Portable Radiator Heater, Manual Control, 1500W
Radiateur Mobile, Commande manuelle, 1500W
Calefactor de Radiador Portátil, Control Manual, 1500W
B0828YLCY7
English . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Français . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Español . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3
EN
IMPORTANT INSTRUCTIONS
Read these instructions carefully and retain them for future use.
If this product is passed to a third party, then these instructions
must be included.
When using electrical appliances, basic safety precautions should always
be followed to reduce the risk of fire, electric shock, and/or injury to
persons including the following:
WARNING
Risk of electric shock! To reduce the risk of fire or
electric shock do not use with an extension cord.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
NO USER-SERVICEABLE PARTS INSIDE
• Read all instructions before using this heater.
• This heater is hot when in use. To avoid burns, do not let bare skin
touch hot surfaces. If provided, use handles when moving this heater.
Keep combustible materials such as furniture, pillows, bedding,
papers, clothes, curtains at least 3 feet (0.9 m) from the front of the
heater and keep away from the sides and rear.
• Extreme caution is necessary when any heater is used by or near
children or invalids and whenever the heater is left operating and
unattended.
• Do not operate any heater with a damaged cord or plug after the
heater malfunctions, has been dropped or damaged by any manner.
Discard heater or return to authorized service facility for examination
and/or repair.
• Do not use outdoors.
• This heater is not intended for use in bathrooms, laundry areas and
similar indoor locations. Never locate heater where it may fall into a
bathtub or other water container.
• Do not run cord under carpeting. Do not cover cord with throw rugs,
runners or similar coverings. Do not route cord under furniture or
appliances. Arrange cord away from traffic area and where it will not
be tripped over.
• To disconnect heater, turn controls to off, then remove plug from
outlet.
• Do not insert or allow foreign objects to enter any ventilation or
exhaust opening as this may cause an electric shock or fire, or
damage the heater. Oil in the heater is permanently sealed and does
not require refilling.
4
EN
• This heater is filled with a precise quantity of special oil. Repairs
requiring opening of the oil container are only to be made by a
professional repair center that should be contacted if there is an oil
leak.
• When scrapping the heater, follow the regulations concerning the
disposal of oil.
• A heater has hot and arcing or sparking parts inside. Do not use it In
areas where gasoline, paint or flammable liquids are used or stored.
• Always plug heaters directly into a wall outlet/receptacle. Never use
with an extension cord or relocatable power tap (outlet/power strip).
• To prevent a possible fire, do not block air intakes or exhaust in any
manner. Do not use on soft surfaces, like a bed, where openings may
become blocked.
• This product draws up to 1500 W of power. To prevent overloading of
the electrical circuit, do not plug the product into a circuit with other
appliances already connected.
• The plug in the socket outlet must always be easily accessible so that
it can be disconnected in an emergency.
Polarized Plug
This appliance has a polarized plug (one blade is wider than the other). To
reduce the risk of electric shock, this plug will fit the outlet only one way.
If the plug does not fit fully in the outlet, reverse the plug. If it still does not
fit, contact a qualified electrician. Do not modify the plug in any way.
SAVE THESE INSTRUCTIONS
Intended Use
• This product is intended for temporarily heating residential rooms with
an effective area coverage of 120-160 ft
2
(11-15 m
2
).
• This product is intended for household use only. It is not intended for
commercial use.
• This product is intended to be used in dry indoor areas only.
• No liability will be accepted for damages resulting from improper use
or non-compliance with these instructions.
5
EN
Product Description
A
D
E
G
CB
H
J
G
I
A
Handle
F
Power cord with plug
B
Power knob
G
Air vents
C
Thermostat knob
H
Radiator fins
D
Power indicator light
I
Front caster wheels
E
Cord hooks
J
Rear caster wheels
6
EN
Before First Use
• Check the product for transport damages.
• Remove all the packing materials.
• Before connecting the product to the power supply, check that the
power supply voltage and current rating corresponds with the power
supply details shown on the product rating label.
DANGER
Risk of suffocation! Keep any packaging materials
awayfrom children – these materials are a potential source of danger,
e.g. suffocation.
Installing Caster Wheels
Step 1
Turn over the product and screw the front caster wheels (I) onto the
threads using the provided wing nuts.
I
7
EN
Step 2
Attach the rear caster wheels (J) by using the U-shaped bolt and locking
it in between the last two radiator fins.
J
Step 3
Turn the product back over once the caster wheels (I) has been installed
and before switching on the product.
8
EN
Installing Cord Hook
Step 1
Insert the cord hook (E) into the air vents (G) matching up with the holes
for the screws.
G
E
Step 2
Tighten the screws until cord hook (E) is secure.
NOTICE
Cord hook (E) can be installed on either side of the product
air vents (G).
Operation
Positioning the product
Place the product on a flat and stable surface to avoid risk of tipping it
over.
Connecting
Fully unwind the power cord (F) and connect the plug to a suitable socket
outlet.
NOTICE
Once connected to the socket outlet, the power indicator
(D) stays lit.
NOTICE
The power indicator light (D) stays lit even once the product
has been turned OFF.
9
EN
Switching on/off
• To switch on the product, turn the power knob (B) clockwise until the
desired level of power level has been selected.
• To switch off the product, turn the power knob (B) anti-clockwise until
OFF has been selected.
Temperature setting
1. To adjust the temperature, turn the thermostat knob (C) clockwise
from MIN to MAX and rotate the power knob (B) clockwise to choose
one of below settings:
Setting Power Heat
I 600 W Low
II 900 W Medium
III 1500 W High
2. When the desired temperature is reached, rotate the thermostat
knob (C) anti-clockwise until the click sound. The product cycles
automatically to maintain the set temperature.
NOTICE
The product gradually heats up once the desired power
level and temperature has been selected.
Cleaning and Maintenance
WARNING
Risk of electric shock! To prevent electric shock,
unplug the product before cleaning.
WARNING
Risk of electric shock! During cleaning do not
immerse the product in water or other liquids. Never hold the product
under running water.
Cleaning
• To clean the product, wipe with a soft, slightly moist cloth.
• Never use corrosive detergents, wire brushes, abrasive scourers,
metal or sharp utensils to clean the product.
Storage
• Wrap the power cord (F) around the cord hooks (E).
• Store the product in its original packaging in a dry area. Keep away
from children and pets.
Maintenance
Any other servicing than mentioned in this manual should be performed
by a professional repair center.
10
EN
Troubleshooting
Problem Solution
Unexpected
crackling sounds.
• This is a normal sound after starting up the
product. Once the heater heats up, the
crackling sound goes away.
Unexpected smell. • This is the result of dust or other debris
accumulating on the heating element.
This is normal during first use and after
prolonged storage. Make sure the product
is placed in a well ventilated area. Keep
the product switched on, until the smell
disappears.
Heater shuts off
unexpectedly
• Ensure the power cord is plugged into a
working socket outlet.
• Safety functions (overheating/tipped over)
may have been activated. Switch off the
heater to cool it down and restart.
Safety Functions
Tip-over switch
• The product automatically stops heating when it tips forward or
backward. The heating element and indicator light switches off.
• After placing the product into normal position, restart the product.
11
EN
Specifications
Model: B0828YLCY7
Voltage/frequency: 120V~, 60Hz
Power consumption: max. 1500W
Dimensions (W x H x D):
approx. 13.1 x 9.8 x 26.3"
33.5 x 25 x 67 cm
Net weight: approx. 16.9 lbs (7.7 kg)
Feedback and Help
Love it? Hate it? Let us know with a customer review.
AmazonBasics is committed to delivering customer-driven products
that live up to your high standards. We encourage you to write a review
sharing your experiences with the product.
amazon.com/review/review‑your‑purchases#
amazon.com/gp/help/customer/contact‑us
amazon.com/AmazonBasics
V01-01/20
