- 1 -
05/2021
Copyright © 2021, Fast ČR, a.s.
EN Microwave oven
Translation of the original manual
SMW 5517WH
- 2 -
05/2021
Copyright © 2021, Fast ČR, a.s.
EN
Microwave oven
Important safety instructions
READ CAREFULLY AND STORE FOR FUTURE USE.
■
This appliance may be used by children 8 years of age and
older and by persons with physical or mental impairments or by
inexperienced persons, if they are properly supervised or have
been informed about how to use the product in asafe manner
and understand the potential dangers.
■ Children must not play with the appliance.
■ Cleaning and maintenance performed by the user must not be
performed by unsupervised children.
■ In the event that the power cord is damaged, have it repaired
at aprofessional service centre to prevent causing adangerous
situation. It is forbidden to use the appliance if it has adamaged
power cord.
■ Cleaning and maintenance performed by the user must not be
performed by children unless they are older that 8 years of age
and under supervision.
■ Children younger than 8 years of age must be kept away from
the appliance and its power cord.
■
This appliance is not designed to be controlled using
aprogrammed device, external timer switch or remote control.
■
The parts of the appliance that come into contact with food
must always be cleaned according to the instructions in this
user'smanual.
WARNING: If the door or the door gasket seal is damaged
then the oven must not be used until repaired by
aqualified person.
- 3 -
05/2021
Copyright © 2021, Fast ČR, a.s.
WARNING: It is dangerous for any untrained person to
carry out any repairs or maintenance whatsoever that
leads to the removal of any cover providing protection
against microwave energy radiation.
WARNING: Liquids and other foods must not be heated
in closed containers because they could explode.
■
This appliance is designed for domestic use and similar locations
such as:
–kitchens in stores; offices and other work environments;
–in agriculture;
–
guests of hotels, motels and other accommodation
environments;
–in bed and breakfast establishments.
■ To ensure sufficient air circulation there must be free space left
around the microwave oven. Allow free space of at least 20cm
above the top surface of the oven and 10cm from behind and
on the sides. Do not block any vents of the oven. Do not remove
the feet of the oven.
■
Use only containers that are suitable for use in microwave ovens.
■
Do not use metal containers for cooking or heating foods or
liquids unless the manufacturer specifies the size and shape of
metal containers suitable for microwave cooking.
■
When heating ameal on plastic or paper dishes, frequently check
the oven to prevent them from catching on fire.
■
The microwave oven is designed for heating food and beverages.
Dehydrating food or drying clothes and heating up heating
cushions, home footwear, washing sponges, damp textiles and
similar items may lead to an injury hazard, ignition or fire.
■
If smoke is being created, turn off the appliance or pull the plug
out of the power socket and leave the door closed to prevent
- 4 -
05/2021
Copyright © 2021, Fast ČR, a.s.
any potential fire from spreading.
■ Microwave heating of drinks may cause adelayed boil, which
must be considered when holding the container. Be careful when
handling the container.
■
The contents of baby bottles and baby food must be stirred
through or shaken up and their temperature must be checked
prior to consumption to prevent burns.
■
Eggs in their shells and whole hard boiled eggs must not be
heated in the microwave oven because they could explode even
after the microwave heating process has finished.
■
Regularly clean the door and the window of the oven from both
sides, the door gasket seal and neighbouring parts and any food
remains. For cleaning, we recommend the use of aweak kitchen
detergent. Ensure that remains of the cleaning agent do not
remain on the inner surface of the door.
■
Clean the oven regularly according to the above mentioned
instructions and remove any food that remains inside it.
■
Failure to keep the oven clean could lead to surface damage,
which could adversely affect the lifetime of the appliance and
could lead to adangerous situation.
■ The appliance must not be cleaned using asteam cleaner.
■ The microwave oven is intended to be placed on acountertop
at amaximum height of 900mm.
■
This microwave oven is intended for use as afree-standing
appliance. It is not designed to be built-in or installed into
acabinet.
■ The microwave oven must not be placed into acabinet.
Before connecting the appliance to apower socket, check that the voltage on its rating label matches the electrical voltage in the power socket.
Connect the appliance only to aproperly grounded socket.
Do not use the microwave oven outdoors or subject it to the effects of the outdoor environment.
Do not place the microwave oven on window sills, kitchen sink drainboards or unstable surfaces. Always place it on astable, even and dry surface.
This microwave oven is intended for heating and cooking food. Use it only for the purposes described in this user'smanual. Do not use corrosive chemicals or fumes in it.
Never use the microwave oven in the direct vicinity of abath, shower or swimming pool.
Do not use the microwave for industrial or laboratory purposes.
Kitchen dishes may become hot as aresult of the heat transferred from the heated food. Sometimes it may be necessary to use protective gloves.
Do not use the kitchen cookware, tableware and utensils listed below in the microwave oven:
- Metal pans and crockery with metal handles or with metal decorations;
- Clamps on plastic bags;
- dishes with melamine surface treatment;
- 5 -
05/2021
Copyright © 2021, Fast ČR, a.s.
- Standard thermometers, which are used for measuring the temperature of meat, etc.
Do not attempt to use the microwave oven with the door open. You could expose yourself to the harmful effect of microwaves. Do not run the microwave oven when it is empty.
Be especially careful when handling heated beverages and foodstuffs as hot steam may be released from them.
Warning: Due to high heat that is generated when using the combination cooking mode, children may only use the microwave oven under adult supervision.
Do not fry food in the microwave oven. Hot oil may damage parts of the oven, dishes or may also cause skin burns.
Before cooking, prick food that has athick peel, such as potatoes, pumpkins, apples.
Prior to moving the oven, always ensure that the turning tray is removed or properly secured in the internal area of the oven. This may damage it.
Do not use the oven without the turning tray being correctly installed.
Some components of the microwave oven may heat up during operation. Do not touch hot surfaces. There is adanger of aburns.
When not using the oven, do not leave paper materials, kitchen dishes or food inside.
Keep the inside of the oven clean. If the walls of the oven are splattered with food juices then wipe them away using adamp cloth. If the oven is heavily soiled, you can use aweak
solution of aneutral kitchen detergent.
Do not use the microwave oven if the power cord or power plug is damaged, if it is not working correctly, if it is damaged or if it has been dropped on the floor. Any repair of the
microwave oven or replacement of adamaged power cord may only be carried out by an authorised service centre, as this will prevent adangerous situation from occurring.
Internal LED source of this appliance is ≤ 60 lm.
- 6 -
05/2021
Copyright © 2021, Fast ČR, a.s.
SMW 5517WH
5
72
1
Micro PowerE xpress
Weight
Time
+
Defrost/Clock
Pause/Cancel
Auto Cooking
Instant/Start
6
4 3
A
8
- 7 -
05/2021
Copyright © 2021, Fast ČR, a.s.
Micro Power
Grill/Combi
Time
Weight
Defrost/Clock
Auto Cooking
Pause/Cancel
Instant/Start
1
2
3
4
5
7
8
6
B
- 8 -
05/2021
Copyright © 2021, Fast ČR, a.s.
EN
Microwave oven
User'smanual
■ Prior to using this appliance, please read the user'smanual thoroughly, even in cases,
when one has already familiarised themselves with previous use of similar types of
appliances. Only use the appliance in the manner described in this user’smanual.
Keep this user'smanual in asafe place where it can be easily retrieved for future use.
■ We recommend saving the original cardboard box, packaging material, purchase
receipt and responsibility statement of the vendor or warranty card for at least the
duration of the legal liability for unsatisfactory performance or quality. In the event
of transportation, we recommend that you pack the appliance in the original box
from the manufacturer.
DESCRIPTION OF THE APPLIANCE
A1 Safety door closing mechanism
A2 Door viewing window
A3 Central swivel connector
A4 Turning tray carrier
A5 Glass turning tray
A6 Control panel with display
A7 Magnetron cover
A8 Metal rack
DESCRIPTION OF THE DISPLAY
B1 Display
B2 Button Micro Power – serves to set
the microwave power level.
B3 Control knob – serves to set the
cooking/heating time or the weight
of the food.
B4 Button Defrost/Clock – serves to
select the defrost program / set the
clock
B5 Button Pause/Cancel – serves
to pause the operation of the
microwave oven / to delete settings
or to cancel operation
B6 Button Grill/Combi – serves
to select the grill program /
combination cooking program
B7 Button Auto Cooking – serves
to select the automatic cooking
program
B8 Button Instant/Start – serves to
select the quick heating/cooking
program / to start the microwave
oven
BEFORE FIRST USE
Before first use, take the appliance and its accessories out of the packaging material
and remove all promotional labels and stickers. Check that neither the appliance nor
any of its parts is damaged.
INSTALLATION
1. Make sure that you have taken all packaging materials, such as plastic bags,
polystyrene, etc. out from inside the oven.
Note:
Do not remove the cover of the magnetron A7, which is located on the right
side of the inside area of the oven.
Warning:
Check whether the oven is damaged in any way, e.g. whether
the oven door is incorrectly attached or dinted, whether the
door gasket seal is damaged or whether the hinges or locks
are loose. If you discover any damage, do not use the oven and
contact aqualified service technician.
2. The microwave oven must be placed on an even, stable surface, that can bear its
weight even with the food inside.
3. Do not locate the oven near sources of heat, in locations with increased humidity or
near flammable materials.
4. This appliance is designed to be used in open space, it is not designed to be built-in.
Therefore, ensure sufficient free space around the oven. Leave at least 20 cm of free
space above the top of the oven and at least 5cm around its sides. The rear side of
the oven may be positioned against awall. Do not cover or block the vents. Do not
remove the feet of the microwave oven.
5. Do not use the oven without the turning tray A5 installed.
6. Make sure that the power cord is not underneath the oven or in contact with hot or
sharp surfaces.
7. The power socket must be easily accessible to enable the power plug to be quickly
disconnected if necessary.
8. Do not use the microwave oven outdoors
Note:
When the microwave oven is turned on for the first time, you may register
aslight odour and smoke. This is anormal event that will disappear with
use. When using it for the first time, we recommend that you place abowl of
water on the turning tray A5, set the oven to the maximum power level and
run the oven for several minutes. The odour is easily eliminated in this way.
GROUNDING INSTRUCTIONS
This microwave oven must be grounded. The microwave oven is equipped with
apower cord, which has agrounding wire with agrounded power plug. The power
plug must be connected to apower socket, which is properly installed and grounded.
Grounding reduces the risk of electrical shock. In the case of ashort circuit, the electric
current is conducted though the grounding wire. We recommend that the oven be
connected to an independent electrical circuit.
Warning:
An incorrectly grounded power socket may present adanger of
electrical shock.
Note:
If you have any questions regarding grounding or electrical instructions,
consult all such matters with aqualified electrician or repair person.
Neither the manufacturer nor the vendor take any responsibility for
whatever damage to the oven or injury resulting from an incorrect electrical
connection.
RADIO WAVE INTERFERENCE
The operation of the oven may cause interference to a radio, television or similar
devices. If you register any interference, perform the following steps to limit or entirely
eliminate the interference:
1. Clean the door and the door gasket seals.
2. Move the radio or television antenna to adifferent location.
3. Point the microwave oven away from the receiver.
4. Move the microwave oven farther away from the receiver.
5. Connect the power plug of the microwave oven into adifferent power socket so that
the oven and the receiver have their own separate electrical circuits.
USING THE MICROWAVE OVEN
Prior to use, check that the turning tray carrier A4 and turning tray A5 are correctly
installed.
Note:
The turning tray A5 must turn freely when the microwave oven is in
operation.
After connecting the power plug into the power socket, abeep is made, the display
flashes three 3 times and then the display B1 flashes "1:00" for you to set the cooking/
heating program and the cooking/heating time.
Set the clock. Proceed according to the instructions in section "Setting the clock"
below in this user'smanual. Nevertheless, it is also possible to control the microwave
oven without the clock being set, however, in order to use certain programs in real
time, it is necessary to set the actual time.
In the event that you need to set the cooking/heating status while the microwave oven
is running, short press button Pause/Cancel B5 once. The operation of the microwave
oven will be paused. To continue cooking/heating, short press button Instant/Start
B8, to cancel the cooking/heating process, press button Pause/Cancel B5 again.
In the event that you perform an incorrect step while setting the microwave oven,
press button Pause/Cancel B5 to cancel the setting.
When the cooking/heating process is finished, the display B1 will show "End" and the
appliance will beep, which will be repeated every 3minutes until button Pause/Cancel
B5 is pressed or the door is opened.
Setting the clock
The clock may be set after inserting the power plug into apower socket, or also during
use.
1. While the microwave oven is in the stand-by mode, press and hold down the button
Defrost/Clock B4 for approx. 3seconds. The numerical hour value will start flashing
on the display B1.
2. Turn the control knob B3 and set the hours.
3. Short press button Defrost/Clock B4. The numerical minutes value will start
flashing on the display B1.
4. Turn the control knob B3 and set the minutes.
5. Short press button Defrost/Clock B4 or wait approx. 60 seconds and the set time
will be shown on the display.
Quick heating / cooking
The quick cooking/heating function is intended for rapidly heating food at the
maximum power level of the microwave oven.
While the microwave oven is in the stand-by mode, press button Instant/Start B8
and the microwave oven will start running at the maximum power level for atime of
1minute. Turn the control knob B3 to set the required cooking/heating time.
Microwave cooking
The microwave cooking function is suitable for cooking and heating food.
1. While the oven is in the stand-by mode, repeatedly press button Micro Power B2 to
select the microwave power level in the following order: 100P – 80P – 60P – 40P –
20P. The set power level will appear on the display B1.
2. Turn the control knob B3 to set the cooking/heating time. You can set up to
60minutes.
3. Press button Instant/Start B8 and the oven will start. The set cooking/heating time
will start counting down on the display B1.
4. If you need to check the cooking/heating process, short press button Pause/Cancel
B5. To resume the operation of the microwave oven, press button Instant/Start B8.
Microwave oven power level table
High power
level
100P 100% microwave power level, suitable for fast heating
Medium-high
power level
80P 80% microwave power level, suitable for medium fast
heating
- 9 -
05/2021
Copyright © 2021, Fast ČR, a.s.
Medium
power level
60P 60% microwave power level, suitable for cooking food
Medium-low
power level
40P 40% microwave power level, suitable for defrosting food
Low power
level
20P 20% microwave power level, suitable for keeping food
warm
Note:
In the event that the maximum microwave power level is selected, the
oven will automatically reduce the power level for acertain time to prevent
excessive overheating and potential damage.
Grill/combination cooking
This program is suitable for grilling meat, steaks, schnitzels, kebabs, sausages or pieces
of chicken meat. Likewise, it can be used for toasting sandwiches and other types of
food.
1. While the microwave oven is in the stand-by mode, repeatedly press button Grill/
Combi B6 to select the grill program or combination cooking program: G (grill) – G1
(combination cooking 1) – G2 (combination cooking 2). The set program will appear
on the display B1.
2. Turn the control knob B3 to set the cooking/heating time.
3. Press button Instant/Start B8 and the oven will start. The set cooking/heating time
will start counting down on the display B1.
Note:
When the grill function is used for the first time, you may register asmall
amount of smoke and a slight odour. This is a normal event that will
disappear with use. When the grill element is used for the first time, its
protective layer is burned off.
Overview table for grilling/combination cooking
G Grilling program, the top heating element will be turned on during
operation. It is suitable for grilling meat, steaks, schnitzels, kebabs,
sausages or pieces of chicken meat.
G1 Combination cooking of grill and microwave cooking: 30% of the time is
microwave cooking + 70% of the time is grilling.
G2 Combination cooking of grill and microwave cooking: 55% of the time is
microwave cooking + 45% of the time is grilling.
Warning:
During the grilling process, all parts of the oven are heated up,
including the rack A8 or the cookware. Such parts are very hot.
Pay increased attention when removing food from the oven.
Use protective kitchen gloves to prevent burns from occurring.
Defrosting
This function is suitable for defrosting food.
1. While the microwave oven is in the stand-by mode, repeatedly press button
Defrost/Clock B4 to select the food defrosting program: d.1 – d.2 – d.3. The set
defrosting program will appear on the display B1.
2. Turn the control knob B3 to set the weight of the food being defrosted.
3. Press button Instant/Start B8 and the oven will start. The preset defrosting time will
start counting down on the display B1.
Note:
During the defrosting process, the microwave oven will automatically pause
operation to enable you to check the food and to rotate it. Then press button
Instant/Start B8 to resume operation of the microwave oven.
Table of defrosting programs
d.1 Program for defrosting meat, set the weight between 0.1 and 2.0 kg.
d.2 Program for defrosting poultry, set the weight between 0.2 and 3.0 kg.
d.3 Program for defrosting seafood, set the weight between 0.1 and 0.9 kg.
Automatic cooking
In the automatic cooking programs, it is not necessary to set the cooking time or
power level. Simply select the type of food that is being prepared, its weight or number
of cups.
1. While the microwave oven is in the stand-by mode, repeatedly press button Auto
Cooking B7 to select the automatic cooking program: A.1, A.2, … A.8. The set
automatic cooking program will appear on the display B1.
2. Turn the control knob B3 to set the weight of the food being cooked/heated.
3. Press button Instant/Start B8 and the oven will start. The preset cooking/heating
time will start counting down on the display B1.
Automatic cooking program table
Program Food Cooking method
A.1 Popcorn Serves to make popcorn in ready-packets that are
available in stores, weight: 0.1 kg
A.2 Heating Serves to heat food, weight: 0.2 – 1.0 kg
A.3 Drink/
beverage
Serves to heat drinks/beverages (1–3 cups)
The temperature of the liquid is approx. 5 – 10°C. Use
larger cups and do not cover.
A.4 Pizza Serves to heat up refrigerated pizza, 1–2 slices
A.5 Potatoes Serves to cook potatoes cut into approx. 5 mm slices.
Total weight: 0.45 – 0.65 kg
Lay the potato slices out on alarge plate and cover with
thin plastic wrap to prevent excessive water loss.
A.6 Vegetables Serves to heat/cook various types of vegetables based
on weight from 0.1 to 0.5 kg.
A.7 Meat Serves to heat/cook various types of meat based on
weight from 0.1 to 0.5 kg.
A.8 Fish Serves to heat/cook various types of fish based on
weight from 0.1 to 0.5 kg.
Note:
Cook/heat food that is at room temperature (approx. 20–25°C). Food that is
too cold will require alonger cooking/heating time, whilst warm food will
require ashorter cooking/heating time.
The temperature, weight and shape of food can significantly affect the
cooking/heating time. If the result is unsatisfactory, set ahigher or lower
food weight.
Delayed start function
The oven enables the cooking/heating process to start at aset time, at aset power
level and for aset time.
Note:
Before setting the delayed start function, check that the clock is correctly
set. If the clock needs adjusting, proceed according to the instructions in
part "Setting the clock".
1. While the oven is in the stand-by mode, repeatedly press button Micro Power B2 to
select the microwave power level. The set power level will appear on the display B1.
2. Turn the control knob B3 to set the cooking/heating time.
3. Press and hold the button Defrost/Clock B4for approximately 3seconds. The hour
digit will start flashing.
4. Use the control knob B3 to set the hours and press button Defrost/Clock B4 to
confirm. The minutes digit will start flashing.
5. Use the control knob B3 to set the minutes and press button Defrost/Clock B4 to
confirm, and the set time will be saved to memory.
6. When the set hour arrives, the microwave oven will start automatically.
Note:
If you need to check the set time, press button Defrost / Clock B4.
Multi-sequence food cooking
To achieve the best results, in certain cases it might be necessary to use various
microwave power output levels. The oven enables up to 4 power levels to be set.
1 While the oven is in the stand-by mode, repeatedly press button Micro Power B2 to
select the microwave power level. The set power level will appear on the display B1.
2. Turn the control knob B3 to set the cooking/heating time.
3. Repeat steps 1 and 2 to set other microwave oven power levels or press button Grill/
Combi B6 and select the grill function. Use the control knob B3 to set the required
cooking/heating time.
4. Press button Instant/Start B8 and the oven will start. The set cooking/heating time
will start counting down on the display B1.
Child safety lock
The child safety lock function enables buttons to be locked to prevent oven settings
from being changed or it being accidentally started when empty.
Activation of the child safety lock: while the oven is in the stand-by mode, hold down
button Pause/Cancel B5 for approx. 3 seconds. All the buttons will be deactivated.
Deactivating the child safety lock: to deactivate the child safety lock, hold don
button Pause/Cancel B5 for approx. 3 seconds.
USING THE CORRECT KITCHEN COOKWARE
1. The ideal type of cookware for cooking in the microwave oven is atransparent
container, which permits the penetration of microwaves inside for the heating of
food.
2. Metal dishes or bowls with ametal rim should not be used, because microwaves
cannot pass through metals.
3. Do not use recycled paper products for cooking in the microwave because they may
contain small metal particles.
4. It is better to use circular or oval containers than square or rectangular containers.
Food located in the corners has atendency to overcook.
5. You should use containers suitable for microwave ovens only in accordance with the
instructions of the manufacturer.
This general list will help you select the right dishes.
Kitchen dishes Safe use Notes
Special plates for
creating acrust
●
Do not use them longer than 8 minutes.
Porcelain and pottery
dishes
●
Porcelain, pottery dishes including glazed
dishes and bone porcelain are suitable if
they do not have metal decorations.
Single use polyester
plates
●
Plates are used for the packaging of some
frozen foods.
- 10 -
05/2021
Copyright © 2021, Fast ČR, a.s.
Kitchen dishes Safe use Notes
Wrapped ready food
• Polystyrene cups
●
May be used to heat foods. Overheating
may cause the polystyrene to melt.
• Paper bags or
newspapers
x
May catch on fire in the oven.
• Recycled paper or
metal edging
x
May cause sparks in the oven.
Glass
• Glass cookware
●
May be used if it doesn't have metal
decorations.
• Fine glass
●
May be used to heat foods and beverages.
Fine glass may crack, if it is suddenly
heated to ahigher temperature.
• Glass jars
●
Remove the lid. Use only for heating.
Metal dishes
• Plates
x
May cause sparks in the oven or food to
catch on fire.
• Metal bag clips
x
Paper dishes
•
Plates, cups,
napkins and kitchen
paper towels
●
Are appropriate for ashort time for
heating and cooking, likewise for the
absorption of excess moisture.
• Recycled paper
x
May cause sparks in the oven.
Plastic dishes
• Dishes
●
Use only heat resistant plastics, other
plastics may due to high temperatures
lose their shape or colour. Do not use
products from melamine.
• Wrapping foils
●
Use to maintain moisture, should not
come into contact with food. When
removing them be careful of the escaping
steam.
• Bags for frozen
foods
▲
Only if intended for cooking or resistant
against high temperatures. Must not be
airtight. If necessary penetrate using afork.
Waxed paper
●
May be used to maintain moisture in foods
and for preventing drops of fat and juices
from spraying.
● recommended use; ▲ limited use; x not recommended;
THE BASICS OF COOKING IN AMICROWAVE OVEN
1. Carefully arrange the food. Place the larger food pieces on the perimeter of the dish.
2. Place the food on an appropriate dish before putting it into the oven. Do not
prepare food directly on the turning tray A5.
3. Set the correct cooking/heating time. We recommend that you set ashorter time
and extend it if necessary. When cooking foods at ahigh temperature, smoke may
be created or afire may start.
4. Cover the food before cooking. This will prevent juices from splashing and food will
be evenly heated.
5. To speed up the heating of certain types of food, e.g. chicken meat or hamburgers,
flip them once during the heating process. Larger pieces of food, e.g. roasts, must be
flipped several times.
6. Certain foods, e.g. meat balls or hamburgers should be arranged both top down as
well as from the centre to the edge.
CLEANING AND MAINTENANCE
Disconnect the power plug from the power socket and allow the appliance to cool
down before cleaning it.
For cleaning, do not use cleaning products with an abrasive effect, solvents, etc. that
could damage the appliance. No part of this appliance is intended for washing in
adishwasher, with the exception of the turning tray A5.
Warning:
To prevent the risk of injury by electrical shock, do not
submerge the appliance, power cord or power plug in water or
any another liquid.
To prevent damaging the operating components of the oven, make sure that during
cleaning, water does not enter the vents located on the sides of the microwave oven.
Keep the microwave oven clean. Clean it regularly according to the instructions below
and remove any food that remains inside it. Failure to do this could damage the surface
of the appliance. This could adversely affect the lifetime of the microwave oven and
result in adangerous situation arising.
Warning:
Do not use steam cleaners to clean the microwave oven.
Prior to first use and during use, regularly clean and wash the turning tray A5. Wash
the turning tray A5 in warm water with asmall amount of kitchen detergent, then
rinse it with clean water and wipe it dry. The turning tray A5 may also be washed in
adishwasher.
In the event that the inside area of the microwave oven is soiled, remove the turning
tray A5 and the carrier A4 and wipe the inner walls using a soft sponge lightly
dampened in warm water. Wipe it with a dry wiping cloth. In the event that the
inner area is heavily soiled, dip the sponge in warm water with asmall amount of
dishwashing detergent. Wipe dry using aclean wiping cloth. Do not use any sprays
or coarse cleaning agents. These could scratch the surface or leave stains and marks.
Regularly clean the turning tray carrier A4 and the base of the inner area to prevent
an increased noise level during operation. Wipe the base of the inner area with asoft
sponge lightly dipped in warm water with asmall amount of dishwashing liquid. Wipe
dry using aclean wiping cloth. Wash the turning tray carrier A4 in warm water with
asmall amount of kitchen detergent, then rinse it with clean water and wipe it dry.
After washing it, insert it back into the microwave oven.
Wipe the external surface, including the door and gasket of the, microwave oven using
sponge lightly dipped in warm water. Wipe dry using aclean wiping cloth.
When cleaning the control panel A5, leave the door slightly ajar to prevent accidentally
turning on the microwave oven while it is empty. Wipe the control panel A5 with adry
wiping cloth. Prevent any water from entering into gaps between the buttons.
If the door fogs up from the inside or the outside, wipe it using aclean, dry wiping
cloth. This is anormal event, especially when preparing food with ahigh water content.
To remove unpleasant odours from the inner area of the microwave oven, in adeep
container mix one cup of water with the juice and peel of one lemon. Set the cooking
time to 5 minutes. Then wipe out the inner area using aclean, dry wiping cloth.
In the event that you need to replace the lighting inside the oven, please contact an
authorised service centre.
An unpleasant odour may develop when the microwave oven is not used for an
extended period of time. To eliminate it, you can:
1. Pour water into alarge glass container and add afew lemon slices. Start the oven at
the maximum power level for 2–3 minutes.
2. Place acup with red tea into the oven and start it at the maximum power level.
3. Place orange peel into alarger bowl and start the oven at the maximum power level
for 1 minute.
Storage
When not using the appliance for an extended period of time, disconnect the power
plug from the power socket, allow the appliance to cool down and clean it according
to the instructions in chapter "Cleaning and maintenance".
Before storing it, check that the appliance and all its accessories are thoroughly clean
and dry.
Store the appliance in adry, clean and well-ventilated location not exposed to extreme
temperatures and out of children'sreach.
BEFORE YOU CONTACT AN AUTHORISED SERVICE CENTRE
Before you contact an authorised service centre, please check the following
recommendations below.
■ Check that the power cord plug is correctly inserted inside apower socket. If not,
pull it out, wait 10 seconds and then plug it back in.
■ Check that the circuit breaker has not been triggered. If everything appears to be
in order, test the power socket by inserting and turning on adifferent appliance.
■ Check that you have chosen the correct program and set the cooking/heating time.
■ Check that the door is properly closed. Otherwise, it will not be possible to start
the oven.
Warning:
If the problem persists, stop using the oven, disconnect the
power plug from the power socket and contact an authorised
service centre. Under no condition should you repair the
microwave oven yourself. It does not contain any parts that the
user can repair themselves.
TECHNICAL SPECIFICATIONS
Rated voltage range .....................................................................................................................230 V~
Rated frequency...............................................................................................................................50 Hz
Rated power input ......................................................................................................................1,280 W
Microwave power output ...........................................................................................................800 W
Grill power.........................................................................................................................................800 W
Operating frequency ........................................................................................................... 2,450 MHz
Noise level ................................................................................................................................... 68 dB(A)
Diameter of the turning tray ...................................................................................................... 27 cm
Volume ...............................................................................................................................17 l (compact)
Outer dimensions ...........................................................................45.1 x 25.8 x 34.4 cm (š x vx h)
Weight ................................................................................................................................... 10.4 kg (net)
The declared noise emission level of the appliance is 68 dB(A), which represents alevel
Aof acoustic power with respect to areference acoustic power of 1pW.
We reserve the right to change text and technical specifications.
- 11 -
05/2021
Copyright © 2021, Fast ČR, a.s.
INSTRUCTIONS AND INFORMATION REGARDING THE
DISPOSAL OF USED PACKAGING MATERIALS
Dispose of used packaging material at asite designated for waste in your municipality.
DISPOSAL OF USED ELECTRICAL AND ELECTRONIC EQUIPMENT
This symbol on products or original documents means that used
electric or electronic products must not be added to ordinary
municipal waste. For proper disposal, renewal and recycling hand over
these appliances to determined collection points. Alternatively, in
some European Union states or other European countries you may
return your appliances to the local retailer when buying an equivalent
new appliance.
Correct disposal of this product helps save valuable natural resources and prevents
potential negative effects on the environment and human health, which could result
from improper waste disposal. Ask your local authorities or collection facility for more
details.
In accordance with national regulations penalties may be imposed for the incorrect
disposal of this type of waste.
For business entities in European Union states
If you want to dispose of electric or electronic appliances, ask your retailer or supplier
for the necessary information.
Disposal in other countries outside the European Union.
This symbol is valid in the European Union. If you wish to dispose of this product,
request the necessary information about the correct disposal method from the local
council or from your retailer.
This product meets all the basic requirements of EU directives related to
it.
