Smeg FD70FN1HM Refrigerator Marble look User Manual

FD70FN1HM

User Manual

Freezer - Fridge

Bedienungsanleitung

Kühl-Gefrierkombination

Manuel d’utilisation

Congélateur – Réfrigérateur

Manuale per l’uso

Congelatore - Frigorifero

Handleiding

Vriezer - Koelkast

EN -2-

EN FIRE Warning; Risk of fire / flammable materials

DE BRANDGEFAHR Warnung; Brandgefahr / entflammbare Materialien

FR INCENDIE

Avertissement; Risque d'incendie / matières

inflammables

IT INCENDIO

Avvertenza; Rischio di incendio / Materiali

infiammabili

NL BRAND

Waarschuwing; Gevaar voor brand / ontvlambare

materialen

EN -3-

INDEX

BEFORE USING THE APPLIANCE ......................................................... 4

General warnings ............................................................................................. 4

Old and out-of-order fridges or freezer ............................................................. 7

Safety warnings ................................................................................................ 7

Installing and operating your fridge freezer ...................................................... 8

Before Using your Fridge ................................................................................. 9

THE VARIOUS FUNCTION AND POSSIBILITIES ................................. 10

Information about New Generation Cooling Technology ................................ 10

Display and Control Panel .............................................................................. 11

Operating your Fridge Freezer ................................................................................ 11

Freezer Temperature Settings ................................................................................. 11

Cooler Temperature Settings ..................................................................................11

Super Freeze Mode ................................................................................................12

Warnings about Temperature Adjustments ..................................................... 13

Accessories .................................................................................................... 14

The Icematic ............................................................................................................14

The Chiller Shelf ......................................................................................................14

The Fresh Dial .........................................................................................................15

Adjustable Door Shelf .............................................................................................15

Adjustable Glass Shelf ............................................................................................15

ARRANGING FOOD IN THE APPLIANCE ............................................ 16

Refrigerator Compartment .............................................................................. 16

Freezer Compartment .................................................................................... 17

CLEANING AND MAINTENANCE ......................................................... 21

TRANSPORTATION AND CHANGING OF INSTALLATION POSITION 22

Repositioning the Door ................................................................................... 22

BEFORE CALLING YOUR AFTER SALES SERVICE ........................... 23

Tips for saving energy .................................................................................... 26

THE PARTS OF THE APPLIANCE AND THE COMPARTMENTS ........ 27

Dimensions ..................................................................................................... 28

TECHNICAL DATA ................................................................................. 29

INFORMATION FOR TEST INSTITUTES ............................................... 29

CUSTOMER CARE AND SERVICE ....................................................... 29

EN -4-

BEFORE USING THE APPLIANCE

General warnings

This appliance is not intended to be used as a built-in appliance.

WARNING: Keep ventilation openings in the appliance

enclosure or in the built-in structure clear of obstruction.

WARNING: Do not use mechanical devices or other means,

other than those recommended by the manufacturer, to

accelerate the defrosting process.

WARNING: Do not use electrical appliances inside the food

storage compartments of the appliance, unless they are of

the type recommended by the manufacturer.

WARNING: Do not damage the refrigerant circuit.

WARNING: To avoid a hazard due to the instability of the

appliance, it must be fixed in accordance with the instructions.

WARNING: When positioning the appliance, ensure the

supply cord is not trapped or damaged.

WARNING: Do not locate multiple portable socket-outlets

or portable power supplies at the rear of the appliance.

If your appliance uses R600a as a refrigerant (you can find

this information on the label on the cooler) be careful during

shipment and installation to prevent your appliance’s cooler

elements from being damaged. Although R600a is a environmental

friendly and natural gas, it is explosive. If the cooler elements

have been damaged and you suspect a leak, move the Fridge

Freezer away from any heat sources or open flame and ventilate

the room the Fridge Freezer is in for a few minutes.

• While carrying and positioning the fridge, do not damage the

cooler gas circuit.

• Do not store explosive substances such as aerosol cans with

a flammable propellant in this appliance.

PART - 1.

EN -5-

• This appliance is intended to be used in household and similar

environments such as:

- staff kitchen areas in shops, offices and other working

environments

- farm houses and by clients in hotels, motels and other

residential type environments

- bed and breakfast type environments

- catering and similar non-retail applications

• If the socket does not match the refrigerator plug, it must

be replaced by the manufacturer, its service agent or similar

qualified persons in order to avoid a hazard.

• This appliance can be used by children aged from 8 years

and above and persons with reduced physical, sensory or

mental capabilities or lack of experience and knowledge if they

have been given supervision or instruction concerning use

of the appliance in a safe way and understand the hazards

involved. Children shall not play with the appliance. Cleaning

and user maintenance shall not be made by children without

supervision.

• Children aged from 3 to 8 years are allowed to load and

unload refrigerating appliances. Children are not expected

to perform cleaning or user maintenance of the appliance,

very young children (0-3 years old) are not expected to use

appliances, young children (3-8 years old) are not expected to

use appliances safely unless continuous supervision is given,

older children (8-14 years old) and vulnerable people can

use appliances safely after they have been given appropriate

supervision or instruction concerning use of the appliance.

Very vulnerable people are not expected to use appliances

safely unless continuous supervision is given.

EN -6-

• A specially grounded plug has been connected to the power

cable of your refrigerator. This plug should be used with a

specially grounded socket of 16 amperes. If there is no such

socket in your house, please have it installed by a qualified

electrician.

• If the supply cord is demaged it must be replaced by the

manufacturer, its service agent or similar qualified persons

in order to avoid a hazard.

• This appliance is not intended for use at altitudes exceeding

2000 m.

To avoid contamination of food, please respect the

following instructions:

• Opening the door for long periods can cause a significant

increase of the temperature in the compartments of the

appliance.

• Clean regularly surfaces that can come in contact with food

and accessible drainage systems.

• Store raw meat and fish in suitable containers in the

refrigerator, so that it is not in contact with or drip onto other

food.

• Two-star frozen-food compartments are suitable for storing

pre-frozen food, storing or making ice cream and making ice

cubes.

• One-, two- and three-star compartments are not suitable for

the freezing of fresh food.

• If the refrigerating appliance is left empty for long periods,

switch off, defrost, clean, dry, and leave the door open to

prevent mould developing within the appliance.

EN -7-

Old and out-of-order fridges or freezer

• If your old fridge or freezer has a lock, break or remove the lock before discarding it,

because children may get trapped inside it and may cause an accident.

• Old fridges and freezers contain isolation material and refrigerant with CFC. Therefore,

take care not to harm environment when you are discarding your old fridges.

Disposal of your old appliance

The symbol on the product or on its packaging indicates that this product may not

be treated as household waste. Instead it shall be handed over to the applicable

collection point for the recycling of electrical and electronic equipment. By ensuring

this product is disposed of correctly, you will help prevent potential negative

consequences for the environment and human health, which could otherwise

be caused by inappropriate waste handling of this product. For more detailed

information about recycling of this product, please contact your local city office, your household

waste disposal service or the shop where you purchased the product.

Notes:

• Please read the instruction manual carefully before installing and using your appliance.

We are not responsible for the damage occurred due to misuse.

• Follow all instructions on your appliance and instruction manual, and keep this manual

in a safe place to resolve the problems that may occur in the future.

• This appliance is produced to be used in homes and it can only be used in domestic

environments and for the specified purposes. It is not suitable for commercial or common

use. Such use will cause the guarantee of the appliance to be cancelled and our company

will not be responsible for the losses to be occurred.

• This appliance is produced to be used in houses and it is only suitable for cooling / storing

foods. It is not suitable for commercial or common use and/or for storing substances

except for food. Our company is not responsible for the losses to be occurred in the

contrary case.

Safety warnings

• Do not connect your fridge freezer to the mains electricity supply using

an extension lead.

• Do not use damaged, torn or old plugs.

• Do not pull, bend or damage the cord.

• Do not use plug adapter.

• This appliance is designed for use by adults. Do not allow children to

play with the appliance or hang off the door.

• Never touch the power cord/plug with wet hands. This may cause a short

circuit or electric shock.

EN -8-

• Do not place glass bottles or cans in the ice-making compartment as

they will burst when the contents freeze.

• Do not place explosive or flammable material in your fridge. Place drinks

with high alcohol content vertically in the fridge compartment and make

sure their tops are tightly closed.

• When removing ice from the ice-making compartment, do not touch it. Ice may

cause frost burns and/or cuts.

• Do not touch frozen goods with wet hands. Do not eat ice-cream or ice cubes

immediately after they are removed from the ice-making compartment.

• Do not re-freeze thawed frozen food. This may cause health issues such as food

poisoning.

Installing and operating your fridge freezer

Before using your fridge freezer for the first time, please pay attention to the following points:

• The operating voltage for your fridge freezer is 220-240 V at 50Hz.

• The plug must be accessible after installation.

• Your fridge freezer may have an odour when it is operated for the first time. This is normal

and the odour will fade when your fridge freezer starts to cool.

• Before connecting your fridge freezer, ensure that the information on the data plate

(voltage and connected load) matches that of the mains electricity supply. If in doubt,

consult a qualified electrician.

• Insert the plug into a socket with an efficient ground connection. If the socket has no

ground contact or the plug does not match, we recommend you consult a qualified

electrician for assistance.

• The appliance must be connected with a properly installed fused socket. The power

supply (AC) and voltage at the operating point must match with the details on the name

plate of the appliance (the name plate is located on the inside left of the appliance).

• We do not accept responsibility for any damages that occur due to ungrounded usage.

• Place your fridge freezer where it will not be exposed to direct sunlight.

• Your fridge freezer must never be used outdoors or exposed to rain.

• Your appliance must be at least 50 cm away from stoves, gas ovens and heater cores,

and at least 5 cm away from electrical ovens.

• If your fridge freezer is placed next to a deep freezer, there must be at least 2 cm between

them to prevent humidity forming on the outer surface.

• Do not cover the body or top of fridge freezer with lace. This will affect the performance

of your fridge freezer.

• Clearance of at least 150 mm is required at the top of your appliance. Do

not place anything on top of your appliance.

• Do not place heavy items on the appliance.

• Use the adjustable front legs to make sure your appliance is level and stable.

You can adjust the legs by turning them in either direction. This must be

done before placing food in the appliance.

• Clean the appliance thoroughly before use (see Cleaning and Maintenance).

EN -9-

• Before using your fridge freezer, wipe all parts with a solution of warm water and a

teaspoon of sodium bicarbonate. Then, rinse with clean water and dry. Return all parts

to the fridge freezer after cleaning.

If your refrigerator includes a fan condenser

The condenser of your fridge is placed at the bottom

of cabinet. As a result of that, assemble the spacer

by fixing it to holes on the cover bottom panel and

turn 90° that’s shown below figure for arranging the

distance between the refrigerator and the back wall at

where you place the fridge. You can move the fridge

towards the back wall until that point.

The distance between the appliance and back wall

must be a maximum of 75 mm.

Before Using your Fridge

• When using your fridge for the first time, or after transportation, keep it

in an upright position for at least 3 hours before plugging into the mains.

This allows efficient operation and prevents damage to the compressor.

• Your fridge may have a smell when it is operated for the first time. This is normal and

the smell will fade away when your fridge starts to cool.

Plastic for distance setting

General notes:

Fresh Food Compartment (Fridge): Most efficient use of energy is ensured in the configuration

with the drawers in the bottom part of the appliance, and shelves evenly distributed, position

of door bins does not affect energy consumption.

Freezer Compartment (Freezer): Most Efficient use of energy is ensured in the configuration

with the drawers and bins are on stock position.

Internal lighting

WARNING!

Risk of electric shock.

• Concerning the lamp(s) inside this product and spare part lamps sold separately: These

lamps are intended to withstand extreme physical conditions in household appliances,

such as temperature, vibration, humidity, or are intended to signal information about the

operational status of the appliance. They are not intended to be used in other applications

and are not suitable for household room illumination.

EN -10-

THE VARIOUS FUNCTION AND POSSIBILITIES

Information about New Generation Cooling Technology

Fridges with new-generation cooling technology have a different

operating system to static fridges. Other (static) fridges may

experience a build up of ice in the freezer compartment due to

door openings and humidity in the food. In such fridges, regular

defrosting is required; the fridge must be switched off, the frozen

food moved to a suitable container and the ice which has formed

in the freezer compartment removed.

In fridges with new-generation cooling technology, a fan blows dry

cold air evenly throughout the fridge and freezer compartments. The

cold air cools your food evenly and uniformly, preventing humidity

and ice build-up.

In the refrigerator compartment, air blown by the fan, located at

the top of the refrigerator compartment, is cooled while passing

through the gap behind the air duct. At the same time, the air is

blown out through the holes in the air duct, evenly spreading cool

air throughout the refrigerator compartment.

There is no air passage between the freezer and refrigerator

compartments, therefore preventing the mixing of odours.

As a result, your fridge, with new-generation cooling technology,

provides you with ease of use as well as a huge volume and

aesthetic appearance.

PART - 2.

EN -11-

Display and Control Panel

Using the Control Panel

1. Enables the setting of the freezer.

2. Enables the setting of the cooler.

3. Freezer set value screen.

4. Cooler set value screen.

5. Economy mode symbol.

6. Super freeze symbol.

7. Alarm symbol.

Operating your Fridge Freezer

Once you have plugged in the product, all symbols will be displayed for 2 seconds and the

initial values will be shown as -18 °C on the freezer adjustment indicator, and +4 °C on the

fridge adjustment indicator.

Freezer Temperature Settings

• The initial temperature value for the freezer setting indicator is -18 °C.

• Press the freezer set button once.

When you first press the button, the previous value will blink on the screen.

• Whenever you press the same button, a lower temperature will be set (-16 °C, -18 °C,

-20 °C, -22 °C or -24 °C).

• If you continue to press the button, it will restart from -16 °C.

NOTE: Eco mode gets activated automatically when the temperature of the freezer

compartment is set to -18°C.

Cooler Temperature Settings

• The initial temperature value for the cooler setting indicator is +4 °C.

• Press the cooler button once.

• Whenever you press the button, a lower temperature will be set (+8 °C, +6 °C, +5 °C,

+4 °C, or +2 °C).

• If you continue to press the button, it will restart from +8 °C.

3 5 6 7 4

1 2

EN -12-

Super Freeze Mode

Purpose

• To freeze a large quantity of food that cannot fit on the fast freeze shelf.

• To freeze prepared foods.

• To freeze fresh food quickly to retain freshness.

How to use

To enable the super freeze mode, press and hold the freezer temperature setting

button for 3 seconds. Once the super freeze mode has been set, the super freeze

symbol on the indicator will be lit and the machine will beep to confirm the mode has been

switched on.

During Super Freeze Mode:

• The temperature of the Cooler may be adjusted. In this case, Super Freeze mode will

continue.

• Economy mode cannot be selected.

• Super Freeze mode can be cancelled in the same way it is selected.

Notes:

• The maximum amount of fresh food (in kilograms) that can be frozen within 24 hours is

shown on the appliance label.

• For optimal appliance performance in maximum freezer capacity, activate super freeze

mode 3 hours before you put fresh food into the freezer.

Super freeze mode will automatically cancel after 24 hours, depending on the

environmental temperature or when the freezer sensor reaches a sufficiently low

temperature.

Recommended Settings for the Freezer and Cooler Compartment Temperature

Freezer

Compartment

Cooler

Compartment

Remarks

-18

C 4

C For regular use and best performance.

-20

C, -22

or -24

C Recommended when environmental temperature exceeds 30 °C.

Super Freeze

mode

C Must be used when you wish to freeze food in a short period of time.

-18

C, -20

-22

C or

-24

These temperature settings must be used when the environmental temperature

is high or if you think the refrigerator compartment is not cool enough becuse

the door is being opened frequently.

Door Open Alarm Function

If the refrigerator door is opened more than 2 minutes, appliance sounds ‘beep beep’.

EN -13-

Warnings about Temperature Adjustments

• Temperature adjustments should be made according to the frequency of door openings

and the quantity of food kept inside the fridge.

• This fridge is designed to work in all ambient temperature. In the ambient temperatures

colder than -5

C, preserving food in the refrigerator compartment isn’t suggested

because the foods that you put into refrigerator compartment, will have a temperature

close to ambient temperature. Consequently, they will freeze. You can keep your foods

until -5

C in refrigerator compartments. With the aid of special algorithm that is designed

by engineers, foods can be preserved in the freezer compartment, colder than -5

ambient temperature.

• Your fridge should be operated up to 24 hours according to the ambient temperature

without interruption after being plugged in to be completely cooled. Do not open doors

of your fridge frequently and do not place much food inside it in this period.

• If the unit is switched off or unplugged, you must allow at least 5 minutes before restarting

or re-plugged the unit in order not to damage the compressor.

• Your fridge is designed to operate in the ambient temperature intervals stated in the

standards, according to the climate class stated in the information label. We do not

recommend operating your fridge out of stated temperatures value limits in terms of

cooling effectiveness.

• This appliance is designed for use at an ambient temperature within the 10°C - 43°C

range.

Climate class and meaning:

T (tropical): This refrigerating appliance is intended to be used at ambient temperatures ranging from

16 °C to 43 °C.

ST (subtropical): This refrigerating appliance is intended to be used at ambient temperatures ranging

from 16 °C to 38 °C.

N (temperate): This refrigerating appliance is intended to be used at ambient temperatures ranging

from 16 °C to 32 °C.

SN (extended temperate): This refrigerating appliance is intended to be used at ambient temperatures

ranging from 10 °C to 32 °C.

EN -14-

Accessories

The Icematic

• Pull the lever towards you and remove the

ice maker tray

• Fill with water to the marked level

• Hold the left end of the lever and set the

ice-tray on the icebox

• When ice cubes have formed, twist the lever

to drop the ice cubes into the icebox.

Note:

Do not fill the icebox with water in order to make ice. It can be broken.

The movement of the ice maker may be difficult while the refrigerator is running. In such

a case should be cleaned by removing the glass shelves.

Removing the icemaker

• Take out of the freezer glass shelves

• Remove the icemaker by dragging left or

right on the shelf.

You can remove the icemaker to use a larger

volume of the freezer compartment.

The Chiller Shelf

Keeping food in the Chiller compartment, instead

of the freezer or refrigerator compartments, allows

food to retain freshness and flavour for longer, while

preserving its fresh appearance. When the Chiller

tray becomes dirty, remove it and wash with water.

(Water freezes at 0°C, but food containing salt or

sugar freezes at temperatures lower than this).

The Chiller compartment is usually used for storing

foods such as raw fish, lightly pickled food, rice, and

so on.

Do not put food you want to freeze or ice trays (to make ice) in the Chiller

compartment.

To remove the Chiller Shelf:

• Pull the chiller shelf towards you by sliding it

on the rails.

• Pull the chiller shelf up from the rail and remove

it from the fridge.

After the chiller shelf is removed, there will be

space for up to 20kg of food to be placed in the

fridge.

Chiller shelf

(In some models)

EN -15-

The Fresh Dial

If the crisper is full, the fresh dial located in front of the

crisper should be opened. This allows the air in the

crisper and the humidity rate to be controlled, to increase

the life of food within.

The dial, located behind the shelf, must be opened if any

condensation is seen on the glass shelf.

Fresh dial

Adjustable Door Shelf

Six different height adjustments can be made to provide storage areas

that you need by adjustable door shelf.

To change the position of adjustable door shelf ;

Hold the bottom of the shelf and pull the buttons on the side of the door

shelf direction of arrow. (Fig.1)

Position door shelf the height you need by moving up and down. After

you get the position that you want the door shelf, release the buttons

on the side of the door shelf (Fig.2) Before releasing the door shelf,

move up down and make sure the door shelf is fixed.

Note: Before moving door shelf is loaded, you must hold the shelf

by supporting the bottom. Otherwise, door shelf could fall off the

rails due to the weight. So damage may occur on the door shelf or rails.

Fig. 1

Fig. 2

(In some models)

Visual and text descriptions in the accessories section may vary according

to the model of your appliance.

Adjustable Glass Shelf

Adjustable glass shelf mechanism provides

higher storage spaces with a simple movement.

To cover the glass shelf, push it.

You can load your food as you want in the

resulting extra space. To bring the shelf in its

original position, pull it toward you.

Fig. 1

Fig. 2

(In some models)

EN -16-

Refrigerator Compartment

It is sufficient to set the fridge thermostat to position ‘2’ or ‘3’ for normal operatingconditions.

• To reduce humidity and avoid the consequent formation of frost, always store liquids in

sealed containers in the refrigerator. Frost tends to concentrate in the coldest parts of

the evaporating liquid and, in time, your appliance will require more frequent defrosting.

• Never place warm food in the refrigerator. Warm food should be allowed to cool at room

temperature and should be arranged to ensure adequate air circulation in the refrigerator

compartment.

• Make sure no items are in direct contact with the rear wall of the appliance as frost will

develop and packaging will stick to it. Do not open the refrigerator door frequently.

• We recommend that meat and clean fish are loosely wrapped and stored on the glass

shelf just above the vegetable bin where the air is cooler, as this provides the best

storage conditions.

• Store loose fruit and vegetable items in the crisper containers.

• Store loose fruit and vegetables in the crisper.

• Storing fruit and vegetables separately helps prevent ethylene-sensitive vegetables

(green leaves, broccoli, carrot, etc.) being affected by ethylene-releaser fruits (banana,

peach, apricot, fig etc.).

• Do not put wet vegetables into the refrigerator.

• Storage time for all food products depends on the initial quality of the food and an

uninterrupted refrigeration cycle before refrigerator storage.

• To avoid cross-contamination do not store meat products with fruit and vegetables.

Water leaking from meat may contaminate other products in the refrigerator. You should

package meat products and clean any leakages on the shelves.

• Do not put food in front of the air flow passage.

• Consume packaged foods before the recommended expiry date.

• For normal working conditions, it will be sufficient to adjust the temperature setting of

your refrigerator to +4 °C.

• The temperature of the fridge compartment should be in the range of 0-8 °C, fresh foods

below 0 °C are iced and rotted, bacterial load increases above 8 °C, and spoils.

• Do not put hot food in the refrigerator immediately, wait for the temperature to pass

outside. Hot foods increase the degree of your refrigerator and cause food poisoning

and unnecessary spoiling of the food.

• Meat, fish, etc. should be store in the chiller compartment of the food, and the vegetable

compartment is preferred for vegetables. (if available)

• To prevent cross contamination, meat products and fruit vegetables are not stored

together.

• Foods should be placed in the refrigerator in closed containers or covered to prevent

moisture and odors.

ARRANGING FOOD IN THE APPLIANCE PART - 3.

EN -17-

IMPORTANT NOTES:

Potatoes, onions and garlic should not be stored in the

refrigerator.

Cooked dishes must remain covered when they are

kept in the fridge. Place them in the fridge when they

are cool, otherwise the temperature/humidity inside the fridge

will increases, reducing the fridge’s efficiency. Covering food

and drink also preserves their flavour and aroma.

Do not allow food to come into contact with the

temperature sensor, which is located in the refrigerator

compartment, in order to keep the refrigerator compartment

at optimum temperature.

The table below is a quick guide to show you the most efficient way to store the major food

groups in your refrigerator compartment.

Food Maximum storage time How and where to store

Vegetables and fruits 1 week Vegetable bin

Meat and fish 2 - 3 Days

Wrap in plastic foil, bags, or in a meat

container and store on the glass shelf

Fresh cheese 3 - 4 Days On the designated door shelf

Butter and margarine 1 week On the designated door shelf

Bottled products e.g.

milk and yoghurt

Until the expiry date

recommended by the

producer

On the designated door shelf

Eggs 1 month On the designated egg shelf

Cooked food All shelves

Freezer Compartment

• The freezer is used for storing frozen food, freezing fresh food, and making ice cubes.

• For freezing fresh food; wrap and seal fresh food properly, that is the packaging should

be air tight and shouldn’t leak. Special freezer bags, aluminum foil polythene bags and

plastic containers are ideal.

• Do not store fresh food next to frozen food as it can thaw the frozen food.

• Before freezing fresh food, divide it into portions that can be consumed in one sitting.

• Consume thawed frozen food within a short period of time after defrosting

• Never place warm food in the freezer compartment as it will thaw the frozen food.

• Always follow the manufacturer's instructions on food packaging when storing frozen

food. If no information is provided food, should not be stored for more than 3 months

from the date of purchase.

• When purchasing frozen food, make sure that it has been stored under appropriate

conditions and that the packaging is not damaged.

• Frozen food should be transported in appropriate containers and placed in the freezer

as soon as possible.

Temperature sensor area

EN -18-

• Do not purchase frozen food if the packaging shows signs of humidity and abnormal

swelling. It is probable that it has been stored at an unsuitable temperature and that

the contents have deteriorated.

• The storage life of frozen food depends on the room temperature, the thermostat setting,

how often the door is opened, the type of food, and the length of time required to transport

the product from the shop to your home. Always follow the instructions printed on the

packaging and never exceed the maximum storage life indicated.

• The maximum amount of fresh food (in kg) that can be frozen in 24 hours is indicated

on the appliance label.

• To freeze fresh food, ensure that as much of the surface of the food as possible is in

contact with the cooling surface.

• For optimum appliance performance to reach maximum freezing capacity, turn the

thermostat knob to the coldest setting 24 hours before placing fresh food in the freezer.

• It is generally sufficient to set the thermostat to the coldest setting for a further 24 hours

after placing the fresh food in the freezer. After this time, reduce the thermostat knob

setting if required.

• Attention. To save energy, if you are only freezing small amounts of food, do not set the

thermostat knob to the coldest setting.

In some models: While loading the freezer compartment, do not fill above

the guidelines otherwise the door will not close properly. If the freezer

compartment door does not close properly, excess ice will form in the freezer

compartment. To prevent the problem recurring, clear the ice and make

sure the door is fully closed.

Also, not closing the freezer and/or fridge compartment doors will increase

your energy consumption.

If the lower shelf of the freezer door is removed and

food obstructs the air suction hole, the efficiency of

your fridge will reduce.

Therefore, take care while loading the freezer

compartment and make sure not to cover the air

suction hole.

Important note:

• Never refreeze thawed frozen food.

• The taste of some spices found in cooked dishes (anise, basilica, watercress, vinegar,

assorted spices, ginger, garlic, onion, mustard, thyme, marjoram, black pepper, etc.)

changes and they assume a strong taste when they are stored for a long period of time.

Therefore, add small amounts of spices to food to be frozen, or the desired spice should

be added after the food has thawed.

Air suction hole

EN -19-

• The storage time of food is dependent on the type of oil used. Suitable oils are margarine,

calf fat, olive oil and butter. Unsuitable oils are peanut oil and pig fat.

• Food in liquid form should be frozen in plastic cups and other food should be frozen in

plastic folios or bags.

The table below is a quick guide to show you the most efficient way to store the major

food groups in your freezer compartment.

Meat and fish Preparation

Maximum storage time

(months)

Steak Wrap in foil 6 - 8

Lamb meat Wrap in foil 6 - 8

Veal roast Wrap in foil 6 - 8

Veal cubes In small pieces 6 - 8

Lamb cubes In pieces 4 - 8

Minced meat In packaging without using spices 1 - 3

Giblets (pieces) In pieces 1 - 3

Bologna sausage/

salami

Should be kept packaged even if it has a

membrane

Chicken and turkey Wrap in foil 4 - 6

Goose and duck Wrap in foil 4 - 6

Deer, rabbit, wild

boar

In 2.5 kg portions or as fillets 6 - 8

Freshwater fish

(Salmon, Carp,

Crane, Catfish)

After cleaning the bowels and scales of the

fish, wash and dry it. If necessary, remove the

tail and head.

Lean fish (Bass,

Turbot, Flounder)

Fatty fishes (Tuna,

Mackerel, Bluefish,

Anchovy)

2 - 4

Shellfish Clean and in a bag 4 - 6

Caviar

In its packaging, or in an aluminium or plastic

container

2 - 3

Snails

In salty water, or in an aluminium or plastic

container

NOTE: Thawed frozen meat should be cooked as fresh meat. If the meat is not cooked after

defrosting, it must not be re-frozen.

Vegetables and Fruits Preparation

Maximum storage time

(months)

String beans and

beans

Wash, cut into small pieces and boil in water 10 - 13

Beans Hull, wash and boil in water 12

EN -20-

Vegetables and Fruits Preparation

Maximum storage time

(months)

Cabbage Clean and boil in water 6 - 8

Carrot Clean, cut into slices and boil in water 12

Pepper

Cut the stem, cut into two pieces, remove the

core and boil in water

8 - 10

Spinach Wash and boil in water 6 - 9

Cauliflower

Remove the leaves, cut the heart into pieces

and leave it in water with a little lemon juice

for a while

10 - 12

Eggplant Cut into pieces of 2cm after washing 10 - 12

Corn Clean and pack with its stem or as sweet corn 12

Apple and pear Peel and slice 8 - 10

Apricot and Peach Cut into two pieces and remove the stone 4 - 6

Strawberry and

Blackberry

Wash and hull 8 - 12

Cooked fruits Add 10 % of sugar to the container 12

Plum, cherry,

sourberry

Wash and hull the stems 8 - 12

Maximum storage

time (months)

Thawing time at

room temperature

(hours)

Thawing time in oven

(minutes)

Bread 4 - 6 2 - 3 4-5 (220-225 °C)

Biscuits 3 - 6 1 - 1,5 5-8 (190-200 °C)

Pastry 1 - 3 2 - 3 5-10 (200-225 °C)

Pie 1 - 1,5 3 - 4 5-8 (190-200 °C)

Phyllo dough 2 - 3 1 - 1,5 5-8 (190-200 °C)

Pizza 2 - 3 2 - 4 15-20 (200 °C)

Dairy products Preparation

Maximum storage

time (months)

Storage conditions

Packet

(Homogenized) Milk

In its own packet 2 - 3

Pure Milk – in its own

packet

Cheese - excluding

white cheese

In slices 6 - 8

Original packaging may

be used for short-term

storage. Keep wrapped in

foil for longer periods.

Butter, margarine In its packaging 6

EN -21-

CLEANING AND MAINTENANCE

Disconnect the unit from the power supply before cleaning.

Do not wash your appliance by pouring water on it.

Do not use abrasive products, detergents or soaps for cleaning the

appliance. After washing, rinse with clean water and dry carefully. When

you have finished cleaning, reconnect the plug to the mains supply with dry

hands.

• Make sure that no water enters the lamp housing and other electrical components.

• The appliance should be cleaned regularly using a solution of bicarbonate

of soda and lukewarm water.

• Clean the accessories separately by hand with soap and water.

Do not wash accessories in a dish washer.

• Clean the condenser with a brush at least twice a year.

This will help you to save on energy costs and increase

productivity.

The power supply must be disconnected during cleaning.

PART - 4.

EN -22-

Replacing LED Lighting

Depending on the model, one LED strip in the freezer

compartment and two LED strips in the cooler compartment

are used to illuminate the interior of your appliance.

To replace any of the LEDs, please contact the nearest

Authorised Service Centre.

Note: The numbers and location of the LED strips may

change according to the model.

Some versions may not include freezer illumination.

Freezer compartment

LED strip light

Fridge compartment

LED strip light

TRANSPORTATION AND CHANGING OF

INSTALLATION POSITION

Transportation and Changing Positioning

• The original packaging and foam may be kept for re-transportation (optional).

• Fasten your appliance with thick packaging, bands or strong cords and follow the

instructions for transportation on the packaging.

• Remove all movable parts (shelves, accessories, vegetable bins, and so on) or fix them

into the appliance against shocks using bands when re-positioning or transporting.

Always carry your appliance in the upright

position.

PART - 5.

Repositioning the Door

• It is not possible to change the opening direction of your appliance door if door handles

are installed on the front surface of the appliance door.

• It is possible to change the opening direction of the door on models without handles.

• If the door-opening direction of your appliance can be changed, contact the nearest

Authorised Service Centre to change the opening direction.

EN -23-

BEFORE CALLING YOUR AFTER SALES SERVICE

PART - 6.

Errors

Your fridge will warn you if the temperatures for the cooler and freezer are at improper levels

or if a problem occurs with the appliance. Warning codes are displayed in the freezer and

cooler indicators.

ERROR TYPE MEANING WHY WHAT TO DO

E01 Sensor warning
