Instruction
Sheet
for
Evaporator
Drain
Tray
Assembly
Installation
cacor
Refrigerator
Models:
EF42BDCB, EF48BDCB, EF42BNDB,
EF48BNDB,
IF42BDCB,
IF48BDCB,
IF42BNDB,
IF48BNDB
Kit
Part
Numbers:
W10199913
(42-Inch
models),
W10199915
(48-Inch
models)
AWARNING
Electrical
Shock
Hazard
Disconnect
power
before
servicing.
Replace
all
parts
and
panels
before
operating.
Failure
to
do
so
can
result
in
death
or
electrical
shock.
Kit
Contains:
1
Clip
6
Sealer-Gum
(Butyl)
1
Clamp
1
Evaporator
Drain
Tray
Assembly
1
Drain
Tube
1.
Instruction
Sheet
Standard
product
manufacturing
warranty
applies.
IMPORTANT:
Evaporator
Drain
Tray
Freeze
Up
Issue
in
2003
thru
2007
production
—
Creates
internal
water
leak
from
ceiling
of
freezer
causing
water
and
ice
to
accumulate
on
the
ceiling,
door
and
seals
of
freezer.
Can
also
cause
a
no
cool
situation,
a
noise
issue
when
ice
forms
blocking
evaporator
motor
and
blade,
or
damper
diffuser
failure.
NOTE:
All
steps
must
be
followed
for
a
proper
repair.
1.
Remove
top
grille.
2.
‘Turn
off
power.
See
Figure
7.
POWER
SWITCH
FIGURE
1
3.
Remove
evaporator
cover and
components
in
order
to
access
the
evaporator
drain
tray.
Remove
evaporator
drain
tray.
5.
Clear
any
remaining
ice
off
the
evaporator
and
on
the
back
wall.
6.
On
the
left
side
of
the
evaporator,
remove
and
discard
the
piece
of
foam.
It
will
not
be
needed.
See
Figure
2.
NOTE:
The
foam
piece
might
come
off
the
evaporator
and
be
stuck
on
the
old
evaporator
drain
tray
when
removed.
FOAM
PIECE
FIGURE
2
7.
Locate
and
unplug
evaporator
defrost
thermistor
at
the
connector.
The
defrost
thermistor
is
mounted
on
the
evaporator.
Follow
wire
and
disconnect
at
the
connector.
Leave
the
defrost
thermistor
permanently
disconnected.
See
Figure
3.
NOTE:
This
will
initiate
a
6
hour
defrost
cycle
time,
keeping
the
evaporator
clear
from
any
ice
build
up.
IMPORTANT:
Do
not
disconnect
the
Defrost
Bi-Metal.
DEFROST
THERMISTOR
CONNECTOR
FIGURE
3
Part
No.
106405
Rev.B
12/08
page
1
of
2
