ET-1
10/20
Star
Washer
Stud
or
Nipple
Cap
Nut
STYLE#1
STYLE#2
Tel: (613) 342-5424, Fax: (800) 263-4598
Glass
(Optional)
Spinner Nut
Fixture
Socket
Special
Tool
STYLE#1
STYLE#2
STYLE#3
Fixture
Socket
Glass
Shade
Or
Finishing
Screws
Glass
Fixture
Bracket
Screw
EASY CONNECT
INSTALLATION INSTRUCTIONS
TM
L
N
STYLE #1
STYLE #2
TOOLS AND MATERIALS REQUIRED:
Phillips
Screwdriver
Wire Cutters
INSTALLATION:
L
N
L
N
Fixture
Option 1
Option 2
Black (Live)
White
(Neutral)
Green (Ground)
(L)
Black
(Live)
(L)
Black (Live)
(L)
Black (Live)
(N)
White
(Neutral)
(N)
White
(Neutral)
(N)
White
(Neutral)
Green
(Ground)
Green
(Ground)
Green
(Ground)
Jumper Wire
Jumper
Wire
Jumper Wire
Electrical
box screws
Electrical
Box
L
N
L
N
Easy Connect
mounting
bracket
TM
Bulb
Decorative
ring
1. Attach Easy Connect™
mounting bracket to electrical
box with electrical box screws
(not included).
2. Option 1: Connect (push)
electrical wires from electric box
(house wiring) into correct
inserts.
Option 2: For multiple green
(ground), black (live) and
white (neutral) wires joined in
the electrical box (house wiring),
attach a single “green”, “black”
and “white” jumper wire before
connecting. Strip 7mm from the
6” jumper wires supplied. Then
connect (push) wires into the
correct inserts.
3. Connect (push) electrical
wires from fixture into correct
inserts.
Optional for some models
(Note: Refer to the style
of assembly that matches the
style of your fixture.)
4.
STYLE#1- Tuck electrical
wires into electrical box and
position fixture over studs or
nipple on mounting bracket
assembly. Secure fixture in place
with star washer(s) and cap
nut(s).
Note: If required, assemble body
and spread the arms of the
fixture out evenly.
STYLE #2 - Attach fixture to
mounting bracket by tightening
the 2 screws.
5.
Style#1
-
Remove spinner
nut from the socket. Place the
glass onto the fixture socket. Use
the special tool that comes with
your fixture to tighten the
spinner nut onto the socket to
secure the glass in place.
Style#2
- Install proper bulb
type and wattage. Remove the
finishing screws that are already
on your fixture. Position glass in
place and secure with finishing
screws.
Style#3
-
Install proper bulb
type and wattage (not
included).
Install decorative
ring.
Fixture
SAFETY PRECAUTIONS:
!
INSTRUCTIONS PERTAINING TO RISK OF FIRE OR INJURY TO PERSONS
READ ALL INSTRUCTIONS
IMPORTANT SAFETY
INSTRUCTIONS
SAVE THESE INSTRUCTIONS
1. TURN OFF ELECTRICAL POWER BEFORE STARTING INSTALLATION
OF LIGHT FIXTURE.
2. WIRING SUPPLIES AS REQUIRED BY LOCAL ELECTRICAL CODE.
3. THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE
APPLICABLE INSTALLATION CODE BY A PERSON FAMILIAR WITH
THE CONSTRUCTION AND OPERATION OF THE PRODUCT AND THE
HAZARDS INVOLVED.
4. TO CLEAN THE FIXTURE, TURN OFF THE POWER, WAIT FOR IT TO
COOL, AND WIPE THE FIXTURE WITH A CLEAN, SOFT CLOTH.
NOTE: Product may not look exactly as shown in figures.
WARNING
Warning - HOT :
Do not touch any metal surface.
!
