en Burner
Cleaning instructions
zh 爐頭
清潔說明
M.-Nr. 10 742 130
en - Cleaning the burners
3
Do not clean any parts of the burners
in a dishwasher.
Remove all loose components of the
burners and clean only by hand using
a solution of warm water and a little
washing-up liquid applied with a soft
sponge.
Clean any soiling from the flame
openings with the brush supplied.
Danger of explosion!
Blocked flame openings can cause a
dangerous build-up of gas in the
base of the hob which could ignite
and cause an explosion. This can
lead to damage to the appliance and
injury.
Ensure the flame openings are kept
clean at all times.
Parts of the burner that cannot be
removed should be wiped clean with
a damp cloth only.
The ignitor and thermocouple should
be very carefully wiped clean using a
well wrung out cloth.
The ignitor must not get wet,
otherwise it will not spark.
Finally dry everything thoroughly with
a clean cloth. Make sure that the
flame openings are completely dry.
The surface of the burner cap will
become duller with time. This is
completely normal and does not
indicate material deterioration.
en - Assembling the burners
4
Place burner head on to burner
base so that the thermocouple
and the ignitor extend through
their respective holes in the burner
head.
The lobes on the burner cap must
fit into the recess on the burner
head. The lobes on the burner
head must fit into the recess on
the burner base.
Replace the burner ring.
Then place the burner caps and
in position.
The burners cannot function
correctly if they are incorrectly
assembled. This can lead to damage
to the appliance and injury.
Ensure that all parts of the burner are
reassembled in the correct order.
Ignite all burners to check that they
are burning correctly:
– The flame must not go out on the
lowest setting, or when the control is
turned quickly from the highest to the
lowest setting.
– On the highest setting, the flame
must have a distinctive and visible
core.
zh - 清潔爐頭
5
切勿將爐頭的任何部件放入洗碗碟機
內清洗。
拆下爐頭所有鬆動的組件，僅使用軟
海綿蘸溫水及少許清潔液清潔。
使用隨附的清潔刷清潔火孔
上的
任何污漬。
以防爆炸﹗
火孔阻塞會引致氣體在煮食爐底部積
聚，非常危險，可能被點燃並引起爆
炸。這可能會損壞爐頭和造成傷害。
確保火孔始終保持清潔。
不可拆下的部件則只可用濕布清潔。
點火裝置和熱電偶須用揩乾了水的濕
布輕輕拭抹。
點火裝置不得弄濕，否則無法點火。
最後用清潔的布抹乾所有部件。要確
保所有火孔要乾透。
爐頭蓋的表面，日久會變得暗啞，這是
正常現象，並非材料變質。
zh - 安裝爐頭
6
將爐頭
放在爐底
上，以使熱電
偶
和點火裝置
貫穿爐頭中各自
的小孔。
爐頭蓋上的凸角
必須對準爐頭上
的凹槽
。爐頭上的凸角
必須對
準爐底上的凹槽
。
更換爐頭圈
。
然後將爐頭蓋
和
放好。
如安裝錯誤，爐頭無法正常工作。這
可能會損壞爐頭和造成傷害。
確保按正確次序重新安裝爐頭各部
份。
點燃所有爐頭，檢查它們能否正常燃
燒：
– 必須保證在最低火力或將控制旋鈕從
最高火力快速轉到最低火力時爐火不
會熄滅。
– 在最高火力下的火焰須有清晰的中
心。
