Troy-Bilt 13AX60TG766 Super Bronco Lawn Tractor User Manual

Automatic Lawn Tractor- Super Bronco TM(Model 60TG)

READ SAFETY RULES AND mNSTRUCTmONS CAREFULLY BEFORE OPERATION

Warning: This unitis equippedwithan internalcombustionengineandshouldnot beusedon or nearany unimprovedforest-covered,brush=

coveredor grass=coveredlandunlessthe engine'sexhaustsystemis equippedwitha sparkarrestermeetingapplicablelocalorstate laws(if any),

If a sparkarresteris used,it shouldbemaintainedineffectiveworkingorderby the operator,Inthe Stateof Californiathe aboveis requiredbylaw

(Section4442of the CaliforniaPublicResourcesCode),Otherstatesmayhavesimilarlaws,Federallawsapplyonfederallands,A sparkarrester

for the muffleris availablethroughyournearestengineauthorizedservicedealeror contactthe servicedepartment,RO,Box361131Cleveland,

Ohio44136=0019,

FORMNO,770=104901

PRINTEDIN U,S,A Troy-Bilt LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019 1/06/2006

This Operator's Manua_ is an important part of your new lawn tractor, mtwH_ he_p you assemble,

prepare and maintain the unit for best performance. P_ease read and understand what it says.

Table of Contents

Slope Gauge ....................................................... 3

Safe Operation Practices ................................... 4

Setting Up Your Lawn Tractor ............................ 8

Operating Your Lawn Tractor ........................... 10

Adjusting Your Lawn Tractor ............................ 18

Maintaining Your Lawn Tractor ........................ 20

Off-Season Storage / Attachments ................. 26

Safety Labels .................................................... 27

TrouMe Shooting .............................................. 28

Parts List ........................................................... 30

Finding and Recording Model Number

BEFOREYOU START ASSEMBLING

YOUR NEW EQUIPMENT,

please locatethe model plate on the equipment and copy the

information to the sample model plate providedto the righL

You can locate the model plate by looking beneath the seal

This information will be necessary to use the manufacturer's

web site and/or obtain assistance from the Customer Support

Department or an authorized service dealer.

Modem Number Seriam Number

0 TR#_H_--T_ TROY=BiLT LLC

P. O. BOX 361131

www.troybiit.com CLEVELAND, ON 44136

338=558=7228

,, 856=848=6483_

Customer Support

P_ease do NOTreturn the unitto the retai_er from which it was

purchased, without first contacting Customer Support.

if you have difficulty assembling this product or have any questions regarding the controls, operation, or maintenance of this

unit, you can seek help from the expert& Choose from the options below:

1, Visittroybilt.com for manyusefulsuggestions,Clickon Customer

Supportbuttonandyouwill get the optionsreproducedin thescreen

shotbelow,CIbk onthe appropriatebuttonandhelpis immediately

availabb,

3, The engine manufacturer is responsibb forall engine=relatedissues

with regardto performance,power=rating,specifications,warrantyand

service,Phase referto the enginemanufacturer'sOwner's/Operator's

Manual,packedseparatelywithyour unit,for moreinformation,

2, Phonea Customer Support Representative at 1=866-840=6483,

your lawn mower on such slopes.

WARNING

Do not mowon inclines

with a dope in excess

of 15 degrees (a rise

of approximately

2-"

feet). A riding r

could overturn and

cause serious injury.

if operating a walb

behind mower on such

a dope, it is extremely

footing and you could

dip, resulting in serious

injury.

Operate RiDiNG

mowers up and down

dopes, neveracross

the face of dopes.

Operate

WALK-BEHIND

mowers across the

face of dopes, never

up and down slopes.

_i i _ i _i _ i _ iii _ _

DANGER: This machine was built to be operated according to the rubs for safe operation in this

manuak As with any type of power equipment, carelessness or error on the part of the operator can

S ale result in serious injury.This machine is capable of amputating hands and feet and throwing objects.

Failureto observe the following safety instructions could result in serious injury or death.

instructionswhich, if

notfollowed, could

endangerthe personal

safety and/or property

of yourself and others.

Read and fobow all

instructionsin this man=

ual before attemptingto

operatethis machine.

Failureto comply with

When you see this

symbol.

H EED ITS WARNING

Your

Responsibility

Restrictthe use

of this power machine

to persons who read.

understand

and follow the warnings

and instructions

in this manual

Children

1. Tragicaccidentscan occurif the operatoris not

abrt tothe presenceof children.Childrenare often

attractedto the machineandthe mowingactivity.

Theydo not understandthe dangers.Neverassume

thatchildrenwill remainwhereyou lastsawthem.

a. Keepchildrenout of the mowingarea and in

watchfulcare of a responsibleadult otherthan

the operator.

b. Be alert and turn machineoff if a childenters

the area.

c. Beforeand while backing,lookbehindand

downfor smallchildren.

d. Nevercarrychildren,evenwiththe blade(s)

shutoff.Theymayfalloffandbeseriously

iniuredor interferewith safemachineoperation.

e. Use extremecarewhenapproachingblind

corners,doorways,shrubs,treesor other

objectsthatmayblockyourvisionof a child

who mayruninto the machine.

f. To avoid back-overaccidents, always

disengage the cutting blade(s) before

shifting into Reverse.If equipped, the

"Reverse Caution Mode" should not be

used when children or others are around.

g. Keepchildrenaway from hotor running

engines.Theycansuffer burnsfroma hot

muffler.

h. Removekeywhen machineis unattendedto

preventunauthorizedoperation.

2. Neverallowchildrenunder14yearsoldto operate

the machine.Children14}'earsold and overshould

readandunderstandthe operationinstructionsand

safetyrubs in this manualand shouldbe trainedand

supervisedbya parent.

Operation

Safe Handling of Gasoline:

1. Toavoid personal injuryor property damage use

extreme care in handlinggasoline. Gasoline is

extremely flammable and the vapors areexplo-

sive. Seriouspersonaliniurycanoccurwhengasoline

is spilledonyourselfor yourclotheswhichcan ignite.

Washyourskinandchangeclothesimmediately.

a. Use onlyan approvedgasolinecontainer.

b. Neverfill containersinsidea vehbb or ona

truckor trailerbedwitha plastb liner.Always

placecontainerson the groundawayfrom

yourvehble beforefilling.

c. When practbal, removegas-powered

equipmentfromthe truck ortrailerand refuelit

onthe ground.Ifthis is not possibb, then

refuelsuchequipmentona trailerwitha

portabb container,ratherthan fromagasoline

dispensernozzb.

d. Keepthe nozzb in contactwith the rimof

the fueltankor containeropeningat all

timesuntilfuelingis complete.Donot usea

nozzleIocbopendevice.

e. Extinguishall cigarettes,cigars,pipesand

othersourcesof ignition.

f. Neverfuel machineindoors.

g. Neverremovegas cap or add fuel whilethe

engineis hot or running.Mow engineto cool

at bast twominutesbeforerefueling.

h. Neveroverfill fuel tank.Fill tank to no more

than1/2inchbelowbottomof filbr neck to

allowspacefor fuel expansion.

i. Replacegasolinecapandtightensecurely.

i. If gasolineis spilled,wipe it offthe engine

andequipment.Moveunitto anotherarea.

Wait5 minutesbeforestartingthe engine.

k. To reducefire hazards,keepmachinefreeof

grass,leaves,orother debrisbuild-up.Clean

upoil orfuel spillageand removeany fuel

soakeddebris.

I. Neverstorethe machineor fuel container

insidewherethere is anopenflame,spark

or pilotlightas on a waterheater,space

heater,furnace,clothesdryeror othergas

appliances.

m. Allowa machineto cool at bast fiveminutes

beforestoring.

GeneralOperation:

1. Read,understand,and followall instructionson the

machineandinthe manual(s)beforeattemptingto

assembleandoperate.Keepthismanualina safe

placefor futureandregularreferenceandforordering

replacementparts.

2. Be familiarwith all controlsand theirproperoperation.

Knowhow to stopthe machineanddisengagethem

quickly.

3. Neverallowchildrenunder 14yearsold to operate

this machine.Children14yearsold andovershould

readandunderstandthe operationinstructionsand

safetyrubs in thismanualandshouldbetrainedand

supervisedby aparent.

4. Neverallowadults to operatethis machinewithout

properinstruction.

5. To helpavoid bladecontactor a thrownobiect iniury,

keepbystanders,helpers,childrenand petsat bast

75 feetfromthe machinewhileit is inoperation.8top

machineif anyoneentersthe area.

6. Thoroughlyinspectthearea wherethe equipmentis to

beused.Removeallstones,sticks,wire,bones,toys,

andotherforeignobiectswhichcould bepickedup

andthrownbythe blade(s).Thrownobiectscancause

seriouspersonaliniury.

7, Planyourmowingpatternto avoiddischargeof

materialtowardroads,sidewalks,bystandersandthe

like.Also,avoiddischargingmaterialagainsta wall or

obstructionwhichmaycausedischargedmaterialto

ricochetbacktowardthe operator.

8. Alwayswearsafety glassesor safetygogglesduring

operationandwhile performingan adiustmentor

repairto protectyour eyes.Thrownobiectswhich

ricochetcan causeseriousiniuryto the eyes.

9. Wearsturdy,rough-sobdworkshoes and close-fitting

slacksandshirts.Loosefittingclothesandiewelry

can becaughtinmovabbparts. Neveroperatethis

machinein barefeetor sandals.

10.Beawareof the mowerandattachmentdischarge

directionanddo notpoint it at anyone.Do notoperate

the mowerwithoutthe dischargecoverorentiregrass

catcherin itsproperplace.

11.Do notput handsor feetnearrotatingpartsor under

the cuttingdeck.Contactwiththe blade(s)can

amputatehandsandfeet.

12.Amissingor damageddischargecovercan cause

bladecontactor thrownobiectiniuries.

13.8topthe blade(s)whencrossinggraveldrives,walks,

or roadsandwhilenot cuttinggrass.

14.Watchfor trafficwhenoperatingnearor crossing

roadways.Thismachineis not intendedfor useon

anypublic roadway.

15.Do notoperatethe machinewhileunderthe influ-

enceof alcoholordrugs.

16.Mowonly in daylightor goodartificiallight.

17,Nevercarrypassengers.

18.Disengageblade(s)beforeshiftinginto reverse.

Backupslowly.Alwayslookdownandbehindbefore

andwhilebackingto avoida back-overaccident.

19.Slowdownbeforeturning.Operatethe machine

smoothly.Avoiderraticoperationandexcessive

instructions wh ch. if

not followed, could

endanger the personal

safety and/or property

of yourself and others.

Read and follow all

instructions in this man-

ual before attempting to

operatethis machine.

these instructions may

result in personal injury.

When you see this

symbol.

HEED iTS WARNING

Your

Responsibility

Restrictthe use

d this power machine

to persons who read,

understand

and follow the warninas

and instructions

in this manual

21.Neverleavea runningmachineunattended.Always

turnoff blade(s),placetransmissionin neutral,set

parkingbrake,stopengineand removekeybefore

dismounting.

22.Useextracare whenloadingor unloadingthe

machineintoa trailerortruck.Thisunitshould not

bedrivenupor downramp(s),becausethe unit

couldtip over,causingseriouspersonaliniury.The

unit mustbepushedmanuallyonramp(s)to loador

unloadproperly.

23.Mufflerandenginebecomehotandcan causea

burn.Do nottouch.

24.Checkoverheadclearancescarefullybeforedriving

underlowhangingtreebranches,wires,dooropen-

ingsetc. wheretheoperatormaybe struckor pulled

fromthe unit,whichcouldresultinseriousiniury.

25.Disengageallattachmentclutches,depressthe

brakepedalcompbtelyandshift into neutralbefore

attemptingto startengine.

26.Yourmachineis designedto cutnormalresidential

grassof aheightno morethan 10".Do notattemptto

mowthroughunusuallytall,dry grass(e.g.,pasture)

or pilesof dry leaves.Drygrassor leavesmay

contactthe engineexhaustand/orbuildup onthe

mowerdeckpresentinga poten%l fire hazard.

27.Useonlyaccessoriesandattachmentsapprovedfor

thismachineby the machinemanufacturer.Read,

understandandfollowall instructionsprovidedwith

the approvedaccessoryor attachment.

28.Dataindicatesthatoperators,age60 yearsand

above,areinvolvedin a largepercentageof riding

mower-relatediniuries.Theseoperatorsshould

evaluatetheirabilityto operatetheridingmower

safelyenoughto protectthemselvesandothersfrom

seriousiniury.

29.If situationsoccurwhicharenot coveredinthis

manual,usecareandgoodiudgment.Contactyour

customerservicerepresentativefor assistance.

WARNING

This symbol points

speed. }

20.Dbengageblade(s),setparkingbrake,stopengine

andwaituntilthe blade(s)cometo acompletestop

beforeremovinggrasscatcher,emptyinggrass,

uncloggingchute,removingany grassor debris,or

makinganyadiustments.

Slope Operation:

Slopesarea majorfactorrelatedto lossof controland

tip-overaccidentswhichcan resultin severeinjury or

death,All slopesrequireextracaution,if you cannot

backupthe slopeor if youfeel uneasyonit, do notmow

it,

Foryour safety,usethe slopegaugeincludedas partof

thismanualto measureslopesbeforeoperatingthisunit

ona slopedor hillyarea,if the slopeis greaterthan 15

;_,_ degreesas shownonthe slopegauge,do notoperate

,, thisunit onthatareaorseriousinjurycouldresult,

uperal:lon Do:

1, Mow up and downslopes,notacross,Exercise

racl:lces extremecautionwhenchangingdirectiononsbpes,

2, Watchfor hobs, ruts,bumps,rocks,or other hidden

objects,Uneventerraincouldoverturnthe machine,

out important safety

instructions which, if

not followed, could

endangerthe personal

safety and/or property

of yourself and others.

Readand follow all

instructions in this man°

ual before attempting to

Tallgrasscan hideobstacbs,

3, Use slow speed,Choosea low enoughspeed

settingso thatyouwill not haveto stoporshift while

onthe slope,Tiresmaylosetractiononslopeseven

thoughthe brakesarefunctioningproperly,Always

keepmachineingearwhengoingdownslopesto

takeadvantageof enginebrakingaction,

4, Followthe manufacturer'srecommendationsfor

wheelweightsorcounterweightsto improvestability,

5, Use extra carewith grasscatchersor otherat-

tachments,Thesecanchangethe stabilityof the

machine,

6, Keepall movementon theslopes slow and gradual

Do not makesuddenchangesinspeedor direction,

Rapidengagementor brakingcouldcausethe front

of the machineto liftand rapidlyfib overbackwards

whichcouldcauseseriousinjury,

7, Avoidstartingor stoppingon a slope,If tires lose

traction,disengagethe blade(s)andproceedslowly

straightdownthe slope,

Do Not:

1, Do notturn on slopes unlessnecessary;then,turn

slowlyandgraduallydownhill,if possibb,

2, Do not mownear drop-offs,ditchesor embankments,

The mowercouldsuddenlyturnoverif awheel is over

the edgeof acliff,ditch,or if anedgecavesin,

3, Do nottry to staNlizethe machineby puttingyourfoot

onthe ground,

4, Do not usea grasscatcheron steep slopes,

5, Do not mowon wet grass,Reducedtractioncould

causesliding,

6, Do notshift to neutraland coastdownhill Over-speed-

ingmaycausethe operatorto lose controlof the

machineresultingin seriousinjuryordeath,

7, Do nottow heavypull behindattachments(e,g,loaded

dumpcart, lawnroller,etc,)on slopesgreaterthan

5 degrees,Whengoingdown hill,the extraweight

tendsto pushthetractorand maycauseyou to loose

control (e,g,tractormayspeedup, brakingandsteer-

ingabilityarereduced,attachmentmayjack-knifeand

causetractorto overturn),

Towing:

1, Towonlywith a machinethat hasa hitchdesignedfor

towing,Do not attachtowedequipmentexceptat the

hitchpoint,

2, Followthe manufacturersrecommendationfor weight

limitsfor towedequipmentandtowingonslopes,

3, Neverallowchildrenor othersin or on towedequip-

ment,

4, On slopes,theweight of thetowed equipmentmay

causelossof tractionandlossof control,

5, Travelslowlyand allowextra distanceto stop,

6, Do notshift to neutraland coastdownhill

these instructions may

result in personal injury,

When you see this

symbol

HEED ITS WARNING

YOUr

Responsibility

Restrictthe use

of this power machine

to persons who read.

understand

and follow the warnings

and instructions

in this manual

Service lO,Neverattemptto makeadiustmentsor repairsto the

1. Neverrun an engineindoorsor in a poorlyventilated

area. Engineexhaustcontainscarbonmonoxide,an

odorless,anddeadlygas.

2. Beforecleaning,repairing,or inspecting,makecertain

the blade(s)andall movingpartshavestopped.

Disconnectthe sparkplugwireandgroundagainstthe

engineto preventunintendedstarting.

3. Periodicallycheckto make surethe bladescome to

compbte stopwithinapproximately(5) fiveseconds

afteroperatingthe bladedisengagementcontrol,if the

bladesdo notstopwithinthethis timeframe,your unit

shouldbeservicedprofessionallyby anauthorized

MTDServiceDealer.

4. Checkbrakeoperationfrequentlyas it is subiectedto

wearduringnormaloperation.Adiustandserviceas

required.

5. Checkthe blade(s)and enginemountingboltsat

frequentintervalsfor propertightness.Also,visually

inspectblade(s)for damage(e.g. excessivewear,

bent,cracked). Replacethe blade(s)with theoriginal

equipmentmanufacturer's(O.E.M.)blade(s)only,

listedin thismanual."Useof partswhichdonot meet

the originalequipmentspecificationsmaybad to

improperperformanceandcompromisesafety!"

6. Mowerbladesare sharp.Wrapthe bladeor wear

gloves,anduseextracautionwhenservicingthem.

7, Keepall nuts,bolts,and screwstight to be surethe

equipmentis insafeworkingcondition.

8. Nevertamperwith the safety interlocksystemor other

safetydevices.Checktheir properoperationregularly.

9. After strikinga foreignobiect,stop the engine,

disconnectthe sparkplugwire(s)and groundagainst

the engine.Thoroughlyinspectthe machinefor any

damage.Repairthe damagebeforestartingand

operating,

machinewhile theengineis running,

11,Grasscatchercomponentsandthe discharge

coveraresubiectto wearanddamagewhichcould

exposemovingpartsor allowobiectsto bethrown,

Forsafetyprotection,frequentlycheckcomponents

andreplaceimmediatelywithoriginalequipment

manufacturer's(O,E,M,)partsonly,listedinthis

manual,"Useof partswhichdo notmeettheoriginal

equipmentspecificationsmaybad to improper

performanceandcompromisesafety!"

12,Do notchangethe enginegovernorsettingsor

over-speedthe engine,The governorcontrolsthe

maximumsafeoperatingspeedof theengine,

13,Maintainor replacesafetyandinstructionlabels,as

necessary,

14,Observeproperdisposallawsandregulationsfor

gas,oil,etc, to protecttheenvironment,

i /

This symbol points

instructions which, if

safety and/or property

of yourself and others,

Readand follow al

ual before attempting to

operatethis machine.

When you see this

symbol,

N EED roTSWARNING

Your

Responsibility

Restrictthe use

of this power machine

to persons who read,

understand

>wthe warnings

and instructions

in this manual

expJos!ve.Neverfuel

machineindoors

°,whilethee.gi.e

Hex Nut Hex Bolt

Figure 1

Figure 2

Attaching the Battery Cables

NOTE:The positivebatteryterminalis markedPos,(+),

The negativebatteryterminalis markedNeg,(-),

• Thepositivecane (heavyredwire) is securedto the

positivebatteryterminal(+)witha hexbolt and hex

nut at thefactory,Beforeattachingthe negativecane

removethe batteryby removingthe positivecane

andhold-downstrap,Notethe dateon theside of the

battery,Ifthe batteryis put into serviceafterthisdate,

chargethe batteryas instructedin the Maintaining

YourLawnTractorsectionof this manualpriorto

operatingthetractor,

• Securebatterybackontothe tractorwiththe hold-

downstrap,Reattachthe positivecane (heavyred

wire)to the positivebatteryterminal(+)with the bolt

andnut,Makecertainthatthe rubberbootcoversthe

terminalto helpprotectit fromcorrosion,

• Removethehex bolt andhexnut fromthe negative

cane,

• Removetheblackplasticcover,if present,fromthe

negativebatteryterminalandattachthe negative

cane (heavyblackwire)to the negativebattery

terminal(-) withthe boltandnut,

• Makecertainthehold=downstrap is in positionover

the battery,securingit inplace,SeeFigure1,

Attaching The Seat

NOTE:Forshippingreasons,seatsareeitherfastened

to the tractorseat'spivotbracketwitha plastictie,or

mountedbackwardto the pivotbracket,In eithercase,

freethe seatformitsshippingpositionand removethe

twohex screws(or knobs,on modelsso equipped)from

the bottomof seatbeforeproceedingwithapplicable

instructionsbelow,

1, Positionthe shoulderscrews (foundon the baseof the

seat)insidethe slot openingsinthe seatpivotbracket,

Figure2,

2, Slide theseat slightlyrearwardin the seat pivot

bracket,liningupthe rearslots inthe pivotbracket

withthe remainingtwo holesinthe seat'sbase,

3, Selectdesiredpositionforthe seat,and securewith

the twoknobsremovedearlier,SeeFigure2,

Attaching The Steering Whee_ f

The hardwarefor attachingthe stettingwheelhasbeen

packedwithinthesteeringwheel,beneaththe steering

wheelcap,Carefullypry offthe steeringwheelcapand

removethe hardware,

NOTE:Therearetwodifferentstylesof steeringwheel

cap,SeeFigure3, Styles vary by model.

1. With the wheels of the tractor pointing straight

forward, placethe steeringwheeloverthe steering

shaft,

2, Placethe washer(with thecuppedside down)over

the steeringshaftandsecurewiththe hex bolt,See

Figure3,

3, Placethe steeringwheelcap overthe centerof the

steeringwheelandpushdownwarduntilit"clicks" into

place,

Gas and Oil FHI-up

The gasolinetankis locatedunderthe hoodandhas a

capacityof three gallons,Donot overfill

,._ j

Figure 3

WARNING: Use extreme care

when handling gasoline. Gasoline

is extremely flammabte and the

vapors are explosive. Never fuel

machine indoors or while the

engine is hot or running. Extin-

guish cigarettes, cigars, pipes,

and other sources of ignition.

Servicethe enginewith gasolineandoilas instructedin

the separateKohlerOperator/OwnerManualpackedwith

yourtractor,Readinstructionscarefully,

IMPORTANT:Yourtractoris shippedwithmotoroil inthe

engine,However,you MUSTcheckthe oillevel before

operating,Becarefulnot to overfill

Shipping Brace Remova_

WARNING: Make sure the riding

mower's engine is off, remove the

ignition key, and set the parking

brake before removing the ship-

ping brace.

Locatethe shippingbrace,if present,andaccompany=

ingwarningtagfoundon the rightside of the mower,

betweenthe dischargechuteandthe cuttingdeck,

SeeFigure4,

= While holdingthe dischargechutewithyourleft hand,

removetheshippingbracewithyourright handby

graspingit betweenyourthumbandindexfingerand

rotatingit clockwise,

Figure 4

WARNING: The shipping brace,

used for packaging purposes

only, must be removed and

discarded before operating your

riding mower.

WARNING: The mowing deck

is capable of throwing objects.

Failure to operate the riding

mower without the discharge

cover in the proper operating

position coutd result in serious

personal injury and/or property

damage.

WARNING

Make sure the riding

mower's engine is

off, remove the igni-

tion key, and set the

parking brake before

removing the shipping

brace.

[he shipping brace,

Jsed for packaging

purposes only, must

be removed and

discarded before

operating your riding

mower.

The mowing deck is

capable of throwing

objects. Failure to

operate the riding

mower without the

discharge cover in

the proper operating

position could result

in serious personal

injury and/or property

damage.

NOTE: Any reference

in this manualto the

RBGHTor LEFT side of

Know Your Lawn Tractor

@ @

A PTO(BladeEngage)Lever G CruiseControIButton

B Ammeter H IgnitionSwitchModule

C ParkingBrakeButton I BrakePedal

D ShiftLever J DrivePedal

E Cup Holder K DeckLift Lever

F Throttb Lever

NOTE:Anyreferencein thismanualto the RIGHTor LEFTside of the tractoris observedfromoperator'sposition,

of the engineandwhenpushedall the wayforward,the

chokecontrolalso,Whensetina given position,the

throttlewill maintaina uniformenginespeed,SeeFigure

IMPORTANT:Whenoperatingthetractorwiththe cutting

deckengaged,becertainthatthe throttb bver is always

inthe FAST(rabbit)position,

Choke Control

Movingthethrottle bver all theway

forwardactivatestheengine'schoke

control Activatingthe chokecontrol

closesthe chokeplateonthe carbu-

retorandaids instartingthe engine,

Referto Starting The Engine in this

section of the manualfordetailed

startinginstructions,

Drake PedaJ

Thebrakepedalis locatedonthe

rightfrontside of the tractorabove

the drivepedalalongthe running

board,The brakepedalcan be

usedfor suddenstopsor settingthe

parkingbrake,

NOTE:The brakepedalmustbe

fullydepressedto activatethe safety

interlockswitchwhenstartingthe

tractor,

ignition Switch Module

WARNING: Never Jeavea running

machine unattended. Always

disengage PTO, move shift lever

into neutraJ position, set parking

brake, stop engine and remove

key to prevent unintended

starting.

Tostartthe engine,insertthe keyintothe ignitionswitch

andturnclockwiseto theSTARTposition,Rebasethe

keyintothe NORMALMOWINGMODEpositiononce

the enginehasfired,

Tostopthe engine,turnthe ignitionkeycounterclockwise

to the OFFposition,SeeFigure7,

Position

Slow _>

Position

Figure 6

>osition

Normal

.Mowing Mode

Start

Position

Figure 7

iMPORTANT:Priorto operatingthe tractor,referto both

Safety interlock Switches andStarting The Engine

inthissectionof the manualfor detailedinstructions

regardingthe IgnitionSwitchModub and operatingthe

tractorin REVERSECAUTIONMODE,

Drive Pedal

The drivepedalis locatedbelowthe

brakepedalon the rightfrontside of

the tractoralongthe runningboard,

Depressthe drivepedalwithyour

rightfootwhenthe tractorshift bver

is ineitherFORWARDor REVERSE

to causethetractorto move,Ground

speedis also controlbdwiththe drive

pedal Thefurtherdownthe pedalis

depressed,the fasterthe tractorwill travel The pedalwill

returnto its originalpositionwhenit's not depressed,

iMPORTANT:Alwaysset the parkingbrakewhenleaving

the tractorunattended,

machine unattended.

A ,vaysd sengage

PTO,move Shift lever

into neutral position,

set parking brake, stop

engine and remove key

to pre_ent un!ntended

Safety Interlock

REVERSE CAUTION

NOTE: The PTO (Blade

Engage) lever must be

in the disengaged (OFF)

sositionwhen starting

:heengine, when

traveUingin reverseand

if the operator leaves

the seat.

AMPS

Figure 8

Ammeter

Theammetermeasuresthe electricaloutputof the

engine'schargingsystem.Undernormaloperating

conditions,withengineat full throttle,the ammeter

shouldindicatepositivecharge.

PTO (B_ade Engage} Lever

o.t i-6--I

OFF, PTO

PTO / BLADE ENGAGE

The PTO(BladeEngage)leveris locatedon the left side

of the dashboardnext to the steeringwheel Movethe

PTO(BladeEngage)leverforwardto engagethe powerto

the cuttingdeck or other(separatelyavailable)attach-

ments;movethe PTO(Blade Engage)leverrearwardto

disengagethe powerto theattachments.

NOTE:The PTO(BladeEngage)levermust be in the

disengaged(OFF)positionwhenstartingthe engine,

whentravelingin reverseand if the operatorleavesthe

seat.

Seat Adjustment Knobs

Toadjustthe seat position,loosenthe two seat adjust-

mentknobsandrepositionthe seat to the desired

position.Oncea comfortablepositionis found,tightenthe

adjustmentknobsto lock the seat in place.Referto Seat

Adjustmentinthe Adjusting Your Tractor sectionof this

manualfor moredetailedinstructions.

Deck Lift Lever

Foundon yourtractor'srightfender,thedecklift leveris

usedto changethe heightof the cuttingdeck.To use,

movethe leverto the left, thenplacein the notchbest

suitedfor yourapplication.

Parking Brake Button

Tosetthe parkingbrake,fully

depressthe brakepedalandpush

the parkingbrakebuttonin. Hold

the buttonin whiletakingyour foot

offthe brakepedal.Boththe park-

ingbuttonand the brakepedal will

thenstay depressed.To release

the parkingbrake,depressthe

brakepedalslightly.The parking

brakebuttonwill thenreturnto its

originalposition.

NOTE:The parkingbrakemustbesetif theoperator

leavesthe seatwith the engine runningor the enginewill

automaticallyshutoff.

IMPORTANT:Alwayssetthe parkingbrakewhen leaving

the tractorunattended.

Thecruisecontrolbuttonis

locatedonthe tractordash

panelto the left of the ignition

switch,Pushthe cruisecontrol

buttonwhiletravelingforwardat a

desiredspeed,While holdingthe

buttonin, releasepressurefrom

the drivepedal This will engage

the cruisecontroland allowthe

tractorto remainat thatspeed

withoutapplyingpressureto the

drivepedal Depressthe brake

pedalor the drivepedalto deactivatecruisecontrol

Referto Setting the Cruise Control laterinthis section

the manualfor detailedinstructionsregardingthe cruise

controlfeature,

NOTE:Cruisecontrolcan NOTbe engagedat the

tractor'sfastestgroundspeed,if the operatorshould

attemptto do so, the tractorwill automaticallydecelerate

to the fastestoptimalmowinggroundspeed,

Shift Lever

Theshift leveris locatedon the

leftside of the fenderand has

threepositions,FORWARD,

NEUTRALand REVERSE,The

brakepedalmustbe depressed

andthe tractormustnot be in

motionwhenthe movingshift

lever,

IMPORTANT:Neverforcethe

shift lever,Doingso may resultin

seriousdamageto the tractor's

transmission,

Safety JnterJock Switches

Thistractoris equippedwitha safetyinterlocksystem

for the protectionof the operator,If the interlocksystem

shouldevermalfunction,donot operatethe tractor,

ContactanauthorizedWhiteOutdoorservicedealer,

, Thesafetyinterlocksystempreventstheengine

fromcrankingor startingunlessthe parkingbrakeis

engaged,and the PTO(BladeEngage)leveris in the

disengaged(OFF)position,

• Theenginewill automaticallyshut off if theoperator

leavestheseatbeforeengagingthe parkingbrake,

leverinthe engaged(ON)position,regardlessof

whetherthe parkingbrakeis engaged,

Withthe ignitionkey in the NORMALMOWING

position,the enginewillautomaticallyshut off if the

PTO(BladeEngage)leveris movedintothe engaged

(ON) positionwiththe shift leverin Reverse,

Reverse

WARNING: Do not operate the

tractor if the interlock system

is malfunctioning. This system

was designed for your safety and

protection.

Caution Mode

WARNING: Use extreme caution

whiJe operating the tractor in

the REVERSE CAUTION MODE.

Always look down and behind

before arid while backing. Do not

operate the tractor when children

or others are around. Stop the

tractor immediately if someone

enters the area.

The REVERSECAUTIONMODEpositionof the key

switchmoduleallowsthe tractorto be operatedin

reversewiththe blades(PTO)engaged,

iMPORTANT:Mowingin reverseis not recommended,

To usethe REVERSECAUTIONMODE:

iMPORTANT:TheoperatorMUSTbe seated in the

tractorseat,

1, Start theengineas previouslyinstructedin this

Operator'sManuak

WARNING

Do not operate the

tractor if the interJock

system is maJfunction-

ing. This system was

designed for your

safety and protection.

Use extreme caution

while operating the

tractor in the REVERSE

CAUTION MODE.

AJways Jookdown and

behind before and

Nhile backing. Do not

operate the tractor

when ehiJdren or oth-

ers are around. Stop

the tractor immediateJy

if someone enters the

area.

Reverse

ndicator .Push Button

Light Reverse

Stop CautionMod_

Position Position

Start

Position

X... ..,,'

Fig.re'

2. Turnthe key from the NORMALMOWING(Green)

positionto the REVERSECAUTION_,IODE(Yellow)

positionof the key switchmodule. See Figure9.

3. Depressthe REVERSEPUSHBUTTON(Orange,

TriangularButton)at the top, rightcornerof the key

switchmodub.The red indicatorlight atthe top, left

cornerof the keyswitch modulewill be ON while

activated.SeeFigure9.

4. Onceactivated(indicatorlightON), thetractorcan

bedrivenin reversewiththe cuttingblades(PTO)

engaged.

5. Alwayslook downand behindbeforeand while

backingto makesure no childrenare around.

6. After resumingforwardmotion,returnthe keyto the

NORMALMOWINGposition.

IMPORTANT:The REVERSECAUTIONMODEwill

remainactivateduntil:

a. The keyis placedin eitherthe NORMALMOW-

INGpositionorSTOPposition.

b. Theoperatorengagesthe parkingbrakebyfully

depressingthe brakepedaland holdingit down

whilegentlypushingtheparkingbrakebutton

inward,

Engaging the Parking Brake

Toengagethe parkingbrake:

1. Fullydepressthe brakepedaland hold it downwith

yourfootwhilegentlypushingtheparkingbrake

buttoninward.

2. Holdthe parkingbrakebuttonin while removingyour

footfrom thebrakepedal

AVOID SERIOUS INJURY OR DEATH

GO UPAND DOWN SLOPES,NOT ACROSS,

AVOIDSUDDENTURN&

DO NOT OPERATETHEUNITWHERE IT COULDSLIPORTIR

IFMACHINESTOPSGOINGUPHILL,STOP BLADE(S) AND

BACK DOWNHILLSLOWLY

DO NOT MOWWHEN CHILDRENOR OTHERSAREAROUND,

NEVER CARRYCHILDREN,EVENWITH BLADES OFE

LOOK DOWNAND BEHINDBEFOREAND WHILE BACKING.

KEEP SAFETY DEVICES(GUARDS,SHIELDS,AND SWITCHES

IN PLACEAND WORKING,

REMOVEOBJECTSTHATCOULDBE THROWNBYTHE

BLADE(Sb

KNOW LOCATIONAND FUNCTIONOF ALL CONTROLS.

BE SUREBLADE(S) AND ENGINEARESTOPPEDBEFORE

PLACINGHANDSORFEET NEAR BLADE(Sb

BEFORE LEAVINGOPERATOR'SPOSITION,DISENGAGE

BLADE(S), PLACETHE SHIFT LEVER IN NEUTRAL ENGAGE

BRAKE LOCK SHUT ENGINEOFF AND REMOVEKEY_

READ OPERATOR'S MANUAL

3. Onceengaged,the parkingbrakebuttonand the brake

pedalwill lock in the "down"position.

Todisengagethe parkingbrake:

1. Slightlydepressthe brakepedal

NOTE:The parkingbrakemustbe engagedif the operator

haves the seatwith the engine runningor the enginewill

automatballyshutoff.

Setting the Cutting Height

1. Sebct the heightpositionof the cuttingdeck by placing

the deck lift leverin anyof thesixdifferentcutting

heightnotcheson the right sideof the fender.

2. Adiustthe deck wheelsso that they are between

_4=inchand_/2=inchabovetheground whenthetractor

is ona smooth,flat surfacesuch as a driveway',

WARNING: Keep hands and feet

away from the discharge opening

of the cutting deck.

_i iii

NOTE:The deckwheelsarean anbscalp featureof the 1, Ifthe bladesare engaged,placethe PTO(Blade

deckand are notdesignedto supportthe weightof the Engage)leverin thedisengaged(OFF)position,

cuttingdeck, 2, Turnthe ignitionkeycounterclockwiseto the STOP

Referto Leveling the Deck on page 18of this manual position,

for moredetailedinstructionsregardingvariousdeck 3, Removethe key from the ignitionswitchto prevent

adiustments, unintendedstarting,

Starting the Engine

.,_ilil_l WARNING: Do not operate the

tractor if the interlock system is

malfunctioning. This system was

designed for your safety and

protection.

NOTE:Referto the TRACTORSET-UPon page8 of this

manualfor GasolineandOilfill-up instructions,

1, insert the tractorkey intothe ignitionswitch,

2, Race the PTO(BladeEngage)leverin the disem

gaged(OFF)position,

3, Engagethe tractor'sparkingbrake,

4, Activatethe chokecontrol,

5, Turnthe ignitionkey clockwiseto the STARTposition,

Afterthe enginestarts, releasethe key,it will returnto

the ON position,

IMPORTANT:Do NOTholdthe key in the STARTposi-

tionfor longerthan ten secondsat a time,Doingso may

causedamageto your engine'selectricstarter,

6, Afterthe enginestarts,deactivatethe chokecontrol

andplacethe throttlecontrolin the FASTposition,

NOTE:Do NOTleavethechokecontrolon whileoperat-

ingthe tractor,Doingso will result in a "rich" fuelmixture

andcausethe engineto run poorly,

Stopping the Engine

Driving The Tractor

WARNING: Avoid sudden starts,

e×-cessive speed and sudden

stops.

WARNING: Do not leave the seat

of the tractor without first placing

the PTO (Blade Engage} lever in

the disengaged (OFF} position,

depressing the brake pedal and

engaging the parking brake. If

leaving the tractor unattended,

also turn the ignition key off and

remove the key.

1, Depressthe brakepedal to releasethe parkingbrake

and letthe pedalup,

2, Movethe throttleleverinto the FAST(rabbit)position,

IMPORTANT:Do NOTuse theshift leverto changethe

directionof travelwhenthetractoris inmotion,Always

usethe brakepedalto bringthe tractorto a complete

stopbeforeshifting,

3, To moveforward,placethe shift leverin the FOR-

WARDposition,thenslowlydepressthe drivepedal

untilthe desiredspeedis achieved,

4, To movein reverse,placethe shift leverin the

REVERSEposition,checkthatthe areabehindis

clear thenslowlydepressthe drivepedal

WARNING: if you strike a foreign

object, stop the engine, discon-

nect the spark plug wire(s)

and ground against the engine.

Thoroughly inspect the machine

for any damage. Repair the

damage before restarting and

operating

WARNING

Do not operate the

tractor if the interlock

system is malfunction-

ing. This system was

designed for your

safety and protection.

if you strike a foreign

object, stop the

engine, disconnect

the spark plug wire(s)

and ground against

the engine. Thoroughly

inspect the machine

for any damage. Repair

the damage before

restarting and operat-

ing.

Do not leave the seat

of the tractor without

first placing the PTO

(Blade Engage) lever in

the disengaged (OFF)

position, depressing

the brake pedal and

engaging the parking

brake. If leaving the

tractor unattended,

also turn the ignition

key off and remove the

_ey.

!'!! ,i

/"q Driving On S_opes Tochangeto the reversedirectionwhenoperatingwith

/ A E Referto the SLOPEGAUGEon page3 to helpdeter= cruisecontrol,depressthe brakepedalto disengagethe

///_ L mineslopeswhereyou mayoperatethe tractorsafely, cru,secontroland bnngthe tractortoe completestop,

F] Thenplacethe shift leverin the REVERSEpositionand

WARNING: Do not mow on depressthedrivepedal,

t,NING

tractor could overturn

and cause serious

injury.

To help avoid blade

contact or a thrown

object injury, keep

bystanders, helpers,

children and pets at

least 75 feet from the

machine while it is in

operation. Stop ma-

chine if anyone enters

the area.

inclines with a slope in excess

of 15 degrees (a rise of approxi-

mately 2-1/2 feet every 10feet).

The tractor could overturn and

cause serious injury.

Mowupanddownslopes,NEVERacross,

Exerciseextremecautionwhenchangingdirection

onslopes,

• Watchfor holes, ruts,bumps,rocks, or otherhidden

obiects,Uneventerraincouldoverturnthe machine,

Tall grasscan hide obstacles,

• Avoidturns whendrivingon a slope, If a turn must

be made,turn downthe slope,Turningup a slope

greatlyincreasesthechanceof a rollover,

, Avoidstoppingwhendrivingupa slope, If it is

necessaryto stopwhiledrivingupa slope,start up

smoothlyandcarefullyto reducethe possibilityof

flippingthetractoroverbackward,

Setting The Cruise Control

1, Race the shiftleverin the FORWARDposition,

thenslowlydepressthedrive pedal untilthedesired

speedis achieved,

2, Lightlydepressthe cruisecontrol button,

3, While continuingto hold the cruisebutton in, lift your

footfrom thedrive pedal(youshouldfeel thecruise

latchengage),

Onceengaged,thecruise controlbuttonand thedrive

pedalwill lockin the "down"position,and thetractorwill

maintainthe sameforwardspeed,

NOTE:Cruisecontrolcan not be engagedat the

tractor'sfastestgroundspeed,If the operatorshould

attemptto do so, the tractorwill automaticallydecelerate

to the fastestoptimal mowinggroundspeed,

Engaging the Blades

Engagingthe PTO(Blade Engage)transferspowerto the

cuttingdeckor other (separatelyavailable)attachments,

Toengagethe blades,proceedas follows:

1, Movethe throttlecontrolleverto the FAST(rabbit)

position,

2, Graspthe PTO(BladeEngage)leverand pivotit all the

wayforwardintothe engaged(ON) position,

3, Keepthe throttleleverin the FAST(rabbit)position

for the mostefficientuseof the cuttingdeck or other

(separatelyavailable)attachments,

IMPORTANT:Theenginewillautomaticallyshutoff if the

PTOis engagedwith the shiftleverin positionfor reverse

travelwiththe ignitionkey in the NORMALMOWING

position,Referto SafetyInterlockSwitchesearlierinthis

section,

Using the Deck Lift Lever

Toraisethe cuttingdeck, movethe deck lift leverto the

left, thenplace it in the notch bestsuited for yourapplica-

tion,Referto SettingThe CuttingHeightearlierin this

section,

Mowing

WARNING: To help avoid blade

contact or a thrown object injury,

keep bystanders, hetpers, children

and pets at least 75 feet from the

machine while it is in operation.

Stop machine if anyone enters the

area.

Thefollowinginformationwill be helpfulwhenusingthe

cuttingdeckwith yourtractor:

Disengagethe cruisecontrolusingone of the following

methods:

1, Depressthe brakepedalto disengagethe cruise

controlandstop the tractor,

2, Lightlydepressthe drivepedal

WARNING:PJanyourmowing

patternto avoiddischargeof

materialstowardroads,side°

waJks,bystandersandthelike.

Nso, avoid discharging material

against a wall or obstruction

which may cause discharged

materiaJ to ricochet back toward

the operator.

Do not mowat high groundspeed,especiallyif a

mulchkit or grasscollectoris installed,

, For bestresultsit is recommendedthat the firsttwo

lapsbe cutwith the dischargethrowntowardsthe

center,Afterthefirst two laps, reversethe directionto

throwthe dischargeto the outsidefor the balanceof

cutting,Thiswill givea betterappearancetothe lawn,

Do notcut thegrass too short,Shortgrass invites

weedgrowthandyellowsquicklyin dryweather,

Mowingshouldalwaysbedonewiththeengineat full

throttle,

Underheavierconditionsit maybenecessarytogo

backover thecut areaa secondtime to get a clean

cut,

Do NOTattemptto mowheavybrushandweedsand

extremelytall grass,Yourtractoris designedto mow

lawns,NOTclearbrush,

Keepthe bladessharpand replacethe bladeswhen

worn,RefertoCutting Blades inthe Maintaining

YourLawnTractorsectionof this manualfor proper

bladesharpeninginstructions,

Mu{ching (If Equipped)

Somemodelscomeequippedwitha mulchkit which

incorporatesspecialblades,alreadystandardon the

tractor,ina processof recirculatinggrassclippings

repeatedlybeneaththecutting deck,The ultra-fine

clippingsarethenforced backinto thelawnwherethey

actas a naturalfertilizer,Observethe followingpointsfor

the best resultswhenmulching,

• Neverattemptto mulchif the lawnis damp,Wet grass

tendsto stick to the undersideof the cuttingdeck

preventingpropermulchingof the clippings,

Figure 10

Do NOTattemptto mulchmorethan 1/3 the total

heightof the grass or approximatelylq/2 inches,

Doingso will causetheclippingsto dump up beneath

the deck and not be mulchedeffectively,

Maintaina slowgroundspeedto allowthegrass

clippingsmoretimeto effectivelybe mulched,

, Alwayspositionthe throttlecontrolleverin the FAST

(rabbit)positionandallow it to remaintherewhile

mowing,Failingto keepthe engineat full throttle

placesstrainon thetractor'sengineanddoes not

allow thebladesto properlymulchgrass,

NOTE:Itis not necessaryto removethe dischargechute

tooperatethe mowerwith the mulchkit installed,

To operatethe cuttingdeck withoutmulching,simply

removethe mulchplugby unthreadingthe plasticwing

nutwhichfastensit to the cuttingdeck,This will allowthe

clippingsto dischargeoutthe side, See Figure10,

Headlights

, The lampsare ON wheneverthe ignitionkeyis moved

out of the STOPposition,

• The lampsturn OFFwhen the ignitionkey is movedto

the STOPposition,

tern to avoid discharge

of materials toward

roads, sidewalks, by-

standers and the like.

A so, avo d d scharg rig'

material against a wall

or obstruction which

may cause discharged

material to ricochet

back toward the

operator.

regardingtirepressure.

Figure 11

/ / /

Figure 12

WARNING:Neverattempt to make

any adjustments while the engine is

running,except where specified in the

operator's manual.

Leveling the Deck

NOTE:Checkthe tractor'stire pressurebeforeperform-

ingany deck levelingadiustments.Referto Tires in the

Maintaining Your Tractor sectionof this manualfor

informationregardingtire pressure.

Front To Rear

The front of the cuttingdeck is supportedbya stabilizer

barthatcan adiustedto levelthe deck from front to rear.

The front of the deck shouldbe between1/4-inchand

3/8-inchlowerthanthe rear of thedeck. Adiustif

necessaryas follows:

1. With thetractor parkedon a firm, levelsurface,place

the deck lift leverin the top notch(highestposition)

androtatethe blade nearestthe dischargechute so

properadiustmentandproceed,if necessary,to the

nextstep.

3. Loosenthe two iam nuts,if present,on the rear sideof

the deck stabilizerbracket.

4. Locatethe lock nut on the front sideof the stabilizer

bracket.SeeFigure11.Tightenthe lock nutto raise

the frontof thedeck; loosenthe lock nut to lowerthe

frontof the deck.

5. Retightenthe two jam nuts loosenedearlierwhen

properadiustmentis achieved.

Side to Side

If thecutting deckappearsto be mowingunevenly,a side

to sideadiustmentcan be performed.Adiustif necessary

as follows:

1. With thetractor parkedon a firm,levelsurface,place

the deck lift leverin the top notch(highestposition)

androtate bothbladesso that they are perpendicular

withthe tractor.

2. Measurethe distancefrom the outsideof the left blade

tip to the groundand the distancefrom theoutsideof

the rightblade tipto the ground.Bothmeasurements

takenshouldbeequal If they'renot,proceedto the

nextstep.

3. Loosen,butdo NOTremove,the hexcap screwon

the left deck hangerbracket.See Figure12.

4. Balancethe deck by usinga wrenchto turnthe

adiustmentgear(foundimmediatelybehindthe hex

capscrewiust loosened)clockwise/uporcounteF

clockwise/down.Thedeckis properlybalancedwhen

both bladetip measurementstakenearlierare equal.

5. Retightenthe hex capscrewon the left deck hanger

bracketwhenproperadiustmentis achieved.

Parking Brake Adjustment

WARNING:Neverattempt to adjust the

brakes while the engine is running.

Always disengage PTO, move shift

lever into neutral position, stop engine

and remove keyto prevent unintended

starting.

If thetractordoes notcome to a completestop whenthe

brakepedaliscompletelydepressed,orif the tractor's

rearwheelscanroll withthe parkingbrakeapplied,the

brakeis in needof adiustment.The brakedisc can be

foundonthe rightside of the transmissionin the rearof

the tractor.Adiustif necessaryas follows:

1. Lookingat the transmissionfrom the rightsideof the

tractor,locatethecompressionspringandbrakedisc.

2, Loosen,but do NOTremove,the hex nutfoundon the

rightsideof the brakeassembly,See Figure13,

3, Usinga feelergauge,set the gap betweenthe brake

discandthe brakepuck at ,011",

4, Reqightenthe hexnut loosenedearlier,

Seat Adjustment

WARNING:Before operating this

machine, make sure the seat is engaged

inthe seat stop, stand behind the

machine and pull back on seat until fully

engagedintostop.

1, Flipthe seat up as shownin Figure14,

2, Loosenthetwo seat adiustmentknobslocatedunder

the seat, See Figure14,

3, Slidethe seat forwardor rearward,then tightenthe

knobsto lock the seat at thedesiredposition,Put the

seatdownto the operatingposition,

Set gap ,011

Figure 13

Hex Nut

Steering Adjustment

If the tractorturnstighter in one directionthan theother,

or if the ball ioints are being replaceddue to damageor

wear,the steeringdrag linksmay need to be adiusted,

Adiustthedrag links so that equal lengthsare threaded

into the ball iointon the left and right side:

1, Loosentheiam nut foundon the drag linkat the rear

of the ball ioint, See Figure15,

2, Removehex nuton the topof ballioint, See Figure15,

3, Threadthe balljointtowardtheiam nutto shortenthe

draglink, Threadthe ballioint awayfrom theiam nut

to lengthenthe drag link,

4, Replacehex nutand retightenthejam nut after proper

adiustmentis achieved,

NOTE:Threadingthe ballioints too far ontothe drag links

will causethe front tires to "toe=in"too far, Propertoe=inis

between1/16"and5/16",

Figure 14

Fronttire toeqncan be measuredas follows:

1, Placethe steeringwheelin positionfor straightahead

travek

2, Infront of the axle, measurethe distancehorizontally

fromthe insideof the left rimto the insideof the right

rim,Notethe distance,

3, Behindtheaxle, measurethe distancehorizontally

fromthe insideof the left rimto the insideof the right

rim,Notethe distance,

4, The measurementtaken in frontof the axle shouldbe

between1/16"and5/16"lessthanthe measurement

takenbehindthe axle, Adiustif necessary,

Figure 15

NOTE: Threading the

bal joints too far onto

the drag linkswill cause

the front tires to "toe-in'

too far, Propertoe-in

is between 1/16"and

5/16".

inorder te rep!acethe

,r Single Shown

Figure 16

WARNING: Before performing

any maintenance or repairs,

disengage PTO, move shift Jever

into neutraJ position, set parking

brake, stop engine and remove

key to prevent unintended

starting.

Engine

Referto the KoNer Operator/Owner Manual for

engine maintenance instructions.

Checkengine oil level beforeeachuseas instructed

in the Kohbr Operator/OwnerManualpackedwith your

unit,Follow the instructionscarefully.

Changing Engine Oil

NOTE:Dependingonthe engine modelfoundon your

tractor,it may be necessaryto removethe tractor'sside

panelin order to replacethe oil filter (if so equipped),

1, Pop openthe protectivecap on the end of the oil

drainvalveto exposethe drainport, See Figure16,

2, Removetheoil fill cap/dipstick fromthe oil fill tube,

3, Pushthe oil drain hose(packedwith this manual)

ontothe oil drain port, Route theoppositeend of the

hoseintoan appropriateoil colbction containerwith

a capacitygreatenoughto colbct the usedoil

4, After theoil has finisheddraining,pushtheoil drain

valvebackin, rotateit clockwiseto lock the valve

closedandre=capthe end of the oil drainvalve to

keepdebrisfromenteringthedrainport,

5, Servicethe oil filter (if soequipped)as instructedin

the separateKohbr Operator/OwnerManualpacked

withyourunit,

Performthe abovestepsinthe oppositeorder afteroil

hasfinisheddraining,

6, Refillthe enginewith newmotoroil as instructedin the

KohlerOperator/OwnerManualpackedwithyour unit,

IMPORTANT:Referto the KohlerOperator/Owner

Manualpackedwithyourunit for informationregardingthe

quantityand properweightof motoroil

Air Cleaner

Servicethe pre=cbaner,if so equipped,and cartridge/air

cbaner elementas instructedin the Kohbr Operator/

OwnerManualpackedwithyour unit,

Spark PJug(s)

Thesparkplug(s)shouldbecleanedand the gap reset

oncea season,Sparkplug replacementis recommended

at the startof each mowingseason,Referto the Kohbr

Operator/OwnerManualfor correctplugtype and gap

specifications,

Lubrication

WARNING: Before lubricating,

repairing, or inspecting, atways

disengage PTO, move shift lever

into neutral position, set parking

brake, stop engine and remove

key to prevent unintended start-

ing.

Engine

Lubricatethe enginewithmotoroil as instructedin the

KohlerOwnerManualpackedwith yourunit,

Pivot Points & Linkage

Lubricateall the pivotpointson the drivesystem,parking

brakeandlift linkageat bast oncea seasonwith lightoil

Rear Wheels

The rearwheelsshouldbe removedfrom the axles once

a season,Lubricatethe axles and the rimswell with an

all=purposegreasebeforere=installingthem,

Front AxJes

Eachendof the tractor'sfrontpivotbaris equippedwith a

greasefitting,Lubricatewitha greasegun afterevery25

hoursof tractoroperation,

Cleaning the Engine And Deck

Anyfuel or oil spilledon the machineshouldbe wiped

off promptly,DoNOTallowdebristo accumulatearound

the coolingfins of the engine or on anyotherpart of the

machine,

IMPORTANT:The useof a pressurewasherto cban your

tractoris NOTrecommended,It maycausedamageto

ebctrbal components,spindles,pulleys,bearingsor the

engine,

Deck Wash System TM

Yourtractor'sdeckmaybeequippedwitha waterport on

itssurfaceas part of its deck wash system,

If equipped,usethe DeckWashSystemTM to rinsegrass

clippingsfromthe deck'sundersideandpreventthe

buildupof corrosivechemicals,Completethe following

stepsAFTEREACHMOWING:

1, Drivethe tractorto a level,clearspot on yourlawn,

nearenoughto a water sillcock(spigot)for your

gardenhoseto reach,

IMPORTANT:Makecertainthetractor'sdischargechute

is directedAWAYfromyourhouse,garage,parkedcars,

etc,

2, Disengagethe PTO(BladeEngage),movethe shift

leverintothe neutralposition,setthe parkingbrake,

andstop theengine,

3, Threadthe hosecoupler(packagedwith yourtractor's

Operator'sManual)ontothe endof yourgardenhose,

4, Attachthe hosecouplerto the waterport on your

deckssurface,SeeFigure17,

5, Turnthe wateron,

6, Whilesittingin theoperator'spositionon thetractor,

re=startthe engineandplacethe throttleleverin the

FAST(rabbit)position,

7, Disengagethe parkingbrake,

8, Movethe tractor'sPTO(BladeEngage)intothe ON

position,

9, Remain in the operator's position with the cutting

deckengagedfor a minimumof two minutes,allowing

the undersideof thecuttingdeck to thoroughlyrinse,

10,Movethe tractor'sPTO(BladeEngage)intothe OFF

position,

11,Turnthe ignitionkeyto the STOPpositionto turn the

tractor'sengineoff andengagethe parkingbrake,

12,Turnthe wateroff anddetachthe hosecouplerfrom

the waterport on yourdeckssurface,

13,Repeatsteps4=11on theoppositeside of thecutting

deck,

Cutting Deck Removal

Toremovethe cuttingdock, proceedas follows:

1, Placethe PTO(BladeEngage)knob(or lever)in the

disengaged(OFF)positionand engagethe parking

brake,

2, Lowerthe deck by movingthedeck lift leverinto the

bottomnotchon the rightfender,

3, Removethe hairpinclip that securesthePTOcableto

the rearof thecuttingdeck, See Figure18,Remove

the PTOcableand accompanyingspringfrom the

cuttingdeck,

4, Removethe deck belt from aroundthetractor's

enginepulley,

i \

i \\

/' ii,_i_ i i_

,jJ

Figure 17

Figure 18

/ // "

// /

Figure 19

5, Lookingat the cuttingdeck from the left side of the

tractor,locatethe deck supportpin on the rear left

side of the deck,See Figure19,

iMPORTANT

Make certain the

tractor's discharge chute

is directed AWAYfrom

your house,garage,

parked cars. etc.

WARNING

Never exceed the

maximum inflation

_ressureshown on the

sidewall of the tire.

Batteries g ive off an

.=xplosive gas whib

:barging. Charge bat-

tery in a wellventiJated

_rea and keep away

from an open flame

_r pilot light as on a

_vaterheater, space

heater, furnace, clothes

dryer or other gas

_ppliances.

Be sure to shut the

engine off, remove

ignition key, discon-

nect the spark plug

wire(s) and ground

against the engine to

prevent unintended

starting before remov=

ing the cutting blade(s)

for sharpening or

replacement. Protect

your hands by using

heavy gloves or a rag

tograsp the cutting

blade.

fromthe deck lift arm,

7, Rotatethe pin slightlytowardthe rear of the tractor

andreleasethe pin intothe hob provided,

8, Repeattheabovestepson thetractor'srightside,

9, Movethe deck lift bver intothe top notchon the right

fenderto raisedecklift armsup and outof the way,

lO,Genflyslide thecuttingdecktowardthe frontof the

tractorallowingthe hooksonthe deck to release

themselvesfromthedeck stabilizerrod,

11,Gentlyslidethe cuttingdeck (from the rightside)out

fromunderneaththe tractor,

Tires

WARNING: Never exceed the

maximum inflation pressure

shown on the sidewall of tire.

The recommendedoperatingtire pressureis:

Approximately10psifor the reartires

,, Approximately14psi for the fronttires

IMPORTANT:Referto the tire sidewallforexacttire

manufacturer'srecommendedormaximumpsi, Do not

overinfiate,Uneventire pressurecouldcausethe cutting

deckto mow unevenly,

Battery

The batteryis sealedand is maintenance-free,Acid

bvels cannotbe checked,

,, Alwayskeepthe batterycabbs and terminaBeban

andfreeof corrosivebuild-up,

,, After cleaningthe batteryand terminaB,apply a light

coatof petroleumicily or greaseto bothterminaB,

Alwayskeepthe rubberbootpositionedoverthe

positiveterminalto preventshorting,

IMPORTANT:If removingthe batteryforany reason,

disconnectthe NEGATIVE(Black)wire fromit's terminal

first,followedbythe POSITIVE(Red)wire.When

re-installingthe battery,alwaysconnectthe POSITIVE

(Red)wire itsterminalfirst,followedbythe NEGATIVE

(Black)wire.Becertainthat thewiresare connectedto

thecorrectterminals;reversingthemcould changethe

polarityandresult in damageto your engine'salternat-

ingsystem.

Charging

If thetractor hasnot beenput into usefor an extended

periodof time,chargethe batterywith an automotive-

type 12-voltchargerfor a minimumof one hour at six

amps.

WARNING: Batteries give off an

explosive gas while charging.

Charge battery in a well ventilated

area and keep away from an open

flame or pilot light as on a water

heater, space heater, furnace,

clothes dryer or other gas appli-

ances.

Jump Starting

WARNING: When removing or

installing the battery, follow

these instructions to prevent the

screwdriver from shorting against

the frame.

IMPORTANT:Neveriumpyourtractor'sdeadbatterywith

the batteryof a runningvehicle,

1. Connectend of one iumpercableto the positive

terminalof thegood battery,thenthe otherend to the

positiveterminalof the dead battery.

2. Connectthe otheriumpercableto the negative

terminalof thegood battery,thento the frame of the

unit with the dead battery.

WARNING: Failure to use this

procedure could cause sparking,

and the gas in either battery could

explode.

CJeaning

Cban the batteryby removingit fromthe tractorand

washingwitha bakingsodaandwatersolution,if neces-

sary,scrapethe batteryterminaBwith a wire brushto

removedeposits,CoatterminaBandexposedwiringwith

greaseor petroleumicily to preventcorrosion,

Battery Failures

Somecommoncausesfor batteryfailureare:

. incorrectinitialactivation • undercharging

. overcharging • corrodedconnections

. freezing

Thesefailures are NOTcovered byyour tractor's

warranty.

Cutting Blades

WARNING:Besuretoshut the

engineoff, remove ignition

key, disconnect the spark plug

wke(s) and ground against the

engine to prevent unintended

starting before removing the cut-

ting Made(s} for sharpening or

replacement. Protect your hands

by using heavy gloves or a rag to

grasp the cutting Made.

WARNING: Periodically inspect

the Made spindles for cracks or

damage, especially if you strike a

foreign object. Replace immedi-

ately if damaged.

Thebladesmayberemovedas follows,

1, Removethe deck from beneaththe tractor,(referto

CuttingDeckRemovalon page21)thengently flip

the deck overto exposeits underside,

2, Placea blockof wood betweenthe centerdeck hous-

ingbaffleand the cuttingbladeto act asa stabilizer,

SeeFigure20,

3, Use a 15/18"wrenchto removethe hexflangenut

thatsecuresthe bladeto thespindleassembly,See

Figure20,

4, Toproperlysharpenthe cutting blades,removeequal

amountsof metalfrom bothends of the bladesalong

the cuttingedges, parallelto the trailingedge,at a

25° to 30° angle,

IMPORTANT:If the cuttingedgeof the blade hasalready

beensharpenedto within 1 5/8" fromthe edge,or if any

metalseparationis present,replacethe bladeswith new

ones,See Figure21,

It is importantthateachcuttingblade edge be ground

equallyto maintainproperbladebalance,

Whenreplacingthe blade,be sureto installthe blade

withthe sideof the blade marked"Bottom" (orwith

a part numberstampedin it) facingthe groundwhen

the moweris in the operatingposition,

IMPORTANT:Usea torquewrenchto tightenthe blade

spindlehexflangenutto between70foot-poundsand 90

foot-pounds,

Figure 20

Figure 21

FUSES

• A fuseis installedin yourtractor'swiringharnessto

protectthe tractor'selectricalsystemfromdamage

causedby excessiveamperage,

, If the electricalsystemdoes notfunction,or your

tractor'senginewill notcrank,first checkto becertain

thatthe fuse has notblown,

, It can eitherbe foundunderthe hoodmountedbehind

the top of the dashpanelon the supportbar,or under

the seat mountedto the insideof the tractorframe

nextto the batterytray,

Always use a fuse with the same

amperage capacity for replace-

ment.

Periodically inspect

the Made spindles for

cracks or damage,

especially if you strike

a foreign object.

Replace immediately if

damaged.

Always use a fuse with

:he same amperage

capacity for replace-

ment.

WARNING

Be sure to shut the

engine off, remove ig=

nition key, disconnect

the spark plugwire(s)

and ground against

the engine to prevent

unintended starting

before removing the

beJt(s).

WARNING: Be sure to shut

the engine off, remove ignition

key, disconnect the spark plug

wire(s) and ground against the

engine to prevent unintended

starting before removing the

belt(s).

Allbeltson yourtractorare subiectto wearandshould

bereplacedif anysigns of wearare present,

IMPORTANT:The V-beltsfoundon yourtractorare

speciallydesignedto engageanddisengagesafely,A

substitute(nomOEM)V-beltcan bedangerousby not

disengagingcompletely,Fora properworkingmachine,

usefactoryapprovedbelts,

Tochangeorreplacethe deck belt on yourtractor,

proceedas follows:

1, Removethe beltkeeperrod(s)from aroundthe

enginepulley,

2, Removethecuttingdeck as instructedearlier in this

section,

3, Removethe beltguardsby removingthe self-tapping

screwsthatfastenthem to the deck,

4, Carefullyloosen,butdo not remove,the deck idler

pulleys,

5, Removethe deck belt fromaroundall pulleys,including

the deck idler pulleys,

6, Routethe newbelt as shownin Figure23 and retighten

the deck idler pulleys,

7, Reinstallthe beltguardsremovedearlierand remount

the deckto thetractor,

8, Routethe beltaroundthe enginepulleyand reinstall

the belt keeperrod(s),

Changing the Transmission Drive

Be_t

NOTE:Severalcomponentsmust beremovedandspecial

tools(i,e, aidimpactwrench)in orderto changethe

tractor'sdrive belt,Seean authorizedMTDServiceDealer

to haveyourdrivebelt replacedor phone CustomerSup-

port as instructedon page2 for informationon orderinga

ServiceManual

Avoid the possibility of

a pinching injury. Do

not place your fingers

on the idler spring or

between the belt and a

pulley while removing

the belt.

LeftHand

SpindlePulley

IdlerPulleys

inePulley

42" Deck

Right Hand

Spindle Pulley

Figure 23

; of this manualbeforestoringfor an extendedperiod, Manualfor properenginecare prior to storingyourtractor,

WARNING

Drain fuel only into an

approved container

outdoors, away from

an open flame. Al-

low engine to coon.

Extinguish cigarettes,

cigars, pipes, and

other sources of igni=

tion prior to draining

fuel.

WARNING: Drain fueJonly into

an approved container outdoors,

away from an open flame. Allow

engine to coot. Extinguish

cigarettes, cigars, pipes, and

other sources of ignition prior to

draining fuel.

WARNING: Never store the

machine or fuel container indoors

where there is an open flame,

spark or pilot tight such as on

water heater, furnace, clothes

dryer or other gas appliance.

Attachments & Accessories

The followingattachmentsandaccessoriesare compatiblefor Model60TGSuper BroncoLawnTractors,Seethe

retailerfromwhichyoupurchasedyourtractor,anauthorizedTroyBilt ServiceDealeror phone1-866-840-6483for

informationregardingprice and availability,

NOTE:Model60TGLawnTractorsare NOTdesignedfor usewithany typeof ground-engagingattachments(e,g,

filleror plow),Useofthis typeof equipmentWILLvoid thetractor'swarranty,

MODEL " DESCRiPTiON

0EM-190-032

OEM-190:116

OEM-190-180

OEM-190-218

OEM-190-607"

OEM-190-658

OEM-190-672

OEM-190-833

42-inchTwo-stageSnowThrower

42-inchDeckMulchKit

TwinBaggerGrassCollector(for42-inchDecks)

RearWheelWeightKit

DeluxeTractorSunshade

GrilleGuard(mountsonfrontof tractor)

46-inch FrontDozerBlade

Notcompatiblewithtractorsequippedwitha GrassCollector

Never store the ma-

chine or fuel container

indoors where there is

an open flame, spark

or pilot light such

as on water heater,

furnace, clothes dryer

or other gas appliance.

NOTE: I_ BOTAMODES,_HE_ _pE_ATORLEAVES_EAT,EfiG]N_WILL

out importantsafety

instructionswhich, if

notfollowed,couUd

endangerthe personal

safetyand/or property

d yourselfand others.

Readand follow aH

instructionsinthis

manual beforeat-

temptingto operate

this machine, FaiBre

to complywith these

instructionsmayresult

in personalinjury,When

yousee this symbol,

HEED iTS WARNING!

Your Responsibility

Restrictthe use

of this power machine

to persons who reao

understand

and follow the warnings

For repairs beyond

the minor adjust-

ments listed here,

contact an authorized

service dealer.

Problem

Engine runs erratic

Cause

1, Unit runningwith CHOKEapplied,

2, Sparkplug wire(s) loose,

3, Blockedfuel lineor stab fuel

4, Ventin gas cap plugged,

5, Wateror dirt in fuel system,

6, Dirty air cbaner,

Remedy

1. PlacePTOknob (or lever)in

1, PushCHOKEcontrol(if so

equipped)in, or movethe throttle

controlout of the CHOKEposition,

2, Connectand tightenspark

plugwire(s),

3, Cban fuel line;fill tank with clean,

fresh(less than30 daysold)

gasoline,Replacefuel filter,if so

equipped,

4, Char vent or replaceif damaged,

5, Drainfuel tank, Refillwith

freshfuel

6, Replaceair cleanercartridge/eb=

mentor cleanpre=cleaner,if so

equipped,

Problem Cause Remedy

. 2, Air flowrestrbted,' 2, CLeangrassclippingsand debris

, , aroundthe engine:scoe!!ng

• • finsandbbwer housing.

Enginehesitates at 1, Sparkplug(s)gap tooclose, 1, Removespark plug(s)and reset

high RPM thegap,

' ..... equipped, ........ .....

Excessive

Vibration

Uneven cut

1, Cuttingblade looseor unbalanced,

2, Damagedor bentcutting blade,

1, Decknot balancedproperly,

2, Dullblade,

3, Uneventire pressure,

1, Tightenbladeand spindle,Balanc(

blade,

2, Replaceblade,

1, Performside-to-sidedeck adiust-

ment,

2, Sharpenor replaceblade,

3, Checktire pressurein all fourtires,

For repairs beyond

the minor adjust-

ments listed here,

contact an authorized

service dealer,

Model 60TG

Models w/Quick

Adjust Seat

Modelsw/Manually

Adjusting Seat

..... i

t_ ¸¸¸•'(iii_ii_ii_'i!¸ •

Ref. Part No. Description

No.

1 710-1268t Screw,#10-16x.375

2 712-04063 Nut, FlangeLock,5/16-18,GrF

3 712-3027t Nut, FlangeLock, 1/4-20

4 720-0309At SeatAdiusterGrip

5 726-0201t Nut, Speed,.3125ID

6 731-04074f Spacer

7 732-0499t CompressionSpring.41x 1.5

8 732-1184 Spring,Extension,.84Dia.x 4.6

9 736-0275t Wash,Flat,.344x.688 x.065

10 736-3019t Wash,Flat,.531x1.062x.134

11 738-0137At Screw,Shld, .340x.285,1/4-20

12 738-0296 Screw,Shoulder,.437x.268

13 738-0966t Screw,Should,.50x.925,3/8-16

14 783_0209D SeatBracket,Lift

15 783_0611t SeatStop

16 783-0738Ct SeatPivotBracket

17 783-0739At SeatAdiustmentLever

18 783-0753t SeatAdiustmentSelector

19 757-04001 LowBack Seat

20 726_3046 RatchetClip

21 735-0657 LR FootPad, Rubber

22 735-0656 RH FootPad,Rubber

23 710_0451 Bolt,Carriage,5/16_18.75,Grl

24 710-0599 Screw,1/4-20,0.500

25 710-0604A Screw,5/16-18,0.625

26 710-0895 Screw,1/4-15,0.750

27 731_1990 Cover,Lift Lever

28 731-2104C Cover,w/ CupHolder

29 736-3078 Washer,Flat,.344x 1.0x.063

30 783_04333A Fender

Ref. Part No. Description

No.

31 783-0677B Adiust.Brkt., Lift

32 783-1489B MountingBracket,Seat

33 710_0227 Screw,#8_18x.50

34 726_0279 Plate,Insulator

35 725_1303 SpringSwitch,Outer

36 725-1439 SpringSwitch,inner

37 726_0278 Plate,InsulatorBoss

38 683_04079 ShaftAssembly,Lift

39 712-04065 Nut,FlangeLock,3/8-16,GrF

40 714-0104 Pin,Cotter,.072Dia.x 1.13

41 714-0111 Pin,Cotter,3/32, 1.0

42 716-0106A Ring,EType,.625Dia.

43 720-0311 Grip, Handle,1/2

44 732_0874 Spring,Torsion

45 738-0138A Screw,5/16-18x.620Gr2

46 738-04130 Scr.,Shldr,.625x.165

47 741-0225 Bearing,RexFlange

48 746_0968 Cable, Lift, 16.16

49 747-04155 Handle,Lift

50 756_1154 Pulley,Roller

51 783_04494 Arm, Lift_RH

783-04711 Arm, Lift- LH

52 736-0607 LockWasher,5/16

53 710-0726 Screw,5/16-12

54 738-04012At ShoulderScrew

55 720-04061t Knob,3/8-16

56 736-0300t FlatWasher,.406x .875x .059

57 783-04081At SeatPivotBracket,ManualAdi.

58 710-0870t HexHeadWasherScrew,3/8_16

t if Equipped

NOTE:Tractorfeaturesvaryby model NOTall partslistedaboveandpicturedon the previouspageare standard

equipment.

parts,calltheCustomer

Service Line at

Model 60TG

Ref. Part No. Description

No.

1 710-04095 Hex Screw,3/8-16, 1,00,Gr5

2 710-0514 HexScrew,3/8q6, 1,00,Gr5

3 710-0843 HexScrew,5/16q8, 1,00,Gr5

4 711q408 Link,Drag,RH

5 711q409A Link, Drag,LH

8 712-0214 Nut, Hex Lock,3/8-24

7 712-04065 Nut, FlangeLock,3/8q6, Grf

8 712-0459 Nut, FlangeLock,7/16-20

9 712-3004A Nut, FlangeLock,5/16q8, Gr5

10 712-0240 Nut,Jam,7/16-20,Gr2

11 717q550E Gear,Steering,11/90Ratio

12 717q554 Gear,Pinion,Steering

13 723-0448A Bali Joint,7/16-20,Lock

14 736-3004 Washer,Flat,,406 x,875x,105

15 738-3084 Washer,Flat,,51 x 1,12x,08

16 710q260A Screw,5/16q8, 0,750

17 738-04154 Spacer,Shoulder,,38x 1,00x,31

18 738qOO1A Shaft,Steering,,6250D x24,25

19 741-0475 PlasticBushing,3801D

20 738-0143 Screw,Shoulder,,498 x,340

21 783-0726E PivotBracket,SupportRH

22 783_0727D PivotBracket,SupportLH

23 783-0728 PivotBracket,Bar

24 631-04028 SteeringWheel

25 731-04681 SteeringWheeICap

26 738-04128 ShoulderScrew,,5x2,380, 3/8q6

27 734_2290A DeluxeRubCap

28 738-0316 FlatWasher,,78 x 1,589x ,06

29 714-04039 CotterPin,5/32x 1,25

30 719-04105 CastIron PivotBar

31 731-04693 PushCap

32 638_04006 LH AxleAssembly,,750

33 638_04005 RHAxle Assembly,,750

34 728-04035 PushNut

35 783_04568 FrontDeck HangerBracket

36 712-0431 FlangeLockNut, 3/8q6

37 741-0656A HexFlangeBearing

38 634_04086 Wheel AssemblyComplete,15x 6

7344731 Tire Only 15 x 6 x 6

634-04081 Rim Onlyw/Valve Stem

parts, call the Customer

service Line at

or visit

wwWitioyb t,¢om:

Mode_ 60TG

Fief. Part No.

No.

1 710-0728

2 710-0599

3 783-04829

4 746-1084

5 731-1999

6 731-05357

7 738-04091

8 783-04827

9 783-04828

10 783-04840

783-04841

11 783-04606A

12 712-0185

13 751-10283

14 751-0603

15 710-1017

16 710-0895

17 710-3217

18 712-0142

Description

Screw,5/16-12x.750

Self-tappingScrew,1/4-20x.5

SidePanel- LH

ThrottleControl/Cable

ChokePlug

HeadlightLens

ShoulderScrew.43x.29

Hood,T Style

SidePanel- RH

PivotBracket- RH

PivotBracket- LH

GrillPivotBracket

SpeedNut

FuelTank,ThreeGallon

FuelCap

Screw,1/4-14x.625

Self-tappingScrew,1/4-15x.75

TrussPhillipsScrew,#8-32x.375

HexNut,#8-32

Ref. Part No.

No.

19 731-1857

20 731-05001A

21 731-04729

22 731-04728

23 747=04161

24 747=1196

25 629-04083t

26 725-04156

27 783-04908

28 710-0642

29 783-04909

30 725-0963

31 736-0270

32 710-1611B

33 725-1649

34 725-04227A

35 725-1745

725-1744

-- 725-04334t

Description

ThrottleControlKnob

DashPanel

CruiseControlButton

ParkingBrakeButton

TankSupportRod

Brake/CruisePivotRod

HeadlightWire Harness

SystemsInd. Monitorw/Ammeter

RHDashSupportPlate

Self-tappingScrew,1/4-20x.75

LHDashSupportPlate

Lamp

BellWasher.265x.75x.062

Screw,5/16-18x.75

HeadlightSocket

ignitionSwitch

ignitionKeyw/plastic cover

ignitionKeyw/oplasticcover

Wire Harness

t Not Shown

_FACTORY PARTS

Model 60TG

Left Hand Transmission

Bolt Mounting

Ref. Part No. Description

No.

1 17840 MountingBracket,Transaxle

2 725-04039 Switch,Interlock

3 17962 Plate,Switch

4 647-04020 LeverAssembly,Shift

5 710-0607 Screw,5/16-18,0.500

6 710-0726 Screw,5/16-12,0.750

7 710-0809 Screw,1/4-20,1.250

8 710-1007 Screw,Seres,3/8-16,1.500

9 710-1266 Screw,5/16-18,3.50, Gr5

10 710-3144 Screw,3/8-16,2.00,Gr5

11 711-0736 AdiustmentFerrule1/4-20x 1.

12 712-0241 Nut,Hex,3/8-24, Gr5

13 712-04063 Nut,FlangeLock,5/16-18,GrF

14 712-0431 Nut,FlangeLock,3/8-16,GrF

15 712-0700 Nut,Flange,9/16-18,Gr2

16 714-0104 Pin,Cotler.O72Dia.x 1.13

17 714-0111 Pin,Cotter,3/32, 1.0

18 714-0209 CotterPin,Internal,.125Dia.

19 714-0470 Pin,Cotter,1/8x 1.25

20 718-0758A PulleyHub,5/8 Spline

21 720-04028 Knob,Shift

22 723-3018 Ball Joint

23 731-04602 Sleeve.758x.821x3.3125

24 731-04604 Sleeve.758x.821x 2.4375

25 732-0384 Spring,Extension,.62Diax 6.12

26 732-0525 SpringClip, Shifter

27 732-0716C Spring,Extension.59ODx 4.00

28 732-0963 Spring,Extension.50Diax 6.37

29 736-0169 Washer,Lock,3/8

30 710-0224 Screw,#10-16.50

31 738-0372B Spacer,Shoulder,1.00x.38 x.38

32 747-04146A Rod, Shift

33 747-04164 Rod, Brake

34 747-1127 IdlerRod, Adiustable,3/8

35 748-0334 Spacer.68

36 750-0566A Spacer.260x.372x 1.030

37 754-0467 Belt,V-Type

38 754-0468 Belt,V-Type

39 756-04002 Pulley,V-Type,7.25Dia.

40 756-04224 IdlerPulley,Flat2.75OD

41 783-04283 Bracket,Shift

Ref. Part No. Description

No.

42 783-04360 Bracket,Shift,F-N-R

43 783-04442 Idler Bracket,CenterDouble

44 647-0031B ControlAssembly,Brake

45 647-0032A ControlAssembly,Speed

46 683-0266 PedalAssembly

47 710-0650 Screw,5/16-18,0.875

48 710-1260A Screw,5/16-18,0.750

49 710-1611B Screw,5/16-18,0.750

50 711-04159B Pin,3/8-16x2.68

51 731-2290A Hub Cap

52 732-0335 Spring,Compression..405x1.17

53 732-0955 Spring,Extension.50OD x 1.41

54 732-0963 Spring,Extension.50OD x 6.37

55 735-0662 Pad

56 735-3049 Pad,Brake

57 736-0187 Washer,Flat.64 x 1.24x.06, Ht

58 736-0262 Washer,Flat.385x.870x.092

59 736-0300 Washer,Flat.406 x.875x.059

60 736-3008 Washer,Flat.344x.750x.120

61 738-0155 Screw,Shoulder.437Diax.162

62 738-0380 Screw,Shoulder,.50x.27Lg,

63 741-0225 Bearing,Hex Flange

84 741-3065B Split Bearing,Hex Flange

65 747-04093 Rod,BrakeLock

66 747-04096 Rod,CruiseControl

67 748-04039BI Latch,CruiseControl

68 783-0732A Bracket,Lockout

69 783-0773A Ped,Brake

70 783-04612 Bracket,SteeringSupport

71 618-04034 Transmission,SingleSpeed

72 683-04055A BracketAssembly,Torque

73 683-04130 Bracket,Idler

74 710-0227 Screw,#8-18x.50

75 710-0514 Screw,3/8-16, 1.00

76 710-0604A Screw,5/16-18.625

77 710-1315 Screw,3/8-16, 1.250

78 712-0130 Nut, Lock,3/8-16,Nylon

79 725-1644 SwitchSpring,Short

80 726-0320 Plate,Insulator

81 750-04294 Spacer,Shoulder

82 756-04209 Pulley,V-Type,3.06

Continued on next page

_FACTORY PARTS

To order replacement

parts, call the Customer

Service Line at

1-800-648-6776,

orvisit

www.troybilt.com.

Model 60TG

_FACTORY PARTS

To order replacement

parts, call the Customer

Service Line at

1=800=648=6776,

or visit

www.troy bilt.com.

Ref. I Part No. Description

No.

83 656=04015 PulleyAss'y,VariableSpeed

84 683=04129 Bracket,Pulley

85 710=0627 Screw,5/16=24,.750

86 710=1652 Screw,1/4=20,.625

87 718=04012 Cup,Bearing

88 736=0362 Washer,Flat

89 741=0600 BallBearing

90 783=04722 SwitchBracket,ParkingBrake

91 736=0242 Washer,Bell.340x.872x.060

92 712=04065 Nut,FlangeLock,3/8=16,GrF

93 710=0599 Screw,1/4=20x.500

94 736=0430 FlatWasher.350x 1.59x.062

95 634=0104 WheelAssyComp,20x 8 x 8

734=1730 Tire Only20 x 8 x 8

734=0603A RimOnly w/Valve Stem

96 736=3010 FlatWasher,.407x .812x .135

97 714=0507 Pin,Cotter,3/32x.750

98 736=0119 LockWasher,5/16

99 725=3167 Switch

100 712=3004A Nut,FlangeLock,5/16=18,Gr 5

_ _"_!_*'_"_'_*'_S_°,°_ _

ustrat

Exhaust gasket,

f_)_ _=_ mountingnuts,and

starter nut supplied

by Kohler

Ref. Part No.

No.

1 710-0227

2 710-0599

3 783-04573

4 783-04574

5 751-3142

6 710-0654A

7 736-0277

8 751-3141

9 726-0205

10 725-0157

Description

ABScrew#8-18x 0,5

TT Screw1/4-20x 0,5

LH MufflerBracket

RHMufflerBracket

Oil DrainCap

TT Screw3/8-16x 1,00

FlatWasher,1,031x 1,620x ,095

Oil DrainExtensionHose

HoseClamp

CaNeTie

Ref.

No.

11 726-0272

12 751-3140

13 751-10349

14 751-0564B

15 751-10162

16 751-10017

17 710-0642

18 728-04000

19 751-10353

20 683-04256

Part No. Description

Clamp

Oil DrainValve

FuelLineHose

MufflerDeflector

Muffler

ExhaustPipe

Screw,1/4-20,x ,750

PopRivet

LongMufflerDeflector

MufflerShield

_FACTORY PARTS

To order replacement

parts, call _heCustomer

Service Line at

1o800-648-6776,

or visit

www.troybilt.com.

Mode_ 60TG

IMPORTANT

For a proper working machine,

Jse Factory Approved Parts.

7-beltsare designed to

_ngageand disengage safely.

substitute (non OEM) Wbeit

sanbe dangerous by not

Jisen a in corn_letel.

Rof.po, ,o. Do,c,p ioo po, ,o. Do,c,p ioo

NO,

1 17962 Plate,Switch

2 647=04036 LeverAssembly,Engagement

3 710=0778 Screw,1/4=20x 1.500

4 710=0859 Screw,3/8=16,2.50

5 710=0276 Screw,Carriage,5/16=18,1.00

6 710=1260A Screw,5/16=18x.750

7 710=3157A Screw,7/16=20,3.25, Gr5

8 710=0726 Screw,5/16=12,0.750

9 714=0145 ClickPin

10 732=04248 ExtensionSpring.380D x 3.9LG

11 736=0171 LockWasher,7/16

12 746=04092 DeckEngagementCable

13 712=04065 Nut,FlangeLock,3/8=16,GrF

14 750=0566A Spacer.260x.372x 1.030LG

15 714=0470 Pin,Cotter,1/8 x 1.25

16 726=0201 Nut,Speed.3125ID

17 731=2111A Knob,PTO

18 783=04590A CableBracket

19 736=0322 Washer,Flat.450 xl.250 x.164

20 741=0708 Bearing,Flange,.500ID

21 747=04307 KeeperRod,Belt

22 747=04470 EngagementHandle,Deck

23 748=0415B Spacer.385ID x.635OD x 1.54

24 736=0108 FlatWasher,.510x .750x .033

Ref.

No.

25 756=04196 Pulley,Engine,3.39x 6.12Dia.

26 783=0744A Stop Bracket,Engagement

27 683=04173 FrameAssembly,Lower

28 710=0607 Screw,5/16=18,0.500

29 710=0642 Screw,1/4=20,0.750

30 710=3005 Screw,3/8=16,1.25,Gr5

31 712=04064 Nut, FlangeLock, 1/4=20,GrF

32 710=0703 Screw,Carriage,1/4=20,.75

33 732=04035 Spring,Compr., 1.28OD x 3.125

34 736=0222 Washer,Lock,1/4,External

35 736=0275 FlatWasher,.344x .688x .065

36 738=04058 Spacer,Shoulder.38x 1.0x.70

37 747=04121A Hold Rod,Battery

38 783=0349 BatteryTray

39 783=04329A SeatBracket,Frame

40 783=04809 Frame,Upper

41 710=0599 Screw,1/4=20,0.50

42 725=1428A Solenoid,12V,100 Amp

43 725=04039 Switch,Interlock

44 710=0224 Screw,#10=16,.50

45 712=3004A Nut, Flange,LockNut, 5/16=18

46 712=0271 Nut, Seres,1/4=20

47 725=1737A Battery,190CCA

i ii ii i i i

ii¸toOrdorrepocement

parts;Callthecustome,

Service Line at

Model 60TG

Ref. Part No. Description

No.

1 732-0614 Ring,Wire

2 716-0231 Ring,E Type.750

3 736-0336* FlatWasher,5/8x 1.0x.030

736-0337* FlatWasher,5/8 x 1.0x.040

736-0349* FlatWasher,5/8 x 1.0x.020

4 736-0335 Washer,Thrust.635x 1.26x.06

5 710-1325 Self-tappingScrew,1/4-20x 1.625

6 719-04017 UpperRousing

7 711q109 input Shaft

8 741-0335 NeedleBearing.625x.813x.495

9 717-1464 144oothBevelPinion

10 716-0108 RetainingRing.437

11 741-0340 SleeveBearing.75x.1.0x 1.0

12 721-0338 Seal.75x 1.0x.125

13 618-04041 DifferentialAssembly

14 741-0336 FlangeBearing,5/8 x 3/4 x 3/4

15 717-04056 42-toothBeveIGear

16 718-04045 ClutchCollar

17 711-04134 DriveShaft

18 736-0495* ThrustWasher,1.0x.632x.O

736-0494* FlatWasher.632x 1.00x.035

19 741-0337 FlangeBearing,5/8 x 3/4 x 15/16

20 611-0011 DetentShaft Assembly

21 741-0862 DetentBall

22 732-0863 CompressionSpring

23 719-04018 LowerHousing

24 717-0678 BrakePuck

25 761-0202 BrakeDisc

26 710-1206 Self4appingScrew,1/4-20x 2.375

27 661-0001 BrakeAssembly

-- 737-0148 Grease(19oz.)

* Useapplicableflat washer(ref.#'s 3 or 18) in this applicationallowing.0150/.0020in. end-play

NOTE: If rebuildingthe upperhousing,includetwo ounces (2 oz.) of Unirex®N3grease(Part No.737-0289)in the

input shaftcavity.

_FACTORY PARTS

To order replacement

parts, call the Customer

Service Line at

1-800-648-6776,

or visit

www.troybilt.eom.

Mode_ 60TG

il 7}

Ref. Part No. Description

No.

1 618=0624 SpindleAssembly,Pul,6,23" Dia

2 683=04138A BrakeAssembly,Deck

3 683=04261 DeckShell,42"

4 683=04167 BrakeAssembly,Deck

5 683=0254B Brkt,Ass'y,Deck,HangerLH

6 710=3015 Screw,1/4=20,,75,Gr5

7 710=0654A Screw,3/8=16,1,00

8 710=0528 Screw,5/16=18,1,250

9 710=0726 Screw,5/16=12,0,750

10 710=0510 Screw,7/16=20,3,00,Gr5

11 710=0778 Screw,1/4=20,1,500

12 710=1260A Screw,5/16=18,,75

13 710=01341 CarriageScrew,, 1/4=20x ,62

14 783=05045 Pivot SupportBracket

15 712=3006 Nut, Hex,1/4=20,Gr5

16 712=0417A Nut, Flange,5/8=18

17 738=0373 Screw,Shldr,,498x 1,53,3/8=16

18 712=04063 Nut, FlangeLock,5/16=18,GrF

19 712=04065 Nut, FlangeLock,3/8=16,GrF

20 712=0641 Nut, Hex,M16=1,5

21 712=3083 Nut, HexLock, 1/2=13,Gr8

22 712=0206 Nut, Hex,1/2=13,Gr5

23 714=0104 Pin,Cot, ,072Dia, x 1,13Lg

24 717=04074 Gear,DeckAdiustment

25 726=0233 Nut, Push,,25 ID x,50 OD

26 732=0459B Spring,Exten,, ,94 Dia, x 6,74

27 732=04287 Spring,Exten,, ,50 Dia, x 6,375

28 734=0973 Wheel,Deck5,0 x 1,38

29 736=0119 Washer,Lock,5/16

30 736=0270 Washer,Bell, ,265x,75 x ,062

31 783=04740 DeckEngagementCableBracket

Ref. Part No. Description

No.

32 736=0300 Washer,Flat,,406x ,875x ,059

33 736=0760 Washer,Lock

34 737=04003C DeckWater Nozzle

35 738=04166 Spacer,Shoulder,,5000x,1475

36 721=04041 WaterNozzleAdapter

37 738=04162A Spacer,Shoulder,,8840x,190

38 742=0616A Blade,21,23",Star3=in=l

39 731=2363t Mulch Rug

40 747=04501 Control Rod,Brake

41 747=04269A Deck Rod,FrontAdiustable

42 748=04069 Pivot Cup,Deck Lift

43 750=0566A Spacer,,260x ,372x 1,030

44 754=04045 Belt, V=Type

45 756=04129 Idler Pulley,4,25"Dia,

46 712=3087t Wing Nut,1/4=20

47 783=04327A Cover,Belt,6,00 Dia,

48 750=04637 Spacr,,455 ID x ,680OD

49 710=0347 Screw,3/8=16x1,75

50 731=1032B Chute Assembly,Discharge

51 736=0407 BellWasher,,45x 1,00x ,062

52 735=0271 Bumper

53 712=0431 FlangeLockNut, 3/8=16

54 714=0470 Cotter Pin

55 732=0306A Comp,Spring,,5310Dx 1,75Lg,

56 747=1116 Deck ReleaseRod

57 683=04252 Deck ldler Assembly

58 710=0216 Screw,3/8-16x,75

59 710=3005 Screw,3/8=16x1,25

60 712=0459 FlangeLockNut, 7/16=20

61 712=3061 HexLock Nut,3/8=24

62 732=0470A ExtensionSpring,,53 ODx 4,75

t If Equipped

Fora proper working machine

Jse Factory Approved Parts.

V-belts are designed to

_ngageand disengage safely.

NOTE:Tractorfeaturesvaryby model NOTall partslistedaboveandpicturedon the previouspageare standard

equipment,

,,rderrepmocement

parts, call the Customer

_ Service Line at

!=800=648,6776'

www.troybilt.com. /

Use this page to make

notesandwritedown

importantinformation.

CAUFORNJA EMiSSiON CONTROL WARRANTY STATEMENT

YOUR WARRANTY RIGHTS AND OBLIGATIONS

The CaliforniaAir ResourcesBoardand MTDConsumerGroupInc are pleasedto explainthe evaporativeemissioncontrolsystemwarrantyon your2006 lawn

mower.In California,new lawnmowermust be designed,built andequippedto meet the State'sstringentanti-smogstandards.MTD ConsumerGroupInc must

warrantthe EECSon your lawnmowerfor the periodof time listedbelow providedthere has beenno abuse,neglector impropermaintenanceof your lawnmower.

YourEECSmayincludeparts such as thecarburetor,fuel-injectionsystem,the ignitionsystem,catalyticconverter,fuel tanks,fuel lines,fuelcaps, valves,

canisters,filters,vaporhoses,clamps,connectors,and otherassociatedemission-relatedcomponents.

Where a warrantaMe condition exists, MTDConsumer Group _newill repair your Hawnmower at no cost to you ineHudingdiagnosis, parts and Habor.

MANUFACTURER'S WARRANTY COVERAGE:

Thisevaporativeemissioncontrol systemis warrantedfor twoyears. If anyevaporativeemission-relatedpart onyour equipmentis defective,the partwill be

repairedor replacedby MTDConsumerGroup Inc.

OWNER'S WARRANTY RESPONSIBILITIES:

Asthe lawn mowerowner,you are responsiblefor performanceof the requiredmaintenancelistedin yourowner'smanual. MTDConsumerGroup Inc recom-

mendsthat you retain all receiptscoveringmaintenanceon your lawnmower,but MTDConsumerGroup Inccannot denywarrantysolelyfor the lackof receipts.

Asthe lawn mowerowner,you shouldhoweverbe awarethat MTDConsumerGroupInc maydenyyou warrantycoverageif yourlawn moweror a part has failed

dueto abuse,neglect, or impropermaintenanceor unapprovedmodifications.

Youare responsiblefor presentingyourlawn mowerto MTDConsumerGroupInc'sdistributioncenteror servicecenteras soonas the problemexists.The

warrantyrepairsshouldbecompletedin a reasonableamountof time, notto exceed30 days.If you havea questionregardingyour warrantycoverage,you should

contactthe MTDConsumerGroupIncService Departmentat 1-800-800-7310.

GENERAL EMISSIONS WARRANTY COVERAGE:

MTDConsumerGrouphc warrantsto the ultimatepurchaserandeachsubsequentpurchaserthat the lawnmoweris: Designed,built and equippedso as to

conformwithall applicableregulations;and freefrom defectsin materialsand workmanshipthatcausethe failure of a warrantedpart to be identicalin all material

respectsto that part as describedin MTDConsumerGroupInc's applicationfor certification.

Thewarranty periodbeginson the datethe lawnmoweris deliveredto anultimatepurchaseror first placedintoservice.Thewarranty period is twoyears.

Subjectto certain conditionsand exclusionsas statedbelow,the warrantyon emission-relatedparts is as follows:

1. Anywarrantedpart that is not scheduledfor replacementas requiredmaintenanceinthe writteninstructionssupplied, is warrantedfor thewarranty period

statedabove. If the part fails duringthe periodof warrantycoverage,the partwill be repairedor replacedby MTDConsumerGroupInc accordingto subsection

(4) below. Anysuch part repairedor replacedunderwarrantywill be warrantedfor the remainderof the period.

2. Anywarrantedpart that is scheduledonly for regularinspectioninthe writteninstructionssuppliedis warrantedfor thewarranty periodstated above.Any such

part repairedor replacedunderwarrantywill be warrantedfor the remainingwarrantyperiod.

3. Any warrantedpart that is scheduledfor replacementas requiredmaintenanceinthe written instructionssuppliedis warrantedfor the periodof time beforethe

first scheduledreplacementdatefor that part. If the part failsbeforethe firstscheduledreplacement,the partwill be repairedor replacedby MTDConsumer

GroupInc accordingto subsection(4) below. Anysuch part repairedor replacedunderwarrantywillbe warrantedfor the remainderof the periodpriorto the

first scheduledreplacementpointfor the part.

4. Repairor replacementof any warrantedpart underthe warrantyprovisionshereinmustbe performedat a warrantystationat no chargeto the owner.

5. Notwithstandingthe provisionsherein,warrantyservicesor repairswill beprovidedat all of our distributioncentersthat arefranchisedto servicethe subject

enginesor equipment.

6. The lawnmowerowner will not bechargedfor diagnosticlaborthat is directlyassociatedwithdiagnosisof a defective,emission-relatedwarrantedpart,

providedthat such diagnosticwork is performedat a warrantystation.

7. MTDConsumerGroupInc is liablefor damagesto other engineor equipmentcomponentsproximatelycaused bya failure underwarrantyof any warranted

part.

8. Throughoutthe lawnmowerwarrantyperiodstated above,MTDConsumerGroupIncwill maintaina supplyof warrantedparts sufficientto meetthe expected

demandfor suchparts.

9. Any replacementpart may be usedinthe performanceof any warrantymaintenanceor repairsand mustbe providedwithoutchargeto the owner.Suchuse will

not reducethe warrantyobligationsof MTDConsumerGroupInc.

10.Add-onor modified partsthat are notexemptedbythe Air ResourcesBoardmaynot beused.The use of any non-exemptedadd-onor modifiedparts by the

ultimatepurchaserwillbe groundsfor disallowinga warrantyclaims. MTDConsumerGroup Incwill not be liableto warrantfailures of warrantedparts caused

bythe use of a non-exemptedadd-onor modifiedpart.

WARRANTED PARTS:

The repairor replacementof any warrantedpartotherwiseeligiblefor warrantycoveragemay be excludedfrom such warrantycoverageif MTDConsumerGroup

Inc demonstratesthat thelawn mowerhas been abused,neglected,or improperlymaintained,andthat such abuse, neglect,or impropermaintenancewas the

directcauseof the need for repairor replacementof the part.That notwithstanding,any adjustmentof a componentthat has a factory installed,and properly

operating,adjustmentlimiting device is still eligiblefor warrantycoverage.The following emissionwarrantyparts list are covered:FuelLine,Fuel Line Clamps

MANUFACTURER'S LIMITED WARRANTY FOR

The limitedwarrantyset forthbelowis givenbyTroy_BiltLLCwithrespect

to newmerchandisepurchasedand usedin the UnitedStates,its posses_

sionsandterritories.

"Troy_Bilt"warrantsthis productagainstdefects in materialand workmam

shipfor a periodof two(2) years commencingon thedate of original

purchaseandwill,at its option,repairor replace,freeof charge,any part

foundto be defectivein materialsor workmanship.This limitedwarranty

shallonly applyif this producthasbeen operatedand maintainedin

accordancewiththe Operator'sManualfurnishedwiththe product,and

has notbeen subiectto misuse,abuse,commercialuse,neglect,accident,

impropermaintenance,alteration,vandalism,theft,fire,water,or damage

becauseof other perilor naturaldisaster.Damageresultingfromthe

installationor use ofany part, accessoryor attachmentnot approvedby

Troy_Biltfor use with theproduct(s)coveredby this manualwill voidyour

warrantyas to any resultingdamage.

Normalwearpartsarewarrantedto befree fromdefects in materialand

workmanshipfor aperiodof thirty (30)daysfromthedate of purchase.

Normalwearpartsinclude,butare notlimitedto itemssuch as: batteries,

belts,blades,bladeadapters,grass bags,rider deck wheels,seats,snow

throwerskidshoes,shaveplates,augerspiralrubberandtires.

NOWTO OBTAIN SERVICE: Warranty service is available, WITH

PROOFOF PURCHASE,through your local authorizedservice

dealer. To locate the dealer in your area, check your Yellow Pages,

or contact Troy-Bilt LLC at RO. Box 361131,Cleveland, Ohio 44136-

0019, or can 1-866-840-6483 or 1-330-558-7220,or log on to our

Web site at www.troybilt.com.

This limitedwarrantydoesnot providecoverageinthe followingcases:

a. The engineor componentparts thereof.These itemsmay

carrya separatemanufacturer'swarranty.Referto applicable

manufacturer'swarrantyfor termsandconditions.

b. Logsplitterpumps,valves,and cylindershavea separateone

yearwarranty.

c. Routinemaintenanceitemssuchas lubricants,filters,blade

sharpening,tune_ups,brakeadiustments,clutch adiustments,

deckadiustments,andnormaldeteriorationof the exteriorfinish

dueto use or exposure.

d. Servicecompletedbysomeoneotherthanan authorizedservice

dealer.

e. Troy_Biltdoesnot extendanywarrantyfor productssold or

exportedoutsideof the UnitedStates,its possessionsand

territories,exceptthosesold throughTroy_Bilt'sauthorized

channelsof exportdistribution.

f. Replacementpartsthatare notgenuineTroy_Biltparts.

g. Transportationchargesandservicecalls.

No impliedwarranty, includingany impliedwarranty of merchant°

ability of fitness for a particular purpose, applies after the applicable

period of express written warranty above as to the parts as identi-

fied. No other express warranty, whether written or oral, except as

mentioned above,given by any person or entity, includinga dealer or

retailer,with respect to any product, shall bind Troy-Bilt. During the

period of the warranty,the exclusive remedy is repair or replacement

of the product as set forth above.

The provisions as set forth inthis warranty providethe sole and

exclusive remedyarising from the sale. Troy-Bilt shall not be liable

for incidental or consequential loss or damage including, without

limitation, expenses incurred for substitute or replacement lawn care

services or for rental expenses to temporarily replace a warranted

product.

Somestatesdo not allowtheexclusionor limitationof incidentalor

consequentialdamages,or limitationson howlongan impliedwarranty

lasts,so the aboveexclusionsor limitationsmaynotapplyto you.

In no eventshall recoveryof any kind be greaterthanthe amountof the

purchasepriceof the productsold. Alteration of safety features of the

product shall void this warranty. Youassumethe risk and liability for

loss,damage,or injuryto youand yourpropertyand/or to others and their

propertyarisingout of the misuseor inabilityto use the product.

This limitedwarrantyshall notextendto anyoneotherthanthe original

purchaseror to the personfor whomit waspurchasedas a gift.

HOWSTATELAW RELATESTO THiSWARRANTY:This limitedwar-

rantygh,'esyouspecificlegalrights,andyou mayalso haveother rights

whichvaryfromstateto state.

IMPORTANT:OwnermustpresentOriginalProofof Purchaseto obtain

warrantycoverage.

TROYBILT LLC, P.O. BOX 361131 CLEVELAM D, OHIO 44136-0019; Phone: 1(866} 840-6483, 1-330-558-7220

Troy-Bilt 13AX60TG766 Super Bronco Lawn Tractor

Product's Documents

Operator’s Manual

Specifications

Troy-Bilt 13AX60TG766 Questions and Answers
