Installation & Operation Instructions

This is the main product document for model 4042780.

The file format is pdf, 11 pages, you can download this manual here .

5
background
1
Santa-Fe-Products.com Santa Fe Air Purifier Installation & Operation Instructions
Serial Number
Install Date
Sold By
Installation & Operation Instructions
The Santa Fe Air Purier utilizes HEPA-grade
ltration and UV sterilization capability to clean
your air while also being quieter than a whisper.
SANTA FE | AIR PURIFIER
08/21 Rev A
Santa-Fe-Products.com | 800.533.7533
background
2
Santa Fe Air Purifier Installation & Operation Instructions Santa-Fe-Products.com
Thank you for purchasing the innovative KF-P32 air purier! Follow all safety precautions to ensure proper operation
of the device. These instructions describe the safety precautions to be observed during operation. They are designed
to prevent injuries or damage to this device.
• Ourairpurieroperateson120V,60Hz.
• Unplugtheunitbeforecleaningormaintenance.Cleaningtheunit,whileitispluggedinmay
resultinelectricshock,electricspark,andseriousinjury.
• ThisairpuriercontainsaUV-Cemitter.
• Unintendeduseoftheairpurierordamagetothehousingmayresultintheescapeof
dangerousUV-Cradiation.UV-Cradiationmay,evenwithminimumexposure,causeharm
totheeyesandskin.
• Donotoperateairpuriersthatareclearlydamaged.
• Thedeviceshouldbecleanedeverytwomonths.Althoughinhighusesituationstheunit
mayneedtobecleanedevery2-4weeks.Beforecleaning,unplugthedevice.Tocleanthe
device,openthebackcover,removethelter,andwipetheinteriorofthedevicewithawet
towel.
• IftheUVlightisdamaged,itmustbereplacedbythemanufacturer,aserviceagent,or
similarlyqualiedpersonstoavoidahazard.
• Theairpurierisnottobeusedbypersons(includingchildren)withreducedphysical,
sensory,ormentalcapabilities,orlackofexperienceandknowledge,unlesstheyhavebeen
giveninstructionoraresupervised.
• Thisairpuriercanbeusedbychildrenaged8yearsandaboveandpersonswithreduced
physical,sensory,ormentalcapabilitiesorlackofexperienceandknowledgeiftheyare
supervisedorreceivinginstructiononuseoftheairpurierfromanadult.Childrenshould
notplaywiththeairpurier.Cleaningandusermaintenanceshouldnotbecompletedby
childrenwithoutsupervision.
• Childrenshouldbesupervisedwhenproductisinused.Donotallowchildrentoplayonor
neartheairpurier.Keepchildren’shair,looseclothing,andbodypartsawayfrom/outof
theintakegrille,bents,holes,oropenings.
• Donothandletheunitwithwethands.Thoroughlydryyourhandsbeforehandlinganypart
oftheairpurier.
• Hair,looseclothing,andbodypartsawayfromopeningsandmovingparts.Hair,loose
clothing,andbodypartscangetcaughtintheairpurierresultingininjury.
SAFETY PRECAUTIONS
CAUTION!CAUTION!
REMOVE THE FILTER FROM THE PLASTIC BEFORE USING THE AIR PURIFIER.
WARNING!WARNING!
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY, READ AND UNDERSTAND
THIS GUIDE BEFORE OPERATING THIS AIR PURIFIER.
background
3
Santa-Fe-Products.com Santa Fe Air Purifier Installation & Operation Instructions
• Donotoperateunitifthecordorplugisdamaged.Doingsocanresultinelectricshock.
Discardthedamagedunitortakeittoanauthorizedservicefacilityforexaminationand/
orrepair.
• Ifthesupplycordisdamaged,itmustbereplacedbythemanufacturer,serviceagent,or
similarlyqualiedpersonstoavoiddamageorinjury.
• Donotrunthecordundercarpeting.Donotcoverthecordwiththrowrugs,runners,
orsimilarcoverings.DONOTROUTETHECORDUNDERFURNITUREORAIRPURIFIER.
Arrangethecordawayfromtrafcareaandwhereitwillnotbetrippedover.
• Onlyusetheairpurierasdescribedinthismanual.
• Donotunplugbypullingonthecord.Doingsomayresultinelectricalsparkorre.Unplug
theunitbygraspingandpullingtheplug.
• Donotusethisproductwithanextensioncord.
• Donotplacetheairpuriernearsourcesofheat.(e.g.:stovetops,ovens,radiators,or
computers)
• Unplugtheairpurierfromthepowersupplybeforeservicing.
• Thisequipmentshouldbeinspectedfrequently.Anydirtthathascollectedshouldbe
removedregularlytopreventexcessiveaccumulationthatmayresultinflashoverorre.
• Donotusetheairpurieroutdoorsoronwetsurfaces.
• Donotusetheairpurierinanenclosedspacewhereflammable,combustibleorexplosive
gasesarepresent.
• Donotuseinanareawheretoxicvapors,flammabledustoroxygentanksarepresent.
• Donotplaceopenflames,includingcandles,directlyinfrontoftheairpurier.
• Itisimportanttokeepallobjectsawayfromtheairintakegrill.
• Placetheairpurieronaflat,stablesurface.Neverplacetheunitonsoftsurfacessuchas
abedsorsofas.
• Positiontheairpuriersothatthedirtyairisnotdrawnacrossyourheadorbodywhile
sittingorsleeping.
• Placetheairpuriersotheplugonthepowercordeasilyreachesastandardelectrical
outlet.
• Thisproductissuitableforusewithsolid-statespeedcontrols.
SAFETY PRECAUTIONS
background
4
Santa Fe Air Purifier Installation & Operation Instructions Santa-Fe-Products.com
Product Diagram
SAFETY PRECAUTIONS
background
5
Santa-Fe-Products.com Santa Fe Air Purifier Installation & Operation Instructions
Instructions for usage
Button Icons:
Power
Speed Low Medium High
Timer
UV
Sleep
Filter Change
Power:Whenpluggedin,thedisplaywillturnonforonesecondandabeepwillbeheard.The
displaywillread“OFF”,andtheairpurierwillremaininstandbystate.
FEATURES AND OPERATION
background
6
Santa Fe Air Purifier Installation & Operation Instructions Santa-Fe-Products.com
Touchingthepowerbuttonwillturnontheairpurier.TheunitdefaultisAutoModeandwill
display“000”flashingand“ ”.Theairqualityindicatoronthescreenwillalternatebetween
green,yellow,orangeandred.Fifteensecondslater,itwillshowreal-timeairqualitydataand
lightupwiththecorrespondingcolortothetablebelow.Afterthat,airpurierwilladjustthe
speedaccordingtotheairqualityautomatically.
Speed:Pressingthe“Speed”buttonwillremovetheairpurierfromAutoMode.Thisbutton
allowstheusertocyclethroughfanspeeds:lowspeed,mediumspeedand
highspeed.
ThefanspeedcannotbechangedduringAutoorSleepmodes.
Timer:Touchingthetimerbuttonwillcausethedisplaytoflash“--H”and“TIMER”.Pressand
holdthebuttontosetthetimerfrom1-12hours.Afterchoosingthedesiredtime,waittwo
secondsforthedisplaytostopflashing.After3secondsthedisplaywillshowPM2.5data,
indicatingsettingisdone.Itcalculatesbycountingdowneveryhour.Whenthetimeisup,the
airpuriershutsdown.
Touchthebuttontillicon“--H”orlongpressthebuttonfor2secondstocanceltimersetting.
UV:Touchingthe“UV”buttonturnsontheUVsterilizationfunctionandlightsuptheUV
symbol.ToturnofftheUVfunctionpressthe“UV”buttonagain,theUVsymbolshouldgo
dark.
Sleep:Touchingthe“Sleep”buttonwillputtheairpurierintoSleepMode.SleepModeuses
thelowestpossiblefanspeedtocreateaquiteenvironment.
Thedisplayandallbuttonswillturnoffleavingonlythe“Sleep”buttonlitupatone-third
brightness.TouchingthesleepbuttonagainwillreturntheunitAutoMode.
FEATURES AND OPERATION
AutoModeChart
Color AirQuality PM2.5Data FanSpeed
Red Bad >151 High
Orange Moderate 150~101 Medium
Yellow Good 100~51 Low
Green VeryGood <51 Lower
background
7
Santa-Fe-Products.com Santa Fe Air Purifier Installation & Operation Instructions
FEATURES AND OPERATION
Display Turn Off Function:Pressandholdthe“Sleep”buttonfor2secondstoturnoffthe
displayandbuttons,onlythe“Power”buttonwillbelitatone-thirdbrightness.Touchingany
buttonwillilluminatethedisplay,atwhichpointthebuttonswillfunctionasusual.After15
secondswithoutanyoperation,thedisplaywillturnoffagain.Pressandholdthe“Sleep”
buttontoexitdisplayturnofffunction.
Filter Change
Whenairpurierreaches3,000workinghours,thelterchangeindicatoriconinthedisplay
willflashredtoreminduserchangelteruntilthelterischanged.Afterlterischanged,in
standbymode,pressthe“Speed”buttontwotimes,thenholdthisbuttonfor2seconds,lter
changeindicatoriconwillflashquickly.Fivesecondslaterthewholedisplayflashesfora
secondandthenturnofftoenterinstandbymodeindicatingthelterchangeiscomplete.
Now,touch“Power”buttontoswitchontheairpurier.
Note:3,000hoursiscalculatedbasedonlowspeed.Itwillremindlterchangelessthan
3,000hoursiftheairpurierworksinotherspeeds.
Protection
Theairpurierhasaprotectionfunction.Whentheltercoverisremovedornotinstalled
well,theairpurierwillautomaticcutoff.
Maintenance
Afterusingtheairpurierforanextendedperiod,dustonthesensorwillaffectitssensitivity.
Wesuggestcleaningtheuniteverytwomonths.Buttimecanbeshortenedorextended
accordingtoindoorenvironment.
background
8
Santa Fe Air Purifier Installation & Operation Instructions Santa-Fe-Products.com
FEATURES AND OPERATION
How to clean the dust sensor
Unplugthenopenthedustsensorcoverandcleanwithawetcottonswab.Thendrythelens
withanew,drycottonswab.
background
9
Santa-Fe-Products.com Santa Fe Air Purifier Installation & Operation Instructions
TROUBLESHOOTING
Ifyourairpurierisnotworkingcorrectly,pleasecheckthetablebelow.
Technical Specications
1. Inputvoltage:AC120V
2. Frequency:60Hz
3. Consumptionpower:40W
4. Applicablearea:46m²
5. Noiselevel:≤55dB
6. CADR:230CFM(390m³/H)
7. Operatingcondition:Temperature:10°~45°
8. Humidity:≤95%RH
Problem PossibleReasons Solution
NoPower Faultinpowersource Switchonwhenthepowersourcegetsregular
NotWorking
Plugimproperlyconnected
Faultinelectricalcircuit
Unplugtheunitandpluginagain
Tryusingtheunitatadifferentoutlet
UnusualNoise
Theremaybeaforeignobjectintheairpurier
Dirtylter
Thelterplasticbagwasnotremoved
Taketoservicecenter
Replacethelter
Removebagfromthelter
background
10
Santa Fe Air Purifier Installation & Operation Instructions Santa-Fe-Products.com
Santa-Fe-Products.com
WARRANTY
We guarantee the unit TO BE free from defects in material or workmanship for a period of one
(1) year from the date of purchase.
Shouldthisunitbeoperatedunderconditionsotherthanthoserecommendedoratvoltages
otherthanthevoltageindicatedontheunit,oranyattemptsmadetoserviceormodifythe
unit,thiswillrenderWARRANTYVOID.Theproductyoubuymaysometimesdifferslightly
fromillustration.
DISPOSAL:Donotdisposethisproductasunsortedmunicipalwaste.Collectionof
suchwasteseparatelyforspecialtreatmentisnecessary.
