www.dcsappliances.ca
www.dcsappliances.com p. 888-936-7872
Product dimensions and specifications are listed as a guide only. For complete installation instructions and specifications, refer to the product Use & Care Guide/Installation Instructions available at www.dcsappliances.com
INSULATED JACKET DIMENSIONS (INCHES)
36 Insulated
Jacket
BGA36-IJS
48 Insulated
Jacket
BGA48-IJS
A
Outside width 40-3/8” 51-1/2”
B
Outside depth 23-3/4” 23-3/4”
C
Outside heigh 11-1/8” 11-1/8”
36” AND 48” INSULATED JACKETS
www.dcsappliances.ca
www.dcsappliances.com p. 888-936-7872
Product dimensions and specifications are listed as a guide only. For complete installation instructions and specifications, refer to the product Use & Care Guide/Installation Instructions available at www.dcsappliances.com
INSULATED JACKET DIMENSIONS (INCHES)
30 Insulated
Jacket
BGB30-IJS
A
Outside width 34-5/28”
B
Outside depth 23-3/4”
C
Outside height 11-1/8”
D
Height of spacers (each side) 1/2”
30” INSULATED JACKET
