Frigidaire FPFU19F8RFE Professional 19 Cu. Ft. Single-Door User Manual

Frigidaire.com USA 1-800-374-4432 Frigidaire.ca Canada 1-800-265-8352

use

care

FREEZER

A16366303 (February 2021)

Introduction .......................................................2

Important Safety information.....................3

Features .............................................................5

Installation .........................................................7

Door Reversal ...................................................9

Door Removal ................................................. 10

Door Handle Installation .............................. 11

Water Supply Connection .......................... 12

Controls and Settings .................................. 15

Ice Maker .......................................................... 19

Storage Features ..........................................20

Filter Replacement ...................................... 22

Care and Cleaning ....................................... 23

Troubleshooting .......................................... 25

Limited Warranty ......................................... 28

INTRODUCTION

Doors

 Handles are secure and tight

 Door seals completely to cabinet on

all sides

 Door is level from side to side across

the top

Leveling

 Appliance is level, side to side and

front to back

 Cabinet is setting solid on all corners

 Anti-tip bracket set in front

Electrical Power

 House power turned on

 Appliance plugged in

Ice Maker

 House water supply connected to

appliance

 No water leaks present at all

connections - recheck in 24 hours

 Ice maker is turned on

Final Checks

 Shipping material removed

 Registration card sent in

Installation Checklist



Welcome to our

family

Thank you for bringing Frigidaire into

your home! We see your purchase as the

beginning of a long relationship together.

This manual is your resource for the use

and care of your product. Please read

it before using your appliance. Keep it

handy for quick reference. If something

doesn’t seem right, the troubleshooting

section will help you with common issues.

FAQs, helpful tips and videos, cleaning

products, and kitchen and home accessories

are available at Frigidaire.com.

We are here for you! Visit our website,

chat with an agent, or call us if you need

help. We may be able to help you avoid

a service visit. If you do need service, we

can get that started for you.

Let’s make it ocial! Be sure to register

your product.

Keep your product info here so it’s easy

to ﬁnd.

Model Number ____________________

Serial Number ____________________

Purchase Date ____________________

jfk;fkda;jfda jfk;fkda;jfda jfk;fkda;jfda jfk;fkda;jfda

Serial Number Location

WARNING

WARNING indicates a potentially haz-

ardous situation which, if not avoided,

could result in death or serious injury.

IMPORTANT

IMPORTANT indicates installation, oper-

ation or maintenance information which

is important but not hazard-related.

DANGER

DANGER indicates an imminently haz-

ardous situation which, if not avoided,

will result in death or serious injury.

CAUTION

CAUTION indicates a potentially haz-

ardous situation which, if not avoided,

may result in minor or moderate injury.

Safety Deﬁnitions

This is the safety alert symbol. It is used

to alert of potential personal injury hazards.

Obey all safety messages that follow this

symbol to avoid possible injury or death.

Safety Instructions

• DO NOT store or use gasoline, or

other ﬂammable liquid within or in the

vicinity of this appliance. Read Product

Label for warnings regarding ﬂamma-

bility and other hazards.

• DO NOT store explosive substances

such as aerosol cans with a ﬂammable

propellant in this appliance.

• DO NOT operate the refrigerator in the

presence of explosive fumes.

• Avoid contact with any moving parts

of automatic ice maker.

• Remove all staples from the carton.

Staples can cause severe cuts, and also

destroy ﬁnishes if they come in contact

with other appliances or furniture.

WARNING

Please read all instructions before using

this appliance.

Child Safety

This appliance is not intended for use by

persons (including children) with reduced

physical, sensory or mental capabilities, or

lack of experience and knowledge, unless

they have been given supervision or in-

struction concerning use of the appliance

by a person responsible for their safety.

Destroy or recycle the carton, plastic

bags, and any exterior wrapping mate-

rial immediately after the refrigerator is

unpacked. Children should NEVER use

these items to play. Cartons covered with

rugs, bedspreads, plastic sheets or stretch

wrap may become airtight chambers, and

can quickly cause suocation.

IMPORTANT SAFETY INFORMATION

WARNING

WARNING! CALIFORNIA RESIDENTS

Cancer and Reproductive Harm

www.P65Warnings.ca.gov

Proper Disposal of your Appliance

Risk of child entrapment

Child entrapment and suocation are not

problems of the past. Junked or aban-

DANGER

DANGER Risk of ﬁre or explosion.

Flammable refrigerant used. Do not use

mechanical devices to defrost refrigera-

tor. Do not puncture refrigerant tubing.

DANGER Risk of ﬁre or explosion.

Flammable refrigerant used. To be re-

paired only by trained service person-

nel. Use only manufacturer-authorized

service parts. Any repair equipment

used must be designed for ﬂammable

refrigerants. Follow all manufacturer

repair instructions. Do not puncture

refrigerant tubing.

CAUTION

CAUTION Risk of ﬁre or explosion.

Dispose of refrigerator properly

in accordance with the applicable

federal or local regulations. Flammable

refrigerant used.

CAUTION Risk of ﬁre or explosion

due to puncture of refrigerant tubing.

Follow handling instructions carefully.

Flammable refrigerant used.

IMPORTANT SAFETY INFORMATION

IMPORTANT

CFC/HCFC Disposal

Your old appliance may have a cooling

system that used CFCs or HCFCs (chlo-

roﬂuorocarbons or hydrochloroﬂuoro-

carbons). CFCs and HCFCs are believed

to harm stratospheric ozone if released

to the atmosphere. Other refrigerants

may also cause harm to the environ-

ment if released to the atmosphere.

If you are throwing away your old

appliance, make sure the refrigerant

is removed for proper disposal by a

qualiﬁed technician. If you intentionally

release refrigerant, you may be subject

to ﬁnes and imprisonment under provi-

sions of environmental legislation.

IMPORTANT

To turn o power to your appliance you

must unplug the power cord from the

electrical outlet.

Grounding type wall receptacle

Power cord with

3-prong grounded plug

Do not, under

any circumstances,

cut, remove,

or bypass the

grounding prong.

WARNING

These guidelines must be followed to

ensure that safety mechanisms in this

appliance will operate properly.

Electrical information

• Plug the appliance into its own ded-

icated 115 Volt, 60 Hz., 15 Amp, AC

only electrical outlet. The power cord

of the appliance is equipped with a

3-prong grounding plug for your pro-

tection against electrical shock haz-

ards. Plug it directly into a properly

grounded 3-prong receptacle. Install

the receptacle in accordance with

local codes and ordinances. Consult a

qualiﬁed electrician. Avoid connect-

ing the appliance to a Ground Fault

Interrupter (GFI) circuit. Do not use

an extension cord or adapter plug.

• If the power cord is damaged, an

authorized service technician should

replace it to prevent any risk.

• Never unplug the appliance by pull-

ing on the power cord. Always grip

the plug ﬁrmly, and pull straight out

from the receptacle to prevent dam-

aging the power cord.

• Unplug the appliance before cleaning

to avoid electrical shock.

• Performance may be aected if the

voltage varies by 10% or more. Oper-

ating the appliance with insucient

power can damage the compressor.

Such damage is not covered under

your warranty.

• Do not plug the unit into an electrical

outlet controlled by a wall switch or

pull cord to prevent the appliance

from being turned o accidentally.

• WARNING: Do not use electrical ap-

pliances inside the food storage com-

partments of the appliance unless

they are recommended accessories

for use within this model.

doned appliances are still dangerous –

even if they will sit for “just a few days”. If

you are getting rid of your old appliance,

please follow the instructions below to

help prevent accidents.

We strongly encourage responsible

appliance recycling/disposal methods.

Check with your utility company or visit

energystar.gov/products/recycle for more

information on recycling your old appli-

ance.

Before you throw away your

old appliance:

• Remove door.

• Leave shelves in place so

children may not easily

climb inside.

• Have refrigerant removed

by a qualiﬁed service technician.

FEATURES

*Features may vary according to model

A Adjustable Tall Item Door Bins

with Dividers

B Adjustable Gallon Door Bin

with Divider

C Adjustable Half-Gallon Door Bins

with Dividers

D LED Lighting

E Air Filter

F Adjustable Full Width Metal Shelves

G *Multi-Port Air Exhaust Ducts

H Soft Freeze Zone Drawer

I Appliance Control Display

J Ice Maker

K Slide-Out Shelf with Removable

Ice Storage Bins

L Lower Storage Drawer with Dividers

D D

G G

IMPORTANT

*Do not place items in front of the

Multi-Port Air Exhaust Ducts as this will

impact temperature performance.

IMPORTANT

Accessories are available for your appliance and may be purchased at

Frigidaire.com or by calling 1-800-374-4432 (Frigidaire.ca or 1-800-265-8352 in

Canada) or from an authorized seller.

IMPORTANT

Moving your Appliance

Your appliance is heavy. When moving the appliance for cleaning or service, raise

the anti-tip bracket (see “Setting the anti-tip bracket”). Be sure to cover the ﬂoor

with cardboard or hardboard to avoid ﬂoor damage. Always pull the appliance

straight out when moving it. Do not wiggle or “walk” the appliance when trying to

move it as ﬂoor damage could occur.

FEATURES

IMPORTANT

Cleaning your Appliance

Remove tape and glue residue from surfaces before turning on the appliance. Rub

a small amount of liquid dish soap over any remaining adhesive with your ﬁngers.

Rinse with warm water and dry with a soft cloth.

Do not use sharp instruments, rubbing alcohol, ﬂammable ﬂuids, or abrasive cleaners

to remove tape or glue. These products can damage the surface of your appliance.

After you remove all of the package materials, clean the inside of your appliance

before using it. See the CARE & CLEANING section in this manual.

See important information about cleaning glass shelves and covers in the STORAGE

FEATURES section of this manual.

This Use & Care Manual provides general

operating instructions for your model. Use

the appliance only as instructed in this Use

& Care Manual. Before starting the appli-

ance, follow these important ﬁrst steps.

Installation

Installation clearances

Allow the following clearances for ease

of installation, proper air circulation, and

plumbing and electrical connections:

Sides 3/16 in.

Top & Back 1 in.

WARNING

DO NOT install the appliance where

the temperature will drop below 0°F

(-18°C) or rise above 110°F (43°C). The

compressor will not be able to maintain

proper temperatures inside the unit.

Location

• Choose a place that is near a ground-

ed electrical outlet. Do Not use an

extension cord or an adapter plug.

• If possible, place the appliance out of

direct sunlight and away from the range,

dishwasher or other heat sources.

• Install the appliance on a ﬂoor that is

level and strong enough to support a

fully loaded appliance.

Freezer

3/8”

(10mm)

3/16”

(5 mm)

3/16”

(5 mm)

1”

(25 mm)

1”

(25 mm)

INSTALLATION

CAUTION

Do not block the lower front of your ap-

pliance. Sucient air circulation is essen-

tial to operate your appliance properly.



NOTE

If your appliance is placed with the door

hinge side against a wall, you may have

to allow additional space for the handle

so the door can be opened wider.

Leveling

Rest all bottom corners ﬁrmly on a

solid ﬂoor.

The ﬂoor must be strong enough to

support a fully loaded appliance.

It is VERY IMPORTANT for your unit to

be level in order to function properly.

If the appliance is not leveled during

installation, the door may be misaligned

and not close or seal properly, causing

cooling, frost or moisture problems.

To Level the Appliance:

Level the unit using a carpenter’s level.

Adjust the leveling feet at the front mak-

ing minor adjustments to the rear leveling

feet as needed. Level the unit front to

back and side to side. Make sure all 4 feet

fully touch the ﬂoor.

CAUTION

The cabinet is heavy. Two people are

recommended to level the cabinet.

IMPORTANT

Level the appliance to ensure optimal

performance of the ice maker.

INSTALLATION

Setting the anti-tip bracket:

Units are equipped with an anti-tip brack-

et. The anti-tip bracket is located on the

lower front corner of the cabinet, on the

lower hinge bracket. After fully leveling

the unit, lower the anti-tip foot by turning

it clockwise until is securely contacts the

ﬂoor. Do not raise the cabinet.

Lower

Anti-tip Bracket

WARNING

The anti-tip device must be

installed according to the

instructions in your Use &

Care Manual. Failure to do

so may result in injury.

Guidelines for ﬁnal positioning of

your appliance:

• Rest all bottom leveling feet ﬁrmly on

a solid ﬂoor.

• The cabinet should be level on all sides.

• The door should be level.

Door

Raise

Door

Raise

Door

Freezer Hinge

Adjustment

Freezer

Refrigerator

Door

Lower Hinge Adjustment for Leveling

the Doors of the Matching Refrigerator /

Freezer Pair

To level the doors using the adjustable

lower hinge (some models):

If the refrigerator door is lower than the

freezer door, raise the refrigerator door

by turning the adjustment screw counter-

clockwise using a 19mm socket wrench.

(See illustration below.)

If the freezer door is lower than the

refrigerator door, raise the freezer door

by turning the adjustment screw counter-

clockwise using a 19mm socket wrench.

(See illustration below.)

Pairing Installation

Pairing kit (TWINSPAIRKIT) is REQUIRED

if you are installing the following

appliances next to each other:

• Freezer and Refrigerator

• Freezer and Freezer

• Refrigerator and Refrigerator

To obtain this kit, please contact the

retailer where you purchased your

appliances, or contact Frigidaire customer

service at 1-800-374-4432 in the US,

1-800-265-8352 in Canada.

DOOR REVERSAL

Single Unit Door Swing Reversal:

CAUTION

Doors are heavy. Two people are recommended to remove or replace the door

assembly from the cabinet.

Left-hand Swing Right-hand Swing

• Freezer: Left-hand to Right-hand Swing order TTDRRVFFKIT

• Refrigerator: Right-hand to Left-hand Swing order TTDRRVFRKIT

Order the kit on Frigidaire.com or by calling 1-800-374-4432 (Frigidaire.ca or

1-800-265-8352 in Canada).

Dual Unit Door Reversal:

• Moving the Freezer door to the Refrigerator also changes the right-hand swing to

a left-hand swing.

• Moving the Refrigerator door to the Freezer also changes the left-hand swing to

a right-hand swing.



NOTE

The hinges and associated hardware also need to be transfered in order to switch doors.

DOOR REMOVAL

IMPORTANT

Before you begin, remove the electrical power cord from the wall outlet. Remove

any food from door shelves.

Tools Necessary:

Socket

Wrench Set

Adjustable

Wrench

5/16"

(8mm)

Fixed

Wrench

Flathead

Screwdriver

and

Phillips

Head or

#2 Square

Drive Head

8mm

(M5x16mm)

Hex head screw x3

Door removal:

CAUTION

Doors are heavy. Two people are recom-

mended to remove or replace the door

assembly from the cabinet.

CAUTION

The door should be closed prior to

removing or installing

• Unplug the unit or switch the breaker

that supplies power to the unit to the

o position.

• Remove the plastic top hinge cover.

• Hold the door in place while remov-

ing the top hinge from the cabinet.

• Remove the M5x16 mm hex head

screws from the top hinge with a

wrench or socket.

• Lift the door upwards and pull up

and away from the cabinet until free

of the bottom hinge pin mounted on

the front of the cabinet.

• To replace the door, reverse the above

procedures and securely tighten all

screws to prevent hinge slippage.

DOOR HANDLE INSTALLATION

CAUTION

Wear gloves and use extreme CAUTION

when installing these handles. The round-

ed end of the handles may be sharp.

Door Handle Mounting Instructions

1. Remove handle from carton and any

other protective packaging.

2. Position handle end caps over upper

and lower pre-installed shoulder

bolts (A) that are fastened into door,

ensuring the holes for the set screws

are facing toward the hinge.

3. While holding handle ﬁrmly against

door, fasten upper and lower Allen set

screws (B) with supplied Allen wrench.



NOTE

All set screws should be tightened and

sub-ﬂush (Allen set screw should be

seated just below the surface of the

end cap) of handle end cap. The end

caps should be drawn tight to door

with no gaps.

WATER SUPPLY CONNECTION



NOTE

Ensure that your water supply line con-

nections comply with all local plumb-

ing codes.

Before Installing The Water Supply Line,

You Will Need:

• Basic Tools: adjustable wrench, ﬂat-blade

screwdriver, and Phillips

screwdriver

• Access to a household cold water

line with water pressure between 30

and 100 psi.

• A braided stainless steel water supply

line with integral ﬁttings such as Smart

Choice® 5304437642 or ¼" copper

line with compression ﬁttings. The line

must be 6� or longer to allow appli-

ance to be moved out for cleaning.

• A shuto valve to connect the water

supply line to your household water

system. DO NOT use a self-piercing

type shuto valve.

• Do not reuse compression ﬁtting or

use thread seal tape.

• A compression nut and ferrule

(sleeve) for connecting a copper

water supply line to the ice maker

inlet valve.

WARNING

To avoid electric shock, which can

cause death or severe personal injury,

disconnect the unit from electrical

power source before connecting a

water supply line to the appliance.

CAUTION

To Avoid Property Damage:

• Use Copper or Stainless Steel braid-

ed tubing for the water supply line.

Frigidaire does not recommend wa-

ter supply tubing made of ¼" plastic.

Plastic tubing greatly increases the

potential for water leaks, and the

manufacturer will not be responsible

for any damage if plastic tubing is

used for the supply line.

• DO NOT install water supply tubing

in areas where temperatures fall

below freezing.

• Chemicals from a malfunctioning

softener can damage the ice maker.

If the ice maker is connected to soft

water, ensure that the softener is

maintained and working properly.

WATER SUPPLY CONNECTION

To Connect Water Supply Line To Ice

Maker Inlet Valve

1. Disconnect the appliance from

electrical power source.

2. Place the end of the water supply

line into a sink or bucket. Turn ON

the water supply and ﬂush the supply

line until the water is clear. Turn OFF

the water supply at the shuto valve.

3. Remove the plastic cap from the wa-

ter valve inlet and discard the cap.

4. If you use copper tubing - Slide the

brass compression nut, and then

the ferrule (sleeve) onto the water

supply line. Push the water supply

line into the water valve inlet as far

as it will go (¼"/6.4 mm). Slide the

ferrule (sleeve) into the valve inlet

and ﬁnger tighten the compression

nut onto the valve. Tighten another

half turn with a wrench; DO NOT

overtighten. See Figure 1.

If you use braided ﬂexible stainless

steel tubing - The nut is already

assembled on the tubing. Slide the

nut onto the valve inlet and ﬁnger

tighten the nut onto valve. Tighten

another half turn with a wrench; DO

NOT overtighten. See Figure 2.

A Plastic Water Tubing to Ice Maker Fill

Tube (foamed within the cabinet)

B Steel Clamp (Fig. 1: ¼"; Fig. 2: ½")

C Brass Compression Nut

D Ferrule (Sleeve)

E Copper Water Line

F Water Valve Bracket

G Valve Inlet

H Water Valve

I Copper Water Line from

Household Water Supply*

J Braided Flexible Stainless Steel

Water Line

*Include enough tubing in the loop to allow

moving the appliance out for cleaning

Figure 1

Figure 2

5. With the steel clamp and screw,

secure the water supply line (copper

tubing only) to the rear panel of

appliance as shown.

6. Coil the excess water supply line

(copper tubing only), about 2½ turns,

behind appliance as shown and

arrange coils so they do not vibrate or

wear against any other surface.

7. Turn ON the water supply at shuto

valve and tighten any connections

that leak.

8. Reconnect the appliance to electri-

cal power source.

9. To turn ice maker on, press and hold

ICE MAKER on the appliance display

for 3 seconds.



NOTE

Check with your local building au-

thority for recommendations on water

lines and associated materials prior to

installing your new appliance. Depend-

ing on your local/state building codes,

Frigidaire recommends for homes with

existing valves its Smart Choice

water

line kit 5305513409 (with a 6�Stain-

less Steel Water Line) and for homes

without an existing valve, Frigidaire

recommends its Smart Choice

water

line kit 5305510264 (with a 20�copper

water line with self-tapping saddle

valve). Please refer to Frigidaire.com for

more information.

WATER SUPPLY CONNECTION

CONTROLS AND SETTINGS

Cool Down Period

To ensure safe food storage, allow the appliance to operate with the door closed for at

least 8 hours before loading it with food.

Power On

Upon opening the door, the settings icon will illuminate on the control panel.

Appliance Control Display

5 6 7 8 9

By pressing the settings icon, you will illuminate all of the icons on the appliance

control. After 10 seconds of no user interaction with the icons or door closure, all the

icons will fade, except for the settings icon.

The appliance control display is located in the cabinet below the upper drawer.

CONTROLS AND SETTINGS

Alarms

Controls

DOOR OPEN

This alert indicates the door has been open for 5 minutes or more. The DOOR

OPEN LED will illuminate and the audible alert will sound until the door is closed.

The audible alert can be turned o by pressing DOOR OPEN or by closing the door.

If the door is ajar for 5 minutes, the interior light will turn o.

POWER OUTAGE

The POWER OUTAGE indicator light informs you there has been a power inter-

ruption which could have led to the internal temperature increasing beyond the

safe temperature range. After you check your food, reset the alarm by pressing

POWER OUTAGE.

HIGH TEMP

If the temperature increases above a safe temperature range, the red HIGH

TEMP LED light will illuminate and the alarm will sound. Reset the alarm by

pressing HIGH TEMP.

The lock button can be used to lock the control panel. Press and hold for 3 sec-

onds to enable/disable. While in the locked state, no changes can be made

until unlocked.

The settings icon illuminates upon opening the appliance door. Press

to reveal

other function icons. After 10 seconds of non use of icons or door closure, all

icons will fade except .

Adjusting Temp

To adjust the temperature setting, press + to raise the temperature and - to

lower the temperature on the appliance control. Allow several hours for the tem-

perature to stabilize between adjustments.

TEMP °F/°C

Short press to toggle between Fahrenheit (°F) and Celsius (°C).

FREEZE BOOST

Prior to grocery shopping, activate FREEZE BOOST so upon returning you can

ensure your newly purchased frozen food will be preserved.

Turning on FREEZE BOOST will cool the appliance down to a target tempera-

ture and will remain active for up to 24 hours before automatically deactivating

or being manually exited.

To turn the function o, press FREEZE BOOST. When you turn o FREEZE

BOOST, it will automatically reset the freezer back to the previous temperature

setting.

AIR FILTER

The AIR FILTER replacement alert will illuminate when it is time to replace the

air ﬁlter. See the FILTER REPLACEMENT

section for instructions on how to

replace the air ﬁlter. After changing the air ﬁlter, reset the AIR FILTER alert by

pressing and holding AIR FILTER.

ICE MAKER

The ice maker is default on, which means it will constantly make ice until the ice

bucket is full. The ice maker can be turned o to stop making new ice. Press and

hold ICE MAKER for 3 seconds to turn it on/o.



NOTE

While in Sabbath Mode, neither the lights nor the appliance control display will work

(except to exit Sabbath Mode) until Sabbath Mode is deactivated.

Additionally, the ice maker will stop ice production when Sabbath mode is activated.

The appliance stays in Sabbath Mode after power failure recovery. It must be deacti-

vated with the buttons on the appliance control display.

Sabbath Mode

The Sabbath Mode is a feature that disables portions of the appliance and its controls

in accordance with observance of the weekly Sabbath and religious holidays within

the Orthodox Jewish community.

To enter Sabbath Mode

Simultaneously press and hold — and TEMP F/C for 5 seconds.

“Sb” will appear on the appliance control display indicating the unit is in Sabbath mode.

CONTROLS AND SETTINGS

For further assistance, guidelines of proper usage and a complete list of

models with the Sabbath feature, please visit the web at star-k.org.

The unit stays in Sabbath mode after a power failure recovery. It must be deactivated

with the buttons on the appliance control display.

To exit Sabbath Mode

Simultaneously press and hold — and TEMP F/C for 5 seconds.

The appliance control display will show all of the icons.

CONTROLS AND SETTINGS

In the Sabbath mode, the HIGH TEMP alarm is active for health reasons. For example,

if you leave the door ajar, the HIGH TEMP alarm is activated. The freezer will function

normally once you close the door, without any violation of the Sabbath/holidays. The

HIGH TEMP alarm comes on when the cabinet temperature is outside the safe zone

for 20 minutes. The alarm silences itself after 10 minutes while the HIGH TEMP icon

stays lit until you exit the Sabbath mode.

All buttons are disabled, and all sounds (except the HIGH TEMP alert* and the

combination to exit Sabbath Mode) are muted. Only the HIGH TEMP alert will

illuminate until you deactivate the Sabbath Mode.

ICE MAKER

IMPORTANT

To ensure proper function of your ice

maker, hook up the water supply imme-

diately or turn the ice maker o (see ICE

MAKER in CONTROLS AND SETTINGS).

CAUTION

• DO NOT place the ice bin in

the dishwasher.

• Wash the ice bin in warm water with

mild detergent. Rinse well and dry.

• Turn o the ice maker when cleaning

the freezer and during vacations.

Your appliance has an automatic ice

maker that will provide a sucient supply

of ice for normal use. The unit will not

produce ice during the ﬁrst 24 hours of

initial operation.

Turning Your Ice Maker On

After you have completed connecting the

plumbing, you must open the water sup-

ply valve. To turn the ice maker on, press

on the appliance control display. Then

press and hold ICE MAKER until the LEDs

above ICE MAKER are illuminated. New

plumbing connections may cause the ﬁrst

production of ice cubes to be discolored

or have an odd ﬂavor. Discard these ﬁrst

cubes until the cubes produced are free

of discoloration and taste.

Turning Your Ice Maker O

To turn the ice maker o, press on the

appliance control display. Then press and

hold ICE MAKER until the LEDs above

ICE MAKER are turned o. Separately, the

ice maker automatically stops producing

ice when the bin is full, and then restarts

when the level of ice drops. Note that

when the ice maker is turned O at the

appliance control, the ice maker will not

produce ice at all

Ice Maker Tips

• If the ice maker will be turned o for

a long period of time, turn the water

supply valve to the closed position.

• Ice cubes stored too long may de-

velop an odd ﬂavor. Empty the ice

bin. The ice maker will then produce

more ice.

• Occasionally shake the ice container

to keep ice separated.

• Keep the ice maker o until the ice

maker is connected to the water

supply or whenever the water supply

is turned o.

• The following sounds are normal

when the ice maker is operating:

• Motor running

• Ice loosening from tray

• Ice dropping into ice container

• Running water

• Water valve opening or closing

Ice Maker Storage Bin

Capacity

The ice maker should produce about 4.5

lbs of ice per 24 hours, depending on

conditions of use.

How much ice can be stored in the ice bins?

When completely full, the bins will hold

about 8 lbs of ice.

STORAGE FEATURES

Full Width Cantilever Shelves

Multi-position adjustable metal shelves

can be moved to any position for larger

or smaller packages. The shipping spacers

that stabilize the shelves for shipping may

be removed and discarded.

To Adjust The Shelves

• Remove all food from the shelf.

• Lift the front edge up to release the

tabs from the slots in the rear and

pull the shelf out.

• Replace the shelf by inserting the

mounting bracket hooks into the

desired support slots at the rear.

• Carefully lower the shelf and lock

into position.

Soft Freeze Zone

The soft freeze zone drawer remains

slightly warmer than the freezer interior

for convenient storage of soft freeze

items such as ice cream.

Slide-Out Shelf with Removable

Ice Storage Bins

The slide-out shelf provides easy access

to the removable ice storage bin. You

should return it back to its fully closed

position to allow the ice maker to

properly dispense ice cubes. If the slide-

out shelf is not in its fully closed position,

it will cause ice to be dispensed outside

the ice bin, possibly causing the need for

a service call.

The removeable storage bins hold ice

from the ice maker. The left-hand bin

is in the primary location for holding

dispensed ice. If you prefer more ice,

simply move the bin to the right, and put

the other bin in place on the left-hand

side for holding newly dispensed ice.

When not holding ice, the right-hand bin

can be used for additional storage. Or you

can remove the right-hand bin in order to

use the slide-out shelf for storage.

Lower Drawer with Dividers

The lower drawer with dividers works

great for food that may need to be

separated. The drawer can easily be used

with the dividers or without by removing

or adding the inserts.

IMPORTANT

When placing frozen items in the freez-

er, leave a gap of at least 2" at the top

of the freezer. Stacking items to the top

can cause ice buildup.

Adjustable Door Bins

The adjustable door bins are specially

designed to hold large containers or

storage bags. Each bin type can be used

only in the zone indicated below so the

door can close correctly. Your unit has 2

Half-Gallon Door Bins (Zone A), a Gallon

Door Bin (Zone B), and 2 Tall Item Door

Bins (Zone C).

To remove a door bin:

• Grasp the ends of the door bin.

• Lift the door bin up until it clears the

locking lugs.

• Pull the door bin straight out toward

you.

To install a door bin:

• Make sure the locking feature on the

bin aligns with the mounting lugs on

the door.

• Lower the door bin into the mounting

lugs until it locks in place.

STORAGE FEATURES

Door Bin Dividers

Customize your unit to ﬁt dierent sized

items as your needs change with door

bin dividers.

To remove, grasp the divider and pull

it upward until it disengages with the

door bin.

To install, slide the divider downward into

the corresponding door bin alignment

features until it is fully placed.

FILTER REPLACEMENT

Pure

Air™ AF-2 Air Filter

WIth more power to clear the air, Frigid-

aire air ﬁlters banish pungent smells and

work better than baking soda.

Pure

Air™

AF-2 Air Filters:

• More powerful than baking soda

Keep your unit fresh for up to 6 months.

• Captures & Keeps Odors Away

Absorbs undesirable smells with

carbon technology.

Here are the product numbers to request

when ordering:

Pure

Air™ AF-2 Air Filter

PAULTRA2

Installing or replacing the air ﬁlter

Your new

Pure

Air™ AF-2 air ﬁlter is

located in the air ﬁlter cover, located in

the top center of the cabinet.

Your appliance control display is

equipped with a REPLACE AIR FILTER

indicator to remind you to change your

ﬁlter every 6 months to ensure optimal

ﬁltering of appliance odors. To order your

replacement ﬁlters, please visit our online

store at Frigidaire.com, by calling toll-free

at 1 (800) 372-4432, or by visiting the

dealer where you purchased your unit.

The air ﬁlter element is held in by the

removable air ﬁlter cover which has a

stainless steel decorative plate.

1. Grab the cover with your hand,

pulling until it releases from the

ﬁxed air ﬁlter housing. The air ﬁlter

element is mounted on the back of

the cover.

2. Remove the old ﬁlter and discard it.

3. Unpackage the new ﬁlter and snap

it into the ﬁlter cover. The open face

(carbon media) of the ﬁlter should be

installed facing outward in the cover.

4. Reattach the air ﬁlter cover to the air

ﬁlter housing by aligning the cover

to the housing and ﬁrmly pushing it

until it snaps in place.

5. Press and hold REPLACE AIR

FILTER on the appliance control to

reset it.

f;ad mva;’ak f;ad mva;’ak f;ad mva;’ak f;ad mva;’ak f;ad mva;’ak f;ad mva;’ak f;ad mva;’ak f;ad mva;’ak

CARE AND CLEANING

Protecting your investment

Keeping your appliance clean maintains

appearance and prevents odor build-up.

Wipe up any spills immediately and clean

the appliance at least twice a year. When

cleaning, take the following precautions:

• Never use CHLORIDE or cleaners

with bleach to clean stainless steel.

• Do not wash any removable parts in

a dishwasher.

• Always unplug the electrical power cord

from the wall outlet before cleaning.

• Remove adhesive labels by hand. Do

not use razor blades or other sharp

instruments which can scratch the

appliance surface.

• Do not remove the serial plate.

Do not use abrasive cleaners such as win-

dow sprays, scouring cleansers, brushes,

ﬂammable ﬂuids, cleaning waxes, concen-

trated detergents, bleaches or cleansers

containing petroleum products on plastic

parts, interior doors, gaskets or cabinet

liners. Do not use paper towels, metallic

scouring pads, or other abrasive cleaning

materials or strong alkaline solutions.

CAUTION

Damp objects stick to cold metal

surfaces. Do not touch interior metal

surfaces with wet or damp hands.

CAUTION

When moving the unit, pull straight out. Do

not shift the appliance from side to side as

this may tear or gouge the ﬂoor covering.

Vacation and Moving Tips

Short Vacations: Leave the unit operating

during vacations of less than 3 weeks.

Long Vacations: If the appliance will not

be used for several months:

• Remove all food and unplug the

power cord.

• Clean and dry the interior thoroughly.

• Leave the door open slightly, blocking

it open if necessary, to prevent odor

and mold growth.

Moving: When moving the unit, follow

these guidelines to prevent damage:

• Disconnect the power cord plug from

the wall outlet.

• Remove foods, then defrost, and

clean the appliance.

• Secure all loose items such as base

panel, baskets, and shelves by

taping them securely in place to

prevent damage.

• In the moving vehicle, secure unit in

an upright position to prevent move-

ment. Also protect outside of the ap-

pliance with a blanket, or similar item.



NOTE

• To disconnect electrical power to the

lights or other electrical components,

unplug the unit or switch the breaker

that supplies power to the unit to the

o position.

• Do not use razor blades or other

sharp instruments which can scratch

the appliance surface when removing

adhesive labels. Any glue left from

tape or labels can be removed with

a mixture of warm water and mild

detergent, or, touch the glue residue

with the sticky side of tape you have

already removed. Do not remove the

serial plate.

CARE AND CLEANING

Care & Cleaning Tips

Part What To Use Tips and Precautions

Interior

& Door

Liners

• Soap and water

• Baking soda

and water

Use 2 tbsp of baking soda in 1 qt of warm

water. Be sure to wring excess water out

of sponge or cloth before cleaning around

controls, light bulb or any electrical part.

Door

Gaskets

• Soap and water Wipe gaskets with a clean soft cloth.

Drawers

& Bins

• Soap and water Use a soft cloth to clean drawer runners and

tracks. Do not wash any removable items (bins,

drawers, etc.) in dishwasher.

Exterior &

Handles

• Soap and water

• Non-Abrasive

Glass Cleaner

Do not use commercial household cleaners,

ammonia, or alcohol to clean handles. Use a

soft cloth to clean smooth handles. Do not use

a dry cloth to clean smooth doors.

Metal

Shelves

• Soap and water Clean with a soft cloth

Door &

Stainless

Steel Air

Tower

Cover

• Soap and water

• Stainless steel

cleaners

Clean with non-abrasive, soapy water and

a dishcloth. Rinse with clean water and a

soft cloth. Use a non-abrasive stainless steel

cleaner. These cleaners can be purchased at

most home improvement or major department

stores. Always follow manufacturer’s

instructions. Do not use household cleaners

containing ammonia or bleach.

NOTE: Always clean, wipe and dry with grain

to prevent scratching.

1-800-265-8352 (Canada)

Frigidaire.ca

1-800-374-4432 (United States)

Frigidaire.com

TROUBLESHOOTING

Let us help you troubleshoot your concern! This section will help you with common

issues. If you need us, visit our website, chat with an agent, or call us. We may be able

to help you avoid a service visit. If you do need service, we can get that started for you!

CONCERN CAUSE SOLUTION

APPLIANCE OPERATION

Appliance does

not run.

• Appliance is plugged

into a tripped Ground

Fault Interrupt (GFI).

• Appliance may not

be plugged in or plug

is loose.

• House fuse blown or

tripped circuit breaker.

• Power outage.

• Appliance must be plugged into a

dedicated circuit with standard outlet.

Contact a certiﬁed electrician to check.

• Ensure plug is tightly pushed into outlet.

• Check/replace fuse with a 15-amp

time-delay fuse. Reset circuit breaker.

• Check house lights. Call the local

electric company.

Appliance

temperature

is colder than

preferred.

• The freezer temperature

is set too low.

• Check freezer temperatures and adjust

the temperature control as needed.

Appliance

temperature is

warmer than

preferred.

• The freezer temperature

is set too high.

• The door is ajar.

• Set control to a colder setting until

appliance temperature is satisfacto-

ry. Allow 24 hours for the tempera-

ture to stabilize.

• Make sure the door is completely

closed and sealed.

Appliance is

noisy or vibrates.

• The cabinet is not level.

• Floor is weak.

• Adjust the leveling feet. See

“Leveling” in the INSTALLATION

section.

Appliance runs

too much or

too long.

• Room or outside

weather is hot.

• Appliance has recently

been disconnected for

a period of time.

• Large amounts of

warm or hot food have

been stored recently.

• Door is opened too

frequently or too long.

• Door may be

slightly open.

• Temperature control

is set too low.

• Gaskets are dirty,

worn, cracked, or

poorly ﬁtted.

• It’s normal for the appliance to work

longer under these conditions.

• It may take 24 hours for the

appliance to cool down completely.

• Warm food will cause appliance

to run more until the desired

temperature is reached.

• Warm air entering the appliance causes

it to run more. Open door less often.

• See DOOR PROBLEMS in

TROUBLESHOOTING section.

• Turn control knob to a warmer

setting. Allow several hours for the

temperature to stabilize.

• Clean or change gasket. (See Care

and Cleaning Tips in CARE AND

CLEANING section). Worn, cracked

or poorly ﬁtting gaskets should

be replaced.

CONCERN CAUSE SOLUTION

APPLIANCE TEMPERATURES

Interior appli-

ance tempera-

ture is too cold.

• Temperature control

is set too low.

• Set control to a warmer setting.

Allow several hours for temperature

to stabilize.

Temperature in-

side appliance

is too warm.

• Temperature control is

set too warm.

• Door is opened too

frequently or too long.

• Door may not be

seating properly.

• Large amount of

warm or hot food has

been stored recently.

• Unit has recently

been disconnected

for a period of time.

• Turn control to a colder setting.

Allow several hours for temperature

to stabilize.

• Warm air enters the appliance every

time the door is opened. Open door

less often.

• Look for food items on the shelves

or in the door bins keeping the door

from closing completely.

• Wait until the appliance has

had a chance to reach its selected

temperature.

• Appliance may take up to 24 hours

to cool down completely.

is displayed

on control.

• The control has

been locked.

• Press for 3 seconds to unlock.

“Sb” is displayed

on the control.

• The control is in

Sabbath Mode.

• Press — and TEMP F/C for 5 seconds.

AUTOMATIC ICE MAKER

Ice maker is not

making any ice.

• Ice maker is turned o. • Turn on the ice maker. Press and hold

the “On/O” button for 3 seconds

until the indicator light is on.

Ice maker is

not making

enough ice.

• Freezer control is set

too warm.

• Set freezer control to a colder set-

ting to improve performance of the

ice maker. Allow 24 hour for tem-

perature to stabilize.

Ice cubes

are freezing

together.

• Ice cubes are not being

used frequently enough.

• Ice cubes are hollow

(partially frozen cubes

with water inside).

• Freezer control is set

too warm.

• Remove ice container and discard

ice from the container. The ice maker

will produce fresh ice.

• Ice and water ﬁlter cartridge may be

clogged. Replace ﬁlter cartridge.

• Set the freezer control to a colder

setting. Allow 24 hours for tempera-

ture to stabilize.

SOUND AND NOISE

Louder sound

levels when-

ever appliance

is on.

• Modern freezers have

increased storage

capacity and more

stable temperatures.

They require heavy-

duty compressors.

• This is normal. When the surround-

ing noise level is low, you might hear

the compressor running while it

cools the interior.

Popping or

cracking sound

when compres-

sor comes on.

Bubbling or

gurgling sound.

• Metal parts under-

go expansion and

contraction, as in hot

water pipes.

• Refrigerant (used to

cool the freezer) is

circulating through-

out the system.

• This is normal. Sound will level o

or disappear as appliance continues

to run.

• This is normal.

TROUBLESHOOTING

CONCERN CAUSE SOLUTION

Vibrating or

rattling noise.

• Appliance is not level. It

rocks on the ﬂoor when

it is moved slightly.

• Floor is uneven or weak.

• Appliance is touching

the wall.

• Level the appliance. Refer to “Level-

ing” in the INSTALLATION section.

• Ensure ﬂoor can adequately support

the appliance. Level the appliance by

putting wood or metal shims under

part of the appliance.

• Re-level appliance or move appli-

ance slightly. Refer to “Leveling” in

the INSTALLATION section.

WATER / MOISTURE / FROST INSIDE APPLIANCE

Moisture forms

on inside ap-

pliance walls.

• Weather is hot and

humid, which increas-

es internal rate of

frost buildup.

• Door is slightly open.

• Door is kept open

too long.

• This is normal.

• Look for food items on the shelves

or in the door bins keeping the door

from closing completely.

• Open the door less often.

ODOR IN APPLIANCE

Odors in

appliance.

• Interior needs to

be cleaned.

• Foods with strong odors

are in the appliance.

• Clean interior with sponge, warm wa-

ter, and baking soda. Replace air ﬁlter.

• Cover the food tightly.

DOOR PROBLEMS

Door will

not close.

• Appliance is not level. It

rocks on the ﬂoor when

it is moved slightly.

• Floor is uneven or weak.

• This condition can force the cabinet

out of square and misalign the door.

Refer to “Leveling” in the INSTALLA-

TION section.

• Ensure ﬂoor can adequately support

appliance. Level the appliance by put-

ting wood or metal shims under part

of the appliance.

• Look for food items on the shelves

or in the door bins keeping the door

from closing completely.

LIGHTING PROBLEMS

Cabinet light is

not working.

• LED is burned out. • Call a Frigidaire service technician.

TROUBLESHOOTING

LIMITED WARRANTY

Your appliance is covered by a one year limited warranty. For one year from your original

date of purchase, Electrolux will pay all costs for repairing or replacing any parts of this

appliance that prove to be defective in materials or workmanship when such appliance is

installed, used and maintained in accordance with the provided instructions.

Exclusions

If You Need Service

This warranty does not cover the following:

1. Products with original serial numbers that have been removed, altered or cannot be

readily determined.

2. Product that has been transferred from its original owner to another party or

removed outside the USA or Canada.

3. Rust on the interior or exterior of the unit.

4. Products purchased “as-is” are not covered by this warranty.

5. Food loss due to any Appliance or freezer failures.

6. Products used in a commercial setting.

7. Service calls which do not involve malfunction or defects in materials or

workmanship, or for appliances not in ordinary household use or used other than in

accordance with the provided instructions.

8. Service calls to correct the installation of your appliance or to instruct you how to use

your appliance.

9. Expenses for making the appliance accessible for servicing, such as removal of trim,

cupboards, shelves, etc., which are not a part of the appliance when it is shipped

from the factory.

10. Service calls to repair or replace appliance light bulbs, air ﬁlters, water ﬁlters, other

consumables, or knobs, handles, or other cosmetic parts.

11. Surcharges including, but not limited to, any after hour, weekend, or holiday service

calls, tolls, ferry trip charges, or mileage expense for service calls to remote areas,

including the state of Alaska.

12. Damages to the ﬁnish of appliance or home incurred during installation, including but

not limited to ﬂoors, cabinets, walls, etc.

13. Damages caused by: services performed by unauthorized service companies; use of parts

other than genuine Electrolux parts or parts obtained from persons other than authorized

service companies; or external causes such as abuse, misuse, inadequate power supply,

accidents, ﬁres, or acts of God.

DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES

CUSTOMER’S SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY

SHALL BE PRODUCT REPAIR OR REPLACEMENT AS PROVIDED HEREIN. CLAIMS

BASED ON IMPLIED WARRANTIES, INCLUDING WARRANTIES OF MERCHANTABILITY

OR FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO ONE YEAR OR THE

SHORTEST PERIOD ALLOWED BY LAW, BUT NOT LESS THAN ONE YEAR. ELECTROLUX

SHALL NOT BE LIABLE FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES SUCH AS

PROPERTY DAMAGE AND INCIDENTAL EXPENSES RESULTING FROM ANY BREACH

OF THIS WRITTEN LIMITED WARRANTY OR ANY IMPLIED WARRANTY. SOME STATES

AND PROVINCES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL

OR CONSEQUENTIAL DAMAGES, OR LIMITATIONS ON THE DURATION OF IMPLIED

WARRANTIES, SO THESE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU. THIS

WRITTEN WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY ALSO HAVE

OTHER RIGHTS THAT VARY FROM STATE TO STATE.

This warranty only applies in the USA and Canada. In the USA, your appliance is warranted

by Electrolux Major Appliances North America, a division of Electrolux Home Products,

Inc. In Canada, your appliance is warranted by Electrolux Canada Corp. Electrolux

authorizes no person to change or add to any obligations under this warranty. Obligations

for service and parts under this warranty must be performed by Electrolux or an

authorized service company. Product features or speciﬁcations as described or illustrated

are subject to change without notice.

Keep your receipt, delivery slip, or some other appropriate payment record to establish

the warranty period should service be required. If service is performed, it is in your best

interest to obtain and keep all receipts. Service under this warranty must be obtained by

contacting Electrolux at the addresses or phone numbers below.

USA

1-800-374-4432

Frigidaire

10200 David Taylor Drive

Charlotte, NC 28262

Canada

1.800.265.8352

Electrolux Canada Corp.

5855 Terry Fox Way

Mississauga, Ontario, Canada

L5V 3E4

welcome

home

Frigidaire.com

1-800-374-4432

Frigidaire.ca

1-800-265-8352

owner support

accessories

service

Our home is your home. Visit us if you

need help with any of these things:

registration

(See your registration card

for more information.)

Frigidaire FPFU19F8RFE Professional 19 Cu. Ft. Single-Door Freezer

Product's Documents

Use & Care Manual

Specifications

Frigidaire FPFU19F8RFE Questions and Answers
