Assembly Instruction
WARNING:
>This unit has been designed to support the
maximum loads shown. Exceeding these
load limits could cause sagging, instability,
product collapse, and/or serious injury.
>DO NOT allow children to climb on unit.
>Put heavier items on lower shelves.
its Space. its Budget
Recommended Maximum Weight
Furinno Large Entertainment Center
MODEL :
15113
*Unit in Pound(lbs)
50
Tool RequiredTool Required
Recomm. 2 Person
Approx. 30 minutes
1511320180319
Customer Support
www.furinno.com
NEED HELP? For replacement requests or product inquiries,
please contact our Customer Service Team by emailing us at
[email protected]. Thank you for selecting Furinno!
Note: The arrow on each
MINI FIX CAM must point
toward the edge of the board.
USEFUL HINTS BEFORE YOU START:
1. Read each step carefully before starting.
2. It is important that each step is performed in correct order to avoid difficulties.
3. Identify, sort and count the parts before assembly.
4. Assemble your furniture on packaging cardboard to prevent scratch or damage.
5. Clean the product with mild cleanser using soft damped cloth. Do not use harsh or abrasive cleanser.
6. Using uncompatible hardware might cause damage to product.
1
2
6pcs
6pcs
A 1pc
No Hardware List Qty No QtyParts List
B
C
1pc
1pc
D
E
F
1pc
1pc
1pc
G
H
I
1pc
1pc
1pc
3 7pcs
4
5
6
8sets
8pcs
16pcs
7 2sets
8 4pcs
9
10
11
2pcs
4pcs
4pcs
12
20pcs
POWER PIN
C/B SCREW B
HANDLE
DOOR SPRING
MAGNET SET
C/B SCREW A
DOWEL
MINI FIX + HOUSING
PVC LEG WITH PLUG
SMALL ROUND LEG
SHORT ROUND POLE
SHELF SUPPORT
J
K
1pc
2pcs
TOP PANEL
CENTER PANEL
BOTTOM PANEL
LEFT SIDE PANEL
CENTER LEFT SIDE PANEL
CENTER RIGHT SIDE PANEL
RIGHT SIDE PANEL
SHELF PANEL
LEFT DOOR PANEL
RIGHT DOOR PANEL
BACK PANEL
