The appliance should be installed by qualified personnel only.
Each step must be carried out and checked in full in the order specified.
Validity
These installation instructions apply to:
63004 (DIPQG9, construction width 100 cm)
63005 (DIPQG12, construction width 120 cm)
H4.2608 (motor housing, extraction, standard)
H4.2604 (motor housing, recirculation, standard, island and wall hood)
H4.2605 (motor housing, recirculation, short, island and wall hood)
H4.2774 (motor housing, extraction with options connection)
General notes
If other firing systems are being used at the same time (e.g. wood, gas, oil or coal-fired heating appliances), safe operation is
only possible providing a room negative pressure of 4 Pa (0.04 mbar) is not exceeded at the location of the appliance.
Risk of toxic fumes! An adequate flow of fresh air must be guaranteed e.g. via non-closable openings in doors or windows
and in combination with an air-intake/exhaust-air wall box or by other technical means.
If the appliance is installed over hobs, each cooking zone must be fitted with an ignition fuse and the minimum distances
(see 'Dimensions') must be adhered to.
Efficient repairs can only be guaranteed if it is possible to uninstall the complete appliance at any time without causing any
damage.
Identification plate
Remove the grease filters. The identification plate is located on the inside of the appliance.
Supplied installation accessories
All fixing elements are contained in the scope of delivery.
Extraction mode
The extracted air must not be fed into a chimney which is used for exhausting fumes from appliances burning gas or other
fuels.
Observe the local fire regulations.
Installation instructions
J63004.113-0
Range hood DIPQG10/DIPQG12
02.09.14
Island hood
Operating mode: Extraction/recirculation
1
