Element EL168WCSTL by Vinotemp 24 Inch Stainless Steel Wine Cooler

User Manual

For EL168WCSTL.

PDF File Manual, 24 pages, Read Online | Download pdf file

EL168WCSTL photo
background
Loading page 2...
Loading page 3...
Loading page 4...
Loading page 5...
Loading page 6...
Loading page 7...
Loading page 8...
Loading page 9...
Loading page 10...
Loading page 11...
Loading page 12...
Loading page 13...
Loading page 14...
Loading page 15...
Loading page 16...
Loading page 17...
Loading page 18...
Loading page 19...
Loading page 20...
Loading page 21...
Loading page 22...
Loading page 23...
Loading page 24...

Other documents for Element EL168WCSTL

The following documents are available:
User Manual Other Documents
  • bottlecapacitychart - (English) Download
  • ConnoisseurSeries FeaturesChart Revised V3 - (English) Download
Energy Guide
  • EL 168WCST EnergyGuideLabel - (English) Download
Specification Photos

Specifications

User Manual - Transcript

  • Page 12 - English - : the unit has run for a few hours If the unit is unplugged has lost power or is turned off wait 3 to 5 minutes before restarting the unit The unit will not restart before this time delay STORING WINE Note Bottle capacities are approximate maximums when storing traditional Bordeaux 750 ML bottles and may include bulk storage Many bottles differ in size and dimensions As such the actual number of bottles you may be able to store may vary When adding a bottle to the wine cooler make sure there is no contact with the ba ck interior of t he cooler Ensure that no bottles are placed directly onto the electronic board of the control panel Always place bottles on the shelves only To avoid damage to the shelves and ensure the cooler maintains a consistent temperature do not overfill the wine cooler SHELVES To prevent damaging the door gasket make sure the door is fully open when pulling shelves out of the rail compartment For easy access to the bottles stored pull the shelves out approximately 13 The shelves are designed with an emergen cy stop to prevent them being removed too far when loaded The shelves has been designed so that a range of shelf height can be selected All the shelves can be adjusted NOTE When using the unit for the first time or after a long period of inactivity there may be a variance of a few degrees between the selected temperature and the temperature indicated on the LED readout This is normal due to the length of inactivity and will correct itself after SETTING A TEMPERATURE Choose between Celsius and Fahrenheitby pushing the button The temperature will now display in Celsius or Fahrenheit If setting the temperature press the button first You can then select the UP or DOWN buttons to change the temperature in one degree increments When pushing either buttons for the first time the readout will show the original temperature set Pressing the UP button will increase the temperature by 1 degree Pressing the DOWN button will decrease the temperature by 1 degree
