NOTE: HVLS blades are not
shown in the assembly to
allow greater detail of parts.
See Figure 14 for finished
assembly.
TRI-LITE HVLS SERIES
CEILING FANS
INSTALLATION INSTRUCTIONS / PLEASE READ AND SAVE THESE INSTRUCTIONS
BEFORE YOU BEGIN
TRI-LITE HVLS-M (04_29_15) Page 1 of 13
See Cable Detail
Drawing
FAN COMPONENTS
CABLE DETAIL
Your kit should include all of the components shown below.
