Use & Care Guide
Guide d’utilisation et d’entretien
Manual de uso y cuidado
English / Français / Español latinoamericano
P/N W11411288A
Transform SR Brands Management LLC,
Hoffman Estates, IL 60179 U.S.A.
www.kenmore.com
Models/Modèles/Modelos: 665.1450*
* = color number, numéro de couleur, número de color
Kenmore
®
ULTRA WASH Dishwasher
Lave-vaisselle ULTRA WASH
Lavavajillas ULTRA WASH
®
®
®
TABLE OF CONTENTS
WARRANTY ................................................................3
DISHWASHER SAFETY .............................................4
PARTS AND FEATURES ............................................6
START-UP / QUICK REFERENCE .............................7
ULTRA WASH
®
FILTRATION SYSTEM ...................8
DISHWASHER EFFICIENCY TIPS.............................9
DETERGENT AND RINSE AID.................................10
Detergent ................................................................10
Rinse Aid ................................................................. 10
LOADING ...................................................................11
Loading for Best Cleaning and
Drying Performance ................................................ 11
Top Rack Loading...................................................12
Bottom Rack Loading .............................................13
DISHWASHER USE ..................................................15
Cycles and Options Information
(on some models) .............................................15
Dishwasher Control Section ................................... 17
Dishwasher Feedback Section ...............................17
Canceling a Cycle ................................................... 17
Changing a Cycle After Dishwasher Is Started ......17
WASHING SPECIAL ITEMS .....................................18
DISHWASHER CARE ...............................................19
Cleaning ..................................................................19
Drain Air Gap ...........................................................19
Vacation or Extended Time Without Use ...............19
TROUBLESHOOTING ..............................................20
SERVICE NUMBERS ...............................BACK PAGE
3
WARRANTY
KENMORE LIMITED WARRANTY
WITH PROOF OF SALE the following warranty coverage
applies when this appliance is correctly installed, operated and
maintained according to all supplied instructions.
One Year on Appliance
FOR ONE YEAR from the date of sale this appliance is warranted
against defects in material or workmanship. A defective
appliance will receive free repair or replacement at option of
seller.
Lifetime on Stainless Steel Tub and Inner Door Panel
FOR AS LONG AS IT IS USED from the date of sale, a free
replacement will be supplied for a stainless steel tub or inner
door panel that leaks due to rust-through. If the tub or panel
rusts through within the rst year, a new part will be supplied
and installed at no charge. If a tub or panel rusts through after
the rst year, a new part will be supplied but not installed at no
charge. You are responsible for the labor cost of part installation
after the rst year from the date of sale.
For warranty coverage details to obtain free repair or
replacement, visit the web page:
www.kenmore.com/warranty
All warranty coverage applies for only 90 DAYS from the
sale date if this appliance is ever used for other than private
household purposes.
This warranty covers ONLY defects in material and
workmanship, and will NOT pay for:
1. Expendable items that can wear out from normal use,
including but not limited to lters, belts, bags or screw-in base
light bulbs.
2. A service technician to clean or maintain this appliance, or to
instruct the user in correct appliance installation, operation
and maintenance.
3. Service calls to correct appliance installation not performed
by Sears authorized service agents, or to repair problems
with house fuses, circuit breakers, house wiring, and plumbing
or gas supply systems resulting from such installation.
4. Damage to or failure of this appliance resulting from
installation not performed by Sears authorized service
agents, including installation that was not in accord with
electrical, gas or plumbing codes.
5. Damage to or failure of this appliance, including discoloration
or surface rust, if it is not correctly operated and maintained
according to all supplied instructions.
6. Damage to or failure of this appliance, including discoloration
or surface rust, resulting from accident, alteration, abuse,
misuse or use for other than its intended purpose.
7. Damage to or failure of this appliance, including discoloration
or surface rust, caused by the use of detergents, cleaners,
chemicals or utensils other than those recommended in all
instructions supplied with the product.
8. Damage to or failure of parts or systems resulting from
unauthorized modications made to this appliance.
9. Service to an appliance if the model and serial plate is
missing, altered, or cannot easily be determined to have the
appropriate certication logo.
DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF
REMEDIES
Customer’s sole and exclusive remedy under this limited warranty
shall be product repair or replacement as provided herein.
Implied warranties, including warranties of merchantability or
tness for a particular purpose, are limited to one year on the
appliance and for as long as used on the stainless steel tub and
inner door panel, or the shortest period allowed by law. Seller
shall not be liable for incidental or consequential damages. Some
states and provinces do not allow the exclusion or limitation of
incidental or consequential damages, or limitation on the duration
of implied warranties of merchantability or tness, so these
exclusions or limitations may not apply to you.
This warranty applies only while this appliance is used in the
United States.
This warranty gives you specic legal rights, and you may also
have other rights which vary from state to state.
Transform SR Brands management,
Hoffman Estates, IL 60179
03/2018
4
DISHWASHER SAFETY
IMPORTANT SAFETY INSTRUCTIONS
WARNING: When using the dishwasher, follow basic precautions, including the following:
SAVE THESE INSTRUCTIONS
■ Read all instructions before using the dishwasher.
■ Use the dishwasher only for its intended function.
■ Use only detergents or rinse agents recommended for use in
a dishwasher, and keep them out of the reach of children.
■ When loading items to be washed:
1) Locate sharp items so that they are not likely to damage
the door seal; and
2) Load sharp knives with the handles up to reduce the risk
of cut-type injuries.
■ Do not wash plastic items unless they are marked
“dishwasher safe” or the equivalent. For plastic items not so
marked, check the manufacturer's recommendations.
■ Do not touch the heating element during or immediately after
use.
■ Do not operate the dishwasher unless all enclosure panels
are properly in place.
■ Do not tamper with controls.
■ Do not abuse, sit on, or stand on the door, lid, or dish racks
of the dishwasher.
■ To reduce the risk of injury, do not allow children to play in
or on the dishwasher.
■ Under certain conditions, hydrogen gas may be produced in
a hot water system that has not been used for two weeks or
more. HYDROGEN GAS IS EXPLOSIVE. If the hot water
system has not been used for such a period, before using
the dishwasher turn on all hot water faucets and let the
water flow from each for several minutes. This will release
any accumulated hydrogen gas. As the gas is flammable,
do not smoke or use an open flame during this time.
■ Remove the door or lid to the washing compartment
when removing an old dishwasher from service or
discarding it.
5
Install where dishwasher is sheltered from the elements.
Avoid possible rupture of ll valve from freezing. Such
ruptures are not covered by the warranty. See the “Vacation
or Extended Time Without Use” section.
Install and level dishwasher on a oor that will hold the
weight, and in an area suitable for its size and use.
Remove all shipping plugs from hoses and connectors (such as
the cap on the drain outlet) before installing. See Installation
Instructions for complete information.
For a grounded, cord-connected dishwasher:
The dishwasher must be grounded. In the event of a
malfunction or breakdown, grounding will reduce the risk of
electric shock by providing a path of least resistance for
electric current. The dishwasher is equipped with a cord
having an equipment-grounding conductor and a grounding
plug. The plug must be plugged into an appropriate outlet
that is installed and grounded in accordance with all local
codes and ordinances.
WARNING: Improper connection of the equipment-
grounding conductor can result in a risk of electric shock.
Check with a qualified electrician or service representative if
you are in doubt whether the dishwasher is properly
grounded. Do not modify the plug provided with the
dishwasher; if it will not fit the outlet, have a proper outlet
installed by a qualified electrician.
For a permanently connected dishwasher:
The dishwasher must be connected to a
grounded metal, permanent wiring system, or an
equipment-grounding conductor must be run
with the circuit conductors and connected to the
equipment-grounding terminal or lead on the
dishwasher.
WARNING
Electrical Shock Hazard
Electrically ground dishwasher.
Connect ground wire to green ground connector in
terminal box.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING
Tip Over Hazard
Do not use dishwasher until completely installed.
Do not push down on open door.
Doing so can result in serious injury or cuts.
6
PARTS AND FEATURES
Upper level wash
ULTRA FLOW
Water feed tube
Model and serial number label
Water inlet opening
Heating element
Detergent dispenser
Active vents
Top rack adjusters
(one on each side on some models)
Flexible tines
(on some models)
Cup shelves
(on some models)
Fold-down tines
(on some models)
Knife holder
(on some models)
Rinse aid dispenser reduces
spotting and improves drying.
(On some models)
TurboZone
®
provides a concentrated
wash on the back of the lower dish
rack to power clean stuck-on foods
without soaking or scrubbing.
Pressurized spray nozzle and
variable speed motor provide
effective cleaning.
Ultra Wash
®
lter removes soil from
water and improves cleaning action.
Lower spray arm
Overll protection oat
Stemware clip
(on some models)
Silverware basket
TOP RACK
BOTTOM RACK
7
START-UP / QUICK REFERENCE (VARIES BY MODEL)
Ultra Wash
®
removable lters provide peak
performance
Cleaning the lters periodically
helps keep the dishwasher
working at peak performance.
The lters can be found
at the bottom center of your
dishwasher.
See “Ultra Wash
®
Filtration System” for information
on removing and maintaining the
lters.
IMPORTANT: Do not block detergent dispenser
Tall items placed in the lower
rack may block the dispenser
door. Cookie sheets and cutting
boards loaded on the
left-hand side of the
dishwasher can easily block the
dispenser. If detergent is inside
of the dispenser or on the
bottom of the tub after the
cycle is complete, the dispenser
was blocked.
Drying - Rinse Aid is essential
You must use a drying agent
such as rinse aid for good
drying performance
(sample included). Rinse
aid along with the Heated
Dry option will provide
best drying and avoid
excessive moisture in the
dishwasher interior.
Accela Wash - When you need fast results
High Efciency dishwashers run longer to
save water and energy just as driving a car
slower saves on gas. When you need fast
results, the Accela Wash will clean your
dishes using slightly more water and energy.
For improved drying, select the Heated Dry
option to add additional time to dry.
SmartWash
®
cycle
SmartWash
®
provides optimal results
using only the amount of water and
energy needed. The SmartWash
®
and
Pots & Pans cycles are recommended for
tough soil.
TurboZone
®
loading (on some models)
When the
TurboZone
®
option
is selected, it
provides a
concentrated wash
on the back of the
lower dish rack for
hard-to-clean
dishes. Place these
dishes with the
soiled surface of the
dish toward the
TurboZone
®
spray
nozzles in the lower
rack of the
dishwasher.
Press START/RESUME every
time you add a dish
To start and resume a cycle, press START/
RESUME and close the door within
3 seconds. If the door is not closed within
3 seconds, the start button LED will ash and
the cycle will not start.
IMPORTANT: If anyone opens the door
(as, to add a dish, even during the Delay
Hours option), the START/RESUME button
must be pressed each time and the door
closed within 3 seconds to resume the cycle.
Detergent Dosing
It is possible to use too much detergent in your dishwasher. This
can lead to etching of your dishes. See “Detergent and Rinse
Aid” to determine the amount of detergent needed based on
your water hardness. Using dishwasher detergent tablets and
packs have been proven better than powder, liquid or gel
detergents to reduce lming on your dishes.
H
E
n
s
q
f
b
m
u
l
D
r
s
p
l
j
m
a
i
s
l
j
m
a
i
H
E
Accela
Wash
H
E
H
E
Back of
dishwasher
USE RINSE AID FOR
BETTER DRYING
Lock
Refill
Full
Add
H
E
H
E
H
E
8
ULTRA WASH
®
FILTRATION SYSTEM
Your dishwasher has the latest technology in dishwasher ltration. This triple ltration system minimizes sound and optimizes water
and energy consumption while providing superior cleaning performance. Throughout the life of your dishwasher, the lter will require
maintenance to sustain peak cleaning performance.
The triple lter system consists of 2 parts, an upper lter assembly and a lower lter.
The upper lter assembly keeps oversized items and foreign objects, along with very ne food particles out of the pump.
The lower lter keeps food from being recirculated onto your dishware.
In order to provide optimum cleaning performance we suggest a monthly lter maintenance by removing and inspecting both the upper
and the lower lter for any soils. Based on your dishwashing habits, cleaning of the lters may be required more or less often than what
is indicated in the chart below.
The lters may need to be cleaned when:
Visible objects or soils are on the upper lter assembly.
There is degradation in cleaning performance (that is, soils still present on dishes).
Dishes feel gritty to the touch.
Removing and maintaining the lters is very easy. The chart below shows the recommended cleaning frequency.
Recommended time intervals to clean your lter
Number of
Loads Per Week
If you wash
before loading
If you scrape and rinse
before loading
If you only scrape before
loading*
If you do not scrape or
rinse before loading
13-14 Once per year Twice per year Every two months Once per week
8-12 Once per year Every four months Every two months Every two weeks
4-7 Once per year Once per year Every four months Once per month
1-3 Once per year Once per year Twice per year Every two months
*Manufacturer’s recommendation: This practice will eliminate the water and energy that you use preparing your dishes for loading. This
will also save you time and effort.
Very Hard Water
If you have hard water (above 15 grains), clean your lter at least once per month. Building up of white residue on your dishwasher
indicates hard water. You may bring your water samples to Sears to check hardness level. For tips on removing spots and stains, see
“Troubleshooting” section.
H
E
Upper Filter
Assembly
Lower Filter
9
Filter Removal Instructions
1. Turn the upper lter assembly 1/4 turn counterclockwise and lift out.
2. Grasp the lower lter in the circular opening, lift slightly, and pull forward to remove.
3. Clean the lters as shown below.
Cleaning Instructions
IMPORTANT: Do not use wire brush, scouring pad, etc., as they may damage the lters.
Rinse lter under running water until most soils are removed. If you
have hard-to-remove soils or calcium deposits from hard water, a
soft brush may be required.
Filter Reinstallation Instructions
1. Noting the previous illustrations, place the lower lter under the locating tabs in the
bottom of the dishwasher so the round opening for the upper lter assembly lines up
with the round opening in the bottom of the tub.
2. Insert the upper lter assembly into the circular opening in the lower lter.
3. Slowly rotate the lter clockwise until it drops into place. Continue to rotate until the
lter is locked into place. If the lter is not fully seated (still turns freely), continue to
turn the lter clockwise until it drops and locks into place.
NOTE: The upper lter assembly arrow does not have to align with the arrow in the Lower
Filter as long as the lter is locked.
IMPORTANT: To avoid damage to dishwasher, do not operate your dishwasher without the Ultra Wash
®
lters properly installed.
Be sure the lower lter is securely in place and the upper lter assembly is locked into place. If the upper lter assembly turns freely,
it is not locked into place.
DISHWASHER EFFICIENCY TIPS
Hot water dissolves and activates the dishwasher detergent. Hot water also dissolves grease on dishes and helps glasses dry spot-
free. For best dishwashing results, water should be 120°F (49°C) as it enters the dishwasher. Loads may not wash as well if the water
temperature is too low.
Additional efciency tips:
To save water, energy and time, only scrape dishes. Do not rinse dishes before putting them into the dishwasher.
Use a delay feature to run your dishwasher during off-peak hours. Local utility providers recommend avoiding heavy usage of
energy at certain times of day.
During the summer, run your dishwasher at night. This reduces daytime heat buildup in the kitchen.
Use a rinse aid to improve drying.
P
H
U
S
W
D
O
N
U
&
T
R
N
L
O
C
K
U
N
L
O
C
K
To replace upper lter assembly
H
E
Locating tab
To remove upper lter assembly
Locating tab
10
DETERGENT AND RINSE AID
Detergent
IMPORTANT: Use only automatic dishwashing detergent. Hand
dishwashing detergent will produce excessive suds and overow
out of the dishwasher.
Recommended Detergent Amount
Add recommended amount of detergent to each compartment as
shown and close the detergent lid.
Powders and Gels
Water
Hardness
Soil
Level
Pre-Wash
Compartment
Main Wash
Compartment
Soft
(0-4 grains
per U.S.
gallon)
Light None 1/2
Normal None 1/2
Heavy Full 1/2
Medium
(5-9 grains
per U.S.
gallon)
Light None 1/2
Normal 1/2 1/2
Heavy Full* Full*
Hard
(10-14 grains
per U.S.
gallon)
Light 1/2 Full*
Normal Full* Full*
Heavy Full* Full*
*Full pre-wash compartment contains 7 tsp (35 mL), and full main
wash cup contains 9 tsp (45 mL).
Premeasured Detergents
Many detergents now come in premeasured forms (gel packs,
tablets, or powder packs). These forms are suitable for all
hardness and soil levels. Always place premeasured detergents in
the main compartment and close the lid.
Using dishwasher detergent tablets and packs have been proven
better than powder, liquid or gel detergents to reduce lming on
your dishes. By using these tablets and packs, over time this will
start to reduce or eliminate white lm. Also, by using a rinse aid
you can minimize repeat buildup of white lm.
IMPORTANT: Extremely hard water mineral deposits (15 grains
per U.S. gallon or more) can cause damage to your dishwasher
and make it difcult to achieve good results. A water softener is
recommended to avoid damage and achieve good results. You
may bring your water samples to Sears to check hardness level.
Rinse Aid
IMPORTANT: Your dishwasher is designed to use a liquid rinse
aid. The use of rinse aids greatly improves drying by allowing
water to drain from the dishes after the nal rinse. They also
keep water from forming droplets that can dry as spots or
streaks.
Filling the Dispenser
The dispenser holds 5 oz (150 mL) of rinse aid. Under most
conditions, this will last 1 to 3 months.
1. Turn the knob to the REFILL position and remove.
2. Pour rinse aid into the opening until the indicator points to
FULL. Do not overll.
3. Clean up any spilled rinse aid. Spilled rinse aid can create
excessive suds.
4. Replace the knob and turn to the LOCK position.
NOTE: Indicator reads correct ll level when door is completely
opened.
Rinse Aid Setting
Your rinse aid dispenser is adjustable. For most water conditions,
the factory setting will give good results. If you have hard water
and notice calcium buildup on your dishware, you may want to try
a higher setting. If you notice foam in your dishwasher, use a
lower setting.
To Adjust the Setting:
1. Turn the knob to the REFILL position and remove.
2. Turn the arrow inside the dispenser to the desired setting.
3. Replace the knob and turn to the LOCK position.
USE RINSE AID FOR
BETTER DRYING
Lock
Refill
Full
Add
11
LOADING
Loading for Best Cleaning and Drying Performance
1. Angle dirtiest dish surfaces downward and allow space
for water to ow up through each rack and between
dishware.
2. For best silverware cleaning, use the slots in the covers
to keep items separated.
3. Use TurboZone
®
(on some models) option with your
dirtiest items facing toward the lower back.
4. Angle concave surfaces such as the bottom of coffee
cups to allow water to drain and improve drying
performance.
5. Check that all spray arms spin freely before every cycle.
6. Place cups and glasses in the rows between tines.
Separating allows water ow.
Soil facing TurboZone
®
spray jets
Separated
Spray arms spin freely.
Angled surfaces
12
Top Rack Loading
Loading Recommendations
Place cups and glasses in the rows between tines. Placing them
over the tines can lead to breakage and water spots. To avoid
damage to your delicate items, be sure china, crystal, stemware
and other similar items do not touch during dishwasher operation.
Load lightweight and dishwasher-safe plastic items only in the top
rack.
Flexible Tines (on some models)
The row of tines on the left-hand and right-hand sides of the top
rack can be adjusted to make room for a variety of dishes.
Cup Shelves and Stemware Clips (on some models)
Fold down the extra shelf on either side of the top rack to hold
additional cups, stemware or long items such as utensils and
spatulas.
Adjustable 2-position Top Rack (on some models)
You can raise or lower the top rack to t tall items in either the
top or bottom rack. Adjusters are located on each side of the top
rack. Raise the top rack to accommodate items up to 9 (22 cm) in
the top rack and 13" (33 cm) in the bottom rack, or lower the top
rack to accommodate items up to 11" (28 cm) in both the top and
bottom racks.
To raise or lower the rack, hold the top rack with one hand near
the adjuster and use the other hand to pull out the top of the
adjuster. Raise or lower the rack to one of the preset positions.
NOTE: The top rack must be level.
Front
10 place load
13
Removable Top Rack
The removable rack allows you to wash larger items such as stock pots, roasters, and
cookie sheets in the lower level rack.
IMPORTANT: Remove dishes prior to removing the upper rack from the dishwasher.
To remove the rack (push tab rack stop):
1. Roll the rack 1/3 to 1/2 of the way out.
2. Remove each plastic push tab rack stop from the end of each track by pushing
inward toward the rack on the ridged area of the rack stop. The rack stop will snap
open and can be easily removed by pulling straight out. Be sure to support the track
while removing rack stops.
3. Roll the rack all the way out of the track and remove from the dishwasher.
To replace the rack:
Reverse the above steps 1 to 3 to replace the rack into the dishwasher.
Bottom Rack Loading
Loading Recommendations
The bottom rack is best suited for plates, pans, casseroles, and
utensils. See recommended loading patterns shown.
Load small items in the bottom rack only if they are secured in
place.
Load plates, soup bowls, etc., between tines.
Load bowls securely between the rows of tines. Ensure that there
is space between dishes so that the spray will reach all surfaces.
Load heavily soiled items facing the spray.
NOTE: Ensure that detergent dispenser is not blocked by tall items
such as cookie sheets and cutting boards placed at the left-hand
front of rack. See “Start Up/Quick Reference” section.
Fold-Down Tines (on some models)
You can fold down one row of tines at the back of the bottom
rack in order to accommodate larger dishware.
Keep this tine row in the 60° position when using the TurboZone
®
(on some models) option.
IMPORTANT: When moving tine row to the at position, fold only
the tine row toward the front of the dishwasher.
10 place load
Front
14
TurboZone
®
Loading (on some models)
IMPORTANT: For proper performance, only one row of items may face the TurboZone
®
spray jets.
You must select the TurboZone
®
wash option to utilize this wash feature.
Load pans, casserole dishes, etc., with the soiled surfaces facing the TurboZone
®
spray jets. TurboZone
®
wash area is located at the back of the lower dish rack.
Below are the recommended loading when using the TurboZone
®
option.
Loading Tall Items
You can wash larger items such as pots, roasters, and cookie
sheets in the bottom rack by removing the top rack. See “Top
Rack Loading” section.
IMPORTANT: Do not block detergent dispenser.
Loading Silverware
Use suggested loading patterns, as shown, to better clean your silverware.
Use the slots in the covers to keep your silverware separated for optimum wash.
NOTE: If your silverware does not t into the designated slots, ip the covers up and mix silverware types to keep them separated.
Load knives down, forks up, and alternate spoons as illustrated, for best cleaning results. Load taller silverware items to the back and
shorter to the front of basket.
Back of
dishwasher
10 place setting with double basket
12 place setting
15
DISHWASHER USE
Cycles and Options Information (on some models)
Cycles Soil Level
Time* (mins.)
w/o Options
Water
Usage
Gallons
(Liters)
Typical** Max
Pots & Pans
Works best on your toughest items such as casseroles with baked-on food
residue. Use with TurboZone
®
(on some models) option to get the best
cleaning of baked-on soils.
All Soil Levels 125 200
7.4
(28.0)
Normal Wash
This cycle with only the Heated Dry option selected, and without other options
selected, is recommended to completely wash and dry a full load of normally
soiled dishes. The energy usage label is based on this cycle and option
combination.
Light 105 170
3.3
(12.4)
Medium 105 170
4.7
(17.6)
Heavy 135 210
7.5
(28.0)
Light Wash (on some models)
Use for lightly soiled items, china or crystal.
Light 74 139
4.0
(15.0)
Quick Rinse (on some models)
Use for rinsing dishes, glasses or silverware that will not be washed right
away.
Do not use detergent. during this cycle, the rinse action will repeatedly pause
for several seconds.
All Soil Levels 10 10
1.7
(6.5)
Accela Wash
To save water and energy, High Efciency dishwashers use advanced ltration
which may result in longer cycle times (in some cases over 2 hours). When
you need fast results, Accela Wash will clean your dishes using slightly more
water and energy. For improved drying, select the Heated Dry option.
All Soil Levels 58 62
5.8
(22.0)
*Adding options will add time to the cycle. See options information section.
**This is the approximate cycle time obtained with 120°F (49°C) hot water available at the dishwasher. Increase in time results from low
temperature of the incoming water.
H
E
H
E
16
Options
Can be selected
with
What it does
Added time to cycle Added
Water
†
Gallons
(Liters)
Typical Max
TurboZone
®
option (on some models)
Blasts into every corner to eliminate the need
for soaking and scrubbing of dirty, baked-
on dishes. For your toughest items, use the
TurboZone
®
option with the Pots & Pans cycle.
See loading information.
Pots & Pans
Normal Wash
Directs all of the cleaning
power of the dishwasher to
the TurboZone
®
area during
certain times in the wash cycle.
42 55
0 - 3.7
(0 - 14.0)
High Temp
Raises the main wash temperature to improve
cleaning for loads containing tough, baked-
on food.
Pots & Pans
Normal Wash
Raises the main wash
temperature from
115°F (46°C) to 130°F or
135°F (54°C or 57°C).
35 45
0 - 3.7
(0 - 14.0)
Sani Rinse
This high temperature option sanitizes your
dishes and glassware in accordance with
NSF International NSF/ANSI Standard
184 for Residential Dishwashers. Certied
residential dishwashers are not intended
for licensed food establishments. Only
sanitizing cycles have been designed to
meet the requirements of the NSF/ANSI 184
performance standard for soil removal and
sanitization efcacy. There is no intention,
either directly or indirectly, that all cycles on
a NSF/ANSI 184 certied dishwasher meet
the NSF/ ANSI 184 performance standard
for soil removal and sanitization efcacy.
The Sani indicator indicates at the end of
the cycle whether the Sani Rinse option was
successfully completed. If the indicator does
not activate, it is probably due to the cycle
being interrupted.
Pots & Pans
Normal Wash
Increases the main wash
temperature from 115°F
(46°C) to 130°F (54°C) and
the nal rinse from 140°F
(60°C) to 156°F (69°C).
55 100
0 - 1.8
(0 - 7.0)
Heated Dry
Turns the heat element on after the wash
cycle is completed. Use rinse aid with or
without the Heated Dry option for best
drying results. Plastic items are less likely to
deform when loaded in the top dish rack.
Available with
any cycle except
Quick Rinse
Turns the heat element on at
the end of the wash cycle.
32 32 0
†
The maximum additional water used for any combination of options is 2.6 gal. (10.0 L).
17
Dishwasher Control Section
Delay Hours (on some models)
Use this option to run your dishwasher during off-peak hours. Local utility providers recommend using energy during off-peak hours
when possible.
To delay the start:
1. Select a wash cycle and options.
2. Press the button.
3. Press START/RESUME.
NOTE: Anytime the door is opened (such as, to add a dish), the Start/Resume button must be pressed again to resume the delay
countdown.
Control Lock Option (on some models)
Use the Control Lock option to avoid unintended use of the dishwasher between cycles. When LOCK ON is lit, all buttons are disabled.
The dishwasher door can still be opened/closed while the controls are locked.
To turn on the Lock:
Press and hold HEATED DRY for 3 seconds. LOCK ON will light up. If you press any pad while your dishwasher is locked, the light
ashes 3 times.
NOTE: The dishwasher cannot start if the control is locked.
To turn off the Lock:
Press and hold HEATED DRY for 3 seconds. The light turns off.
Dishwasher Feedback Section
Selecting Cycles and Options
1. Select the desired cycle. If you want to run the last cycle that was completed, you can simply press START/RESUME once to show
which options you used, then press START/RESUME again to start the cycle.
2. Select the desired options. Not all options are available for every cycle. If an invalid option is selected for a given cycle, the lights
will ash.
Turning Off/On the Sound
Press and hold HIGH TEMP for 3 seconds to toggle sound on and off. The sound will not be deactivated for cycle interruption or
service required messages.
Canceling a Cycle
1. Open the door slightly to stop the cycle. Wait for the spraying action to stop before completely opening the door.
2. Press CANCEL/DRAIN button once. The Cancel/Drain light will light up.
3. Close the door within 3 seconds. The dishwasher starts a drain cycle (if water remains in bottom of dishwasher). Let the dishwasher
drain completely. The Cancel/Drain light turns off after 2 minutes.
Changing a Cycle After Dishwasher Is Started
You can interrupt a cycle and restart your dishwasher from the beginning using the following procedure.
1. Open the door slightly to stop the cycle. Wait for the spraying action to stop, then open the door completely.
2. Check that detergent dispenser cover is still closed. If cover is open, you will need to rell the detergent dispenser before restarting
your new cycle.
3. Press CANCEL/DRAIN twice to reset the control.
4. Select new cycles and options.
5. Press START/RESUME.
18
WASHING SPECIAL ITEMS
If you have doubts about washing a particular item, check with the manufacturer to see if it is dishwasher safe.
Material Dishwasher Safe? Comments
Aluminum Yes High water temperature and detergents can affect nish of anodized aluminum.
Disposable Aluminum No Do not wash disposable aluminum pans in the dishwasher. These might shift during
washing and transfer black marks to dishes and other items.
Bottles and Cans No Wash bottles and cans by hand. Labels attached with glue can loosen and clog
the wash system and reduce washing performance.
Cast Iron No Seasoning will be removed, and then cast iron will rust.
China/Stoneware Yes Always check manufacturer’s recommendations before washing. Antique,
hand-painted, or over-the-glaze patterns may fade. Gold leaf can discolor or
fade.
Crystal Yes Always check manufacturer’s recommendations before washing. Some types of
leaded crystal can etch with repeated washing.
Gold No Gold-colored atware will discolor.
Glass Yes Milk glass material yellows with repeated dishwasher washing.
Hollow-Handle Knives No Handles of some knives are attached to the blade with adhesives which can
loosen if washed in the dishwasher.
Pewter, Brass, Bronze,
and Copper
No High water temperatures and detergent can discolor or pit the nish.
Disposable Plastics No Cannot withstand high water temperatures and detergents.
Plastics Yes Always check manufacturer’s recommendations before washing. Plastic items
may vary in their ability to withstand high temperatures and detergents. It is
recommended that lightweight items such as lids and butter dishes be placed
in the upper rack only. Sturdy items such as coolers and high-chair trays may
be placed in the lower rack. When washing plastic items in the lower rack, it is
recommended not to use the Heated Dry option.
Stainless Steel Yes Run a rinse cycle if not washing immediately. Prolonged contact with food
containing salt, vinegar, milk products, or fruit juice can damage nish.
Sterling Silver or
Silver Plate
Yes Run a rinse cycle if not washing immediately. Prolonged contact with food
containing salt, acid, or sulde (eggs, mayonnaise, and seafood) can damage
nish.
Tin No Not recommended.
Wooden Ware No Wash by hand. Always check manufacturer’s instructions before washing.
Untreated wood can warp, crack, or lose its nish.
Large Casserole Dish Yes There may be certain casserole dishes that may not t in front of the TurboZone
®
(on some models) feature in the back of the lower dish rack. Adjust the tines as
necessary to load the large dishes.
19
DISHWASHER CARE
Cleaning
Cleaning the exterior
In most cases, regular use of a soft, damp cloth or sponge and
a mild detergent is all that is necessary to keep the outside of
your dishwasher looking nice and clean. If your dishwasher has a
stainless steel exterior, a stainless steel cleaner is recommended.
Cleaning the interior
Hard water minerals can cause a white lm to build up on the
inside surfaces, especially just beneath the door area.
Do not clean the dishwasher interior until it has cooled. You may
want to wear rubber gloves. Do not use any type of cleanser
other than dishwasher detergent because it may cause foaming or
sudsing.
To clean interior:
Make a paste with powdered dishwasher detergent on a damp
sponge and clean.
OR
Use liquid automatic dishwasher detergent and clean with a
damp sponge.
OR
See the vinegar rinse procedure in the “CLOUDY OR SPOTTED
DISHWARE” in the
“TROUBLESHOOTING” section.
NOTE: Run a normal cycle with dishwasher detergent after
cleaning the interior.
Drain Air Gap
Some state or local plumbing codes require the addition of a
drain air gap between a built-in dishwasher and the home drain
system. Check the drain air gap when your dishwasher is not
draining well.
The drain air gap is usually located on top of the sink or
countertop near the dishwasher. To order a drain air gap, please
call 1-844-553-6667. Ask for Part Number 300096. You may
also purchase the part online: www.searspartsdirect.com.
NOTE: The drain air gap is an external plumbing device that is
not part of your dishwasher. The warranty provided with your
dishwasher does not cover service costs directly associated with
the cleaning or repair of the external drain air gap.
To clean the drain air gap Clean the drain air gap periodically to ensure proper drainage
of your dishwasher. With most types, you lift off the chrome cover.
Unscrew the plastic cap. Then check for any soil buildup. Clean if
necessary.
Vacation or Extended Time Without Use
To reduce the risk of property damage If you will not be using the dishwasher during the summer
months, turn off the water and power supply to the
dishwasher.
Make sure the water supply lines are protected against
freezing conditions. Ice formations in the supply lines can
increase water pressure and damage your dishwasher or
home. Damage from freezing is not covered by the warranty.
When storing your dishwasher in the winter, avoid water
damage by having your dishwasher winterized by authorized
service personnel.
20
TROUBLESHOOTING
CHECK THESE POINTS TO HELP SAVE YOU TIME AND MONEY.
PROBLEM SOLUTION
DISHWASHER DOES NOT
RUN
NOTE: It is normal for the dishwasher to repeatedly pause several times during a cycle.
If the Start/Resume light is blinking, close the door and push START/RESUME.
Be sure the door is closed and latched.
Check that there is not an interference with large casserole dishes and the wash system at the back
of the dishwasher. Adjust loading as necessary to ensure door is closed and latched.
Be sure you have disabled Sleep Mode by pressing either START/RESUME or CANCEL/DRAIN, or
opening the door before selecting your cycle/option.
Be sure you have selected a cycle. See the “Cycles and Options Information.”
Be sure there is power to the dishwasher. A circuit breaker or fuse may have tripped.
If lights other than Start/Resume blink and the unit will not run, you will need to call for service.
DETERGENT REMAINS IN THE
DISPENSER OR TABLET IS ON
BOTTOM OF TUB
Check for dishware such as cookie sheets, cutting boards, or large containers, etc., that may be
blocking the detergent dispenser from opening properly.
Be sure your detergent is fresh and lump free.
Be sure the cycle has completed (blue light is on). If it has not completed, you will need to resume the
cycle by closing the door and pressing START/RESUME.
CYCLE RUNS TOO LONG NOTES:
To use less water and reduce energy consumption, you will encounter cycles that typically run for
up to 3 hours.
A water heater setting of 120°F (49ºC) is best. The dishwasher will delay longer while heating
cooler water.
Some options will add time to the cycle. See the “Cycles and Options Information” section. The
Heated Dry option adds ½ hour.
Try the 1 Hour Wash cycle.
Run the hot water at a faucet close to the dishwasher before selecting and starting the cycle.
DISHWASHER NOT DRYING NOTE: Plastic and items with nonstick surfaces are difcult to dry because they have a porous
surface which tends to collect water droplets. Towel drying may be necessary.
Use of rinse aid along with the Heated Dry option is needed for proper drying.
Proper loading of items can affect drying. See the specic loading instructions within this guide.
Glasses and cups with concave bottoms hold water. This water may spill onto other items when
unloading.
Unload the bottom rack rst.
Locate these items on the more slanted side of the rack for improved results.
WILL NOT FILL Be sure the water is turned on to the dishwasher.
Check that the oat is free from obstructions. See the “Parts and Features” section.
Check for suds in the dishwasher. If foam or suds are detected, the dishwasher may not operate
properly or may not ll with water.
WATER REMAINS IN THE
TUB/WILL NOT DRAIN
Be sure the cycle has completed (the blue light is on). If it has not, you will need to resume the cycle
by closing the door and pressing START/RESUME.
If dishwasher is connected to a food waste disposer, be sure the knockout plug has been removed
from the disposer inlet.
Check for kinks in the drain hose.
Check for food obstructions in the drain or disposer.
Check your house fuse or circuit breaker.
21
PROBLEM SOLUTION
HARD WATER (WHITE
RESIDUE ON DISHWASHER
INTERIOR OR GLASSWARE)
NOTE: Extremely hard water mineral deposits can cause damage to your dishwasher and make
it difcult to achieve good cleaning. You may bring water samples to Sears to check your water
hardness level. A water softener is strongly recommended if your hardness is 15 grains or more. If a
water softener is not installed, the following steps may help:
Use a commercial cleaner designed for dishwashers once per month.
Clean the Ultra Wash
®
lters at least once per month.
Always use a rinse aid.
Always use a high-quality, fresh detergent.
Use a detergent booster/water softener additive designed for dishwashers.
ODORS NOTE: If the dishwasher is not used daily, you can run a rinse cycle with the partial load until a full
load is ready to run, or use the Top Rack Only option (on some models) for partial loads.
Run a vinegar rinse through the dishwasher by putting 2 cups (500 mL) of white vinegar in an upright
glass measuring cup in the lower rack. Run a normal cycle with the Heated Dry option turned off. Do
not use detergent.
The dishwasher may not be draining properly. See the “WATER REMAINS IN THE TUB/WILL NOT
DRAIN” section in the “Troubleshooting” section.
NOISY NOTES:
Surging sounds can occur periodically throughout the cycle while the dishwasher is draining.
Normal water valve hissing may be heard periodically.
A normal snap sound may be heard when the detergent dispenser opens during the cycle and
when the door is opened at the end of the cycle.
Improper installation will affect noise levels.
Be sure the lters are properly installed.
A thumping sound may be heard if items extend beyond the racks and interfere with the wash arms.
Readjust the dishware and resume the cycle.
FOOD SOILS REMAIN ON
DISHES
Be sure the dishwasher is loaded correctly. Improper loading can greatly decrease the washing
performance. See the “Loading for Best Cleaning and Drying Performance” section.
Check lter to ensure it is properly installed. Clean it if needed. See the “Cleaning Instructions”
section in the “Ultra Wash
®
Filtration System” section for details.
Select the proper cycle and option for the type of soils. The Pots & Pans cycle with the
TurboZone
®
(on some models) option can be used for tougher loads.
Be sure the incoming water temperature is at least 120°F (49ºC).
Use the proper amount of fresh detergent. More detergent is needed for heavier-soiled loads and
hard water conditions.
Scrape food from dishes prior to loading (do not prerinse).
DID NOT SANITIZE If the sanitized light is blinking, the load is NOT sanitized. The cycle was interrupted in the nal rinse,
or your water heater is set too low. Set your water heater to 120ºF (49ºC).
DAMAGE TO DISHWARE Improper loading can cause dishes to become chipped or damaged. See the specic loading
instructions within this guide.
BLINKING LIGHTS If Start/Resume or any status lights are blinking and the dishwasher will not run, close the door and
push START/RESUME. If the dishwasher still will not run, call service.
H
E
H
E
22
PROBLEM SOLUTION
CLOUDY OR SPOTTED
DISHWARE (AND HARD
WATER SOLUTION)
NOTES:
Liquid rinse aid is necessary for drying and to reduce spotting.
Use the correct amount of detergent.
Conrm that the cloudiness is removable by soaking the item in white vinegar for 5 minutes. If the
cloudiness disappears, it is due to hard water. Adjust the amount of detergent and rinse aid. See
“HARD WATER (WHITE RESIDUE ON DISHWASHER INTERIOR OR GLASSWARE)” in
“Troubleshooting.” If it does not come clear, it is due to etching.
Be sure the incoming water temperature is set at 120°F (49ºC).
Try using the High Temp and Sani Rinse options.
To remove spotting, run a vinegar rinse through the dishwasher.
Wash and rinse the affected dishware and load into dishwasher. Remove all silverware and
metal items. Put 2 cups (500 mL) of white vinegar in a glass measuring cup in the lower rack. Run
a normal cycle with the Heated Dry option turned off. No detergent is needed.
ETCHING (PERMANENT
CLOUDINESS)
This is an erosion of the surface of the glassware and can be caused by a combination of: water that
is too hot, from using too much detergent with soft water or by pre-washing. Detergent needs food
soil to act upon. If etching has occurred, the glassware is permanently damaged. To avoid further
etching, adjust the detergent amount to match the water hardness, stop pre-washing, and use water
heating options only when incoming water temperature is below 120°F (49ºC).
LEAKING WATER Be sure dishwasher has been installed properly and is level.
Suds can cause the dishwasher to overow. Measure the detergent accurately and use only
detergents designed for use in a dishwasher. Less detergent is needed in soft water. Try another
brand of detergent if sudsing continues.
To avoid rinse aid leaking from the dispenser, be sure the lid is securely attached and avoid
overlling.
TUB IS DISCOLORED NOTES:
High iron content in the water can discolor the tub.
Tomato-based foods can discolor the tub or dishware.
A citrus-based cleaner can be used to clean.
W11411288A
©2020 Transform SR Brands LLC 01/20
Kenmore
®
Customer Care Hotline
Service à la clientèle
Línea directa de atención
al cliente
To schedule in-home repair service
or order replacement parts
Para pedir servicio de reparación
a domicilio, y ordenar piezas
Para pedir servicio de reparación a
domicilio y ordenar piezas
1-844-553-6667
www.
kenmore.
com
®
