Please read ths user manual frst!
Dear Customer,
We hope that your product, which has been produced in modern plants and checked
under the most meticulous quality control procedures, will provide you an effective
service.
Therefore, read this entire user manual carefully before using the product and keep
it as a reference. If you handover the product to someone else, give the user manual
as well.
The user manual wll help you use the product n a fast and safe way.
•Read the manual before nstallng and operatng the product.
•Make sure you read the safety nstructons.
•Keep the manual n an easly accessble place as you may need t later.
•Read the other documents gven wth the product.
Remember that this user manual is also applicable for several other models.
Differences between models will be identified in the manual.
Explanaton of symbols
Throughout ths user manual the followng symbols are used:
C
Important nformaton or
useful hnts.
A
Rsk of njury and damage to
the property.
B
Rsk of electrc shock.
Packagng materals of
the product are manufac-
tured from recyclable ma-
terals n accordance wth
our Natonal Envronment
Regulatons.
2 /37 EN
Refrgerator / User Manual
1 Safety and environment
instructions 3
1.1. General safety . . . . . . . . . . . . . . . . . . . 3
1.1.1 HC warning . . . . . . . . . . . . . . . . . . . . . . 5
1.1.2 For models with water dispenser 5
1.2. Intended use. . . . . . . . . . . . . . . . . . . . . 6
1.3. Child safety . . . . . . . . . . . . . . . . . . . . . . 6
1.4. Compliance with WEEE Directive and
Disposing of the Waste Product. 7
1.5. Compliance with RoHS Directive 7
1.6. Package information . . . . . . . . . . . . 7
2 Your appliance 8
3 Installation 9
3.1. Appropriate installation location 9
3.2. Installing the plastic wedges. . . . 9
3.3. Adjusting the feet . . . . . . . . . . . . . .10
3.4. Electrical connection . . . . . . . . . . .10
3.5. Reversing the doors . . . . . . . . . . . . 11
3.6. Reversing the doors . . . . . . . . . . . . 12
4 Preparation 13
4.1. Things to be done for energy
saving. . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.2. Initial use . . . . . . . . . . . . . . . . . . . . . . . 13
5 Operating the product 14
5.1. Temperature setting button . . . 14
5.2. Fast freeze . . . . . . . . . . . . . . . . . . . . . 14
5.3. Vacation function . . . . . . . . . . . . . . 15
5.4. Indicator panel. . . . . . . . . . . . . . . . . .16
5.5. Indicator panel. . . . . . . . . . . . . . . . . .18
5.6. Twist Ice – matic . . . . . . . . . . . . . . . 21
5.7. Ice container . . . . . . . . . . . . . . . . . . . . 21
5.8. Egg holder . . . . . . . . . . . . . . . . . . . . . .22
5.9. Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
5.10 Crisper . . . . . . . . . . . . . . . . . . . . . . . . . .22
5.11. Chiller compartment. . . . . . . . . . . .22
5.12 Moving door shelf . . . . . . . . . . . . . .23
5.13 Sliding storage container . . . . . .23
5.14.Blue light . . . . . . . . . . . . . . . . . . . . . . .23
5.15 Humidity controlled crisper . . . .24
5.16.Auto Icematic . . . . . . . . . . . . . . . . . .24
5.17. Description and cleaning of odour
filter. . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
5.18.Using the water dispenser. . . . .26
5.19.Filling the water dispenser's tank 26
5.20. Cleaning the water tank . . . . . .28
5.21 Drip tray. . . . . . . . . . . . . . . . . . . . . . . . .29
5.22.Freezing fresh food . . . . . . . . . . . .30
5.23. Recommendations for preserving
the frozen food . . . . . . . . . . . . . . . . . 31
5.24.Deep-freeze information . . . . . . 31
5.25.Placing the food. . . . . . . . . . . . . . . . 31
5.26.Door open warning . . . . . . . . . . . .32
5.27.Changing the door opening
direction . . . . . . . . . . . . . . . . . . . . . . . .32
5.28.Illumination lamp. . . . . . . . . . . . . . .32
6 Maintenance and cleaning 33
6.1. Avoiding bad odors . . . . . . . . . . . . .33
6.2. Protecting the plastic surfaces 33
6.3. Door Glasses . . . . . . . . . . . . . . . . . . .33
7 Troubleshooting 35
Contents
3/37 EN
Refrgerator / User Manual
This section provides
the safety instructions
necessary to prevent the
risk of injury and material
damage. Failure to observe
these instructions will
invalidate all types of
product warranty.
1.1. General safety
• Ths product should
not be used by
persons wth physcal,
sensory and mental
dsabltes, wthout
suffcent knowledge
and experence or by
chldren. The devce
can only be used by
such persons under
supervson and
nstructon of a person
responsble for ther
safety. Chldren should
not be allowed to play
wth ths devce.
• In case of malfuncton,
unplug the devce.
• After unpluggng, wat
at least 5 mnutes before
pluggng n agan.
• Unplug the product
when not n use.
• Do not touch the plug
wth wet hands! Do not
pull the cable to plug off,
always hold the plug.
• Wpe the power plug’s tp
wth a dry cloth before
pluggng n.
• Do not plug n the
refrgerator f the socket
s loose.
• Unplug the product
durng nstallaton,
mantenance, cleanng
and repar.
• If the product wll not be
used for a whle, unplug
the product and remove
any food nsde.
• Do not use the product
when the compartment
wth crcut cards located
on the upper back part
of the product (electrcal
card box cover) (1) s
open.
1
1 Safety and envronment nstructons
Instructons for safety and envronment
4 / 37 EN
Refrgerator / User Manual
1
• Do not use steam or
steamed cleanng
materals for cleanng
the refrgerator and
meltng the ce nsde.
Steam may contact the
electrfed areas and
cause short crcut or
electrc shock!
• Do not wash the
product by sprayng
or pourng water on
t! Danger of electrc
shock!
• In case of malfuncton,
do not use the product,
as t may cause electrc
shock. Contact the
authorzed servce
before dong anythng.
• Plug the product nto
an earthed socket.
Earthng must be
done by a qualfed
electrcan.
• If the product has LED
type lghtng, contact
the authorzed servce
for replacng or n case
of any problem.
• Do not touch frozen
food wth wet hands!
It may adhere to your
hands!
• Do not place lquds
n bottles and cans
nto the freezer
compartment. They
may burst out!
• Place lquds n uprght
poston after tghtly
closng the ld.
• Do not spray
flammable substances
near the product, as t
may burn or explode.
• Do not keep flammable
materals and products
wth flammable gas
(sprays, etc.) n the
refrgerator.
• Do not place contaners
holdng lquds on
top of the product.
Splashng water on an
electrfed part may
cause electrc shock
and rsk of fre.
Instructons for safety and envronment
5/37EN
Refrgerator / User Manual
• Exposng the product
to ran, snow, sunlght
and wnd wll cause
electrcal danger. When
relocatng the product,
do not pull by holdng
the door handle. The
handle may come off.
• Take care to avod
trappng any part of
your hands or body
n any of the movng
parts nsde the
product.
• Do not step or lean on
the door, drawers and
smlar parts of the
refrgerator. Ths wll
cause the product to
fall down and cause
damage to the parts.
• Take care not to trap
the power cable.
1.1.1 HC warning
If the product comprses
a coolng system usng
R600a gas, take care
to avod damagng the
coolng system and ts
ppe whle usng and
movng the product.
Ths gas s flammable.
If the coolng system
s damaged, keep the
product away from
sources of fre and
ventlate the room
mmedately.
C
The label on the
nner left sde
ndcates the type
of gas used n the
product.
1.1.2 For models
with water
dispenser
• Pressure for cold water
nlet shall be maxmum
120 ps (8 bar). If
your water pressure
exceeds 80 ps (5.5
bar), use a pressure
lmtng valve n your
mans system. If you do
not know how to check
Instructons for safety and envronment
6 / 37 EN
Refrgerator / User Manual
your water pressure,
ask for the help of a
professonal plumber.
• If there s rsk of water
hammer effect n your
nstallaton, always
use a water hammer
preventon equpment
n your nstallaton.
Consult Professonal
plumbers s you are not
sure that there s no
water hammer effect n
your nstallaton.
• Do not nstall on the
hot water nlet. Take
precautons aganst
of the rsk of freezng
of the hoses. Water
temperature operatng
nterval shall be 33°F
(0.6°C) mnmum and
100°F (38°C) maxmum.
• Use drnkng water only.
1.2. Intended use
• Ths product s desgned
for home use. It s not
ntended for commercal
use.
• The product should be
used to store food and
beverages only.
• Do not keep
senstve products
requrng controlled
temperatures
(vaccnes, heat
senstve medcaton,
medcal supples, etc.)
n the refrgerator.
• The manufacturer
assumes no
responsblty for any
damage due to msuse
or mshandlng.
• The product’s bench
lfe s 10 years. The
spare parts necessary
for the product to
functon wll be
avalable for ths
perod.
1.3. Child safety
• Keep packagng
materals out of
chldren’s reach.
• Do not allow the
chldren to play wth
the product.
Instructons for safety and envronment
7/37EN
Refrgerator / User Manual
• If the product’s door
comprses a lock,
keep the key out of
chldren’s reach.
1.4. Compliance
with WEEE Directive
and Disposing of
the Waste Product
Ths product comples wth EU
WEEE Drectve (2012/19/EU).
Ths product bears a classfcaton
symbol for waste electrcal and
electronc equpment (WEEE).
Ths product has been
manufactured wth hgh
qualty parts and materals
whch can be reused and
are sutable for recyclng.
Do not dspose of the
waste product wth normal
domestc and other wastes at the
end of ts servce lfe. Take t to the
collecton center for the recyclng of
electrcal and electronc equpment.
Please consult your local authortes
to learn about these collecton
centers.
1.5. Compliance with
RoHS Directive
• Ths product comples wth EU
WEEE Drectve (2011/65/EU).
It does not contan harmful and
prohbted materals specfed n
the Drectve.
1.6. Package
information
• Packagng materals of the product
are manufactured from recyclable
materals n accordance wth our
Natonal Envronment Regulatons.
Do not dspose of the packagng
materals together wth the
domestc or other wastes. Take
them to the packagng materal
collecton ponts desgnated by the
local authortes.
8 /37 EN
Refrgerator / User Manual
1.
Frdge - compartment door shelf
2.
Temperature settng button
3.
Water dspenser fllng tank
4.
Egg secton
5.
Water dspenser reservor
6.
Storage contaner under the door shelf
7.
Movng door shelf
8.
Adjustable feet
9.
Crsper
10.
Chller compartment
11.
Lock and key
12.
Bottle shelf
13.
Frdge - compartment glass shelf
14.
Fan
15.
Freezer compartment shelf
16.
Icebox / Ice-makng compartment
17.
Freezer compartment
18.
Frdge compartment
2 Your applance
C
*optional:Fgures n ths user manual are gven as an example and may not
match the product exactly. If the relevant parts are not avalable n the product you
purchased, the fgure apples to other models.
*1
*3
*5
*4
*6
*2
*7
8
*9
*10
*11
*12
*13
14
14
17
18
*15
*16
*16
8
9/37 EN
Refrgerator / User Manual
3 Installaton
3.1. Appropriate
installation location
Contact an Authorized Service for the
installation of the product. In order to
prepare the product for use, refer the
information in the user manual and
ensure that electrical installation and
water installation are appropriate. If not,
call a qualified electrician and technician
to have any necessary arrangements
carried out.
B
WARNING: Manufacturer shall
not be held lable for damages that
may arse from procedures carred
out by unauthorzed persons.
B
WARNING: Product must not
be plugged n durng nstallaton.
Otherwse, there s the rsk of
death or serous njury!
A
WARNING: If the door clearance
of the room where the product
shall be place s so tght to prevent
passng of the product, remove
the door of the room and pass
the product through the door by
turnng t to ts sde; f ths does
not work, contact the authorzed
servce.
•Placetheproductonanevenfloor
surface to prevent jolts.
•Installtheproductatleast30cm
away from heat sources such as hobs,
heater cores and stoves and at least 5
cm away from electrcal ovens.
•Productmustnotbesubjectedto
drect sun lght and kept n humd
places.
•Appropriateairventilationmustbe
provded around your product n order
to acheve an effcent operaton. If the
product s to be placed n a recess n
the wall, pay attenton to leave at least
5 cm dstance wth the celng and sde
walls.
•Donotinstalltheproductinplaces
where the temperature falls below
-5°C.
3.2. Installing the
plastic wedges
Plastc wedges suppled wth the
product are used to create the dstance
for the ar crculaton between the
product and the rear wall.
1. To nstall the wedges, remove the
screws on the product and use the
screws suppled together wth the
wedges.
2. Insert the 2 plastc wedges onto the
rear ventlaton cover as llustrated n
the fgure.
Installation
10 / 37 EN
Refrgerator / User Manual
3.3. Adjusting the feet
If the product stands unbalanced
after nstallaton, adjust the feet on
the front by rotatng them to the rght
or left.
3.4. Electrical
connection
A
WARNING: Do not make
connectons va extenson
cables or mult-plugs.
B
WARNING: Damaged power
cable must be replaced by the
Authorzed Servce Agent.
C
If two coolers are to be
nstalled sde by sde, there
should be at least 4 cm
dstance between them.
• Our company shall not be lable
for any damages that wll arse
when the product s used
wthout groundng and electrcal
connecton n accordance wth the
natonal regulatons.
• Power cable plug must be wthn
easy reach after nstallaton.
• Connect your refrgerator to a
grounded outlet rated for a voltage
value of 220-240V /50 Hz. Outlet
shall have 10 to 16A fuse.
• Do not extenson cords or cordless
multple outlets between your
product and the wall outlet.
Installation
11 / 37 EN
Refrgerator / User Manual
3.5. Reversing the doors
Proceed in numerical order .
10
10
5
4
1
6
4
12
13
3
7
8
9
14
19
19
22
17
180°
23
21
16
15
24
24
11
45 °
2
20
18
Installation
12 / 37 EN
Refrgerator / User Manual
3.6. Reversing the doors
Proceed in numerical order .
10
10
5
4
1
6
4
12
13
3
7
8
9
14
19
19
22
17
180°
23
21
16
15
2
20
11
45 °
18
13/37 EN
Refrgerator / User Manual
4.1. Things to be done
for energy saving
A
Connectng the product to electrc
energy savng systems s rsky
as t may cause damage on the
product.
• Do not leave the doors of your
refrgerator open for a long tme.
• Do not put hot food or drnks n your
refrgerator.
• Do not overload the refrgerator,
coolng capacty wll fall when the ar
crculaton nsde s hndered.
• In order to store maxmum amount
of food n the freezer compartment,
the cematc, avalable n the freezer
compartment and easly removable by
hand, shall be taken out. Net volume
and energy consumpton values
declared on the power data plate of
your refrgerator are measured and
tested by removng the cematc. Do
not remove the shelves nsde the
freezer compartment and on the door
of freezer compartment shall not be
removed and they shall always be
used they provde ease of use and
effcency n energy consumpton.
• Arflow should not be blocked by
placng foods on the sdes of the
freezer compartment fan. A mnmum
dstance of 3 cm shall be provded on
the sdes of protectve fan cover.
• The baskets/drawers that are
provded wth the chll compartment
must always be n use for low energy
consumpton and for better storage
condtons.
• Food contact wth the temperature
sensor n the freezer compartment
may ncrease energy consumpton of
the applance. Thus any contact wth
the sensor(s) must be avoded.
• Dependng on the features of your
product, thawng frozen food n
frdge compartment wll both provde
energy savng and preserve the food
qualty.
4 Preparaton
• Do not allow contact of the food wth
the frdge compartment temperature
sensor shown n the fgure below.
4.2. Initial use
Before startng to use your refrgerator,
ensure that all preparatons are made
n accordance wth the nstructons n
sectons "Instructons for safety and
envronment" and "Installaton".
• Run the product wthout puttng any
food for 6 hours and do not open ts
door unless certanly requred.
C
You wll hear a nose when the
compressor starts up. The lquds
and gases sealed wthn the
refrgeraton system may also
gve rse to nose, even f the
compressor s not runnng and ths
s qute normal.
C
Front edges of the product may
feel warm. Ths s normal. These
areas are desgned to be warm to
avod condensaton.
C
In some models, the nstrument
panel automatcally turns off
5 mnutes after the door has
closed. It wll be reactvated when
the door has opened or pressed
on any key.
14 /37 EN
Refrgerator / User Manual
5 Operating the product
5.1. Temperature
setting button
The nteror temperature of your
refrgerator changes for the followng
reasons;
•Seasonal temperatures,
•Frequent openng of the door and
leavng the door open for long perods,
•Food put nto the refrgerator
wthout coolng down to the room
temperature,
•The locaton of the refrgerator n the
room (e.g. exposng to sunlght).
•You may adjust the varyng nteror
temperature due to such reasons by
usng the settng button.
The numbers around the control knob
ndcate the temperature values n “°C”.
If the ambent temperature s 25°C, we
recommend you to use the temperature
control knob of your refrgerator at 4°C. Ths
value may be ncreased or decreased as
requred n other ambent temperatures.
5.2. Fast freeze
If large amounts of fresh food are going
to be frozen, adjust the temperature
control knob to ( ) max. 24 hours
before putting the fresh food in the fast
freeze compartment.
It is strongly recommended to keep the
knob at this position at least 24 hours
to freeze maximum amount of fresh
food declared as freezing capacity. Take
special care not to mix frozen food and
fresh food.
Remember to turn the temperature
control knob back to its previous position
once food has frozen.
C
*optional:Fgures n ths user manual are gven as an example and may not
match the product exactly. If the relevant parts are not avalable n the product you
purchased, the fgure apples to other models.
Operating the product
15/37EN
Refrgerator / User Manual
5.3. Vacation function
If the doors of the product are
not opened for 12 hours after the
temperature control knob is switched
to the hottest position, then the
vacation function will be activated
automatically.
To cancel the function, change the
knob setting.
It is not recommended to store food
in cooler compartment when the
vacation function is active.
•When the settng operaton s
completed, you may press the
temperature control knob and have
t hdden.
Operating the product
16 / 37 EN
Refrgerator / User Manual
5.4. Indicator panel
Indcator panels may vary accordng to the product model.
Audo – vsual functons on the ndcator panel helps you n usng your
product.
45
7
6
8
9
1
2
3
1. Frdge Compartment
Indcator
2. Error status ndcator
3. Temperature ndcator
4. Vacaton functon button
5. Temperature settng
button
6. Compartment selecton
button
7. Freezer compartment
ndcator
8. Economy mode ndcator
9. Vacaton functon ndcator
*optonal
C
*optional:Fgures n ths user manual are gven as an example and may
not match the product exactly. If the relevant parts are not avalable n the
product you purchased, the fgure apples to other models.
Operating the product
17/37EN
Refrgerator / User Manual
1. Frdge compartment ndcator
Fridge compartment light is illuminated
while the fridge compartment
temperature is set.
2. Error status ndcator
If your refrigerator does not perform
enough cooling or in case of a sensor
fault, this indicator is activated. When this
indicator is activated, “E” is displayed on
the freezer compartment temperature
indicator, and numbers such as “1,2,3...”
are displayed on the fridge compartment
temperature indicator. These numbers
on the indicator inform service personnel
about the error.
3. Temperature ndcator
Indicates freezer, fridge compartment
temperature.
4. Vacaton functon button
Press on Vacation Button for 3 seconds to
activate this function. When the vacation
function is activated, “- -” is displayed on
the fridge compartment temperature
indicator and no active cooling is
performed on the fridge compartment.
It is not suitable to keep the food in the
fridge compartment when this function
is activated. Other compartments shall
be continued to be cooled as per their set
temperature.
To cancel this function press Vacation
button again.
5. Temperature settng button
Changes the temperature of the relevant
compartment between -24°C... -18°C and
8°C...1°C.
6. Compartment selecton button
Selection button: Press compartment
selection button to switch between fridge
and freezer compartments.
7. Freezer compartment ndcator
Fridge compartment light is
illuminated while the freezer
compartment temperature is set.
8. Economy mode ndcator
Indicates that the refrigerator
operates in energy saving mode.
This display shall be activated if the
freezer compartment temperature is
set to -18°C.
9. Vacaton functon ndcator
Indicates that vacation is activated.
Operating the product
18 / 37 EN
Refrgerator / User Manual
C
*Optonal: Figures in this user manual are schematic and may not match
the product exactly. If the subject parts are not included in the product you
have purchased, then those parts are valid for other models.
5.5. Indicator panel
Indicator panel allows you to set the temperature and control the other
functions related to the product without opening the door of the product. Just
press the inscriptions on relevant buttons for function settings.
1
3
45
6
789
*10
12
11
2
1. Power falure/Hgh temperature /
error warnng ndcator
This indicator ( ) illuminates during
power failure, high temperature
failures and error warnings. During
sustained power failures, the
highest temperature that the freezer
compartment reaches will flash on the
digital display. After checking the food
located in the freezer compartment (
) press the alarm off button to clear the
warning.
Please refer to "remedies advised
for troubleshooting" section on
your manual if you observe that this
indicator is illuminated.
2. Energy savng functon (dsplay
off):
If the product doors are kept closed
for a long time energy saving
function is automatically activated
and energy saving symbol is
illuminated. ( )
When energy saving function is
activated, all symbols on the display
other than energy saving symbol will
turn off. When the Energy Saving
function is activated, if any button
is pressed or the door is opened,
energy saving function will be
canceled and the symbols on display
will return to normal.
Operating the product
19/37EN
Refrgerator / User Manual
Energy saving function is activated
during delivery from factory and
cannot be canceled.
3.Quck frdge functon
The button has two functons. To
actvate or deactvate the quck cool
functon press t brefly. Quck Cool
ndcator wll turn off and the product
wll return to ts normal settngs. ( )
C
Use quck coolng functon
when you want to quckly cool
the food placed n the frdge
compartment. If you want to
cool large amounts of fresh
food, actvate ths functon
before puttng the food nto
the product.
C
If you do not cancel t, quck
coolng wll cancel tself
automatcally after 8 hours or
when the frdge compartment
reaches to the requred
temperature.
C
If you press the quck coolng
button repeatedly wth short
ntervals, the electronc crcut
protecton wll be actvated
and the compressor wll not
start up mmedately.
C
Ths functon s not recalled
when power restores after a
power falure.
4. Frdge compartment
temperature settng button
Press this button to set the
temperature of the fridge
compartment to 8, 7,6, 5,4,3, 2, 8...
respectively. Press this button to set
the fridge compartment temperature
to the desired value. ( )
5.Vacation Function
In order to activate vacation function,
press the this button ( ) for 3
seconds, and the vacation mode
indicator ( ) will be activated. When
the vacation function is activated,
“- -” is displayed on the fridge
compartment temperature indicator
and no active cooling is performed
on the fridge compartment. It is not
suitable to keep the food in the fridge
compartment when this function is
activated. Other compartments shall
be continued to be cooled as per their
set temperature.
To cancel this function press Vacation
function button again.
6. Alarm off warnng:
In case of power failure/high
temperature alarm, after checking
the food located in the freezer
compartment press the alarm off
button ( ) to clear the warning.
7. Key lock
Press key lock button ( )
simultaneously for 3 seconds. Key
lock symbol
( ) will light up and key lock mode
will be activated. Buttons will
not function if the Key lock mode
is active. Press key lock button
simultaneously for 3 seconds again.
Key lock symbol will turn off and the
key lock mode will be exited.
Press the key lock button if you
want to prevent changing of
the temperature setting of the
refrigerator ( ).
Operating the product
20 / 37 EN
Refrgerator / User Manual
8. Eco fuzzy
Press and hold eco fuzzy button
for 1 seconds to activate eco fuzzy
function. Refrigerator will start
operating in the most economic
mode at least 6 hours later and the
economic usage indicator will turn
on when the function is active (
). Press and hold eco fuzzy function
button for 3 seconds to deactivate
eco fuzzy function.
This indicator is illuminated after 6
hours when eco fuzzy is activated.
9. Freezer compartment
temperature settng button
Press this button to set the
temperature of the freezer
compartment to -18,-19,-20,-21,
-22, -23,-24, -18... respectively.
Press this button to set the freezer
compartment temperature to the
desired value.( )
10. Icematic off indicator
Indicates whether the icematic is on
or off. ( )If On, then the icematic
is not operating. To operate the
icematic again press and hold the On-
Off button for 3 seconds.
C
Water flow from water tank
wll stop when ths functon s
selected. However, ce made
prevously can be taken from
the cematc.
11. Quck freeze functon button/
cematc on-off button
Press this button to activate or
deactivate the quick freezing
function. When you activate the
function, the freezer compartment
will be cooled to a temperature lower
than the set value. ( )
To turn on and off the icematic press
and hold it for 3 seconds.
C
Use the quck freeze functon
when you want to quckly
freeze the food placed n frdge
compartment. If you want to
freeze large amounts of fresh
food, actvate ths functon
before puttng the food nto
the product.
C
If you do not cancel t, Quck
Freeze wll cancel tself
automatcally after 4 hours or
when the frdge compartment
reaches to the requred
temperature.
C
Ths functon s not recalled
when power restores after a
power falure.
12. Economc usage ndcator
Indicates that the product is running
in energy-efficient mode. ( )This
indicator will be active if the Freezer
Compartment temperature is set to
-18 or the energy efficient cooling
is being performed due to Eco-Extra
function.
C
Economc usage ndcator s
turned off when quck coolng
or quck freeze functons are
selected.
Operating the product
21/37EN
Refrgerator / User Manual
5.6. Twist Ice – matic
(Ths feature s optonal)
•Remove the water tank by rotatng
t to the left.
•Open the water tank cover by
turnng t and add water to the
water tank up to the lower part of
the water tank cover.
•Place the water tank on ts place as
shown n the fgure after addng
water and have t seated by rotatng
t on the drecton of the arrow.
Water shall be poured down to the
cebank.
•When ce has formed, rotate
cebank knob n the drecton of
the arrow to allow that the ce s
dropped down to the ce drawer.
•Take the ce cubes by pullng ce
drawer out.
•Pull the front face towards you n
order to wash the cebank, and put
t on the sldes on the nteror area
and push t to ts place n order to
replace t.
•Pull the twst cematc unt towards
you n order to remove the unt, and
put t on the sldes on the celng
and push t to ts place n order to
replace t.
5.7. Ice container
•Remove the ce contaner from the
freezer compartment.
•Fll the ce contaner wth water.
•Place the ce contaner n the
freezer compartment. About two
hours later, the ce s ready.
Operating the product
22 / 37 EN
Refrgerator / User Manual
5.11. Chiller
compartment
(Ths feature s optonal)
Use this compartment to store
delicatessen that shall be stored in a
lower temperature or meat products
that you will consume in a short time.
Chiller compartment is the coolest
place in your refrigerator where
you can keep dairy products, meat,
fish and poultry under ideal storage
conditions. Fruits and vegetables
should not be stored in this
compartment.
•Remove the ce contaner from the
freezer compartment and bend t
over the servce plate. Ice cubes wll
easly fall down to the servce plate.
5.8. Egg holder
You can install the egg holder to
the desired door or body shelf. If
it will be placed on body shelves
than the lower cooler shelves are
recommended.
A
Never place the egg holder n
the freezer compartment
5.9. Fan
Fan is designed to ensure homoge-
neous distribution and circulation of
the cold air inside your refrigerator.
Operation time of the fan may vary
depending on the properties of your
product.
While the fan works only with the
compressor in some products, the
control system determines its opera-
tion time in some products in accor-
dance with the cooling requirement.
5.10. Crisper
Crsper of the product s desgned
specally to keep the vegetables fresh
wthout loosng ther humdty. For ths
purpose, cool ar crculaton s ntensfed
around the crsper n general.
Operating the product
23/37EN
Refrgerator / User Manual
5.12. Moving
door shelf
(Ths feature s optonal)
Moving door shelf may be fixed in 3
different positions.
Press the buttons shown in the sides
at the same amount in order to move
the shelf. Shelf shall be movable.
Move the shelf up or down.
Release the buttons when you have
the shelf in the desired position.
Shelf shall be fixed on the position
where you release the buttons.
5.13. Sliding
storage container
(Ths feature s optonal)
This accessory is designed to increase
the usable volume of the door
shelves.
It allows you to easily place the tall
bottles, jars and tins to the lower
bottle shelf thanks to its ability to
move right or left.
5.14. Blue light
(Ths feature s optonal)
Beko Active Fresh Blue Light TM
technology ensures that the process
of photosynthesis continues in the
refrigerator prolonging the storage
life of fresh fruit and vegetables while
maintaining their natural flavours and
nutrition.
Operating the product
24 / 37 EN
Refrgerator / User Manual
5.15. Humidity
controlled crisper
(everfresh)
(Ths feature s optonal)
Humidity rates of the vegetables and
fruit are kept under control with the
feature of humidity-controlled crisper
and the food is ensured to stay fresh
for longer.
We recommend you to place the leafy
vegetables such as lettuce, spinach
and the vegetables which are sensitive
to humidity loss, in a horizontal manner
as much as possible inside the crisper,
not on their roots in a vertical position.
While the vegetables are being placed,
specific gravity of the vegetables
should be taken into consideration.
Heavy and hard vegetables should be
put at the bottom of the crisper and
the lightweight and soft vegetables
should be placed over.
Never leave the vegetables inside the
crisper in their bags. If the vegetables
are left inside their bags, this will cause
them to decompose in a short period
of time. In case contacting with other
vegetables is not preferred for hygiene
concerns, use a perforated paper and
other similar packaging materials
instead of a bag.
Do not place together the pear, apricot,
peach, etc. and apple in particular
which have a high level of generation
of ethylene gas in the same crisper
with the other vegetables and fruit.
The ethylene gas which is emitted by
these fruit may cause the other fruit
to ripen faster and decompose in a
shorter time.
5.16. Auto Icematic
(Ths feature s optonal)
The Auto Icematic allows you
to make ice in the fridge easily.
Remove the water tank in the fridge
compartment, fill it wilt water and
install it back to obtain ice from the
Icematic.
First ice cubes will be ready in
approximately 2 hours in the Icematic
drawer located in the freezer
compartment.
If you fill the water tank completely,
you will be able to obtain
approximately 60-70 ice cubes.
Change the water in water tank if it
has waited around 2-3 weeks.
C
For the products having
automatic Icematic, sound may
be heard during ice pouring.
This sound is normal and does
not signal any error.
Operating the product
25/37EN
Refrgerator / User Manual
5.17. Description and
cleaning of odour filter
(Ths feature s optonal)
Odor filter prevents unpleasant odor
build-up in your product.
1. Pull the cover nto whch the odor
flter s nstalled downwards from
the front secton and remove as
llustrated.
2. Leave the flter under sunlght
for one day. Flter wll be cleaned
durng ths tme.
3. Install the flter back to ts place.
C
Odor flter must be cleaned
once n a year.
Operating the product
26 / 37 EN
Refrgerator / User Manual
5.18. Using the
water dispenser
*optonal
C
It is normal for the first few
glasses of water taken from
the dispenser to be warm.
C
If the water dispenser is
not used for a long period
of time, dispose of first few
glasses of water to obtain
fresh water.
1. Push n the lever of the water ds-
penser wth your glass. If you are
usng a soft plastc cup, pushng
the lever wth your hand wll be ea-
ser.
2. After fllng the cup up to the level
you want, release the lever.
C
Please note, how much
water flows from the
dispenser depends on
how far you depress the
lever. As the level of water
in your cup / glass rises,
gently reduce the amount
of pressure on the lever
to avoid overflow. If you
slightly press the arm, the
water will drip; this is quite
normal and not a failure.
5.19. Filling the water
dispenser's tank
Water tank filling reservoir is located
inside the door rack.
1. Open the cover of the tank.
2. Fill the tank with fresh drinking
water.
3. Close the cover.
C
Do not fill the water tank
with any other liquid
except for water such as
fruit juices, carbonated
beverages or alcoholic
drinks which are not
suitable to use in the water
dispenser. Water dispenser
will be irreparably damaged
if these kinds of liquids are
used. Warranty does not
cover such usages. Some
chemical substances and
additives contained in these
kinds of drinks/liquids may
damage the water tank.
Operating the product
27/37EN
Refrgerator / User Manual
C
Use clean drinking water
only.
C
Capacity of the water tank is
3 litres; do not overfill.
Operating the product
28 / 37 EN
Refrgerator / User Manual
5.20. Cleaning
the water tank
1. Remove the water fllng reservor
nsde the door rack.
2. Remove the door rack by holdng
from both sdes.
3. Grab the water tank from both s-
des and remove t wth an angle of
45°C.
4. Remove the cover of the water
tank and clean the tank.
C
Components of the water
tank and water dispenser
should not be washed in
dishwasher.
Operating the product
29/37EN
Refrgerator / User Manual
5.21. Drip tray
Water that dripped while using the
water dispenser accumulates in the
spillage tray.
Remove the plastic filter as shown in
the figure.
With a clean and dry cloth, remove
the water that has accumulated.
Operating the product
30 / 37 EN
Refrgerator / User Manual
5.22. Freezing
fresh food
• In order to preserve the quality
of the food, it shall be frozen as
quickly as possible when it is
placed in the freezer compartment,
use the fast freezng feature for
ths purpose.
• You may store the food longer n
freezer compartment when you
freeze them whle they are fresh.
• Pack the food to be frozen and
close the packng so that t would
not allow entrance of ar.
• Ensure that you pack your food
before puttng them n the freezer.
Use freezer contaners, fols and
mosture-proof papers, plastc
bags and other packng materals
nstead of tradtonal packng
papers.
• Label each pack of food by addng
the date before freezng. You may
dstngush the freshness of each
food pack n ths way when you
open your freezer each tme. Store
the food frozen before n the front
sde of compartment to ensure
that they are used frst.
C
The freezer compartment
defrosts automatically.
• Frozen food must be used
mmedately after they are thawed
and they should not be re-frozen.
• Do not freeze too large quanttes
of food at one tme.
Freezer
Compartment
Settng
Frdge
compartment
Settng
Remarks
-18°C 4°C This is the normal recommended setting.
-20,-22 or
-24°C
4°C
These settings are recommended when the ambient
temperature exceeds 30°C.
Quick Freeze 4°C
Use when you wish to freeze your food in a short time.
Your product will return to its previous mode when the
process is over.
-18°C or colder 2°C
Use these settings if you think that your fridge
compartment is not cold enough because of the hot
ambient conditions or frequent opening and closing of
the door.
Operating the product
31/37EN
Refrgerator / User Manual
5.23. Recommendations for
preserving the frozen food
Compartment shall be set to -18°C at least.
1.
Put packages n the freezer as quckly as possble after purchase wthout
allowng the to thaw.
2.
Check whether the "Use By" and "Best Before" dates on the packagng are
expred or not before freezng t.
3.
Ensure that the package of the food s not damaged.
5.24. Deep-freeze information
According to IEC 62552 standards, the product shall freeze at least 4.5 kg of
food at 32°C ambient temperature to -18°C or lower within 24 hours for every
100-litres of freezer volume.
It is possible to preserve the food for a long time only at -18°C or lower
temperatures.
You can keep the freshness of food for many months (at -18°C or lower
temperatures in the deep freeze).
Foods to be frozen should not be allowed to come in contact with the
previously frozen items to prevent them from getting thawed partially.
Boil the vegetables and drain their water in order to store vegetables for
a longer time as frozen. After draining their water, put them in air-proof
packages and place them inside the freezer. Food such as bananas, tomatoes,
lettuce, celery, boiled eggs, potatoes are not suitable for freezing. When
these foods are frozen, only their nutritional value and taste shall be affected
negatively. They shall not be spoiled so that they would create a risk for human
health.
5.25. Placing the food
Freezer
compartment
shelves
Various frozen food
such as meat, fish, ice
cream, vegetables and
etc.
Refrigerator
compartment
shelves
Food in pans, covered
plates and closed
containers, eggs (in
closed container)
Door shelves
of fridge
compartment
Small and packaged
food or beverage
Crisper Vegetables and fruits
Operating the product
32 / 37 EN
Refrgerator / User Manual
Fresh zone
compartment
Delicatessen
(breakfast food, meat
products that shall be
consumed in a short
time)
5.26. Door open
warning
(Ths feature s optonal)
An audio warning signal will be given
when the door of your product is
left open for at least 1 minute. This
warning will be muted when the door
is closed or any of the display buttons
(if any) are pressed.
Door open warning is given to user
both visually and acoustically. If the
warning continues for 10 minutes,
interior lights will be turned off.
5.27. Changing the
door opening direction
Door openng drecton of your ref-
rgerator can be changed accordng
to the place you are usng t.If ths s
necessary, please call your nearest
Authorzed Servce.
Above descrpton s a general exp-
resson.For nformaton on changng
the openng drecton of the door, you
must refer to the warnng label loca-
ted on the nner sde of the door.
5.28. Illumination lamp
LED lamps are used as llumnaton
lamps. Contact authorzed servce n
case of any problem wth ths type of
lght.
The lamp(s) used in this appliance
is not suitable for household room
illumination. The intended purpose of
this lamp is to assist the user to place
foodstuffs in the refrigerator/freezer
in a safe and comfortable way.
33/37 EN
Refrgerator / User Manual
6 Mantenance and cleanng
Service life of the product is increase if it
is regularly cleaned
B
WARNING: Frst unplug the product
before cleanng your refrgerator.
•
Never use any sharp and abrasve
tools, soap, household cleaners,
detergent and wax polsh for cleanng.
•
Dssolve one teaspoon of carbonate
n half lter of water. Soak a cloth wth
the soluton and wrung t thoroughly.
Wpe the nteror of the applance wth
ths cloth and the dry thoroughly.
•
Make sure that no water enters the
lamp housng and other electrcal
tems.
•
Clean the door wth a damp cloth.
To remove door and body shelves,
remove all of ts contents. Remove
door shelves by movng them
upwards. After cleanng, slde them
from top to bottom to nstall.
•
Never use cleanng agents or water
that contan chlorne to clean the
outer surfaces and chromum coated
parts of the product. Chlorne causes
corroson on such metal surfaces.
• Do not use sharp, abrasve tools,
soap, household cleanng agents,
detergents, kerosene, fuel ol,
varnsh etc. to prevent removal and
deformaton of the prnts on the
plastc part. Use lukewarm water and
a soft cloth for cleanng and then
wpe t dry.
6.1. Avoiding bad odors
Materials that may cause odor are not
used in the production of our appliances.
However, due to inappropriate food
preserving conditions and not cleaning
the inner surface of the appliance as
required can bring forth the problem of
odor.
Therefore, clean the refrigerator wth
carbonate dssolved n water every 15
days.
•
Keep the food n closed contaners.
Mcroorgansms spreadng out from
uncovered contaners can cause
unpleasant odours.
•
Never keep the food that have expred
best before dates and spoled n the
refrgerator.
6.2. Protecting the
plastic surfaces
Clean with arm water immediately as the
oil may cause damage on the surface
when it is poured on plastic surfaces.
6.3. Door Glasses
Remove the protective foil on the
glasses.
There is a coating on the surface of
the glasses.This coating minimizes the
stain build-up and helps to remove the
possible stains and dirt easily.Glasses
that are not protected with such a
coating may be subject to persistent
binding of air or water based organic or
inorganic dirt such as limescale, mineral
salts, unburned hydrocarbons, metal
oxides and silicones that can easily and
quickly cause stains or material damage.
Keeping the glass clean becomes too
difficult despite the regular cleaning.
Consequently, the appearance and the
transparency of the glass deteriorates.
Harsh and corrosive cleaning methods
and compounds will intensify these
defects and speed up the deterioration
process.
Water-based cleaning products that are
not alkaline and corrosive must be used
for regular cleaning purposes.
34 / 37 EN
Refrgerator / User Manual
Mantenance and cleanng
Non-alkaline and non-corrosive materials
must be used for cleaning so that the
service life of this coating lasts for a long
time.
These glasses are tempered to increase
their durability against impacts and
breaking.
A safety film is also applied to their rear
surfaces as an extra safety measure
in order to prevent them from causing
damage to their surrounding in case of a
breakage.
*Alkali is a base that forms hydroxide
ions (OH¯) when it is dissolved in water.
Li (Lithium), Na (Sodium), K (Potassium)
Rb (Rubidium), Cs (Cesium) and artificial
and radioactive Fr (Fan-sium) metals are
called ALKALI METALS.
35/37 EN
Refrgerator / User Manual
7 Troubleshootng
Check this list before contacting the service. Doing so will save you time and money.
This list includes frequent complaints that are not related to faulty workmanship or
materials. Certain features mentioned herein may not apply to your product.
The refrigerator is not working.
• The power plug s not fully seated. >>> Plug t n to seat completely nto the
socket.
• The fuse connected to the socket powerng the product or the man fuse s
blown. >>> Check the fuses.
Condensation on the side wall of the cooler compartment (MULTI ZONE, COOL,
CONTROL and FLEXI ZONE).
• The envronment s too cold. >> Do not nstall the product n envronments wth
temperatures below -5°C.
• The door s opened too frequently >>> Take care not to open the product’s
door too frequently.
• The envronment s too humd. >>> Do not nstall the product n humd
envronments.
• Foods contanng lquds are kept n unsealed holders. >>> Keep the foods
contanng lquds n sealed holders.
• The product’s door s left open. >>> Do not keep the product’s door open for
long perods.
• The thermostat s set to too low temperature. >>> Set the thermostat to
approprate temperature.
Compressor is not working.
• In case of sudden power falure or pullng the power plug off and puttng back
on, the gas pressure n the product’s coolng system s not balanced, whch
trggers the compressor thermc safeguard. The product wll restart after
approxmately 6 mnutes. If the product does not restart after ths perod,
contact the servce.
• Defrostng s actve. >>> Ths s normal for a fully-automatc defrostng
product. The defrostng s carred out perodcally.
• The product s not plugged n. >>> Make sure the power cord s plugged n.
• The temperature settng s ncorrect. >>> Select the approprate temperature
settng.
• The power s out. >>> The product wll contnue to operate normally once the
power s restored.
The refrigerator's operating noise is increasing while in use.
• The product’s operatng performance may vary dependng on the ambent
temperature varatons. Ths s normal and not a malfuncton.
The refrigerator runs too often or for too long.
36 /37 EN
Refrgerator / User Manual
Troubleshootng
• The new product may be larger than your prevous one. Larger products wll run
for longer perods.
• The room temperature may be hgh. >>> The product wll normally run for long
perods n hgher room temperature.
• The product may have been recently plugged n or a new food tem s placed
nsde. >>> The product wll take longer to reach the set temperature when
recently plugged n or a new food tem s placed nsde. Ths s normal
• Large quanttes of hot food may have been recently placed nto the product.
>>> Do not place hot food nto the product.
• The doors were opened frequently or kept open for long perods. >>> The
warm ar movng nsde wll cause the product to run longer. Do not open the
doors too frequently.
• The freezer or cooler door may be ajar. >>> Check that the doors are fully
closed.
• The product may be set to temperature too low. >>> Set the temperature to a
hgher degree and wat for the product to reach the adjusted temperature.
• The cooler or freezer door washer may be drty, worn out, broken or not
properly settled. >>> Clean or replace the washer. Damaged / torn door
washer wll cause the product to run for longer perods to preserve the current
temperature.
The freezer temperature is very low, but the cooler temperature is adequate.
• The freezer compartment temperature s set to a very low degree. >>> Set the
freezer compartment temperature to a hgher degree and check agan.
The cooler temperature is very low, but the freezer temperature is adequate.
• The cooler compartment temperature s set to a very low degree. >>> Set the
freezer compartment temperature to a hgher degree and check agan.
The food items kept in cooler compartment drawers are frozen.
• The cooler compartment temperature s set to a very low degree. >>> Set the
freezer compartment temperature to a hgher degree and check agan.
The temperature in the cooler or the freezer is too high.
• The cooler compartment temperature s set to a very hgh degree. >>> Cooler
compartment temperature settng has an effect on the freezer compartment
temperature. Change the temperature of the cooler or freezer compartment
and wat untl the temperature of the related compartments come to the
adequate level.
• The doors were opened frequently or kept open for long perods. >>> Do not
open the doors too frequently.
• The door may be ajar. >>> Fully close the door.
• The product may have been recently plugged n or a new food tem s placed
nsde. >>> Ths s normal. The product wll take longer to reach the set
temperature when recently plugged n or a new food tem s placed nsde.
• Large quanttes of hot food may have been recently placed nto the product.
>>> Do not place hot food nto the product.
Shaking or noise.
37/37 EN
Refrgerator / User Manual
Troubleshootng
• The ground s not level or durable. >>> If the product s shakng when moved
slowly, adjust the stands to balance the product. Also make sure the ground s
suffcently durable to bear the product.
• Any tems placed on the product may cause nose. >>> Remove any tems
placed on the product.
The product is making noise of liquid flowing, spraying etc.
• The product’s operatng prncples nvolve lqud and gas flows. >>> Ths s
normal and not a malfuncton.
There is sound of wind blowing coming from the product.
• The product uses a fan for the coolng process. Ths s normal and not a
malfuncton.
There is condensation on the product's internal walls.
• Hot or humd weather wll ncrease cng and condensaton. Ths s normal and
not a malfuncton.
• The doors were opened frequently or kept open for long perods. >>> Do not
open the doors too frequently; f open, close the door.
• The door may be ajar. >>> Fully close the door.
There is condensation on the product's exterior or between the doors.
• The ambent weather may be humd, ths s qute normal n humd weather. >>>
The condensaton wll dsspate when the humdty s reduced.
The interior smells bad.
• The product s not cleaned regularly. >>> Clean the nteror regularly usng
sponge, warm water and carbonated water.
• Certan holders and packagng materals may cause odour. >>> Use holders and
packagng materals wthout free of odour.
• The foods were placed n unsealed holders. >>> Keep the foods n sealed
holders. Mcroorgansms may spread out of unsealed food tems and cause
malodour.
• Remove any expred or spolt foods from the product.
The door is not closing.
• Food packages may be blockng the door. >>> Relocate any tems blockng the
doors.
• The product s not standng n full uprght poston on the ground. >>> Adjust
the stands to balance the product.
• The ground s not level or durable. >>> Make sure the ground s level and
suffcently durable to bear the product.
The vegetable bin is jammed.
• The food tems may be n contact wth the upper secton of the drawer. >>>
Reorganze the food tems n the drawer.
A
WARNING: If the problem perssts after followng the nstructons n ths
secton, contact your vendor or an Authorsed Servce. Do not try to repar the
product.
www.beko.com.tr
www.beko.com
.au
57 5210 0000/AN
