ELECTRONIC OVEN CONTROL
NOTE : The basic timer isexternally arranged in different configurations in various appliance models.
This does not change the way it operates.
PREHEAT
OR
CONV 11MER
VAN BAKEor COOK STOP
CLEAN BROIL TIME -tiME CLOCK CANCEL
_r
PREHEAT
OR
CONV
B_.E_OAST BAKE
VARI BAKE or COOK STOP
Figure 1 Figure 2
TIMER
6
CANCEL
Control Pad Functions
Read the instructions carefully before using the oven.
Preheat Pad
(or Conv. Bake/
Roast Pad)
\
Clean Pad
Bake Pad
/
Vari Broil Pad Bake Time Pad
Up and Down Arrow Pad
Stop Time Pad Clock Pad
The oven can be programmed to:
• Preheat and bake (some models)
• Bake normally
• Convection bake and roast (some models)
• Time bake/roast
• VariBroil
• Self-clean
Note: Pushbuttons or pads may be shaped differently.
Important: The electronic control isinoperable until the clock issetto the correct time of
day, after the appliance isfirst plugged in, or after a power interruption. The
electronic timer has a memory and when power disconnected it will show
display of the last time recorded.
For a silent control panel:
When choosing a function, a beep will be heard each time a pad ispushed. If desired, the
controlscan beprogrammed for silent operation. Pushand hold STOPTIME After 7seconds,
the control will beep once. Thiswill block the controls from sounding when a pad ispushed.
To return the sound, push and hold STOPTIME again for 7 seconds until 1 beep isheard.
Timer Pad
Cancel Pad
Versibn en espafiol
Si desea obtener una copia en
espahol de este Manual del
Usuario, s[rvase escribir a la
direcci6n que se incluye a
continuaci6n. Solicite la P/N
318204003.
Electrolux Home Products
Attn.: Care Use
P.O. Box212378
Augusta, GA 39017
Electronic Oven Control 318200181 (0202) Rev.D
1
