Install proper bulb type and
wattage(not included).
Warning: Risk of Shock
Start threading stem into “open
coupling” till stem just appears on
the inside of open coupling.
Be careful not to damage the
wires while installing.
Loosen “B”. Adjust stud to
desired length and lock in place with
“B”.
Mount the mounting bracket
to outlet box using outlet box screws
(not included). Make sure the studs
or nipple on the mounting bracket
are facing out from the outlet box.
Connect the ground wires
(bare copper or green) from your
fixture to the ground wires (bare
copper or green) or ground screw in
the electrical outlet box. Connect
black wire from fixture to black wire
in outlet box and connect the white
wire from fixture to white wire in
outlet box.
Outlet
Box
Outlet Box Screws
(not included)
Ground
Wire
Mounting
Bracket
INSTALLATION:
White
BlackHouse supply
Ground wire
Fixture
Ground wire
Fixture
Bulb
ISF511A03
ISF578A03
10/14
TOOLS AND MATERIALS REQUIRED:
SAFETY PRECAUTIONS:
Phillips
Screwdriver
Wire Cutters
Wiring supplies
as required by
electrical code
1. TURN OFF ELECTRICAL POWER BEFORE STARTING INSTALLATION OF LIGHT FIXTURE.
2. THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE APPLICABLE INSTALLATION CODE
BY A PERSON FAMILIAR WITH THE CONSTRUCTION AND OPERATION OF THE PRODUCT AND THE
HAZARDS INVOLVED.
3. CAUTION – RISK OF FIRE. CONSULT A QUALIFIED ELECTRICIAN TO ENSURE CORRECT BRANCH CIRCUIT
CONDUCTOR.
4. CONNECT THE GROUND WIRES (BARE COPPER OR GREEN) FROM YOUR FIXTURE TO THE GROUND
WIRE (BARE COPPER OR GREEN) OR GROUND SCREW IN THE ELECTRICAL OUTLET BOX.
Pliers Wrench
L
I
G
H
T
I
N
G
&
F
A
N
S
E
C
L
A
I
R
A
G
E
S
&
V
E
N
T
I
L
A
T
E
U
R
S
SEMI-FLUSH
MOUNT
!
INSTRUCTIONS PERTAINING TO RISK OF FIRE OR INJURY TO PERSONS
READ ALL INSTRUCTIONS
IMPORTANT SAFETY
INSTRUCTIONS
SAVE THESE INSTRUCTIONS
QUESTIONS OR CONCERNS CONTACT CANARM AT:
1-800-265-1833 (English) / 1-800-567-2513 (French)
Monday through Friday 8:00 AM to 5:00 PM E.S.T.
Imported By: CANARM LTD., 2157 Parkedale Ave., Brockville, Ontario, K6V 5V6, Tel: (613) 342-5424, Fax: (800) 263-4598
Studs
“B”
1. Carefully insert the decorative
stem into the screw stud and tighten
by a star washer, hex nut and the
finial.
Glass
Hex Nut
Finial
8. Attach the stem to the
fixture. Secure the glass in place
using the fibre washer, hex nut, and
finial.
Fibre
washer
2.
3.
4.
5. Secure the pan to the
nipple by tightening the hex
nut. Screw the finial to the
nipple.
6.
7.
Decorative
Stem
Finial
Hex Nut
Star
Washer
Nipple
Hex Nut
Finial
Pan
NOTE: Product May Not Look Exactly As Shown In Figures.
