SC1455
EV Charger
OWNERS MANUAL
READ THE ENTIRE MANUAL BEFORE USING THIS PRODUCT.
FAILURE TO DO SO COULD RESULT IN SERIOUS INJURY.
1. IMPORTANT SAFETY INSTRUCTIONS – SAVE THESE INSTRUCTIONS
1.1 SAVE THESE INSTRUCTIONS – This manual contains important safety and operating instructions.
1.2 Keep out of reach of children.
1.3 Do not expose the charger to rain or snow.
1.4 Be sure the area around the vehicle is well ventilated while it is being charged.
WARNING: RISK OF ELECTRIC SHOCK.
1.5 The charger plug must be plugged into an outlet that is properly installed and grounded in accordance
with all local codes and ordinances. The plug pins must t the receptacle (outlet). Do not use with an
ungrounded system.
1.6 DANGER: Never alter the AC cord or plug provided – if it does not t the outlet, have a proper grounded
outlet installed by a qualied electrician. An improper connection can result in a risk of an electric shock
or electrocution.
1.7 Do not use with an extension cord.
1.8 Do not operate charger if it has received a sharp blow, been dropped, or otherwise damaged in any way;
take it to a qualied service person.
1.9 Do not disassemble charger; take it to a qualied service person when service or repair is required.
Incorrect reassembly may result in a risk of electric shock or re.
1.10 Use the charger only for charging compatible EV vehicles.
2. FEATURES
1. Charging status LEDs
2. Control panel
3. EV charger
4. Universal J1772 connector
5. 120V adapter cable
6. 28-foot cable
4
1
2
3
6 5
0099002242-00
