IMPORTANT: READ AND SAVE THESE INSTRUCTIONS

FOR RESIDENTIAL & INDOOR USE ONLY

INSTALLATION GUIDE & USER’S MANUAL

ISLAND MOUNT RANGE HOOD

Model: Pro-X Series PX05-I36 / I42

IMPORTANT NOTICE: The Important Safety Instructions and warnings in this manual are not meant to cover all possible problems and/or situations that can occur upon installation of this unit. Use extreme caution when installing. maintaining or operating this or any other appliance. Contact the XtremeAir USA. LLC.

Customer Support Team at 1.714.554.9000 or email: [email protected] with any concerns or situations that you do not understand. The manufacturer disclaims all liability for any damage or injury caused as a result of not following instructions for installation contained in this manual.

To avoid the possibility of an explosion or fire. do not store or use combustible. flammable or explosive vapors and liquids (such as gasoline) inside or in the vicinity of this or any other appliance. Keep all combustible items (such as aerosol cans) away from cook top burners. ovens and range hoods. Do not store flammable or explosive materials in adjacent cabinets or surrounding areas.

Disclaimer: The manufacturer and/or distributor/reseller decline all responsibility in the event of failure to observe the instructions provided for installation. maintenance and suitable use of the product. The manufacturer and/or distributor/reseller shall NOT be responsible for any injury due to negligence and the warranty of the unit shall automatically be voided due to failure to observe proper safety and installation procedures. The manufacturer and/or distributor/reseller will not be held responsible for any damages to personal property or real estate or any bodily injuries whether caused directly or indirectly by the range hood.

WARNING - TO REDUCE THE RISK OF FIRE. ELECTRIC SHOCK. OR INJURY TO PERSONS. OBSERVE THE FOLLOWING:

+Use this unit only in the manner intended by the manufacturer. If you have questions. contact the manufacturer.

PRODUCT: Do not remove permanently affixed labels. warnings or plates from the product. This may void the warranty. Do not try to alter the hood.

INSTALLATION: The installation in this manual is intended for qualified installers. service technicians or persons with a similar qualified background. Installation and electrical wiring must be provided by qualified professionals and in accordance with all applicable codes and standards. including fire-related construction.

When cutting or drilling into the wall or ceiling; do not damage electrical wiring and other utilities. It is recommended that two or more people assist with the installation. The range hood may have very sharp edges; please wear protective gloves if it is necessary to remove any parts for installing. cleaning or servicing.

VENTING: For kitchen range or cook top ventilating use only. DO NOT use units to exhaust hazardous or explosive materials and vapors. Ducted fans MUST always be vented to the outdoors. DO NOT vent exhaust into spaces between walls. crawl spaces. ceiling. attics and/or garages. Use only metal ductwork. Old duct work should be cleaned or replaced if necessary to avoid the possibility grease fires. Check all joints on ductwork to insure proper connections. All joints should be properly taped.

ELECTRICAL: All electrical wiring must be properly installed. insulated and grounded. TURN POWER OFF and un-plug cords from outlet before servicing and/ or cleaning to insure your safety.

OPERATION: Caution is suggested when using high settings on cooking range. Keep all fan. baffle. spaces. filter. grease tunnel. oil container and grease laden surfaces clean. Grease should not be allowed to accumulate on fan. baffle. spaces. filter. grease tunnel. and oil container. Never allow the filters to become blocked or clogged. Do not allow foreign objects such as cigarettes and/or napkins. to be absorbed into the hood. Clean ventilating fans frequently.

Grease should not be allowed to accumulate on the fan or filters.

DANGER

IMPORTANT SAFETY INSTRUCTIONS. 2

HEIGHT & CLEARANCE .. 3

VENTING REQUIREMENT 3

VENTING METHODS. 3

ELECTRICAL REQUIREMENT .. 3

TOOLS YOU WILL NEED 3

PARTS SUPPLIED 4

GENERAL INSTALLTION DIAGRAM. 4

INSTALLATION 5-6

RANGE HOOD OPERATION. 6-7

SPECIFICATION .. 7

TROUBLE SHOOTING 7-8

USE & CARE INFORMATION .. 8

MAINTENANCE .. 8

PRODUCT WARRANTY. 9

TABLE OF CONTENTS

1. IMPORTANT SAFETY INSTRUCTIONS

IMPORTANT: Observe all governing building codes and city ordinances.

A 120 volt. 60 Hz. AC. 15-amp outlet is needed (fused electrical circuit is required) It is the customer’s responsibility: 1. To contact a qualified electrical installer. To assure that the electrical installation is adequate and in conformance with National Electrical Code. ANSI/ NFPA

70 — latest edition*. or CSA Standards C22. 1-94. Canadian Electrical Code. Part 1 and C22. 2 No. 0-M91 - latest edition and all local codes and ordinances.

2. HEIGHT & CLEARANCE 3. VENTING REQUIREMENTS

IMPORTANT:

NEVER exhaust air or terminate ductwork into crawl spaces. between walls. ceiling. attics or garages. All exhaust must be ducted to the outside.

Hood mounted too low could result in heat and/or fire hazard. Hoods mounted too high will be hard to reach and will lose its performance and efficiency.

Use metal ductwork only.

DO NOT use plastic ventilation.

DO NOT use 4” (10.2 cm) laundry-type wall caps.

Fasten all connections with sheet metal screws. Tape all joints with aluminum tape.

Use caulking to seal exterior wall or roof openings around the cap.

The ventilation system must have a damper. If the roof or wall cap has a damper. you may opt out from usage of your range hood supplied damper (for some models only).

For the most efficient & quiet operation:

A distance of 26” to 30” is recommended between stove top and the bottom of range hood.

It is recommended that the range hood be vented vertically through the roof with a minimum of a 6” or larger vent work.

ALWAYS. when possible. reduce the number or transitions and turns. If a long duct run is required. increase duct size from 6” to 7” or 8”. If a reducer is used. install a long reducer instead of a pancake reducer. Reducing duct size will restrict/decrease airflow.

The size of the vent should be uniform.

Use no more than three 90° elbows.

Make sure there is a minimum of 24” (61 cm) of straight vent between the elbows if more than one elbow is used.

4. VENTING METHODS

5. ELECTRICAL REQUIREMENTS

6. TOOLS YOU WILL NEED

Min 26” Max 30”

36” Base

(2) 2” x 4” x 24” stud (1) 24” x 36”/42” x ¾” plywood Note: about 6” wider than stove is ok Cabinet Jack

OPTIONAL

Pencil or Marker

Phillip Screwdriver Level

Aluminum Tape Wall/Keyhole Saw Tape Measure Powered Screwdriver

STEP #3: INSTALLING “SUPPORT BRACKET”

STEP #4: ATTACHING HOOD BODY

STEP #5: INSTALLING CHIMNEYS - DO NOT REMOVE CHIMNEY PROTECTIVE FILM UNTIL FINISHED INSTALLATION

STEP #2: INSTALLING “CEILING BRACKET”

A. Cut out a hole in the ceiling where the ducting

B. Prepare support framework for ceiling

C. Place chimney bracket against ceiling & screw

D. Drop the ducting and electrical work through

STEP #1: MARKING “CEILING BRACKET” A. Put a thick. protective covering over counter top. cook top or Range to protect from damage or debris.

B. Find and mark the center point directly above your cook top.

C. Place the ceiling bracket on the ceiling around the center point.

Make sure it is square with your cook top).

D. Trace the outline of the ceiling bracket onto the ceiling.

E. Trace a circle where the ducting will go.

F. Mark the 4 pre-holes where you will insert the screws.

9. INSTALLATION

D. Have a third person raise up the

Hood should be directly under the support brackets.

E. Attach the hood to the support brackets at all 4 corners with bolts.

F. Connect the ductwork to the range hood. Use aluminum tape to secure the pipe joint area.

G. Connect power plug.

CAREFULLY REMOVE CHIMNEY PROTECTIVE FILM.

Set the lower “HOOK” chimney piece into place so it drops into the top of the hood.

Carefully slide and drop lower “SLOT” chimney into place. Make sure SLOT and HOOK are snapped.

HINT: Due to the heavy weight of this range hood. use of a vertical jack to lift and support the hood in place is highly recommended.

Slide upper “slot” chimney (USC) into place connecting the 6 “C” locks – 3 on each side.

Slide the entire chimney up and secure with the ceiling bracket using the 2 provided bolts – 1 on each side.

Slide upper “hook” chimney (UHC) in. leave about 1” from the ceiling. Use tape to hold it up from falling down if you don’t have any helper to hold it.

IMPORTANT

Before moving to STEP5. do the following:

1. Make sure the damper is able to open

FULLY when the hood is on.

2. Test run to see if there is any air leaks

/ abnormal noise.

Attach lower chimney bracket (P3) vertically to the`inside of the 4 multi-hole brackets (P2) installed in the previous step. Make sure to adjust to its “TOTAL BRACKET LENGH”. Prefer to dimension table page 4.

Attach the multi-hole brackets (P2) to the outside 4 corners of the ceiling brackets (P1).

STEP #6: INSTALLING OIL TUNNEL & BAFFLE FILTERS

IMPORTANT: BEFORE YOU BEGIN

1. This unit is equipped with TOUCH SENSITIVE CONTROLS so please DO NOT PRESS. A light touch and hold on the required button for a matter of a (1) one

2. TOUCH THE ENTIRE BUTTON. See the following illustration:

Importance Notice:

1. 2 ½ HOUR AUTOMATIC SHUT OFF: this range hood will be shut off for every approx. 2 ½ hour. You can re-start

2. 30 HOUR REMINDER: after 30 hours of use. the timer (8) will be flashing. To clear it. please refer to “G-To Clear

Cleaning Reminder” on page 7.

TYPE 2: TOUCH BUTTON

1. (1) To power ON/OFF. and to activate power-off delay timer.

2. (2) To decrease blower (motor) speed. decrease timer value. and enter timer mode.

3. (7) To increase blower (motor) speed. increase timer value. and cumulative timer reset.

4. (3) Blower (motor) is running light indicator.

5. (4) Shows current blower (motor) speed (1-4).

6. (5) Lights up when lights turned on.

7. (6) To turns ON/OFF lights.

8. (8) Indicates the accumulated time the system is running.

9. (9) Indicates the length of time left for delay off function.

10. (10) Lights up when auto-shutdown delay timer function is on.

For best results. Start the range hood before cooking and allow it to operate several minutes after the cooking is completed to clear all smoke and odors from the kitchen.

Entire button covered and lightly touched.

CORRECT

Button is NOT completely covered.

INCORRECT

10. RANGE HOOD OPERATION

OIL TUNNEL: Drop oil tunnel into the inside hood body slot.

1. Angle (higher point) baffle filter

2. Lift the lower angle of the baffle

3. Slide (backward) forward into slot.

To remove the baffle. please reverse the process.

A. ACTIVATING BLOWER FUNCTION:

 Option 1: Touch and hold down (+) for 1-2 seconds.  Option 2: Touch and hold down power sign (1) for 1-2 seconds. (The blower will be running at the same speed as last used).

Note: The system saves user configurations. settings such as timer and blower (motor) speed will remain the same the next time it is turned on.

B. ADJUSTING BLOWER SPEED:

 Touch and hold down (+) for increase.  Touch and hold down (-) for decrease.

C. TURNING OFF THE BLOWER:

 Touch and hold down power sign (1) for 1-2 seconds.

D. TO TURN THE LIGHT ON/OFF:

 Touch Light button (6) once to turn on the lights. and once again to turn off the lights.

E. ADJUSTING THE TIMER FUNCTION:

 While the blower (motor) is not running. touch and hold Decrease Value button (2) over 3 seconds (until it’s flashing) to enter timer mode.  Adjust to desired period of delay off timer by touching Increase Value or Decrease Value button (minimum 1 minute to maximum 15 minutes).

This setting will be saved immediately.

F. ACTIVATING THE TIMER FUNCTION:

 While the blower (motor) is running. touch and hold “Power” button (1) for over 3 seconds to activate delay off timer. Power-Off Delay Timer Indicator

(10) will light up and Power-Off Delay Digital Timer (9) will begin to countdown. When it reaches zero. the blower (motor) will shut down.

G. TO CLEAR CLEANING REMINDER:

 When blower (motor) starts to rotate. cumulative running time will be shown in Power-On Elapsed Digital Timer (8). This timer icon flashes when 30 hours

 After cleaning the filters and when the motor is not in use. touch and hold (+) Increase Value button (7) over 3 seconds to reset the timer. Please note

Body Design Non-Magnetic 1.0 mm Stainless Steel. Satin Finish

Power Rating V/60Hz (USA & Canada standard)

General Input Power W (150W + 4x2W)

Motor Input Power 150 W each

Ampere 1.3 A

Levels Of Speed Control 4 Levels

Maximum Airflow CFM

Noise Level Approximately 1.5 – 6.0 sones or 33 – 54 dB

Number Of Motors Single Motor

Motor Type Single Chamber Ultra Quiet

Fan Type Squirrel Cage blower

Filtration Type Heavy Duty Stainless Steel Baffle Filter

Illumination 4 LED lights. 2W Maximum/each

Venting Size Top 6 inches Round

Interference Protection Radio Frequency Interference Protected

Note Specification subject to change without notice.

1. If the range hood or lights does not operate after installation:

Check if the range hood has been plugged in. Make sure that all power has been turned back ON. Check if the fuse is not blown and all electrical wiring is properly connected.

Swap out light assembly to working ones to deter mine whether it is caused by defective bulbs. See replacing the light bulbs on Page 13.

2. The range hood vibrates when the blower is on:

The range hood might not have been secured properly on to the ceiling or wall.

Check if the motor is secured in place. If not. then tighten the motor in place. Check if the blower wheel is damaged.

11. SPECIFICATION

12. TROUBLESHOOTING

3. The blower or fan seems weak:

 Check that the duct sized used is at least 6”. Range hood WILL NOT function efficiently with insufficient duct size & loosely secured.  Check if duct is clogged or if damper unit (half-circular flapper) is not installed correctly or opening properly. A tight mesh on a side wall cap unit might also cause

4. The lights work but the blower is not spinning at all. is stuck or is rattling.

 The blower might be jammed or scraping the bottom due to shipping damage. Please contact us immediately.  The motor is defective. possibly seized - change the motor.

5. The hood is not venting out properly:

 Make sure the distance between the stove top and the bottom of the hood is within 26” and 30” in distance. Due to different ceiling height configurations.

 Reduce the number of elbows and length of ductwork. Check if all joints are properly connected. sealed. and taped.  Make sure the power is on high speed for heavy cooking.

6. The hood is noisier than normal

 The duct is not secure and causes vibration.  The smaller duct size than required is being used.

7. Control panel is not active

 Check to make sure the auto function is not on.

Operations:

Read and understand all instructions and warnings in this manual before operating the appliance. Save these instructions for future reference.

Always leave safety grills and filters in place. Without these components. operating blowers could catch on to hair. fingers and loose clothing.

NEVER dispose cigarette ashes. ignitable substances. or any foreign objects into blowers.

NEVER leave cooking unattended. When frying. oil in the pan can easily overheat and catch fire. The risk of self combustion is higher when the oil has been used several times.

NEVER cook on “open” flames under the range hood. Check deep-fryers during use: Superheated oil may be flammable.

Cleaning:

The saturation of greasy residue in the blower and filters may cause increased inflammability. Keep unit clean and free of grease and residue build up at all times to prevent possible fires.

FILTERS MUST BE CLEANED PERIODICALLY AND FREE FROM ACCUMULATION OF COOKING RESIDUE.

DO NOT operate blowers when filters are removed. Never disassemble parts to clean without proper instructions. Disassembly is recommended to be performed by qualified personnel only. Read and understand all instructions and warnings in this manual before proceeding.

SAFETY WARNING: Never put your hand into area housing the fan while the fan is operating! For optimal operation. clean range hood and all baffle/spacer /filter/grease tunnel/oil container regularly. Regular care will help preserve the appearance of the range hood.

Cleaning Exterior surfaces:

Clean periodically with stainless steel cleaner or hot soapy water and clean cotton cloth. Do not use corrosive or abrasive detergent (e.g. Comet Power Scrub. EZ-Off oven cleaner). or steel wool/scoring pads. which will scratch and damage the stainless steel surface. For heavier soil use liquid degrease such as “Formula 409®” or “Fantastic” brand cleaner.

If hood looks splotchy (stainless steel hood). use a stainless steel cleaner to clean the surface of the hood. Avoid getting cleaning solution on or into the control panel. Follow directions of the stainless steel cleaner. CAUTION: Do not leave on too long as this may cause damage to hood finish. Use soft towel to wipe off the cleaning solution. gently rub off any stubborn spots. Use dry soft towel to dry the hood.

After cleaning. you may use non abrasive stainless steel polish such as 3M ® or ZEP. to polish and buff out the stainless luster and grain. Always scrub lightly. with clean cotton cloth. and with the grain.

DO NOT allow deposits to accumulate or remain on the hood.

DO NOT use ordinary steel wool or steel brushes. Small bits of steel may adhere to the surface and cause rusting.

DO NOT allow salt solutions. disinfectants. bleaches. or cleaning compounds to remain in contact with stainless steel for extended periods. Many of these compounds contain chemicals. which may be harmful. Rinse with water after exposure and wipe dry with a clean cloth.

Cleaning Grease Filter / Stainless Steel Filter less Grill: IMPORTANT: Drain oil from oil containers before oil and residue overflow!

The metal filters fitted by the factory are intended to filter out residue and grease from cooking. It needs not be replaced on a regular basis but are required to be kept clean.

Filters should be cleaned after every 30 hours of use. Remove and clean by hand or dishwasher. Use proper degreasing detergent for stainless steel and leave to soak if heavily soiled. Dry filters and re-install before using hood.

13. USE & CARE INFORMATION

14. MAINTENANCE
