nursery HEPA air purifier
Pio
Hello, i’m
Own’s Handbk
read & save these important instructions
2 English
Welce to Vnadobaby
Vornado began in 1945, continues to revolutionize airflow today and is now tailored for the nursery.
®
A THIRD
genati
NAME
Thank you for choosing to put a Vornadobaby product in your nursery. Our
goal is to provide healthy, comfortable air - through every season. Vornado has
been doing this for quite a while now. We’ve brought all our experience in air
health and comfort, and tailored it exclusively for your nursery.
3
English
Español p. 22
Français p. 42
Important Safety Instructions ................................................................. 4
Safety ......................................................................................................... 7
Purio Controls ........................................................................................... 8
Plug In & Placement ................................................................................ 9
How To Use ............................................................................................. 11
Purio Filters ............................................................................................. 13
Keeping Purio Clean ............................................................................. 18
Tips .......................................................................................................... 19
Troubleshoot .......................................................................................... 20
Warranty .................................................................................................. 21
Contents
4 English
This owner’s guide and any additional inserts are considered
part of the product. They contain important information
about safety, use and disposal. Before using the product,
please familiarize yourself with all operating and safety
instructions. Please keep all documents for future reference
and pass these documents on, together with the product,
to any future owner. See our website to view, download and
print the most current version of this owner’s guide.
INTENDED USE:
This product is intended to purify the air in indoor living
spaces only in the United States and Canada. This product
is not intended for commercial or industrial use. The
manufacturer assumes no responsibility for damage or injury
due to unauthorized use or product modification. Failure to
follow these directions will void the product warranty.
WARNING: Risk to Children and Impaired Persons
- Supervision is required during the installation, operation,
cleaning and maintenance of this product by children
under age 12 and anyone with reduced physical, sensory
or mental capabilities. Children should be supervised to
ensure that they do not play with the appliance, its parts
and packaging material.
INSTALLATION WARNING—To reduce risk of fire, electrical
shock and injury to persons, observe the following:
- Place this product away from curtains, draperies,
tablecloths and other fabrics, since they may be drawn into
the product, damage the motor and/or cause a fire.
- No part of this product (the appliance, power cord, plug,
packaging, etc.) should be placed near furnaces, fireplaces,
stoves or other high temperature heat sources. Do not use
this product in a window, on an uneven or unstable surface,
or near water.
- The appliance, power supply, power cord and plug cannot
come into contact with water. Do not use this product
on wet surfaces. Do not use this product in a bathtub
or shower or position product where it may fall into a
bathtub, laundry, swimming pool or other water container.
Do not use this product outdoors or expose it weather or
elements.
- Do not run cord under carpeting. Do not cover cord
with throw rugs, runners, or similar coverings. Do not
route under furniture or appliances. Arrange cord away
from traffic area and where it will not be tripped over.
The cord should not hang over edges of counters or be
placed where it can be crimped or closed in doors. Place
appliance near an easily accessible outlet so the product
IMPORTANT SAFETY
INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
5
English
can be unplugged quickly during an emergency.
SAFE USE WARNING—To reduce risk of fire, electrical
shock and injury to persons, observe the following:
- WARNING: To reduce likelihood of circuit overload, fire
and electric shock, do not operate with a solid state speed
device, such as a dimmer control switch.
- Do not operate unit if the unit has been dropped or
damaged. Do not use this product if it has a damaged
power cord or plug. To avoid risk of electrical shock,
do not attempt to repair or replace parts. Only original
replacement parts may be used. If the power cord is
damaged, it must be replaced by the manufacturer, its
service agent, or similarly qualified persons in order to
avoid a hazard. Contact Vornado Consumer Service at
1-800-234-0604 (phone) or consumerservice@vornado.
com (email) for further instructions about replacement and
repair.
- Risk of fire. Use only the power cord and plug provided.
- Before plugging power cord into electrical outlet, be sure
that all electrical information on the rating label, including
voltage, is compatible with your outlet’s power supply.
- Never use the cord as a handle or otherwise yank, strain or
stretch the power cord.
- While the product is plugged in, do not insert or allow
foreign objects to enter any input or output opening as
this may cause risk of electric shock or fire, or damage the
product.
- A loose fit between wall outlet (receptacle) and plug may
cause overheating and distortion of the plug. Discontinue
use of the product in this outlet. Contact a qualified
electrician to replace loose or worn outlets.
- This appliance has a polarized plug (one blade is wider than
the other.) To reduce the risk of electrical shock, this plug is
intended to fit in a polarized outlet only one way. If the plug
does not fit fully in the outlet, reverse the plug. If it still does
not fit, contact a qualified electrician. Do not attempt to
defeat this safety feature.
- Before moving, repositioning, servicing, cleaning and when
not in use, use the product controls to turn off the power
and then unplug. To disconnect from outlet, grasp and pull
only the plug. Also, power off and unplug if the product will
be left unattended for an extended period of time or during
electrical storms.
SERVICING WARNING—To reduce risk of fire, electrical
shock and injury to persons, observe the following:
- Clean your product regularly, only as is instructed in this
manual. Prior to cleaning, turn off the power on your
product and unplug. Do not use gasoline, thinners, solvents,
ammonias or other chemicals for cleaning. Refer to the
CLEANING instructions provided.
- Do not open appliance housing while product is plugged
in. To avoid risk of shock, all service and/or repairs must be
done by a Vornado Authorized Service Center.
6 English
FCC Consumer Advisement
This equipment may generate, use and/or radiate radio
frequency energy that may cause harmful interference to
radio communications. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to contact Vornado Consumer Service. Changes
or modifications to this unit not expressly approved by
the party responsible for compliance could void the user’s
authority to operate the product.
DISPOSAL WARNING
To reduce waste and environmental harm, observe the
following:
PACKAGE RECYCLING:
The packaging protects the appliance from transport damage.
The packaging materials are selected from the point of
view of their environmental friendliness and disposal
technology and are therefore recyclable. Dispose of all
packaging materials in an environmentally responsible
manner.
READ AND SAVE THESE
INSTRUCTIONS
7
English
Safety
Plug It In Safely! Your Purio has a 6 ft. power cord, covered for additional safety. Vornado
recommends placing product as close to an outlet as possible and securing the remaining cord.
Locking Controls
Keeps Purio Off when not
in use.
Sturdy Base
Maintains upright position.
Door Lock
Secured Door Lock protects
baby from any moving parts
and dirty filters.
No Pinch Points or
Sharp Edges
Worry free protection in
the baby room.
Finger Friendly Design
Resists curious fingers.
Covered Power Cord
Storage
Safely store power cord
inside base of Purio.
8 English
Power ( )
Sleepy Time ( )
Purio Controls
Fan ( - High, Medium, Low)
Filter Reset Buttons
1
2
3
4
5
6
1
2 3
4
5 6
7
Control Lock ( )
Night Glow ( )
7
Filter Cover Lock ( )
9
English
Fan ( - High, Medium, Low)
Power Cord Storage
For your convenience and safety the Power Cord
Storage keeps the power cord neat and out of
harms way.
1. Lift the Power Cord Storage flap to locate
plug, then unwind the power cord stored
inside.
Safety Tip: Power cords increase strangulation
risks. Secure as much excess cord as possible
inside the Power Cord Storage.
Plug In & Placement
10 English
Set Up
1. Position Purio so the air is directed across the
room, unobstructed.
2. Plug power cord into standard wall outlet.
Safety Tip: It is best to position Purio close to the
power outlet and store excess power cord inside
the Power Cord Storage.
11
English
Operation
1. Press Power button On ( ). The control
panel will illuminate when On and dim after
approximately 20 seconds.
2. Press the Night Glow button ( ) to power
Night Glow On or Off.
3. Press the Fan button ( ) to select desired Fan
speed. Low speed ( ), Medium speed ( ) or
High speed ( ).
4. Select the Sleepy Time button ( ) if desired.
This feature will automatically adjust the Fan
speed to Low and power the Night Glow
Off when Purio senses no light or low light
conditions.
Note: Previous control settings are kept for the
next time Purio is powered On, unless Purio is
unplugged.
How To Use
12 English
Locking Controls
1. To engage this feature press and hold the
Control Lock button ( ) for 3 seconds. The
Control Lock icon will blink 3 times rapidly to
show it is locked.
Note: The Control Lock icon will blink 3 times
slowly if any button is pressed while the
Control Lock is engaged. While this feature is
engaged you will not be able to change the
settings or Power Purio On or Off. If Purio is
powered Off, you may still engage the Control
Lock.
2. To turn this feature off press and hold the
Control Lock button ( ) for 3 seconds.
13
English
Purio Filters
Replacing the Filters
The word HEPA or Carbon will illuminate on
Purio when it is time to replace the Filter.
1. Power Purio Off and unplug.
2. Push Panel Unlock button to release the front
panel. Pull the front panel away from Purio.
While your Purio came equipped with Filters, you will eventually have to replace the Activated
Carbon Filter after 4,000 hours and HEPA Filter after 9,000 hours of run time, depending on use.
Replace the Filters with only genuine Vornado® brand Filters. Purio will ping to notify when the Ac-
tivated Carbon Filter and HEPA Filter should be replaced. If powered On, the Night Glow will slowly
fade On and Off.
²
²
14 English
3. Remove the Permanent Pre-Filter by pulling
on the center. You may need to flex the
Permanent Pre-Filter slightly to release the
tabs at the sides.
4. Take hold of the Activated Carbon Filter at any
place along the perimeter and remove.
²
²
²
15
English
5. To remove the HEPA Filter, take hold of the tab
and pull to release.
6. Remove and discard used Filters. Replace with
genuine Vornado Filters.
7. Gently press around the perimeter of the
Filter to ensure secure placement.
Purio Filters
²
16 English
8. To replace Permanent Pre-Filter you may need
to flex the Permanent Pre-Filter slightly to
insert the tabs at the sides.
9. Replace Front Panel. Align the tabs at the
bottom and push the Front Door closed until
you will hear the lock engage. Purio will not
power On if the Front Panel is not securely in
place.
²
²
²
²
17
English
10. To reset Filter notification, press and hold
the Carbon or HEPA reset button for 3
seconds or until Carbon or HEPA is no longer
illuminated.
Automatic Refill Program
Select the shipment interval and Vornado
will send replacement Filters automatically.
Eliminate the hassle of remembering to reorder.
Maintain the high efficiency of your Vornado
Purio. To sign up, visit www.vornadobaby.com,
email [email protected] or call
1-800-234-0604. Cancel at anytime.
Purio Filters
Model # MD1-0031 Model # MD1-0030
18 English
Cleaning
1. Power Purio Off and unplug.
2. Dust or vacuum the Grill and Air Inlets.
Note: Do not use gasoline, thinners, solvents or
other chemicals for cleaning.
3. The Permanent Pre-Filter can be cleaned with
a vacuum or rinsed.
Note: If vacuuming, use the vacuum brush
attachment. If rinsing, allow Permanent Pre-Filter
to completely dry.
Keeping Purio Clean
19
English
Tips
• During the off-season or after extended
periods of non-use, you may choose to store
your Purio. To ensure long life of the product,
it is recommended to store your Purio by
following these instructions:
• Unplug power cord and wrap cord neatly
inside the Safe Storage.
- Thoroughly clean your Purio.
- Use the brush attachment on your household
vacuum cleaner to vacuum any accumulated
dust on Purio or wipe down the entire sur-
face with a soft cloth. You may also use a can
of compressed air for debris.
- Cover, or place Purio back into retail carton
if available. This will prevent Purio from ac-
cumulating dust over time.
- Store Purio in a cool and dry location.
• Always set Power button to Off and unplug
Purio before cleaning.
• The motor is permanently lubricated and re-
quires no oiling. Do not use gasoline, thinners,
solvents or other chemicals for cleaning.
• Your Purio has no user serviceable parts.
Do not disassemble Purio. This will void
your warranty. If service is required, return
your Purio to Vornado (see WARRANTY for
instructions).
20 English
Unit is not plugged in. Plug power cord into electrical outlet.
Front Panel may not be properly installed. Remove and reinstall the
Front Panel to assure proper placement.
Household circuit breaker / ground fault interrupter has tripped or
blown a fuse. Reset circuit breaker / ground fault interrupter, or replace
fuse. For assistance, contact a licensed electrician.
Unit is damaged or in need of repair. Cease usage and unplug. Con-
tact Consumer Service for assistance.
Controls may be locked. If Lock symbol is illuminated, press and hold
the Control Lock button for 3 seconds to turn Off.
Unit set to a low speed setting. Adjust to a higher speed setting.
Debris build-up on filter. Check and replace filters.
Airflow is blocked. Remove obstruction.
Unit fails to
power on.
Airflow is weak
or slow.
Troubleshoot
21
English
Happy Pent Guantee
Call Tl Free
800.234.0604
www.vornadobaby.com
support@vornadobaby.com
Vornado Air LLC (“Vornado”) warrants to the original consumer or purchaser this Vornadobaby® Purio Nursery HEPA Air Purifier
(“Product”) is free from defects in material or workmanship for a period of five (5) years from the date of purchase. If any such
defect is discovered within the warranty period, Vornado, at its discretion, will repair or replace the Product at no cost.
For warranty or repair service:
Call 1-800-234-0604 or email support@vornadobaby.com to obtain a Return
Authorization (“RA”) form. Please have or include your Product’s model number
and serial number, as well as your name, address, city, state, zip code and phone
number when contacting Vornado for warranty service.
After receiving the RA form, ship your Product to:
Vornado Air LLC Attn: Warranty & Repair 415 East 13th Street Andover, KS
67002 For your convenience, please have your model number and serial
number when contacting Vornado with service inquiries. To assure proper
handling, packages must be clearly marked with the RA number. Packages
not clearly marked with the RA number may be refused at the receiving dock.
Please allow 1-2 weeks for repair and return of your Product after the Product is
received.
Product registration available online at www.vornadobaby.com
Repairs not covered by the warranty or outside the warranty period will
require a fee to cover the cost of materials, labor, handling and shipping.
This warranty does not apply to defects resulting from abuse of the Product,
modification, alteration, repair or service of the Product by anyone other
than Vornado, mishandling, improper maintenance, commercial use of the
Product, damages which occur in shipment or are attributed to acts of God.
REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE
EXCLUSIVE REMEDY OF THE CONSUMER. VORNADO SHALL NOT BE LIABLE
FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR BREACH OF
ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT. EXCEPT TO
THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED WARRANTY
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON THIS
PRODUCT IS LIMITED IN DURATION TO THE DURATION OF THIS WARRANTY.
Some states do not allow the exclusion or limitation of incidental or consequen-
tial damages, or allow limitations on how long an implied warranty lasts, so the
above limitations or exclusions may not apply to you. This warranty gives you
specific legal rights, and you may have other rights that vary from state to state.
If you’re not satisfied with this product, let us know. We’ll go the extra mile to ensure you’re a happy Vornadobaby parent!
© 2015 Vornado Air LLC Andover, KS 67002 U.S. Patent Pending. Specifications subject to change
without notice. Vornado® and Vornadobaby® are trademarks owned by Vornado Air LLC.
Designed, engineered and supported in Andover, KS
CL3-0619 R-, V00
Speak your mind vornadobaby.com/reviews
Hable con franqueza vornadobaby.com/reviews
Évaluer ce produit en ligne vornadobaby.com/reviews
Vornado Air, LLC
415 East 13th Street, Andover, Kansas 67002
800.234.0604
vornadobaby.com
support@vornadobaby.com
