Stock No.
Attach wall bracket (single and double)* to corner
oor cabinet with bolt M8 x16mm, washer
18 x 8 x 1mm and spring washer 14 x 8.8 x 2.6mm,
and tighten with wrench (not included).
Attach corner unit back panel to wall bracket
(single & double)* with bolt M6 x 16mm, nut
M6 and spring washer 12 x 6.5 x 0.8mm, and
tighten with wrench (not included).
Attach mounting bracket to back panel of corner wall cabinet with bolt M6 x 12mm and tighten with
phillips screwdriver (not included).
*Use wall bracket (single x 2 ) + wall bracket (double x 2) for connecting with other unit back panel.
*Use wall bracket ( single x 4) if assemble corner unit alone.
To make assembly easier we recommend having two persons aid one another in assembly.
