Indesit EWDEP751451FR N Freestanding washer dryer: 7.0 kg

Quick Guide

For EWDEP751451FR N.

PDF File Manual, 4 pages, Read Online | Download pdf file

EWDEP751451FR N photo
GB
Quick Guide
THANK YOU FOR BUYING A INDESIT PRODUCT
In order to receive a more complete assistance,
please register your product on
www.indesit.com/register
Before using the appliance carefully read the Safety Instruction.
Before using the machine, it is imperative that the transport bolts are removed.
For more detailed instructions on how to remove them, see the Installation Guide.
CONTROL PANEL
WASH CYCLE TABLE
PRODUCT DESCRIPTION
1.
3.
2.
5.
4.
7.
6.
8.
1. Top
2. Detergent dispenser drawer
3. Control panel
4. Handle
5. Porthole door
6. Drain pump (behind the plinth)
7. Plinth (removable)
8. Adjustable feet (2)
DETERGENT DISPENSER DRAWER
Compartment 1: Do not pour detergent into
the compartment 1.
Detergent should only be poured into the
compartment 2.
Compartment 2: Washing detergent (powder
or liquid)
Liquid detergent should only be poured in
immediately prior to the start of the wash cycle.
Compartment 3: Additives (fabric softener,
etc.)
The fabric softener should not overow the grid.
! Use powder detergent for white cotton garments, for pre-washing, and
for washing at temperatures over 60°C.
! Follow the instructions given on the detergent packaging.
Maximum load 7 kg
Power input in o mode 0.5 W / in left-on mode 8 W
Detergents and
Additives
Recommended
detergent
Residual
dampness
% (*)
Energy
consumption
kWh
Total water lt
Laundry
temperature °C
Wash cycle
Temperature
Max.
spin speed
(rpm)
Max.
load for
washing
(kg)
Duration
(h : m)
Drying
Max.
load for
drying
(kg)
Wash
Fabric
softener
Powder
Liquid
Setting Range 2 3
1 White 60°C
– 90°C 1400
7.0 2:45
5.0
49 0.90 90
55
2 Mix Colours 40°C
– 40°C 1400
7.0 **
5.0
3 Synthetics (3) 40 °C
- 60 °C
1200 4.0 2:55
4.0
35 0.80 55 43
4 Cotton (2) 40 °C
- 60 °C
1400
7.0 3:55
5.0
49 1.40 105 45
5 Silk & Delicates 30 °C
- 30 °C
600 (***) 2.0 **
6 Wool 40 °C
- 40 °C
800 2.0 ** 2.0
7 Jeans 40°C – 40°C
1200 (***) 4.0 **
4.0
8
Sport Intensive
30°C – 30°C 600
4.0 **
9 Eco 40-60 (1) 40 °C 40°C
1351 7.0 3:28
5.0
53 1.05 50 38
1351 3.5 2:42
53 0.78 50 36
1351 2.0 2:10
53 0.60 35 35
10 20°C 20 °C
- 20 °C
1400
7.0 1:50
5.0
49 0.16 90 22
11 Cotton Dry 0 **
5.0
12 Synthetics Dry 0 **
4.0
13 Express Wash&Dry 30 °C 30 °C 1200 0.5 **
0.5
14 Rinse
1400
7.0 **
5.0
15 Spin
1400
7.0 **
5.0
16 Drain 0 7.0 **
Required dosage Optional dosage
1
2
3
For all testing institutes:
2) Long cotton cycle: set programme 4 at temperature 40°C.
3) Long synthetics cycle: set cycle 3 at a temperature of 40°C.
* After programme end and spinning with maximum selectable spin speed, in default
programme setting.
** The duration of the wash cycles can be checked on the display.
*** The display will show the suggested spin speed as default value.
The cycle duration indicated on the display or instruction manual is an estimate based on
standard conditions. The actual duration may vary in relation to several factors, such as the
temperature and pressure of the incoming water, ambient temperature, amount of detergent,
load quantity and type, load balancing and any additional options selected. The values given
for programmes other than the Eco 40-60 programme are indicative only.
1) Eco 40-60 (Wash) - Test wash cycle in compliance with EU Ecodesign regulation
2019/2014. The most ecient programme in terms of energy and water consumption for
washing normally soiled cotton laundry.
Note: spin speed values shown on the display can slightly diers from the values stated in
the table.
Eco 40-60 (Drying)-
Test drying cycle in compliance with EU Ecodesign regulation
2019/2014
. To access “wash and dry cycle select “Eco 40-60” wash programme and set
“Drying” option level to “A3
”.
The most ecient programme in terms of energy and water
consumption for washing and drying normally soiled cotton laundry. (Cycle duration: full load
9h:50’ / half load 5h:40’).
1
7 6
4
5
3
2
ДДДДДДД
DISPLAY
8
1. ON/OFF button
2. TEMPERATURE button
3. OPTIONS buttons and indicator lights
4. START/PAUSE button and indicator light
5. DRYING button
6. SPIN button
7. WASH CYCLE SELECTOR KNOB
8. Detergent dispenser drawer
