Owner’s
Manual
Double-Door, Double-Drawer,
Stainless Steel, Free-Standing
Refrigerators
monogram.com
01-14 GE
225D1804P009
49-60630-2
2
Consumer Information
Stainless Steel Refrigerator
Introduction
Your new Monogram refrigerator makes an eloquent statement of style, convenience and kitchen
planning flexibility. Whether you chose it for its purity of design, practical storage arrangements or
DVVLGXRXVDWWHQWLRQWRGHWDLO³RUIRUDOORIWKHVHUHDVRQV³\RX·OOILQGWKDW\RXU0RQRJUDPUHIULJHUDWRU·V
superior blend of form and function will delight you for years to come.
The information on the following pages will help you operate and maintain your refrigerator properly.
If you have any other questions, visit our Website at: monogram.com
Contents
Consumer Services
Important Phone Numbers ..................27
Model and Serial Numbers ....................3
Performance Data Sheet ....................26
Problem Solver .......................... 20–24
Product Registration ..........................3
Safety Instructions ........................ 4–7
State of California
Water Treatment Device Certificate ..........27
Notes ...................................29-31
Warranty ...........................Back Cover
Care and Cleaning
&OHDQLQJ³2XWVLGHDQG,QVLGH ................18
Light Bulb Replacement ..................... 19
Moving .....................................18
Vacation ....................................18
Operating Instructions
Automatic Icemaker .........................17
Additional Features ..........................15
Crispers .....................................16
Internal Water Dispenser ....................10
2WKHU&RQWUROV ...............................9
Performance Air Flow System .................8
Shelves and Bins ........................ 12–14
Temperature Controls ........................8
TurboCool ...................................9
Water Filter .................................11
Before
using
your
refrigerator
Read this manual carefully. It is intended to help
you operate and maintain your new refrigerator
properly.
Keep it handy for answers to your questions.
,I\RXGRQ·WXQGHUVWDQGVRPHWKLQJRUQHHG
more help, there is a list of toll-free consumer
service numbers included in the back section
of this manual.
OR
Visit our Website at: monogram.com
3
Write
down
the model
& serial
numbers
<RX·OOVHHWKHPRQDODEHOLQVLGHWKHIUHVKIRRG
compartment at the top on the right side.
Please write these numbers on the Consumer
3URGXFW2ZQHUVKLS5HJLVWUDWLRQ&DUGLQFOXGHG
with the packing material.
Before sending in this card, please also write
these numbers here:
Model Number
Serial Number
Use these numbers in any correspondence
or service calls concerning your refrigerator.
If you
received a
damaged
refrigerator
Immediately contact the dealer (or builder) that
sold you the refrigerator.
Save time
& money
Before you request service, check the Problem
Solver in the back of this manual.
It lists causes of minor operating problems that
you can correct yourself.
If you
need
service
To obtain service, see the Consumer Services
page in the back of this manual.
:H·UHSURXGRIRXUVHUYLFHDQGZDQW\RXWREH
pleased. If for some reason you are not happy
with the service you receive, here are steps to
follow for further help.
For customers in the USA:
FIRST, contact the people who serviced your
appliance. Explain why you are not pleased.
In most cases, this will solve the problem.
NEXT, if you are still not pleased, write all
WKHGHWDLOV³LQFOXGLQJ\RXUSKRQHQXPEHU³WR
Manager, Customer Relations
GE Appliances
Appliance Park
Louisville, KY 40225
For customers in Canada:
FIRST, contact the people who serviced your
appliance. Explain why you are not pleased.
In most cases, this will solve the problem.
NEXT, if you are still not pleased, write all
WKHGHWDLOV³LQFOXGLQJ\RXUSKRQHQXPEHUWR
Manager, Consumer Relations
Mabe Canada Inc.
1 Factory Lane, Suite 310
Moncton, N.B. E1C 9M3
Consumer Information
Stainless Steel Refrigerator
READ AND SAVE THESE INSTRUCTIONS
WARNING: When using this
appliance, always exercise basic safety
precautions, including the following:
• Use this appliance only for its intended purpose
DVGHVFULEHGLQWKLV2ZQHU·V0DQXDO
• This refrigerator must be properly installed in
accordance with the Installation Instructions
before it is used.
• Do not allow children to climb, stand or hang
on the shelves in the refrigerator. They could
damage the refrigerator and seriously injure
themselves.
• Do not touch the cold surfaces in the freezer
compartment when hands are damp or wet.
Skin may adhere to these extremely cold surfaces.
• Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
• In refrigerators with automatic icemakers,
avoid contact with moving parts of the ejector
mechanism, or with the heating element located
on the bottom of the icemaker. Do not place
fingers or hands on the automatic icemaking
mechanism while the refrigerator is plugged in.
• Keep fingers out of the “pinch point” areas:
clearances between the doors and between
the doors and cabinet are necessarily small.
Be careful closing doors when children are
in the area.
• Unplug your refrigerator before cleaning and
making repairs. NOTE: We strongly recommend
that any servicing be performed by a qualified
individual.
• Before replacing a burned-out light bulb,
the refrigerator should be unplugged in order
to avoid contact with a live wire filament.
(A burned-out light bulb may break when
being replaced.)
NOTE: Turning control to OFF does not remove
power to the light circuit.
• Do not refreeze frozen foods which have thawed
completely.
,03257$176$)(7<,16758&7,216
DANGER: RISK OF CHILD ENTRAPMENT
Child entrapment and suffocation are not problems
of the past. Junked or abandoned refrigerators are
still dangerous…even if they will sit for “just a few
days.” If you are getting rid of your old refrigerator,
please follow the instructions below to help prevent
accidents.
Before you throw away your old refrigerator
or freezer:
• Take off the doors.
• Leave the shelves in place so that children
may not easily climb inside.
REFRIGERANTS
All refrigeration products contain refrigerants, which
under federal law must be removed prior to product
disposal.
If you are getting rid of an old refrigeration product,
check with the company handling the disposal
about what to do.
4
5
0(685(6'(6e&85,7e,03257$17(6
LIRE ET CONSERVER CES INSTRUCTIONS
AVERTISSEMENT : Lorsque
vous utilisez le réfrigérateur, observez toujours
certaines précautions de base, notamment :
• N’utilisez le réfrigérateur que pour son usage
prévu, comme décrit dans le présent manuel.
• Installez le réfrigérateur conformément aux
directives d’installation avant de l’utiliser.
• Ne laissez pas les enfants grimper, s’asseoir,
se tenir debout ni se pendre aux clayettes
du réfrigérateur. Ils pourraient endommager
le réfrigérateur et se blesser gravement.
• Une fois le réfrigérateur en marche, ne touchez
pas les surfaces froides du congélateur, surtout
si vous avez les mains humides ou mouillées :
ODSHDXULVTXHG·DGKpUHUjFHVVXUIDFHVWUqV
froides.
• N’entreposez et n’utilisez pas d’essence ou
autres vapeurs et liquides inflammables à
proximité de cet appareil ou de tout autre
appareil électroménager.
• Pour les réfrigérateurs dotés d’une machine
à glaçons automatique, évitez le contact avec
OHVSLqFHVPRELOHVGXPpFDQLVPHpMHFWHXU
RXDYHFO·pOpPHQWFKDXIIDQWVLWXpjODSDUWLH
LQIpULHXUHGHODPDFKLQHjJODoRQV1HSRVH]
pas les doigts ou les mains sur le mécanisme
GHODPDFKLQHjJODoRQVSHQGDQWTXH
le réfrigérateur est branché.
• Éloignez les doigts des parties du réfrigérateur
où l’on peut facilement se pincer : les espaces
entre les portes et entre les portes et les placards
sont toujours étroits. Soyez prudent lorsque
YRXVIHUPH]OHVSRUWHVGHO·DSSDUHLOHQSUpVHQFH
des enfants.
• Débranchez votre réfrigérateur avant
de le nettoyer et de le réparer. REMARQUE :
Nous vous recommandons vivement de confier
WRXWHUpSDUDWLRQjXQWHFKQLFLHQTXDOLILp
• Avant de remplacer une ampoule grillée,
le réfrigérateur doit être débranché afin
G·pYLWHUWRXWFRQWDFWDYHFXQILOVRXVWHQVLRQ
(Une ampoule grillée peut se briser pendant
O·RSpUDWLRQ
REMARQUE : Lorsque vous placez la commande
sur éteint, l’alimentation électrique de l’ampoule
n’est pas coupée.
• Ne faites pas recongeler des aliments surgelés
qui ont complètement dégelé.
DANGER: RISQUES POUR LES ENFANTS
/HVHQIDQWVSULVDXSLqJHRXPRUWVG·DVSK\[LHVRQW
WRXMRXUVG·DFWXDOLWp/HVDSSDUHLOVGHUpIULJpUDWLRQ
abandonés sont toujours aussi dangereux, même
VLRQQ·DWWHQGTXH´TXHOTXHMRXUVµSRXUV·HQ
débarasser. Si vous ne gardez pas votre ancien
appareil, veuillez suivre les directives ci-dessous
afin de prévenir les accidents.
Avant de vous débarasser de votre vieux
appareil de réfrigération :
• Démontez les portes.
• /DLVVH]OHVFOD\HWWHVHQSODFHDILQG·HPSrFKHU
OHVHQIDQWVGHJULPSHUjO·LQWpULHXU
RÉFRIGÉRANTS
Tous les appareils de réfrigération contiennent
des refrigerants qui, conformément aux lois
fédérales, doivent être enlevés avant toute
pOLPLQDWLRQGHO·DSSDUHLO
Si vous vous débarrassez de vieux appareils de
UpIULJpUDWLRQYpULILH]DXSUqVGHODVRFLpWpTXL
V·RFFXSHGHOHXUpOLPLQDWLRQFHTXHYRXV
devez faire.
SAVE THESE INSTRUCTIONS
,03257$176$)(7<,16758&7,216
HOW TO CONNECT ELECTRICITY
Do not, under any circumstances, cut or remove
the third (ground) prong from the power cord.
For personal safety, this appliance must be
properly grounded.
The power cord of this appliance is equipped
with a 3-prong (grounding) plug which mates
with a standard 3-prong (grounding) wall outlet
to minimize the possibility of electric shock
hazard from this appliance.
Have the wall outlet and circuit checked by
a qualified electrician to make sure the outlet
is properly grounded.
Where a standard 2-prong wall outlet is
encountered, it is your personal responsibility
and obligation to have it replaced with a
properly grounded 3-prong wall outlet.
The refrigerator should always be plugged into
its own individual electrical outlet which has
a voltage rating that matches the rating plate.
This provides the best performance and also
prevents overloading house wiring circuits which
could cause a fire hazard from overheated wires.
Never unplug your refrigerator by pulling
on the power cord. Always grip plug firmly
and pull straight out from the outlet.
Repair or replace immediately all power cords
that have become frayed or otherwise damaged.
Do not use a cord that shows cracks or abrasion
damage along its length or at either end.
When moving the refrigerator away from the wall,
be careful not to roll over or damage the power cord.
USE OF EXTENSION CORDS
Because of potential safety hazards under
certain conditions, we strongly recommend
against the use of an extension cord.
However, if you must use an extension cord, it is
absolutely necessary that it be a UL-listed, 3-wire
grounding type appliance extension cord having
a grounding type plug and outlet and that
the electrical rating of the cord be 15 amperes
(minimum) and 120 volts.
6
7
CONSERVEZ CES DIRECTIVES
0(685(6'(6e&85,7e,03257$17(6
RACCORDEMENT ÉLECTRIQUE
Ne coupez ni retirez en aucun cas la troisième
broche (mise à la terre) de la fiche du cordon
d’alimentation. Pour votre sécurité, cet appareil
doit être correctement mis à la terre.
/HFRUGRQG·DOLPHQWDWLRQGHFHWDSSDUHLOHVW
PXQLG·XQHILFKHjEURFKHVPLVHjODWHUUH
qui se branche dans une prise mural ordinaire
jDOYpROHVPLVHjODWHUUHSRXUUpGXLUHDX
minimum les risques du chocs électriques.
Faites examiner la prise de courant et le circuit
par un électricien qualifié pour vous assurer
TXHODSULVHHVWFRUUHFWHPHQWPLVHjODWHUUH
6LODSULVHPXUDOHHVWGXW\SHVWDQGDUGjDOYpROHV
il vous incombe de la faire remplacer par une prise
jDOYpROHVFRUUHFWHPHQWPLVHjODWHUUH
/DPDFKLQHjJODoRQVGRLWWRXMRXUVrWUH
branché dans sa propre prise de courant,
dont la tension nominale est identique
jFHOOHLQGLTXpHVXUODSODTXHVLJQDOpWLTXH
Cette précaution est recommandée pour garantir
un rendement optimum et éviter une surcharge des
circuits électriques de la résidence, ce qui pourrait
FUpHUXQULVTXHG·LQFHQGLHSDUVXUVFKDXIIHGHVILOV
1HGpEUDQFKH]MDPDLVO·DSSDUHLOHQWLUDQWOHFRUGRQ
G·DOLPHQWDWLRQ6DLVLVVH]IHUPHPHQWODILFKH
du cordon et tirez droit pour la retirer de la prise.
Réparez ou remplacez immédiatement tout cordon
HIILORFKpRXHQGRPPDJp1·XWLOLVH]SDVXQFRUGRQ
IHQGLOOpRXSUpVHQWDQWGHVVLJQHVG·XVXUH
/RUVTXHYRXVGpSODFH]O·DSSDUHLOGXPXUIDLWHV
attention de ne pas la faire rouler sur le cordon
G·DOLPHQWDWLRQDILQGHQHSDVO·HQGRPPDJHU
CORDONS PROLONGATEURS
Nous vous recommandons fortement de ne pas
utíliser de cordons prolongateurs à cause des
risques potentiels qu’ils présentent dans certaines
conditions.
7RXWHIRLVVLYRXVGpFLGH]G·XWLOLVHUWRXWGHPrPH
un cordon prolongateur, il est absolument
QpFHVVDLUHTX·LOV·DJLVVHG·XQFRUGRQjILOVDYHF
PLVHjODWHUUHSRXUDSSDUHLOVpOHFWURPpQDJHUV
homologué UL
aux États-Unis) ou homologué CSA (au Canada),
SRXUYXG·XQHILFKHHWG·XQHSULVHPLVHVjODWHUUH
GHDPSqUHVPLQLPXPHWGHYROWV
8
Temperature
controls
The temperature controls are preset in the factory at 37°F
for the fresh food compartment and 0°F for the freezer
compartment. Allow 24 hours for the temperature to stabilize
to the preset recommended settings.
The temperature controls can display both the SET temperature
as well as the actual temperature in the fresh food and freezer
compartments. The actual temperature may vary slightly
from the SET temperature based on usage and operating
environment.
Setting either or both controls to OFF stops cooling in both
the freezer and fresh food compartments but does not shut
off electrical power to the refrigerator.
NOTE: The refrigerator is shipped with protective film covering
the temperature controls. If this film was not removed during
installation, remove it now.
To change the temperature, press and release
the (warmer) or (colder) pad. The SET light
will come on and the
display will show the set temperature. To change
the temperature, tap either the (warmer) or
(colder) pad until the
desired temperature is displayed. Fresh food
temperatures can be adjusted between 34°F
and 44°F and the freezer temperatures can be
adjusted between -6°F and +6°F.
2QFHWKHGHVLUHGWHPSHUDWXUHKDVEHHQ
set, the temperature display will return to
the actual fresh food and freezer temperatures
after 5 seconds. Several adjustments may
be required. Each time you adjust controls,
allow 24 hours for the refrigerator to reach
the temperature you have set.
To turn the cooling system off, tap
the (warmer) pad for either the fresh food
compartment or the freezer until the
GLVSOD\VKRZV2))To turn the unit back on,
press
the (colder) pad for either the fresh food
compartment or freezer. The SET light will
illuminate on the side you selected. Then press
the (colder) pad again (on the side where
the SET light is illuminated) and it will go to
the preset points of 0°F for the freezer and 37°F
for the fresh food compartment.
2SHUDWLQJ,QVWUXFWLRQV
Stainless Steel Refrigerator
Performance
Air Flow
System
The Performance Air-Flow System is designed to
maximize temperature control in the fresh food
and freezer compartments. This unique special
feature consists of the Air Tower along the top
and back walls of the fresh food compartment
and the Air Tunnel on the bottom portion of
the freezer rear wall. Placing food in front of
the louvers on these components will not affect
performance.
Although the Air Tower and the Air Tunnel
can be removed, doing so will affect temperature
performance. (For removal instructions, on-line,
24 hours a day, contact us at GEAppliances.
com or call 800.444.1845. In Canada, call us at
1.800.561.3344.)
9
How
TurboCool
™
works
TurboCool rapidly cools
the refrigerator compartment in
order to more quickly cool foods. Use
TurboCool when adding
a large amount of food to the
refrigerator compartment, putting away
foods after they have been sitting out at room
temperature
or when putting away warm leftovers. It can
also be used if the refrigerator has been
without power for an extended period.
2QFHDFWLYDWHGWKHFRPSUHVVRUZLOOWXUQRQ
immediately and the fans will cycle on and
off at high speed as needed for 8 hours.
The compressor will continue to run until
the refrigerator compartment cools to
approximately 34°F (1°C), then it will cycle
on and off to maintain this setting. After
8 hours, or if TURBOCOOL is pressed again,
the refrigerator compartment will return
to the original setting.
2WKHU&RQWUROV
Stainless Steel Refrigerator
How to use
TurboCool
1 Press TURBOCOOL. The refrigerator
temperature display will show TC.
2 After TurboCool is complete,
the refrigerator compartment
will return to the original setting.
NOTES:
• The refrigerator temperature cannot
be changed during TurboCool.
• The freezer temperature is not affected during
TurboCool.
• When opening the refrigerator door during
TurboCool, the fans will continue to run if
they have cycled on.
Door Alarm
The door alarm will sound
if either door is open for more than
2 minutes. The beeping sound will
stop when you close the door.
10
Internal Water Dispenser
Stainless Steel Refrigerator
Internal Water
Dispenser
The water dispenser is located on the left wall
inside the refrigerator compartment.
To dispense water:
1 Hold the glass against the recess.
2 Push the water dispenser button.
3 Hold the glass underneath the dispenser
for 2–3 seconds after releasing the dispenser
button. Water may continue to dispense
after the button is released.
If no water is dispensed when the refrigerator is
first installed, there may be air in the water line
system. Press the dispenser button and run 1
1
ø2
gallons to remove trapped air from the water line
and to fill the water system. During this process,
the dispenser noise may be loud as the air is
purged from the water line system. To flush out
impurities in the water line, throw away the first
6 glassfuls of water.
NOTE: To avoid water deposits, the dispenser
should be cleaned periodically by wiping with
a clean cloth or sponge.
Water filter
Water Filter
Stainless Steel Refrigerator
11
ridge
older
Cartridge
Holder
To reduce the risk associated with choking, do not allow children under 3 years of age to have access to small parts
during the installation of this product. The disposable filter cartridge should be replaced every
6 months at the rated capacity, or sooner if a noticeable reduction in flow rate occurs.
For the maximum benefit of your filtration system, GE recommends the use of GE-branded filters only. Using
GE-branded filters in GE and Hotpoint
®
refrigerators provides optimal performance and reliability. GE filters
meet rigorous industry NSF standards for safety and quality that are important for products that are filtering your water. GE has not
qualified non-GE-branded filters for use in GE and Hotpoint refrigerators and there is no assurance
that non-GE-branded filters meet GE's standards for quality, performance and reliability.
If you have questions, or to order additional filter cartridges, visit our website at www.gewaterfilters.com
or call GE Parts and Accessories, 800.626.2002.
Customers in Canada should consult the yellow pages for the nearest Camco Service Center.
WARNING
Water filter cartridge
The water filter cartridge is located in the back upper right corner of
the refrigerator compartment.
When to replace the filter on models
with a replacement indicator light
There is a replacement indicator light for the water filter cartridge
on the dispenser. This light will turn orange to
tell you that you need to replace the filter soon.
The filter cartridge should be replaced when the replacement
indicator light turns red or if the flow of water to the dispenser or
icemaker decreases.
When to replace the filter on models
without a replacement indicator light
The filter cartridge should be replaced every six months
or earlier if the flow of water to the dispenser or
icemaker decreases.
Removing the filter cartridge
If you are replacing the cartridge, first remove the old one
by slowly turning it to the left. Do not pull down on the cartridge. A
small amount of water may drip down.
CAUTION: To reduce the risk associated with property damage due
to water leakage, read and follow instructions before installation
and use of this system. Installation and use MUST comply with all
state and local plumbing codes.
Installing the filter cartridge
1
Fill the replacement cartridge with water from the tap
to allow for better flow from the dispenser immediately
after installation.
2
Line up the arrow on the cartridge and the cartridge holder. Place
the top of the new cartridge up inside the holder.
Do not push it up into the holder.
3
Slowly turn it to the right until the filter
cartridge stops. DO NOT OVERTIGHTEN.
As you turn the cartridge, it will
automatically raise itself into position.
The cartridge will move about a ½ turn.
4
Run water from the dispenser for 1-1/2 gallons (about three
minutes) to clear the system and prevent sputtering.
5
Press and hold the RESET WATER FILTER pad (on some models) on
the dispenser for three seconds.
NOTE: A newly installed water filter cartridge may cause water
to spurt from the dispenser.
Filter bypass plug
Y
ou must use the filter bypass plug when a replacement filter
cartridge is not available. The dispenser and the icemaker will not
operate without the filter or filter bypass plug.
To use the filter bypass plug on Water by Culligan
™
models,
you must first remove the filter adaptor from the cartridge holder by
turning it to the left.
SmartWater
Filter Bypass
Plug
Filter Bypass
Plug
ter
ss
ug
Water by Culligan
The slide-out spillproof shelf allows you to reach
items stored behind others. The special edges
are designed to help prevent spills from dripping
to lower shelves.
To remove:
1 Remove all items from shelf.
2 Slide the shelf out until it stops.
3 Lift the front edge of the shelf until the central
tabs are above the front bar.
4
Continue pulling the shelf forward until
it can be removed.
To replace:
1
Place the rear shelf tabs just in front
of the central notches on the shelf frame.
2 Slide the shelf in until the central tabs
are slightly behind the front bar.
3 Lower the shelf into place until it is horizontal
and slide the shelf in.
Make sure that the shelf sits flat after reinstallation
and doesn’t move freely from side to side.
Make sure you push the shelves all the way
in before you close the door.
12
Rearranging
the shelves
Shelves in the refrigerator compartment
are adjustable.
Refrigerator Compartment
To remove:
1 Remove all items from the shelf.
2 Tilt the shelf up at the front.
3 Lift the shelf up at the back and bring
the shelf out.
To replace:
1
While tilting the shelf up, insert the top hook
at the back of the shelf in a slot on the track.
2 Lower the front of the shelf until the bottom
of the shelf locks into place.
1
Shelves and Bins
Stainless Steel Refrigerator
Slide-out
spillproof
shelf
This shelf splits in half and slides under itself
for storage of tall items on the shelf below.
This shelf can be removed and replaced or
UHORFDWHGMXVWOLNH6OLGH2XW6SLOOSURRI6KHOYHV
2QVRPHPRGHOVWKLVVKHOIFDQQRWEHXVHG
in the lowest position.
QuickSpace
™
shelf
Some models have wire shelves that
can be adjusted in the same manner.
2
1
2
13
To Remove the Full-Width Basket on
Top Freezer Drawer Models:
1 2SHQWKHWRSIUHH]HUGUDZHUXQWLOLWVWRSV
2 The freezer basket rests on the inside tabs
on the drawer slides.
3 Lift the front end of the basket so that the front
two alignment tabs come out of the metal slide
bracket first. Then rotate the front edge of the
basket up while lifting the remaining two rear
alignment tabs out of the metal slide bracket.
4 Make sure the plastic sleeves remain attached
to the 4 slots on the metal slide brackets.
When Replacing the Full-Width Basket:
Tilt the basket back and lower it down into
the drawer. Rotate the basket to a horizontal position
and press it down into the 4 alignment tabs.
NOTE: Always be sure that all 4 basket slots
are engaged in the metal slide brackets before sliding
back into the freezer.
Basket
removal (top
drawer)
Shelves and Bins
Stainless Steel Refrigerator
Appearance may vary
Tab
The freezer basket has a divider that can be both
repositioned or removed.
To Remove the Divider in the Bottom
Freezer Basket:
Pull the divider forward until the rear locating tabs
are out of the slots. Turn the divider slightly to the
side to release the front locating tabs and lift out.
To Replace the Divider in the Bottom
Freezer Basket:
Turn the divider slightly to one side so the tabs on
the front fit into the vent slots on the basket. Position
the divider so the back locating tabs snap into place
in the back vent slots.
To Reposition the Divider
in the Bottom Freezer Basket:
1 Remove the divider as instructed above.
2 Slide the divider left or right to the desired
location and replace as instructed above.
Adjustable
divider in
bottom
freezer
basket
Tabs
To Remove the 2-Piece Basket:
1
2SHQWKHERWWRPIUHH]HUGUDZHUXQWLO
it stops.
2 Pull the divider forward until the rear locating tabs
are out of the slots. Turn the divider slightly to the
side to release the front locating tabs and lift out.
3 The freezer basket rests on the metal slide
brackets and is held in place with swing locks.
4 Turn the swing locks from horizontal to vertical
position.
5 Lift the front of the basket up, rotate it toward
you, and bring it straight up to remove.
6 Lift the back portion of the basket up and out
of the drawer.
When Replacing the 2-Piece Basket:
1
Place the rear of the basket onto the metal slide
brackets. There will be 2 pins on each underside
of the back that will align for securing the
basket.
2
Seat the front of the basket onto the metal slide
brackets and over the swing locks.
3
Turn the swing locks from vertical to horizontal
position to lock the basket in place.
4 Turn the divider slightly to one side so the tabs
on the front fit into the vent slots on the basket.
Position the divider so the back locating tabs
snap into place in the back vent slots.
Shelves and Bins
Stainless Steel Refrigerator
14
Adjustable bins can easily be carried from
refrigerator to work area.
To remove: Lift bin straight up, then pull out.
To replace or relocate: Slide in the bin just above
the molded door supports, and push down.
The bin will lock in place.
The snugger helps prevent tipping, spilling
or sliding of small items stored on the door shelf.
Grip the finger hold near the rear of the snugger
and move it to fit your needs.
Adjustable
bins on
the door
Appearance may vary
Basket removal
(bottom drawer)
To remove: Lift the bin straight up, then
pull out.
To replace: Engage the bin in the molded
supports on the door and push down. It will lock
in place.
Non-
Adjustable
bins on
the door
To remove: Lift the rack straight up, then pull out.
To replace: Engage the rack in the molded
supports on the door and push down. It will lock
in place.
Non-
Adjustable
beverage
rack
15
The doors are factory set for a 150°
door swing. To avoid contact damage
to the refrigerator doors or to adjacent
cabinetry or walls, observe the minimum
clearances shown.
• Allow 4” clearance on each side
to an adjacent wall for a 90° open ing
and access to drawers.
• Allow 15” clearance on each side
to an adjacent wall for removal of drawers.
If the top of the doors are uneven, first try to raise
the lowest door by turning the leveling leg on
the same side as the door until the doors are
even. If the unit rocks, re-adjust the leveling
legs to the extent that the unit is stable.
If the doors remain uneven, turn the adjustable
pin to raise, or lower, the left door to match
the right door. Use a 1/4s Allen wrench
to turn the pin.
Additional Features
Stainless Steel Refrigerator
Door
alignment
Door swing
clearances
15"15"
150˚ Door Swing
90˚ Door Swing
24-5/8"
19-1/16"
Adjustable Pin
Leveling
Leg
Slide the control all the way to the Vegetable
setting to provide high humidity recommended
for most vegetables.
Slide the control all the way to the Fruit setting
to provide lower humidity levels recommended
for most fruits.
16
Crispers and Pans
Stainless Steel Refrigerator
Excess water that may accumulate in the bottom
of the drawers should be wiped dry.
Fruit and
vegetable
crispers
Adjustable
humidity
crispers
The convertible meat pan has its own cold air
duct to allow a stream of cold air from the freezer
compartment to flow to the pan.
The variable temperature control regulates
the air flow from the Climate Keeper.
Set the control to the coldest setting to store
fresh meats.
Set the control to Cold to convert the pan
to normal refrigerator temperature and provide
extra vegetable storage space. The cold air duct
is turned off. Variable settings between these
extremes can be selected.
Convertible
meat pan
To remove:
1 Remove the fruit and vegetable drawers.
2 Pull the drawer out to the stop position.
3 Lift the lid to access the 4 swing locks.
4
Rotate all four swing locks to the unlock
position.
5
Lift the front of the drawer up and out.
To replace:
1 Make sure all four swing locks are in the unlock
position.
2
Place the sides of the drawer into the drawer
supports, making sure the swing locks fit
on the drawer slots.
3
Lock all four swing locks by rotating them
to the lock position.
4
Lower the lid and slide in the drawer.
5
Replace the fruit and vegetable drawers.
Deli pan
removal
Swing Locks –
Unlock Position
Swing Locks –
Lock Position
About the crispers and pans. GEAppliances.com
Not all features are on all models.
How to Remove and Replace the Veg pan frame
To remove:
Pull out the pan by sliding it straight out into a fully
open position.
Remove the pan by lifting the front while continuing to
pull on it.
To replace:
Tilt the rear of the pan downwards (front up).
Insert the pan inside the frame and side track.
Pan wheels should be behind frame wheels.
Slide the pan while tilting the front of it downwards
until the pan is fully engaged.
How to Remove and Replace the Veg Pans
To remove:
Remove all items from the shelf.
Lift approximedely an inch front
of the shelf, disengaging lock.
Slide frame forward to disengage from frame lock
s.
To replace:
Place shelf on side tracks
Slide shelf to the back of the case until
the shelf snaps back into lock.
Make sure that the shelf sits flat after
UHLQVWDOODWLRQDQGGRHVQ·WPRYHIUHHO\VLGHWRVLGH
Make sure to install the frame all the way back to the
case before closing the door.
17
Automatic Icemaker
Stainless Steel Refrigerator
Automatic
icemaker
NOTE: A newly installed refrigerator may take 12 to 24 hours to begin making ice.
The icemaker will produce seven cubes
SHUF\FOH³DSSUR[LPDWHO\²FXEHV
in a 24-hour period, depending on freezer
compartment temperature, room temperature,
number of door openings and other use
conditions.
See below for how to access ice and reach
the power switch.
If the refrigerator is operated before
the water connection is made to the icemaker,
set the power switch in the O (off) position.
When the refrigerator has been connected
to the water supply, set the power switch
to the l (on) position. The icemaker power light
will turn green when the freezer light switch is
pressed in or when the freezer door is closed.
The icemaker will fill with water when it cools to
15°F (–10°C). A newly installed refrigerator may
take 12 to 24 hours to begin making ice cubes.
You will hear a buzzing sound each time
the icemaker fills with water.
Throw away the first few batches of ice to allow
the water line to clear.
Be sure nothing interferes with the sweep
of the feeler arm.
When the bin fills to the level of the feeler arm,
the icemaker will stop producing ice. It is normal
for several cubes to be joined together.
If ice is not used frequently, old ice cubes will
become cloudy, taste stale and shrink.
NOTE: In homes with lower-than-average water
pressure, you may hear the icemaker cycle
multiple times when making one batch of ice.
NOTE: Set the power switch to the O (off) position
if the water supply is shut off.
Feeler Arm
Icemaker
Green
Power Light
Power
Switch
To reach the icemaker power switch, open the top
freezer drawer and remove the full-width basket.
Always be sure to replace the basket.
To access ice, open the bottom freezer drawer.
The ice bucket is located below the mullion. Pull it
forward to access ice.
Accessing ice
and reaching
the power
switch
To access ice.
Ice
Bucket
To reach the power switch.
18
Mullion
19
Care and Cleaning
Stainless Steel Refrigerator
The stainless steel panels and handles can be
cleaned with a commercially available stainless
steel cleaner such as Stainless Steel Magic™.
Stainless Steel Magic is available at Ace, True
Value, Servistar, HWI and other leading stores.
It is also available through GE Parts and
$FFHVVRULHV2UGHUSDUWQXPEHU
WX10X15.
Do not use appliance wax or polish
on the stainless steel.
Cleaning
the outside
To help prevent odors, leave an open box
of baking soda in the fresh food and freezer
compartments.
Unplug the refrigerator before cleaning.
If this is not practical, wring excess moisture
out of sponge or cloth when cleaning around
switches, lights or controls.
8VHZDUPZDWHUDQGEDNLQJVRGDVROXWLRQ³
about a tablespoon (15 ml) of baking soda to
a quart (1 liter) of water. This both cleans and
neutralizes odors. Rinse and wipe dry.
Use of any cleaning solution other than
that which is recommended, especially those
that contain petroleum distillates, can crack
or damage the interior of the refrigerator.
Avoid cleaning cold glass shelves with hot
water because the extreme temperature
difference may cause them to break. Handle
glass shelves carefully. Bumping tempered
glass can cause it to shatter.
Do not wash any plastic refrigerator parts
in the dishwasher.
Cleaning
the inside
Be careful when moving the refrigerator away
from the wall. All types of floor coverings can be
damaged, particularly cushioned coverings and
those with embossed surfaces.
Pull the refrigerator straight out and return it
to position by pushing it straight in. Moving
the refrigerator in a side direction may result
in damage to the floor covering or refrigerator.
When pushing the refrigerator back, make sure
you don’t roll over the power cord or icemaker
supply line.
Behind the
refrigerator
For long vacations or absences, remove food
and unplug the refrigerator. Clean the interior
with a baking soda solution of one tablespoon
(15 ml) of baking soda to one quart (1 liter)
of water. Leave the doors open.
Set the icemaker power switch to the O (off)
position and shut off the water supply to
the refrigerator.
If the temperature can drop below freezing,
have a qualified servicer drain the water supply
system to prevent serious property damage due
to flooding.
Preparing
for vacation
Secure all loose items such as shelves and
drawers by taping them securely in place
to prevent damage.
When using a hand truck to move the
refrigerator, do not rest the front or back of the
refrigerator against the hand truck. This could
damage
the refrigerator. Handle only from the sides
of the refrigerator.
Be sure the refrigerator stays in an upright
position during moving.
Preparing
to move
CAUTION: Light bulbs may be hot.
Setting the controls to OFF does not remove
power to the light circuit.
1 Unplug the refrigerator.
2 Remove the freezer basket for access. The bulb
is located at the rear of the freezer inside a light
shield.
3 To remove, grasp the shield at the top and pull out
to release the tabs at the bottom.
4 After replacing with an appliance bulb of the
same or lower wattage, replace
the shield and freezer basket.
5 Plug the refrigerator back in.
20
Replacing the Light Bulbs
Stainless Steel Refrigerator
Setting the controls to OFF does not remove
power to the light circuit.
1 Unplug the refrigerator.
2 The bulbs are located at the top
of the compartment, inside the light shield.
3 To remove the light shield, pull forward
on the shield to disengage the tabs at the back
of the shield. Pull down to remove the light
shield.
4 After replacing the bulbs with appliance
bulbs of the same or lower wattage, replace
the light shield. When replacing the light shield,
set the front tabs into the appropriate slots
in the front of the shield housing and pull
forward to seat the tabs at the back
of the shield into the housing.
5 Plug the refrigerator back in.
Fresh food
FRPSDUWPHQW³
upper light
Tabs
Appearance may vary
Light
Shield
Freezer light
• You may hear cracking or popping sounds
when the refrigerator is first plugged in.
This happens as the refrigerator cools
to the correct temperature.
• Electronic dampers click open and closed to
provide optimal cooling and energy savings.
• The compressor may cause a clicking or
chirping sound when attempting to restart (this
could take up to 5 minutes).
• The electronic control board may cause
a clicking sound when relays activate
to control refrigerator components.
• Expansion and contraction of cooling coils
during and after defrost can cause a cracking
or popping sound.
• After an icemaking cycle, you may hear
the ice cubes dropping into the ice bucket.
• The flow of refrigerant through the freezer
cooling coils may make a gurgling noise like
boiling water.
• Water dropping on the defrost heater can
cause a sizzling, popping or buzzing sound
during the defrost cycle.
• A water dripping noise may occur
during the defrost cycle as ice melts from
the evaporator and flows into the drain pan.
• Closing the door may cause a gurgling sound
due to pressure equalization.
21
Normal
operating
sounds
Newer refrigerators sound different from older refrigerators. Modern refrigerators have more
features and use newer technology.
CLICKS, POPS,
CRACKS and CHIRPS
Do you hear what I hear? These sounds are normal.
WATER SOUNDS
HUMMM...
WHOOSH...
• The new high efficiency compressor may run
faster and longer than your old refrigerator
and you may hear a high-pitched hum or
pulsating sound while it is operating.
• Sometimes the refrigerator runs for an
extended period, especially when the doors
are opened frequently. This means that
the Frost Guard
™
feature is working
to prevent freezer burn and improve
food preservation.
• You may hear a whooshing sound when
the doors close. This is due to pressure
equalizing within the refrigerator.
• You may hear the fans spinning at high
speeds. This happens when the refrigerator
is first plugged in, when the doors are opened
frequently or when a large amount of food
is added to the refrigerator or freezer
compartments. The fans are helping
to maintain the correct temperatures.
• If either door is open for over 3 minutes,
you may hear the fans come on in order
to cool the light bulbs.
• The fans change speeds in order to provide
optimal cooling and energy savings.
For additional information on normal
icemaker and dispenser operating
sounds, see the Automatic Icemaker
and Internal Water Dispenser
sections.
The Problem Solver
Stainless Steel Refrigerator
22
Questions?
Use this
problem
solver!
PROBLEM POSSIBLE CAUSE
REFRIGERATOR • Refrigerator may be in defrost cycle when motor does not operate for
DOES NOT OPERATE about 30 minutes.
(LWKHURUERWKFRQWUROVVHWWR2))6HWWRDWHPSHUDWXUHVHWWLQJ
• If interior light is not on, refrigerator may not be plugged in at
wall outlet. Push the plug completely into the wall outlet.
• The fuse is blown/circuit breaker is tripped. Replace fuse or reset
the breaker.
• The refrigerator is in showroom mode. Unplug it and plug it back in.
VIBRATION OR • Adjust the rollers as shown in the Installation Instructions.
RATTLING (Slight
vibration is normal.)
MOTOR OPERATES • Normal when refrigerator is first plugged in. Wait 24 hours for
FOR LONG PERIODS the refrigerator to completely cool down.
OR CYCLES ON AND
2IWHQRFFXUVZKHQODUJHDPRXQWVRIIRRGDUHSODFHGLQUHIULJHUDWRU
OFF FREQUENTLY
This is normal.
• Door left open or package holding door open.
• Hot weather or frequent door openings. This is normal.
• Temperature controls set at the coldest setting.
See Temperature Controls.
FRESH FOOD • Temperature controls not set cold enough.
OR FREEZER See Temperature Controls.
COMPARTMENT
• Warm weather or frequent door openings.
TOO WARM
• Door left open for long time.
• Package may be holding door open.
FROST OR ICE • Door left open or package holding door open.
CRYSTALS ON
• Too frequent or too long door openings.
FROZEN FOOD
(Frost within package
is normal.)
DIVIDER BETWEEN • Automatic energy saver system circulates warm liquid around
FRESH FOOD the front edge of the freezer compartment to help prevent condensation
AND FREEZER from forming on the outside.
COMPARTMENTS
FEELS WARM
AUTOMATIC • Icemaker power switch is in the O (off) position.
ICEMAKER
• Water supply turned off or not connected. See Installation Instructions.
DOES NOT WORK
• Freezer compartment too warm. Allow 24 hours for the refrigerator
to completely cool down.
• Piled up cubes in storage bin cause icemaker to shut off.
Level cubes in bin.
• Ice cubes stuck in icemaker (green power light on the icemaker
is blinking). Turn off the icemaker, remove cubes and turn the icemaker
back on.
(Modern refrigerators
with more storage space
and a larger freezer
require more operating
time. They start and stop
often to maintain even
temperatures.)
The Problem Solver
Stainless Steel Refrigerator
23
Questions?
Use this
problem
solver!
PROBLEM POSSIBLE CAUSE
FREQUENT • Icemaker power switch is in the l (on) position, but the water supply
“BUZZING” SOUND to the refrigerator has not been connected. Set the power switch
to the O (off) position. Keeping it in the l (on) position will damage
the water valve.
ICE CUBES HAVE 2OGFXEHVQHHGWREHGLVFDUGHG
ODOR/TASTE
• Ice storage bin needs to be emptied and washed.
• Unsealed packages in fresh food and/or freezer compartments may
be transmitting odor/taste to ice cubes.
• Interior of refrigerator needs cleaning. See Care and Cleaning.
SMALL OR • Water filter clogged. Replace the filter or use the filter bypass plug.
HOLLOW CUBES
SLOW ICE CUBE • Door may have been left open.
FREEZING
• Turn temperature of freezer compartment colder.
See Temperature Controls.
CUBE DISPENSER • Icemaker or water supply turned off. Turn on icemaker or water supply.
DOES NOT WORK
• Ice cubes are frozen to the icemaker feeler arm. Remove the cubes.
• Irregular clumps in the storage bin. Break up with fingertip pressure
and discard remaining clumps. The freezer may be too warm. Adjust
the freezer temperature control colder one step at a time until clumps
do not form.
WATER HAS POOR • Water dispenser has not been used for a long time. Dispense water
TASTE/ODOR until all water in the system has been replenished.
WATER IN FIRST • Normal when refrigerator is first installed. Allow 24 hours for
GLASS IS WARM the refrigerator to completely cool down.
• Water dispenser has not been used for a long time. Dispense water
until all water in the system has been replenished.
• Water system has been drained. Allow several hours for the replenished
water supply to chill.
WATER DISPENSER • Water supply line turned off or not connected.
DOES NOT WORK See the Installation Instructions.
• Water filter clogged. Replace the filter or use the filter bypass plug.
• Air may be trapped in the system. Press the dispenser arm for
at least 2 minutes.
WATER SPURTING • Newly installed filter cartridge. Run 1
1
ø2 gallons from the dispenser
FROM DISPENSER to clear the system.
The Problem Solver
Stainless Steel Refrigerator
24
Questions?
Use this
problem
solver!
PROBLEM POSSIBLE CAUSE
WATER IS NOT • Water in reservoir is frozen. Call for service.
DISPENSED BUT
• Fresh food control setting is too cold. Set to a warmer setting.
ICEMAKER
IS WORKING
NO WATER • Water supply line or shutoff valve is clogged. Call a plumber.
OR ICE CUBE
• Replace the filter or use the filter bypass plug.
PRODUCTION
ORANGE GLOW • Defrost heater is on. This is normal.
IN FREEZER
REFRIGERATOR • Foods with strong odors should be tightly wrapped.
HAS ODOR
• Interior needs cleaning. See Care and Cleaning.
• Keep open box of baking soda in refrigerator; replace every 3 months.
DOOR NOT • Door gasket on hinge side is sticking or folding over. Apply paraffin
CLOSING wax to the face of the gasket.
PROPERLY
• A door bin is hitting a shelf inside the refrigerator. Move the door
bin up one position.
MOISTURE FORMS • Not unusual during periods of high humidity. Wipe surface dry.
ON OUTSIDE OF
• Door left open or package holding door open.
REFRIGERATOR
MOISTURE • Too frequent or too long door openings.
COLLECTS INSIDE
• In humid weather, air carries moisture into refrigerator when doors
are opened.
INTERIOR LIGHT • No power at outlet.
DOES NOT WORK
• Light bulb needs replacing. See Care and Cleaning.
HOT AIR FROM • Normal air flow cooling motor. In the refrigeration process, it is
BOTTOM OF normal that heat be expelled in the area under the refrigerator.
REFRIGERATOR Some floor coverings are sensitive and will discolor at these safe
and normal temperatures.
REFRIGERATOR • Adaptive defrost keeps compressor running during door openings.
NEVER SHUTS OFF This is normal. The refrigerator will cycle off after the door remains
BUT TEMPERATURES closed for two hours.
ARE OK
REFRIGERATOR • Door is open and door alarm is on.
BEEPING
The Problem Solver
Stainless Steel Refrigerator
25
Questions?
Use this
problem
solver!
PROBLEM POSSIBLE CAUSE
ACTUAL • Unit just plugged in. Allow 24 hours for the system to stabilize.
TEMPERATURE
• Door open for too long. Allow 24 hours for the system to stabilize.
NOT EQUAL TO
• Warm food added to refrigerator. Allow 24 hours for the system
SET TEMPERATURE
to stabilize.
• Defrost cycle is in process. Allow 24 hours for the system to stabilize.
SELECTTEMP • Fresh food compartment temperature control is set at the warmest
FEATURE IS setting. This is normal. In order to minimize energy usage,
NOT WORKING the SELECTTEMP feature is disabled when the fresh food
compartment temperature control is set at the warmest setting.
DOORS ARE • Unlevel floor. Adjust rollers then align doors by adjusting the fresh
NOT ALIGNED food compartment hinge. See Installation Instructions.
The Problem Solver
Stainless Steel Refrigerator
26
Performance Data Sheet
SmartWater
™
Filtration System³GE MWF Cartridge
The concentration of the indicated substances in water entering the system was reduced to a concentration less than or equal to the permissible
limit for water leaving the system as specified in NSF/ANSI Standard 42 and Standard 53. System tested and certified by NSF International against
NSF/ANSI Standard 42 and Standard 53 for the reduction of substances listed below.
The following pharmaceutical reduction claims have not been certi¿ed by NSF International or the state of California.
Claims tested and veri¿ed by independent laboratory:
Contaminant
Reduction AvHUDJH,Q¾XHQW
16)VSHFL½HG
Challenge Concentration
Avg %
Reduction
Average Product
Water
Concentration
Max Permissible
Product Water
Concentration
NSF Reduction
Requirements
NSF
Test Report
Atenolol 978 ng/L N/A 99.5% 5.0 ng/L N/A N/A J-00121587
Fluoxetine 907 ng/l N/A 99.4% 5.4 ng/L N/A N/A J-00121587
Ibuprofen 885 ng/L N/A 94.1% 52.3 ng/L N/A N/A J-00121588
Progesterone 1097 ng/L N/A 99.5% 5.0 ng/L N/A N/A J-00121589
Trimethoprim 415 ng/L N/A 99.5% 2.0 ng/L N/A N/A J-00121587
It is essential that the manufacturer’s recommended installation, maintenance and filter replacement requirements be carried out for the product to perform as advertised.
See Installation Manual for Warranty information.
Application Guidelines/Water Supply Parameters
Service Flow 0.5 gpm (21.9 lpm)
Water Supply Potable Water
Water Pressure 40-120 psi (2.8-8.2 bar)
Water Temperature 33°F-100°F (0.6°C-38°C)
Note: While the testing was performed under standard laboratory conditions,
actual performance may vary.
Replacement Cartridge: MWF. For estimated costs of replacement elements
please call 1-800-626-2002 or visit our website at www.geapplianceparts.com.
WARNING
To reduce the risk associated with ingestion of contaminants:
• Do not use with water that is microbiologically unsafe or of unknown quality
without adequate disinfectio
n before and after the system. Systems certL¿ed
for cyst reduction may be used on disinfected water that may contain ¿lterable
cysts. EPA Establishment Number 10350-MN-005.
NOTICE
To reduce the risk associated with property damage due to water leakage:
• Read and follow use instructions before installation and use of this system.
• Installation and use MUST comply with all state and local plumbing codes.
• Do not install if water pressure exceeds 120 psi (8.2 bar). If your water pressure
exceeds 80 psi, you must install a pressure-limiting valve. Contact a plumbing
professional if you are uncertain how to check your water pressure.
• Do not install where water hammer conditions may occur. If water hammer
conditions exist you must install a water hammer arrester. Contact a plumbing
professional if you are uncertain how to check for this condition.
• Do not install on hot water supply lines. The maximum operating water
temperature of this ¿lter system is 100º F (38º C).
• Protect ¿lter from freezing. Drain ¿lter when temperatures drop
below 33ºF (0.6ºC).
•
must be replaced every 6 months at the
rated capacity, or sooner if a noticeable reduction in ÀRw rate occurs.
For conditions of use, health claims certified by the California Department of Public
Health, and replacements, see performance data sheet. California Department
of Public Health Certification #05-1698. The contaminants or other substances
removed or reduced by this water filter are not necessarily in all users’ water.
Capacity 300 Gallons (1,135 Liters). Contaminant Reduction Determined by NSF testing.
Substance Tested
for Reduction AvHUDJH,Q¾XHQW
16)VSHFL½HG
Challenge Concentration
Avg %
Reduction
Average Product
Water
Concentration
Max Permissible
Product Water
Concentration
NSF Reduction
Requirements
NSF
Test Report
Chlorine Taste and Odor 2.0 mg/L 2.0 mg/L ± 10% 97.5% 0.05 mg/L N/A J-00077703
Nominal Particulate
&ODVV,WRP 7,833,333 pts/mL At least 10,000 particles/mL 99.7% 18,617 pts/mL N/A J-00077704
Cyst* 101,000 cysts/L Minimum 50,000 cysts/L 99.99% 1 cyst/L N/A J-00100036
Asbestos 47 MF/L
WR¿EHrV/¿EHrs
grHDWHUWKDQPLQOHQJWK >99% 0)/ N/A J-00077707
Atrazine 0.009 mg/L 0.009 mg/L ± 10% 94.5% 0.0005 mg/L 0.003 mg/L N/A J-00077708
Benzene 0.016 mg/L 0.015 mg/L ± 10%± 96.7% 0.0005 mg/L 0.005 mg/L N/A J-00077717
Carbofuran 0.08 mg/L 0.08 mg/L ± 10% 98.7% 0.001 mg/L 0.04 mg/L N/A J-00077718
Endrin 0.007 mg/L 0.006 mg/L ± 10% 97.1% 0.0002 mg/L 0.002 mg/L N/A J-00100039
Lead @ pH 6.5 0.152 mg/L 0.15 mg/L ± 10% 99.3% 0.001 mg/L 0.010 mg/L N/A J-00077722
Lead @ pH 8.5 0.148 mg/L 0.15 mg/L ± 10% 99.3% 0.001 mg/L 0.010 mg/L N/A J-00077723
Lindane 0.002 mg/L 0.002 mg/L ± 10% 99.0% 0.00002 mg/L 0.0002 mg/L N/A J-00077726
Mercury @ pH 6.5 0.0058 mg/L 0.006 mg/L ± 10% 93.2% 0.0004 mg/L 0.002 mg/L N/A J-00100037
Mercury @ pH 8.5 0.0061 mg/L 0.006 mg/L ± 10% 93.2% 0.0004 mg/L 0.002 mg/L N/A J-00092355
P-Dichlorobenzene 0.222 mg/L 0.225 mg/L ± 10% 99.8% 0.005 mg/L 0.075 mg/L N/A J-00077729
Tetrachloroethylene 0.015 mg/L 0.015 mg/L ± 10% 96.7% 0.0005 mg/L 0.005 mg/L N/A J-00082184
Toxaphene 0.015 mg/L 0.015 mg/L ± 10% 93.2% 0.001 mg/L 0.003 mg/L N/A J-00077730
2,4-D 0.218 mg/L 0.210 mg/L ± 10% 99.5% 0.0009 mg/L 0.07 mg/L N/A J-00085470
*Based on the use of Cryptosporidium parvum oocysts.
Tested and cerWL½ed by NSF International
against NSF/ANSI Standard 42 and
Standard 53 in model GE MWF for the
reduction of the claims speci½Hd on the
performance data sheet.
REPLACEMENT
ELEMENT
27
State of California Department of Public Health
Water Treatment Device
Certificate Number
05-1698
Date Issued: February 2,2010
Modified June 25, 2013
Trademark/Model Designation Replacement Elements
GE MWF MWF
PLWF
Manufacturer: General Electric Company
The water treatment device(s) listed on this certificate have met the testing requirements pursuant to
Section 116830 of the Health and Safety Code for the following health related contaminants:
Microbiological Contaminants and Turbidity Inorganic/Radiological Contaminants
Cysts Asbestos
Lead
Mercury
Organic Contaminants
Carbofuran
Endrin
p-Dichlorobenzene
Benzene
Atrazine
Lindane
Tetrachloroethylene
Toxaphene
2,4- D
Rated Service Capacity 300 gallons Rated Service Flow: 0.5 gallons per minute
Conditions of Certification
Do not use where water is microbiologically unsafe or with water of unknown quality, except that systems
for cyst reduction may be used on disinfected waters that contain filterable cysts.
28
With the purchase of your new Monogram appliance, receive
the assurance that if you ever need information or assistance
IURP*(ZH·OOEHWKHUH$OO\RXKDYHWRGRLVFDOO³WROO IUHH
GE Answer
Center
®
In the USA:
800.626.2000
Whatever your question about any Monogram major appliance, GE Answer Center
®
information
VHUYLFHLVDYDLODEOHWRKHOS<RXUFDOO³DQG\RXUTXHVWLRQ³ZLOOEHDQVZHUHGSURPSWO\DQG
courteously. Call the GE Answer Center
®
Monday to Friday, 8 a.m. to 10 p.m. EST, and Saturday,
8 a.m. to 7 p.m. EST.
OR
Visit our Website at: monogram.com
In Canada, call 1.800.561.3344.
,Q+RPH5HSDLU
Service
In the USA:
800.444.1845
In Canada:
1.800.561.3344
$*(FRQVXPHUVHUYLFHSURIHVVLRQDOZLOOSURYLGHH[SHUWUHSDLUVHUYLFHVFKHGXOHGDWDWLPHWKDW·V
convenient for you. To schedule service, call Monday to Friday, 7 a.m. to 10 p.m. EST, or Saturday
and Sunday, 8 a.m. to 6 p.m. EST. Many GE Consumer Service company- operated locations offer
\RXVHUYLFHWRGD\RUWRPRUURZRUDW\RXUFRQYHQLHQFH2XUIDFWRU\WUDLQHGWHFKQLFLDQVNQRZ
\RXUDSSOLDQFHLQVLGHDQGRXW³VRPRVWUHSDLUVFDQEHKDQGOHGLQMXVWRQHYLVLW
In Canada: Monday to Friday, 7 a.m. to 8 p.m. and Saturday, 8 a.m. to 5 p.m. EDST.
Service
Contracts
In the USA:
800.626.2224
In Canada:
1.800.561.3344
You can have the secure feeling that GE Consumer Service will still be there after your
ZDUUDQW\H[SLUHV3XUFKDVHD*(FRQWUDFWZKLOH\RXUZDUUDQW\LVVWLOOLQHIIHFWDQG\RX·OO
UHFHLYHDVXEVWDQWLDOGLVFRXQW:LWKDPXOWLSOH\HDUFRQWUDFW\RX·UHDVVXUHGRIIXWXUH
VHUYLFHDWWRGD\·VSULFHV
Parts and
Accessories
In the USA:
800.626.2002
In Canada:
1.800.561.3344
Individuals qualified to service their own appliances can have parts or accessories sent directly
to their home. The GE parts system provides access to over 47,000 parts…and all GE Genuine
Renewal Parts are fully warranted. VISA, MasterCard and Discover cards are accepted.
Visit www.geappliances.com.
User maintenance instructions contained in this manual cover procedures intended to be
performed by any user. Other servicing generally should be referred to qualified service
personnel. Caution must be exercised, since improper servicing may cause unsafe operation.
For Customers
With Special
Needs…
In the USA:
800.626.2000
GE offers Braille controls for a variety of GE appliances, and a brochure to
assist in planning a barrier-free kitchen for persons with limited mobility.
Consumers with impaired hearing or speech who have access to a
TDD
or a conventional teletypewriter may call 800.TDD.GEAC (800.833.4322)
to request information or service.
Consumer Services
Stainless Steel Refrigerator
Notes
29
Notes
30
Notes
31
YOUR MONOGRAM REFRIGERATOR WARRANTY
Staple sales slip or cancelled check here. Proof of original
purchase date is needed to obtain service under warranty.
Warranty
Stainless Steel Refrigerator
WHAT IS
COVERED
From the Date
of the Original
Purchase
LIMITED ONE-YEAR WARRANTY
For one year from date of original purchase, we will provide, free of charge, parts and service labor in your home
to repair or replace any part of the refrigerator that fails because of a manufacturing defect.
LIMITED FIVE-YEAR WARRANTY
For five years from date of original purchase, we will provide, free of charge, parts and service labor
in your home to repair or replace any part of the sealed refrigerating system (the compressor, condenser,
evaporator and all connecting tubing) that fails because of a manufacturing defect.
LIMITED THIRTY-DAY WARRANTY ON WATER FILTER CARTRIDGE (Water filter, if included)
From the date of the original purchase we will provide, free of charge, replacement parts for any part
of the water filter cartridge that fails because of a manufacturing defect. During this limited thirty-day warranty,
we will also provide, free of charge, a replacement water filter cartridge.
This warranty is extended to the original purchaser and any succeeding owner for products purchased for
ordinary home use in the 48 mainland states, Hawaii, Washington, D.C. or Canada. If the product is located in an
area where service by a GE Authorized Servicer is not available, you may be responsible for a trip charge or you
may be required to bring the product to an Authorized GE Service location for service. In Alaska the warranty
is the same except that it is LIMITED because you must pay to ship the product to the service shop or for the
VHUYLFHWHFKQLFLDQ·VWUDYHOFRVWVWR\RXUKRPH
All warranty service will be provided by our Factory Service Centers or by our authorized Customer Care
®
servicers during normal working hours.
Should your appliance need service, during warranty period or beyond, in the USA call 800.444.1845.
In Canada: 800.561.3344. Please have your serial number and model number available when calling for service.
Some states/provinces do not allow the exclusion or limitation of incidental or consequential damages,
so the above limitation or exclusion may not apply to you. This warranty gives you specific legal rights, and you
may also have other rights which vary from state to state/province to province. To know what your legal rights
DUHLQ\RXUVWDWHSURYLQFHFRQVXOW\RXUORFDORUVWDWHSURYLQFLDOFRQVXPHUDIIDLUVRIILFHRU\RXUVWDWH·V$WWRUQH\
General.
Warrantor in USA: General Electric Company,
Louisville, KY 40225
Warrantor in Canada: Mabe Canada Inc.
WHAT IS NOT
COVERED
• Service trips to your home to teach you how
to use the product.
• Replacement of house fuses or resetting of circuit
breakers.
• Damage to the product caused by accident, fire,
floods or acts of God.
• Failure of the product if it is used for other than
its intended purpose or used commercially.
• Damage caused after delivery.
• Improper installation, delivery or maintenance.
If you have an installation problem, contact
your dealer or installer. You are responsible for
providing adequate electrical, plumbing and
other connecting facilities.
• Replacement of the light bulbs, if included,
or water filter cartridge, if included, other than
as noted above.
• Replacement of the water filter cartridge,
if included, due to water pressure that is outside
the specified operating range or due to excessive
sediment in the water supply.
• Loss of food due to spoilage (in the USA only).
• Incidental or consequential damage caused
by possible defects with this appliance.
• Product not accessible to provide required
service.
225D1804P009
49-60630-2
Printed in the United States
01-14 GE
(;&/86,212),03/,(':$55$17,(6³<RXUVROHDQGH[FOXVLYHUHPHG\LVSURGXFWUHSDLUDVSURYLGHG
in this Limited Warranty. Any implied warranties, including the implied warranties of merchantability
or fitness for a particular purpose, are limited to one year or the shortest period allowed by law.
