FWD30S
Family Line: 30” Professional Warming drawer
30” Professional Warming drawer / Forza Radical design Aestethics / St.steel
Compatible with FOSP30S and FODP30S ovens
CONTROL
Temperature range 86°F - 194°F / 30°C - 90°C
Fan assisted •
Function Indicator / Thermostat on/off •
PERFORMANCE
Maximum temperature 194°F / 90°C
Cooking at low temperature (slow cooking) •
Leavening •
Heating dishes and food •
Slow close assistance •
Open / Close push - pull system -
ELECTRICAL SPECIFICATIONS
Max power absorbed (W) 1100 W
Power (V/Hz) 120/60
Power cord 59”
Plug NEMA 5 -15P
CAPACITY
Volume 2,1 cbft (61.4 lt)
DIMENSIONS
Overall dim - width 29 7/8” (758 mm)
Overall dim - height 10 3/8” (264 mm)
Overall dim - depth 23” (583 mm)
Door Depth with handle 5 15/16” (151 mm)
Cutout - width 28 7/16” (722 mm)
Cutout - height (min) 9 21/64” (237 mm)
Cutout - depth (min) 24” (610 mm)
TECHNICAL FEATURES
Net Weight 68.5 lbs - 31.0 kg
Gross Weight 75.2 lbs - 34.1 kg
Warranty 2 years parts & labor
for zacucina.com
Specifications updated on 01/12/2021
INSTALLATION TECHNICAL DRAWINGS
Installation below a single oven Installation below a double oven
27-7/8" (707)
23" (583)
29-1/2" (750)
9-1/16" (230)
10-3/8" (264)
29-7/8" (758)
PRODUCT TECHNICAL DRAWING
Electrical Location
24" (610)
9-1/4"
(235)
28-7/16
(722)
1”
24” (610) Min.
Inside
Oven
Cutout
9-1/4”
(235)
28-3/8”
(722)
Allow 5/8”
Overlap on All sides
Min. Above Toekick or Adjust o Oven Installation Height
1”
24” (610) Min. Inside
28-3/8”
(722)
9-1/4”
(235)
Oven
Cutout
Min. Above Toekick
Allow 5/8”
Overlap on All sides
3/4” Min.
(20) Min.
9” 21/64
(237)
9” 21/64
(237)
3/4” Min.
(20) Min.
9” 21/64
(237)
25-3/64” (636)
