GRLP3 CONVERSION KiT APPLiCATiON iNSTRUCTiONS
INSTALLATION AND SERVICE MUST BE PERFORMED BY
A QUALIFIED INSTALLER.
IMPORTANT: SAVE FOR LOCAL ELECTRICAL INSPECTOR'S USE.
READ AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
I_ This conversion kit must be installed by a qualified service technician in accordance with the
manufacturer's instructions and all applicable codes and requirements of the authority having jurisdiction.
Failure to follow instructions may result in fire, explosion or production of carbon monoxide causing property
damage, personal injury or loss of life. The qualified service agency is responsible for the proper installation of
this kit. The installation is not proper and complete until the operation of the converted appliance is checked as
specified in the manufacturer's instructions supplied with this kit.
Before proceeding with the conversion, shut off the gas supply and disconnect the electrical
power to the range. Be sure both power supplies are off before installing the conversion kit. Failure to do so
could cause serious bodily injury.
IMPORTANT: Do not attempt to use this conVersion kit on products for which itis not specifically
designated: Consult the product installation manual or parts list to determine the correct conversion
kit number prior to use.
Tools Required for L.P. Conversion"
(A) 3/8", 1/2" and 5/8" Open End Wrench, (B) #1 Square Tip Screwdriver,
(C) 1/8" Wide Flat Blade Screwdriver, (D) 7rnm & 3/16" Nutdriver
A--_ B--_
C-_ D-__
How to Convert the Range for use with LP/Propane Gas
1. Convert the Pressure Regulator
To access the gas regulator, remove the storage drawer or warmer drawer. If equipped with a storage drawer, open and remove the drawer completely. For
models equipped with a front panel, remove the front panel and skip steps b & c below. For models equipped with warmer drawer, follow all the instructions
below to remove the warmer drawer. NOTE: DO NOT ATTEMPT TO CONVERT MODELS THAT FEATURE A LOWER OVEN.
a. _ Electrical Shock Hazard can occur and result in serious injury or death. Disconnect electrical power to the range
before removing the warmer drawer for servicing.
b. Locate glide lever on each side of drawer, pull up on the left glide lever and push down on the right glide lever (See Fig. 1).
c. Pull the drawer away from the range (See Fig. 2).
........ _ ,:;:,2_ ................... _,_:: _ .........
Pull up with finger
Left Glide
Pushdown with finger
[]
Fig. 1
p/n 316417518 rev F (1008)
Fig. 2
( Continued on following page )
