Pub No. 49-1000209 Rev. 0 02-19 GEA
Write the model and serial numbers here:
Model # _______________________________
Serial # _______________________________
Find these numbers on a label inside the
refrigerator compartment at the top on the right side
behind the controls.
Side by Side Refrigerators
Model: CZS22M
Contents
Safety Information ...............................3
Using the Refrigerator
Controls ......................................5
Water Filter - XWF ..............................6
Shelves and Bins ...............................7
Crispers and Pans ..............................8
Doors ........................................9
Automatic Icemaker ............................10
Ice and Water Dispenser ........................11
Care And Cleaning
The Outside ..................................12
The Inside ...................................12
Behind the Refrigerator .........................12
Preparing for Vacation ..........................13
Preparing to Move .............................13
Replacing the Light Bulbs .......................13
Installation Instructions
Preparing to Install the Refrigerator ................14
Moving the Refrigerator .........................15
Installing the Refrigerator ........................19
Installing the Water Line ........................23
Troubleshooting Tips ...........................26
Limited Warranty ...............................29
Consumer Support
Water Filter Limited Warranty ....................30
Performance Data Sheet ........................31
Consumer Support .............................32
Owner's Manual and Installation Instructions
ENGLISH/FRANÇAIS/ESPAÑOL
TM
49-1000209 Rev. 02
THANK YOU FOR MAKING CAFÉ A PART OF YOUR HOME.
We take pride in the craftsmanship, innovation and design that goes into every Café product, and
we think you will too. Among other things, registration of your appliance ensures that we can deliver
important product information and warranty details when you need them.
Register your Café appliance now online. Helpful websites are available in the Consumer Support
section of this Owner’s Manual. You may also mail in the pre-printed registration card included in the
packing material.
TM
49-1000209 Rev. 0 3
SAFETY INFORMATION
IMPORTANT SAFETY INFORMATION
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE
CAUTION
To reduce the risk of injury when using your refrigerator, follow these basic safety precautions.
Ŷ 'RQRWFOHDQJODVVVKHOYHVRUFRYHUVZLWKZDUP
water when they are cold. Glass shelves and
covers may break if exposed to sudden temperature
changes or impact, such as bumping or dropping.
Tempered glass is designed to shatter into many
small pieces if it breaks.
Ŷ .HHSILQJHUVRXWRIWKH³SLQFKSRLQW´DUHDV
clearances between the doors and between the
doors and cabinet are necessarily small. Be careful
closing doors when children are in the area.
Ŷ 'RQRWWRXFKWKHFROGVXUIDFHVLQWKHIUHH]HU
compartment when hands are damp or wet, skin
may stick to these extremely cold surfaces.
Ŷ 'RQRWUHIUHH]HIUR]HQIRRGVZKLFKKDYHWKDZHG
completely.
Ŷ ,QUHIULJHUDWRUVZLWKDXWRPDWLFLFHPDNHUVDYRLG
contact with the moving parts of the ejector
mechanism, or with the heating element that
releases the cubes. Do not place fingers or hands
on the automatic ice making mechanism while the
refrigerator is plugged in.
Ŷ Use a sturdy glass when dispensing ice (on models with
ice dispenser
READ AND SAVE THESE INSTRUCTIONS
WARNING
To reduce the risk of fire, explosion, electric shock, or injury when using your refrigerator, follow
these basic safety precautions:
Ŷ 7KLVUHIULJHUDWRUPXVWEHSURSHUO\LQVWDOOHG
and located in accordance with the Installation
Instructions before it is used.
Ŷ 8QSOXJWKHUHIULJHUDWRUEHIRUHPDNLQJUHSDLUVRU
cleaning.
NOTE: Power to the refrigerator cannot be
disconnected by any setting on the control panel.
NOTE: Repairs must be performed by a qualified
Service Professional.
Ŷ 5HSODFHDOOSDUWVDQGSDQHOVEHIRUHRSHUDWLQJ
Ŷ 'RQRWXVHDQH[WHQVLRQFRUG
Ŷ 'RQRWVWRUHRUXVHJDVROLQHRURWKHUIODPPDEOH
vapors and liquids in the vicinity of this or any other
appliance.
Ŷ 'RQRWVWRUHH[SORVLYHVXEVWDQFHVVXFKDVDHURVRO
cans with a flammable propellant in this appliance.
Ŷ 7RSUHYHQWVXIIRFDWLRQDQGHQWUDSPHQWKD]DUGV
WRFKLOGUHQUHPRYHWKHIUHVKIRRGDQGIUHH]HU
doors from any refrigerator before disposing of it or
discontinuing its use.
Ŷ 7RDYRLGVHULRXVLQMXU\RUGHDWKFKLOGUHQVKRXOGQRW
stand on, or play in or with the appliance.
Ŷ &KLOGUHQDQGSHUVRQVZLWKUHGXFHGSK\VLFDOVHQVRU\
or mental capabilities or lack of experience and
knowledge can use this appliance only if they are
supervised or have been given instructions on safe
XVHDQGXQGHUVWDQGWKHKD]DUGVLQYROYHG
Ŷ 7KLVDSSOLDQFHLVLQWHQGHGWREHXVHGLQKRXVHKROG
and similar applications such as: staff kitchen areas
LQVKRSVRIILFHVDQGRWKHUZRUNLQJHQYLURQPHQWV
IDUPKRXVHVE\FOLHQWVLQKRWHOVPRWHOVEHG
EUHDNIDVWDQGRWKHUUHVLGHQWLDOHQYLURQPHQWV
catering and similar non-retail applications.
Ŷ &RQQHFWWRSRWDEOHZDWHUVXSSO\RQO\$FROGZDWHU
supply is required for automatic icemaker operation.
The water pressure must be between 40 and 120 psi
(275-827 kilopascals).
Ŷ 'RQRWDSSO\KDUVKFOHDQHUVWRWKHUHIULJHUDWRU
Certain cleaners will damage plastic which may
cause parts such as the door or door handles to
detach unexpectedly. See the Care and Cleaning
section for detailed instructions.
INSTALLATION
WARNING
EXPLOSION HAZARD
.HHSIODPPDEOHPDWHULDOVDQGYDSRUVVXFKDVJDVROLQHDZD\IURPUHIULJHUDWRU)DLOXUHWRGRVRFDQUHVXOWLQILUH
explosion, or death.
49-1000209 Rev. 04
SAFETY INFORMATION
IMPORTANT SAFETY INFORMATION
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE
PROPER DISPOSAL OF YOUR OLD REFRIGERATOR
Do not, under any circumstances, cut or remove the third (ground) prong from the power cord. For
personal safety, this appliance must be properly grounded.
The power cord of this appliance is equipped with a
3-prong (grounding) plug which mates with a standard
SURQJJURXQGLQJZDOORXWOHWWRPLQLPL]HWKH
SRVVLELOLW\RIHOHFWULFVKRFNKD]DUGIURPWKLVDSSOLDQFH
Have the wall outlet and circuit checked by a qualified
electrician to make sure the outlet is properly
grounded.
Where a standard 2-prong wall outlet is encountered, it
is your personal responsibility and obligation to have it
replaced with a properly grounded 3-prong wall outlet.
Do not use an adapter.
The refrigerator should always be plugged into its own
individual electrical outlet which has a voltage rating
that matches the rating plate.
$9ROW$&+]RUDPSIXVHGJURXQGHG
electrical supply is required. This provides the best
performance and also prevents overloading house
ZLULQJFLUFXLWVZKLFKFRXOGFDXVHDILUHKD]DUGIURP
overheated wires.
Never unplug your refrigerator by pulling on the power
cord. Always grip plug firmly and pull straight out from
the outlet.
Immediately discontinue use of a damaged supply
cord. If the supply cord is damaged, it must be
replaced by a qualified service professional with an
DXWKRUL]HGVHUYLFHSDUWIURPWKHPDQXIDFWXUHU
When moving the refrigerator away from the wall, be
careful not to roll over or damage the power cord.
CONNECTING ELECTRICITY
WARNING
ELECTRICAL SHOCK HAZARD
Plug into a grounded 3-prong outlet
Do not remove the ground prong
Do not use an adapter
Do not use an extension cord.
Failure to follow these instructions can result in death, fire, or electrical shock.
WARNING
SUFFOCATION AND ENTRAPMENT HAZARD
Failure to follow these disposal instructions can result in death or serious injury
IMPORTANT: Child entrapment and suffocation
are not problems of the past. Junked or abandoned
refrigerators are still dangerous even if they will sit
IRU³MXVWDIHZGD\V´,I\RXDUHJHWWLQJULGRI\RXUROG
refrigerator, please follow the instructions below to help
prevent accidents.
Before You Throw Away Your Old Appliance
Ŷ7DNHRIIWKHIUHVKIRRGDQGIUHH]HUGRRUV
Ŷ Leave the shelves in place so that children may not
easily climb inside.
Refrigerant and Foam Disposal:
Dispose of appliance in accordance with Federal and Local Regulations. Flammable insulation material used
requires special disposal of your appliance. Contact your local authorities for the environmentally safe disposal of
your appliance.
49-1000209 Rev. 0 5
Controls
Freezer Compartment Temperature Control
$GMXVWIUHH]HUFRPSDUWPHQWWHPSHUDWXUH7KH
IUHH]HUWHPSHUDWXUHLVSUHVHWLQWKHIDFWRU\DW 0°F
(-17.8°C)$OORZKRXUVIRUWHPSHUDWXUHWRVWDELOL]H
to the preset recommended setting.
Fresh Food Compartment Temperature Control
Adjust fresh food compartment temperature. The
fresh food temperature is preset in the factory at
37°F (2.8°C). Allow 24 hours for temperature to
VWDELOL]HWRWKHSUHVHWUHFRPPHQGHGVHWWLQJ
Door Alarm (on some models)
To set the alarm, press this pad until the indicator
light comes on. This alarm will sound if either door is
open for more than 3 minutes. The light goes out and
the beeping stops when you close the door.
LED dispenser Light
Press the Light pad to turn your dispenser light on
and off.
Water Filter
Press and hold 3 seconds to reset the Water Filter
timer.
TurboCool
TM
(on some models)
TurboCool ™ rapidly cools the refrigerator
compartment in order to more quickly cool foods.
Use TurboCool ™ when adding a large amount
of food to the refrigerator compartment, putting
away foods after they have been sitting out at room
temperature or when putting away warm leftovers. It
can also be used if the refrigerator has been without
power for an extended period.
NOTES: The refrigerator temperature cannot be
changed during TurboCool™.
7KHIUHH]HUWHPSHUDWXUHLVQRWDIIHFWHGGXULQJ
TurboCool™.
When opening the refrigerator door during
TurboCool™, the fans will continue to run if they
have cycled on.
Lock Controls
Press and hold the Lock Controls pad for 3
seconds to lock out ice and water dispenser and all
other controls. Press and hold to unlock the controls.
COMPRESSOR
7RWXUQRႇFRPSUHVVRU
5DLVHWKHIUHH]HUWHPSHUDWXUHDERYHWKHKLJKHVW
VHWWLQJE\SUHVVLQJWKH)UHH]HUZDUPHUEXWWRQXQWLOWKH
display starts blinking.
2. Raise the Fresh Food temperature above the highest
setting until you see OFF.
To turn on the compressor:
3UHVV)UHVK)RRGRU)UHH]HUFROGHUEXWWRQ
NOTE: Compartment lights and the user interface
display will stay on.
Model CZS22M
The temperature controls can display both the SET temperature as well as the actual temperature in the refrigerator
DQGIUHH]HU7KHDFWXDOWHPSHUDWXUHPD\YDU\VOLJKWO\IURPWKH6(7WHPSHUDWXUHEDVHGRQXVDJHDQGRSHUDWLQJ
environment.
The temperature controls are preset in the
factory at 37°F (2.8°C) for the refrigerator
compartment and 0°F (-17.8°C) for the
IUHH]HUFRPSDUWPHQW$OORZKRXUVIRU
WKHWHPSHUDWXUHWRVWDELOL]HWRWKHSUHVHW
recommended settings.
USING THE REFRIGERATOR: Controls
49-1000209 Rev. 06
USING THE REFRIGERATOR: Water Filter Cartridge - XWF
Water Filter Cartridge - XWF
Water Filter Cartridge
The water filter cartridge holder is located in the
back upper-right corner of the fresh food refrigerator
compartment.
When to Replace the Filter
If there is a replacement indicator light for the water filter
cartridge on the dispenser, a red light will start blinking to
tell you that you need to replace the filter soon. For
models that don’t have the indicator light, the filter
cartridge should be replaced every six months, or earlier
if the flow of water to the dispenser or icemaker
decreases.
Removing the Filter
If you are replacing the filter, first remove the previous
one by gently grasping the filter and slowly turning it to
the left, about a ¼ turn. The filter should automatically
release itself when you have rotated it far enough to the
left. A small amount of water may drip down.
CAUTION
If air has been trapped in the system,
the filter cartridge may be ejected as it is removed. Use
caution when removing.
Filter Bypass Plug
To reduce the risk of property damage due to water
leakage, you MUST use the filter bypass plug when a
replacement filter cartridge is not available. Some models
do not come equipped with the filter bypass plug. To
obtain a free bypass plug, visit us on-line at
cafeappliances.com/service. In Canada, visit
cafeappliances.ca/service. The dispenser and icemaker
will not operate without either the filter or the bypass plug
installed. The bypass plug is installed in the same way as
DILOWHUFDUWULGJH´
Installing the Filter Cartridge in a Side by
Side Refrigerator
1. Line up the arrow on the filter with the
arrow on the filter cartridge holder.
Gently push the top of the new filter up
inside the holder.
2. Slowly turn the filter to the right until it
stops. DO NOT OVERTIGHTEN. As you
turn the filter, it will automatically raise
itself into position. The filter will move
about a ¼ turn or 90 degrees.
3. Run water from the dispenser for 2 gallons (7.6 liters)
or approximately 5 minutes to clear the system. Water
may spurt out and air bubbles may be visible during
this process.
4. To reset filter, press and hold the WATER FILTER
pad (only on select models) on the dispenser for three
seconds.
Service Flow 0.5 gpm (1.89 lpm)
Water Supply Potable Water
Water Pressure 25-120 psi (172-827 kPa)
Water Temperature 33°F-100°F (0.6°C-38°C)
Capacity 170 gallons (643.5 liters)
Sign-up for TEXT REMINDERS by texting
REPLACE to 70543.
WARNING
To reduce the risk associated with choking, do not allow children under 3 years of age
to have access to small parts during the installation of this product. The disposable filter cartridge should be
replaced every 6 months at the rated capacity, or sooner if a noticeable reduction in flow rate occurs.
For the maximum benefit of your filtration system, GE Appliances, a Haier company, recommends the use of
GE Appliances-branded filters only. Using GE Appliances-branded filters in Café refrigerators provides optimal
performance and reliability. Our filters meet rigorous industry NSF standards for safety and quality that are important
for products that are filtering your water. There is no assurance that brands other than GE Appliances filters meet
our standards for quality, performance and reliability.
If you have questions, or to order additional filter cartridges, visit gewaterfilters.com. In Canada, visit
cafeappliances.ca/service or consult the yellow pages for the nearest Camco Service Center.
Application Guidelines/Water Supply
49-1000209 Rev. 0 7
Not all features are on all models.
Refrigerator Door Bins and Freezer Door Tilt-Out Bins
Large Bins
7KHODUJHUUHIULJHUDWRUGRRUELQVDQGIUHH]HUWLOWRXWGRRU
bins are adjustable.
To remove: Lift the front of the bin straight up, then lift
up and out.
To replace or relocate: Engage the back side of the bin
in the molded supports of the door. Then push down on
the front of the bin. Bin will lock in place.
Small Bins
To remove: Lift the front of the bin straight up then out.
To replace: Position the bin above the rectangular
molded supports on the door. Then slide the bin down
onto the support to lock it in place.
The snugger helps prevent tipping, spilling or sliding of
small items stored on the door shelf. Place a finger on
either side of the snugger near the rear and move it back
and forth to fit your needs.
NOTE: Be careful when placing items in the top bin.
Make sure that items do not block or fall into the ice
chute.
Shelves and Bins
)UHH]HUWLOWRXWELQ Door bins
Ice Chute
Slide-Out Spillproof Shelf
The slide-out spillproof shelf
allows you to reach items
stored behind others. The
special edges are designed
to help prevent spills from
dripping to lower shelves.
To remove: Slide the shelf out
until it reaches the stop, then
press down on the tab and
slide the shelf straight out.
To replace or relocate: Line the shelf up with the
supports and slide it into place. The shelf can be
repositioned when the door is at 90° or more. To
reposition the shelf, slide
the shelf past the stops
and angle downward. Slide
shelf down to the desired
position, line up with the
supports and slide into
place.
Make sure you push the shelves all the way back in
before you close the door.
Press tab and pull shelf
forward to remove
QuickSpace™ Shelf (on some models)
This shelf splits in half and slides under itself for storage
of tall items on the shelf below.
This shelf can be removed and
replaced or relocated just like
Slide-Out Spillproof Shelves.
On some models, this shelf
can not be used in the lowest
position.
Slide-Out Freezer Shelves
To remove, slide the shelf back to the stop position, lift
the left side and slide out from the ribs.
To install the shelf, reverse
these steps. Make sure to push
the shelves all the way back in
before closing the door.
NOTE FOR DISPENSER
MODELS: In order to take full
advantage of the tilt-out ice bin
(on some models), only store
items on the shelf below the ice
bin that are no taller than the
lowest point on the bin.
USING THE REFRIGERATOR: Shelves and Bins
49-1000209 Rev. 08
Not all features are on all models.
Fruit and Vegetable Crispers
Excess water that may accumulate in
the bottom of the drawers should be
wiped dry.
On some models, the bottom drawer
has full extension slides that allow full
access to the drawer.
Adjustable Humidity Crispers
Slide the control all the way to the HI setting to provide
high humidity recommended for most vegetables.
Slide the control all the way to the LO setting to provide
lower humidity levels recommended for most fruits.
Crisper Removal
Crispers can easily be removed by pulling the drawer
straight out and lifting the drawer up and over the stop
location.
If the door prevents you from taking out the drawers, first
try to remove the door bins. If this does not offer enough
clearance, the refrigerator will need to be rolled forward
until the door opens enough to slide the drawers out. In
some cases, when you roll the refrigerator out, you will
need to move the refrigerator to the left or right as you
roll it out.
Crispers and Pans
HI
LO
USING THE REFRIGERATOR: Crispers and Pans
49-1000209 Rev. 0 9
USING THE REFRIGERATOR: Doors
Door Alignment
If doors are uneven, adjust the refrigerator door.
To remove the base grille, open the doors, remove the
screw at each end of the base grille and then pull the
grille straight out.
8VLQJD´VRFNHWZUHQFKWXUQWKHGRRUDGMXVWLQJ
VFUHZWRWKHULJKWWRUDLVHWKHGRRUWRWKHOHIWWR
lower it. (A nylon plug, imbedded in the threads of the
pin, prevents the pin from turning unless a wrench is
used.)
2. After one or two turns of the wrench, open and close
the refrigerator door and check the alignment at the
top of the doors.
Refrigerator Doors (on some models)
The refrigerator doors may feel different than the ones
you are used to. The special door opening/closing
feature makes sure the doors close all the way and are
securely sealed.
When opening and closing the door you will notice a stop
position. If the door is opened past this stop point, the
door will remain open to allow you to load and unload
food more easily. When the door is only partially open, it
will automatically close.
The resistance you feel at the stop position will be
reduced as the door is loaded with food.
Doors
When the door is only partially open,
it will automatically close.
Beyond this stop the door will stay open.
´6RFNHW:UHQFK
Raise
49-1000209 Rev. 010
Not all features are on all models.
Automatic Icemaker
The icemaker will produce seven cubes per cycle—
approximately 100–130 cubes in a 24-hour period,
GHSHQGLQJRQIUHH]HUFRPSDUWPHQWWHPSHUDWXUHURRP
temperature, number of door openings and other use
conditions.
If the refrigerator is operated before the water connection
is made to the icemaker, set the power switch in the
OFF position.
When the refrigerator has been connected to the water
supply, set the power switch to the ON position.
The icemaker will fill with water when it cools to 15°F
(–10°C). A newly installed refrigerator may take 12 to 24
hours to begin making ice cubes.
<RXZLOOKHDUDEX]]LQJVRXQGHDFKWLPHWKHLFHPDNHU
fills with water.
Throw away the first few batches of ice to allow the
water line to clear.
Be sure nothing interferes with the sweep of the feeler
arm.
When the bin fills to the level of the feeler arm, the
icemaker will stop producing ice. It is normal for several
cubes to be joined together.
If ice is not used frequently, old ice cubes will become
cloudy, taste stale and shrink.
CAUTION
Avoid contact with the moving parts of
the ejector mechanism, or with the heating element
(located on the bottom of the ice maker) that releases
the cubes. Do not place fingers or hands on the
automatic ice making mechanism while the refrigerator is
plugged in.
Special note about dispenser models:
Ŷ6RPHPRGHOVKDYHDWLOWRXWLFHELQ7KHELQFDQEH
tilted out as shown in the illustrations, and it will hold
itself up while you take ice out or turn the icemaker
power switch on and off. Be sure to put the bin back in
place before closing the door.
ŶTo restore your ice level from an empty bucket
stage, the following steps are recommended:
1. 12 hours after the first batch of ice has fallen into the
bin, dispense 3 to 4 cubes.
2. After an additional 6 hours, dispense 3 to 4 cubes
again.
These steps will restore your ice level in the shortest
amount of time.
NOTE:
In homes with lower than average water pressure, you
may hear the icemaker cycle multiple times when making
one batch of ice.
Accessing Ice and Reaching the Power
Switch on Dispenser Models
There are two types of ice storage bins on
dispenser models. One has a shelf above the bin, the
other does not.
Special note for models with tilt-out ice bin:
Ŷ7KHVHPRGHOVKDYHDWLOWRXWLFHELQ7KHELQFDQEH
tilted out as shown in the illustrations, and it will hold
itself up while you take ice out or turn the icemaker
power switch on and off. Be sure to put the bin back in
place before closing the door.
NOTE: In order to take full advantage of the tilt-out ice
bin, only store items on the shelf below the ice bin that
are no taller than the lowest point on the bin.
To access ice, pull the bin
forward.
To reach the power switch,
pull the shelf straight out.
Always be sure to replace the
shelf.
Removing Ice Bin (dispenser models)
CAUTION
The ice bin is heavy when full.
Set the power switch to
the OFF position before
removing the bin.
When replacing the bin, be
sure to press it firmly into
place. If it does not go all
the way back, remove it and
rotate the drive mechanism
1/4 turn. Then push the bin
back again.
Automatic Icemaker
Icemaker
Feeler Arm
Power
Switch
USING THE REFRIGERATOR: Automatic Icemaker
Shelf
Ice Bin
Shelf
Rotate
Drive
Mechanism
Dispenser Models only
49-1000209 Rev. 0 11
USING THE REFRIGERATOR: Ice and Water Dispenser
Using the Dispenser
Select CUBED, CRUSHED,
or WATER .
Press the glass gently against
the top of the dispenser
cradle.
The spill shelf is not self-
draining. To reduce water
spotting, the shelf and its grille
should be cleaned regularly.
If no water is dispensed
when the refrigerator is first
installed, there may be air in
the water line system. Press
the dispenser arm for at least two minutes to remove
trapped air from the water line and to fill the water
system. To flush out impurities in the water line, throw
away the first six glassfuls of water.
CAUTION
Laceration Hazard
Ŷ1HYHUSXWILQJHUVRUDQ\RWKHUREMHFWLQWRLFHFUXVKHU
discharge opening. Doing so can result in contacting
the ice crushing blades and lead to serious injury or
amputation
Ŷ8VHDVWXUG\JODVVZKHQGLVSHQVLQJLFH$GHOLFDWH
glass may break and result in personal injury.
Locking the Dispenser
Press the Lock Controls pad for 3 seconds
to lock the dispenser and control panel. To
unlock, press and hold the pad again for 3
seconds.
Dispenser Light
This pad turns the light in the dispenser on
and off. The light also comes on when the
dispenser cradle is pressed. For models
with a bulb, if the light burns out, it should
be replaced with a 6 watt 12V maximum
bulb. For LED models, contact Factory
Service.
Quick Ice (on some models)
When you need ice in a hurry, press this
pad to speed up ice production. This will
increase ice production for the following
48 hours or until you press the pad again.
Door Alarm (on some models)
To set the alarm, press this pad until the
indicator light comes on. This alarm will
sound if either door is open for more than
3 minutes. The light goes out and the
beeping stops when you close the door.
Water Filter (on some models)
The Filter Indicator Light will turn yellow
when the filter is nearing expiration., and
red when the filter is expired. After you
replace the water filter, press and hold
the Reset Filter pad for 3 seconds until
the light turns off to reset the timer.
Ice and Water Dispenser (on some models.)
Important Facts About Your Dispenser
Ŷ Do not add ice from trays or bags to the storage
drawer. It may not crush or dispense well.
Ŷ Avoid overfilling glass with ice and use of narrow
glasses. Backed-up ice can jam the chute or cause
WKHGRRULQWKHFKXWHWRIUHH]HVKXW,ILFHLVEORFNLQJ
the chute, poke it through with a wooden spoon.
Ŷ Beverages and foods should not be quick-chilled
in the ice storage drawer. Cans, bottles or food
packages in the storage drawer may cause the
icemaker or auger to jam.
Ŷ To keep dispensed ice from missing the glass, put
the glass close to, but not touching, the dispenser
opening.
Ŷ Some crushed ice may be dispensed even though
you selected CUBED ICE. This happens occasionally
when a few cubes accidentally get directed to the
crusher.
Ŷ After crushed ice is dispensed, some water may drip
from the chute.
Ŷ Sometimes a small mound of snow will form on the
door in the ice chute. This condition is normal and
usually occurs when you have dispensed crushed ice
repeatedly. The snow will eventually evaporate.
Spill Shelf
49-1000209 Rev. 012
Care and Cleaning
Cleaning the Outside
The dispenser drip area, (on some
models) beneath the grille, should be
wiped dry. Water left in this area may
leave deposits. Remove the deposits
by adding undiluted vinegar to the well.
Soak until the deposits disappear or
become loose enough to rinse away.
The dispenser cradle (on some models). Before
cleaning, lock the dispenser by pressing and holding the
LOCK pad for 3 seconds. Clean with warm water and
baking soda solution—about a tablespoon (15 ml) of
baking soda to a quart (1 l) of water. Rinse thoroughly
and wipe dry.
Cleaning the Inside
To help prevent odors, leave an open box of baking
VRGDLQWKHIUHVKIRRGDQGIUHH]HUFRPSDUWPHQWV
Unplug the refrigerator before cleaning. If this is not
practical, wring excess moisture out of sponge or cloth
when cleaning around switches, lights or controls.
Use warm water and baking soda solution— about a
tablespoon (15 ml) of baking soda to a quart (1 liter) of
ZDWHU7KLVERWKFOHDQVDQGQHXWUDOL]HVRGRUV5LQVHDQG
wipe dry.
Use of any cleaning solution other than that which
is recommended, especially those that contain
petroleum distillates, can crack or damage the
interior of the refrigerator.
CAUTION
Do not clean glass shelves or covers
with warm water when they are cold. Glass shelves and
covers may break if exposed to sudden temperature
changes or impact such as bumping or dropping.
Tempered glass is designed to shatter into many small
pieces if it breaks.
Do not wash any plastic refrigerator parts in the
dishwasher.
The chill/thaw tray is dishwasher safe.
CARE AND CLEANING
Directions for Cleaning Outside Surfaces, Door Handles, and Trim
DO USE DO NOT USE
Soft, clean cloth or sponge Abrasive cloths, scrubbing sponges, scouring or steel
wool pads
Mild detergent mixed with warm water
$SSURYHGVWDLQOHVVVWHHOFOHDQHUV9LVLWWKH&DIp
Appliances parts store for approved stainless steel
cleaners: cafeappliances.com/parts
&OHDQHUVZLWKR[DOLFDFLGVXFKDV%DU.HHSHUV)ULHQG6RIW
Cleanser™ can be used to remove surface rust, tarnish
and small blemishes on stainless steel surfaces only.
Abrasive powders or sprays
Window Sprays or Ammonia
Citrus or plant oil-based cleaners
Acidic or vinegar-based cleaners
Oven cleaners
Cleaners containing acetone (propanone)
Any cleaner with WARNING about plastic contact
NOTE: DO NOT allow stainless steel cleaner to come in contact with any plastic parts such as trim pieces, handle
hardware and liners. If unintentional contact of cleaners with plastic parts does occur, clean plastic part with a
sponge and mild detergent mixed with warm water.
49-1000209 Rev. 0 13
Behind the Refrigerator
Be careful when moving the refrigerator away from
the wall. All types of floor coverings can be damaged,
particularly cushioned coverings and those with
embossed surfaces.
Pull the refrigerator straight out and return it to position
by pushing it straight in. Moving the refrigerator in a side
direction may result in damage to the floor covering or
refrigerator.
When pushing the refrigerator back, make sure you
don’t roll over the power cord or icemaker supply line (on
some models).
CARE AND CLEANING
Care and Cleaning
Preparing for Vacation
For long vacations or absences, remove food and
unplug the refrigerator. Clean the interior with a baking
soda solution of one tablespoon (15 ml) of baking soda
to one quart (1 liter) of water. Leave the doors open.
Set the icemaker power switch to the OFF position and
shut off the water supply to the refrigerator.
,IWKHWHPSHUDWXUHFDQGURSEHORZIUHH]LQJKDYHD
qualified servicer drain the water supply system (on
some models) to prevent serious property damage due
to flooding.
Preparing to Move
Secure all loose items such as shelves and drawers by
taping them securely in place to prevent damage.
When using a hand truck to move the refrigerator, do not
rest the front or back of the refrigerator against the hand
truck. This could damage the refrigerator. Handle only
from the sides of the refrigerator.
Be sure the refrigerator stays in an upright position
during moving.
Replacing the lights on models with LED lighting (on some models)
Setting the controls to OFF does not remove power to
the light circuit. Not all features are on all models.
Refrigerator Compartment
There is an LED lighting display in the top and sides of
the fresh food compartment and in the rear and side of
WKHIUHH]HUFRPSDUWPHQWRQVRPHPRGHOV
If this assembly needs to be replaced, schedule service
on-line at cafeappliances.com/service.
LED
Lighting
Display
49-1000209 Rev. 014
Installation Instructions
Refrigerator Models
CZS22M
BEFORE YOU BEGIN
Read these instructions completely and
carefully.
•
IMPORTANT — Save these instructions
for local inspector’s use
•
IMPORTANT — Observe all governing
codes and ordinances.
• Note to Installer – Be sure to leave these
instructions with the Consumer.
• Note to Consumer –.HHSWKHVHLQVWUXFWLRQVIRU
future reference.
• Skill level – Installation of this appliance requires
basic mechanical skills.
• Completion time – Refrigerator Installation
30 minutes
Water Line Installation
30 minutes
• Proper installation is the responsibility of the
installer.
• Product failure due to improper installation is not
covered under the Warranty.
If the refrigerator has already been installed, remove
the base grille (see Step 2 in Moving the Refrigerator),
then skip to Step 5 in Installing the Refrigerator.
PREPARATION
WATER SUPPLY TO THE ICEMAKER
(on some models)
If the refrigerator has an icemaker, it will have to be
connected to a cold water line. A water supply kit is
available at extra cost from your dealer or
by visiting our
website at cafeappliances.com/parts. In Canads,
visit cafeappliances.ca/parts.
TOOLS YOU WILL NEED
Phillips Head Screwdriver
´DQG´6RFNHW ´DQG´:UHQFK
3ODVWLF3XWW\.QLIH
Questions? Visit our Website at: cafeappliances.com
In Canada, visit cafeappliances.ca
INSTALLATION INSTRUCTIONS
49-1000209 Rev. 0 15
INSTALLATION INSTRUCTIONS
Installation Instructions
MOVING THE REFRIGERATOR
LOADING THE REFRIGERATOR
ONTO A HAND TRUCK
Leave all tape and door pads on doors until the
refrigerator is in its final location.
To move the refrigerator, use a padded hand
truck. Center the refrigerator on the hand truck
and secure the strap around the refrigerator.
DO NOT OVERTIGHTEN THE STRAP.
1
REMOVE THE BASE GRILLE
Remove the grille by removing the two
Phillips head screws.
2
If the refrigerator must go through any
HQWUDQFHWKDWLVOHVVWKDQ´ZLGHWKH
doors must be removed. Proceed to
Step 3.
DO NOT remove the handles.
,IDOOHQWUDQFHVDUHPRUHWKDQ´ZLGH
skip to Installing the Refrigerator.
CAUTION
Lifting Hazard.
Single person lift can cause injury. Use assistance
when handling, moving or lifting the refrigerator
doors.
NOTE: When moving door, to prevent damage to
door and electronics carefully place the door in a
proper location.
WARNING
To reduce the risk of electric shock
or injury during installation, you must first unplug the
refrigerator before proceeding. Failure to follow these
instructions can result in electrical shock.
49-1000209 Rev. 016
DISCONNECT THE WATER
COUPLING (on some models)
If the refrigerator has a water dispenser,
there is a water line from the cabinet into the
ERWWRPKLQJHRQWKHIUHH]HUGRRUWKDWPXVWEH
disconnected.
To disconnect, push in on the white collar of the
coupling and pull out the tubing.
White collar
Bottom
IUHH]HU
hinge
3
Installation Instructions
MOVING THE REFRIGERATOR (Cont.)
DISCONNECT THE POWER
COUPLING (on some models)
If the refrigerator has a water dispenser,
there is a power line (harness) from the cabinet
LQWRWKHERWWRPKLQJHRQWKHIUHH]HUGRRUWKDW
must be disconnected.
To disconnect, pull apart at the coupling.
4
Bottom
IUHH]HU
hinge
DISCONNECT THE ELECTRICAL
CONNECTORS (on some models)
If the refrigerator has a refreshment center,
there are electrical connectors (harnesses)
from the cabinet into the bottom hinge on the
refrigerator door that must be disconnected.
To disconnect, pull apart each connector.
5
Bottom
refrigerator
hinge
CLOSE THE FREEZER AND
REFRIGERATOR DOORS
6
INSTALLATION INSTRUCTIONS
49-1000209 Rev. 0 17
INSTALLATION INSTRUCTIONS
Installation Instructions
MOVING THE REFRIGERATOR (Cont.)
D
E
REMOVE THE REFRIGERATOR
DOOR
WARNING
Follow all steps for removing
and reinstalling the door. Failure to follow these
instructions, leaving off parts, or overtightening
screws, can lead to the door falling off and result
in injury and property damage.
Remove the refrigerator door top hinge cover (if
HTXLSSHGE\HLWKHUVTXHH]LQJLWDQGSXOOLQJLW
up or by prying it off with a plastic putty knife.
5HPRYHWKHWZR´KH[KHDGVFUHZVWKHQ
lift the hinge straight up to free the hinge pin.
Open the refrigerator door to 90.°
8
A
B
C
REMOVE THE FREEZER DOOR
WARNING
Follow all steps for removing
and reinstalling the door. Failure to follow these
instructions, leaving off parts, or overtightening
screws, can lead to the door falling off and result
in injury and property damage.
5HPRYHWKHIUHH]HUGRRUWRSKLQJHFRYHULI
HTXLSSHGE\HLWKHUVTXHH]LQJLWDQGSXOOLQJLW
up or by prying it off with a plastic putty knife.
5HPRYHWKHWZR´KH[KHDGVFUHZVWKHQ
lift the hinge straight up to free the hinge pin.
2SHQWKHIUHH]HUGRRUWR.°
$VRQHSHUVRQVORZO\OLIWVWKHIUHH]HUGRRUXS
and off the bottom hinge, the second person
should carefully guide the water line and power
line (harness) through the bottom hinge.
Set the door on a non-scratching surface with
the inside up.
7
A
C
B
´+H[+HDG
90°
90°
´+H[+HDG
90°
49-1000209 Rev. 018
Installation Instructions
MOVING THE REFRIGERATOR (Cont.)
REMOVE THE REFRIGERATOR
DOOR (Cont.)
Lift the refrigerator door up and off the bottom
hinge.
If the refrigerator has a refreshment center, one
person should slowly lift the door up and off the
bottom hinge and the second person should
carefully guide the electrical lines (harnesses)
through the bottom hinge.
Set the door on a non-scratching surface with
the inside up.
8
90°
Refreshment Center Models only
D
E
REPLACING THE DOORS
WARNING
Follow all steps for removing
and reinstalling the door. Failure to follow these
instructions, leaving off parts, or overtightening
screws, can lead to the door falling off and result
in injury and property damage.
To replace the doors, simply reverse steps 3
through 8.
However, please note the following:
• When lowering the doors onto the bottom
hinges, make sure the second person carefully
guides the tube and harnesses through the
holes in the hinges.
• When connecting the water line, make sure
you insert the tubing all the way to the mark.
• Do not pinch the tubing and harnesses when
placing the doors on the bottom hinges.
• When connecting the power line and the
electrical lines (refreshment center models
only), be sure that the connectors are seated
together fully.
9
Mark
INSTALLATION INSTRUCTIONS
49-1000209 Rev. 0 19
INSTALLATION INSTRUCTIONS
Installation Instructions
INSTALLING THE REFRIGERATOR
DIMENSIONS AND SPECIFICATIONS
REFRIGERATOR LOCATION
• Do not install the refrigerator where the
temperature will go below 60°F (16°C) because
it will not run often enough to maintain proper
temperatures.
• Do not install the refrigerator where the
temperature will go above 100°F (37°C) because it
will not perform properly.
• Do not install the refrigerator in a location exposed to
water (rain, etc.) or direct sunlight.
• Install it on a floor strong enough to support it fully
loaded.
If installed against a wall, allow clearance of 14-3/16" on
freezer side to remove bin.
Clearance required to remove fresh food full-size pan without
disassembling is 18-15/16".
Allow additional space for any necessary leveling adjustments.
A
G
D
C
F
B
E
H
Height to top of hinge (in.)
CZS22M
Models
A
Height to top of case (in.) B
Case depth without door (in.) C
Case depth less door handle (in.) D
Case depth with door handle (in.) E
'HSWKZLWKIUHVKIRRGGRRURSHQÛLQF
Width (in.) G
:LGWKZLWKGRRURSHQÛZLWKGRRUKDQGOHLQH
Each side (in.)
Top (in.)
Back (in.)
AIR
CLEARANCES
OVERALL
DIMENSIONS
70-1/8
69
24
28-3/4
29-3/8
46-1/2
36-1/4
42-1/4
1/8
1
2
49-1000209 Rev. 020
Installation Instructions
INSTALLING THE REFRIGERATOR (Cont.)
CONNECTING THE
REFRIGERATOR TO THE HOUSE
WATER LINE
(icemaker and dispenser models)
A cold water supply is required for automatic
icemaker and dispenser operation. If there is
not a cold water supply, you will need to provide
RQH6HH³,QVWDOOLQJWKH:DWHU/LQH´VHFWLRQ
NOTES:
• Before making the connection to the
refrigerator, be sure the refrigerator power
cord is not plugged into the wall outlet.
• If your refrigerator does not have a water filter,
we recommend installing one if your water
supply has sand or particles that could clog
the screen of the refrigerator’s water valve.
Install it in the water line near the refrigerator.
If using Universal Water Line Refrigerator
7XELQJ.LW you will need an additional tube
(WX08X10002) to connect the filter. Do not cut
plastic tube to install filter.
If you are using copper tubing, place a
compression nut and ferrule (sleeve) onto the
end of the tubing coming from the house cold
water supply.
If you are using the Universal Water Line tubing,
the nuts are already assembled to the tubing.
If you are using copper tubing, insert the end
of the tubing into the refrigerator connection, at
the back of the refrigerator, as far as possible.
While holding the tubing, tighten the fitting.
If you are using Universal Water Line tubing,
insert the molded end of the tubing into the
refrigerator connection, at the back of the
refrigerator, and tighten the compression nut
until it is hand tight. Then tighten one additional
turn with a wrench. Overtightening may cause
leaks.
WARNING
Connect to potable water supply only.
A cold water supply is required for automatic
icemaker operation. The water pressure
must be between 40 and 120 psi (275-827
kilopascals).
WARNING
ELECTRIC SHOCK
HAZARD
Attach tubing clamp using existing hole only.
DO NOT drill into the refrigerator.
1
A
B
Fasten the tubing into the clamp provided to
hold it in position. You may need to pry open
the clamp.
C
TURN ON THE WATER SUPPLY
Turn the water on at the
shutoff valve (house water
supply) and check for any
leaks.
2
PLUG IN THE REFRIGERATOR
Before plugging in the
refrigerator, make sure the
icemaker power switch is set to
the OFF position.
See the grounding information
attached to the power cord.
3
Option 2
Option 1
Universal Water
Line Tubing
Refrigerator
Connection
INSTALLATION INSTRUCTIONS
PUT THE REFRIGERATOR IN
PLACE
Move the refrigerator to its final location.
4
49-1000209 Rev. 0 21
INSTALLATION INSTRUCTIONS
Installation Instructions
INSTALLING THE REFRIGERATOR (Cont.)
LEVEL THE REFRIGERATOR
The refrigerator can be leveled by adjusting the
rollers located near the bottom hinges.
Rollers have three purposes:
• Rollers adjust so the door closes easily when
opened about halfway. (Raise the front about
´>PP@IURPWKHIORRU
• Rollers adjust so the refrigerator is firmly
positioned on the floor and does not wobble.
• Rollers allow you to move the refrigerator
away from the wall for cleaning.
To adjust the rollers on 23’ (33” wide),
25’ models:
• Turn the roller adjusting screws clockwise
to raise the refrigerator, counterclockwise to
ORZHULW8VHD´KH[VRFNHWRUZUHQFKRU
an adjustable wrench.
5
Rollers
Raise
Roller adjusting screw
LEVEL THE DOORS
Adjust the refrigerator door to make the doors
even at the top.
To align:
8VLQJD´ZUHQFKWXUQWKHGRRUDGMXVWLQJ
screw to the right to raise the door, to the left to
lower it.
NOTE:
A nylon plug, imbedded in the threads of the
pin, prevents the pin from turning unless a
wrench is used.
After one or two turns of the wrench, open
and close the refrigerator door and check the
alignment at the top of the doors.
6
A
B
Doors should be even at top
Raise
´ZUHQFK
49-1000209 Rev. 022
Installation Instructions
INSTALLING THE REFRIGERATOR (Cont.)
REPLACE THE BASE GRILLE
Replace the grille by installing the two Phillips
head screws.
7
SET THE CONTROLS
Set the controls to the recommended setting.
8
START THE ICEMAKER
Set the icemaker power switch to the I (on)
position. The icemaker will not begin to operate
until it reaches its operating temperature of 15°F
(–9°C) or below. It will then begin operation
automatically. It will take 2–3 days to fill the ice
bin.
NOTE:
In lower water pressure conditions, the water
valve may turn on up to 3 times to deliver
enough water to the icemaker.
9
Power
switch
INSTALLATION INSTRUCTIONS
49-1000209 Rev. 0 23
INSTALLATION INSTRUCTIONS
Installation Instructions
INSTALLING THE WATER LINE (icemaker & dispenser models)
BEFORE YOU BEGIN
If the water supply to the refrigerator is from
a Reverse Osmosis Water Filtration System
AND the refrigerator also has a water filter, use
the refrigerator’s filter bypass plug. Using the
refrigerator’s water filtration cartridge in conjunction
with the RO filter can result in hollow ice cubes and
slower water flow from the water dispenser.
This water line installation is not warranted by
the refrigerator or icemaker manufacturer. Follow
WKHVHLQVWUXFWLRQVFDUHIXOO\WRPLQLPL]HWKHULVNRI
expensive water damage.
Water hammer (water banging in the pipes) in
house plumbing can cause damage to refrigerator
parts and lead to water leakage or flooding. Call a
qualified plumber to correct water hammer before
installing the water supply line to the refrigerator.
To prevent burns and product damage, do not hook
up the water line to the hot water line.
If you use your refrigerator before connecting the
water line, make sure the icemaker power switch is
in the OFF position.
Do not install the icemaker tubing in areas where
WHPSHUDWXUHVIDOOEHORZIUHH]LQJ
When using any electrical device (such as a power
drill) during installation, be sure the device is double
insulated or grounded in a manner to prevent the
KD]DUGRIHOHFWULFVKRFNRULVEDWWHU\SRZHUHG
All installations must be in accordance with local
plumbing code requirements.
WHAT YOU WILL NEED
• Copper or Universal Water Line Refrigerator
7XELQJ.LW´RXWHUGLDPHWHUWRFRQQHFWWKH
refrigerator to the water supply. If using copper, be
sure both ends of the tubing are cut square.
To determine how much tubing you need: measure
the distance from the water valve on the back of the
refrigerator to the water supply pipe. Be sure there
is sufficient extra tubing to allow the refrigerator to
move out from the wall after installation.
8QLYHUVDO:DWHU/LQH5HIULJHUDWRU7XELQJ.LWs are
available in the following lengths:
6’ (1.8 m) – WX08X10006
15’ (4.6 m) – WX08X10015
25’ (7.6 m) – WX08X10025
WARNING
Connect to potable water supply only.
A cold water supply is required for automatic
icemaker operation. The water pressure must be
between 40 and 120 psi (275-827 kilopascals).
49-1000209 Rev. 024
Installation Instructions
INSTALLING THE WATER LINE (Cont.)
WHAT YOU WILL NEED (Cont.)
NOTE: The only GE Appliances, a Haier company,
approved plastic tubing is that supplied in Universal
Water Line Refrigerator Tubing kits. Do not use any
other plastic water supply line because the line is
under pressure at all times. Certain types of plastic
will crack or rupture with age and cause water
damage to your home.
• A water supply kit (containing tubing, shutoff valve
and fittings listed below) is available at extra cost
from your dealer or from cafeappliances.com/
parts. In Canada, visit cafeappliances.ca/parts.
• A cold water supply. The water pressure must be
between 20 and 120 p.s.i. (138-827 kPa).
• Power drill.
• 1/2” or adjustable wrench.
• Straight and Phillips blade screwdriver.
• Two 1/4” outer diameter compression nuts and
2 ferrules (sleeves)—to connect the copper tubing
to the shutoff valve and the refrigerator water valve.
OR
• If you are using a Universal Water Line Refrigerator
Tubing kit, the necessary fittings are preassembled
to the tubing.
• If your existing copper water line has a flared fitting
at the end, you will need an adapter (available at
plumbing supply stores) to connect the water line to
the refrigerator OR you can cut off the flared fitting
with a tube cutter and then use a compression
fitting. Do not cut formed end from Universal Water
Line Refrigerator tubing.
• Shutoff valve to connect to the cold water line.
The shutoff valve should have a water inlet
ZLWKDPLQLPXPLQVLGHGLDPHWHURI´DWWKH
point of connection to the COLD WATER LINE.
Saddle-type shutoff valves are included in many
water supply kits. Before purchasing, make sure
a saddle-type valve complies with your local
plumbing codes.
SHUT OFF THE MAIN WATER
SUPPLY
Turn on the nearest faucet long enough to clear
the line of water.
CHOOSE THE VALVE
LOCATION
Choose a location for the valve that is easily
accessible. It is best to connect into the side of
a vertical water pipe. When it is necessary to
FRQQHFWLQWRDKRUL]RQWDOZDWHUSLSHPDNHWKH
connection to the top or side, rather than at the
bottom, to avoid drawing off any sediment from
the water pipe.
DRILL THE HOLE FOR THE
VALVE
'ULOOD´KROHLQWKHZDWHUSLSHHYHQLIXVLQJ
a self-piercing valve), using a sharp bit. Remove
any burrs resulting from drilling the hole in the
pipe.
Take care not to allow water to drain into the
drill.
)DLOXUHWRGULOOD´KROHPD\UHVXOWLQUHGXFHG
ice production or smaller cubes.
1
2
3
Install the shutoff valve on the nearest frequently used
drinking water line.
INSTALLATION INSTRUCTIONS
49-1000209 Rev. 0 25
INSTALLATION INSTRUCTIONS
FASTEN THE SHUTOFF VALVE
Fasten the shutoff valve to the cold water pipe
with the pipe clamp.
NOTE: Commonwealth of Massachusetts
Plumbing Codes 248CMR shall be adhered to.
Saddle valves are illegal and use is not permitted
in Massachusetts. Consult with your licensed
plumber.
TIGHTEN THE PIPE CLAMP
Tighten the clamp screws until the sealing
washer begins to swell.
NOTE: Do not overtighten or you may crush the
tubing..
ROUTE THE TUBING
Route the tubing between the cold water line and
the refrigerator.
Route the tubing through a hole drilled in the wall
or floor (behind the refrigerator or adjacent base
cabinet) as close to the wall as possible.
NOTE: Be sure there is sufficient extra tubing to
allow the refrigerator to move out from the wall
after installation.
FLUSH OUT THE TUBING
Turn the main water supply on and flush out the
tubing until the water is clear.
Shut the water off at the water valve after about
one quart (1 liter) of water has been flushed
through the tubing.
To complete the installation of the refrigerator, go
back to Step 1 in Installing the Refrigerator.
CONNECT THE TUBING TO THE
VALVE
Place the compression nut and ferrule (sleeve)
for copper tubing onto the end of the tubing and
connect it to the shutoff valve.
Make sure the tubing is fully inserted into the
valve. Tighten the compression nut securely.
For plastic tubing from a Universal Water Line
5HIULJHUDWRU7XELQJ.LW, insert the molded
end of the tubing into the shutoff valve and
tighten compression nut until it is hand tight,
then tighten one additional turn with a wrench.
Overtightening may cause leaks.
NOTE: Commonwealth of Massachusetts
Plumbing Codes 248CMR shall be adhered
to. Saddle valves are illegal and use is not
permitted in Massachusetts. Consult with your
licensed plumber.
4
5
6
8
7
Installation Instructions
INSTALLING THE WATER LINE (Cont.)
Pipe Clamp
Vertical Cold Water Pipe
Saddle-Type
Shutoff Valve
Washer
Inlet End
Pipe Clamp
Clamp
Screw
Saddle-Type
Shutoff Valve
Compression Nut
Packing Nut
Outlet Valve
Ferrule (sleeve)
Universal Water Line
Refrigerator Tubing
49-1000209 Rev. 026
Newer refrigerators sound different from older refrigerators.
Modern refrigerators have more features and use newer technology.
HUMMM...
WHOOSH...
Ŷ The new high efficiency compressor may run faster
and longer than your old refrigerator and you may
hear a high-pitched hum or pulsating sound while it
is operating.
Ŷ Sometimes the refrigerator runs for an extended
period, especially when the doors are opened
frequently. This means that the Frost Guard™
IHDWXUHLVZRUNLQJWRSUHYHQWIUHH]HUEXUQDQG
improve food preservation.
Ŷ <RXPD\KHDUDZKRRVKLQJVRXQGZKHQWKHGRRUV
FORVH7KLVLVGXHWRSUHVVXUHHTXDOL]LQJZLWKLQWKH
refrigerator.
Ŷ
You may hear the fans spinning at high speeds.
This happens when the refrigerator is first plugged
in, when the doors are opened frequently or when
a large amount of food is added to the refrigerator
RUIUHH]HUFRPSDUWPHQWV7KHIDQVDUHKHOSLQJWR
maintain the correct temperatures.
Ŷ If either door is open for over 3 minutes, you may
hear the fans come on in order to cool the light
bulbs.
Ŷ
The fans change speeds in order to provide optimal
cooling and energy savings.
CLICKS, POPS,
CRACKS and SNAPS
Ŷ You may hear cracking or popping sounds when
the refrigerator is first plugged in. This happens as
the refrigerator cools to the correct temperature.
Ŷ Electronic dampers click open and closed to
provide optimal cooling and energy savings.
Ŷ The compressor may cause a clicking or chirping
sound when attempting to restart (this could take
up to 5 minutes).
Ŷ The electronic control board may cause a clicking
sound when relays activate to control refrigerator
components.
Ŷ Expansion and contraction of cooling coils during
and after defrost can cause a cracking or popping
sound.
Ŷ On models with an icemaker, after an icemaking
cycle, you may hear the ice cubes dropping into
the ice bucket.
WATER SOUNDS
Ŷ The flow of refrigerant through the cooling coils may
make a gurgling noise like boiling water.
Ŷ Water dropping on the defrost heater can cause
DVL]]OLQJSRSSLQJRUEX]]LQJVRXQGGXULQJWKH
defrost cycle.
Ŷ A water dripping noise may occur during the defrost
cycle as ice melts from the evaporator and flows
into the drain pan.
Ŷ Closing the door may cause a gurgling sound due to
SUHVVXUHHTXDOL]DWLRQ
Do you hear what I hear? These conditions are normal.
Normal Operating Conditions
For additional information on normal
icemaker and dispenser operating sounds,
see the About the automatic icemaker and
About the ice and water dispenser sections.
TROUBLESHOOTING TIPS: Normal Operating Conditions
49-1000209 Rev. 0 27
TROUBLESHOOTING TIPS
Problem Possible Causes What To Do
Refrigerator does not operate Refrigerator in defrost cycle. Wait about 30 minutes for defrost cycle to end.
Freezer control in 0 (off) position. 0RYHWKHIUHH]HUFRQWUROWRDORZHUWHPSHUDWXUHVHWWLQJ
Refrigerator is unplugged. Push the plug completely into the outlet.
The fuse is blown/circuit breaker is
tripped.
Replace fuse or reset the breaker.
Refrigerator is in showroom mode. Unplug the refrigerator and plug it back in.
Vibration or rattling (slight
vibration is normal)
Rollers need adjusting. See Rollers.
Motor operates for long
periods or cycles on and
off frequently. (Modern
refrigerators with more storage
VSDFHDQGDODUJHUIUHH]HU
require more operating time.
They start and stop often to
maintain even temperatures.)
Normal when refrigerator is first
plugged in.
Wait 24 hours for the refrigerator to completely cool down.
Often occurs when large amounts of
food are placed in refrigerator.
This is normal.
Door left open. Check to see if package is holding door open.
Hot weather or frequent door
openings.
This is normal.
Temperature controls set at the
coldest setting.
See Controls.
5HIULJHUDWRURUIUHH]HU
compartment too warm
Temperature control not set cold
enough.
See Controls.
Warm weather or frequent door
openings.
Set the temperature control one step colder. See Controls.
Door left open. Check to see if package is holding door open.
)URVWRULFHFU\VWDOVRQIUR]HQ
food (frost within package is
normal)
Door left open. Check to see if package is holding door open.
Too frequent or too long door
openings.
Divider between refrigerator
DQGIUHH]HUFRPSDUWPHQWV
feels warm
Automatic energy saver system
circulates warm liquid around front
edge of freezer compartment.
This helps prevent condensation on the outside.
Automatic icemaker does not
work
Icemaker power switch is in the OFF
position.
Slide the power switch to the ON position.
Water supply turned off or not
connected.
See Installing the water line.
Freezer compartment too warm. Wait 24 hours for the refrigerator to completely cool down.
Piled up cubes in the storage bin
cause icemaker to shut off.
Level cubes by hand.
Ice cubes stuck in icemaker. Turn off the icemaker, remove cubes and turn the icemaker
back on.
Ice cubes have odor/taste Ice storage bin needs cleaning. Empty and wash bin. Discard old cubes.
Food transmitting odor/taste to ice
cubes.
Wrap foods well.
Interior of refrigerator needs
cleaning.
See Care and cleaning.
Small or hollow cubes Water filter clogged. Replace filter cartridge with new cartridge or with plug.
6ORZLFHFXEHIUHH]LQJ Door left open. Check to see if package is holding door open.
Temperature control not set cold
enough.
See Controls.
)UHTXHQW³EX]]LQJVRXQG´ Icemaker power switch is in the 1
(on) position, but the water supply
to the refrigerator has not been
connected.
6HWWKHSRZHUVZLWFKWRWKHRIISRVLWLRQ.HHSLQJLWLQWKH
(on) position will damage the water valve.
2UDQJHJORZLQIUHH]HU
Defrost heater is on. This is normal.
Cube dispenser does not work
(on some models)
Icemaker or water supply turned off. Turn on icemaker or water supply.
Ice cubes are frozen to icemaker
feeler arm.
Remove cubes.
An item is blocking or has fallen into
the ice chute inside the top bin of the
freezer.
Remove any item that might be blocking, or has fallen into the
chute.
Irregular ice clumps in storage
container.
Break up with fingertip pressure and discard remaining
clumps.
)UHH]HUPD\EHWRRZDUP$GMXVWWKHIUHH]HUFRQWUROWRD
colder setting, one position at a time, until clumps do not form.
Dispenser is /2&.('. Press and hold the Lock pad for 3 seconds.
Water has poor taste/odor
(on some models)
Water dispenser has not been used
for a long time.
Dispense water until all water in system is replenished.
Troubleshooting Tips... Before you call for service
Save time and money! Review the charts on the following pages first and you may not need to call for service.
49-1000209 Rev. 028
Problem Possible Causes What To Do
Water in first glass is warm (on
some models)
Normal when refrigerator is first
installed
Wait 24 hours for the refrigerator to completely cool
down.
Water dispenser has not been used for
a long time.
Dispense water until all water in system is replenished.
Water system has been drained. Allow several hours for replenished supply to chill.
Water dispenser does not work
(on some models)
Water supply line turned off or not
connected.
See Installing the water line.
Water filter clogged. Replace filter cartridge or remove filter and install plug.
Air may be trapped in the water system. Press the dispenser arm for at least two minutes.
Dispenser is /2&.('. Press and hold the Lock pad for 3 seconds.
Water spurting from
dispenser
Newly-installed filter cartridge. Run water from the dispenser for 3 minutes (about 1
1
/2
gallons).
Water is not dispensed (on
some models) but icemaker is
working
Water in reservoir is frozen. Call for service.
Refrigerator control setting is too cold. Set to a warmer setting.
No water or ice cube production Supply line or shutoff valve is clogged. Call a plumber.
Water filter clogged. Replace filter cartridge or remove filter and install plug.
Dispenser is /2&.('. Press and hold the Lock pad for 3 seconds.
CUBED was selected but
CRUSHED was dispensed (on
some models)
Last setting was CRUSHED. A few cubes were left in the crusher from the previous
setting. This is normal.
Refrigerator has odor Foods transmitting odor to
refrigerator.
Foods with strong odors should be tightly wrapped.
.HHSDQRSHQER[RIEDNLQJVRGDLQWKHUHIULJHUDWRU
replace every three months.
Interior needs cleaning. See Care and cleaning.
Moisture forms on outside of
refrigerator
Not unusual during periods of high
humidity.
Wipe surface dry.
Moisture collects inside (in
humid weather, air carries
moisture into refrigerator when
doors are opened)
Too frequent or too long door
openings.
This is normal fo rthe beverage center.
Due to the higher himidity in the
refrigerator, you may on occasion
experience fog or small amounts
of moisture in the refrigerator
compartment
This is normal for the beverage center loads and
environmental conditions change with a paper towel if
desired.
Interior light does not work No power at outlet. Replace fuse or reset the breaker.
Light bulb burned out. See Replacing the light bulbs.
For LED lights Call Service.
Water on kitchen floor or on
ERWWRPRIIUHH]HU
Cubes jammed in chute. Poke ice through with a wooden spoon.
Hot air from bottom of
refrigerator
Normal air flow cooling motor. In the
refrigeration process, it is normal that
heat be expelled in the area under the
refrigerator. Some floor coverings are
sensitive and will discolor at these
normal and safe temperatures.
Refrigerator never shuts off but
WKHWHPSHUDWXUHVDUH2.
Adaptive defrost keeps compressor
running during door openings.
This is normal. The refrigerator will cycle off after the
door remains closed for 2 hours.
Refrigerator is beeping Door is open. Close door.
Door not closing properly Door gasket on hinge side sticking or
folding over.
Apply petroleum jelly on face of gasket
Actual temperature not equal to
Set temperature
Unit just plugged in. $OORZKRXUVIRUV\VWHPWRVWDELOL]H
Door open for too long $OORZKRXUVIRUV\VWHPWRVWDELOL]H
Warm food added to refrigerator $OORZKRXUVIRUV\VWHPWRVWDELOL]H
Defrost cycle is in process $OORZKRXUVIRUV\VWHPWRVWDELOL]H
Troubleshooting Tips... Before you call for service
TROUBLESHOOTING TIPS
49-1000209 Rev. 0 29
LIMITED WARRANTY
Staple your receipt here. Proof of the original purchase
date is needed to obtain service under the warranty.
Ŷ Service trips to your home to teach you how to use
the product.
Ŷ,PSURSHULQVWDOODWLRQGHOLYHU\RUPDLQWHQDQFH
Ŷ)DLOXUHRIWKHSURGXFWLILWLVDEXVHGPLVXVHGRU
used for other than the intended purpose or used
commercially.
Ŷ/RVVRIIRRGGXHWRVSRLODJH
Ŷ5HSODFHPHQWRIKRXVHIXVHVRUUHVHWWLQJRIFLUFXLW
breakers.
Ŷ'DPDJHWRILQLVKVXFKDVVXUIDFHUXVWWDUQLVKRU
small blemishes not reported within 48 hours of
delivery.
Ŷ5HSODFHPHQWRIWKHZDWHUILOWHUFDUWULGJHLI
included, due to water pressure that is outside
the specified operating range or due to excessive
sediment in the water supply.
Ŷ5HSODFHPHQWRIWKHOLJKWEXOEVLILQFOXGHGRU
water filter cartridge, if included, other than as
noted above.
Ŷ'DPDJHWRWKHSURGXFWFDXVHGE\DFFLGHQWILUH
floods or acts of God.
Ŷ,QFLGHQWDORUFRQVHTXHQWLDOGDPDJHFDXVHGE\
possible defects with this appliance.
Ŷ3URGXFWQRWDFFHVVLEOHWRSURYLGHUHTXLUHGVHUYLFH
Ŷ'DPDJHFDXVHGE\DQRQ*($SSOLDQFHV%UDQG
water filter.
What Café Will Not Cover:
For the Period of: Café Will Replace
One Year
From the date of the
original purchase
Any part of the refrigerator which fails due to a defect in materials or workmanship.
During the limited one-year warranty, Café will also provide, free of charge, all labor
and related service to replace the defective part.
Thirty Days
(Water filter, if included)
From the original
purchase date of the
refrigerator
Any part of the water filter cartridge which fails due to a defect in materials or
workmanship. During this limited thirty-day warranty, Café will also provide, free of
charge, a replacement water filter cartridge.
Five Years
From the date of the
purchase
Any part of the sealed refrigerating system (the compressor, condenser, evaporator an all
connecting tubing) which fails due to a defect in materials or workmanship.
During this limited five-year sealed refrigerating system warranty, Café will also
provide, free of charge, all labor and related service to replace the defective part in the
sealed refrigerating system.
cafeappliances.com
$OOZDUUDQW\VHUYLFHLVSURYLGHGE\RXU)DFWRU\6HUYLFH&HQWHUVRUDQDXWKRUL]HGVHUYLFHWHFKQLFLDQ7RVFKHGXOHVHUYLFH
online, visit us at cafeappliances.com/service. Please have your serial number and your model number available when
scheduling service. In Canada, visit cafeappliances.ca/service.
Café Refrigerator Limited Warranty
EXCLUSION OF IMPLIED WARRANTIES
Your sole and exclusive remedy is product repair as provided in this Limited Warranty. Any implied warranties,
including the implied warranties of merchantability or fitness for a particular purpose, are limited to one year or the
shortest period allowed by law.
For US Customers: This limited warranty is extended to the original purchaser and any succeeding owner for products
SXUFKDVHGIRUKRPHXVHZLWKLQWKH86$,IWKHSURGXFWLVORFDWHGLQDQDUHDZKHUHVHUYLFHE\D&DIp$XWKRUL]HG6HUYLFHU
LVQRWDYDLODEOH\RXPD\EHUHVSRQVLEOHIRUDWULSFKDUJHRU\RXPD\EHUHTXLUHGWREULQJWKHSURGXFWWRDQ$XWKRUL]HG
Café
Service location for service. In Alaska, the limited warranty excludes the cost of shipping or service calls to your
home.
Some states do not allow the exclusion or limitation of incidental or consequential damages. This limited warranty
gives you specific legal rights, and you may also have other rights which vary from state to state. To know what your
legal rights are, consult your local or state consumer affairs office or your state’s Attorney General.
Warrantor: GE Appliances, a Haier company
Louisville, KY 40225
For Customers in Canada: This limited warranty is extended to the original purchaser and any succeeding owner
for products purchased in Canada for home use within Canada. In-home warrant service will be provided in areas
where it is available and deemed reasonable by Mabe to provide.
Warrantor Canada: MC Commercial, Inc., Burlington, Ontario, L7R 5B6
Servicing your refrigerator may require the use of the onboard data port for diagnostics. This gives a
Café Factory Service technician the ability to quickly diagnose any issues with your appliance and helps
Café improve its products by providing Café with information on your appliance. If you do not want your
appliance data to be sent to Café, please advise your technician NOT to submit the data to Café at the time
of service.
49-1000209 Rev. 030
Staple your receipt here. Proof of the original purchase
date is needed to obtain service under the warranty.
* If your GE Appliances part fails because of a manufacturing defect within thirty days from the date of original purchase for use, we will give you
a new or, at our option, a rebuilt part without charge. Return the defective part to the parts supplier from whom it was purchased together with a
FRS\RIWKH³SURRIRISXUFKDVH´IRUWKHSDUW,IWKHSDUWLVGHIHFWLYHDQGVKRZVQRVLJQVRIDEXVHLWZLOOEHH[FKDQJHG7KHZDUUDQW\GRHVQRW
cover the failure of parts which are damaged while in your possession, are abused, or have been installed improperly. It does not cover the cost
of returning the part to the supplier from whom it was purchased nor does it cover the cost of labor to remove or install it to diagnose the fault. It
does not cover parts used in products in commercial use except in the case of air conditioning equipment. In no event shall GE Appliances be
liable for consequential damages.
Warrantor: GE Appliances, a Haier company
Louisville, KY 40225
Seller:
Name
Address
City State Zip
Signature Date
Buyer:
Name
Address
City State Zip
Signature Date
What GE Appliances will not cover:
Ŷ Service trips to your home to teach you how to use the product.
Ŷ Improper installation.
Ŷ Failure of the product if it is abused, misused, used for other than the intended purpose or used commercially.
Ŷ Replacement of house fuses or resetting of circuit breakers.
Ŷ Damage to the product caused by accident, fire, floods, or acts of God.
Ŷ Incidental or consequential damage caused by possible defects with this appliance.
Water Filter Cartridge Limited Warranty
This limited warranty is extended to the original purchaser and any succeeding owner for products purchased for
home use within the USA. In Alaska, the limited warranty excludes the cost of shipping or service calls to your home.
Some states do not allow the exclusion or limitation of incidental or consequential damages. This limited warranty
gives you specific legal rights, and you may also have other rights which vary from state to state. To know what your
legal rights are, consult your local or state consumer affairs office or your state’s Attorney General.
For Purchases Made In Iowa: This form must be signed and dated by the buyer and seller prior to the
consummation of this sale.
This form should be retained on file by the seller for a minimum of two years.
For the period of GE Appliances will replace
Thirty Days
From the date
of the original
purchase
Any part of the water filter cartridge which fails due to a defect in materials
or workmanship during this limited thirty-day warranty.*
Contact us at cafeappliances.com/parts.
EXCLUSION OF IMPLIED WARRANTIES
Your sole and exclusive remedy is part exchange as provided in this Limited Warranty. Any implied warranties,
including the implied warranties of merchantability or fitness for a particular purpose, are limited to six months or
the shortest period allowed by law.
LIMITED WARRANTY
49-1000209 Rev. 0 31
Performance Data Sheet
Model: XWF
Ŷ6\VWHPFHUWLILHGE\,$30257DJDLQVW16)$16,6WDQGDUGVIRUWKHUHGXFWLRQRIFODLPVVSHFLILHGRQWKHSHUIRUPDQFHGDWD
sheet and at iapmort.org.
Ŷ$FWXDOSHUIRUPDQFHPD\YDU\ZLWKORFDOZDWHUFRQGLWLRQV
It is essential that the manufacturer’s recommended installation,
maintenance and filter replacement requirements be carried out for the
product to perform as advertised. See Installation Manual for Warranty
information.
Application Guidelines/Water Supply Parameters
Service Flow 0.5 gpm (1.89 lpm)
Water Supply Potable Water
Water Pressure 25-120 psi (172-827 kPa)
Water Temperature 33°F-100°F (0.6°C-38°C)
Capacity 170 gallons (643.5 liters)
Substance Tested for Reduction
Influent challenge
concentration
(mg/L)
Maximum permissible
product water
concentration (mg/L)
Avg %
Reduction
Chlorine Taste and Odor 2.0 mg/L +/- 10% N/A 96.9
Chloramine Taste and Odor 3.0 mg/L +/- 10% 0.5 96.9
Particulate, Class I At least 10,000/mL N/A 91.4
Cysts 50,000/L N/A >99.99
Lead 0.15 0.01 98.85
Mercury 0.006 0.002 96.3
Asbestos 107 to 108 fibers/ L N/A >99
Toxaphene 0.015 +/- 10% 0.003 86.95
VOC (Chloroform surrogate chemical) 0.300 0.015 99.7
Alachlor 0.050 0.001 > 98
$WUD]LQH 0.100 0.003 > 97
%HQ]HQH 0.081 0.001 > 99
Carbofuran 0.190 0.001 > 99
carbon tetrachloride 0.078 0.0018 98
FKORUREHQ]HQH 0.077 0.001 > 99
chloropicrin 0.015 0.0002 99
2,4-D 0.110 0.0017 98
dibromochloropropane (DBCP) 0.052 0.00002 > 99
R'LFKORUREHQ]HQH 0.08 0.001 > 99
S'LFKORUREHQ]HQH 0.040 0.001 > 98
1,2-dichloroethane 0.088 0.0048 95
1,1-dichloroethylene 0.083 0.001 > 99
cis-1,2-dichloroethylene 0.170 0.0005 > 99
trans-1,2-dichloroethylene 0.086 0.001 > 99
1,2-dichloropropane 0.080 0.001 > 99
cis-1,3-dichloropropylene 0.079 0.001 > 99
dinoseb 0.170 0.0002 99
Endrin 0.053 0.00059 99
(WK\OEHQ]HQH 0.088 0.001 > 99
ethylene dibromide (EDB) 0.044 0.00002 > 99
bromochloroacetonitrile 0.022 0.0005 98
dibromoacetonitrile 0.024 0.0006 98
dichloroacetonitrile 0.0096 0.0002 98
trichloroacetonitrile 0.015 0.0003 98
1,1-dichloro-2-propanone 0.0072 0.0001 99
1,1,1-trichloro-2-propanone 0.0082 0.0003 96
heptachlor (H-34, Heptox) 0.025 0.00001 >99
heptachlor epoxide 0.0107 0.0002 98
hexachlorobutadiene 0.044 0.001 > 98
hexachlorocyclopentadiene 0.060 0.000002 > 99
Lindane 0.055 0.00001 > 99
methoxychlor 0.050 0.0001 > 99
pentachlorophenol 0.096 0.001 > 99
VLPD]LQH 0.120 0.004 > 97
Styrene 0.150 0.0005 > 99
1,1,2,2-tetrachloroethane 0.081 0.001 > 99
Tetrachloroethylene 0.081 0.001 > 99
Toluene 0.078 0.001 > 99
2,4,5-TP (silvex) 0.270 0.0016 99
tribromoacetic acid 0.042 0.001 > 98
7ULFKORUREHQ]HQH 0.160 0.0005 > 99
1,1,1-trichloroethane 0.084 0.0046 95
1,1,2-trichloroethane 0.150 0.0005 > 99
trichloroethylene 0.180 0.0010 > 99
bromoform 0.300 0.015 95
bromodichloromethane 0.300 0.015 95
chlorodibromomethane 0.300 0.015 95
xylenes 0.070 0.001 >99
Meprobamate 400 +/- 20% 60 95.5
Atenolol 200 +/- 20% 30 95.9
&DUEDPD]HSLQH 1400 +/- 20% 200 98.6
DEET 1400 +/- 20% 200 98.6
Metolachlor 1400 +/- 20% 200 98.7
Trimethoprim 140 +/- 20% 20 96.1
Linuron 140 +/- 20% 20 96.6
TCEP 5000 +/- 20% 700 98.1
TCPP 5000 +/- 20% 700 98.1
Phenytoin 200 +/- 20% 30 96
Ibuprofen 400 +/- 20% 60 95.9
Naproxen 140 +/- 20% 20 96.5
Estrone 140 +/- 20% 20 97.1
Bisphenol A 2000 +/- 20% 300 99.1
Nonyl phenol 1400 +/- 20% 200 97.3
NOTE: While the testing was performed under standard
laboratory conditions, actual performance may vary.
Replacement Cartridge: XWF. For estimated costs
of replacement elements please visit our website at
cafeappliances.com.
WARNING
To reduce the risk associated with
ingestion of contaminants:
• Do not use with water that is microbiologically unsafe
or of unknown quality without adequate disinfection
before and after the system. Systems certified for cyst
reduction may be used on disinfected water that may contain
filterable cysts.
NOTICE
To reduce the risk of water leakage or flooding, and to
ensure optimal filter performance:
• Read and follow use instructions before installation and
use of this system.
• Installation and use MUST comply with all state and local
plumbing codes.
• Do not install if water pressure exceeds 120 psi (827
kPa). If your water pressure exceeds 80 psi (552 kPa), you
must install a pressure-limiting valve. Contact a plumbing
professional if you are uncertain how to check your water
pressure.
• Do not install where water hammer conditions may occur.
If water hammer conditions exist you must install a water
hammer arrester. Contact a plumbing professional if you are
uncertain how to check for this condition.
• Do not install on hot water supply lines. The maximum
operating water temperature of this filter system is 100º F
(38º C).
• Protect filter from freezing. Drain filter when temperatures
drop below 33ºF (0.6ºC).
• Change the disposable filter cartridge every six months or
sooner if you observe a noticeable reduction in water flow
rate.
• Failure to replace the disposable filter cartridge at
recommended intervals may lead to reduced filter
performance and cracks in the filter housing, causing water
leakage or flooding.
• This System has been tested according to NSF/ANSI 42,
53 and 401 for the reduction of the substances listed below.
The concentration of the indicated substances in water
entering the system was reduced to a concentration less
than or equal to the permissible limit for water leaving the
system, as specified in NSF/ANSI 42, 53 and 401.
XWF System is certified by IAPMO R&T
against NSF/ANSI Standards 42,53, and 401
for the reduction of claims specified on the
performance data sheet and at iapmort.org.
Printed in United States
CONSUMER SUPPORT
Consumer Support
Café Website
Have a question or need assistance with your appliance? Try the Café website 24 hours a day, any day of the year! You can also
shop for more great Café products and take advantage of all our on-line support services designed for your convenience. In the
US: cafeappliances.com
Register Your Appliance
Register your new appliance on-line at your convenience! Timely product registration will allow for enhanced communication and
prompt service under the terms of your warranty, should the need arise. You may also mail in the pre-printed registration card
included in the packing material. In the US: cafeappliances.com/register
Schedule Service
Expert Café repair service is only one step away from your door. Get on-line and schedule your service at your convenience any
day of the year. In the US: cafeappliances.com/service
Extended Warranties
Purchase a Café extended warranty and learn about special discounts that are available while your warranty is still in effect. You
can purchase it on-line anytime. Café Service will still be there after your warranty expires.
In the US: cafeappliances.com/extended-warranty
Remote Connectivity
For assistance with wireless network connectivity (for models with remote enable),
visit our website at cafeappliances.com/connect
Parts and Accessories
Individuals qualified to service their own appliances can have parts or accessories sent directly to their homes
(VISA, MasterCard and Discover cards are accepted). Order on-line today 24 hours every day.
In the US: cafeappliances.com/parts
Instructions contained in this manual cover procedures to be performed by any user. Other servicing generally should
be referred to qualified service personnel. Caution must be exercised, since improper servicing may cause unsafe
operation.
Contact Us
If you are not satisfied with the service you receive from Café, contact us on our website with all the details including your phone
number, or write to:
,QWKH86*HQHUDO0DQDJHU&XVWRPHU5HODWLRQV_&DIp$SSOLDQFHV$SSOLDQFH3DUN_/RXLVYLOOH.<
cafeappliances.com/contact
