9443 • 092221
If a problem cannot be remedied or you are experiencing diculty in installation,
please contact the Service Department: 1-877-459-3267, 8 a.m. - 5 p.m. Central Time.
HARLEE 2-LIGHT
SEMI-FLUSHMOUNT
Owner’s Manual
Model #20719
SKU # 351-8400
®
US
Hardware
Kit
Owner’s
Manual
3
1
2
8 9
10
11
12
5
6
4
7
PACKAGE CONTENTS
2
1. Canopy
2. Decorative Hook (x3)
3. Fixture
4. Chain (x3)
5. Glass Assembly
6. Owner’s Manual
7. Hardware Kit
8. Wire connector (x3)
9. Outlet Box Screw (x2)
10. Mounting Bracket
11. Mounting Screw (x2)
12. Screw Cap (x2)
Unpack your xture and check the contents. You should
have the following items:
Note: Some of the hardware listed is pre-assembled to
other parts. You will be instructed where to locate it.
PACKAGE CONTENTS
HARDWARE LIST
HARDWARE CONTENTS
TOOLS REQUIRED (not included)
Tools required for assembly: Electrical tape, Phillips Screwdriver, Pliers, Safety Glasses, Step Ladder, Wire Cutters
and Wire Strippers
Helpful Tools: AC Tester Light, Tape Measure, and Wiring Handbook
WARNING
READ ALL SAFETY INFORMATION AND INSTALLATION INSTRUCTIONS BEFORE BEGINNING TO INSTALL THE
LIGHT FIXTURE AND SAVE INSTRUCTIONS.
This xture is intended for indoor use only. Not suitable for damp or outdoor locations.
The net weight of the light xture is approximately: 5.5 lb.
To avoid risk of electric shock, be sure to shut o power at the main fuse or circuit breaker box before
installing or servicing this xture. Turning o the electrical power by using the light switch is not
sucient to prevent electrical shock.
Installation must comply with the national electrical code, ANSI/NFPA 70-1999 and local codes. If you
are unfamiliar with the methods of installing electrical wiring, seek the services of a qualied licensed
electrician.
To avoid personal injury, the use of gloves or protective clothing may be necessary when handling
xture parts with sharp edges.
To reduce the risk of re, electrical shock or personal injury, do not connect this xture to a outlet box
that is not properly grounded.
To reduce the risk of re, electrical shock, or personal injury, each wire connector used with this light
xture should accept only one 18-gauge wire from the light xture and one 18-gauge wire from the
outlet box.
Ensure the light xture is mounted to an outlet box with a ground wire and is secured to the building
structure.
Wire colors from outlet box may not be the same color used in this manual. When in doubt, consult a
qualied licensed electrician to determine the proper wiring.
SAFETY INSTRUCTIONS
3
4
ASSEMBLY INSTRUCTIONS
1
3. Attach the mounting bracket to the outlet box (not
included) using the two outlet box screws from the
hardware bag.
2. Remove the screw caps from the mounting screws and
save for later use.
4. Loosen the ground screw preassembled to the
mounting bracket. Wrap the Green/Bare (ground) supply
wire around the shaft of the ground screw. Re-tighten the
ground screw.
Green/Bare (ground)
3
2
4
Outlet Box
Screw
Screw Cap
Mounting
Screw
1. Turn OFF the electrical power at the main fuse or circuit
breaker.
DANGER: Failure to disconnect the power supply prior to
installation may result in serious injury or death.
ASSEMBLY INSTRUCTIONS
5
7. Reinstall the previously removed screw caps onto the
mounting screws to secure the xture to the mounting
bracket.
6. Lift the holes in the canopy over the mounting screws.
Note: The hex nuts preassembled to the mounting
bracket screws can be adjusted if the xture does not t
ush to the ceiling.
8. Use the three clipping links at the end of each chain to
attach the three chains to the glass assembly.
Mounting
Screw
Clipping
Link
Glass
Assembly
Screw Cap
7
Mounting
Screw
Canopy
Hex Nut
Hole
8
6
Bare/Green
(ground)
Bare
White
White (neutral)
Black
Black (hot)
5
5. Connect supply and xture wires according to the
diagram and these steps:
• Connect the Bare wire from the xture to the Bare/Green
(ground) supply wire.
• Connect the White wire from the xture to the White
(neutral) supply wire.
• Connect the Black wire from the xture to the Black (hot)
supply wire.
Secure all wiring connections together with wire
connectors from hardware bag.
Note: If supply wire colors dier from these, contact a
professional electrician to determine proper wiring.
6
ASSEMBLY INSTRUCTIONS
11
11. Restore the power at the fuse box and the wall
switch.
Assembly is complete.
10
Bulb
(sold separately)
10. Install two 60 watt max. E26-base bulbs (sold
separately). Note: It is not necessary to use Edison-shaped
bulbs (shown).
Decorative Hook
9
9. Attach the ends of the three chains to the decorative
hooks on the top of the xture.
7
If you have diculty operating your new light xture, or have diculty with installation, please contact Customer
Service : 1-877-459-3267, 8 a.m. - 5 p.m. Central Time.
WARNING: Ensure the power is turned o to the light xture before performing any maintenance.
PROBLEM SUGGESTED REMEDY
Fixture does not light up. 1. Turn on wall switch, and check fuses or circuit breakers.
2. Check wire connections from outlet box to light xture, located in the canopy.
3. Install a new bulb.
TROUBLESHOOTING
TROUBLESHOOTING
5-YEAR LIMITED WARRANTY
To obtain service, please contact the Service Department:
1-877-459-3267, 8 a.m. - 5 p.m. Central Time.
Model Name: 2-Light Semi-Flushmount
Model No: 20719 - Matte Black (SKU: 351-8400)
The manufacturer warrants all of its lighting xtures against defects in materials and workmanship
for ve (5) years from the date of purchase. If within this period the product is found to be defective,
take a copy of the bill of sale as a proof of purchase and the product in its original carton to the place
of purchase. The manufacturer will, at its option, repair, replace or refund the purchase price to the
consumer. All costs of installation and removal of the xture is the responsibility of the consumer. This
warranty does not cover xtures becoming defective due to misuse, accidental damage or improper
handling and/or installation and specically excludes liability for direct, incidental or consequential
damages. As some states do not allow exclusions of limitations on an implied warranty, the above
exclusion and limitation may not apply. This warranty gives you specic rights and you may also have
other rights which may vary from state to state.
