PLANNING
GUIDE
Web: http://www.Dacor.com
Corporate Phone: 800-793-0093
Specifications are subject to change without notice.
See installation instructions for additional details.
9.3
Remote Blowers
REMP3, REMP16
REMP
3 1/4" x 10" to
Round
Transistion
45° Adjustable
Elbow
Air
Discharge
REMP SLOPED INSTALLATION
(Cutaway Side View)
17 1/8" (435mm)
5 13/16"
(148mm)
8"
(203mm)
19" (483mm)
7 13/16"
(198mm)
24 1/16"
(611mm)
3 5/8"
(92mm)
9 1/4"
(235mm)
Mounting
Flange
25 1/2"
(648mm)
7 1/2"
(191mm)
9 1/2" (241mm)
Discharge
Cutout
Location
Intake Collar
Intake Collar
C
L
C
L
C
L
C
L
Power Supply
Conduit
Location
Discharge
REMP3 OVERALL DIMENSIONS
(Top & Side Views)
24" (610mm)
9 9/16"
(243mm)
10"
(254mm)
26" (660mm)
11 1/2"
(292mm)
31 1/2"
(800mm)
3 1/2"
(89mm)
12 1/4"
(311mm)
Mounting
Flange
33 1/2"
(851mm)
9 1/2"
(241mm)
12 11/16"
(322mm)
Discharge
Cutout
Location
Intake Collar
Intake Collar
C
L
C
L
C
L
C
L
Discharge
Power Supply
Conduit
Location
REMP16 OVERALL DIMENSIONS
(Top & Side Views)
