
odours in the fridge zone for improved
air quality.
KKF-RF replacement filters
(ActiveAirClean)
Replacement filters to the fit the holder
are available. We recommend replacing
the charcoal filters every 6months.
XKS3100W WiFi stick
(Miele@home)
The WiFi stick enables your refrigeration
appliance to communicate, so that you
can access appliance data at any time
with a smartphone or tablet (iOS® or
Android™ operating systems).
To use the Miele@mobile app or
Miele@home features, such as the op-
tion to switch on SuperCool/Super-
Freeze, you must insert the WiFi stick
into your Miele refrigeration appliance
and connect it to your WiFi network.
Fitting and installation instructions for
the stick are supplied with it and de-
scribe how to install the WiFi stick and
connect to a WiFi network.
Before using for the first time
23
Before using for the first time
Packaging material
Remove all packaging material from
the inside of the appliance.
Protective foil
The stainless steel trim to the interior
shelves and the door shelves has a
layer of protective foil to prevent dam-
age during transportation. The appli-
ance doors, and side panels where ap-
plicable, have a protective foil.
Do not remove the foil until the appli-
ance has been positioned in its final
location.
Cleaning the appliance
Please refer to the relevant instruc-
tions in “Cleaning and care”.
Clean the inside of the appliance and
the accessories.
Clean the entire surface of the appli-
ance doors before writing on them for
the first time with a microfibre cloth
and lukewarm water. Then dry the
surface with a soft cloth.
Connecting the appliance
Connect the appliance to the electri-
city supply as described in “Electrical
connection”.
Standby
will appear in the display.
Switching on and off
24
Touch display
Using pointed or sharp objects on
the touch display can damage it.
Only touch the display with your fin-
gers.
If your fingers are cold, the touch dis-
play may not react.
Switching on
To enable the temperature to get suffi-
ciently cold inside the appliance, allow
the appliance to run for approx.
2hours before placing food in it.
Do not place food in the freezer sec-
tion until the temperature is at least
-18°C.
Standby
Touch briefly.
The welcome message
Miele - Willkommen will appear in the dis-
play for approx. 3seconds.
If this does not happen and ap-
pears in the display, the safety lock is
still activated (see “Selecting further
settings - Activating or deactivating
the safety lock - Deactivating the
safety lock temporarily”).
°C
5
-18
°C
Start screen
The display changes to the start screen.
The interior lighting will come on and
become brighter until the maximum
brightness is reached. The appliance is
switched on and begins to cool down to
the following pre-set temperatures:
- Temperature in the refrigerator sec-
tion=5°C
- Temperature in the freezer section=
-18°C
Start screen
°C
5
-18
°C
The start screen is the screen from
which all settings can be selected.
Switching on and off
25
The display is divided into several fields
for this purpose:
The temperature display for the refri-
gerator section is in the upper field.
Touch the temperature display to ac-
cess the refrigerator section display.
Here you can set or change the temper-
ature (see “The correct temperature -
Setting the temperature”) as well as se-
lect the Super cool function and/or
the DynaCool function (see “Using
Super cool, Super freeze and
DynaCool”).
The temperature display for the
freezer section is in the lower field.
This is also identified by.
Touch the temperature display to ac-
cess the freezer section display. Here
you can set or change the temperature
as well as select the Super freeze
function (see “Using Super cool, Super
freeze and DynaCool”).
Settings mode is on the right-
hand side.
Touch the symbol to access Settings
mode. Here further settings can be se-
lected (see “Selecting further settings”).
Switching off the refrigeration
appliance
You can switch the appliance off in Set-
tings mode (see “Selecting further set-
tings”).
°C
5
-18
°C
Start screen
Touch.
Settings mode
Use the or arrow buttons until
is displayed.
Switching off the refrigeration appliance
Touch.
The temperature display goes out and
lights up.
The interior lighting of the refrigerator
section will go out and cooling will be
switched off.
will go out after approx. 10minutes.
The display goes dark and switches to
energy-saving mode.
Switching on and off
26
Switching off the refrigerator section
separately
The refrigerator section can be
switched off without having to switch
off the freezer section.
Tip: We recommend using the Holiday
mode function if you are away on holi-
day (see “Selecting further settings -
Switching Holiday mode on/off”), so
that the appliance operates at lower
power rather than being switched off
completely.
If the Party mode, DynaCool or
Super cool functions have been
previously selected, these will be
switched off automatically.
°C
5
-18
°C
Standby
Touch the temperature display in the
field for the refrigerator section.
5
°C
OK
Refrigerator section display
Touchor until is displayed.
Touch.
TouchOK to confirm your entry.
°C
-18
Start screen - refrigerator section switched
off
The temperature display for the refriger-
ator section goes out and lights up.
The refrigerator section is switched off.
The temperature in the freezer section is
still displayed. The interior lighting in the
refrigerator goes out.
Switching on and off
27
Switching the refrigerator section on
separately (if previously switched off)
°C
-18
Start screen - refrigerator section switched
off
Touch in the field for the refriger-
ator section.
4
°C
OK
Refrigerator section display
Touch or until 4°C is displayed.
Touch OK to confirm your entry.
The refrigerator section is switched on
and begins to cool down to the temper-
ature set. When the door is opened the
interior lighting comes on.
Switching off for longer peri-
ods of time
If, during a long absence, the refri-
geration appliance is switched off
but not cleaned and the door(s) left
shut, there is a risk of mould forming
inside the appliance.
It is essential to clean the refrigera-
tion appliance.
If the refrigeration appliance is not go-
ing to be used for a longer period of
time, observe the following:
Switch the refrigeration appliance off.
Switch the appliance off at the wall
socket and pull the plug out of the
socket, or disconnect the fuse.
Clean the refrigeration appliance and
leave the door ajar to air the appli-
ance and avoid odours building up in-
side.
It is also advisable to carry out the last
two instructions if you are switching
the refrigerator section off for a longer
period of time.
The correct temperature
28
It is very important to set the correct
temperature for storing food in the ap-
pliance. Bacteria will cause food which
is not stored at the correct temperature
to deteriorate rapidly. Temperature influ-
ences the growth rate of these bacteria.
Reducing the temperature reduces their
growth rate.
The temperature in the refrigeration ap-
pliance will rise:
- The more often the appliance door is
opened and the longer it is kept open
- The more food that is stored in it
- The warmer the food is which is be-
ing put into it
- The higher the ambient temperature
surrounding the refrigeration appli-
ance. This refrigeration appliance is
designed for use within specific am-
bient temperatures (climate range).
Do not use in ambient temperatures
for which it is not designed.
...in the refrigerator section
We recommend a temperature of 4°C
in the refrigerator section.
...in the freezer section
To freeze fresh food and to store frozen
food for long periods, a temperature of
-18°C is required. At this temperature
the growth of bacteria is generally hal-
ted. As soon as the temperature rises
above -10°C, the bacteria become act-
ive in the food again so it cannot be
kept as long. For this reason, partially
defrosted or defrosted food must not be
re-frozen. Food may be re-frozen once it
has been cooked , as the high temper-
atures achieved when cooking destroy
most bacteria.
The correct temperature
29
Temperature display
°C
5
-18
°C
Start screen
In normal operation the upper temper-
ature display shows the average, cur-
rent temperature in the refrigerator
section and the lower temperature
display the lowest temperature in
the freezer section.
Depending on the ambient temperature
and the temperature setting, it can take
the appliance a few hours to reach the
temperature required and for this tem-
perature to then be shown as a con-
stant temperature in the display.
Setting the temperature
The temperatures for the refrigerator
and freezer sections can be set inde-
pendently of one another.
Touch the temperature display for the
section you want to change.
The previously set temperature will ap-
pear.
4
°C
OK
Refrigerator section display
-18
°C
OK
Freezer section display
Use the and arrow buttons to
set the temperature higher or lower.
The correct temperature
30
Touch OK immediately after setting
the temperature to confirm your entry.
Or wait approx. 8seconds after the
sensors were last touched. The tem-
perature will then be adopted auto-
matically.
Tip: The newly set temperature can also
be confirmed and adopted by closing
the appliance door.
The temperature display will then
change to the current temperature in
the appliance.
Temperature range
- The temperature in the refrigerator
section can be adjusted from 1°C to
9°C.
- The temperature in the freezer sec-
tion can be adjusted from -15°C to
-26°C.
Tip: If you have adjusted the temperat-
ure, wait for approx. 6hours if the ap-
pliance is not very full and for approx.
24hours if the appliance is full before
checking the temperature display, as it
will take this long for the appliance to
give an accurate reading.
If, after this time, the temperature is
still too high or too low, you will need
to adjust it again.
Using Super cool, Super freeze and DynaCool
31
The following functions are available
depending on section:
- Refrigerator section
Super cool and DynaCool
- Freezer section
Super freeze
See the following pages for more in-
formation on these functions and how
to switch them on.
Super freeze function
For optimum results switch on the Su-
per freeze function before putting fresh
food into the freezer section. This helps
food to freeze quickly and retain its nu-
trients, vitamins, flavours and appear-
ance.
Exceptions:
- When placing food in the freezer that
is already frozen
- When freezing up to 1kg of fresh
food daily
The SuperFreeze function should be
switched on 6hours before placing
food in the freezer section.
When freezing the maximum amount
of food the SuperFreeze function
should be switched on 24hours be-
forehand.
When SuperFreeze is switched on, the
appliance will work at full power to
lower the temperature in the freezer.
The SuperFreeze function will switch it-
self off automatically after approx.
65hours. The quantity of fresh food
placed in the freezer will determine the
time before the SuperFreeze function
turns off.
Tip: To save energy, you can manually
switch off SuperFreeze once the freezer
reaches a constant temperature of
-18°C or colder. Monitor the temperat-
ure in the freezer section.
When SuperFreeze is switched off, the
appliance will run at normal power
again.
Super cool function
The Super cool function can be used to
rapidly reduce the temperature in the
refrigerator section to its lowest setting
(depending on the room temperature).
Tip: Super cool is particularly recom-
mended for the rapid chilling of large
amounts of fresh food or drink.
When Super cool is switched on, the
appliance will work at full power to
lower the temperature in the appliance.
It switches itself off automatically after
approx. 12hours.
Tip: To save energy, you can switch the
Super cool function off yourself once
food and drinks are sufficiently chilled.
After switching Super cool off the appli-
ance reverts to working at normal
power.
Using Super cool, Super freeze and DynaCool
32
DynaCool function
When the DynaCool function is not
switched on, the natural circulation of
air in the appliance will cause different
temperature zones in the refrigerator as
the cold, heavy air will sink to the low-
est section of the appliance. You should
bear this in mind when placing food in
the appliance (see “Storing food in the
refrigerator section”).
However, if you are placing a large
amount of food in the refrigerator at any
one time, (e.g. after the weekly shop) it
is a good idea to switch DynaCool on.
This way you can distribute the temper-
ature inside the appliance to all areas
more evenly so that all the food will be
chilled to about the same degree.
The temperature is set as normal.
DynaCool should also be selected
when:
- the ambient temperature in the room
is high (above approx. 30°C), and
- the room humidity level is high.
With DynaCool switched on, the fan is
ready: when the compressor switches
on, the fan also switches on automat-
ically.
Tip: Because DynaCool requires more
energy, you should switch it off under
normal conditions.
To save energy, the fan switches off
automatically whilst the door is open.
Switching a function on or off
Touch the temperature display for the
section you want.
5
°C
OK
Refrigerator section display - DynaCool, Su-
per cool
-18
°C
OK
Freezer section display - Super freeze
The current temperature and and
or appear in the display.
Touch the symbol for the function you
want.
- If the symbol is lit up orange, the
function is selected.
- If the symbol is white, the function is
deselected.
Touch OK to confirm your entry.
Or wait approx. 8seconds after the
sensors were last touched. The entry
will then be adopted automatically.
Super cool, Super freeze or DynaCool
are switched on or off.
Using Super cool, Super freeze and DynaCool
33
Functions that are switched on are not
displayed in the start screen.
Any function which was previously
switched on will be switched off fol-
lowing an interruption to the power
supply.
Displaying a selected function
Touch the temperature display for the
relevant section.
The current temperature appears on the
display. The symbol for the selected
function lights up orange.
Temperature and door alarm
34
The appliance has a warning system
which ensures that the temperature in
the freezer cannot rise unnoticed and to
avoid energy being wasted if a door is
left open.
Temperature alarm
Health risk caused by decom-
posing food.
If the temperature in the freezer sec-
tion remains above -18°C for a long
time, the frozen goods can start to
defrost. This will reduce the storage
life of the food.
Check whether the frozen goods
have started to defrost. If they have,
check that the food is safe to use
and if it is, then use it as soon as
possible or cook it before freezing it
again.
If the temperature in the freezer section
becomes too warm,
will light up red
in the freezer section temperature dis-
play.
An alarm will also sound until the cause
of the alarm is rectified or the alarm is
switched off.
The temperature the appliance is set at
determines the temperature the appli-
ance recognises as being too warm.
The temperature alarm is only dis-
played on the start screen and not
when selecting a setting.
A temperature alarm is displayed be-
fore an existing door alarm.
The audible and visual signals will be
activated if:
- You switch on the refrigeration appli-
ance and the temperature in a tem-
perature zone differs greatly from the
set temperature.
- A lot of warm room air enters the
freezer when you are rearranging or
taking out frozen goods.
- You are freezing large amounts of
food at once.
- You are freezing warm food.
- There was a mains outage.
- The refrigeration appliance has a
fault.
The alarm will stop and
will go out
as soon as the temperature has
dropped down to the correct level
again.
Switching the temperature alarm off
early and checking the warmest tem-
perature
If the alarm disturbs you, you can
switch it off early. You can also find out
what the warmest temperature was in
the freezer section.
Touch
.
The fault message is confirmed and the
alarm will stop. The start screen ap-
pears in the display: the warmest tem-
perature recorded in the freezer section
so far will flash in the temperature dis-
play for approx. 1minute. The temper-
ature display will then change to show
the current temperature in the freezer
section.
Temperature and door alarm
35
You can exit from the flashing temperat-
ure display early:
Touch the temperature display for the
freezer section.
The flashing warmest temperature dis-
play will go out. The display will then re-
vert to showing the current temperature
in the freezer section.
Door alarm
The appliance has a warning system to
prevent energy being wasted and food
becoming warm if the doors are left
open.
If an appliance door is left open for a
longer period of time,
will light up
yellow on the relevant temperature dis-
play. An alarm tone will also sound.
The amount of time until the door alarm
is triggered depends on the setting se-
lected (factory default setting =
1minute) and can be changed (see
“Selecting further settings – Changing
the time until the door alarm is
triggered”). However, the door alarm
can also be turned off (see “Selecting
further settings – Setting the volume/
Switching alarms and audible tones on/
off”).
The alarm will stop and
will go out
on the display as soon as the door is
closed.
Temperature and door alarm
36
The door alarm is only displayed on
the start screen.
The door alarm is automatically
supressed when you are in Settings
mode. No symbol will be displayed
and no alarm will sound.
If an audible tone does not sound in
the event of a door alarm, the alarm
has been switched off in Settings
mode (see “Selecting further settings –
Setting the volume/Switching alarms
and audible tones on/off”).
Switching the door alarm off early
If the noise disturbs you, you can
switch the alarm off if you wish.
Touch
.
The current temperature is shown in the
display. The alarm will stop.
Selecting further settings
37
Settings overview
The following settings can be activated or changed. Default settings are shown in
bold or as marked level in the segment bar.
Setting Selection/factory default set-
ting
Switching Party mode on/off On (orange symbol)/off
Switch Holiday mode on/off On (orange symbol)/off
Use minute minder
(QuickCool Timer)
0:00–9:59 h:min
/ Activate/deactivate the safety
lock
On/off
Switch appliance off OK
Switch Sabbath mode on/off On (orange symbol)/off
Change the time before the
door alarm is triggered
Level1–7 (level1 = 30sec)
(level2 = 1min)
Miele@home system settings
(only visible if the WiFi stick
has been fitted)
Further setting options are de-
scribed in the fitting and in-
stallation instructions, which
are enclosed with the stick.
/
Switch keypad tone on/off On/off
/ Set volume/switch off alarms
and audible tones
Off – level7
Selecting further settings
38
Set the display brightness Level 1–7
°C Change the temperature unit °C/°F
Demo mode (only visible when
switched on)
Off
Reset default settings
Access information about your
refrigeration appliance
Display (important when re-
porting a fault to Miele Service)
Replace charcoal filter re-
minder
On (orange symbol)/off
Clean ventilation grille reminder On (orange symbol)/off
Selecting further settings
39
Selecting further settings
In Settings mode, certain settings
can be adjusted and functions selected,
allowing you to adjust the refrigeration
appliance to suit your requirements.
See the following pages for more in-
formation on these settings.
The door alarm and other warnings
are automatically supressed when you
are in Settings mode. No symbol will
be displayed and no alarm will sound.
Exception: If there is an appliance fault
(F+numbers), Settings mode will be
exited automatically. The fault code
will be shown on the display and an
alarm will sound (see “Problem solving
guide – Display messages”).
Selecting the setting you want
°C
5
-18
°C
Start screen
Touch.
Settings mode
Scroll left or right using
theorarrow buttons.
The symbol for the selectable setting
appears in the middle of the display.
The symbols for the next available set-
tings appear in the background to the
right and left, but are not selectable.
Touch the symbol for the setting you
want (see “Settings overview”).
Depending on the setting selected,
there are two options:
1. You go into a sub-menu with further
options or where values can be
entered.
2. You select the setting directly. The
symbol turns orange and this con-
firms your selection. If the symbol is
white, the function has not been ac-
tivated.
Selecting further settings
40
Entering values
All values entered must be confirmed
withOK. If the value is not confirmed
the display will revert to the start screen
after approx. 15seconds and the set or
altered values will not be adopted.
Exiting a menu (“Back”)
You can return to the previous screen
by touching.
Entries made before this which have not
been confirmed withOK will not be
saved.
Explanation of the different
Settings
Switching Party mode on or off
This function is particularly useful if you
need to cool or freeze large quantities
of food and drink quickly and make ice
cubes, for example, if you are expecting
a large number of guests.
Super cool, DynaCool and Super freeze
are switched on automatically:
The refrigerator section as well as the
freezer section cool down very rapidly
to their lowest temperature (depending
on the ambient room temperature).
Tip: Switch the function on approx.
4hours before placing food in the appli-
ance.
If Party mode cannot be switched on,
the refrigerator section has been
switched off separately or Holiday
mode is switched on.
Party mode will switch off automatically
after approx. 20 hours. You can switch
it off earlier at any time.
If previously switched on, Party mode
will switch off if there is an interruption
to the power supply.
Selecting further settings
41
Switching Holiday mode on / off
This function is useful when going on
holiday if you do not wish to switch the
refrigerator section off completely and
do not need a high degree of cooling.
The freezer section remains switched
on at -18°C. The refrigerator section is
regulated at a temperature of 15°C, re-
maining in operation whilst also saving
energy.
Do not store any temperature-
sensitive food which goes off easily
such as fruit, vegetables, fish, meat
and dairy products during this time.
Food which does not go off quickly can
be stored in the appliance for some
time at this moderate refrigerator sec-
tion temperature and the energy con-
sumption is lower than in normal opera-
tion.
This also prevents the build-up of
odours and mould which can occur if
the refrigerator section is switched off
and the door is closed.
When Holiday mode is switched on, it is
displayed in the start screen:
°C
-18
Holiday mode start screen
If Holiday mode cannot be switched
on, the refrigerator section has been
switched off separately.
If Party mode, Super cool or DynaCool
are switched on, these will be
switched off when Holiday mode is
selected.
Selecting further settings
42
Using the minute minder (Quick-
Cool timer)
The minute minder can be used to time
other activities in the kitchen,
e.g.chilling pastry. The audible tone will
sound at the set time.
A maximum minute minder duration of
9h59min can be set.
– Setting the minute minder
Touch.
Use or to set the hours.
Confirm withOK.
The hours are now set. You can now set
the minutes.
Use or to set the minutes.
Confirm withOK.
The minutes are now set. The set
minute minder time starts counting
down. If the appliance door is opened
again, the minute minder duration will
appear counting down in the display.
After approx. 3s, the display changes
to the start screen.
If the minute minder duration is dis-
played or altered, the minute minder
duration countdown will be halted.
In the event of an interruption to the
power supply or when power is re-
stored, any previously set minute
minder duration will be deleted.
– When the minute minder duration
has elapsed
An audible signal will sound and will
flash.
Touch the display.
The start screen appears.
–Altering a minute minder entry
Open the appliance door.
and the minute minder duration
countdown appear for approx. 3s in
the display.
During this time, touch the minute
minder duration countdown in the
display.
Touch to alter a minute minder dur-
ation. Proceed exactly as for setting
the minute minder duration (see “Set-
ting the minute minder”).
–Cancelling a minute minder dura-
tion
Open the appliance door.
and the minute minder duration
countdown appear for approx. 3s in
the display.
During this time, touch the minute
minder duration countdown in the
display.
Touch to delete a minute minder
duration.
The start screen appears.
You can also alter or cancel a set
minute minder duration in Settings
mode.
Selecting further settings
43
Activating or deactivating the
safety lock
The safety lock can be activated to pre-
vent:
- the appliance being switched off by
mistake,
- the temperature being changed by
mistake,
- the DynaCool, Super cool and Super
freeze functions being selected by
mistake,
- settings being adjusted by mistake (it
is only possible to deactivate the
lock).
This prevents the appliance being
switched off or settings adjusted
without your knowledge, by children, for
example.
The safety lock will remain activated
following an interruption to the power
supply, if previously switched on.
– Deactivating the safety lock tem-
porarily
Touch the display.
appears.
Touch for approx. 6seconds.
You can now select further settings
(temperature, additional functions, etc.).
When the appliance door is closed
again the safety lock is switched back
on.
– Deactivating the safety lock
Touch the display.
appears.
Touch for approx. 6seconds.
The start screen will appear.
Touch.
Select.
lights up orange.
Touch.
appears in the display. The safety
lock is deactivated.
Switching the refrigeration appliance
off
The whole refrigeration appliance can
be switched off with this function.
The temperature display goes out and
lights up.
The interior lighting goes out and cool-
ing is turned off.
will go out after approx. 10minutes
and the display will turn dark (Energy-
saving mode).
Selecting further settings
44
Switching Sabbath mode on/off
The appliance offers a Sabbath pro-
gramme for the purposes of religious
observance.
The following are switched off:
- the interior lighting when the door is
opened,
- all audible and visual signals,
- the temperature display,
- the DynaCool, Super cool, Super
freeze, Party mode or Holiday mode
functions (if previously selected),
- the minute minder (if previously
switched on).
Furthermore you cannot select any set-
tings in Settings mode.
The Sabbath mode function will switch
itself off automatically after approx.
120hours.
Ensure that the doors are properly
closed, as visual and audible alarms
are switched off.
Any interruption to the power supply
during this time is not shown in the
display. After an interruption to the
power supply, the appliance will re-
start in Sabbath mode, if it was previ-
ously switched on.
– Switching Sabbath mode on
Touch.
lights up orange.
Then lights up white in the display.
Sabbath mode display
will go out after approx. 3seconds
and the display will go dark.
– Switching Sabbath mode off pre-
maturely
Touch the display.
appears.
Touch.
lights up orange.
Touch.
lights up white. The function is
switched off.
Selecting further settings
45
Setting the time before the door
alarm
is triggered
The refrigeration appliance has a door
alarm. If a door is open for a longer
period of time an alarm will sound (if
this has not been switched off: see
“Setting the volume/Switching alarms
and audible tones on/off”) and
will
light up in the display (see “Temperature
and door alarm – Door alarm”).
You can set the time before the door
alarm
sounds with the segment bar:
The time can be set in 30-second incre-
ments, starting with 30seconds (level
1=1filled-in segment) up to a max-
imum of 3minutes 30seconds
(level7=7filled-in segments).
Switching the sensor tone
on /
off
Every time a selectable field is touched
a sensor tone sounds. You can switch
this on
or off
.
Setting the volume/Switching alarms
and audible tones on/off
You can set the volume of the alarms
and audible tones in the segment bar:
If all segments are filled in, the max-
imum volume is set.
If no segments are filled in, the alarm
and audible tones are switched off.
appears.
You will hear the volume change as it is
adjusted.
Alarms and audible tones for temper-
ature alarms, error messages, inter-
ruptions to the power supply or a set
minute minder cannot be switched off.
Selecting further settings
46
Setting the display brightness
You can set the display brightness in
the segment bar:
If all segments are filled in, the max-
imum brightness is selected.
You will see the brightness change as it
is being adjusted.
Setting the temperature unit°C/°F
You can choose between degrees
Celsius°C and degrees Fahrenheit°F
for the temperature display.
Switching Demo mode off
Demo mode allows the refrigeration
appliance to be presented in the
showroom without the cooling system
being switched on. Do not activate
this setting for domestic use.
If Demo mode has been switched on as
a default setting, will show on the dis-
play. You can switch the function off
here.
If Demo mode has been switched off it
cannot be switched on again via Set-
tings mode.
Resetting to the factory default set-
tings
All appliance settings are reset to the
factory default and the appliance is
switched off.
Accessing information
Appliance data (model number and
serial number) is shown in the display.
Tip: This data is important when report-
ing an appliance fault to Miele Service.
Confirm with OK to leave the informa-
tion screen.
–Displaying licence agreements
Licences used can be displayed via ©.
Selecting further settings
47
Replace charcoal filter reminder
The appliance is not supplied with fil-
ters with holder KKF-FF (Active
AirClean). These are available to pur-
chase separately (see “Accessories –
Optional accessories”).
If the charcoal filter indicator has been
activated, you will be reminded to re-
place the filter after approx. 6months
(see “Cleaning and care” – “Replacing
the charcoal filters”).
Thesymbol will then appear in the
start screen in the temperature display
and an audible tone will sound (if
switched on).
Touch the symbol to confirm the mes-
sage. This resets the counter and the
display changes back to the start
screen.
Clean ventilation grille reminder
The appliance has a ventilation grille in
the plinth.
If the Clean ventilation grille reminder is
activated, you will be reminded to dust
the ventilation grille after ap-
prox.12months (see “Cleaning and
care - Cleaning the ventilation grille”).
will then appear in the display and
an audible tone will sound (if switched
on).
Tip: The ventilation grille should be
cleaned on a regular basis with a brush
or vacuum cleaner (e.g. use the dusting
brush for Miele vacuum cleaners).
A build-up of dust will increase the en-
ergy consumption of the appliance.
Touch the symbol to confirm the mes-
sage. This resets the counter and the
display changes back to the start
screen.
Storing food in the refrigerator section
48
Risk of explosion due to flam-
mable mixes of gases.
Electrical components can cause
flammable mixes of gases to ignite.
Do not store explosive materials in
the refrigeration appliance or any
products containing propellants (e.g.
spray cans).
Risk of damage due to greasy or
oily food.
If storing food which contains a lot of
fat or oil in the refrigeration appliance
or the appliance door, make sure
that it does not come into contact
with plastic components as this
could cause stress cracks or break
the plastic.
Make sure that no fat or oil leaks
onto the plastic parts of the refrigera-
tion appliance.
Different storage zones
Due to natural air circulation, there are
different temperature zones in the refri-
gerator section.
Cold, heavy air sinks to the lowest sec-
tion of the refrigeration section. Make
use of the different zones when placing
food in the appliance.
Tip: To allow air to circulate efficiently,
do not pack food too closely together in
the appliance.
If there is insufficient air circulation,
the cooling performance will de-
crease and energy consumption will
increase.
Do not cover the fan in the rear wall
of the appliance.
Tip: Do not store food in such a way
that it touches the rear wall of the refri-
gerator section as it may freeze to the
rear wall.
Warmest area
The warmest area in the refrigerator
section is at the top in the front area
and in the door. Use this for storing but-
ter and cheese.
Storing food in the refrigerator section
49
Coldest area
The coldest area in the fridge zone is
directly above the DailyFresh drawer
and at the back of the appliance.
Use these areas to store all delicate and
highly perishable food such as:
- Fish, meat, poultry
- Cold cuts, ready meals
- Dishes or baked goods containing
eggs or cream
- Fresh dough, cake mixtures, pizza or
quiche dough
- Raw milk cheese and other raw milk
products
- Pre-packed vegetables
- Other fresh food (with a label stating
it should be kept at a temperature of
approx. 4°C)
Tip: Store food in such a way that it
does not touch the rear wall of the
fridge zone. Otherwise it could freeze to
the rear wall.
Food which is not suitable for
storage in the refrigerator sec-
tion
Not all food is suitable for refrigeration
at temperatures below 5°C, because it
may be sensitive to cold. Depending on
the type of food, the appearance, con-
sistency, flavour and/or vitamin content
may be altered if stored at too cold a
temperature.
Food which is sensitive to cold in-
cludes:
- Pineapples, avocados, bananas,
pomegranates, mangoes, melons,
papayas, passionfruit, citrus fruit
such as lemons, oranges, mandarins,
grapefruit
- Fruit (which is not yet ripe)
- Aubergines, cucumbers, potatoes,
peppers, tomatoes, courgettes
- Hard cheeses (e.g. Parmesan, moun-
tain cheese)
Notes on buying food
The freshness of the food when it is first
placed in the appliance is the most im-
portant factor for how long it stays
fresh.
Take into account the use-by date and
the correct storage temperature.
Time out of the refrigerator, e.g. trans-
porting food in a warm car, should be
kept to a minimum.
Storing food in the refrigerator section
50
Storing food correctly
Ensure that food stored in the fridge
zone is in packaging or covered prop-
erly (some exceptions apply in the
DailyFresh drawer). This will prevent
food odours from affecting other food,
stop food from drying out and also pre-
vent any cross-contamination of bac-
teria. This is particularly important when
storing meat products. Make sure that
food such as raw meat and fish in par-
ticular does not come into contact with
other food.
By ensuring that the temperature set-
tings are correct and by taking appro-
priate hygiene measures, you can pro-
long the storage life of your food con-
siderably. This prevents food waste.
Protein-rich food
Please note that food rich in protein de-
teriorates faster than other types of
food. Shellfish, for example, deterior-
ates faster than fish, and fish deterior-
ates faster than meat.
Storing food in the DailyFresh drawer
51
The DailyFresh drawer provides good
storage conditions for fruit and veget-
ables.
The humidity level in the DailyFresh
drawer can also be regulated to suit the
food being stored. Food retains its own
moisture if stored at a higher humidity
and so does not dry out as quickly. The
temperature is approximately equivalent
to the temperature in the refrigerator
section.
Remember that the fresher the food
when placed in the appliance, the
longer it will stay fresh.
Regulating the humidity level in the
DailyFresh drawer
A slide control is used to regulate the
amount of moisture present.
Slide control at = moisture not in-
creased
For hygiene reasons always keep these
foods covered or wrapped.
Slide control at = moisture in-
creased
This setting is suitable for storing fruit
and vegetables.
The slide control closes the vents in the
drawer so the moisture cannot escape.
The moisture level greatly depends on
the type and quantity of food being
stored, if stored unwrapped.
If the quantity of food being stored in
this compartment is small, the humidity
level may be too low.
Tip: If you are only storing a small
amount of food, wrap it in airtight pack-
aging.
Increased moisture in the drawer
can, in some circumstances, cause a
build-up of condensate.
Wipe off any condensate with a
cloth.
Storing food in the DailyFresh drawer
52
Storage results for food stored
in the DailyFresh drawer
Observe the following tips if you find
that food you have stored does not
keep well (e.g. food becomes limp or
wilts after only being stored for a
short time):
- Only place fresh food in the appli-
ance. The initial condition of the food
is crucial to maintaining freshness.
- Clean the drawer before storing food
in it.
- Very wet food should be dried off be-
fore storing it.
- Do not store food which is sensitive
to cold in the drawer (see “Food
which is not suitable for storing in the
refrigerator section”).
- Set the slide control to the correct
position for the food being stored (hu-
midity not increased or humidity in-
creased).
- An increased humidity level in the
humidity controlled compartment is
achieved by the moisture present in
the food being stored, i.e. the more
food stored in the compartment, the
higher the humidity.
If too much moisture collects in the
compartment at the setting and
the food is affected, dry the floor with
a cloth, and place a rack or similar
item in the compartment so that ex-
cess moisture can drip down.
If the humidity level becomes too low,
wrap the food in airtight packaging.
Adjusting the interior fittings (refrigerator section)
53
Adjusting the door/bottle shelf
Only move door/bottle shelves when
they are empty.
Push the door/bottle shelf upwards,
then remove it by pulling it forwards.
Replace the shelf at the required
height. Ensure that it is securely
pushed back into position.
Moving the shelves
Stoppers prevent the shelves from be-
ing dislodged by mistake.
The shelves can be adjusted accord-
ing to the height of the refrigerated
goods:
1. Lift the shelf up slightly at the front.
2. Pull it forwards a little and lift it until
the notch at the side is in line with
the shelf support. It can then be
raised or lowered to the required
level.
The raised edge on the protective strip
at the back must face upwards to pre-
vent food from touching the back of
the appliance and freezing to it.
Adjusting the bottle rack
The bottle rack can be placed at differ-
ent positions in the appliance.
Raise the bottle rack slightly at the
front, and pull it forwards a little until
the notch at the side is in line with the
shelf support. It can then be raised or
lowered to the required level.
The rear rail must face upwards to pre-
vent bottles from touching the back of
the appliance.
Stoppers prevent the bottle rack from
being dislodged by mistake.
Adjusting the interior fittings (refrigerator section)
54
Removing the DailyFresh
drawer and rollers
The DailyFresh drawer is on rollers and
can be removed for filling, emptying or
cleaning purposes.
Pull out the drawer as far as it will go,
and then lift it up and out.
Remove the roller runners from the
appliance floor.
Moving the storage drawer
(CompactCase)
You can move the drawer to a position
of your choice:
Pull out the drawer as far as it will go,
and then remove it.
Risk of damage due to incorrect
insertion of the shelf with the Com-
pactCase holder.
This could damage the temperature
sensor and the holder, or the temper-
ature sensor may not function cor-
rectly.
Do not place the shelf with the Com-
pactCase holder on the temperature
sensor.
Raise the shelf slightly at the front
and pull it forwards a little. Lift it until
the notches at the side are in line with
the shelf supports. It can then be
raised or lowered to the required
level.
Replace the drawer.
Adjusting the interior fittings (refrigerator section)
55
Adjusting or removing the
bottle holder
The bottle holder can be moved left or
right to create more room for drink car-
tons.
The bottle holder can be removed com-
pletely (e.g. for cleaning):
Pull the bottle holder upwards to re-
move it from the rear edge of the
bottle shelf.
The bottle holder can be replaced after
cleaning.
Moving the charcoal filters
Charcoal filters and a KKF-FF (Active
AirClean) holder are available as op-
tional accessories (see “Accessories -
optional accessories”).
When storing very strong smelling
food (e.g. very ripe cheese):
- Place the holder with the charcoal fil-
ters on the shelf where this food is
kept.
- Change the filters sooner if neces-
sary.
- Use more charcoal filters (with hold-
ers) in the appliance (see “Accessor-
ies – Optional accessories”).
The holder for the charcoal filters sits
on the protective strip at the back of the
shelf.
To move the charcoal filters, pull the
holder upwards to remove it from the
protective strip.
Refit the holder on the protective strip
of the shelf you wish to use it on.
Freezing and storing food
56
Maximum freezing capacity
To ensure that fresh food placed in the
freezer freezes through to the core as
quickly as possible, the maximum
freezing capacity must not be ex-
ceeded. The maximum freezing capa-
city for freezing within a 24-hour period
is given on the data plate: “Freezing ca-
pacity...kg/24hrs”.
Freezing fresh food
Fresh food should be frozen as quickly
as possible. This way the nutritional
value of the food, its vitamin content,
appearance and taste are not impaired.
Food which takes a long time to freeze
will lose more water from its cells,
which then shrink. During the defrosting
process, only some of this water is re-
absorbed by the cells. What this means
in practice is that the food loses more
moisture. You can see this in the large
amount of water that collects around
the food when it defrosts.
If food is frozen quickly, the cells have
less time to lose moisture, so they
shrink less. As there is not so much
moisture loss, it is easier for the food to
reabsorb it during the defrosting pro-
cess, and very little water collects
around the defrosted food.
Storing frozen food
Never re-freeze partially or fully de-
frosted food. Defrosted food may
only be re-frozen after it has been
cooked.
When buying frozen food to store in
your freezer, check:
- That the packaging is not damaged
- The use-by date
- The temperature at which the frozen
food is being stored in the shop.
The length of time food can be kept
is reduced if it has been stored at a
temperature warmer than -18°C.
Buy frozen food once you have fin-
ished the rest of your shopping and
wrap it in newspaper or use a cool
bag or cool box to transport it.
Put it into the freezer as soon as pos-
sible.
Freezing and storing food
57
Home freezing
Only freeze fresh food which is in a
good condition.
Before placing food in the appliance
When freezing more than 1kg of
fresh food, switch on the Super
freeze function for some time before
placing the food in the freezer (see
“Using Super cool, Super freeze and
DynaCool - Super freeze function”).
This helps food which is already stored
in the freezer to stay frozen.
Placing frozen food in the freezer
Risk of damage caused by load-
ing too much food.
Loading food which is too heavy can
cause damage to the freezer draw-
ers/glass shelves.
Do not exceed the relevant maximum
load size:
Freezer drawer = 25kg
Glass shelf = 35kg
Unfrozen food should not touch
frozen food as this will cause the
frozen food to begin to thaw.
To prevent food sticking together
when frozen, make sure that the
packaging and containers are dry.
–Freezing small amounts of food
Place the food in the upper freezer
drawers.
Place the frozen food flat in the bot-
tom of the freezer drawers so that it
freezes through to the core as quickly
as possible.
–Freezing the maximum amount of
food (see data plate)
If the ventilation slots are blocked the
cooling performance will decrease
and energy consumption will in-
crease.
When placing food in the freezer,
make sure that the ventilation slots
are not blocked.
Remove the upper freezer drawers.
Place the food flat on the upper glass
shelves so that it freezes through to
the core as quickly as possible.
Once frozen:
Place the frozen food in the freezer
drawer and push it back in.
Freezing and storing food
58
Storage time for frozen food
The storage life of food is very variable,
even at a constant temperature of
-18°C. Decomposition processes also
take place in frozen food, albeit at a
very reduced speed. For example, fat
can become rancid from contact with
oxygen in the air. This is why lean meat
can be stored approx. twice as long as
fatty meat.
The storage times quoted are guide val-
ues for the storage life of different food
groups in the freezer zone.
Food group Storage
time
(Months)
Ice cream 2to6
Bread, baked goods 2to6
Cheese 2to4
Fish, oily 1to2
Fish, lean 1to5
Sausage, ham 1to3
Game, pork 1to12
Poultry, beef 2to10
Vegetables, fruit 6to18
Herbs 6to10
For standard freezing results, follow the
advice on packaging.
By keeping the freezer zone at a con-
stant temperature of -18°C and taking
appropriate hygiene measures you can
maximise the storage life of your food
and avoid food waste.
Defrosting frozen goods
Never re-freeze partially or fully de-
frosted food. Defrosted food may only
be re-frozen after it has been cooked.
Frozen goods can be defrosted in differ-
ent ways:
- In a microwave oven
- In an oven using “Fan heat” or the
“Defrost” setting
- At room temperature
- In the refrigerator zone (the cold
given off by the frozen food helps to
keep the other food cold)
- In a steam oven
Flat pieces of partially thawed meat
or fish can be placed directly into a hot
frying pan.
Meat and poultry (e.g. mince, chicken,
fish fillets) should not come into contact
with other foods while defrosting. Catch
the liquid from defrosting and dispose
of it carefully.
Fruit should be defrosted at room tem-
perature in its packaging, or in a
covered bowl.
Most vegetables can be cooked while
still frozen. Just put straight into boiling
water or hot fat. The cooking time is
slightly less than that of fresh veget-
ables due to changes in the cell struc-
ture.
Freezing and storing food
59
Cooling drinks quickly
To cool drinks quickly in the refrigerator
section, switch on the SuperCool func-
tion.
If you want to cool a large amount of
drinks, or if you want to cool drinks in
the freezer section, select Party
mode in Settings mode.
When cooling drinks quickly in the
freezer, make sure bottles are not left in
for more than one hour. Otherwise
they could burst.
Tip: To avoid forgetting about bottles
placed in the freezer you can set the
minute minder (QuickCool timer) in
Settings mode.
Adjusting the interior fittings
Removing the drawers and glass
shelves
The drawers can be removed for filling,
emptying or cleaning purposes.
You can also expand the space avail-
able in the freezer section. If you wish to
freeze large items such as a turkey or
game, the glass shelves between the
drawers can be removed.
Pull out the drawer as far as it will go,
and then lift it up and out.
Lift the glass shelf slightly, then pull it
forward and out.
Freezing and storing food
60
Using accessories
Using the cool pack
The cool pack prevents the temperature
in the freezer zone from rising too
quickly in the event of a power cut. This
can help prolong the storage life.
Place the cool pack in the top drawer
of the freezer zone.
The cool pack will be at its most effect-
ive after it has been in the freezer for
approx. 24hours.
–In the event of a power cut
Place the frozen cool pack directly on
top of the frozen food in the front of
the top drawer.
Tip: When placing fresh food in the
freezer, use the cool pack to separate
the fresh food from the food which is
already frozen so that the frozen food
does not begin to thaw.
Making ice cubes
Fill the ice cube tray three quarters
full with water and place it on the bot-
tom of one of the freezer drawers.
Once frozen, use a blunt instrument,
for example a spoon handle, to re-
move the ice tray from the freezer if it
is stuck.
Tip: Ice cubes can be removed easily
from the tray by holding it under running
water for a short time.
Defrosting
61
Fridge zone and DailyFresh
drawer
The fridge zone and the DailyFresh
drawer defrost automatically.
Condensate and frost can build up on
the back wall of the fridge zone and the
DailyFresh drawer whilst the com-
pressor is running. You do not need to
remove this.
The condensate drains through a chan-
nel and drain hole into an evaporation
system at the back of the refrigeration
appliance. The warmth generated by
the compressor causes the condensate
to evaporate automatically.
Keep the condensate channel and
drain hole clean to enable this. Con-
densate must be able to drain away
unhindered at all times.
Freezer section
The appliance is equipped with a
“NoFrost” system. The freezer defrosts
automatically.
The moisture generated in the appli-
ance collects on the condenser and is
automatically defrosted and dissipated
from time to time.
This automatic defrosting system en-
ables the freezer to remain permanently
ice-free. Food stored in the freezer will
not defrost with this system.
Cleaning and care
62
Do not let water get into the elec-
tronic module or the lighting.
Risk of damage due to moisture
ingress.
The steam from a steam cleaner can
damage plastic and and electrical
components.
Do not use a steam cleaner to clean
the refrigeration appliance.
Cleaning water must not get into the
drain hole.
The data plate located inside the in-
terior cabinet of the refrigeration appli-
ance must not be removed. It contains
information which is required in the
event of a fault.
Cleaning agents
Cleaning and conditioning agents
used inside the appliance must be
food safe.
To avoid damaging all the surfaces of
your appliance, do not use:
- cleaning agents containing soda, am-
monia, acids or chlorides
- cleaning agents containing descaling
agents
- abrasive cleaning agents, e.g.
powder cleaners and cream cleaners
- solvent-based cleaning agents
- stainless steel cleaning agents
- dishwasher cleaner
- oven cleaner
- cleaning agents for ceramic hobs
- glass cleaning agents (except to
clean the glass front: for this a glass
cleaning agent containing a little al-
cohol, but no citric or similar addit-
ives may be used)
- hard, abrasive sponges and brushes,
e.g. pot scourers
- melamine eraser blocks
- sharp metal scrapers
We recommend using a clean sponge,
lukewarm water with a little washing-up
liquid to clean the surfaces of the appli-
ance.
The following pages contain important
information on cleaning.
Cleaning and care
63
Preparing the refrigeration ap-
pliance for cleaning
Switch the refrigeration appliance off.
appears in the display and cooling is
switched off.
Take any food out of the refrigeration
appliance and store it in a cool place.
Remove the shelves and bottle shelf
from the door.
Take out the freezer drawers and
glass plates.
Take out all other removable parts for
cleaning.
Dismantling an adjustable shelf
Before cleaning the shelf remove the
stainless steel trim at the front and the
protective strip at the back of the shelf.
To do this:
Place the shelf on a worktop covered
with a soft material (e.g. a tea towel).
Pull the stainless steel trim off the
shelf beginning at one side.
After cleaning the shelf reattach the
stainless steel trim and the protective
strip.
Removing the DailyFresh slide con-
trol
Remove the DailyFresh slide control be-
fore cleaning. Proceed as follows:
Place the shelf on a worktop covered
with a soft material (e.g. a tea towel).
Pull the slide control panel (1) and the
plastic trim (2) off, starting from one
side.
After cleaning the shelf reattach the
plastic trim and the slide control
panel.
Cleaning and care
64
Dismantling the storage drawer
(CompactCase)
Place the storage drawer on a work-
top covered with a soft material (e.g.
a tea towel).
Pull off the supports (1) from the
sides of the shelf.
Pull the stainless steel trim (2) off the
shelf.
Pull the protective strip (3) off the
shelf.
After cleaning the shelf reattach the
stainless steel trim, the protective
strip and the supports.
Cleaning the interior and ac-
cessories
The refrigeration appliance should be
cleaned regularly (at least once a
month).
Remove soiling immediately to pre-
vent it from drying on.
Clean the interior with a clean
sponge, lukewarm water and a little
washing-up liquid.
After cleaning, wipe with clean water
and dry with a soft cloth.
Remove the stainless steel parts be-
fore cleaning the adjustable shelves in
a dishwasher.
The following parts cannot be cleaned
in a dishwasher:
- the stainless steel trim
- the protective strips at the back of
the adjustable shelves
- all drawers and the compartment lid
(depending on model)
- the bottle rack
- the cool pack
These accessories should all be hand
washed.
Cleaning and care
65
Risk of damage as a result of ex-
cessively high dishwasher temperat-
ures.
Parts of the refrigeration appliance
may become unusable, e.g. deform,
if they are washed in the dishwasher
at more than 55°C.
For dishwasher-safe parts, only use
dishwasher programmes with a max-
imum temperature of 55°C.
Contact with natural dyes from car-
rots, tomatoes and ketchup, etc., may
discolour the plastic parts in the dish-
washer. This discolouration does not
affect the stability of the parts.
The following parts can be cleaned in
the dishwasher:
- the bottle holder, egg tray, ice cube
tray (depending on model)
- the shelves and bottle shelf in the
door
- the adjustable shelves (with the trim/
strips removed and without the print-
ing)
- the roller runners
- the holder for the charcoal filter
(available as an optional accessory)
Clean the condensate channel and
drain hole frequently so that con-
densate can drain away unhindered.
Use a straw or similar to clear the
drain if necessary.
Take the DailyFresh drawer out to do
this.
Leave the door open to air the appli-
ance for a short while and to prevent
odours building up.
Cleaning the front of the appli-
ance and the side panels
If soiling is left on for any length of
time, it may become impossible to
remove.
Surfaces may suffer discolouration or
damage.
Therefore, it is best to remove soiling
from the appliance front and side
panels immediately.
All surfaces are susceptible to
scratching. Contact with unsuitable
cleaning agents can alter or discol-
our the surfaces. Scratches on glass
fronts can lead to breakage in some
circumstances.
See the information on “Cleaning
agents” at the beginning of this sec-
tion.
Risk of damage as a result of in-
correct cleaning.
The glass front can alter or discolour
if you spot-clean it or remove soiling
when it is dry.
Wipe the entire surface of the glass
front with a wet cloth.
Clean the entire outer surface with a
clean, fluff-free microfibre cloth, a
dash of washing-up liquid and plenty
of hot water.
After cleaning, wipe with clean water
and dry with a soft cloth.
Cleaning and care
66
Using a glass-cleaning agent con-
taining additives, e.g. citrus or sim-
ilar, would cause streaking on the en-
tire surface.
Use a glass-cleaning agent which
contains a little alcohol but no citrus
or similar additives.
Tip: We also recommend the Miele
ceramic and stainless steel cleaner.
Cleaning the ventilation grille
A build-up of dust will increase the en-
ergy consumption of the appliance.
The ventilation grille should be
cleaned on a regular basis with a
brush or vacuum cleaner (e.g. use the
dusting brush for Miele vacuum
cleaners).
Tip: If you want to be reminded auto-
matically every 12 months, switch the
“Clean ventilation grille” reminder on
(see “Selecting further settings – Clean
ventilation grille reminder”).
Cleaning the door seal
If the door seal is damaged or has
slipped out of its groove, the appli-
ance door may not close properly
and cooling performance will be re-
duced. As a result, condensate will
build up in the interior cabinet and
this can cause a build-up of ice.
Do not damage the door seal and
ensure it does not slip out of its
groove.
Risk of damage as a result of in-
correct cleaning.
If you treat the door seal with oils or
grease, it can become porous.
Do not use any oils or grease on the
door seal.
The door seal should be cleaned reg-
ularly with clean water and then
wiped dry with a cloth.
Cleaning and care
67
After cleaning
Replace all shelves and accessories
in the appliance.
Switch the refrigeration appliance on.
Switch on the Super freeze function
for a while so that the freezer section
can cool down quickly.
Switch on the Super cool function for
a while so that the refrigerator section
can cool down quickly.
Place food in the refrigerator section
and close the door.
Place the freezer drawers with the
frozen food back in the freezer sec-
tion and close the door.
When the temperature in the freezer
section is a constant -18°C or colder
press the Super freeze button to
switch the Super freeze function off.
Replacing the charcoal filters
Charcoal filters and a KKF-FF (Active
AirClean) holder are available as op-
tional accessories (see “Accessories -
optional accessories”).
Replace the charcoal filters in the
holder every 6months.
If you would like to be reminded auto-
matically every 6months, switch on the
“Replace charcoal filter” reminder (see
“Selecting further settings – Replace
charcoal filter reminder”).
Replacement KKF-RF charcoal filters
can be obtained from the Miele Cus-
tomer Service Department, from your
dealer or from Miele's website.
Tip: The charcoal filter holder is dish-
washer-safe.
Pull the charcoal filter holder upwards
to remove it from the adjustable shelf.
When in position, the charcoal filters
must not touch the rear wall of the
refrigeration appliance as the mois-
ture could cause them to stick to it.
Insert the new charcoal filters deep
enough in the holder to ensure that
they do not protrude over the edge
of the holder.
Cleaning and care
68
Remove both charcoal filters and
place the new filters with the sur-
rounding edge pointing downwards in
the holder.
Place the holder in the middle of the
raised edge at the back of the ad-
justable shelf, so that it clicks into po-
sition.
Touch to confirm that the filters
have been replaced.
The “Replace charcoal filter” reminder
will go out on the display and the
counter will be reset.
Problem solving guide
69
Many malfunctions and faults that can occur in daily operation can be easily
remedied. Time and money will be saved because a service call will not be
needed.
The following guide may help you to find the reason for a malfunction or a fault,
and to correct it.
To prevent unnecessary loss of temperature it is advisable not to open the door
while waiting for the appliance to be serviced.
Problem Cause and remedy
The appliance is not
getting cold and the in-
terior lighting does not
come on when the door
is opened.
The appliance has not been switched on.
Switch the appliance on.
The mains plug is not inserted in the socket correctly
or the plug connector is not inserted into the socket
at the back of the appliance correctly.
Insert the mains plug into the mains socket and
the plug connector into the appliance socket cor-
rectly and switch on.
Check whether the mains fuse has tripped. There
could be a fault with the appliance, the household
electrical wiring or another electrical appliance.
Contact a qualified electrician or Miele.
The compressor runs
continuously.
This is not a fault. To save energy, the compressor
runs at a lower speed, but for longer, when less
cooling is required.
The compressor is
switching on more fre-
quently and for longer
periods of time. The
temperature in the refri-
geration appliance is
too low.
The ventilation gaps have been covered or become
too dusty.
Do not block the ventilation gaps.
Dust the ventilation gaps regularly.
The appliance doors have been opened too fre-
quently, or a large amount of fresh food has been
placed inside and/or frozen at the same time.
Only open the appliance doors when necessary
and for as short a time as possible.
After a while, the temperature will return to normal by
itself.
The appliance doors are not closed properly. A thick
layer of ice may have formed in the freezer.
Close the appliance doors.
Problem solving guide
70
Problem Cause and remedy
After a while, the temperature will return to normal by
itself.
If a thick layer of ice has already formed, this will af-
fect cooling and increase energy consumption.
Defrost the refrigeration appliance and clean it.
The ambient room temperature is too high. The
higher the ambient temperature, the longer the com-
pressor has to run.
See “Installation – Location”.
The temperature setting in the refrigeration appliance
is too low.
Correct the temperature setting.
A large amount of food is being frozen at once.
See “Freezing and storing food”.
The SuperCool function is still switched on.
You can switch off the SuperCool function earlier
to save energy.
The SuperFreeze function is still switched on.
You can switch off the SuperFreeze function earlier
to save energy.
The compressor comes
on less and less often
and for shorter periods
of time. The temperat-
ure in the refrigeration
appliance rises.
This is not a fault. The temperature setting is too
high.
Correct the temperature setting.
Check the temperature again after 24hours.
The frozen food begins to defrost.
The ambient temperature is too low for this refrigera-
tion appliance.
If the ambient temperature is too low, the com-
pressor will run less frequently. This may cause the
freezer section to become too warm.
See the information in “Installation – Installation
site”.
Increase the ambient temperature.
The door seal is dam-
aged or needs to be re-
placed.
No tools are required to change the door seal.
Change the door seal. A replacement is available
from Miele or from specialist retailers.
Problem solving guide
71
Problem Cause and remedy
Ice or condensation has
built up inside the refri-
geration appliance. The
appliance door may not
close correctly.
The door seal has come out of its groove.
Check that the door seal is correctly positioned in
the groove.
The door seal is damaged.
Check whether the door seal is damaged.
Problem solving guide
72
Display warnings
Message Cause and remedy
lights up on the dis-
play, the appliance does
not get cold even
though the controls and
the interior lighting are
working.
Demo mode is switched on.
Switch Demo mode off (see “Selecting further set-
tings – Switching Demo mode off”).
Nothing is visible on the
display. The display is
completely blank.
Energy-saving mode is switched on. If the appli-
ance has not been operated for a while (approx.
10minutes), the display is switched off.
Touch the display.
The display shows the most recent indication.
Sabbath mode is switched on. The interior lighting is
switched off and the appliance is cooling down.
Touch the display.
will then light up white in the display (see “Select-
ing further settings – Switching Sabbath mode on/
off”).
is lit up in the display
and the appliance can-
not be used.
The safety lock has been activated.
Deactivate the safety lock temporarily or switch it
off completely (see “Selecting further settings -
Activating or deactivating the safety lock”).
lights up in the refri-
gerator section temper-
ature display and an
audible tone sounds.
The Replace charcoal filter reminder setting has
been activated. This is the reminder to change the
Active AirClean charcoal filters.
Confirm that the filters have been replaced by
touching in the display, and replace the char-
coal filters in the holder (see (“Cleaning and care” -
“Replacing the charcoal filters”).
lights up in the dis-
play and an audible
tone also sounds.
The Clean ventilation grille reminder setting has
been activated. This is the prompt to clean the ventil-
ation grille.
Confirm the message by touching in the display
and clean the ventilation grille (see “Cleaning and
care - Cleaning the ventilation grille”).
Problem solving guide
73
Message Cause and remedy
lights up yellow
in the temperat-
ure display for
the refrigerator
section and/or
the freezer sec-
tion and an alarm
also sounds.
The door alarm has been activated.
Touch and hold
for a few seconds.
The alarm will stop and the
symbol will go out.
Close the relevant appliance door.
Problem solving guide
74
Message Cause and remedy
lights up red in
the freezer sec-
tion temperature
display and an
alarm also
sounds.
The temperature alarm has been activated; the tem-
perature in the freezer section has risen higher or
fallen lower than the temperature set.
Possible reasons for this include:
– The appliance door has been opened too fre-
quently.
– A large quantity of fresh food has been placed
in the freezer without switching on the Super-
Freeze function.
– A prolonged power cut (mains outage) has oc-
curred.
– The refrigeration appliance has a fault.
Tap
.
The alarm message is confirmed:
goes out and
the alarm stops.
The warmest temperature recorded in the freezer
section will flash for about 1minute in the display.
Then the temperature display will change to the cur-
rent temperature in the freezer section.
You can exit from the flashing temperature display
early:
Touch the temperature display for the freezer sec-
tion.
The warmest temperature displayed will disappear.
The display will then revert to showing the current
temperature in the freezer.
Rectify the cause of the alarm.
Depending on the temperature displayed, you
should check whether food in the freezer has star-
ted to thaw or has defrosted. If it has, it should be
used as soon as possible. Defrosted food may
only be re-frozen after it has been cooked.
Problem solving guide
75
Message Cause and remedy
lights up red in
the display and
an alarm also
sounds.
Indication of an interruption to the power supply: the
temperature in the freezer section over the last few
days or hours has risen too high because of a power
cut or interruption to the power supply.
Tap
.
The fault message is confirmed:
goes out and the alarm will stop.
The warmest temperature recorded in the freezer
section will flash for about 1minute in the temperat-
ure display for the freezer section. Then the temper-
ature display will change to the current temperature
in the freezer section.
You can exit from the flashing temperature display
early:
Touch the temperature display for the freezer sec-
tion.
The warmest temperature displayed will disappear.
The display will then revert to showing the current
temperature in the freezer. The appliance will go back
to the last temperature setting when the power is
back on.
Rectify the cause of the alarm.
Depending on the temperature displayed, you
should check whether food in the freezer has star-
ted to thaw or has defrosted. If it has, it should be
used as soon as possible. Defrosted food may
only be re-frozen after it has been cooked.
Problem solving guide
76
Message Cause and remedy
lights up red in
the display and a
fault code F with
numbers may ap-
pear. An alarm
will also sound.
There is a fault.
Tap on the display to switch the alarm off.
Call the Miele Customer Service Department.
To report the fault, you need the fault code and also
the model number and serial number of your refriger-
ation appliance. You can access this information on
the display.
To do this, touch on the display.
The appliance data required will be shown on the
display.
Confirm with OK to exit the information display and
the fault code will be shown again on the display.
The refrigeration appliance can be switched off dir-
ectly from the fault message display.
There is an appliance fault: this display always has
priority over any settings which have just been selec-
ted.
An appliance fault has priority over any current door
and/or temperature alarms displayed.
Problem solving guide
77
The interior lighting is not working.
Problem Cause and remedy
The interior lighting is
not working.
The refrigeration appliance has not been switched
on.
Switch the refrigeration appliance on.
Sabbath mode is switched on: the display is dark
and the refrigeration appliance is cooling.
Touch the display.
will then light up white in the display (see “Select-
ing further settings – Sabbath mode”).
To avoid overheating, the lighting switches itself off
automatically after approx. 15minutes if the appli-
ance door is left open. If this is not the case, then
there is a fault.
Risk of electric shock due to exposed, live
electrical components.
When removing the lighting cover, there is a risk of
coming into contact with live electrical compon-
ents.
Do not remove the lighting cover. The LED lighting
may only be repaired or replaced by the Miele
Customer Service Department.
Danger of injury from LED lighting.
This lighting corresponds to risk group RG2. If the
cover is defective, there is a danger of eye injury.
If the lighting cover is defective, do not look from a
close range directly into the lighting with optical in-
struments (e.g. magnifying glass or similar).
Call the Miele Customer Service Department.
Problem solving guide
78
Other problems
Problem Cause and remedy
Food has frozen to-
gether.
The food packaging was not dry when placed in the
freezer.
Use a blunt instrument, e.g. a spoon handle or
plastic scraper, to prise it apart carefully.
The external walls of
the appliance feel
warm.
This is not a fault. The heat created by the evapor-
ator is used to prevent condensation.
There is no audible
alarm even though the
door has been open for
a long time.
Not a fault! The alarm has been switched off in Set-
tings mode (see “Selecting further settings – Setting
the volume/Switching alarms and audible tones
on/off”).
Noises
79
Normal
noises
What causes them
Brrrrr ... A humming noise is made by the motor (compressor). This noise
can get louder for brief periods when the motor switches on.
Blubb,
blubb ...
A gurgling noise can be heard when coolant is circulating
through the pipes.
Click ... Clicking sounds are made when the thermostat switches the
motor on and off.
Sssrrrrr ... You can sometimes just hear the sound of the fan inside the ap-
pliance.
Crack ... A cracking sound can be heard when materials expand inside
the appliance.
Remember that the noise of the compressor and the coolant circulating in the
system is unavoidable.
Noises Cause and remedy
Rattling, vi-
brating
The refrigeration appliance is uneven. Realign the appliance us-
ing a spirit level by raising or lowering the adjustable feet under-
neath the refrigeration appliance.
The refrigeration appliance is touching another appliance or
piece of furniture. Move it away.
Drawers, baskets or shelves are jiggling or are stuck. Check all
removable items and refit them correctly.
Bottles or containers are touching. Separate them.
Service
80
Contact in the event of a fault
In the event of any faults which you
cannot remedy yourself, please contact
your Miele dealer or the Miele Customer
Service Department.
You can book a Miele Customer Ser-
vice Department call-out online at
www.miele.com/service.
Contact information for the Miele Cus-
tomer Service Department can be
found at the end of this document.
Please quote the model identifier and
serial number of your appliance (Fabr./
SN/Nr.) when contacting the Miele Cus-
tomer Service Department. This inform-
ation can be found on the data plate.
Please note that telephone calls may be
monitored and recorded for training
purposes and that a call-out charge will
be applied to service visits where the
problem could have been resolved as
described in this booklet.
The data plate can be found inside the
appliance.
Displaying appliance informa-
tion
This can be found in Settings mode un-
der Information (see “Selecting further
settings”) or on the data plate inside the
refrigeration appliance.
–Displaying licence agreements
Licences used can be displayed via ©.
EPREL database
From 1 March 2021, information on en-
ergy labelling and ecodesign require-
ments will be available in the European
Product Database (EPREL). You can
find the product database at the follow-
ing link https://eprel.ec.europa.eu/. You
will be asked to enter the model identi-
fier.
The model identifier can be found on
the data plate.
SN-ST
R600a:
XXXXXX
Nr. XX/ XXXXXXXXX.
XXX l
XXg
Warranty
The appliance warranty is valid for 2
years from date of purchase. In the UK,
you must activate your cover by calling
0330 160 6640 or registering online at
www.miele.co.uk.
For more information on country-spe-
cific warranty terms and conditions,
please contact Miele Customer Service.
Installation
*INSTALLATION*
81
Installation
Fire risk and risk of damage from
appliances which give off heat.
Appliances which give off heat can
catch fire and set fire to the refrigera-
tion appliance.
Do not place appliances which give
off heat, such as mini-ovens, double
burner hobs or toasters on the refri-
geration appliance.
Fire risk and danger of damage
from open flames.
Open flames can set fire to the refri-
geration appliance.
Keep open flames (e.g. a candle)
away from the refrigeration appli-
ance.
Side-by-side installation
Risk of damage due to condens-
ation on external appliance panels.
In environments with high humidity,
condensation can build up on ex-
ternal appliance panels, which can
cause corrosion.
Do not place different refrigeration
appliance models directly next to or
on top of one other.
Your refrigeration appliance must not be
installed “side-by-side” because it is
not equipped with built-in heating units
in the side panels.
If you want to place several refrigeration
appliances next to each other, a dis-
tance of 100mm must be maintained
between them.
Please contact your dealer for specific
information about which combinations
will work with your appliance.
Installation
*INSTALLATION*
82
Location
This appliance should be installed in a
dry, well-ventilated room.
When deciding where to install your re-
frigeration appliance please bear in
mind that it will use more energy if in-
stalled near to a heater, a cooker or
other appliance that gives off heat. Dir-
ect sunlight should also be avoided.
The higher the room temperature, the
longer the compressor runs and the
higher the energy consumption is.
When installing the appliance, please
note:
- The socket must be easily accessible
in an emergency, not concealed be-
hind the appliance.
- The plug and cable must not touch
the rear of the appliance as they
could be damaged by vibrations from
the appliance.
- Do not plug in other appliances be-
hind this appliance.
Risk of damage due to corrosion.
In environments with high humidity,
condensation can build up on ex-
ternal refrigeration appliance panels.
This condensate can cause corrosion
on external appliance panels.
Install the refrigeration appliance in a
dry and/or air-conditioned room with
sufficient ventilation.
After installation, make sure that the
appliance doors close properly, the
ventilation gaps are not covered and
that the refrigeration appliance has
been installed in accordance with
these installation instructions.
Climate range
This refrigeration appliance is designed
for use within specific ambient temper-
atures (climate range). Do not use in
ambient temperatures for which it is not
designed. The climate range is stated
on the data plate in the interior cabinet
of the refrigeration appliance.
Climate range Ambient temper-
ature
SN +10to +32°C
N +16to +32°C
ST +16to +38°C
T +16to +43°C
A lower ambient temperature leads to
the compressor switching off for longer
periods. This can cause the internal
temperature in the refrigeration appli-
ance to rise with the risk of food deteri-
orating and going off.
Installation
*INSTALLATION*
83
Ventilation
Risk of fire and damage due to
insufficient ventilation.
If the refrigeration appliance is not
ventilated sufficiently, the com-
pressor will run more frequently and
for longer periods. This will result in
increased energy consumption and a
higher operating temperature for the
compressor. This may, in turn, cause
damage to the compressor.
Please ensure that there is adequate
ventilation around the refrigeration
appliance.
It is essential to observe the required
ventilation gaps.
The ventilation gaps must not be
covered or blocked in any way.
They must also be regularly dusted.
Air at the back of the refrigeration appli-
ance gets warm.
Fitting supplied wall spacers
The wall spacers supplied must be
used in order to achieve declared en-
ergy consumption values and to pre-
vent the build-up of condensation at
high ambient temperatures. The appli-
ance depth is increased by approx.
15mm with the wall spacers fitted. If
the wall spacers are not used, the
functionality of the appliance is not af-
fected. Energy consumption is only
slightly increased with less distance
between the appliance and the wall.
Fit the wall spacers onto the back of
the refrigeration appliance on the bot-
tom left and right.
Installation
*INSTALLATION*
84
Installing the refrigeration appliance
Danger of injury and damage
due to the refrigeration appliance tip-
ping over.
There is an increased danger of in-
jury and damage if the refrigeration
appliance is installed by a single per-
son.
Two people are required for installing
the refrigeration appliance.
Risk of damaging the floor.
Moving the refrigeration appliance
can cause damage to the floor.
Move the refrigeration appliance
carefully on floors that are sensitive
to scratching.
For easier installation, there are trans-
port handles on the back at the top
and transport wheels underneath the
refrigeration appliance.
Tip: The refrigeration appliance must be
empty when it is installed.
Prepare the refrigeration appliance for
installation as close as possible to its
intended installation site.
Connect the refrigeration appliance to
the electricity supply as described in
“Electrical connection”.
Move the refrigeration appliance
carefully to its intended installation
site.
Position the refrigeration appliance
with the wall spacers (if used) or the
back close to the wall.
Risk of damage to the appliance
door.
The appliance doors could hit the
wall of the room resulting in damage
to the doors.
Protect the glass doors by fitting a
felt stopper, for example, to the wall
of the room.
Installation
*INSTALLATION*
85
Aligning the appliance
To align the appliance, adjust the
front feet using the spanner supplied
Levelling the appliance door
Risk of damage and injury
caused by the appliance door falling
out or the refrigeration appliance tip-
ping over.
If the additional adjustable foot on
the hinge plate at the bottom is not
resting firmly on the floor, the appli-
ance door can fall out or the refriger-
ation appliance can tip over.
Use the open spanner supplied with
the appliance to unscrew the ad-
justable foot until it is resting on the
floor.
Then unscrew the adjustable foot by
a further quarter turn.
Installing the refrigeration appliance
in a run of kitchen units
Risk of fire and damage due to
insufficient ventilation.
If the refrigeration appliance is not
ventilated sufficiently, the com-
pressor will run more frequently and
for longer periods. This will result in
increased energy consumption and a
higher operating temperature for the
compressor. This may, in turn, cause
damage to the compressor.
Please ensure that there is adequate
ventilation around the refrigeration
appliance.
It is essential to observe the required
ventilation gaps. The ventilation gaps
must not be covered or blocked in
any way.
Top box
Refrigeration appliance
Housing unit
Wall
Installation
*INSTALLATION*
86
* The appliance depth is increased by
approx. 15mm for refrigeration appli-
ances with wall spacers fitted.
The refrigeration appliance can be built
into any run of kitchen units and in-
stalled directly next to a kitchen fur-
niture housing unit. The appliance front
must protrude in front of furniture fronts
by at least 65mm. This enables the ap-
pliance door to be opened and shut
without being obstructed. To match the
height of the rest of the kitchen units,
the refrigeration appliance can be fitted
with a suitable top box.
When installed next to a wall, a dis-
tance of at least 40mm must be main-
tained on the hinge side between the
wall and the refrigeration appli-
ance.
The larger the ventilation gap, the
more economically the compressor
will work.
- A ventilation gap of at least 50mm
depth must be provided at the back
of the refrigeration appliance behind
the whole width of the top box for air
to circulate.
- The ventilation gap under the ceiling
must be at least 300cm
2
to ensure
that warm air can escape without ob-
struction.
Installation
*INSTALLATION*
87
Appliance dimensions
* Dimensions without wall spacers. Appliance depth is increased by 15mm with the wall
spacers supplied fitted.
A
[mm]
B
[mm]
KFN 29233 D bb 1177 787
Installation
*INSTALLATION*
88
Changing the door hinging
The refrigeration appliance is supplied
with hinges on the right. If left-hand
hinging is required, the hinges must be
changed.
Always change the door hinging
with the assistance of another per-
son.
If the door seal is damaged or has
slipped out of its groove, the door
will not close properly and cooling
performance will be reduced. Con-
densate will build up in the interior
and this can cause a build-up of ice.
Do not damage the door seal and
ensure it does not slip out of its
groove.
Preparing to change the door hinging
To change the door hinging, you will
need the following tools:
Place a suitable cover on the floor in
front of the appliance to protect the
appliance doors and your floor from
damage.
Remove the shelves/bottle shelf from
the appliance door.
Installation
*INSTALLATION*
89
Removing the top covers
Open the appliance door.
Push off right outer cover.
Remove cover from the door
hinge.
Remove panel on the inside of the
door.
Use a flat-head screwdriver to push
the tab down and pull the cover
out of the coupling.
Removing the upper door
Danger of injury when removing
the upper door.
The upper door is not secure as
soon as the pin has been removed
from the door hinge.
The door must be held by a second
person.
Carefully lift off safety cover.
Installation
*INSTALLATION*
90
Loosen pin slightly (ap-
prox.¼turn) until it clicks.
Now use your fingers to pull pin
right out.
Danger of injury when removing
the upper door.
As soon as the hinge pin is located in
the upper door rather than in the
middle hinge plate, the lower door is
not secured and could fall off.
Ensure that the hinge pin remains
located in the middle hinge plate and
in the lower door.
Lift the upper door off and place it
carefully to one side.
Removing the lower door
Danger of injury when removing
the lower door.
As soon as the hinge pin is removed
from the lower door in the following
instructions, the door is no longer
secured.
The door must be held by a second
person.
Open the lower door.
Remove hinge pin from the bear-
ing bush in lower door.
Tip: Please note that the grey plastic
cover on the middle hinge plate can
fall off when the door is being removed.
Lift lower door off and place it
carefully to one side.
Installation
*INSTALLATION*
91
Changing the lower hinge plate over
Pull hinge pin complete with
washer and adjusting foot upwards to
remove.
Unscrew hinge plate.
Slightly loosen screw of door clos-
ing aid on hinge plate.
Turn door closing aid 90° clock-
wise to the opposite locating hole in
hinge plate.
Then tighten screw up again.
Remove cover and refit on the op-
posite side.
Secure hinge plate on the opposite
side, starting with screw in the
middle at the bottom.
Then screw in the other two
screws.
Insert hinge pin complete with
washer and adjusting foot.
Important. The lug on the hinge pin
must be pointing backwards again.
Installation
*INSTALLATION*
92
Changing the middle hinge plate over
Pull off cover.
Unscrew hinge plate with the pro-
tective film underneath.
Turn hinge plate through 180° and
screw it with the protective film into
position on the opposite side.
The protective film protects the appli-
ance housing from damage.
Turn grey plastic cover through
180° and refit it in hinge plate.
Tip: Plastic cover fits over the pro-
truding bearing bush so that this is
covered from underneath and from the
side.
Turn cover through 180° and refit it
on the opposite side.
Changing the door hinge over
Undo and remove screw on door
hinge.
Pull bearing bush out of the guide
on door hinge and refit it on the
opposite side.
Installation
*INSTALLATION*
93
Push cover off to the side.
Turn cover through 180° and refit it
on the opposite side. Push on the
cover from the side and click it into
position.
Fit upper door hinge onto the pins
on the appliance.
Secure door hinge with screws .
Preparing the doors
Tip: Spread a suitable cover over a
stable surface to protect the appliance
door from damage. Place the door on it
with the outside facing down.
Carry out the following steps on both
doors.
Changing the door opening aid over
Remove cover from the opening
for the recessed handle.
Press the door opening aid down,
and remove the covers from the
right and left hand side of the handle
recess.
Installation
*INSTALLATION*
94
Fully unscrew the screw with the grey
plastic collar and the screw
without the collar.
Pull door opening slider upwards
and off. You may need to use a little
force.
Tip: Press the door opening aid down-
wards. The slider can then be pulled out
more easily.
Now remove door opening aid.
Refit opening aid on the opposite
side.
Ensure when inserting door opening
slider, that the plastic on the slider
is not up against the door seal.
This would damage the door seal.
The flush side of door opening
slider must point towards the door
seal.
Installation
*INSTALLATION*
95
Push door opening slider through
the slot until it clicks into position.
Secure the door opening aid using
the screw with the plastic collar
and the screw without a plastic col-
lar. Do not tighten the screws.
Tip: Check whether the opening aid
moves easily by pressing it. If it does
not, you will need to loosen the screws
slightly.
Fit covers and.
Changing over the bearing bush
stopper
Pull the stopper out of door bearing
bush and replace it on the oppos-
ite side.
Lower freezer section door: changing
over the spring clip
Replace spring clip (keeper) on the
opposite side:
Press the lug downwards and push
spring clip to the side out of the
guide.
Installation
*INSTALLATION*
96
Push spring clip into the guide on
the opposite side until it clicks into
place.
Upper refrigerator section door: fit-
ting the bearing bush supplied and
changing over the spring clip
Fit the bearing bush (supplied with
the appliance) in the opening on the
lower edge of the appliance door.
Make sure that it clicks into place.
Replace spring clip (keeper) on the
opposite side:
Press the lug downwards and push
spring clip to the side out of the
guide.
Push spring clip into the guide on
the opposite side until it clicks into
place.
Remove the bearing bush from the
opposite side.
Tip: Keep the bearing bush in case you
want to change over the door hinging
again at a later date.
Installation
*INSTALLATION*
97
Refitting the lower door
Place door onto hinge pin from
above.
Close appliance door.
Insert middle hinge pin through
middle hinge plate into the bearing
bush.
Important. The lug on the hinge pin
must point backwards again and must
be guided into the groove on the hinge
plate.
Refitting the upper door
Place upper door onto middle
hinge pin and guide the upper
opening of the door on the hinge side
on to the door hinge.
Use your fingers to insert bolt into
the door bearing bush.
Screw in bolt (by approx. ¼turn)
until it clicks into position.
Fit safety cover on to bolt.
The appliance door is not secure
until safety cover has been cor-
rectly fitted.
Installation
*INSTALLATION*
98
Fitting the upper covers
Push on cover until it clicks into
position.
Fit cover on the door hinge.
Push panel on from the side until it
clicks into position.
1
Push on outer cover.
Close the upper door.
Aligning the appliance doors
The appliance doors can be aligned
with the appliance housing after they
have been fitted.
In the following illustration, the appli-
ance door is not shown in the closed
position to make it easier to see what
you have to do.
To align the lower door use the long
outer slots in the lower hinge plate:
Remove the middle screw from the
hinge plate.
Slightly loosen both outer screws.
Align the door by sliding the hinge
plate to the left or right.
Then tighten screws again. The
screw does not need to be refitted.
Installation
*INSTALLATION*
99
Align the upper door using the long
outer slots in the middle hinge plate:
Slightly loosen both screws.
Align the door by sliding the hinge
plate to the left or right.
Then tighten screws.
Electrical connection
The refrigeration appliance must only be
connected to an earthed socket using
the connection cable supplied.
Appliance plug connector
Mains plug
A longer connection cable is available
to order from the Miele Customer Ser-
vice Department.
The socket must be easily accessible
after the refrigeration appliance has
been installed. If the socket is not easily
accessible, ensure that a suitable
means of disconnection is provided on
the installation side for each pole.
Risk of fire from overheating.
Connecting the refrigeration appli-
ance to a multi-socket plug adapter
or to an extension lead can overload
the cable.
For safety reasons, do not use an ex-
tension lead or multi-socket adapter.
The electrical installation must comply
with VDE0100 requirements.
For safety reasons, we recommend us-
ing a type A residual current device
(RCD) in the assigned electrical installa-
tion for connecting the refrigeration ap-
pliance.
Installation
*INSTALLATION*
100
If the mains connection cable is dam-
aged, it must only be replaced with a
specific mains connection cable of the
same type (available from the Miele
Customer Service Department). For
safety reasons, such replacement may
only be carried out by a qualified spe-
cialist or the Miele Customer Service
Department.
These operating instructions and the
data plate indicate the nominal power
consumption and the appropriate fuse
rating. Compare this information with
the data of the on-site electrical con-
nection.
If in any doubt, consult a qualified elec-
trician.
Do not connect the refrigeration appli-
ance to a stand-alone inverter such as
those used with an autonomous energy
source, e.g. solar power. When the refri-
geration appliance is switched on,
power surges could result in an auto
switch-off. This could damage the elec-
tronic module.
Connecting the appliance
Insert the plug connector into the
socket at the back of the refrigeration
appliance.
Make sure that the plug connector has
clicked into position correctly.
Insert the mains plug into the mains
socket and switch on.
The appliance is now connected to the
electricity supply:
will appear on the display.
Follow the steps described in “Switch-
ing on and off – Switching on”.
United Kingdom
Miele Co. Ltd., Fairacres, Marcham Road, Abingdon, Oxon, OX14 1TW
Tel: 0330 160 6600, Internet: www.miele.co.uk/service, E-mail: [email protected]
Australia
Miele Australia Pty. Ltd.
ACN 005 635 398
ABN 96 005 635 398
1 Gilbert Park Drive
Knoxfield, VIC 3180
Tel: 1300 464 353
Internet: www.miele.com.au
Miele Electrical Appliances Co., Ltd.
1-3 Floor, No. 82 Shi Men Yi Road
Jing' an District
200040 Shanghai, PRC
Tel: +86 21 6157 3500
Fax: +86 21 6157 3511
E-mail: [email protected],
Internet: www.miele.cn
China Mainland
Miele (Hong Kong) Ltd.
41/F - 4101, Manhattan Place
23 Wang Tai Road
Kowloon Bay, Hong Kong
Tel: (852) 2610 1025
Fax: (852) 3579 1404
Email:
Website: www.miele.hk
Hong Kong, China
Miele India Pvt. Ltd.
1st Floor, Copia Corporate Suites,
Commercial Plot 9,
Mathura Road, Jasola,
New Delhi - 110025
E-mail: customercare@miele.in
Website: www.miele.in
India
Miele Ireland Ltd.
2024 Bianconi Avenue
Citywest Business Campus
Dublin 24
Tel: (01) 461 07 10
Fax: (01) 461 07 97
E-Mail: [email protected]
Internet: www.miele.ie
Ireland
Malaysia
Miele Sdn Bhd
Suite 12-2, Level 12
Menara Sapura Kencana
Petroleum
Solaris Dutamas No. 1
Jalan Dutamas 1
50480 Kuala Lumpur, Malaysia
Phone: +603-6209-0288
Fax: +603-6205-3768
Miele New Zealand Limited
IRD 98 463 631
8 College Hill
Freemans Bay, Auckland 1011
New Zealand
Tel: 0800 464 353
Internet: www.miele.co.nz
New Zealand
Miele Pte. Ltd.
29 Media Circle
#11-04 ALICE@Mediapolis
Singapore 138565
sTel: +65 6735 1191
Fax: +65 6735 1161
E-Mail: [email protected]
Internet: www.miele.sg
Singapore
Miele (Pty) Ltd.
63 Peter Place
Bryanston 2194
P.O. Box 69434
Bryanston 2021
Tel: (011) 875 9000
Fax: (011) 875 9035
E-mail: [email protected]
Internet: www.miele.co.za
South Africa
Miele Appliances Ltd.
Showroom 1
Eiffel 1 Building
P.O. Box 114782 - Dubai
Tel. +971 4 3044 999
Fax. +971 4 3418 852
800-MIELE (64353)
E-Mail: [email protected]
Website: www.miele.ae
United Arab Emirates
Manufacturer:
Miele & Cie. KG, Carl-Miele-Straße 29, 33332 Gütersloh, Germany
Thailand
Miele Appliances Ltd.
BHIRAJ TOWER at EmQuartier
43rd Floor Unit 4301-4303
689 Sukhumvit Road
North Klongton Sub-District
Vadhana District
Bangkok 10110, Thailand
Sheikh Zayed Road, Umm Al Sheif
M.-Nr. 10 360 950 / 03en - GB, IE, ZA
KFN 29233 D bb
